MOBILE APPLICATIONS UPDATE AND OVERVIEW 4 DECEMBER 2012 ANTTEC

(1)

MOBILE APPLICATIONS UPDATE AND

OVERVIEW

(2)

Mobile applications

Update and Overview

Bert Van Vreckem Wim De Bruyn

HoGent, FBO, Applied informatics

[email protected] [email protected]

Thanks to the Agoria colleagues for extra information

(3)

Wifi local short range

Wireless networking for mobile user interfaces

Wifi local short range 3G-4G coverage

Development environments Security

(4)

Mobile Solutions in Industry

Mobile

TCP/IP

• TCP/IP everywhere (Controllers / PROFINET IO)

• One-wire approach

WIRELESS

• Controlled entry of Wireless devices • Anywhere, anything…

Mobile

Solutions

in

Industry

WIRELESS • Anywhere, anything…

• Flexibility

SECURE

• Robust – High available • IP65 / Outdoor / EMC

INDUSTRIAL

• Focus on Plant availability • Remote access

(5)

Wireless technologies – different characteristics

Data rate in Mbps HSPA IEEE 802.11n IEEE 802.11g/a IEEE 802.11b WLAN/ IWLAN > 100 54 11 2 Range, mobility Personal Area (PAN) Local Area (LAN) Wide Area (WAN) 100 m 200 m HSPA UMTS/ EDGE/ GPRS/ GSM Wireless modem 433, 868, 915 MHz (US only) 0,1 0,01 Bluetooth IEEE 802.15.4 WirelessHART

(6)

Consumer versus Industrial WLAN - Points of attention

Consumer market

Single Point (1 AP)

Limited Wireless clients

Clients are mostly not

• Industrial

Market

Multiple AP’s (Roaming) Several Wireless clients Moving clients

Resulting Features

Supporting 2,4 & 5 GHz (IEEE 802.11

a/b/g/h)

Robust housing IP65 Temp: –20°C ... +60°C with condensation

(outdoor)

Power Supply 19-57V DC

Clients are mostly not

moving Best-chance Performance Comfort Classical shared medium Moving clients Deterministic Performance

Reliable Solution (SLA) Harsh Conditions

– Industrial features

Effective ROI driven

solution DC Flexible/Redundant Easy Configuration with Web-wizards Configuration Plug for easy replacement

Industrial certifications ATEX, EMC, UL, FM,

…

Supporting latest new Security

(7)

Planning iWLAN Applications

Site Surveys

Planning

• Use it as offline tool

• See the effect of access points

Commissioning / Maintenance

• Us it as online tool

• No iWLAN without preparation

• Us it as online tool

(8)

Planning iWLAN Applications

(9)

Planning iWLAN Applications

Current WLAN radio standards

2.4 GHz

5 GHz

IEEE 802.11b IEEE 802.11g IEEE 802.11a*) _{IEEE 802.11h}*)

Transmission

modes DSSS OFDM OFDM OFDM

Recommended for PN-IO / Safety !

Saturation might occur… * Germany Range Indoor: 30 m Outdoor: 100 m Indoor: 30 m Outdoor: 100 m Indoor: 10-15 m Outdoor: -Indoor: 30-50 m Outdoor: > 1000 m**) Transmitting power 100 mW 100 mW 63 mW TPC 200 mW (indoor) 1 W (indoor/outdoor)

Data rate 11 MBit/sec 54 MBit/sec 54 MBit/sec 54 MBit/sec

Susceptibility

to faults High Medium Low Low

Non-overlapping channels 3 3 4 19 Approved frequencies Almost standardized Almost

(10)

Planning iWLAN Applications

(11)

Planning iWLAN Applications

Select the right antenna

-3dB circle -3dB intersection points 75_° beam width Directional Versus Omni-directional

(12)

Focus on Security ISA99

Enterprise Control Network

WinCC Web Client OS Web Client Data Monitor Web Client Historian

Web Client Firewall Domain Controller

Support Station Support Station Router ISDN Historian Web Client SIMATIC IT Server SIMATIC IT SQL- Server Remote Support

DMZ – Data Access & Exchange MES Zone ERP Zone WAN Domain Controller Web Navigator Server OS Web Server Front-Firewall

Firewall, ISA Server _WSUS

Server RDP Gateway Virenscan Server Mobile Support Perimeter Network Manufacturing Operations Network

Control System Network

Process Control Network Support Station Router ISDN WinCC Client OS Client Domain Controller Maintenance Server Engineering Station OS Server OS Server WinCC Sever WinCC Sever S7-400H S7-400 S7-400H DCS Zone Local Support S7-400 Back-Firewall

Firewall, ISA Server

(13)

3G Mobile coverage ex. Base, 4G in experimentation phase

(14)

Comparison, very implementation dependend

3G 4G

Data Throughput: Up to 3.1mbps Practically speaking, 3 to 5 mbps but potential estimated at a range of 100 to 300 mbps.

Peak Upload Rate: 50 Mbit/s 500 Mbit/s

Peak Download Rate: 100 Mbit/s 1 Gbit/s

14

Peak Download Rate: 100 Mbit/s 1 Gbit/s

Switching Technique: packet switching packet switching, message switching

Network Architecture: Wide Area Cell Based Integration of wireless LAN and Wide area.

Services And Applications: CDMA 2000, UMTS, EDGE etc

Wimax2 and LTE-Advance

Forward error correction (FEC):

3G uses Turbo codes for error correction.

Concatenated codes are used for error corrections in 4G.

(15)

How to come to a cross-platform

Software development environments

How to come to a cross-platform

application environment ?

(16)

Leading development platforms hardware-related

iOS (Apple)

Android (Linux-like) Webkit Blackberry OS Symbian (Webkit Gecko) Symbian (Webkit Gecko)

Windows Mobile – ME || Windows 8 : Visual studio This is very much in use in industrial environments

(17)

Market Share April 2011

(18)

Mobile Application Development platforms

(19)

(20)

(21)

IDE

HTML/CSS/JS

Using HTML5/CSS3/Js for Mobile Development

Apple

App Store Android

Marketplace

Library

Package

(22)

Code your pages

“Run”

How to combine these tools !

Titanium SDK

Running!

Project in XCode/ObjC

(23)

Leading cross-platform development solutions

Rhomobile, Rhodes Appcelerator, Titanium Widgetpath Phonegap (Adobe!) 23 Phonegap (Adobe!) Mosync

(24)

Information Security in mobile applications

C: Confidentiality (secure tunnels)

I: Integrity (no changes possible)

A: Availability for authenticated users = CIA 24 = CIA D: Disclosure A: Alteration D: Denial = DAD

(25)

Internet of Things & Mobile applications

(26)

Thank you for your attention!

Questions ?

Up to the user-cases - presentations

Possibility to have questions during panel-discussion Informal questions during break and networking

26 Informal questions during break and networking

Visit the booths and discuss with your peers [email protected]
