SOFTWARE UPDATE

NOTICE

9200/9200 II

9300/9300 II

DATE

APRIL, 1975

---PRODUCT:

92001920011193001930011

841118414 DNCOS REVISION

5. O. 0

(2)

(3)

\ .... /

A. SOFTWARE UNIT:

Ident.

Master 8411/8414 System Preparation Tapes Master Tape #1

Master Tape #2

Rev. Block Count

5.0

B. REASON FOR RELEASE:

C.

D.

1. Several enhancements to the RPG compiler, including the calculation

time EXCEPTION operation.

2. Initial release of a tape cross-referencing utility and a disc

cross-referencing utility.

3. Initial release of the 8411/8414 Direct Processor IOCS.

4. The capability of adding records to a sequential disc file.

5. Implementation of the System Execution Area and its related software.

6. Revisions to many areas of Disc NCOS software, including Sort Merge,

Transients, Supervisor and Job Control, Assembler and Linker, Librarian, Dump/Restore and the Sequential Disc IOCS.

SOFTWARE RESTRICTIONS:

See individual Appendices for discussion of restrictions. HARDWARE CONFIGURATION - Minimum for System Generation:

1. 24-K Memory

2. Two disc drives (8411 or 8414)

3. Card Reader (type ¢7ll)

E. SPECIAL NOTES:

1. Extensive changes have been made to all areas of the disc software.

I t is suggested you do not attempt to generate or use this software without first reviewing this release memo.

2. All loadable modules have been upgraded to the latest revision level.

The loadable supervisor includes the Control Stream from Dis~ feature,

which may be used for system generation. The loadable RllT supplied

is the latest version and includes the "Source Code from Disc Feature".

3. Only one version of this disc software release has been prepared;

its loadable supervisor uses the standard card reader (type ¢7ll) as

a control stream reader. If i t is necessary to generate a system

which will employ a different control stream read device, the generation must be done at an installation which has the standard reader or else the loadables at the beginning of each master disc

must be replaced with loadables generated and linked for the appropriate control stream reader before generating the final system.

4. The default System Job Control Stream file for the Job Control program

supplied herewith is SYSFILE (SJCS=SYSFILE).

1 of 3 9200/920011/9300/930011

Memo #147

(4)

5. The loadable non-concurrent supervisor which is supplied for system generation purposes includes the following channel assignments.

L.U .#~Hex) Channel Device

ALL HEX

~~-~7 3~-37 8411/8414 Disc Drives

~8 ~l Card Reader

~9 ~2 Serial Punch

~A ~3 Bar Printer

~B ~7 l~~l

~C ~6 Row Punch

~D ~5 Optical Document Reader

~E ~C Paper Tape

~F ~B Drum Printer

6. The following parameters were used to generate the loadable Supervisor in this release. This supervisor occupies 4,992 (X'138~') bytes.

7.

8.

9.

AFl'R=ALL SIZE=24 CSR=CRD DEVA=8 SJCS=YES SYST=8411 DCUl=X·3~' UNTl=8 DUMP=TEMP

There is a leadable Disc Reportlrogram Generator on the master tape/ disc with a base address of X' '. I t was linked with 3 disc label parameter areas reserved. If 1S compiler meets the installation's requirements, the user can omit the linking of RIIT, and use the leadable RIIT included in this release.

There is no objection to users substituting other program names for UNIVAC-supplied utilities, e.g. "PRGM PHASEZRO,*" may be changed to "PRGM DSORT,*" or whatever other name is desired in the linker deck. Names of overlays (PHASE statements) ~ ~ be changed however, nor may names of programs within the RPG or COBOL compilers be altered. Two versions of an RPG compiler (R411 plus RIIT, Rev. 3 plus Rev 4, etc.) must not be present in the same sysfile.

The following appendices are included in this release:

A Master Tape/Disc Table of Contents

B System Job Control Stream

C System Generation Procedures

D Transient DNCOS 8411/8414 RPG

E 8411/8414 Sort Merge

F Implementation of DNCOS in 16-K Memory

G Tran and Transients

H Supervisor and Job Control

I 8411/8414 Disc Assembler (KSMB)

J 8411/8414 Disc Linker (DLll)

9200/920011/9300/930011

(5)

'"--,,

K Librarian (LIBS)

L Miscellaneous IOCS

M OS-500

N 8411/8414 Disc Utilities (DASM, DPRT, ISF)

o

Dump/Restore Utility (DPRS)

P Tape Cross-Reference Utility

Q Disc Cross-Reference Utility R NOTE Job Control Card

S SKIP Job Control Card

T VOL Job Control Card

U Sequential Disc IOCS (DSPIT AND DTFSD)

V Direct Processor

W DTFMT, DMTIO, IMTIT

X The System Execution Area

Y Halts

10. All SUR's that were to be corrected in Revision 5.¢ are cleared with this release.

F. ORDERING PROCEDURES:

Master 8411/8414 System Preparation Tapes Rev. 5.¢ are available with this release on tape or 8411/8414 Disc. The software may be ordered by forwarding the attached "Software System Support Request" directly to Software Order Services with applicable Software Media. i.e. two tapes

or two 8411 disc or 1 8414 disc unit.

Sperry Univac 9200/9300 Software Coordinator PDC Software Order Services

P.O. Box 500, Jolly

&

Township Line Roads Blue Bell, Pennsylvania 19422

Note: All users outside of the United States should check with their local UNIVAC subsidiary office for distribution procedureso

The above applies to United States Customers only.

G. DESTRUCTION:

This memo supersedes and orders the destruction of 920011/9300/930011 Memo #141, dated August, 1974, and its updates. All corrections and

changes described in Memo #141's update memos have been incorporated in this releaseo

3 of 3 _Memo9200/9200Il/9300/9300II _#147

(6)

(7)

--\...-/
