The current Instruction Manual contains information necessary for installation,

commissioning and operation of the TAVRIDA ELECTRIC MV vacuum circuit breakers. It is

absolutely necessary for the proper use of the vacuum circuit breakers to read the Instruction

Manual carefully before starting and to adhere to the instructions and relevant regulations.

SAFETY FIRST

Take note of the operating loads of the vacuum circuit breakers specified in the technical data.

Check that this manual is available to all persons concerned with installation, commissioning and

operation.

Check that the installation position (distances, spatial separation, and the surroundings) is

suitable for the switching devices.

Check that all the installation, commissioning and the operation is carried out by electrical

specialists.

Check that during installation, commissioning and operation, the respective regulations (such as

IEC) as well as appropriate national safety regulations have been adhered to.

Take note that in the operation of the vacuum circuit breakers inevitably certain parts of this device

are subject to dangerous voltage and that mechanical parts, including remote control ones, can

move quickly. Non-adherence to these warning instructions can lead to equipment damage, serious

injury or death.

Note especially the important or danger information marked as follows in this manual:

Low voltage devices (namely control modules of all types) meet the requirements of the EMC Directive 89/336/EEC, the Low Voltage Directive 73/23/EEC

(3)

CONTENTS

PRESENTATION 5

PART NUMBERING 6

MARKING 6

Marking of switching modules 6

Marking of control modules 7

SEALING 8

Sealing of switching modules 8

Sealing of control modules 8

SWITCHING MODULES ISM/TEL 9 Product range 9 Design 10 Overall design 10 Magnetic actuator 11 Vacuum interrupters 12 Operation 13 Closing 13 Opening 13 Manual closing 14 Manual opening 14 ISM/TEL-12-20/1000-051(F) 15 ISM/TEL-12-20/1000-052(F) 15 ISM/TEL-12-20/1000-055(F) 15 ISM/TEL-12-20/1000-067(F) 15 ISM/TEL-12-25/800-066 16 ISM/TEL-12-25/800-068 16 ISM/TEL-12-25/800-081 16 ISM/TEL-12-25/800-082 16 ISM/TEL-12-25/800-083 16 ISM/TEL-12-25/1250-066 17 ISM/TEL-12-25/1250-068 17 ISM/TEL-12-25/1250-081 17 IISM/TEL-12-25/1250-082 17 ISM/TEL-12-25/1250-083 17 ISM/TEL-12-31.5/1600-066 18 ISM/TEL-12-31.5/1600-068 18 ISM/TEL-12-31.5/1600-081 18 ISM/TEL-12-31.5/1600-082 18 ISM/TEL-12-31.5/1600-083 18 ISM/TEL-24-16/800-057 19 ISM/TEL-24-16/800-058 19 ISM/TEL-12-20/1000-089 20 ISM/TEL-24-16/800-053 21 Auxiliary switches 22 Overall drawings 23 ISM/TEL-12-20/1000-051(F) 23 ISM/TEL-12-20/1000-052(F) 23 ISM/TEL-12-20/1000-055(F) 24 24 ISM/TEL-12-25/800-066, ISM/TEL-12-25/1250-066, ISM/TEL-12-31.5/1600-066 25 ISM/TEL-12-25/800-068, ISM/TEL-12-25/1250-068, ISM/TEL-12-31.5/1600-068 25 ISM/TEL-12-20/1000-067(F)

(4)

ISM/TEL-12-25/800-081, ISM/TEL-12-25/1250-081, ISM/TEL-12-31.5/1600-081 26 ISM/TEL-12-25/800-082, ISM/TEL-12-25/1250-082, ISM/TEL-12-31.5/1600-082 26 ISM/TEL-12-25/800-083, ISM/TEL-12-25/1250-083, ISM/TEL-12-31.5/1600-083 27

ISM/TEL-24-16/800-057 27

ISM/TEL-24-16/800-058 28

ISM/TEL-12-20/1000-089 29

ISM/TEL-24-16/800-053 29

Small wiring terminations 30

CONTROL MODULES CM/TEL 31 Product range 32 Design 33 Operation 34 Operation modes 34 Capacitor charging 34 Closing 34 Tripping 34 Antipumping duty 34 Blocking duty 34 Supervision 34 Signalling 35 Malfunction detection 35

Origins and operation of Inputs 36

“Close & Supervision” input 36

“Closing Coil Simulator” 37

“Trip & Supervision” input 37

“Trip Coil Supervision” input 38

“Tripping Coil Simulator” 38

“Alternative Trip & Supervision” input 38

“Alternative Tripping Coil Simulator” 39

“Dry Contact Close” input 39

“Dry Contact Trip” input 39

“Current Power Supply” 39

“Current Power Supply Mode” input 39

ISM/TEL auxiliary switch input 39

Destination and operation of outputs 40

“Failure” output 40

“Emergency Trip” outputs 40

“Fleeting” output 40

“Passing” output 40

“Actuator Coil” output 40

“Ready” output 40

Technical specification 41

Overall drawings 45

CM/TEL-X/X-12-01A 45

CM/TEL-X/X-12-02A (03A) 45

Small wiring terminations 46

CM/TEL-X/X-12-01A terminals 46

ROUTING TEST PROCEDURE 49

APPLICATION GUIDE 50

(5)

80

Selection 50

Installation 50

Mounting of the ISM/TEL 51

Mounting of the CM/TEL 54

Interlocking 55

Connection of the position indicator 56

Connection of manual trip facility 56

Wiring 57

Adjustment of the control inputs 60

Commissioning tests 61

Operation test 61

High voltage test 62

Insulation resistance test 62

Main contact resistance test 62

Maintenance 63

Operation test 63

High voltage test 63

Insulation resistance test 63

Contact resistance test 63

PACKAGING 64

Packaging of switching modules 64

Packaging of control modules 66

STORAGE 68 TRANSPORTATION 68 DISPOSAL 68 WARRANTIES 68 DELIVERY SET 68 AMENDMENT SHEET 69 ATTACHMENTS 70

Insulation hoods mounting 70

SM rod extension unit. Assembly 71

Accessories 72

NOTES

73

Mounting of surge arrester SAI/TEL type

74 CM/TEL installation

(6)

Instruction manual Presentation 5 PRESENTATION           

Draw-out unit equipped with ISM/TEL 12–20/1600 for KYN 18A–10 switchgear, China Draw-out unit equipped with

ISM/TEL 12–20/630 for retrofit of LMT switchgear, UK

Draw-out unit equipped with ISM/TEL 12–20/1600 for K- series switchgear, Russia

These modules, based on the latest switching and electronic control technology, can be used as core components for medium voltage switchgear. There are two basic module types:

switching modules (ISM/TEL) used to close and open primary circuits;

control modules (CM/TEL) used to provide control (close and trip operations) of ISM/TEL and to replicate the auxiliary interface of conventional circuit breakers.

Switching modules are three pole units. Each pole incorporates a vacuum interrupter and single-coil magnetic actuator encapsulated in solid insulation.

Control modules are µP electronics units, containing built-in close and trip capacitors. These capacitors are discharged to the actuator coil in different directions to provide the relevant operations.

When applied to any switchgear, a pair of modules (one switching module and one control module) must be used. The ability to choose switching and control modules separately allows any type of switchgear to be easily equipped regardless of its primary and auxiliary circuits.

Since their first introduction in the early 1990's, the modules have gained an excellent reputation among switchgear manufacturing companies. Tavrida Electric has now supplied more than 100 000 pairs of modules used in over 50 different types of switchgear (both retrofitted and brand new). These modules have been the product of many years of R&D effort by Tavrida Electric scientists and engineers and their use in your switchgear will allow you and your customers to benefit from their unique combination of features:

no maintenance needed during its entire lifetime; long mechanical and interrupting life;

fast autoreclosing capability;

easy adaptation to any primary interface (sta-tionary or withdrawable);

easy adaptation to a wide range of auxiliary voltages;

easy adaptation to any signaling interface; easy SCADA compatibility;

low power consumption;

compact dimensions and light weight.

Some examples of application of the modules for different switchgear are presented below.

(7)

Part numbering of the control modules is as follows: Part numbering of the switching modules is as follows:

PART NUMBERING

MARKING

Marking of switching modules

The indoor switching module is provided with a label as follows:

VACUUM CIRCUIT BREAKER ISM/TEL-12-20/1000-055 Sequence O-0.3s-CO-15s-CO IEC 62271-100 WWW.TAVRIDA.EE Year of manufacture 200 Ur (kV) Ud (kV) Up (kV) Mass (kg) 12 42 75 75 I (rA) Is (ckA) fr (Hz) t (s) 1000 20 50/60 4 k

(8)

Instruction manual Marking 7 Marking of control modules

SEALING

Sealing of switching modules

Each switching module is sealed with a red sealing label:

Any attempt to peel the film will result in the display of a hidden "OPENED" indication

Manufacturer warranty does not cover switching modules with damaged or removed sealing labels.

Control modules and switching modules that are not included in the commercial product list and are not for use in service are produced in accordance with product ordering procedures. These modules are tagged with additional film labels.

(9)

Sealing of control modules

After the routine test procedure, each control unit is sealed with two special films (31x14.5 mm).

These films are attached to a joint of the module's case and cover.

In case of removing or damaging these seal films during the warranty period, the warranty is canceled.

(10)

Instruction manual Switching modules ISM/TEL 9

SWITCHING MODULES ISM/TEL

Module type Rated voltage, kV Rated normal_{current, A} Rated breaking_{current, kA} _distance,mmPole to pole

ISM/TEL-12-20/1000-051(F)* 12 1000 20 200 ISM/TEL-12-20/1000-052(F)* 12 1000 20 250 ISM/TEL-12-20/1000-055(F)* 12 1000 20 210 ISM/TEL-12-20/1000-067(F) 12 1000 20 150 ISM/TEL-12-25/800-066 12 800 25 150 ISM/TEL-12-25/800-068 12 800 25 275 ISM/TEL-12-25/800-081 12 800 25 210 ISM/TEL-12-25/800-082 12 800 25 200 ISM/TEL-12-25/800-083 12 800 25 250 ISM/TEL-12-25/1250-066 12 1250 25 150 ISM/TEL-12-25/1250-068 12 1250 25 275 ISM/TEL-12-25/1250-081 12 1250 25 210 ISM/TEL-12-25/1250-082 12 1250 25 200 ISM/TEL-12-25/1250-083 12 1250 25 250 ISM/TEL-12-31.5/1600-066 12 1600 31,5 150 ISM/TEL-12-31.5/1600-068 12 1600 31,5 275 ISM/TEL-12-31.5/1600-081 12 1600 31,5 210 ISM/TEL-12-31.5/1600-082 12 1600 31,5 200 ISM/TEL-12-31.5/1600-083 12 1600 31,5 250

* Index F (optional) means that ISM is intended for frequent CO operation.

ISM/TEL-12-20/1000-089 12 1000 20

-ISM/TEL-20-16/800-053 24 800 16

-ISM/TEL-24-16/800-057 24 800 16 210

ISM/TEL-24-16/800-058 24 800 16 275

ISM/TEL modules differ in rated voltage, rated current, rated breaking current and pole-to-pole distances. The complete range of products complies with the following Table.

(11)

Design

Overall design

  

Overall design of ISM/TEL

vacuum interrupter frame synchronizing shaft micro switches interlocking pin magnetic actuator shaft interlocking interface

In contrast to the majority of conventional circuit breakers, this patented design incorporates three independent magnetic actuators: one per pole. This minimizes the number of moving parts, all of which are symmetrical about the central axis. The vacuum interrupter and the magnetic actua-tor are located at opposite ends of a hollow sup-port insulator. The actuator armature is rigidly coupled to the vacuum interrupter moving con-tact by a linear drive insulator within the support insulator. This provides direct linear movement in both directions and avoids the use of rotating shafts, bearings and bell cranks. The result is a maintenance free ISM/TEL with a long trouble-free mechanical life.

The actuators are situated inside the frame as shown in the figure below. A synchronising shaft connects the three poles and performs three functions:

opening synchronization of the poles; operation of auxiliary switches;

link drive for mechanical interlocks on switchgear. The design shown in the figure below is used for rated current up to 1000 A. For rated currents exceeding 1000 A, a different design (chimney type) is used. However, it is essentially similar in structure.

(12)

Magnetic actuator



The actuator is held in its two end positions without the use of mechanical latches:

in the OPEN position the armature is held by the opening spring;

in the CLOSED position the armature is held by the magnetic flux produced by a ring magnet.

This actuator has only one coil. To close and trip the actuator it is necessary to inject current into the coil in different directions.

(13)

Vacuum interrupters

  



Finely dispersed vacuum arc resulting from stabilizing effect of axial magnetic field.

The family of TELvacuum interrupters

As soon as the vacuum interrupter contacts open, the interrupting current initiates a so-called "vacuum arc" that burns essentially as plasma originating from evaporated contact material. The current continues to flow through this plasma until a zero current is reached. At this moment the arc is extinguished and a transient recovery voltage appears across the open gap. If the contact surface is locally overheated, it produces a lot of vapour, resulting in the deterioration of the vacuum followed by an electrical breakdown. To avoid this, effective control of the vacuum arc is necessary.

The most effective way to achieve this goal is to apply an axial magnetic field produced by the interrupting current itself. This method is imple-mented in vacuum interrupters developed and manufactured by Tavrida Electric for ISM/TEL modules.

Several major benefits result from this design: high interrupting capacity;

very compact dimensions;

low chopping current (4-5 amps) This limits inductive switching overvoltages to safe values; axial magnetic field minimizes contact erosion and ensures a very long and reliable life.

(14)

Instruction manual Switching modules ISM/TEL 13 Operation Closing            Opening

 To open the interrupter a current of opposite polarity, derived from the opening capacitor in the control module, is passed through the coil for 15-20 milliseconds. (Line 4-5)

 This current partially demagnetises the ring magnet and reduces the magnetic holding force

 Opposing forces from the charged opening spring and the contact pressure spring cause the arma-ture to release and accelerate rapidly. After 2 mm of free travel it engages with the drive insulator and thus the moving contact.

 The peak force produced by the armature at this point exceeds 2000 N which ensures easy break-ing of any micro-welds at the contact surfaces which can appear due to short circuit current action.

 The moving contact accelerates rapidly ensuring a high interrupting capacity. (Line 5)

 At full travel (Line 6) the armature, drive insula-tor, moving contact assembly is again held open by the opening spring force.

 The synchronising shaft is also driven through 44° of rotation during the opening operation and provides position indication, auxiliary switch operation and mechanical interlocking actions.

Typical oscillograms of ISM/TEL module operation

 In the OPEN position the vacuum interrupter con-tacts are held open by the force of the opening spring in the actuator acting through the drive insulator.

To close the vacuum interrupter contacts a current pulse, derived from the closing capacitor in the control module, is injected into the actuator coil. The current in the coil produces a magnetic flux in the gap between the upper yoke and the actuator armature.

Rising coil current increases the magnetic flux and the electromagnetic attraction between yoke and armature increases to overcome the restraining force of the opening spring. (Line 1)

The armature, drive insulator and moving contact start to move.

As the armature moves towards the upper yoke the magnetic air gap decreases and consequently the magnetic attraction force increases. This increasing force accelerates the armature, drive insulator and moving contact to a closing speed of 1 m/s. This optimum speed ensures a complete absence of contact bounce and reduces the probability of pre-strikes of the vacuum gap before the contacts close. (Line 2)

The accelerating armature also generates a back emf in the coil and reduces the coil current

(Line 1-2)

At contact close (Line 2), the moving contact stops but the armature travel continues for 2mm under rapid deceleration caused by compressing the contact pressure spring.

At the limit of its travel the armature latches mag-netically to the upper yoke. (Line 2a) The moving armature induced back emf collapses and the coil current again increases (Line 2a-3) saturating the ring magnet.

This saturation increases the power of the ring permanent magnet to a level that generates flux to hold the armature in the CLOSED position after the coil current has been cut off by an auxiliary switch. ( Line 3) Testing has proved that this flux is sufficient to hold the actuator CLOSED even under vibration and impact conditions.

The travel of the armature also compresses the opening spring in preparation for the next opening operation.

The synchronising shaft is also driven through 44° of rotation during the closing operation and pro-vides position indication, auxiliary switch operation and mechanical interlocking actions.

(15)

Manual closing

Closing can only be carried out through the con-trol module.

If the normal substation supply to the control mod-ule is deenergized it may be operated using a portable low voltage source through special emer-gency power supply inputs. TEE has developed a generator machine (TEE-HSSG-01) which provides a sufficient level of voltage for charging close capacitors of CM/TEL. The generator is enclosed in metal case, which is convenient for transportation and supply connection.

Manual opening

The module may be manually opened. By rotating the synchronizing shaft, a force exceeding the magnetic attraction forces of the ring magnet is applied to the armature, which then starts to move. As the air-gap increases the opening spring and contact pressure spring overcome any magnetic holding force and the interrupter opens.

Note: It is not possible to close ISM/TEL by forcing the synchronizing shaft to rotate. Any attempt to do so will result in damage to the mechanism and possible injury to personnel.

Alternatively, a stationary type power supply unit (TEE-PSU-01) can be used to provide CM/TEL close capacitors charging. The set consists of ORACLE charger and HAWKER GENESIS miniature battery.

(16)

Instruction manual Switching modules ISM/TEL 15 ISM/TEL-12-20/1000-051(F) ISM/TEL-12-20/1000-052(F) ISM/TEL-12-20/1000-055(F) ISM/TEL-12-20/1000-067(F) Applicable standards: IEC 62271-100 GB 1984-89 GOST 687-78

* For ISM/TEL-12-20/1000-051F, ISM/TEL-12-20/1000-052F, ISM/TEL-12-20/1000-055F, ISM/TEL-12-20/1000-067F only ** Excluding acceptance time of the relevant control input (Refer to CM/TEL technical specification for details)

67

Rated voltage, kV Rated normal current, A

Rated capacitive switching current, A Rated power frequency test voltage, kV Rated impulse test voltage, kV peak Rated short-circuit breaking current, kA Rated short-circuit making current, kA peak Short time withstand current, 4s, kA Mechanical life, CO cycles, not less than

Interrupting life operations, not less than - at rated current, Close-Open

- at rated breaking current, Open - at other currents, Open

Closing time**, ms, not more than Opening time**, ms, not more than Breaking time**, ms, not more than Standard operating duty**

Main contacts resistance, µOhm, not more than

Maximum ambient temperature Minimum ambient temperature

Design class with regard to severity of ser-vice conditions in accordance with IEC 60932 Mechanical vibration withstand capability in accordance with IEC 721-3-4

Maximum altitude above sea level, m Weights, kg ISM/TEL-12-20/1000-051(F) ISM/TEL-12-20/1000-052(F) ISM/TEL-12-20/1000-055(F) ISM/TEL-12-20/1000-067 Maximum humidity Rated frequency, Hz 12 1000 800 42 75 20 51 20 50000 (150000*) 50000 (150000*) 100

Refer to Fig. below 60

10 20

O-0,3 s-CO15 s-CO 40 + 55°C - 40°C 1 Class 4M4 1000 33 35 35 33 98 % non condensing 50/60

Technical specification

(17)

Applicable standards: IEC 62271-100 GB 1984-89 GOST 687-78 ISM/TEL-12-25/800-066 ISM/TEL-12-25/800-068 ISM/TEL-12-25/800-081 ISM/TEL-12-25/800-082 ISM/TEL-12-25/800-083

* Excluding acceptance time of the relevant control input (Refer to CM/TEL technical specification for details)

Rated capacitive switching current, A Rated power frequency test voltage, kV Rated impulse test voltage, kV peak Rated short-circuit breaking current, kA Rated short-circuit making current, kA peak Short time withstand current, 4s, kA Mechanical life, CO cycles, not less than

Interrupting life operations, not less than - at rated current, Close-Open

- at rated breaking current, Open - at other currents

Closing time**, ms, not more than Opening time**, ms, not more than Breaking time**, ms, not more than Standard operating duty**

Main contacts resistance, µOhm, not more than 30 Maximum ambient temperature

Minimum ambient temperature

Maximum altitude above sea level, m Rated frequency, Hz Weights, kg ISM/TEL-12-25/800-081 ISM/TEL-12-25/800-068 ISM/TEL-12-25/800-082 ISM/TEL-12-25/800-083 ISM/TEL-12-25/800-066 Maximum humidity 12 800 800 42 75 25 63 25 30000 30000

Refer to Fig. below 10

O-0,3 s-CO-15 s-CO + 55°C 1 Class 4M4 1000 100 60 20 - 40°C 50/60 60 65 75 65 68 98 % non condensing

(18)

Instruction manual Switching modules ISM/TEL 17 Applicable standards: IEC 62271-100 GB 1984-89 GOST 687-78 ISM/TEL-12-25/1250-068 ISM/TEL-12-25/1250-081 ISM/TEL-12-25/1250-082 ISM/TEL-12-25/1250-083

* Excluding acceptance time of the relevant control input (Refer to CM/TEL technical specification for details) ISM/TEL-12-25/1250-066

Rated capacitive switching current, A Rated power frequency test voltage, kV Rated impulse test voltage, kV peak Rated short-circuit breaking current, kA Rated short-circuit making current, kA peak Short time withstand current, 4s, kA Mechanical life, CO cycles, not less than - at rated current, Close-Open

Closing time**, ms, not more than Opening time**, ms, not more than Breaking time**, ms, not more than Standard operating duty** Maximum ambient temperature Minimum ambient temperature

Maximum altitude above sea level, m

Interrupting life operations, not less than

Main contacts resistance, µOhm, not more than 30 Rated frequency, Hz Weights, kg ISM/TEL-12-25/1250-081 ISM/TEL-12-25/1250-068 ISM/TEL-12-25/1250-082 ISM/TEL-12-25/1250-083 ISM/TEL-12-25/1250-066 Maximum humidity 12 1250 800 42 75 25 63 25 30000 30000

Refer to Fig. below 10 + 55°C 1 Class 4M4 1000 100 60 20

O-0,3 s-CO-15 s-CO

- 40°C 50/60 60 75 65 68 65 98 % non condensing

(19)

12 1600 800 42 75 31,5 80 31,5 30000 30000 10 + 55°C 1 Class 4M4 1000

Applicable standards: IEC 62271-100 GB 1984-89 GOST 687-78 ISM/TEL-12-31.5 600/1 -068 ISM/TEL-12-31.5 600/1 -081 ISM/TEL-12-31.5 600/1 -082 ISM/TEL-12-31.5/1600-083 ISM/TEL-12-31.5/1600-066

Refer to Fig. below Rated voltage, kV

Rated normal current, A

Rated capacitive switching current, A Rated power frequency test voltage, kV Rated impulse test voltage, kV peak Rated short-circuit breaking current, kA Short time withstand current, 4s, kA Mechanical life, CO cycles, not less than - at rated current, Close-Open

Closing time**, ms, not more than Opening time**, ms, not more than Breaking time**, ms, not more than Standard operating duty** Maximum ambient temperature Minimum ambient temperature

Maximum altitude above sea level, m

Interrupting life operations, not less than

O-0,3 s-CO-15 s-CO Rated short-circuit making current, kA peak

50 60

20 Main contacts resistance, µOhm, not more than 30

- 40°C Rated frequency, Hz 50/60 60 75 65 Weights, kg 66 65 ISM/TEL-12-31.5 600/1 -068 ISM/TEL-12-31.5 600/1 -081 ISM/TEL-12-31.5 600/1 -082 ISM/TEL-12-31.5 600/1 -083 ISM/TEL-12-31.5/1600-066

(20)

19

ISM/TEL-24-16/800-057 ISM/TEL-24-16/800-058

Applicable standards: IEC 62271-100 GB 1984-89 GOST 687-78 Rated voltage, kV

Rated normal current, A

Rated power frequency test voltage, kV Rated impulse test voltage, kV peak Rated short-circuit breaking current, kA Rated short-circuit making current, kA peak 40 Short time withstand current, 4s, kA

Mechanical life, CO cycles, not less than 30000 Interrupting life operations, not less than - at rated current, Close-Open

- at rated breaking current, Close-Open - at other currents

Closing time**, ms, not more than

Opening time**, ms, not more than 10 Breaking time**, ms, not more than

Standard operating duty**

Main contacts resistance, µOhm, not more than Maximum ambient temperature

Minimum ambient temperature

Maximum altitude above sea level, m Rated frequency, Hz Weights, kg ISM/TEL-24-16/800-057 ISM/TEL-24-16/800-058 Maximum humidity 24 800 50 16 16 100 70 20 40 1 Class 4M4 125 30000

Refer to Fig. below

O-0,3 s-CO-15 s-CO + 55°C - 40°C 1000 50/60 37 35 98 % non condensing

(21)

ISM/TEL-12-20/1000-089 Applicable standards: IEC 62271-100 GB 1984-89 GOST 687-78 - 40°C 50/60 98 % non condensing Rated frequency, Hz Maximum humidity .

(22)

21

Instruction manual Switching modules ISM/TEL

Applicable standards: IEC 62271-100 GB 1984-89 GOST 687-78 ISM/TEL-24-16/800-053 50/60 Rated frequency, Hz Maximum humidity - 40°C 98 % non condensing O-0,3 s-CO-15 s-CO

(23)

Auxiliary switches

Maximum Electrical AC Ratings Voltage

VAC Resistive loadA Inductive loadA 125 250 10* 10* 5 5

Maximum Electrical DC Ratings Voltage

VDC Resistive loadA Inductive loadA up to 30 50 75 0.75 0.5 0.25 0.75 0.03 0.03 125 250 10* 1 3 1 Minimum Electrical AC/DC Ratings

Voltage

VDC/VAC Resistive loadmA Inductive loadmA

12 to 30 100 100

* At 5 min shortterm duty. Continuous current 5A.

All three-phase switching modules are equipped with thirteen auxiliary switches, six normally open (NO) and seven normally closed (NC).

All single-phase switching modules are equipped with four auxiliary switches, two normally open (NO) and two normally closed (NC).

Auxiliary switches are operated by a cam that is fitted on the synchronizing shaft. One NC auxiliary switch is used for interconnection with the control module. All others are available for external use. Auxiliary switch ratings are shown in the table below.

(24)

Instruction manual Switching modules ISM/TEL 23 Overall drawings

ISM/TEL-12-20/1000-051(F)

(25)

ISM/TEL-12-20/1000-055(F)

(26)

ISM/TEL-12-25/800-066, ISM/TEL-12-25/1250-066, ISM/TEL-12-31.5/1600-066

(27)

ISM/TEL-12-25/800-081, ISM/TEL-12-25/1250-081, ISM/TEL-12-31.5/1600-081, ISM/TEL-17.5-25/1600-081

(28)

ISM/TEL-12-25/800-083, ISM/TEL-12-25/1250-083, ISM/TEL-12-31.5/1600-083

ISM/TEL-24-16/800-057 560 M10 45 1 262±0,5 265 73 10 68 ,5 M10 13 4 M10 50 9 45 103 30 112 31 4 149±0,5 100 35 210±1 30 160 132±0,2 210±1 86 50 ±0 ,2 86 21 0± 0, 5 17 0 57 100

(29)

(30)

ISM/TEL-12-20/1000-089

(31)

Small wiring terminations

X1 X2

Terminal № Designation Terminal № Designation

All switching modules have identical terminations as shown below.

WAGO cage clamps are used for the termination. Wires are connected into the clamps using a special screwdriver, supplied with each module. The WAGO clamps can accept either solid or stranded wire within the range 0.5 - 1.5 sq mm. Insulation stripping length shall be 6-10 mm.

1 NO auxiliary switch 1(1) 15 NC auxiliary switch(1) (AS1)

2 NO auxiliary switch 1(2) 16 NC auxiliary switch(2) (AS2)

3 NO auxiliary switch 2(1) 17 NC auxiliary switch 7(1)

13 actuator coil(1)(SC1) 27 NC auxiliary switch 12(1)

14 actuator coil(2)(SC2) 28 NC auxiliary switch 12(2)

(32)

Note: NC auxiliary switch with terminals 15,16 is used for interconnection with control module.

Terminal arrangement for the single-phase ISM

XT1

Terminal No. Connection Terminal No. Connection

1 2 3 4 5 6 8 7 9 10 11 12 NC Auxiliary switch 1 (AS2)

NC Auxiliary switch 1 (AS1)

NC Auxiliary switch 2 NC Auxiliary switch 2 NC Auxiliary switch 3 NC Auxiliary switch 3 NO Auxiliary switch 4 NO Auxiliary switch 4 NO Auxiliary switch 5 NO Auxiliary switch 5 Actuator coil (SC1) Actuator coil (SC2)

Note: NC auxiliary switch with terminals 1, 2 is used for interconnection with control module.

(33)

I/O interface for C M/TEL-X/X-12-01A modules

I/O interface for CM/TEL-X/X-12-02A modules

I/O interface for CM/TEL-X/X-12-03A modules CONTROL MODULES CM/TEL

Product range

Potential zones corresponding to electrically isolated terminals are separated with lines. Outgoing arrows indicate outputs, incoming arrows indicate inputs.

Control modules differ in their I/O interface and range of rated control voltage. The complete range of products is shown in the following Table:

Module type Rated voltage range, V I/O interface

CM/TEL-24/60-12-01 A 24/30/48/60 DC See next page

CM/TEL-100/220-12-01 A 110/220 DC, 100/127/220 AC See next page

CM/TEL-100/220-12-02 A 110/220 DC, 100/127/220 AC See next page

(34)

Instruction manual Control modules CM/TEL 33 Design



Overall design of CM/TEL-X/X-12-02A(03A) Overall design of CM/TEL-X/X-12-01A

The control modules are totally enclosed in a polymeric housing designed for simple flat surface 4 hole mounting. On the front panel there are:

LED indicators that report on the self-monitoring system of the control module;

Selector switches are to set rated current for type 12-02A and 12-03A control modules;

WAGO cage clamps for small wiring terminations. For CM/TEL-X/X-12-02A and CM/TEL-X/X-12-03A additional WAGO cage clamps are provided for the termination of control cables.



(35)

Operation

Operation modes

Capacitor charging

Both the "Close" and "Trip" capacitors are charged when an auxiliary voltage is applied to the "Power Supply" input.

Alternatively the "Close" capacitor can be charged from the "Emergency Power Supply" input. This feature allows ISM/TEL to be closed using a low voltage alternative power supply (for example, handset battery) when the main "Power Supply" input is dead.

Alternative charging of the "Trip" capacitor can be achieved by using the "Current Power Supply" inputs connected to CTs. This alternative method also requires the "Current Power Supply Mode" input terminals to be short-circuited. This feature allows the control module to maintain tripping ability in the event of a long control power supply outage.

For more detailed information refer to the descrip-tion of relevant inputs.

Closing

ISM/TEL can be closed through the "Close and Supervision" input or the "Dry Contact Close" input. For more detailed information refer to the description of the relevant inputs. Note: after mechanical tripping, closing will not proceed unless Trip instruction is activated via any applicable input.

Tripping

ISM/TEL can be tripped through the "Trip & Supervision" input, the 'Alternative Trip & Supervision Input", the "Dry Contact Trip" input and any of the "Current Power Supply" inputs if "Current Power Supply Mode" input terminals are open-circuited.

For more detailed information refer to the descrip-tion of the relevant input.

Anti-pumping duty

For any close and trip inputs the following rule is applicable.

During a close operation, if a trip instruction is received before the close instruction becomes passive then the close instruction will be blocked. For the next close operation the close instruction must be re-applied after the trip instruction has become passive.

Blocking duty

For any close and trip inputs the following rule is applicable.

If a close instruction is received while a trip instruction remains active then the close instruction is blocked.

For the next close operation the close instruction must be re-applied after the trip instruction has become passive.

Supervision

The control module simulates the behaviour of a conventional circuit breaker with regard to super-vision of the health of the "Close" and "Trip" cir-cuits. To achieve this, the supervision circuits of the switchgear can be connected to the "Close & Supervision" and the "Trip & Supervision" inputs. For more detailed information refer to the descrip-tion of the relevant inputs.

(36)

Instruction manual Control modules CM/TEL 35

Event Event(output) LED indicators Dry contact indication

CM/TEL-X/X-X-01A CM/TEL-X/X-X-02A CM/TEL-X/X-X-03A CM/TEL-X/X-X-01A CM/TEL-X/X-X-02A CM/TEL-X/X-X-03A

Malfunction of the Module Failure     

Power supply ON Power    -

-The Module is ready to accept any

of the control signals Ready      

ISM has performed a close operation Fleeting - - - - 

-ISM has performed a trip operation Passing - - - - 

-ISM has been tripped through "Alternative Trip & Supervision", "Dry Contact Trip" or "Current Power Supply" inputs, Manual Trip

Emergency

Trip - - - 

Auxiliary power is applied to

"Emergency Power Supply" input - -  - -

-Type of malfunction Condition of the "Failure" LED indicator

prescribed limit One blink followed by 1,5 s interval

Nonconformity of auxiliary contact of ISM Two successive blinks followed by 1,5 s interval Actuator coil is open-circuited Three successive blinks followed by 1,5 s interval Actuator coil is short-circuited Four successive blinks followed by 1,5 s interval

Manual trip Five successive blinks followed by 1,5 s interval

Nonconformity of Module Six and more successive blinks followed by 1,5 s interval



-Malfunction detection

The self-monitoring system within the module detects the malfunctions shown below and signals these on the "Failure" LED indicator by differing patterns of LED blinks.

code name

Emergency Power

Signalling

The control module provides LED indications and dry contact signaling of a number of events in accordance with the following Table. For more detailed information refer to the description of the relevant outputs.

(37)

 



Origins and operation of inputs

"Close & Supervision " input

The "Close & Supervision" input simulates the behaviour of the closing coil of a conventional circuit breaker (CB) with an NC auxiliary switch in series.

Typical wiring of the dose and supervisory circuits to conventional circuit breaker

SPR -supervisory relay, SR - signal relay, CS- closing switch contact R - current limiting resistor, AS - auxiliary switch, CC - closing coil.

The input can be in low or high impedance mode depending on the conditions described below. When the input is in low impedance mode its resistance is determined by an external resistor connected to the terminals of the "Closing Coil Simulator".

Typical wiring of the close and supervisory circuits to CM/TEL SPR- supervisory relay, R-current limiting resistor, AS - aux-iliary switch, CC -closing coil SR- signal relay, CS- closing switch contact, ER -external resistor for simulation of closing coil resistance, 1, 2 - "Close & Supervision" input terminals, 3,4 - "Closing Coil Simulator" input terminals.

Low impedance mode of the input occurs if the following conditions are met:

ISM/TEL is open (ISM/TEL auxiliary switch closed); Closing capacitor is charged;

No malfunction is detected;

In this state the close circuit supervision current, limited by resistance of the supervision relay coil flows through the input. The relay is activated and signals that ISM/TEL is ready to close. If the control switch CS is closed, the total control voltage is applied to the input. The current is no longer limited by SPR coil resistance, so it increases and exceeds the minimum level accepted as a "Close" instruction. If this current is sustained for a period longer than the "Close" instruction acceptance time, then the "Close" instruction is accepted, the closing capacitor is discharged into the actuator coil and the ISM/TEL module closes. The input remains in the low impedance mode for 60 ms to pro-vide enough time for the operation of the signal relay SR. After this time has expired, the input impedance becomes high and remains in this mode until the conditions specified above are met again. If the supervision relay coil short circuits, this must not lead to the uninstructed operation of the circuit breaker. To avoid this situation, resistor R is generally included in the circuit. This resistor limits the current values below the minimum accepted level. However this current is generally higher than the maximum sustained current. If this is the case, the input impedance becomes high after 200 ms; it then stays in the low impedance mode for 200 ms every 50 s to check the status of the supervision circuit. The supervision circuit is considered healthy when the input current drops below the maximum sustained level. In this situation the input impedance mode becomes low again.

(38)



SPR1 supervisory relay, R1 current limiting resistor, AS auxiliary switch, TC tripping coil, SR1 signal relay, TS -tripping switch contact.

SPR1 - supervisory relay, R1, R2 - current limiting resistors, SR1 - signal relay, TS - tripping switch contact, SPR2 - trip coil supervision relay, ER1 - external resistor for simulation of the TC resistance, AS - auxiliary switch, TC - tripping coil, 5,6 - terminals of the "Trip & Supervision" input, 7 - terminal for connection of the "Trip Coil Supervision" input 8,9 -"Tripping Coil Simulator" input terminals.

"Closing Coil Simulator”

This input is used for the connection of external resistor ER, which replicates the resistance of the closing coil of a conventional circuit breaker. This resistor determines the resistance of the "Close & Supervision" input in the open state.

"Trip & Supervision" input

The "Trip & Supervision" input simulates the behaviour of the trip circuit of a conventional circuit breaker with NO auxiliary switch in series.

Typical wiring of the "Trip & Supervision" and "Trip Coil Supervision" circuits to conventional circuit breaker

The input can be in low or high impedance mode depending on the conditions described below. When input is in low impedance mode its resist-ance is determined by external resistor connected to the terminals of the "Tripping Coil Simulator".

Typical wiring of the "Trip & Supervision" and "Trip Coil Supervision" circuits to CM/TEL

Low impedance mode of the input occurs if the following conditions are met:

ISM/TEL is closed (ISM/TEL auxiliary switch is open);

Tripping capacitor is charged; No malfunction is detected;

In this state the trip circuit supervision current, limited by resistance of the supervision relay coil, flows through the input. The relay is activated and signals that ISM/TEL is ready to trip. If control switch TS is closed then the total control voltage is applied to the input. The current is no longer limited by relay coil resistance, so it increases and exceeds the minimum level accepted as a "Trip" instruction. If this current is sustained for a period longer than the "Trip" instruction acceptance time, then the "Trip" instruction is accepted, the tripping capacitor is discharged into the actuator coil and the ISM/TEL module opens. The input remains in the low impedance mode for 60 ms to provide enough time for operation of the signal relay SRI. After this time has expired, the input impedance becomes high and remains in this mode until the conditions specified above are met again.

(39)

If the supervision relay coil short circuits this must not lead to the uninstructed operation of the circuit breaker. To avoid this situation, resistor R1 is generally put in series with the relay coil. This resistor limits the current values below the minimum accepted level. However this current is generally higher than maximum sustained cur-rent. If this is the case, the input impedance becomes high after 200 ms; it then stays in the low impedance mode for 200 ms every 50 s to check the status of the supervision circuit. The supervision circuit is considered healthy when the sustained current drops below the maximum sustained level. In this situation the input impedance mode becomes low again.

Trip Coil Supervision" input

The "Trip Coil Supervision" input is used to simu-late the tripping coil of a conventional circuit breaker (see previous page). It allows the "Trip Coil Supervision" relay to be connected, which can supervise the health of the trip coil irrespective of the position of ISM/TEL. The input can be in the low or high impedance mode depending on the conditions described below. When the input is in the low impedance mode, it's resistance is determined by the external resistor ER1 con-nected to the terminals of the "Tripping Coil Simulator".

The input is in the low impedance mode if no malfunction is detected.

In this state the trip coil supervision current, lim-ited by the resistance of the supervision relay coil, flows through the input. Relay SPR2 is activated and signals that the trip coil is healthy.

"Tripping Coil Simulator"

This input is used for the connection of external resistor ER1, which replicates the resistance of the Tripping Coil of a conventional circuit breaker. This resistor determines the resistance of the "Trip & Supervision" and "Trip Coil Supervision" inputs in the open state.

'Alternative Trip & Supervision" input

The 'Alternative Trip & Supervision" input simu-lates the behaviour of the alternative shunt release of a conventional circuit breaker with NO auxiliary switch in series.

Typical wiring of the 'Alternative Trip & Supervision" circuit to conventional circuit breaker

SPR3 - supervisory relay, R3 - current limiting resistor, 5R3-signal relay, ATS - alternative tripping switch contact, AS-auxiliary switch, SRC - shunt release coil

The input can be in the low or high impedance mode depending on the conditions specified below. When the input is in the low impedance mode, its resistance is determined by an external resistor connected to the terminals of the 'Alternative Tripping Coil Simulator".

(40)

Instruction manual Control modules CM/TEL 39          

Typical wiring of the 'Alternative Trip & Supervision" circuit to CM/TEL

SPR3S-supervisory relay, R3- current limiting resistor, SR3-signal relay, ATS - alternative tripping switch contact ER2external resistor for simulation of the SRC resistance, 10,11 -terminals of the "Trip & Supervision" input 12,13- "Tripping Coil Simulator" input terminals.

Functionality of the input is identical to that of the "Trip & Supervision" input.

“Alternative Tripping Coil Simulator"

This input is used for the connection of external resistor ER2, which replicates the resistance of the alternative shunt release of a conventional circuit breaker. This resistor determines the resistance of the 'Alternative trip and Supervision" input in the low impedance mode.

"Dry Contact Close" input

The "Dry Contact "Close" input can be used to close ISM/TEL. The close instruction is accepted through this input if the following conditions are met:

ISM/TEL is open (ISM/TEL auxiliary switch is closed);

Closing capacitor is charged; No malfunction is detected;

"Dry Contact "Close" input is short circuited longer than "Close" instruction acceptance time; "Dry Contact "Trip" input is open circuited.

"Dry Contact Trip" input

The "Dry Contact "Trip" input can be used to trip ISM/TEL. The "Trip" instruction is accepted through this input if the following conditions are met:

Tripping capacitor is charged; No malfunction is detected;

"Dry Contact "Trip" input is short circuited longer than "Trip" instruction acceptance time.

"Current Power Supply"

The "Current Power Supply" inputs can be con-nected to CTs and may be selected for either but not both of the following functions:

to charge the trip capacitor,;

to simulate the operation of the series trip coils of a conventional direct tripping circuit breaker. To select Trip Capacitor Charging the "Current Power Supply Mode" terminals must be short circuit together by a local jumper.

The trip capacitor is charged by line current CT power but trip operation is only available from "Trip" instructions through other appropriate inputs.

To select Series Trip Coil simulation the "Current Power Supply Mode" terminals must be open cir-cuited.

The trip capacitor is again charged by line current CT power but trip operation results from a trip instruction from the direct tripping relay.

"Current Power Supply Mode" input

This input is used for selection of the operating mode of the "Current Power Supply" inputs as described above.

ISM/TEL auxiliary switch input

This input is used for connection of the NC auxil-iary switch of ISM/TEL.

(41)



Destination and operation of outputs

"Failure" output

The "Failure" output is used to signal the detec-tion of any malfuncdetec-tion as specified in the secdetec-tion "Malfunction". The output is represented by CO relay contacts. Its NC contacts open when no malfunction is detected.

"Emergency Trip" outputs

The "Emergency Trip" output simulates the behaviour of the relevant mechanical switch of a conventional circuit breaker.

The output is represented by two bistable relays (with NO and CO contacts). These relays change their position at closing. At tripping, they switch to the original position if the trip instruction has been accepted through the "Trip and Supervision" input.

If the trip instruction has been accepted through another input, the relays do not switch to the original position. The relays can be reset by the application of the control voltage to the "Emergency Trip Reset Input" when the switching module under control is in the Open position.

"Fleeting" output

The "Fleeting" output is used to simulate the action of the relevant mechanical switch of a conventional circuit breaker during a “Trip” opera-tion. This output is represented by a relay, which closes NO contacts in 25±5 ms after the tripping of the ISM/TEL (closing of the ISM/TEL auxiliary switch) and opens these contacts after an addi-tional 50±5 ms.

"Passing" output

The "Passing" output is used to simulate the action of the relevant mechanical switch of a conventional circuit breaker during a “Close” operation. This output is represented by a relay which closes NO contacts in 25±5 ms after closing of the ISM/TEL (opening of the ISM/TEL auxiliary switch) and opens these contacts after an addi-tional 50±5 ms.

"Actuator Coil" output

This output is used for connection of the coil of the magnetic actuator.

"Ready" output

The "Ready" output is used to indicate that the control module is ready to accept "Trip" and "Close" instructions through any of the relevant inputs. This state appears if the following condi-tions are met:

"Trip" and "Close" capacitors are fully charged; No malfunction is detected.

This output is represented by an NO relay that holds the contact closed if the conditions speci-fied above are met.

(42)

* When Installation regulations are fulfilled (See section Installation)

Technical specification

Standard operating duty

Maximum number of CO operations per hour Maximum operating temperature

Minimum operating temperature Maximum humidity

Maximum altitude above sea level Degree of protection

Mechanical vibration withstand capability

Electrical strength

Power frequency, 1 min in accordance with IEC 62271 100

Insulation resistance at 1000V DC, not less than

Electromagnetic Compatibility (EMC)*

Weights, not more than

- CM/TEL-X/X-12-01A - CM/TEL-X/X-12-02A - CM/TEL-X/X-12-03A

Atmospheric environment capability in accordance with IEC 60068…2

in accordance with IEC 1000 4 11 voltage variations 15%, duration 2..3 s, period 5..10 s Electrical fast transient/burst immunity in accordance

with IEC 1000 4 4 Level 4, 4 kV Oscillatory waves immunity in accordance with IEC 1000 4 12

Surge immunity in accordance with IEC 1000 4 5 4kV common, 2 kV diff. 1.2/50 s Power frequency magnetic field immunity in accordance

with IEC 1000 4 8 Level 5(A), 100 A/m 60 s, 1000 A/m 2 s Pulse magnetic field immunity in accordance with IEC 1000 4 9 Level 5(A), 1000 A/m

Damped oscillatory magnetic field immunity in accordance

with IEC 1000 4 10 Level 5(B), 0,1 MHz and 1 MHz 100 A/m Lightning impulse 1.2/50 µs in accordance

with IEC 60255 5 5 kV General O-0,3s-CO-15s-CO 100 0 + 55 C 0 - 40 C 98 % non condensing 2000 m IP40 Class4M4 96 h,+ 55C 96 h, - 40C 2000 V 5 MOhm

Voltage dips, short interruptions and voltage variations immunity

Class III, 1MHz, 2.5kV common, 1kV diff.

1.8 kg 2.8 kg 3.2 kg

(43)

for closing for closing

Power consumption from power supply, not more than During preparation for “Close” (close capacitor charging)

Standing load

Preparation time for “Close” operation, not more than After initial power application

After previous “Close” operation

Preparation time for “trip” operation (”Trip” capacitor charging) After initial power application, not more than

Time of ability for “Trip” operation after power outage, not less than

Emergency power supply Voltage range

Power consumption, not more than During preparation for “Close” (close capacitor charging)

Standing load

Voltage range

“Trip & Supervision”, “Alternative Trip & Supervision” inputs

Rated currant I (to be adjusted by external resistor and selection

switches) N

Minimum accepted level of the control instruction (”Trip”) I I Maximum sustained supervision current

Control instruction (”Trip”) acceptance time

Equal to the external resistor Input resistance in low impedance mode

Input resistance in high impedance mode, not less than

(44)

Instruction manual Control modules CM/TEL 43 Dry Contact ”Trip” and Dry Contact ”Close” inputs

Control instruction (“Trip” or “Close”) recognition time 1)

Voltage on the “Dry contact” inputs, generated by CM, not more than Current at the moment of the input closing, not less than

Time constant of current falloff, not less than

Current steady-state value, not less than 3) _5mA

Operating current range

Power consumption for each phase during preparation for "Trip* ("Trip" capacitor charging), not more than

- at 2A 5 VA

- at 5A 12 VA

- at 10A 25 VA

- at 30A 120 VA

- at 300A 8 kVA

Preparation time for ”Trip” operation (charging of the “Trip” capacitor), not more than

- at 2A 1000 ms

- at 5A 400 ms

- at 10A 150 ms

- at 30A 110 ms

- at 300A 100 ms

Current carrying capacity, not less than

- at 2A ∞ - at 10A 100 s - at 150A 1 s - at 300A 0.1 s - at 30A 10 s 15 2ms 30V 100mA 10ms

”Current Power Supply”, inputs

2 - 300 A

±

2)

1 Applicable to modules CM/TEL-X/X-02 (03) "Close" instruction recognition time is (15 ± 2) ms 2 Parameters of this section are indicated in case currents flow through both inputs

(45)

“Trip Coil Supervision” input Input resistance at low-impedance mode, not more than

Input resistance at high-impedance mode, not less than

“Emergency Trip Reset” input Voltage range

Input resistance

20,4...275 V AC or DC

Maximum direct interrupt current at 250 V and t=1 ms, not more

than 0.12 A

Switching parameters of signaling relay contacts “Failure”, “Ready”, “Fleeting”, “Passing”, “Emergency Trip”

Minimum switching current at 12 V, not less than

Maximum alternating interrupt current at 250 V and cosφ=0,3, not

more than 2 A

Voltage range

Minimum acceptable level of the control instruction (“Close”) Maximum sustained supervisory current

Control instruction (“Close”) acceptance time Input resistance in open state

Input resistance in closed state, not less than

Maximum accepted level of the control instruction (“Close“) Rated currents In (to be adjusted by external resistor and selection

switches) 0,5/1/1,5/2/2,5/3/4/5 A

“Close & Supervision” input

20.4...275 V AC or DC

0,8*In

0,3*In, but not more than 0.2 A 25±5ms

Equal to the external resistor ER 500kOhm

11±3A

Equal to the external resistor 500kOhm

36 15%kOhm±

10mA The EMC Directive 89/336/EEC

(46)

Instruction manual Control modules CM/TEL 45 Overall drawings CM/TEL-X/X-12-01A CM/TEL-X/X-12-02A (03A) CONTROL MODULE CONTROL MODULE

(47)

X1 X2

1 Earth 1 "Ready" (1) (com)

2 No connection 2 "Ready" (2) (NO)

3 "Power Supply" ~(+) 3 "Ready" (3) (NC)

4 "Power Supply" ~(-) 4 "Failure" (1) (com)

5 No connection 5 "Failure" (2) (NC)

6 No connection 6 "Failure" (3) (NO)

7 No connection 7 "Auxiliary Switch" (1)

9 "Dry Contact "Close" 9 "Actuator Coil" (1)

10 "Dry Contact "Close"/"Trip" 10 "Actuator Coil" (2)

11 "Dry Contact "Close"/"Trip" 11 No connection

12 "Dry Contact "Trip" 12 Earth

Small wiring terminations

CM/TEL-X/X-12-01A terminals

WAGO cage damps are used for small wiring ter-minations. Wires are connected to the clamps using a special screwdriver, supplied with each module. The WAGO clamps can accept either solid or stranded wire within the range 0.5 - 1.5 sq mm. Insulation stripping length shall be 6-10 mm.

(48)

X1 X2

6 No connection 6 "Failure" (3) (N0)

10 "Dry Contact "Close"/"Trip" 10 "Actuator Coil" (2) 11 "Dry Contact "Close"/"Trip" 11 No connection

X3 X4

1 "Close & Supervision" (1) 1 "Passing" (1) 2 "Close & Supervision" (2) 2 "Passing" (2)

3 "Closing Coil Simulator" (1) 3 No connection

5 No connection 5 No connection

6 "Trip & Supervision" (1) 6 No connection

7 "Trip & Supervision" (2) 7 No connection

8 "Tripping Coil Simulator" (1) 8 No connection

9 "Tripping Coil Simulator" (2) 9 No connection

10 "Trip Coil Supervision" 10 No connection

11 No connection 11 No connection 12 "Fleeting" (1) 12 No connection 13 "Fleeting" (2) 13 No connection 14 No connection 14 No connection 15 No connection 15 No connection 16 No connection 16 No connection

(49)

X1 X2

6 "Emergency Power Supply" (+) 6 "Failure" (3) (NO) 7 "Emergency Power Supply" (-) 7 "Auxiliary Switch" (1)

8 No connection 8 "Auxiliary Switch"(2)

10 "Dry Contact "Close"/"Trip" 10 "Actuator Coil" (2) 11 "Dry Contact "Close"/"Trip" 11 No connection

X3 X4

1 "Close & Supervision"·(1) 1 "Emergency Trip (CO)" (1) (NO) 2 "Close & Supervision"·(2) 2 "Emergency Trip (CO)" (2) (com) 3 "Closing Coil Simulator" (1) 3 "Emergency Trip (CO)" (3) (NC)

5 No connection 5 "Current Power Supply Mode" (1)

6 "Trip & Supervision"·(1) 6 "Current Power Supply Mode" (2)

7 "Trip & Supervision"·(2) 7 No connection

8 "Tripping Coil Simulator" (1) 8 "Alternative Trip & Supervision" (1) 9 "Tripping Coil Simulator" (2) 9 "Alternative Trip & Supervision" (2) 10 "Trip Coil Supervision" 10 "Alternative Tripping Coil Simulator"(1)

11 No connection 11 "Alternative Tripping Coil Simulator"(2)

12 "Emergency Trip” (1) 12 No connection

13 "Emergency Trip” (2) 13 "Current Power Supply N1" (1)

14 No connection 14 "Current Power Supply N1" (2)

15 "Emergency Trip Reset" (1) 15 "Current Power Supply N2" (1) 16 "Emergency Trip Reset" (2) 16 "Current Power Supply N2" (2)

(50)

Instruction manual Routine test procedure 49 Routinе test procedure

Test Conformity criteria

Design and visual checks

Measurement of resistance of the main circuit (for

each pole) compliance with the requirements of technical specification

Power-frequency-voltage immunity of the main

cir-cuits (phase to earth and across open contacts) absence of breakdowns during 1min after reaching specified test absence of breakdowns during 1 min after voltage application

Test Conformity criteria

Standard operating duty test compliance with the requirements of technical specification_{(O-0,3s-CO-15s-CO)} Maximum number of CO operations per hour test compliance with the requirements of technical specification Power consumption tests

Operation time accuracy tests

Operation at various input signal's levels tests Input impedance accuracy tests

compliance with the requirements of technical specification compliance with the requirements of technical specification compliance with the requirements of technical specification

Before delivery, each switching module shall be subjected to the following routinе test procedure.

Failure to meet any of the below-mentioned requirements means failure to pass the routine test procedure

accuracy of nameplate data, compliance of the module type to order, absence of mechanical damages, scratches, colour variations affecting module appearance

Mechanical operation tests

(1000 CO operations at rated operating voltage +5% standard operating duties at rated, minimum and maximum operating voltage)

proper operation of main and auxiliary contacts, compliance of the closing and opening times with requirements

of technical specification, absence of contact bounce

Power-frequency-voltage immunity of the auxiliary circuits (between any electrically insulated terminals

compliance with the requirements of technical specification

Both serial switching and control modules are provided with Routine test certificate. voltage level

and earth)

Before delivery, each control module shall be subjected to the following routine test procedure:

(51)



 

Selection

The selection of all modules must be based on: the required basic operating parameters. The parameters in the Technical Specification must not be exceeded under any circumstances.

for ISM/TEL, the pole to pole spacing appropriate for the switchgear.

for CM/TEL, the Control Voltages and the I/O Interface requirements.

The following general selection rules with regard to the choice of interface are applicable.

1. When the Control Module is connected in the switchgear panel with DC auxiliary power in combination with a modern mP relay, providing a s i g n a l i n g i n t e r f a c e o f i t s o w n , CM/TEL-X-X/X-12-O1A can be used.

2. When the Control Module is connected in the switchgear panel with DC auxiliary power with electromechanical relays or mP relay that does not provide required signaling interface, CM/TEL-X-X/X-12-02A can be used.

3.When the Control Module is connected in the switchgear panel with AC auxiliary power and with electromechanical relays, CM/TEL-X-X/X-12-03A can be used.

Installation

Every project using Tavrida Electric modules must have the prior approval of the company Product Manager.

The following section contains generic require-ments to be taken into account when developing such a project.

Any deviations from these requirements must be approved by Tavrida Electric. For further advice on module selection or if there are any other queries, please contact Tavrida Electric.

(52)

Instruction manual Application guide 51

Mounting diagram for ISM/TEL-12-20/1000-XX,

ISM/TEL-24-Mounting diagram for ISM/TEL-12-31.5/1600-XX in draw out

switchgear. Mounting diagram for ISM/TEL-12-31.5/1600-XX in station-ary switchgear.

1 Required fixing points 2 Optional fixing points 3 Additional support structure

* Spring washers are supplied installed on the module terminals. Do not lose these washers when mounting.

16/800-XX in draw out switchgear Mounting diagram for ISM/TEL-12-20/1000-XX, ISM/TEL-24-16/800-XX in stationary switchgear.

1 1

When ISM/TEL-12-20-1000 is used in a stationary switchgear application with Isc value reaching 20kA, an additional supporting bar must be used to interconnect all 3 poles.

When ISM/TEL-12-31,5-1600 is used in a stationary switchgear application with Isc value of more than 25kA, the use of all fixing points is compulsory.

Mounting of the ISM/TEL

In any switchgear application, the ISM/TEL mod-ules shall be installed with the actuator/inter-rupter drive axis vertical. (For ISM types, the actuator may be either below or above the inter-rupter.)

Primary connections to the ISM/TEL modules shall be made using rigid busbars, the design of which shall avoid excessive static force being applied to the modules. Additionally, in draw out switchgear, support insulators shall be used to avoid transferring excessive contact forces to the ISM/TEL module when operating the isolating mechanism.

With stationary switchgear, contact isolation forces do not appear and additional support insu-lators are generally not needed.

H o we v e r , f a u l t c u r re n t c a n pro d u c e electrodynamic forces in busbars.To avoid damage to the modules, the following limits for maximum unsupported busbar length shall be applied to the design:

ISM/TEL-12-20/1000-XX 0.5 m ISM/TEL-24-16-800-XX 0.5 m ISM/TEL-12-31.5-1600-XX 1.0 m

Other dimensions necessary for correct mounting are indicated in the overall drawings.

(53)

For ISM/TEL-12-20/1000-067, ISM/TEL-24-16/800-57 additional insulation barriers between poles shall be used as shown in the figures below.

Mounting threads and specified tightening torques are shown below.

Recommended size and position of insulation
