(1)

202 2

PRICES

TECHNICAL DATA

EQUIPMENT

(2)

2 3 EDITION15

STANDARD EQUIPMENT

EDITION15

EDITION15

FOR THE FOURTH TIME IN A ROW CARADO IS THE OVERALL WINNER OF THE "KÖNIG- KUNDE-AWARD"

CARADO DEVELOPS AND PRODUCES EX- CELLENT VEHICLES – IN THE TRUEST SENSE OF THE WORD. WE ARE PROUD TO BE ABLE TO OFFER YOU A UNIQUE HOME FOR YOUR TRAVELS. THE NUMEROUS AWARDS WE HAVE RECEIVED FOR OUR MOTORHOMES AND CAMPERVANS, AS WELL AS ACHIVING THE BEST IN CUSTOMER SATISFACTION ARE INCENTIVES FOR US TO CONTINUE STRIV- ING FOR THE HIGHEST LEVEL OF QUALITY NOW, AND IN THE FUTURE.

4

Camper Van

22

Van

34

Motorhomes

CAMPER VAN

TA BL E O F C O N TE N T S

MOTORHOMES VAN

MODEL RANGE

PACKS

OPTIONAL EQUIPMENT MODEL RANGE

STANDARD SPECIFICATION PACKS

OPTIONAL EQUIPMENT

MODEL RANGE Semi-Integrated Overcab Integrated

STANDARD SPECIFICATION PACKS

OPTIONAL EQUIPMENT 6

8 10 12 16

34 36 40 42 44 46 50 54 22

26 28 30 32

(3)

4 5 More

Info

C AM PE R V AN CV 54 0 CV 60 0 CV 60 1 CV 64 0

(4)

0 1 2 3 4 5 6 7 m 6

CV640CV601CV600CV540

7

TYPE / MODEL CV540 CV600 CV601 CV640

BASIC PRICE INCL. VAT £ 39,370.- 40,290.- 41,310.- 42,220.-

PERMITTED NUMBER OF PERSONS

BERTHS / + / + / + / +

Length / Width / Height (cm) 541 / 205 / 270 599 / 205 / 270 599 / 205 / 270 636 / 205 / 270

Headroom in living area (cm) 190 190 190 190

Standard chassis Fiat Ducato Fiat Ducato Fiat Ducato Fiat Ducato

Standard engine 2,2 l Multijet 2,2 l Multijet 2,2 l Multijet 2,2 l Multijet

kW (BHP) 88 (120) 88 (120) 88 (120) 88 (120)

Mass in running order (kg) 2654 2724 2764 2814

Maximum load (kg) 646 576 536 686

Technically permissible total mass (kg) 3300 3300 3300 3500

Trailer load braked (unbraked) (kg) 2500 (750) 2500 (750) 2500 (750) 2500 (750)

Tyre size 215/70 R 15 C 215/70 R 15 C 215/70 R 15 C 215/70 R 15 C

Wheelbase (cm) 345 404 404 404

Bed dimension middle L x B (cm) 185 x 87 / 63 185 x 105 / 88 185 x 105 / 88 185 x 105 / 88 Bed dimension rear L x B (cm) 195 x 133 / 130 197 x 157 / 150 185 x 157 / 150

187 x 130 191 x 74

182 x 85

Refrigerator volume incl. freezer (l) 84 84 84 84

Heating type Combi 4 Combi 4 Combi 6 Diesel Combi 4

Fresh water tank (red. Vol.) (l) 100 (20) 100 (20) 100 (20) 100 (20)

Waste water tank approx. l 90 90 90 90

Sockets 230 V 3 3 3 3

Sockets: USB 2 2 2 2

1) 1) 1) 1)

OPT OPT OPT OPT

2) 2) 2) 2)

3) 3) 3) 3)

OPT OPT OPT OPT

4) 4) 4) 4)

Optional Standard Not possible All prices are recommended retail prices in GBP including legal applicable VAT, On The Road Charges (OTR including delivery from Germany, registration and PDI). Possible import duties are not included and will be charged separately.

OPT

OPT Optional • Standard equipment – Not possible All footnotes, see page 62–63.

CAMPER VAN MODEL RANGE

Configure your dream Camper Van

Also available as EDITION15: further information on page 16

(5)

8 9

FIAT DUCATO BASE VEHICLE

Fiat Ducato 2,2 l Multijet 88 kW (120 BHP) - EURO 6

LED daytime running lights Cruise control

ESP incl. ASR & Hillholder ABS

Start & Stop function incl. booster Driver airbag

Passenger airbag Electric cab windows Manual cab air conditioning Central locking cab with remote

control

Fix & Go breakdown kit

On-board computer incl. exterior temperature display

Central cup holder

Disc brakes, rear and front wheel stabilisers, heat convection, tachometer, power steering, height- adjustable headlights, immobiliser, lap and diagonal seat belts Steel rims 15" including wheel trims Tablet holder and USB port Driver and passenger seats in

matching colours

Height and rake adjustment for driver seat (optional for passenger seat)

Swiveling driver and passenger seats

75l fuel tank

CONVERSION

7-year water ingress warranty Double glazed hinged windows with

cassette blinds and fly screens (siting area, kitchen)

Rear hinged window (incl. blackout blind and flyscreen)

Both rear doors with hinged window (incl. roller blind)

Roof light 40 x 40 cm over lounging area with fly screen and blinds Roof light 40 x 40 cm over bedroom

with fly screen and blinds Rear storage space with 4

integrated lashing rings

COMFORT

Isofix for 2 seats

Bulkhead incl. step for rear double bed

Pedestal in lounging area with integrated storage compartment Half dinette with integrated storage

compartment

Rear bed with partly slatted frame High quality mattresses with

integrated GOODSITE for better sleeping comfort

Ergonomically shaped upholstery for improved seating comfort Easy to position spotlight in light bar

(except 601)

Spacious storage compartments and storage options

Storage space in rear and sliding doors

Spacious wardrobe

Furniture in 'Pure Spring' and 'Cosy White'

Floor in 'Casual Suite'

5)

INSTALLATIONS

Flexible light strip

Illuminated pedestal in lounging area

Individually adjustable LED spotlights

High-performance, maintenance- free leisure battery (95 Ah AGM) On-board control panel supplies information about filling levels and battery capacity

Electric charger for leisure and vehicle battery 12 V / 18 A CEE 230 V external socket with

safety device

Sockets 3 x 230V, 1 x USB (double) (except 540)

Water tank 100 l and waste water tank 90 l

HEATING / GAS SUPPLY

Gas bottle locker for 2 x 11 kg gas bottles (except CV601 with 2 x 5 kg bottles)

Gas heating Combi 4 (except CV601)

Diesel heating Combi 6 (CV601) Gas control valves easily accessible

and centrally arranged

KITCHEN

Ergonomically arranged kitchen with spacious work top

Large soft-close drawers in kitchen 2 burner hob with piezo ignition and

split glass lid

Worktop behind cooker (except CV540)

Compressor fridge 84 l LED light tube

Suspension bar (except CV540)

BATHROOM

Fixed washbasin Spacious storage area Cassette toilet C 223 Flush fitting LED spotlights Roof light with fly screen

SOFT

FURNISHING

Soft furnishing Grafit

EXTERIOR COLOUR

Fiat white

STANDARD SPECIFICATIONCAMPER VAN

Carado Original A ccessories

More original accessories here!

All footnotes, see page 62–63.

Isofix for 2 seats

Kitchen with generous work surface 84L Compressor fridge

(6)

10 11

BASIC PACKAGE Additional weight 42.7 kg Electric and heated mirrors

Radio pre-wiring with loudspeakers and roof antenna (DAB) Height-adjustable passenger seat

Captain-Chair incl. 2 armrests Roof light over lounge area 70 x 50 cm

Shower equipment (extendable shower head, shower curtain, guide rail and shower holder) Window in bathroom

Textile cab blinds Clothes rail in bathroom Wide entrance step Flyscreen door

Rotating plate for table extension in seating area

SPECIAL PRICE (€) 1,780.-

STYLE PACKAGE Additional weight 0 kg Leather steering wheel and gear knob in leather trim Instrument panel with applications (Techno-Trim) Gloss black radiator grill with chrome strips

SPECIAL PRICE (€) 300.-

CHASSIS SAFETY PACK Additional weight 0.5 kg Brake assistant with pedestrian and cyclist detection

Lane Assist

Rain and light sensor

Traffic sign and high beam detection

SPECIAL PRICE (€) 850.-

CHASSIS EASY DRIVING PACK Additional weight 0.3 kg Adaptive cruise control

Intelligent speed detection Fatigue detection

SPECIAL PRICE (€) 750.-

BASIC PACKAGE Additional weight 42.7 kg Electric and heated mirrors

Radio pre-wiring with loudspeakers and roof antenna (DAB) Height-adjustable passenger seat

Captain-Chair incl. 2 armrests Roof light over lounge area 70 x 50 cm

Shower equipment (extendable shower head, shower curtain, guide rail and shower holder) Window in bathroom

Textile cab blinds Clothes rail in bathroom Wide entrance step Flyscreen door

Rotating plate for table extension in seating area

SPECIAL PRICE (€) 1,780.-

STYLE PACKAGE Additional weight 0 kg Leather steering wheel and gear knob in leather trim Instrument panel with applications (Techno-Trim) Gloss black radiator grill with chrome strips

SPECIAL PRICE (€) 300.-

CHASSIS SAFETY PACK Additional weight 0.5 kg Brake assistant with pedestrian and cyclist detection

Lane Assist

Rain and light sensor

Traffic sign and high beam detection

SPECIAL PRICE (€) 850.-

CHASSIS EASY DRIVING PACK Additional weight 0.3 kg Adaptive cruise control

Intelligent speed detection Fatigue detection

SPECIAL PRICE (€) 750.-

SPECIAL PRICE (£) SPECIAL PRICE (£)

SPECIAL PRICE (£)

SPECIAL PRICE (£)

PACKSCAMPER VAN

Flyscreen door

All footnotes, see page 62–63.

Turntable style table extension for the seating area

Blackout cab blinds Bathroom conversion to shower

(7)

12 13

OPTIONAL EXTRAS PRICE ADDITIONAL WEIGHT CV540 CV600 CV601 CV640

FIAT DUCATO BASE VEHICLE

Fiat Ducato 2,2 l Multijet 103 kW (140 BHP) - EURO 6 890.- £

Fiat Ducato 2,2 l Multijet 118 kW (160 BHP) - EURO 6 2,680.- £ 15 kg

Weight increase from 3,3t to 3,5t Fiat light 540.- £

Weight increase from 3,3t light to 3,5t MAXI chassis (always incl. 16" steel

wheels) 860.- £ 40 kg

Weight increase from 3,5 t light to 3,5 t MAXI chassis (always incl. 16" steel

wheels) 320.- £ 40 kg

16" steel wheels for light chassis with 3,500 kg (only in conjunction with

weight increase) with wheel trims 270.- £ 10 kg

16 "alloy wheels for 3,500 kg Light chassis (only in conjunction with chassis

upgrade) 690.- £ 8 kg

16 "alloy wheels for 3,500 kg Maxi Chassis 480.- £

Traction+ incl. Hill Descent Control 90.- £ 0.5 kg

ESC Setup 50.- £

Blind spot assistant 580.- £

9 Shift automatic gearbox (not in conjunction with 120 bhp) 3,300.- £ 18 kg

90 L fuel tank 90.- £ 13.5 kg

Digital instrument cluster 480.- £ 0.3 kg

Headlights with black frame 70.- £

LED Daytime running lights 380.- £

Fully LED headlights including indicators and LED daytime running lights. 1,060.- £

Multifunction steering wheel 90.- £ 0.4 kg

Fog lights 2 kg

Parking sensors 310.- £ 0.5 kg

Electrically folding door mirrors 160.- £ 0.6 kg

Tyre pressure indicator 250.- £ 0.8 kg

OPTIONAL EXTRAS PRICE ADDITIONAL WEIGHT CV540 CV600 CV601 CV640

CONVERSION

Insulated waste water tank 490.- £ 10.5 kg

6) 7)

6) 7)

8) 9)

10) 11) 12)

13) 11)

160.- £

OPTIONAL EXTRAS PRICE ADDITIONAL WEIGHT CV540 CV600 CV601 CV640

COMFORT

Soft furnishing Arctica (grey) 180.- £

Bed conversion for lounging area (transversal guest bed) 280.- £ 5 kg

Wooden duckboard for the shower tray 70.- £ 2 kg

Folding blackout blinds in cab 550.- £ 7.5 kg

OPTIONAL EXTRAS PRICE ADDITIONAL WEIGHT CV540 CV600 CV601 CV640

INSTALLATIONS

Second AGM leisure battery 95 Ah 280.- £ 27 kg

Heating Combi 6 E (with el. heating element) incl. digital control panel 500.- £ 2 kg

Pre-cabling for solar panel 140.- £ 2 kg

Pre-cabling for reversing camera 180.- £ 1 kg

TV pre-cabling / TV holder 270.- £ 3 kg

USB-port in the light rail 50.- £

OPTIONAL EXTRAS PRICE ADDITIONAL WEIGHT CV540 CV600 CV601 CV640

SOFT FURNISHING

Soft furnishing Arctica (grey) 180.- £

OPTIONAL EXTRAS PRICE ADDITIONAL WEIGHT CV540 CV600 CV601 CV640

EXTERIOR COLOUR

Aluminium Grey metallic 800.- £ 2.5 kg

Fer Grey metallic 800.- £ 2.5 kg

Black metallic 800.- £ 2.5 kg

14) 14) 14)

OPTIONAL EXTRAS PRICE ADDITIONAL WEIGHT CV540 CV600 CV601 CV640

FIAT DUCATO BASE VEHICLE

Fiat Ducato 2,2 l Multijet 103 kW (140 BHP) - EURO 6 890.- £

Fiat Ducato 2,2 l Multijet 118 kW (160 BHP) - EURO 6 2,680.- £ 15 kg

Weight increase from 3,3t to 3,5t Fiat light 540.- £

Weight increase from 3,3t light to 3,5t MAXI chassis (always incl. 16" steel

wheels) 860.- £ 40 kg

Weight increase from 3,5 t light to 3,5 t MAXI chassis (always incl. 16" steel

wheels) 320.- £ 40 kg

16" steel wheels for light chassis with 3,500 kg (only in conjunction with

weight increase) with wheel trims 270.- £ 10 kg

16 "alloy wheels for 3,500 kg Light chassis (only in conjunction with chassis

upgrade) 690.- £ 8 kg

16 "alloy wheels for 3,500 kg Maxi Chassis 480.- £

Traction+ incl. Hill Descent Control 90.- £ 0.5 kg

ESC Setup 50.- £

Blind spot assistant 580.- £

9 Shift automatic gearbox (not in conjunction with 120 bhp) 3,300.- £ 18 kg

90 L fuel tank 90.- £ 13.5 kg

Digital instrument cluster 480.- £ 0.3 kg

Headlights with black frame 70.- £

LED Daytime running lights 380.- £

Fully LED headlights including indicators and LED daytime running lights. 1,060.- £

Multifunction steering wheel 90.- £ 0.4 kg

Fog lights 2 kg

Parking sensors 310.- £ 0.5 kg

Electrically folding door mirrors 160.- £ 0.6 kg

Tyre pressure indicator 250.- £ 0.8 kg

OPTIONAL EXTRAS PRICE ADDITIONAL WEIGHT CV540 CV600 CV601 CV640

CONVERSION

Insulated waste water tank 490.- £ 10.5 kg

6) 7)

6) 7)

8) 9)

10) 11) 12)

13) 11)

160.- £

OPTIONAL EXTRAS PRICE ADDITIONAL WEIGHT CV540 CV600 CV601 CV640

FIAT DUCATO BASE VEHICLE

CONVERSION

COMFORT

OPTIONAL EQUIPMENTCAMPER VAN

• Standard equipment Optional equipment – Not possible All footnotes, see page 62–63.

(8)

14 15

OPTIONAL EXTRAS PRICE ADDITIONAL WEIGHT CV540 CV600 CV601 CV640

PAINTED BUMPER

Bumper painted in White 360.- £ 1 kg

Bumper painted in Aluminium Grey metallic for Light chassis 360.- £ 1 kg

Bumper painted in Fer Grey Metallic for Light chassis 360.- £ 1 kg

Bumper black in metallic for Light Chassis 360.- £ 1 kg

OPTIONAL EXTRAS PRICE ADDITIONAL WEIGHT CV540 CV600 CV601 CV640

PACKS

Basic Package 1,780.- £ 42.7 kg

Style Package 300.- £

Chassis Safety Pack 850.- £ 0.5 kg

Chassis Easy Driving Pack 750.- £ 0.3 kg

6)

6) 6) 6)

15) 13)

Standard Optional extra Mandatory Not possible Please note the information on page 33

OPTIONAL EXTRAS PRICE ADDITIONAL WEIGHT CV540 CV600 CV601 CV640

COMFORT

Soft furnishing Arctica (grey) 180.- £

Bed conversion for lounging area (transversal guest bed) 280.- £ 5 kg

Wooden duckboard for the shower tray 70.- £ 2 kg

Folding blackout blinds in cab 550.- £ 7.5 kg

OPTIONAL EXTRAS PRICE ADDITIONAL WEIGHT CV540 CV600 CV601 CV640

INSTALLATIONS

Second AGM leisure battery 95 Ah 280.- £ 27 kg

Heating Combi 6 E (with el. heating element) incl. digital control panel 500.- £ 2 kg

Pre-cabling for solar panel 140.- £ 2 kg

Pre-cabling for reversing camera 180.- £ 1 kg

TV pre-cabling / TV holder 270.- £ 3 kg

USB-port in the light rail 50.- £

OPTIONAL EXTRAS PRICE ADDITIONAL WEIGHT CV540 CV600 CV601 CV640

SOFT FURNISHING

Soft furnishing Arctica (grey) 180.- £

OPTIONAL EXTRAS PRICE ADDITIONAL WEIGHT CV540 CV600 CV601 CV640

EXTERIOR COLOUR

Aluminium Grey metallic 800.- £ 2.5 kg

Fer Grey metallic 800.- £ 2.5 kg

Black metallic 800.- £ 2.5 kg

14) 14) 14)

OPTIONAL EXTRAS PRICE ADDITIONAL WEIGHT CV540 CV600 CV601 CV640

PACKS

EXTERIOR COLOUR

PAINTED BUMPER

OPTIONAL EXTRAS PRICE ADDITIONAL WEIGHT CV540 CV600 CV601 CV640

PAINTED BUMPER

Bumper painted in White 360.- £ 1 kg

Bumper painted in Aluminium Grey metallic for Light chassis 360.- £ 1 kg

Bumper painted in Fer Grey Metallic for Light chassis 360.- £ 1 kg

Bumper black in metallic for Light Chassis 360.- £ 1 kg

OPTIONAL EXTRAS PRICE ADDITIONAL WEIGHT CV540 CV600 CV601 CV640

PACKS

Basic Package 1,780.- £ 42.7 kg

Style Package 300.- £

Chassis Safety Pack 850.- £ 0.5 kg

Chassis Easy Driving Pack 750.- £ 0.3 kg

6)

6) 6) 6)

15) 13)

Standard Optional extra Mandatory Not possible Please note the information on page 33

OPTIONAL EXTRAS PRICE ADDITIONAL WEIGHT CV540 CV600 CV601 CV640

COMFORT

Soft furnishing Arctica (grey) 180.- £

Bed conversion for lounging area (transversal guest bed) 280.- £ 5 kg

Wooden duckboard for the shower tray 70.- £ 2 kg

Folding blackout blinds in cab 550.- £ 7.5 kg

OPTIONAL EXTRAS PRICE ADDITIONAL WEIGHT CV540 CV600 CV601 CV640

INSTALLATIONS

Second AGM leisure battery 95 Ah 280.- £ 27 kg

Heating Combi 6 E (with el. heating element) incl. digital control panel 500.- £ 2 kg

Pre-cabling for solar panel 140.- £ 2 kg

Pre-cabling for reversing camera 180.- £ 1 kg

TV pre-cabling / TV holder 270.- £ 3 kg

USB-port in the light rail 50.- £

OPTIONAL EXTRAS PRICE ADDITIONAL WEIGHT CV540 CV600 CV601 CV640

SOFT FURNISHING

Soft furnishing Arctica (grey) 180.- £

OPTIONAL EXTRAS PRICE ADDITIONAL WEIGHT CV540 CV600 CV601 CV640

EXTERIOR COLOUR

Aluminium Grey metallic 800.- £ 2.5 kg

Fer Grey metallic 800.- £ 2.5 kg

Black metallic 800.- £ 2.5 kg

14) 14) 14)

INSTALLATIONS

OPTIONAL EQUIPMENTCAMPER VAN

• Standard equipment Optional equipment – Not possible All footnotes, see page 62–63.

(9)

17 17

C AM PE R V AN

More Info

ED IT IO N 15

(10)

18 1919

CAMPER VAN EDITION15

Folding blinds

CAMPER VAN EDITION15

Whether on a campsite near a lively city or in the middle of the serene countryside: our EDITION15 Campervans fit in everywhere they go. They are not only compact, agile, and flexible they are also fully equipped with everything you need. Everything important is already on board. Every one of our vehicles is made in Germany and each one is packed with experience and quality.

The EDITION15 Carado Campervans are therefore always first choice when it comes to special travel experiences – regardless of whether you are travelling alone, as a couple or with friends. The optional pop-top roof provides sleeping space for up to four people and because everything is included you al- ways feel at home wherever you are. Just get in, drive off, and enjoy.

Living area Bathroom LED daytime running lights

Awning Campovolo exterior colour

Pop-top roof

(11)

20 2121

EDITION 15

TOP EQUIPPED

Optional equipment × Included in Pack – Not possible All footnotes, see page 62–63.

THE NEW EDITION15 CONVINCES WITH ITS INNER VALUES. WITH ITS TOP EQUIPMENT, IT FULFILS EVERY WISH – AND ALL THIS AT AN ABSOLUTELY FAIR PRICE.

CAMPER VAN EDITION15

CAMPER VAN – EDITION15 CV540 CV600 CV601 CV640

Length / Width (cm) 541 / 205 599 / 205 599 / 205 636 / 205

Height / Height with pop-top roof (cm) 273 / 289 273 / 289 273 / 289 273 / 289

Standard Chassis and Engine Fiat Ducato 2,2 l Multijet Fiat Ducato 2,2 l Multijet Fiat Ducato 2,2 l Multijet Fiat Ducato 2,2 l Multijet

Power rating kW (bhp) 103 (140) 103 (140) 103 (140) 103 (140)

Mass in running order approx. (kg) / with pop-top roof 2.748 / 2.890 2.821 / 2.963 2.861 / 3.003 2.913 / 3.055

Maximum load, approx. (kg) / with pop-top roof 752 / 610 679 / 537 639 / 497 587 / 445

Technically permissible total mass (kg) 3.500 3.500 3.500 3.500

CHASSIS

Fiat Ducato 140 bhp × × × ×

Weight increase from 3.3 t Light-Chassis to 3.5 t Light-Chassis × × × ×

White exterior colour × × × ×

Bumpers painted in white 6) × × × ×

16" Alloy Wheels × × × ×

Traction+ with Hill Descent Control × × × ×

90 L Diesel fuel tank × × × ×

ESC Setup ×

Multifunction steering wheel × × × ×

CONVERSION

Awning × × × ×

Edition graphics × × × ×

Pop-top roof (optional) 35) × × × ×

COMFORT

Soft furnishings in Nebula with edition lettering × × × ×

Blackout blinds in drivers cab × × × ×

INSTALLATIONS

Pre-cabling for rear view camera × × × ×

PACKS

Basic Package 36) × × × ×

Style Package × × × ×

INDIVIDUAL PRICES TOTAL 45.570 £ 46.580 £ 47.600 £ 48.170 £

Total Savings 2.220 £ 2.310 £ 2.410 £ 2.080 £

SPECIAL VEHICLE PRICE 43.350 £ 44.270 £ 45.190 £ 46.090 £

SPECIAL VEHICLE PRICE WITH POP-TOP ROOF 47.040 £ 47.960 £ 48.890 £ 49.790 £

(12)

23 More Info

EDITION15

V A N V 13 2 V 33 7 V 339 ED IT IO N 15

IMAGE FOR DISPLAY PURPOSES

(13)

24

V339

V337

25 25

VAN EDITION15

VAN

EDITION15

They are slim, manoeuvrable and fully capable in every respect: the EDITION15 Carado Vans. Our jubilee models are mobile all-rounders. They can handle hairpin bends, old town centres and much more.

Every square centimetre is ideally utilised in our EDITION15 vans. The result: an opti- mised feeling of space - no matter which model you choose.

Living area Awning TV package

Bed conversion from single bed to double bed

Living room seating area upholstered in 'Nebula' Special colour overhead locker doors

Graphite grey metallic cab colour

(14)

0 1 2 3 4 5 6 7 m 26

V339 V337 V132

27

TYPE / MODEL V132 ED15 V337 ED15 V339 ED15

BASIC PRICE INCL. VAT £ 43,390.- 46,290.- 46,180.-

PERMITTED NUMBER OF PERSONS

BERTHS / +

Length / Width / Height (cm) 595 / 214 / 274 665 / 214 / 274 686 / 214 / 274

Headroom in living area (cm) 195 195 195

Standard chassis Fiat Ducato Fiat Ducato Fiat Ducato

Standard engine 2,2 l Multijet 2,2 l Multijet 2,2 l Multijet

kW (BHP) 103 (140) 103 (140) 103 (140)

Mass in running order (kg) 2637 2716 2728

Maximum load (kg) 863 784 772

Technically permissible total mass (kg) 3500 3500 3500

Trailer load braked (unbraked) (kg) 2000 (750) 2000 (750) 2000 (750)

Tyre size 225/75 R 16 CP 225/75 R 16 CP 225/75 R 16 CP

Wheelbase (cm) 345 380 380

Bed dimension middle L x B (cm) 192 x 65 / 45 - -

Bed dimension rear L x B (cm) 194 x 140 / 130 200 x 70

195 x 80 200 / 195 x 194

195 x 140

Refrigerator volume incl. freezer (l) 89 (11) 89 (11) 89 (11)

Heating type Combi 4 Combi 4 Combi 4

Fresh water tank (red. Vol.) (l) 116 (20) 116 (20) 116 (20)

Waste water tank approx. l 92 92 92

Sockets 230 V 4 4 4

Sockets: USB 2 2 2

Inner dimensions storage locker right/

left W x H (cm) 65 x 110

45 x 85 70 x 105

70 x 75 85 x 90

85 x 90

1) 1) 1)

OPT

2) 2) 2)

16) 16) 16)

OPT

4) 4) 4)

Optional Standard Not possible All prices are recommended retail prices in GBP including legal applicable VAT, On The Road Charges (OTR including delivery from Germany, registration and PDI). Possible import duties are not included and will be charged separately.

OPT

VAN MODEL RANGE

OPT Optional • Standard equipment – Not possible All footnotes, see page 62–63.

Configure your dream Motorhome

Also available as a EDITION15: further information on page 22

(15)

28 29

KITCHEN

Ergonomically arranged kitchen with spacious work top

Large soft-close drawers in kitchen 3 burner hob and glass lid

Fridge 89 l with 11 l freezer compartment

Waste bin

BATHROOM

Vario-bathroom

Roof vent with integrated flyscreen blind

Large mirrors

Clothes rail in bathroom

HIGHLIGHTS EDITION15

Leather steering wheel and gear knob in leather trim

Bed conversion single to double bed Edition graphics

Awning 3.5 m Awning 4.5 m

Insulated waste water tank 2nd external storage door (size

depends on layout) Soft furnishing Nebula

Special colour overhead lockers Pre-cabling for reversing camera Radio pre-wiring including speakers Black Chassis colour

LED daytime running lights Fiat Ducato 2,2 l Multijet 103 kW

(140 BHP) - EURO 6 16" alloy wheels

Bumper black in metallic for Light Chassis

Basic Package Style Package

BASIC VEHICLE FIAT DUCATO

Fiat Ducato 2,2 l Multijet 103 kW (140 BHP) - EURO 6

Front Wheel Drive

Daytime running lights, integrated in headlights

Cruise control Driver airbag Passenger airbag

ABS, EBD, ESP incl. ABS and hillholder

Start & Stop function incl. booster Electric operated cab windows and

central locking

Body coloured front bumper Fix & Go breakdown kit Central cup holder

Comfortable driving experience with rear and front axle stabilizers Manual cab air conditioning Disc brakes, heat convection,

tachometer, power steering, immobiliser, 3-point seat belt Steel rims 15" including wheel trims Tablet holder and USB port Driver and passenger seats with

armrests & upholstered covers Driver and passenger seats swivel 75l fuel tank

Height and rake adjustment for driver seat (optional for passenger seat)

16" alloy wheels

CONVERSION

7-year water ingress warranty GRP (glass fibre reinforced plastic)

roof and rear wall Aluminium sidewalls

Roof and sidewall thickness: 34mm, floor thickness: 41mm

Rear moulding with integrated lights in three parts

High quality entrance door with ergonomic handle inside and outside Flyscreen door (one-piece)

Double glazed hinged window with cassette blinds and flyscreens (except for bathroom)

Roof light with frosted perspex glass and flyscreen

Electric step

Large rear garage with lowered frame, lashing rings and interior lighting (depending on model) Splash water seals for the exterior

storage locker and doors Payload in garage up to 150 kg

12)

13)

5)

COMFORT

Ergonomically shaped upholstery for improved seating comfort Isofix for 2 seats

Table extension

High-quality mattress in all beds Removable and washable mattress

cover

Wooden slatted frame in all fixed- beds for better sleeping comfort Spacious storage compartments and

storage options

Ventilation for storage locker and seat backrest

Overhead lockers with softclose system

Furniture in 'Pure Spring' Floor in 'Casual Suite'

INSTALLATIONS

High-performance, maintenance- free leisure battery (95 Ah AGM) On-board control panel supplies information about filling levels and battery capacity

Automatic switching and separating systems for starter and leisure battery as well as for refrigerator Electric charger for leisure and

vehicle battery 12 V / 18 A CEE 230 V external socket with

safety device

Residual Current Device (RCD) LED-Awning light

LED Interior light USB Socket (double)

Water tank incl. boiler 116 l, waste water tank 92 l

HEATING / GAS SUPPLY

Gas bottle locker for 2 x 11 kg gas bottles

Gas heating Combi 4

Gas control valves easily accessible and centrally arranged

VAN

Wardrobe under bed Living area

All footnotes, see page 62–63.

Kitchen with 3-burner hob

Rear bed with high-quality mattresses

STANDARD EQUIPMENT

(16)

30 31 V339

CHASSIS SAFETY PACK Additional weight 0.5 kg Brake assistant with pedestrian and cyclist detection

Lane Assist

Rain and light sensor

Traffic sign and high beam detection

SPECIAL PRICE (€) 840.-

CHASSIS EASY DRIVING PACK Additional weight 0.3 kg Adaptive cruise control

Intelligent speed detection Fatigue detection

SPECIAL PRICE (€) 740.-

BASIC PACKAGE Additional weight 23.5 kg Electric and heated mirrors

Radio pre-wiring including speakers Radio aerial integrated in mirror Height-adjustable passenger seat Panoramic roof light over lounge area Clear glass roof light 40 x 40 Shower cubicle lining

Mirror with indirect lighting and coat hooks Captain chairs with covers

Additional power outlet in overhead locker above the kitchen unit Power outlet in the garage

SPECIAL PRICE (€)

STYLE PACKAGE Additional weight 0 kg Leather steering wheel and gear knob in leather trim Instrument panel with applications (Techno-Trim) Gloss black radiator grill with chrome strips

SPECIAL PRICE (€)

CHASSIS SAFETY PACK Additional weight 0.5 kg Brake assistant with pedestrian and cyclist detection

Lane Assist

Rain and light sensor

Traffic sign and high beam detection

SPECIAL PRICE (€) 840.-

CHASSIS EASY DRIVING PACK Additional weight 0.3 kg Adaptive cruise control

Intelligent speed detection Fatigue detection

SPECIAL PRICE (€) 740.-

BASIC PACKAGE Additional weight 23.5 kg Electric and heated mirrors

Radio pre-wiring including speakers Radio aerial integrated in mirror Height-adjustable passenger seat Panoramic roof light over lounge area Clear glass roof light 40 x 40 Shower cubicle lining

Mirror with indirect lighting and coat hooks Captain chairs with covers

Additional power outlet in overhead locker above the kitchen unit Power outlet in the garage

SPECIAL PRICE (€)

STYLE PACKAGE Additional weight 0 kg Leather steering wheel and gear knob in leather trim Instrument panel with applications (Techno-Trim) Gloss black radiator grill with chrome strips

SPECIAL PRICE (€)

CHASSIS SAFETY PACK Additional weight 0.5 kg Brake assistant with pedestrian and cyclist detection

Lane Assist

Rain and light sensor

Traffic sign and high beam detection

SPECIAL PRICE (€) 840.-

CHASSIS EASY DRIVING PACK Additional weight 0.3 kg Adaptive cruise control

Intelligent speed detection Fatigue detection

SPECIAL PRICE (€) 740.-

BASIC PACKAGE Additional weight 23.5 kg Electric and heated mirrors

Radio pre-wiring including speakers Radio aerial integrated in mirror Height-adjustable passenger seat Panoramic roof light over lounge area Clear glass roof light 40 x 40 Shower cubicle lining

Mirror with indirect lighting and coat hooks Captain chairs with covers

Additional power outlet in overhead locker above the kitchen unit Power outlet in the garage

SPECIAL PRICE (€)

STYLE PACKAGE Additional weight 0 kg Leather steering wheel and gear knob in leather trim Instrument panel with applications (Techno-Trim) Gloss black radiator grill with chrome strips

SPECIAL PRICE (€) INCLUDED IN EDITION 15

INCLUDED IN EDITION 15

SPECIAL PRICE (£)

SPECIAL PRICE (£)

VAN PACKS

All footnotes, see page 62–63.

Vario-bathroom with shower Steering wheel in leather finish

Queen bed Seating area with captain style chairs

and panoramic roof

(17)

32 33

OPTIONAL EXTRAS PRICE ADDITIONAL WEIGHT V132 ED15 V337 ED15 V339 ED15

BASIC VEHICLE FIAT DUCATO

Fiat Ducato 2,2 l Multijet 118 kW (160 BHP) - EURO 6 2,650.- £ 15 kg

Weight increase to 3,65 t (no chassis modification) 220.- £

Traction+ 90.- £ 0.5 kg

9 Shift automatic gearbox (not in conjunction with 120 bhp) 3,260.- £ 18 kg

90 L fuel tank 90.- £ 13.5 kg

Digital instrument cluster 470.- £ 0.3 kg

Headlights with black frame 70.- £

LED daytime running lights 380.- £

Fully LED headlights including indicators and LED daytime running lights. 1,050.- £

Multifunction steering wheel 90.- £ 0.4 kg

OPTIONAL EXTRAS PRICE ADDITIONAL WEIGHT V132 ED15 V337 ED15 V339 ED15

CONVERSION

Two rear corner steadies 260.- £ 6 kg

OPTIONAL EXTRAS PRICE ADDITIONAL WEIGHT V132 ED15 V337 ED15 V339 ED15

COMFORT

Bed conversion for seating area 2) 260.- £ 5 kg

Carpet 230.- £ 5 kg

Wooden duckboard for the shower tray 70.- £ 2 kg

Foldable window blinds 530.- £ 7.5 kg

10)

12)

13)

17)

OPTIONAL EXTRAS PRICE ADDITIONAL WEIGHT V132 ED15 V337 ED15 V339 ED15

BASIC VEHICLE FIAT DUCATO

Fiat Ducato 2,2 l Multijet 118 kW (160 BHP) - EURO 6 2,650.- £ 15 kg

Weight increase to 3,65 t (no chassis modification) 220.- £

Traction+ 90.- £ 0.5 kg

9 Shift automatic gearbox (not in conjunction with 120 bhp) 3,260.- £ 18 kg

90 L fuel tank 90.- £ 13.5 kg

Digital instrument cluster 470.- £ 0.3 kg

Headlights with black frame 70.- £

LED daytime running lights 380.- £

Fully LED headlights including indicators and LED daytime running lights. 1,050.- £

Multifunction steering wheel 90.- £ 0.4 kg

OPTIONAL EXTRAS PRICE ADDITIONAL WEIGHT V132 ED15 V337 ED15 V339 ED15

CONVERSION

Two rear corner steadies 260.- £ 6 kg

OPTIONAL EXTRAS PRICE ADDITIONAL WEIGHT V132 ED15 V337 ED15 V339 ED15

COMFORT

Bed conversion for seating area 2) 260.- £ 5 kg

Carpet 230.- £ 5 kg

Wooden duckboard for the shower tray 70.- £ 2 kg

Foldable window blinds 530.- £ 7.5 kg

10)

12)

13)

17)

OPTIONAL EXTRAS PRICE ADDITIONAL WEIGHT V132 ED15 V337 ED15 V339 ED15

INSTALLATIONS

Second AGM leisure battery 95 Ah 260.- £ 27 kg

Heating Combi 6 E (with el. heating element) incl. digital control panel 560.- £ 2 kg

12V TV pre-cabling incl. flat screen holder 180.- £ 3 kg

Electric floor heating in living area 440.- £ 6 kg

Pre-cabling for solar panel 130.- £ 2 kg

Oven in kitchen 440.- £ 12 kg

Extractor fan 220.- £ 3 kg

OPTIONAL EXTRAS PRICE ADDITIONAL WEIGHT V132 ED15 V337 ED15 V339 ED15

PACKS

Chassis Safety Pack 840.- £ 0.5 kg

Chassis Easy Driving Pack 740.- £ 0.3 kg

Standard Optional extra Mandatory Not possible Please note the information on page 33

OPTIONAL EXTRAS PRICE ADDITIONAL WEIGHT V132 ED15 V337 ED15 V339 ED15

BASIC VEHICLE FIAT DUCATO

Fiat Ducato 2,2 l Multijet 118 kW (160 BHP) - EURO 6 2,650.- £ 15 kg

Weight increase to 3,65 t (no chassis modification) 220.- £

Traction+ 90.- £ 0.5 kg

9 Shift automatic gearbox (not in conjunction with 120 bhp) 3,260.- £ 18 kg

90 L fuel tank 90.- £ 13.5 kg

Digital instrument cluster 470.- £ 0.3 kg

Headlights with black frame 70.- £

LED daytime running lights 380.- £

Fully LED headlights including indicators and LED daytime running lights. 1,050.- £

Multifunction steering wheel 90.- £ 0.4 kg

OPTIONAL EXTRAS PRICE ADDITIONAL WEIGHT V132 ED15 V337 ED15 V339 ED15

CONVERSION

Two rear corner steadies 260.- £ 6 kg

OPTIONAL EXTRAS PRICE ADDITIONAL WEIGHT V132 ED15 V337 ED15 V339 ED15

COMFORT

Bed conversion for seating area 2) 260.- £ 5 kg

Carpet 230.- £ 5 kg

Wooden duckboard for the shower tray 70.- £ 2 kg

Foldable window blinds 530.- £ 7.5 kg

10)

12)

13)

17)

OPTIONAL EXTRAS PRICE ADDITIONAL WEIGHT V132 V337 V339

BASIC VEHICLE FIAT DUCATO

CONVERSION

INSTALLATIONS COMFORT

OPTIONAL EXTRAS PRICE ADDITIONAL WEIGHT V132 ED15 V337 ED15 V339 ED15

INSTALLATIONS

Second AGM leisure battery 95 Ah 260.- £ 27 kg

Heating Combi 6 E (with el. heating element) incl. digital control panel 560.- £ 2 kg

12V TV pre-cabling incl. flat screen holder 180.- £ 3 kg

Electric floor heating in living area 440.- £ 6 kg

Pre-cabling for solar panel 130.- £ 2 kg

Oven in kitchen 440.- £ 12 kg

Extractor fan 220.- £ 3 kg

OPTIONAL EXTRAS PRICE ADDITIONAL WEIGHT V132 ED15 V337 ED15 V339 ED15

PACKS

Chassis Safety Pack 840.- £ 0.5 kg

Chassis Easy Driving Pack 740.- £ 0.3 kg

Standard Optional extra Mandatory Not possible Please note the information on page 33

PACKS

VAN OPTIONAL EQUIPMENT

• Standard equipment Optional equipment – Not possible All footnotes, see page 62–63.

(18)

35

SE M I- INTEG R A TE D O V ERC AB INTEG R A TE D

M OTO R H O M ES

More info Integrated

More info Overcab More info Semi-integrated

References

Related documents

trees (Crescentia) with fleshy, hard-shelled fruits used for m a racas, and the Sausage Tree (Kigelia, p. Handsome wood is prized for cabinetwork.. long) ti pped

[r]

Em "God and the Devil", um poema sobre o famoso par bíblico, Smith ilustra a arbitrariedade da existência humana como um meio para um fim que foi por eles projetado

Using data from the Farm Business and Farm Management, this study rates the credit risk into 10 risk levels plus a default level, defines a farm business cycle with peak, normal

We don't want to have all tiles to be placed next to each other and that's why we need to put some empty space among them: although it does not affect game play, it will make our

Our method uses a linear mixed modelling approach to combine datasets of transcription factor binding motif enrichments in open chromatin and gene expression across the same set of

The purpose of this pilot study was to investigate the impact of the implementation of an enhanced post cardiac ablation education program, compared to standard discharge

However, for the shadow economy to exist in the social optimum along with the legal sector, it is necessary that people’s moral sentiments do not punish illicit transactions
