Dawn Song

1

Privacy and Anonymity

Dawn Song

[email protected]

Slides credit: John Mitechell & Vitaly Shmatikov

2

Anonymous web browsing

• Why?

1. Discuss health issues or financial matters anonymously

2. Bypass Internet censorship in parts of the world

3. Conceal interaction with gambling sites

4. Law enforcement

• Two goals:

– Hide user identity from target web site: (1), (4)

– Hide browsing pattern from employer or ISP: (2), (3)

• Stronger goal: mutual anonymity (e.g. remailers)

3

Current state of the world I

•ISPs tracking customer browsing habits: –Sell information to advertisers

–Embed targeted ads in web pages (1.3%)

»Example: MetroFi (free wireless)

[Web Tripwires: Reis et al. 2008]

•Several technologies used for tracking at ISP: –NebuAd, Phorm, Front Porch

–Bring together advertisers, publishers, and ISPs »At ISP: inject targeted ads into non-SSL pages

•Tracking technologies at enterprise networks: –Vontu (symantec), Tablus (RSA), Vericept

4

Current state of the world II

•EU directive 2006/24/EC: 3 year data retention –For ALL traffic, requires EU ISPs to record:

»Sufficient information to identify endpoints (both legal entities and natural persons)

»Session duration

»… but not session contents

–Make available to law enforcement »… but penalties for transfer or other access to data

•For info on US privacy on the net:

–“privacy on the line” by W. Diffie and S. Landau

5

Part 1: network-layer privacy

Goals:

Hide user’s IP address from target web site Hide browsing destinations from network

6

1

_{attempt: anonymizing proxy}

HTTPS:// anonymizer.com ? URL=target User1 User₂ User3 anonymizer.com Web1 Web₂ Web3 SSL HTTP

7

Anonymizing proxy: security

• Monitoring ONE link: eavesdropper gets nothing • Monitoring TWO links:

–Eavesdropper can do traffic analysis –More difficult if lots of traffic through proxy

• Trust: proxy is a single point of failure –Can be corrupt or subpoenaed

»Example: The Church of Scientology vs. anon.penet.fi

• Protocol issues:

–Long-lived cookies make connections to site linkable

8

How proxy works

• Proxy rewrites all links in response from web site –Updated links point to anonymizer.com

»Ensures all subsequent clicks are anonymized

• Proxy rewrites/removes cookies and some HTTP headers

• Proxy IP address:

–if a single address, could be blocked by site or ISP –anonymizer.com consists of >20,000 addresses

»Globally distributed, registered to multiple domains

»Note: chinese firewall blocks ALL anonymizer.com addresses

9

2

_{Attempt: MIX nets}

Goal: no single point of failure

10 E_pk2( R3, E_pk3( R6,

MIX nets

•Every router has public/private key pair –Sender knows all public keys

•To send packet:

–Pick random route: R2 → R3→ R6→ srvr –Prepare onion packet:

R3 R5 R4 R1 R2 R6 E_pk6( srvr , msg) msg _srvr packet = 11 Eavesdropper’s view at a single MIX

• Eavesdropper observes incoming and outgoing traffic

• Crypto prevents linking input/output pairs •Assuming enough packets in incoming batch •If variable length packets then must pad all to max len

• Note: router is stateless user1 user₂ user₃ Ri batc h 12

Performance

–Privacy as long as at least one honest router on path

• Problems:

–High latency (lots of public key ops) »Inappropriate for interactive sessions

»May be OK for email

–No forward security

• Homework puzzle: how does server respond? –hint: user includes “response onion” in forward packet

R3

R2 R6

13

Web-based user tracking

Browser provides many ways to track users: 1.3rd_{party cookies ; Flash cookies} 2.Tracking through the history file 3.Machine fingerprinting

14

3

_{party cookies}

–User goes to site A. com ; obtains page –Page contains <iframe src=“B.com”> –Browser goes to B.com ; obtains page

HTTP response contains cookie –Cookie from B.com is called a 3rd_{party cookie} • Tracking: User goes to site D.com

–D.com contains <iframe src=“B.com”> –B.com obtains cookie set when visited A.com

⇒

15

Can we block 3

_{party cookies?}

• IE and Safari: block set/write

–Ignore the “Set-Cookie” HTTP header from 3rd_parties

⇒Site sets cookie as a 1st_{party; will be given} cookie when contacted as a 3rd_party –Enabled by default in IE7

• Firefox and Opera: block send/read

–Always implement “Set-Cookie” , but never send cookies to 3rd_party

–Breaks sess. mgmt. at several sites (off by default)

16

Effectiveness of 3

_{party blocking}

–3rd_{party can become first party and then set cookie} –Flash cookies not controlled by browser cookie policy

• Better proposal:

–Delete all browser state upon exit –Supported as an option in IE7

17 1

Tracking through the history file

•E.g., site checks hyper-link color for history •Applications:

–Context aware phishing: » Phishing page tailored to victim –Marketing

–Use browsing history as 2nd_{factor authentication}

18 1

Context-aware Phishing

• Stanford students see:

19 1

SafeHistory/SafeCache

•Define Same Origin Policy for all long term browser state

–history file and web cache

–Firefox extensions: SafeHistoryand SafeCache

•Example: history

–Color link as visited only when site can tell itself that user previously visited link:

»A same-site link, or

»A cross-site link previously visited from this site

20

Machine fingerprinting

•Tracking using machine fingerptings •User connects to site A.com

–Site builds a fingerprint of user’s machine –Next time user visits A.com, site knows it is

the same user

21

Machine fingerprints

ƒe.g. user-agent header:

Mozilla/5.0 (Windows; U; Windows NT 6.0; en-US; rv:1.8.1.14) Gecko/20080404 Firefox/2.0.0.14

• Javascript and JVM can interrogate machine properties:

–Timezone, local time, local IP address

• TCP timestamp: exploiting clock skew

–TCP_timestamp option: peer embeds 32-bit time in every packet header. Accurate to ≈100ms

–fingerprint = (real-time ∆ between packets) (timestamp ∆ between-packets)

22

Administravia

• Office hour on Tue changed to 1-3pm due to schedule conflict

• Additional office hour on Thu/Fri afternoon to help students preparing the final

• In-class final: Dec 10, 306 Soda • Final review on Wed

• Guest lecture on Mon: real-world experiences about breaking security systems

23

De-anonymizing data

24

Problem statement

•An organization collects private user data –Wishes to make data available for research –Individual identities should be hidden

•Examples:

–Search queries over a 3 month period (AOL) –Netflix movie rentals

–Census data

25

Incorrect approach

•Replace “username” or “userID” by random value

Dan → a56fd863ec

John→ 87649dce63

–Same value used for all appearances of userID

•Problem: often data can be de-anonymized by combining auxiliary information

–Examples: AOL search data census data

26

Netflix Prize Dataset

•Released in October 2006 to support research on better recommender algorithms

–Real movie ratings of 500,000 Netflix subscribers »10% of all Netflix users as of late 2005

–Names removed –Maybe perturbed

•Good target for real-world de-anonymization –What can you learn from someone’s movie ratings? –What to use as source of external information?

27

Netflix’s Take on Privacy

Even if, for example, you knew all your own

ratings and their dates you probably couldn’t

identify them reliably in the data because only a small sample was included (less than one-tenth of our complete dataset) and that data was subject to

perturbation. Of course, since you know all your own ratings that really isn’t a privacy problem is it?

-- Netflix Prize FAQ

28

De-Anonymizing Netflix Records

•Average subscriber has 214 dated ratings •How many does the attacker need to know to

identify his victim’s record in the dataset? –Twois enough to reduce to 8 candidate records –Fouris enough to identify uniquely (on average) –Works even better with relatively rare ratings

»“The Astro-Zombies” rather than “Star Wars” •Sparsity!Negligible information leakage is

sufficient for complete re-identification

Fat Tail effect helps here: most people watch obscure crap (really!)

Fat Tail effect helps here: most people watch obscure crap (really!)

29

Robustness

•De-anonymization algorithm is robust to errors in attacker’s external knowledge

–Dates and ratings may be known imprecisely –Some may even be completely wrong

–Perturbation = noise in the data = doesn’t matter!

•Why? Sparsity!!

–Nearest neighbor is so far, can tolerate huge amount of noise, perturbation, imprecision

•Where to find external knowledge? –Cross-correlating with Internet Movie DB

30

What Did We Learn?

These ratings are not in IMDb user’s public profile… Does this tell you anything about this user?

31

Netflix Users with Distance < 0.15

Could edges reflect real-life relationships?
