POWER PULSE VALVES remote pilot threaded or Quick Mount connection 3/4 to 1 1/2

(1)

NC

FEATURES

• The piston cartridge pulse valves are especially designed for dust collector service applications, combining high flow, long life and extremely fast opening and closing to produce reliable and economical operation

• The angle bodies and special piston cartridge result in unique operating fea-tures required for dust collector service applications

• The high quality polyacetal (POM) piston cartridge guarantees a long operating life and a large temperature range

• The design with Quick Mount connections eliminates the time consuming thread cutting and sealing resulting in maximum flexibility while the valve will be anchored to the pipes

• Valves can be supplied according to ATEX Directive 94/9/EC for non-electrical equipment by using suffix GD

• The components satisfy all relevant EC directives

POWER PULSE VALVES

remote pilot

threaded or Quick Mount connection

3/4 to 1 1/2

GENERAl

Differential pressure (PS) 0,3 - 8,5 bar [1 bar = 100kPa] Ambient temperature range -20 to +85°C

CONSTRUCTION

Body Aluminium

Bonnet Aluminium

Quick Mount clamps Steel

Bolts Steel

Sealings NBR (nitrile)

Piston/cartridge POM (polyacetal) / NBR (nitrile)

PIlOT SOlENOID VAlVES (2/2 NC function)

SPECIFICATIONS

2/2

353

Series

fluid temperature range (TS) piston

air -20 to +85°C POM (polyacetal)

main pulse valve catalogue number remote pilot connection recommended executions orifice size (mm)

manifold pilot valves in a box (IP65)

single pilot valves (IP20) E353A810 E353A820 S353A710 S353A720 S353A810 S353A820

G 1/8 3,6 pilot box series 110_{2 to 12 pilots 1/8} series 257

pipe size remote pilot connection orifice size flow coefficient Kv operating pressure

differential (bar) catalogue

number Quick Mount

clamps min.

max. (PS) air

(mm) (m3_/h) _(l/min) _~/= _standard _{ATEX dust II2G/D}

(G*) - Threaded pipe connection

3/4 1 11/2 1/8 1/8 1/8 20 25 40 14 23 46 233 383 768 0,3 0,3 0,3 8,5 8,5 8,5 E353A810 E353A820 E353A830 E353A810 GD E353A820 GD E353A830 GD

(Ø) - Quick Mount connection on inlet

3/4 1 11/2 1/8 1/8 1/8 20 25 40 14 23 46 233 383 768 0,3 0,3 0,3 8,5 8,5 8,5 S353A810 S353A820 S353A830 S353A810 GD S353A820 GD S353A830 GD C117-281 C117-282 C117-290

(Ø) - Quick Mount connection on inlet & outlet

3/4 1 11/2 1/8 1/8 1/8 20 25 40 14 23 46 233 383 768 0,3 0,3 0,3 8,5 8,5 8,5 S353A710 S353A720 S353A730 S353A710 GD S353A720 GD S353A730 GD C117-281 C117-282 C117-290 X003GB-2009/R8 Availability

, design and specifications are subject to change without notice

. All r

ights reser

ved.

(2)

VALVES SERIES 353

OPTIONS

● Pilot boxes containing 2 to 12 pilot valves.

● Pilot valves can be equipped with explosionproof solenoids for hazardous locations according to “ATEX” and national

standards.

● Additional Quick Mount clamps for outlet connection, see “Specifications” table.

● The valves can be mounted in any position without affecting operation.

● Pipe connection identifier is: G*= combination thread according to ISO 228/1 and ISO 7/1 or Ø for Quick Mount.

● For Quick Mount types tightness is achieved by the O-ring sealing on the pipes (3/4"=Ø26,4 to 27,4 and 1"=Ø33,2 to 34,2

and 1 1/2"=Ø47,8 to 48,8) according to ISO 4200.

● When connecting piping or tubing to the G1/8 connection in the valve bonnet, the remote ASCO pilot valve should be

mounted as close as possible to the main pulse valve. Connection tubing lengths of 3 meter or less have little effect on the pulse response. Installations with over 3 meter of tubing must be tested under actual operating conditions. Tubing with Ø 6 mm O.D. is recommended for all installations.

● Other pipe threads are available on request.

● Installation/maintenance instructions are included with each valve. ● Spare parts kit and replacement coils are available.

INSTAllATION

DIMENSIONS (mm), WEIGHT (kg)

catalogue number A B C D E F weight (C)

E353A810 (GD) E353A820 (GD) E353A830 (GD) S353A810 (GD) S353A820 (GD) S353A830 (GD) S353A710 (GD) S353A720 (GD) S353A730 (GD) 84 96 121 103 115 146 103 115 146 94 100 127 94 100 127 113 119 153 42 51 60 42 51 60 61 70 86 50 62 71 69 81 97 69 81 97 39 46 62 39 46 62 39 46 62 77 77 112 77 77 112 77 77 112 0,42 0,53 1,07 0,50 0,59 1,27 0,58 0,65 1,27 Fig.1 Fig.1 Fig.1 Fig.2 Fig.2 Fig.2 Fig.3 Fig.3 Fig.3 (C) construction type

Fig. 1: Threaded type Fig. 2: Quick Mount type (inlet only)

A B C D E F A B C D G H B A C D E F

Fig. 3: Quick Mount type (inlet & outlet)

X003GB-2009/R8 Availability

. All r

ights reser

ved.

(3)

NC

IN

2/2

353

Series

DP14242GB-2012/R01 Availability

. All r ights reser ved. FEATURES • The diaphragm pulse valves are especially designed for dust collector service applications, combining high flow, long life and extremely fast opening and closing to produce reliable and economical operation • The high flow, angle type bodies in combination with the special main diaphragm assemblies give the unique operating features required for dust tcollector service applications • Integral compression fittings for fast, easy, secure installation • Valves can be supplied according to ATEX Directive 94/9/EC for non-electrical equipment by using suffix GD • The valves satisfy all relevant EC directives

GENERAL

fluids () temperature range (TS) diaphragm ()

air -40 to +85 °C TPE (3/4 und 1) -20 to +85 °C CR (1 1/2)

MATERIALS IN CONTACT WITH FLUID

() Ensure that the compatibility of the fluids in contact with the materials is verified Body Aluminium / Stainless steel 316L Spring Stainless steel

Diaphragm TPE (thermoplastic polyester elastomer oder CR (chloroprene)

PILOT SOLENOID VALVES (2/2 NC function)

main pulse valve catalogue number remote pilot connection recommended executions orifice size

manifold pilot valves in a box

(IP 65)

single pilot valves (IP20)

(mm)

G353A041

G 1/8 3.6 pilot box series _{2 to 12 pilots 1/8}110 series 257

G353-055 G353A042 G353-056 G353A045

G 1/4 5,6 pilot box series C20

4 to 6 valves 1/4 series 262 / 272 G353-066

SPECIFICATIONS

pipe size remote pilot connection orifice size flow coefficient Kv operating pressure

differential (bar) catalogue

number

FPM

min.

max. (PS) air ()

G Ø B (mm) (m³/h) (l/min) ~/= aluminium stainless steel 316L

G - threaded pipe connection

3/4 G 1/8 24 14 233 0,35 8,5 G353A041 G353A130 V

1 G 1/8 27 17 283 0,35 8,5 G353A042 G353A131 V

1 1/2 G 1/8 52 46 768 0,35 8,5 G353A045 - V

Ø - Compression fitting pipe connection

3/4 G 1/8 24 14 233 0,35 8,5 G353-055 - V 1 G 1/8 27 17 283 0,35 8,5 G353-056 - V 1 1/2 G 1/8 52 43 717 0,35 8,5 G353-066 - V

Ø B

IN

PULSE VALVES

single stage, remote pilot

threaded body or compression fitting

3/4 to 1 1/2

(4)

DP14242GB-2012/R01 Availability

. All r

ights reser

ved.

OPTIONS

• Valves can also be supplied with FPM (fluoroelastomer) diaphragms and seals. Use the appropriate optional suffix letter for identification

• Sequential controller for pilot solenoid valves • Pilot boxes containing 2 to 12 pilot solenoid valves

• Pilot solenoid valves can be equipped with explosionproof solenoids for hazardous locations according to “ATEX” and national standards

INSTALLATION

• The valves can be mounted in any position without affecting operation • Threaded pipe connection is G (ISO 228/1) or compression fitting

• When connecting piping or tubing to the G1/8 connection in the valve bonnet, the remote ASCO pilot valve should be moun-ted as close as possible to the main pulse valve. Connection tubing lengths of 3 meter or less have little effect on the pulse response. Installations with over 3 meter of tubing must be tested under actual operating conditions. Tubing with Ø 6 mm O.D. is recommended for all installations

• For compression fitting types tightness is achieved by the compressed gasket on the blow tube • Other pipe threads are available on request

• Installation/maintenance instructions are included with each valve • Spare parts kits and replacement coils are available

DIMENSIONS (mm), WEIGHT (kg)

catalogue number A B C D E F G weight (1) (C)

G353A041 - G 1/8 51 89 75 41 65 0,45 Fig. 1 G353A042 - G 1/8 51 89 75 41 64 0,4 Fig. 1 G353A045 30 G 1/4 71 130 136 71 98 1 Fig. 1 G353-055 - G 1/8 88 125 75 47 109 0,58 Fig. 2 G353-056 - G 1/8 88 124 75 47 129 0,61 Fig. 2 G353-066 30 G 1/4 117 177 136 73 161 1,33 Fig. 2 G353A130 - G 1/8 51 89 75 41 64 0,92 Fig. 3 G353A131 - G 1/8 51 89 75 41 64 0,87 Fig. 3 (C) Construction type

VENTIL BAUREIHE 353

IN A B C D E F G A B C D E F G

Fig. 1: Threaded pipe connection - aluminium Fig. 2: Compression type fitting - aluminium

Fig. 3: Threaded pipe connection - Stainless steel

(5)

NC

1

IN

PULSE VALVES

dual stage, remote pilot

threaded body 1 1/2 to 3 or

compression fitting Ø 1 1/2

FEATURES

• The pulse valves are especially designed for dust collector service

applications, combining high flow, long life and extremely fast opening and closing to produce reliable and economical operation

• The high flow, angle type bodies in combination with the special main diaphragm assemblies give the unique operating features required for dust collector service applications

• Integral compression fittings for fast, easy, secure installation • Valves can be supplied according to ATEX Directive 94/9/EC for non-electrical equipment by using suffix GD

• The components satisfy all relevant EC directives

GENERAl

temperature range (TS) diaphragm

air -20 to +85°C CR (chloroprene)

fluids

CONSTRUCTION

Body Aluminium

Springs Stainless steel Diaphragms CR (chloroprene)

main pulse valves

single pilot valves remote pilot connection orifice size (mm) G1/8 3,6

manifold pilot valves in a box (IP65) (IP20) G1/4 5,6 recommended executions G353A048 G353A049 G353-058 G353A046 G353A063

SPECIFICATIONS

series 257 _ pilot box series 110 2 to 12 valves 1/8 pilot box series C20 4 to 6 valves 1/4 catalogue number pipe size

G - Threaded pipe connection

Ø - Compression fitting pipe connection

1 1/2 G353A063 max. (PS) flow coefficient Kv orifice size 0,35 0,35 0,35 1,0 717 1 1/2 2 2 1/2 3 52 52 66 66 76 46 77 92 170 43 768 1290 1540 2833 0,35 8,5 8,5 8,5 6,0 8,5 G353A046 G353A048 G353A049 G353-058(1) (mm) (m3_/h) _(l/min) _{~ /=} air operating pressure differential (bar) min.

(1) Threaded pipe connections are external (male thread).

V V V V

2/2

353

Series

standard ATEX II2G/D

V G353A063 GD G353A046 GD G353A048 GD G353A049 GD G353-058 GD(1) OPTION FPM Ø B

IN

. All r

ights reser

ved.

(6)

VALVES SERIES 353

OPTIONS

INSTAllATION

A B C D E F G H weight 1,10 2,60 2,30 3,70 1,43 30 30 30 48 30 G 1/8" G 1/4" G 1/4" G 1/4" G 1/8" 71 95 95 143 87 130 168 168 240 177 136 165 165 192 136 G 3/8" G 3/4" G 3/4" G 1/2" G 3/8" 90 121 121 121 96 120 166 166 214 183 Fig.1 Fig.1 Fig.1 Fig.3 Fig.2 (C) catalogue number G353A046 (GD) G353A048 (GD) G353A049 (GD) G353-058 (GD) G353A063 (GD) (C) construction type A B C D E F G H A B C D E F G H IN A B C D E F G H

● Valves can also be supplied with FPM (fluorelastomer) diaphragms and seal materials. Use the appropriate optional

suffix letter for identification

● Sequential controller for pilot solenoid valves ● Pilot boxes containing 2 to 12 pilot solenoid valves

● Pilot solenoid valves can be equipped with explosionproof solenoids for hazardous locations according to “ATEX” and

national standards

● The valves can be mounted in any position without affecting operation ● Threaded pipe connection is: G = G (ISO 228/1) or compression fittings

● When connecting piping or tubing to the G1/8 or G1/4 connection in the valve bonnet, the remote ASCO pilot valve should be

mounted as close as possible to the main pulse valve. Connection tubing lengths of 3 meter or less have little effect on the pulse response. Installations with over 3 meter of tubing must be tested under actual operating conditions. Tubing with Ø 6 or Ø 8 mm O.D. is recommended for all installations

● For compression fitting types tightness is achieved by the co mpressed gasket on the blow tube ● Other pipe threads are available on request

● Installation/maintenance instructions are included with each valve ● Spare parts kit and replacement coils are available

Fig.1 Threaded type Fig.2 Compression fitting type

Fig. 3 External threaded type

. All r

ights reser

ved.

(7)

2/2

Series

355

POWER PULSE

TANK SYSTEM

(Ø160)

remote pilot

1

FEATURES

● Power Pulse Tank System using aluminium profile and end covers with CE

approval according to Directive 97/23/EC for Pressure Equipment

● Full immersed valve system with special springless piston/diaphragm design

offers highest peak pressure and best flow performance operating features required for dust collector applications

● The high quality TPE piston/diaphragm guarantees a long operating life and a

large temperature range

● Possibility to apply different combinations of pitch distances and upto 24 valves ● Easy to connect to other tank systems. Service connections for different

acces-sories such as: filter regulator, pressure gauge, safety valve and automatic / manual drain valve

● Several blow pipe connections available, such as: Quick Mount, push-in, hose or

threaded

CONSTRUCTION

Tank Anodized aluminium

Adapter/body Aluminium Clipring Stainless steel Clamps Stainless steel Bolts (clamps) Stainless steel Sealings & disc NBR (nitrile)

Piston/diaphragm TPE (thermoplastic polyester elastomer)

GENERAl

Differential pressure (PS) 0,3 to 8,5 bar [1 bar = 100 kPa] Ambient temperature range -20°C to +85°C

Tank System

volume 0,20 dm3_{per cm tank}

recommended min. tank volume 10 dm3_{(equals 500 mm tank length)} min. pitch distance 120 mm

maximum length 3000 mm min. pulse time 50 ms

NC

single pilot valve (IP20) orifice size (mm) G1/8 3,6 E355AN . . E355AO . . E355AP . . E355AQ . .

pilot valve box (IP65)

RECOMMENDED PIlOT VAlVES AND BOXES

(2/2 NC function)

pilot box series 110

2 to 12 pilots 1/8 US E257A001 US E257A002 US E257A003 main pulse valve catalogue number remote pilot valve connection

fluid temperature range (TS) piston/diaphragm

air -20 to +100 °C TPE (thermoplastic polyester elastomer)

. All r

ights reser

ved.

(8)

flow coefficient

Kv

VALVES SERIES 355

SPECIFICATIONS

(1) for a selection of pilot boxes see pages X003-29 to X003-38 (2) specify required number of valves between 01 and 24

catalogue number (mm) pipe size remote pilot connection orifice size min.

operating pressure differential (bar)

G air

maximum (PS)

Male threaded connection (R1") Male hose connection (Ø 33,5-33,9)

Push-in connection (Ø 33,2-34,2) Quick mount with clamps (Ø 33,2-34,2)

N

P

Q

O

for example:

F E355A N 06

ORDERING INFORMATION

-(l/min) (m3_/h)

. E355A . . .

1" 1/8 25 23 384 0,30 8,5

6 valves pilot box

12 valves pilot box

F

(1)

E 3 5 5 A

06

₍₂₎

+ Dimension code (specified on next page)

34 9 37 9 64 52 37 64 ₅₂ 17 X003GB-2009/R8 Availability

. All r

ights reser

ved.

(9)

VALVES SERIES 355

ORDERING INFORMATION DIMENSION CODE

Start distance A (min. 110 mm) Standard pitch B/C/D (min. 120 mm) Deviating pitch B/C/D (min. 120 mm) End distance A (min. 110 mm) Example I: Dimension code for a 4 valves tank system:

Operator Remote, pilotbox controlled 24V/DC without heating Connection Quick Mount

Number of valves 4 pcs Start and End distance 110 mm Standard pitch 170 mm Deviating pitch None Catalogue number F E355AN04 Dimension code 110170

Pilotbox S G110A040 24V/DC Complete order number F E355AN04 + 110170 Example II: Dimension code for a 12 valves tank system:

Operator Remote, controlled with external pilotbox

Connection Thread

Number of valves 12 pcs Start and End distance 130 mm Standard pitch 140 mm

Deviating pitch Between valve 3 and 4 is position D; 180 mm and between valve 7 and 8 is position H; 200 mm Catalogue number E355AQ12

Dimension code 130140D180H200

Complete order number E355AQ12 + 130140D180H200 For assistance please consult our website: www.asconumatics.eu

90 35 110 180 145 258 140 78 38 36

Fig. 1 (front view)

DIMENSIONS (mm)

22 217 174 46,5 A B C D A Ø45 52 Service connection G¼" Pressure supply G1"

Fig. 2 (side view)

space for: 187 mm 6 pilot valve box

322 mm 12 pilot valve box G1/8"

. All r

ights reser

ved.

(10)

VALVES SERIES 355/353

SEPARATE / SPARE POWER PUlSE VAlVES

OPTIONS

● Special customized executions

● Pilot boxes containing 2 to 12 pilot valves

● Separate pilot valves can be equipped with explosionproof solenoids for hazardous locations according to “ATEX”

(CENELEC) and national standards

● Separate Quick Mount clamps for outlet connection; kit number: C132-679

● Tank system can be mounted in any position using the standard brackets integrated in the end cap (M12 bolts

recommended) without affecting operation

● Pipe connection identifier is: R = according to ISO 7/1, G = according to ISO 228/1 or Ø for other outlet connections ● For Quick Mount types tightness is achieved by the O-ring sealing on the pipe (1" = Ø33,2 to 34,2) according to ISO 4200 ● When connecting piping or tubing to the G1/8 connection in the valve bonnet, the remote ASCO pilot valve should be

mounted as close as possible to the main pulse valve. Connection tubing lengths of 3 meter or less have little effect on the pulse response. Installations with over 3 meter of tubing must be tested under actual operating conditions. Tubing with Ø 6 mm is recommended for all installations

● Installation/maintenance instructions are included with each tank system ● Spare valves, spare parts kits and coils are available

INSTAllATION

SPECIFICATIONS

G1/8" Ø 99 99 33 pipe size catalogue number 1 E353A231

(G) Female threaded connection (ISO 228/1)

weight

0,428

FEATURES - (same as for the tank system)

G1"

. All r

ights reser

ved.

(11)

Series

2/2

357

TANK SYSTEM

(

Ø 8"

)

remote pilot

1 1/2

NC

FEATURES

• Immersion tank system using steel profile and welded end covers with CE appro-val according to Directive 87/404/EC

• Immersed valve system with special diaphragm design offers highest peak pres-sure and best flow performance operating features required for dust collector applications

• The high quality diaphragms are reinforced and wear resistant to guarantee a long operating life, even under harsh conditions

• Possibility to apply different combinations of pitch distances

• Service connections for different accessories such as: filter regulator, pressure gauge, safety valve and automatic/manual drain valve

• Available with hose and threaded blow pipe connections

GENERAl

Differential pressure (PS) 0,35 to 8 bar [1 bar = 100kPa] Ambient temperature range -10 to +80°C

fluid temperature range (TS) seal materials

air -10 to +80°C CR (chloroprene)

CONSTRUCTION

Tank Steel, grey

Bonnet Aluminium

Bolts Stainless steel Sealing & NBR (nitrile) Diaphragm CR (chloroprene)

pipe

size pulse valvesmain remote pilotconnection

recommended executions orifice

size (mm)

manifold pilot valves in a box

(IP 65)

single pilot valves

(IP20)

1 1/2" G357APxx G1/8 3,6 pilot box series _{2 to 12 valves 1/8}110 series 257

G357AQxx

SPECIFICATIONS

pipe size

orifice size flow coefficient_Kv

operating pressure differential (bar) catalogue number min max. (PS) air

(mm) (m3_/h) _(l/min) _{~ / =} _hose _threaded

8" Tank System

1 1/2" 40 46 768 0,35 8 G357APxx (1) (2) _G357AQxx (1) (2)

(1)_{Standard tank has round ends. For flat ends use suffix FE}

(2)_{xx indicates the number of valves}

. All r

ights reser

ved.

(12)

tank diameter fig. C Ø E F G H 8" 2 348 284 50 8 110 tank diameter fig. B C D Ø E F G H 8" 3 210 348 200 284 50 8 110

INSTAllATION

• Tank System can be mounted in any position. We can supply standard mounting brackets with each tank by specifying suffix MB behind the catalogue number (see figure 2 and 3)

• Installation / maintenance instructions and declaration of conformity are included with each tank system • Spare part kits and coils are available F G C E H Ø13 _F C D Ø13 H E Ø13 G B

MOUNTING BRACKETS

ORDERING

ORDERING EXAMPlE TANK SYSTEM:

G357AP 04 (*) _{+ 170 180 D200}

deviating pitch standard pitch start & end dist. tank end type no. of valves catalogue no.

Example: Dimension code for a 4 valves tank system:

Tank diameter 8"

Operator Remote

Pipe size 1 1/2"

Connection Hose (see fig. 1: Connection Type)

Number of valves 4 pcs

Start and End distance 170 mm

Standard pitch 180 mm

Deviating pitch Between valve no. 3 and no. 4 is position D (see fig. 1) 200 mm

Catalogue number G357AP04 24V/DC

Dimension code 170180D200

Fig.2 - Contra bracket _{Fig.3 - Bracket}

tank

diameter fig.

A

min. start distance

B / C / D

minimum pitch

A

min. end distance Ø E F G Ø H

(round) (flat) (round) (flat) (round) (flat)

8" 1 170 118 160 160 170 118 218,1 G 1 1/2" 70 18 48,3

() For standard tank (round ends) use no suffix, for flat ends use suffix FE

DIMENSIONS (mm)

Fig.1 Flat ends (Suffix "FE")

Connection Type 80 80 Ø H F 40 HOSE THREADED A B C D A G A G F F Ø E F CERT. PLATE 1/4" GAS FEMALE (3x)

TANK SYSTEM SERIES 357

SPARE PARTS KITS

catalogue number spare parts kit no.

~/=

G357APxx _C113826

G357AQxx

. All r

ights reser

ved.
