Model : HS5790
Wireless
PC to TV Kit
Features
• Wireless connectivity from Laptop or PC to any HDTV or Projector • HDMI output for audio & video support and VGA Output for Projectors • Same room coverage, up to 30ft line of site range between PC & TV • Up to 2048 × 1152 resolution. HD Video up to 1080p
Package Contents
• Wireless AV Receiver • Wireless USB Dongle • Installation CD & Manual • DC Adapter
Specifications
Technology UWB(Ulta Wide Band: 3.1 GHz ~ 10.6 GHz) Wireless connection USB to HDMI v.1.3 / USB to RGB / USB to Optical Interface USB 2.0
Resolution Display Resolution up to 2048 × 1152(QWXGA)Video Streaming 1080P 30fps Video Display Modes Mirror, Extend & Primary
Ports & Connectors
Transmitter USB Port × 1
Receiver HDMI® Port × 1 D-sub Port(VGA) × 1 S/PDIF(5.1ch) × 1 Audio Jack(3.5mm) × 1 USB Port × 1 DC-IN Socket × 1 Input Power DC 5V / 1.5A
Configuration
Wireless up to 30ft (10m)
Wireless USB to HDMI - Video Streaming 1080P - Display resoution up 2048x1152 - Display Mode : Mirror, Extended, Primary
HDMI
USB
Front Speaker Center Speaker
Full HDTV Set
Front Speaker
Rear Speaker Rear Speaker
Wireless USB to VGA - Video Streaming 1080P - Display resoution up 2048x1152 - Display Mode : Mirror, Extended, Primary
Wireless S/PDIF (5.1Ch) Wireless Stereo Sound
Wireless USB Port - Web Cam
- Interactive Electronic Whiteboard - Printer, USB Memory
5.1Ch Audio Receiver S/PDIF
Model : HSM25C
Miracast WiFi Wireless
Display Adapter
Features
• Enjoy photos, videos, and any other content on your HDTV - no wires required
• Works with Miracast-certified mobile devices and PCs, as well as most Windows 7/8 laptops
• Works with Intel® WiDi system using software version 3.5 or higher • Live video and audio experience
• Creates a dedicated wireless network for better quality
• Take Bluecast wherever you go : at home, in the office, on business trip
• Easy to use, and everything you need is included
The Bluecast Wireless Display Kit lets you wirelessly display any content from a laptop, tablet, or smartphone on an HDTV. Surf the Web or watch movies from Netflix, Hulu, Amazon, or YouTube - all from the comfort of your living room couch. Bluecast supports up to full 1080p HD video and HD audio, so you can enjoy the convenience of wireless without compromising your HD experience.
Bluecast is perfect at home, on the road, or in the office. Use it to show your vacation photos on your HDTV at home; stream the video on your laptop to the HDTV in your hotel room; or share your laptop with the conference room projector.
Configuration
Support for Miracast, WiFi, DLNA
Tablet Notebook Rx Adapter
Smart-Phone HDMI
Features
• Compliant with Super Speed USB 3.0 spec with transfer rates up to 5Gbps
• Backward compatible to USB 2.0 spec • DVI and HDMI display outputs compliant • Supports display resolution up to 2048 × 1152 • Supports full HD 1080p video playback via USB 3.0 • 10/100/1000 Mbps Ethernet connectivity • Provides six USB 3.0 ports
• Supports MIC in / Headphone out • USB Plug&Play connectivity
System Requirements
• Intel Dual core 2.0 or above• 2GB system Memory & 50MB of available disk space • Graphics Chipsets supported : Intel, AMD and NVIDIA • An available USB 2.0 or USB 3.0 Port
• Windows 8 / Windows 7 / Vista & XP
Package Contents
• USB 3.0 Dual Video Docking Station × 1 • Power Adapter × 1
• CD(Driver & User’s Manual) × 1 • Quick Installation Guide × 1 • USB 3.0 Cable × 1
Model : HSD390DS
USB 3.0 Dual Video
Docking Station
Specifications
Host Interface USB 3.0
Connectors
Video output: HDMI
® Female Connector
DVI-I HDDE 30pin Female Connector Host upstream Port USB 3.0 B type Female connector HUB 3.0 Port USB 3.0 A Type Female Connector Audio Port 3.5mm stereo Mic & Headset Ethernet Port RJ45 Connector Power DC Power Jack
Display resolution HDMI
® 2048 × 1152
DVI 2048 × 1152 Audio Stereo out and digital audio out (HDMI) Ethernet 10/100/1000Mbps
Power Power Adapter DC 20V / 2A
* Specification is subject to change without further notice.
USB 2.0 / 3.0 Devices Printer, Mouse, Keyboard, Scanner, Camera
5Gbps Super speed
To filess transfer
USB 2.0 / 3.0 Devices Digital Video / USB Device
MIC & Headphone Ethernet
HDMI & DVI Monitor
Laptop
Features
• Compliant with Super Speed USB 3.0 spec with transfer rates up to 5Gbps
• Backward compatible to USB 2.0 spec • DVI and HDMI display outputs compliant • Supports display resolution up to 2048 × 1152 • Supports full HD 1080p video playback via USB 3.0 • 10/100/1000 Mbps Ethernet connectivity • USB Plug&Play connectivity
System Requirements
• Intel Dual core 2.0 or above
• 2GB system Memory & 50MB of available disk space • Graphics Chipsets supported : Intel, AMD and NVIDIA • An available USB 2.0 or USB 3.0 Port
• Windows 8 / Windows 7 / Vista & XP
Package Contents
• USB 3.0 Dual Video Adapter × 1 • CD(Driver & User’s Manual) × 1 • Quick Installation Guide × 1 • USB 3.0 Cable × 1
Specifications
Host Interface USB 3.0 Video Interface DVI, HDMI®
Ethernet 10/100/1000Mbps RJ45
Connectors Video output: DVI HDDE 30pin and HDMI
® Female Connector
Host upstream link : USB 3.0 Micro B type connector Connectivity Up to 6 Display Adapters on a computer
Supported Modes Extended Desktop(Default), Mirrored Desktop, Primary Display
* Specification is subject to change without further notice.
Model : HSD390DH
USB 3.0 Dual Video
Adapter
HDMI
Features
• Compliant with Super Speed USB 3.0 spec with transfer rates up to 5Gbps
• Backward compatible to USB 2.0 spec
• DVI / HDMI / DisplayPort display outputs compliant • Supports display resolution up to 2048 × 1152 • Supports full HD 1080p video playback via USB 3.0 • USB Plug&Play connectivity
System Requirements
• Intel Dual core 2.0 or above
• 2GB system Memory & 50MB of available disk space • Graphics Chipsets supported : Intel, AMD and NVIDIA • An available USB 2.0 or USB 3.0 Port
• Windows 8 / Windows 7 / Vista & XP
Package Contents
• USB 3.0 Graphics Display Adapter × 1 • CD(Driver & User’s Manual) × 1 • Quick Installation Guide × 1 • USB 3.0 Cable × 1
Specifications
Host Interface USB 3.0 Video Interface DVI / HDMI / DP
Connectors Video Output : DVI / HDMI / DP
Host upstream link : USB 3.0 Micro B type connector Connectivity Up to 6 Display Adapters on a computer
Supported Modes Extended Desktop(Default), Mirrored Desktop, Primary Display
* Specification is subject to change without further notice.
HSD350DV
(USB 3.0 to DVI Port)
HSD350DP
(USB 3.0 to Display Port)
HSD350HD
(USB 3.0 to HDMI Port)
USB 3.0 (Micro B Type)
Model : HSD350DV / HSD350DP / HSD350HD
USB 3.0 to Multiple Screen
Graphics Display Adapter
HDMI
Specifications
Features
• USB 3.0 Graphics Display Adapter • Supports a data transfer rate of up to 5Gbps • Plug-and-Play, hot swappable and no driver needed • Backward compatible to USB 2.0 & 1.1 specifications • LEDs allow for easy status monitoring
• 1 USB smart charger provides high-speed intelligent charging • Power Adapter : 5V/2A(4Port)
5V/4A(7Port)
Model : HSH340 (4Port) / HSH370 (7Port)
Super Speed 5Gbps USB 3.0
HUB with Power Adapter
USB 3.0 Micro USB 3.0 HSH340 (4Port) HSH370 (7Port) Front USB 3.0 Port 7Port rear (HSH370) Power port Rear USB 3.0 Port
Uplink Port iPad / smartphone provides a dedicated port for charging
Front USB 3.0 Port 4Port rear (HSH340) Power port Uplink Port Side
Hanshin Information Technology Co., Ltd.
2F, No. 201, IT Venture Town, Taprip-Dong 694, Yuseong-Gu, Daejeon, Korea Tel : 82-42-933-8507 Fax : 82-42-933-8509 E-mail : [email protected]
