Process Automation Festo Didactic

(1)

Qualification solutions

for process automation

(2)

2 Worldwide at your ﬁngertips. Find your contact person at: www.festo-didactic.com Process automation

Professional, industry-focused qualification solutions

for process automation

Networked system

With 3 or 4 stations

Measurement and control of level, flow rate, pressure and temperature

Compact Workstation

Measurement and control of level, flow rate, pressure and temperature

MPS

®

_PA

The new learning system for process automation

Filtering, mixing, tempering and filling as in industry

(3)

3 www.festo-didactic.com

Process automation

Few industries have as many fac-ets or are as interesting as the proc-ess industry, which produces a wide range of products for the most di-verse areas of daily life.

On the one hand, the chemical indus-try produces preliminary products for other industries. This group in-cludes base chemicals, petrochemi-cals, polymers as well as refined and special chemicals. Key consumers in-clude the automotive, packaging and building industries.

On the other hand, chemical prod-ucts are used in the areas of health, the environment and nutrition. As well as the chemical and pharmaceu-tical industry, the process industry includes other sectors such as the biotechnology, paper and food in-dustries.

Even though the end products may differ, automation is making huge leaps forward in each of these ar-eas. International competition and the resultant pressure to continu-ally increase productivity as well as a continuously expanding range of variants and strict requirements for process and quality assurance de-mand automation solutions.

(4)

4 www.festo-didactic.com Process automation

Filtering, mixing, tempering and filling

as in industry

Modular

The modularity of the learning sys-tem enables you to realise a diverse range of configurations for typical production processes from very dif-ferent industries in a safe learning environment.

Training for many areas of application and careers – Electronic engineers – Mechatronics engineers – Systems engineers – Microtechnologists

– Process technicians for plastic and rubber technology, glass and coat-ing technology

– Experts in food, confectionery and fruit juice technology

– Experts in water supply, sewage technology, pipe, canal and indus-trial services

– Chemical engineers – Pharmaceutical engineers – Biotechnicians

– Paper technicians

– Systems engineers for sanitary, heating and air conditioning tech-nology

(5)

5 Worldwide at your ﬁngertips. Find your contact person at: www.festo-didactic.com

Train efficiently

Festo – The partner to the process industry

Festo is fast becoming a key part-ner to the process industry. It is only logical that the process automation learning system benefits from this know-how and is tailored to the re-quirements of different industries through its consistent modularisa-tion:

– Water supply and disposal industry – Food industry

– Bulk goods industry

– Chemical and petrochemical indus-tries

– Biotechnology/pharmaceutical industries

– Paper industry

Why stop production to facilitate training?

It is prohibitively expensive to shut down an industrial system to facili-tate training. Comprehensive train-ing in the individual areas of process automation requires industry-ori-ented model systems or training in-stallations. „Learning by doing“ and „process orientation“ are two princi-ples that are central to the success-ful imparting of the many detailed training aims in process technology. Simulation of a process engineering system on a PC provides the oppor-tunity of using a simulation as an ac-tual training system.

(6)

6 www.festo-didactic.com Process automation

Understanding process automation –

By means of seminars and workshops

Open seminar on measurment and control fundamentals of control technology

The participants will acquire basic knowledge and skills in the areas of electrical engineering as well as measurement and control technol-ogy. They will learn about the basic structure, mode of operation and application of process engineer-ing systems and be able to use this equipment. The procedure for the identification of control systems, se-lection of a suitable controller and definition and setting of control pa-rameters will also be explained. Target group

The seminar is recommended for an-yone seeking training in the funda-mentals of control technology. Training aims

– Project planning, standards, flow charts

– Analysis of the sensors, actuators, components and control systems in a system

– Measurement transformation of physical measurement variables – Analogue value processing with

Siemens S7

– Analysis, recording and evaluation of various control processes such as level, flow rate, pressure and temperature

– Commissioning of a test system – Basic principles of control

technol-ogy, P, I, PI and PID controllers in theory and practice

– Definition: Y – W – Z – X – etc., am-plification, rate time, reset time, dwell time, balance time, inactive time

– Setting of the control parameters for different control processes – Practical utilisation of applications

in the process industry: · use of an industrial controller as

control equipment

· use of a Siemens SPS (S7-300) as control equipment

On request

Specific customer training course Customer-specific training course for those employed in the areas of main-tenance, servicing and operational support.

The following training aims are con-veyed to the participants using the professional training equipment of Festo Didactic through „learning by doing“:

– Cross section of all controller types (P, I, D, PI, PD, PID)

– Controller technologies (Fluid Lab®

-PA, industrial controllers and mod-ern PLCs)

Looking for something more? Workshop offering more complex ex-ercises on practical operational sup-port and maintenance, for example: – Replacement and reuse of sensors

and their incorporation into a con-trol process

– Error localisation through diagno-sis of the controller characteristics – Control process with inactive time

on request

On request

The goal of Festo Didactic is to offer further training that not only supports personnel in com-panies with current problems, but that also provides new ap-proaches to future tasks. Festo is fast becoming a key partner to the process industry. Close coordination with our par-ent company, Festo AG & Co. KG., ensures the use of the most modern equipment and systems in our learning systems and a source of first-hand expertise for our trainers.

However our focus and meth-odology also set us apart. Our trainers and consultants are practicians. They are familiar with the requirements of the participants attending their courses, including those re-quirements that go beyond the purely technical.

We set ourselves a high stand-ard. You will immediately no-tice the difference between our seminars and those offered by other providers. We provide new answers to old questions – an-swers that will help you to take that critical step in your opera-tional projects.

(7)

Fluid Lab

®

_-PA

Fluid Lab®_{-PA can be used to teach}

and demonstrate the fundamentals of control technology. The main com-ponents required for actuating the MPS®_{PA stations using a PC are the}

„EasyPort D/A“ and the Fluid Lab®

-PA software.

Fluid Lab®_{-PA can be easily installed}

on any Microsoft Windows operat-ing system.

Key features

Three main functions are integrated in Fluid Lab®_{-PA in combination with}

the EasyPort D/A: Measurement

For detection and evaluation of measured variables from 8 digital/ 4 analogue input signals. Open-loop control

For binary or continuous control of 8 digital/2 analogue outputs. Closed-loop control

For freely selectable closed-loop con-trol functions such as 2-point, P, I, PI and PID.

Actual process or simulation All exercises and experiments can be performed online on the actual proc-ess in conjunction with the station or offline using the pre-integrated simulation.

„Settings“ menu item

The following parameters can be set here for the four analogue input channels and the sensors connected to them:

– Factor – Offset – Filter – Inversion

The analogue and binary output sig-nals can also be switched and the signal states of the inputs read off. General PC system settings can also be made here.

„Process Sequence“ menu item The process sequence of each sta-tion can be easily started from Fluid Lab®_{-PA. All of the process steps are}

visualised and can be monitored on the flow chart.

„Measuring and Control“ menu item All the functions of the MPS®_PA

station can be clearly and directly controlled. The states of the proc-ess valves, pumps and sensors are graphically recorded, which means they can be directly evaluated. The following functions are provided for recording the sensor characteristics and determining the step response: – Selection of measuring channels – Factor for physical scale – Adaptation of the time scale – Display of the input signals – Setting of output signals, switching

on/off of the manipulated variable – Printing of the measured value

dis-play or saving as a .jpg file „Analysis“ menu item Analyses of a wide range of proc-ess components can be directly per-formed using predefined exercises, for example:

– Recording of sensor characteristics – Recording of pump characteristics – Recording of heating

characteris-tics

This permits a fast and thorough un-derstanding of the typical process components.

„2-Point Controller“ and „Continuous Controller“ menu item For easy parameterisation of the re-quired controller with an immedi-ate effect on the process. One click of the mouse starts various control-ler functions for the selected control system. Documentation of the con-troller parameters is also straight-forward. The measured values and characteristic curve profiles can be easily printed out.

(8)

8 24-month Festo Didactic warranty

MPS®_{PA – The new learning system for process automation}

MPS

®

_{PA – The new learning system for process automation}

Teaching today using the technology of tomorrow

MPS®_{PA, an innovative learning}

sys-tem equipped with the most modern technical features and products from market leaders.

Practical training

The exclusive use of industrial components underlines the necessary practi-cality and ensures a speedy transfer of knowledge from a training scenario to practical application.

Sensors

Typical process engineering sensors assume control of temperature, level, flow rate and pressure in the MPS®_PA.

(9)

9 www.festo-didactic.com MPS®_{PA – The new learning system for process automation}

Investment protection

A well thought-out modular design with clear-cut interfaces facilitates adapta-tion to future developments in components as well as open-loop and closed-loop control systems. This means that the system can be adapted to new re-quirements.

Boundless variety

It is only logical that the MPS®_{PA stations can be combined with stations from}

the greater MPS®_{family. After all, it is this possibility of combination with}

MPS®_{stations that makes the MPS}®_{PA an interesting proposition for basic and}

further training in many industries which are dominated by process automa-tion but still require elements from producautoma-tion automaautoma-tion.

(10)

MPS®_{PA – The new learning system for process automation}

Measuring and controlling as in industry

Components The closest thing to reality

The MPS®_{PA learning system is}

based on industrial standards. The MPS®_{PA concept is based on a}

market leaders‘ automation solu-tions and trends and can be control-led in a number of ways:

Simulation box

Fluid Lab®_-PA

PLC

PLC with external industrial controller

Operation and configuration Advantages

– Simple commissioning of an MPS®_{PA station}

– Testing and commissioning of process components or system components of a station

– Commissioning and testing of an MPS®_{PA station}

– Analysis of process components and control processes of an MPS®

PA station

– Monitoring and analysis of the process sequences of a station – Testing, configuration and opti-misation of control processes (2-point, P, PI or PID controllers) – Analysis of the control response

– Programming of process se-quences and recipe controllers – Analogue signal processing – Operation and monitoring using

the touch panel

– Programming of PID controllers – Configuration and

parameterisa-tion of P, PI or PID controllers

Same as PLC, plus:

– Operation of an industrial con-troller (manual operation, auto-matic operation)

– Parameterisation of industrial controllers (P, PI or PID control algorithm)

– Configuration of measuring rang-es, setpoint value limits and alarm limits

– Self-optimisation with oscillation or step response method

(11)

11 24-month Festo Didactic warranty MPS®_{PA – The new learning system for process automation}

Combining stations

MPS®_{PA stations can be}

combined as follows:

Stations Possible direct downstream station

Filtration Mixing Reactor Bottling

Filtration Mixing Reactor The new interface concept offers

many possibilities for direct combina-tion of individual MPS®_{PA stations.}

Various aspects determine the deci-sion as to which combination is re-quired:

– Training aims

– Supplementation of existing stations

– Budget

The MPS®_{204 complete system}

(12)

12 24-month Festo Didactic warranty MPS®_{PA 204 Complete system}

MPS

®

_{PA 204 Complete system}

Control technology is clearly and practically explained using the P, PI or PID control algorithm. The temper-ature sensor – the reactor station us-es a PT100 rus-esistance thermometer – supplies a unit signal of 0 – 10 V via the measuring transducer. The con-troller approaches the setpoint tem-perature via the continuously control-lable heater and keeps it constant.

Using a constant flow rate, the three raw materials are mixed to a recipe in the mixing station. The flow rate is recorded by means of an electronic flow sensor with impeller and addi-tionally displayed using a variable-area flowmeter. The controller ad-justs the necessary flow rate via the pump with analogue control.

Pressure control ensures constant-ly high filter quality during flushing. The pressure sensor with LCD dis-play, analogue output and switching output always supplies the correct measurement variable. The control-ler ensures constantly high filter quality during rinsing via the propor-tional pressure regulator.

The filling level of the dosing tank is detected in the bottling station using an analogue filling level sensor. The controller regulates the filling level to the required setpoint value via the continuously controllable pump. The filling level in the dosing tank is kept constant during filling, which optimises the quality of the filling process.

(13)

13 www.festo-didactic.com MPS®_{PA 204 Complete system}

Function

The system is made up of the filtra-tion, mixing, reactor and bottling sta-tions. The filtration station filters a liquid. The filtrate is pumped from the first tank into the second tank through the filter using various proc-ess valves. The filtered liquid is then fed into the first tank in the mixing station. The mixing station mixes different recipes from three reser-voir tanks. The finished mixture is pumped to the reactor station, where it is tempered. Depending on the recipe selected, different tempera-ture profiles with different stirring times are activated. The bottling sta-tion fills the liquid into bottles. These bottles are transported to the filling position via conveyors. A pneumatic separator separates the bottles. The bottles are filled with different filling quantities from the dosing tank in accordance with the recipe selected.

MPS PA 204 with SIMATIC S7-300 control package 544248 MPS PA 204 with Festo CPX control package 544249 MPS PA 204 with Allen Bradley ML 1500 control package 544250 MPS PA 204 with Mitsubishi MELSEC control package 544251

The complete system is made up of the filtration, mixing, reactor and bottling stations with trolleys, colour touch panels, mounting frames and power supply units and includes: – 4x PLC board

(either with SIMATIC S7-313C, Festo CPX, Allen Bradley ML 1500 or Mitsubishi MELSEC FX1N)

– 4x Fluid Lab®_{-PA software with digital/analogue EasyPort PC interface}

– 4x digital/analogue simulation box – 4x industrial controller

Supplied complete with all the necessary connecting cables.

Special training aims

– Construction, wiring and commis-sioning of a system for process technology

– Measurement of electrical and process-related variables such as level, flow rate, pressure and tem-perature

– Design and commissioning of con-trol circuits

– Evaluation of the control response – Networking of process engineering

systems

– Process operation and monitoring, system management

– Selection, application and actua-tion of process valves

– Analysis of control processes and control circuits

– Parameterisation and optimisation of P, PI or PID controllers – Drafting of open-loop and

closed-loop control programs

– Process operation and monitoring – Inspection, maintenance and

serv-icing

Included in the scope of delivery: Various measurement and control options

– Simple commissioning, simulation and display using the simulation box

– Multimedia measurement, open and closed-loop control, op-eration, monitoring and commissioning using Fluid Lab®_-PA

– Starting process sequences in the PLC or monitoring them using the touch panel

– The PLC or the industrial controller likewise included for each station can assume the control function. Parameteri-sation of the controller is performed at the touch panel or directly at the industrial controller. All the process vari-ables are shown clearly – and also as a trend – both on the touch panel and on the industrial controller.

The MPS®_{PA complete system offers everything required}

for an efficient start with measurement and closed-loop con-trol technology.

Successful project work thanks to modular structure Learning by doing – the MPS®_{PA system offers process}

technology that you can really get to grips with. This allows you to implement your own project ideas quickly and with-out risk.

(14)

14 Worldwide at your ﬁngertips. Find your contact person at: www.festo-didactic.com MPS®_{PA Stations}

Filtration station

Function

The filtration station filters liquids. The filtrate is pumped from the first tank into the second tank through the filter using a knife gate. The fil-tered liquid reaches the second tank via a butterfly valve with pneumatic semi-rotary drive. The filtered liquid can be pumped onwards to the next station using a separate pump. The filter can be rinsed using a rinse pro-gram. Regulated compressed air is additionally blown through the filter to loosen deposits.

Measurement and control Sensors detect the filling level of the container in the filtering station. This permits lessons on simple control exercises for monitoring the pumps right up to complete control projects involving complex processes. Pressure control ensures constant-ly high filter quality during flushing. The pressure sensor with LCD dis-play, analogue output and switching

output always supplies the correct measured variable. The controller with P, PI or PID control algorithm ensures constantly high filter qual-ity during rinsing via the proportional pressure regulator. Control technolo-gy is clearly and practically explained in this way.

(15)

MPS®_{PA Stations}

Shutting off, opening, closing The right selection of process valve, drive, drive accessories and control valve plays an important role in com-plex process sequences. The filtering station uses an extremely wide range of process components. All the valve actuators are actuated via a directly connected NAMUR valve.

Knife gate with COPAC linear actua-tor.

Butterfly valve with sturdy rack and pinion COPAR rotary actuator and large visual display.

Three-way ball valve with SYPAR scotch yoke rotary actuator and large visual display.

Complete Filtration station 544253 (with trolley, colour touch panel, mounting frame and power supply unit)

Also order

Open-loop and closed-loop control with PLC:

PLC board with SIMATIC S7-313C 533526 SIMATIC S7 connecting cable set 544296 PLC board with Festo CPX 541187 Festo CPX connecting cable set 544297 PLC board with Allen Bradley ML 1500 544300 Allen Bradley ML 1500 connecting cable set 544298 PLC board with Mitsubishi MELSEC 544301 Mitsubishi MELSEC connecting cable set 544299 Or alternative:

SIMATIC S7 EduTrainer Compact 313C 533018 SIMATIC S7 connecting cable set 544296 For working with Fluid Lab®_-PA:

Fluid Lab-PA 544304

Digital/analogue EasyPort PC interface 193930 RS232 PC data cable 162305 RS232 USB adapter 540699

SysLink cable 034031

Analogue cable 529141

For simple commissioning, simulation and display using the simulation box:

Digital/analogue simulation box 526863

For professional control using industrial controllers:

Industrial controller 544293

Recommended accessories

Replacement filter cartridge 544303 Mains cable for tabletop power supply unit On request

Training aims for project work – Construction, wiring and

commis-sioning of a system for process technology

– Selection, application and actua-tion of process valves – Measurement of electrical and

process-related variables such as level and pressure

– Design and commissioning of control circuits

serv-icing

Recommended training media – Fluid Lab®_-PA

– Web-based training program, Fundamentals of open and closed-loop control

– Design and simulation program FluidSIM®_Pneumatics

(16)

16 Worldwide at your ﬁngertips. Find your contact person at: www.festo-didactic.com MPS®_{PA Stations}

Mixing station

Function

The mixing station mixes different recipes from three reservoir tanks. The liquid from one of the three reservoir tanks is pumped into the main tank in a controlled manner by opening the respective two-way ball valve. The finished mixture can be pumped to the next station via a sec-ond pump – or pumped back to the reservoir tank.

Measurement and control Using a constant flow rate, the three raw materials are mixed to a recipe in the mixing station. The flow rate is recorded by means of an electronic flow sensor with impeller and addi-tionally displayed using a variable-area flowmeter. The output signal from the flow sensor is converted to a standard signal from 0 – 10 V. The mixing station can also be actuated through binary means using the in-tegrated comparator. The controller

adjusts the necessary flow rate via the pump with analogue control – using a simple two-point controller or various dynamic controllers such as P, PI or PID. This permits a clear explanation of control technology on various levels.

(17)

Always the right mixture The component mix of the mixing station offers a wide selection of typ-ical components from process engi-neering. Pumps and process valves, various sensors for signal detection as well as electronic modules for signal conversion permit the right „training mix“.

Sensors for detecting the filling lev-el of containers. With overflow pro-tection thanks to additional sensors on each container, thereby virtually eliminating the possibility of over-flow.

Signal converters convert all ana-logue signals from the station to standard signals from 0 – 10 V. Prac-tical for the purpose of experimen-tation: integrated comparators also supply purely binary signals.

Two-way ball valve with SYPAR scotch yoke rotary actuator, large optical display and directly connect-ed NAMUR valve.

Complete Mixing station 544254 (with trolley, colour touch panel, mounting frame and power supply unit)

Also order

Fluid Lab-PA 544304

Mains cable for tabletop power supply unit On request

– Selection, application and connec-tion of various flow sensors – Measurement of electrical and

process-related variables such as level and flow rate

serv-icing

(18)

18 24-month Festo Didactic warranty MPS®_{PA Stations}

Reactor station

Function

The reactor station tempers a liquid. Depending on the recipe selected, different temperature profiles with different stirring times are activated. A cooling pump is activated to cool the liquid. The tempered liquid can be pumped onwards to the next sta-tion using a separate pump.

Measurement and control Sensors detect the filling level of the reservoir in the reactor station. This facilitates lessons on simple control exercises for monitoring the pumps right up to complete control projects involving complex processes. Exact adherence to the various tem-perature profiles when activating the recipes is achieved by means of temperature control. The tempera-ture sensor (PT100 resistance ther-mometer) supplies a unit signal of

0 – 10 V via the measuring transduc-er. The controller with P, PI or PID control algorithm can approach the setpoint temperature values via the dynamically controlled heating unit and keep the values constant. Sim-ple control exercises, for examSim-ple control using the two-point control-ler, can be realised using the reactor station. Control technology is clearly and practically explained in this way.

(19)

Heating and stirring

Key basic operations in many proc-ess engineering systems involve heating and stirring. The compo-nents of the reactor station are de-signed to permit a wide range of ex-periments in this area.

Infinitely adjustable heating with control signal from 0 – 10 V. A safe experimental environment permits integrated linking of the heater with the integrated temperature switch – thus ruling out the possibility of „running dry“ in a practical way.

Signal converters convert all ana-logue signals from the station to standard signals from 0 – 10 V. Prac-tical for the purpose of experimen-tation: integrated comparators also supply purely binary signals. Stirrer with DC motor.

Complete Reactor station 544255 (with trolley, colour touch panel, mounting frame and power supply unit)

Also order

Fluid Lab-PA 544304

Mains cable for tabletop power supply unit On request

– Selection, application and connec-tion of temperature sensors – Measurement of electrical and

process-related variables such as level and temperature

– Use and connection of measuring transducers

serv-icing

(20)

20 www.festo-didactic.com MPS®_{PA Stations}

Bottling station

Function

The bottling station fills bottles with liquid. The liquid is pumped into the dosing tank from the reservoir. The bottles are transported to the filling position via conveyors. A pneumatic separator separates the bottles. The bottles are filled with different filling quantities from the dosing tank in accordance with the recipe selected.

Measurement and control The filling level of the dosing tank is detected in the filling station us-ing an analogue fillus-ing level sensor. The controller regulates the filling level to the required setpoint value via the dynamically controlled pump (0 – 10 V).

The filling level in the dosing tank is kept constant during filling, which optimises the quality of the filling process. Various control algorithms such as P, PI or PID can be applied and optimised during experiments.

The characteristics of the control process can be modified using hand valves already integrated. Control technology is clearly and practically explained in this way.

(21)

Transporting, separating, filling Few segments of the diversified process industry are associated with such a wide range of end products as the food industry. All foodstuffs, whether dairy products, baked goods, juice, beer or wine have their own requirements with regard to the handling and production of the cor-responding end products. Transport-ing, separatTransport-ing, dosing and bottling play an important role here.

Optical sensors, adjustable using background suppression, monitor transportation on the conveyors of the filling station.

The filling quantity can be easily ad-justed by selecting different recipes. The pneumatic separator ensures

that there is never more than one bottle at the filling position.

Complete Bottling station 544256 (with trolley, colour touch panel, mounting frame and power supply unit)

Also order

Fluid Lab-PA 544304

Set of 20 x 100 ml bottles 544302 Mains cable for tabletop power supply unit On request

– Selection and application of filling level sensors

– Measurement of electrical and process-related variables such as level

serv-icing

(22)

22 Worldwide at your ﬁngertips. Find your contact person at: www.festo-didactic.com Process automation – Networked system

Networked system with 3 or 4 stations

A standard connecting station with 2/2-way solenoid valve and S7-300 controller controls the interaction of the individual stations.

Adjustable centrifugal pump to en-sure the right flow for every station.

Sipart DR19 controller from Siemens – now fitted in all stations.

An alternative connecting station with pneumatic process actuators from Festo, Namur valves and CPX valve terminal actuation is also available.

(23)

23 Information on customer projects: www.festo-didactic.com

Process automation – Networked system

Function

A networked system enables level control, flow rate control, pressure control and temperature control sys-tems to be operated simultaneously. Each station is equipped with a Sie-mens DR19 and can therefore also be operated individually. The sta-tions are connected to the host com-puter (PC) via Profibus DP. Access to the process variables of all sta-tions is provided by the operation and visualisation software InTouch or WinCC.

Step by step to greater complexity Training starts with individual groups of students at the individual stations tackling tasks of similar complexity. The complexity can be gradually in-creased later by merging the stations into one system.

Training aims

This system complements the train-ing aims of the Compact Worksta-tion.

– Commissioning and maintenance personnel:

Realizing bus networks. From plan-ning, design and configuration through to realisation. – Operators:

Process operation, monitoring and performance training as part of system management.

The networked system can be sup-plied as a version with 4 stations (level control, flow rate control, pres-sure control and temperature con-trol) or as a version with 3 stations (no pressure control).

In both cases, a connecting station comprising a pump and 8 x 2/2-way solenoid valves controls the flow of water between the stations. Six or eight capacitive sensors (depend-ing on whether there are 3 stations or 4 stations respectively) monitor the level of the containers. Supplied with a SIPART DR19 controller and S7-313-2DP.

Integrated systems:

from the control station to the field Modern communication technology enables you to „see“ the sensor from the control room. The critical ques-tion remains as to which signals are relevant for display or which inter-vention options should be made accessible to individual groups of people. The system provides a quick insight into complex relationships and points to trends in the latest technologies and methods through the use of hardware and software from market leaders.

SIMATIC WinCC is a PC-based con-trol and monitoring system designed for visualising and controlling proc-esses, sequences and machines. InTouch is an interactive system for visualising, monitoring and con-trolling industrial processes on IBM compatible computers.

System with 4 stations On request

Comprising:

level, flow rate, pressure and temperature control as well as a standard connecting station

– 4x industrial controller DR19 in the ER mounting frame

– 1x EduTrainer®_{with S7-313C-2DP}

– 5x mobile trolley

– 5x power supply unit in the mounting frame

– 1x individual licence STEP 7 – 1x licence for WinCC or InTouch – 1x licence for SIMATIC PDM – 1x Profibus card CP 5611 – 1x set of Profibus cables – Technical documentation – Initial start-up at Festo Didactic System with 3 stations On request

Comprising:

level, flow rate and temperature control as well as a standard connecting station

– 3x industrial controller DR19 in the ER mounting frame

– 1x EduTrainer®_{with S7-313C-2DP}

– 4x mobile trolley

– 4x power supply unit in the mounting frame

– 1x individual licence STEP 7 – 1x licence for WinCC or InTouch – 1x licence for SIMATIC PDM – 1x Profibus card CP 5611 – 1x set of Profibus cables – Technical documentation – Initial start-up at Festo Didactic

Commissioning and training on-site upon request.

Also order

Simulation box, digital/analogue 526863

Control variants

See Compact Workstation

Recommended training media

– Fluid Lab®_{-PA, including EasyPort, digital/analogue}

(24)

Process automation – Compact Workstation

Compact Workstation with level, flow rate,

pressure and temperature closed-loop control systems

Optimisation relative to your space requirement Maybe you‘re restricted in the amount of space you have available but you want each of your training workstations to offer a high level of complexity. If so then the Compact Workstation with four integrated closed-loop control systems is the solution for you. As shown in the flow chart, the individual control sys-tems can be activated by simply re-positioning the ball valves. The flex-ible piping system enables you to change the flow scheme or integrate other components quickly and easily. Function

The four control systems in the Com-pact Workstation can be operated individually. The level and flow rate control systems can be structured as a cascade control system through the addition of an appropriate controller. The layout of the sensors and servo drives permits experimentation with both continuous (e.g. P, I, PI, PID) and discontinuous action controller types (e.g. 2-point controllers). The pump can either be controlled directly or operated in controlled speed mode. The manipulated variable of the con-troller in the flow rate and pressure control systems can alternatively act upon a proportional directional con-trol valve. A ball valve with pneu-matic drive is built into the return between the high-level container and the lower reservoir. The pneu-matic drive can be used to simulate a “load” for switching on a disturbance in the level control system or as an on-off valve for emergency switch-off. Scope of delivery of the

Compact Workstation (Basic version including manual without actuation components)

Mechanical components, fully assembled – 2 containers – Reservoir

– Plug-in piping system – Aluminium profile benches – Mounting frame

– Profile plate 700 x 700 x 32 mm Sensors

– 2 capacitive sensors – 2 float switches – 1 process drive signal box – Ultrasound sensor – Flow sensor – Pressure sensor – PT100 temperature sensor Actuation components – Pump

– Proportional directional control valve

– Ball valve with pneumatic drive – Heater

Electrical components – I/O connection board with

measuring transducer – Motor controller with relay – I/O terminal, SysLink, 8 I/8 O – Analogue terminal, SysLink, 15-pin

Compact Workstation On request Commissioning and training on-site upon request.

(25)

25 24-month Festo Didactic warranty Process automation – Compact Workstation

Mounting frame

Can be equipped with accessories for controllers, control unit and/or touchpanel. It can also be converted from the ER format to DIN A4 format at any time by the user. The activa-tion and/or control devices can be replaced in just seconds.

Pneumatic drive

With ball valve and signal box. Train-ing aims: Design and application ar-eas of various metering and shut-off devices when controlling the flow of liquids.

Intelligent in the field – closedloop control with the CPX/ FEC valve terminal and the FED 120 touchpanel

The Festo Front End Controller with integrated web server and Ethernet interface is ideally suited to current communication tasks.

Piping and instrument flow chart An important part of project work in process engineering is develop-ing a pipdevelop-ing and instrument flow chart. A piping and instrument flow chart explains the electrical, meas-uring and control technology func-tions using measuring points and final control elements. The measure-ment variable or another input vari-able, its processing, its direction of action and directional specifications and positions should follow from the chart.

Visualisation with WinCC or InTouch on request.

Accessories for the Compact Workstation – Trolley

– Tabletop power supply or power supply unit for the mounting frame – Control kit

Recommended training media – Fluid Lab®_{-PA, including EasyPort,}

digital/analogue

Control kit S1:

Siemens SIMATIC EduTrainer®

Compact with S7-313C

– 1 x EduTrainer Compact S7-313C – 1 x control unit

– 2 x I/O data cable – 1 x analogue cable Note: STEP 7 software and MPI cable must be ordered separately if required.

Control kit S1-DP On request Control kit S1 On request

Control kit PC2:

Fluid Lab®_{-PA software licence with}

EasyPort

– 1 x Fluid Lab®_{-PA, individual licence}

– 1 x EasyPort D/A – 1 x RS232 data cable – 1 x mains cable – 1 x I/O data cable – 1 x analogue cable

Control kit PC2 On request

Control kit F3:

Festo CPX/FEC®_{with FED}

– 1 x Festo CPX/FEC®

– 1 x Ethernet cable, crossover – 1 x FED-120 touchpanel – 1 x I/O data cable – 1 x analogue cable

Note: FST software and programming cable must be ordered separately if required.

Control kit F3 On request

Control kit S2:

Siemens SIPART DR19 controller – 1 x SIPART DR19 with serial

inter-face integrated in ER frame – 1 x PDM software for

parameterisa-tion and configuraparameterisa-tion of the DR19 controller

– 1 x serial data cable – 1 x I/O data cable – 1 x analogue cable

Control kit S2 On request

Control kit F2:

Festo CPX/FEC®_{valve terminal}

– 1 x Festo CPX/FEC®

– 1 x control unit

– 1 x Ethernet cable, crossover – 2 x I/O data cable

– 1 x analogue cable

Note: FST software and programming cable must be ordered separately if required.

Control kit F2 On request

I/O simulation box, digital/analogue

– 1 x simulation box incl. mains cable – 1 x I/O data cable, crossover – 1 x analogue cable, crossover

I/O simulation box On request

(26)

26

Hybrid processes

www.festo-didactic.com

Hybrid processes

Boundless variety

Qualification solutions and training factories for production and process automation.

Tell us what you need – we‘ll design your ideal learning environment and establish the required dependencies at process level. We look forward to designing solutions with you for spe-cial topics such as:

– Water treatment – Cooling and refrigeration

technology

– pH value measurement – Conductivity measurement – Pneumatics in process

engineer-ing, for example slide valve actua-tors with positioners, specifically

for the paper industry. MPS®_PA,

combined with MPS®_stations

It is only logical that the MPS®_PA

(process automation) stations can be combined with stations from the greater MPS®_{family. This makes}

MPS®_{an interesting proposition for}

basic and further training in many industries which are dominated by process automation but still require elements from production automa-tion.

The well thought-out modular de-sign with clear-cut interfaces pro-tects your investment and facilitates adaptation to future developments in components as well as open-loop and closed-loop control systems. This means that the system can be adapted to new requirements.

(27)

27 Hybrid processes

Information on customer projects: www.festo-didactic.com

Production automation and process automation

AFB –

The modular concept factory for all hybrid production tasks

Customer-specific solutions The learning system for all processes

associated with production automa-tion and process automaautoma-tion. – Production

– Handling of seals – Packaging – Filling

– Transportation and routing – Storage

– Input/output

The ideal solution for hybrid pro-duction process requirements in the food sector. The platform con-nects stations and elements from the MPS®_{Modular Production}

Sys-tem with stations from the MPS®_PA

learning system and the Compact Workstation.

The system is therefore complete-ly modular and new processes and training content can be added grad-ually. Project work with hands-on training can take place at individual stations, on partially integrated pro-duction lines and in a fully integrated learning factory.

You have specific requirements? Numerous installations across the globe have given rise to a range of solutions with a particular focus on hybrid automation.

An example of this is provided by Siemens AG Professional Education Berlin, whose mixing and filling sta-tion demonstrates how a continu-ous flow process is brought into line with a gradual container filling proc-ess. The students experience an op-erational process showing the entire sequence of an automated customer order processing system.

Detailed information on this and other projects can be found on the website:

www.festo-didactic.com under Services ➔ References.

(28)

56943 en Festo Didactic GmbH & Co. KG

Rechbergstraße 3 73770 Denkendorf/Germany Tel. ++49 (0)711/3467-0 Fax ++49 (0)711/34754-88500 www.festo-didactic.com [email protected]
