Network development and design

A short introduction to the MOVE Meter:

a web based tool to support your

planning process

// 6-Nov-15 //

(3)

Content

1. MOVE Mobility

2. MOVE Meter introduction

3. The MOVE Meter in Austin

4. The use of MOVE Meter with HERE in Houston

5. Other features of the MOVE Meter

6. Some technical details

7. Contact information

(4)

1. MOVE Mobility

// 6-Nov-15 //

(5)

MOVE MOBILITY

• Founded in 2012

• Focus:

• Front office in business development for

our partners in international markets

• Europe (Germany, UK, Georgie)

• Outside Europe (US, Uganda, South

Africa, Mexico, Kenia)

• Software development and applications

• MOVE Meter

• Monitoring tool

• Our ambition is to support cities in their

transition towards a Smart Moving City

(6)

2. MOVE Meter introduction

// 6-Nov-15 //

(7)

The MOVE Meter facilitates planning processes

// 6-Nov-15 //

pagina 7 Network development and design with the MOVE Meter

It is a web based tool that:

- let you play with different scenarios

- is easy to use by all planners

- presents results quickly (< 10 minutes per scenario)

In the case of Austin and Houston the tool was used to:

- show the bicycle potential

- demonstrate the impact of cycling on congestion

The MOVE Meter results are based on your traffic data.

For Houston actual speed data (on and off peak) was

used.

(8)

Basic structure of the MOVE Meter

// 6-Nov-15 //

User Interface

Your own model info

OD-Matrix and skims

MOVE Meter

Link characteristics

Databases

Modules

Loaded link information

OD-Matrix

1. Socio-economic changes

TAZ info

OD-Skims

2. Reduce number of trips

BIG Data (i.e. HERE)

Network

3. Change infrastructure

OD-Manipulation

Route Assignment

I

m

p

o

r

t

M

o

d

u

l

e

(9)

Modules

Accessibility index is based on actual on and off peak speeddata (HERE dataset)

Consult

Add measures

Compare

Base scenario

New scenario

Base Scenario with New Scenario

1. Accessibility and land use

1. Socio-economic changes

1. Accessibility and land use

2. Mobility

2. Reduce number of trips

2. Environment

3. Environment

3. Change infrastructure

3. Traffic and infrastructure

4. Traffic and infrastructure

Accessibility Index

Benchmark and Effects based on Big Data

Delayed trips (travel times peak vs. off-peak)

Amount

Motive

Car or Freight

Direction

Triplength

Loaded network

Speed characteristics

OD information

(10)

3. The MOVE Meter in Austin (TX)

// 6-Nov-15 //

(11)

Where is my network congested?

(12)

Who is using my network?

// 6-Nov-15 //

(13)

Where to invest in cycling?

(14)

What is the potential impact of cycling?

// 6-Nov-15 //

(15)

(16)

What did the MOVE Meter add to the process

in Austin ?

// 6-Nov-15 //

…”Austin officials gave the firm (MOVE Mobility)

transportation planning data from its Metropolitan

Planning Organization (MPO), and they now have a

tool by which to analyze how bicycle infrastructure

can affect the transportation system as a whole. The

introduction to the tool allowed us to see one way

and one tool Dutch cities use to make transportation

decisions related to bicycles."

(17)

Overview HERE data (actual on and off

peak speeds on an average weekday).

Short trips on the network

4. The use of the MOVE Meter with HERE

in Houston

(18)

Overview of HERE dataset for the Houston area

// 6-Nov-15 // Network development and design with the MOVE Meter pagina 19

(19)

You can zoom in to any area

(20)

HERE tells you more about congestion

MOVE Meter slides Houston pagina 21

(21)

HERE: delay in morning and evening peak

(22)

Travel times to zones according to model/here

(23)

Assessment of the quality of accessibility

(24)

Use the OD matrices to select and plot short

trips (< 7 miles) on a grid

(25)

(26)

Example of implementation of bicycle programme

(27)

Effect of the bicycle programme

Right hand panel shows possible increase of speed on the network due

to decrease in demand

(28)

Effect of measures on car accessibility

(29)

Impact of infill or sprawl in Utrecht

Network performance based on actual

speeds

Accessibility Index

5. Other MOVE Meter applications

// 6-Nov-15 //

(30)

Click on the zones where you want to build 20.000 houses.

The MOVE Meter calculates trips and divides them over the region.

Impact of infill or sprawl in Utrecht (1)

Scenario 1: Condense in the city Scenario 2: Urban sprawl

6-Nov-15

(31)

Impact of infill or sprawl in Utrecht (2)

Increase of traffic when condensing Increase when spreading

(32)

The use of the Accessibility Indicator (BBI)

6-Nov-15 Network development and design with the MOVE Meter pagina 33

(33)

Den Haag Centre :

(34)

Monitoring using actual speeds 2013 and 2014

including travel times per distance class

// 6-Nov-15 // Network development and design with the MOVE Meter pagina 36

(35)

(36)

Difference with other transport modeling tools

// 6-Nov-15 //

• Web based (you can use any PC/laptop anywhere);

• Easy to use (no need to know Transport Planning

Software);

• Quick scenario analyses;

• Based on data from your own Transportation Model;

• Scenario analyses ready after 10-15 minutes.

(37)

Why is the MOVE meter so fast?

1. The MOVE Meter works with less

zones. It aggregates data from zones

that are further away from the area

you have pointed out as focus area.

2. The MOVE meter focuses on the

issues addressed. So when you want

to assign an OD-matrix to get an idea

of the effects on V/C ratios, the MOVE

Meter assigns the OD matrix without

calculating new speeds or changes in

modal split.

Zones in the original model

The MOVE meter aggregates

data outside the focus area.

(38)

MOVE Mobility

Marcel van Lieshout

P.O. Box 234

NL-7400 AE Deventer

www.movemobility.nl

[email protected]

+31 (0) 6 22 37 87 87

7. Contact information
