Developing for MSI Android Devices

(1)

Android Application

Development

Enterprise Features

October 2013

(2)

Developing for MSI Android Devices

• Majority is the same as developing

for any Android device

• Fully compatible with Android SDK

• We test using the Android

Compatibility Test Suite (CTS) to

ensure compatibility

• We have added extensions and

features to enable enterprise

applications/deployments

(3)

Getting Started with Android

Development

(4)

• Download ADT bundle from

http://developer.android.com/sdk/index.html

• Single download, includes

everything you need to begin

developing apps (almost)

– Eclipse + ADT plugin

– Android SDK Tools

– Android Platform-tools

Install the Android Developer Tools

– Android Platform-tools

– The latest Android platform

– The latest Android system image for the emulator

• JDK 6 (JRE alone is not sufficient)

from Sun (Oracle)

– JDK 7 not officially supported, but works

http://www.oracle.com/technetwork/java/javasebusiness/d

(5)

• MSI devices fully compatible with ADB and other tools

• ADB creates a link over USB used for command line tools and Eclipse IDE

debugger

• Google provides USB ADB driver with Android SDK

• Configuring Google USB ADB Driver

– Windows XP and Windows7 Driver available

Configuring Android Debug Bridge

(ADB)

– Windows XP and Windows7 Driver available

• Copy driver to PC

• Update to adb_usb.ini to include Motorola devices (0x0451 and 0x05E0)

• Connect device to PC and navigate to folder with driver when asked

– Windows 8

• Disable device driver signature enforcement

• Same procedure as above

– Linux

(6)

USB Media Transfer Protocol (MTP)

• Starting with Ice Cream Sandwich , Android changed its

default USB protocol from USB Mass Storage to Media

Transfer Protocol (MTP)

• Windows 7 works with MTP out of the box

• Windows XP requires update to Windows Media Player 11

to install MTP patch

–

Click Help -> Check for Player Updates from WMP

–

Or download MTP kit from

http://www.microsoft.com/en-us/download/details.aspx?id=19153

• Ensure select Composite ADB Device when installing USB

(7)

• Use system settings to Enable Android Debug Bridge

Device Set- Up for Development

Jelly Bean

Settings -> Developer Options Gingerbread

(8)

Android API Levels

• Each Version of Android has a unique API Level, allowing applications

to ensure compatibility

– Gingerbread devices – API Level 10

– Jelly Bean devices – API Level 16

– Complete list at developer.android.com/guide/topics/uses-sdk-element.html

• The Application manifest.xml <uses-sdk> element lets you define

compatibility with one or more versions of Android

– android:minSdkVersion — Specifies the minimum API Level on which the application is able to run. The default value is "1“ (runs on all versions)

– android:targetSdkVersion — Specifies the API Level on which the application is designed to run (i.e. what is was tested on)

– android:maxSdkVersion — Specifies the maximum API Level on which the application is able to run.

(9)

More Info on

Native Development

• Google’s Android Training Site:

http://developer.android.com/training/index.html

• Google’s API Reference:

http://developer.android.com/reference/packages.html

• Google’s Developer News and Documents:

(10)

Retrieving Battery Status

• Receive standard Android

ACTION_BATTERY_CHANGED

broadcast Intent

• Intent Extended Data has various battery information

• Motorola Adds additional battery data in the

standard Android Intent

(11)

Standard Battery Data Available

Constant Data value

EXTRA_HEALTH integer containing the current health constant.

EXTRA_ICON_SMALL integer containing the resource ID of a small status bar icon with battery state

EXTRA_LEVEL integer field containing the current battery level, from 0 _{to EXTRA_SCALE} EXTRA_PLUGGED integer indicating whether the device is plugged in to a _{power source}_{power source} EXTRA_PRESENT boolean indicating whether a battery is present

EXTRA_SCALE integer containing the maximum battery level EXTRA_STATUS integer containing the current status constant

EXTRA_TECHNOLOGY String describing the technology of the current battery EXTRA_TEMPERATURE integer containing the current battery temperature

(12)

Motorola Battery Data Available

Constant Data value

"bkvoltage" Backup Battery Voltage "mfd" Battery Manufacture Date "serialnumber" Battery Serial Number "partnumber" Part Number for Battery "uniqueid" Unique ID for Battery "uniqueid" Unique ID for Battery

"ratedcapacity" Rated Capacity of the Battery

(13)

Example: Retrieving Battery Status

mBattFilter = new IntentFilter(Intent.ACTION_BATTERY_CHANGED );

mBattIntent = this.registerReceiver(this.batteryInfoReceiver, mBattFilter);

private static final String MOTO_EXTRA_SERIAL_NUMBER = "serialnumber";

private BroadcastReceiver batteryInfoReceiver = new BroadcastReceiver() {

Register the Intent

Receiver runs when battery

private BroadcastReceiver batteryInfoReceiver = new BroadcastReceiver() { @Override

public void onReceive(Context context, Intent intent) { /* Standard Android Battery Information */

int status = intent.getIntExtra(BatteryManager.EXTRA_STATUS,-1);

String tech = intent.getExtras().getString(BatteryManager.EXTRA_TECHNOLOGY);

int voltage = intent.getIntExtra(BatteryManager.EXTRA_VOLTAGE, 0);

/* Motorola Solutions specific Data (only one field shown here as an example)*/

String SerialNumber = intent.getExtras().getString(MOTO_EXTRA_SERIAL_NUMBER);

when battery status changes

Battery Info is in Intent “extra”

(14)

• On ET-1, 5V power for

accessories can be

controlled by an application

via Intents

• Accessory port is the top

USB Power

• Accessory port is the top

USB port

USB Power Control Intents

com.motorolasolutions.intent.USBPOWERENABLE

com.motorolasolutions.intent.USBPOWERDISABLE

(15)

What is Mx?

• Mx represents a suite of Enterprise Features

on Top of standard, commercially available

AOSP (Android Open Source Project)

• Mx maintains Compatibility with Standard

Android Applications

• Mx maintains Compatibility with Standard

Android Applications

• There is no generally available exposed API

Surface for Mx (currently exclusive to MDM

partners)

(16)

• Multiuser Authentication

• Separation of User Data Spaces

• Reduced System Settings Dialog

• Whitelist Application

• Secure Storage

• Volume Encryption

Mx OS Extension Features

• Volume Encryption

• Full SD Card Encryption

• Certificate Management

• Silent Application Installation

• Ability to enable/disable USB Mass Storage & ADB

• Set a New APK as the Default Home Screen

(17)

• Overview

–

Allows multiple users to access the device

• Each user optionally has their own data space and settings

–

Unlock screen replaced by a credentials dialog

• Username and password required to unlock the device

–

Notification area will indicate the current user. Tapping on the

MX Multiuser Framework

–

Notification area will indicate the current user. Tapping on the

notification will trigger the logout process

–

Choice of Local or Remote Authentication

• Local database on the device

• Authenticate against an Active Directory server

• When remote authentication is selected, users in the local database are permitted as well.

–

Only administrator users are permitted to modify any system

setting

(18)

• Development Impact

–

The multiuser framework is transparent

–

Although data separation adds a layer of abstraction, no special

coding is needed

• Avoid using hard coded paths

–

All open applications are forced closed upon logout

Development Info & Tips

MX Multiuser Framework

–

All open applications are forced closed upon logout

• Exception: those applications or services that are required to span

users

• Tips

–

Always create at least one administrative user in the local

database. This will allow a device using remote authentication

to be unlocked and configured if connection to the AD server is

lost.

(19)

• Overview

–

Works in conjunction with Multiuser Framework

–

Each user is assigned to a group(s)

–

Each group is assigned a white list of packages which are

permitted

–

Each white list consists of three separate pieces

Development Info & Tips

MX Application Lock

–

Each white list consists of three separate pieces

• System list – applications needed for the system to operate properly

• Common list – applications permitted for ALL groups

• Individual list – applications permitted for the individual group

–

Users included in multiple groups are permitted the sum of the

individual list for each group

–

Packages are defined by their package name

–

Any application not included on the white list is NOT permitted

to be installed or launched

(20)

• Development Impact

–

All applications spawned from another application must be

included on the same white list

• Tips

Development Info & Tips

MX Application Lock

• Tips

–

Be sure to create an administrator group for users that are

permitted to use ALL applications

–

Be careful with use of the wildcard character in the white list,

this may lead to permitting applications that are unintended for

that group

(21)

• Overview

– Encryption can span the entire SD Card or only an individual folder tree

– When the entire SD Card is encrypted:

• The card will be reformatted

– When only a folder tree is encrypted:

• Different folder trees can use different keys

• The folder tree can be mounted under /data or /sdcard

Development Info & Tips

MX Secure Storage

• The folder tree can be mounted under /data or /sdcard

– Encryption / decryption occurs between the file system and the application making this feature transparent to applications.

– The auto mount feature can be used to direct the system to mount the encrypted data automatically on reset

– If the encryption key is known, the data within the encrypted area can be copied to a Linux system and read

(22)

• Development Impact

–

None: once the encrypted area is mounted, the data from the

application is read and written using standard algorithms

• Tips

–

In many cases the SD Card is used to deploy OS updates. If the

entire SD Card is encrypted, the recovery mechanism will not be

Development Info & Tips

MX Secure Storage

entire SD Card is encrypted, the recovery mechanism will not be

able to read the SD Card

–

When a folder tree is mounted under /data, make sure the path

is correct for the intended application

–

A folder tree cannot be mounted if the mount point contains

unencrypted data

–

Factory reset will erase the encryption keys. Be sure to record

and secure encryption keys to re-install into a device that has

been factory reset.

(23)

MSI Utilities – 4 Basic Utilities

1) Multiuser Administrator - on-device utility used to enable/disable the Multiuser feature and populate the credentials database.

2) AppLock Administrator - on-device utility used to enable/disable the Application Lock feature and install groups and white list files

3) Enterprise Administrator - a desktop utility used to manage users, groups and white lists. The export function of this utility will write files in the format necessary for the Multiuser

Administrator and the AppLock Administrator (migrating to XML)

4) Secure Storage Administrator (SSA) – on-device utility used to install and delete encryption keys. Also used to create, mount/un-mount and delete EFS partitions.

(24)

Enterprise Administrator

• Runs on Windows

• Manage

–

Users

–

Groups

–

Packages

–

Packages

• Local or Server based user authentication

• Import and Export

–

Users

–

Groups

(25)

(26)

Determining Packages Installed on Device

• On Host computer, open a command prompt

(or a terminal in Ubuntu)

C:\ [path of sdk]\platform-tools\adb shell

$pm list packages –f > sdcard/pkglist.txt

$exit

(27)

(28)

(29)

(30)

Multi-User Administrator

• Users must be defined in the Enterprise

Administrator before enabling

• Export Files from the Enterprise Administrator

• Copy to root of device

• Loading User list immediately enables

Multi-user Mode

(31)

(32)

Multi-User

Enabled

•Note Multi-User icon in upper left •Drag icon down to log off

(33)

App Lock Administrator

• Multi-User must be enabled before App Lock

• Groups and White lists must be defined in the

Enterprise Administrator before enabling

• Export Files from the Enterprise Administrator

• Copy to root of device

(34)

(35)

Secure Storage Administrator

• Allows creation and maintenance of

encryption keys

• Allows creation, control, and deletion of

encrypted volumes

(36)

(37)

Enterprise Home Screen (EHS)

• Comparable to Windows AppCenter

• Separately Downloadable App (apk), XML configured (folder = /enterprise/usr/)

• Device Oriented (i.e. Not Individual User)

• Replacement App Launcher – exposes only chosen icons

• Ability to selectively choose Icons/apps on home screen Kiosk Mode (auto app invocation preventing user from

• Kiosk Mode (auto app invocation preventing user from exiting)

• Auto Launch (auto app invocation allowing user to exit)

• A Separate “Tools Screen” (to better organize)

• An Admin Password for enabling configuration (256 bit AES encrypted)

(38)

Enterprise Home Screen

Enterprise Home Screen (EHS) is a replacement application launcher Designed to allow only specified applications to be launched.

Enterprise Home Screen is configured via an xml file found in the /enterprise/usr/ folder in the internal memory of the device. This file is read on startup and every time the home button is pressed while in EHS.

Features…

• Kiosk mode and auto launch applications

• User and Admin modes

– Admin password with 256 bit AES encryption

• Tools menu, battery and wireless status screens

• Customize

– EHS launcher title

– Icon text and background color

– Background wallpaper

– Orientation

(39)

Enterprise Home Screen (EHS)

https://developer.motorolasolutions.com/docs/DOC-1875 4

(40)

Enterprise Home Screen

Enterprise Home Screen is configured via an xml file. This file is read on startup and every time the home button is pressed while in EHS.

1. Auto launch (optional) 2. Kiosk launch (optional) 3. Applications

4. Tools 5. Password 5. Password 6. Preferences

•Title text displayed in the launcher title bar

•App icon label background color

•App icon label text color

•Screen orientation

•Bypass swipe to unlock

(41)

Button Remapping

(42)

OS - Key Button Remapping

• Each device has external buttons that can be remapped

to change function or launch an application

• Remapping tool on device under Settings|Key

Programmer

• To deploy to multiple devices, configure the buttons as

desired and then export an XML file

• To deploy mappings on MC40

– Copy the XML file to a /enterprise/user/keypad folder on the device

– NOTE: no reset is required, the XML file will be automatically consumed and the keys remapped

(43)

Folder Persistence in MSI Android Devices

Folder Reboot Enterprise Reset Factory Reset

/data Persistent Not Persistent Not Persistent /enterprise Persistent Persistent Not Persistent /sdcard Persistent Persistent Persistent

• Enterprise and Factory reset thru recovery mode (similar to an OS

update)

• Reset files available from

http://supportcentral.motorolasolutions.com

• Ensure you use correct reset file (gingerbread or Jellybean)

(44)

GOOGLE MOBILE SERVICES

Google offers a variety of applications and associated services for developers independent of the Android Open Source Project. The services are available as native

Android API’s via an SDK extra. The services can only be used on Android devices that choose to include them.

(45)

SECURITY

Google Mobile Services requires devices to be identifiedwith a specific GoogleID, and routes enterprise data through Google’s servers.

PRIVACY

Google revamped their privacy policy in early 2012

WHY GOOGLE MOBILE SERVICES IS NOT

PRESENT ON ALL MSI DEVICES

PRIVACY

Google revamped their privacy policy in early 2012 allowing for richer user profiling across all services, for targeted advertising.

Usage acceptance allows Google to track a device’s every move.

Google may collect IP Addresses,location, nearby wi-fi info, local storage and device setting details.

(46)

(47)

More Information

•

Join the Motorola Solutions Android Developer Community

https://developer.motorolasolutions.com/community/android

• The “Go To” place for all your MSI Android development needs

(48)

THANK YOU

MOTOROLA, MOTO, MOTOROLA SOLUTIONS and the Stylized M Logo are trademarks orregistered trademarks of Motorola Trademark Holdings, LLC and are used under license. All other trademarks are the property of their respective owners. © 2013 Motorola Solutions, Inc. All rights reserved.
