WE HAVE THE RIGHT POWER SUPPLY FOR YOUR APPLICATION

Switchmode Power Supplies

Australia Core Assortment

Catalogue & Price List 2010/2011

WE HAVE THE RIGHT

POWER SUPPLY

FOR YOUR APPLICATION

P L U S C O M P L E T E P E A C E O F M I N D W I T H

Power Supply Selection Considerations

Method of operation

Primary switch-mode power supplies are distinguished by a high degree of efficiency and also by their compact dimensions and moderate generation of heat. The mains voltage is rectified directly. The rectified voltage is then chopped with a higher frequency than that of the mains frequency. A transformer – which can be quite small due to the high switching frequency – converts the voltage with the switching frequency to the required value.

The voltage is now rectified and smoothed by a filter. This regulator control itself is carried out by means of pulse-width modulation. The on and off times of the chopper transformers are regulated to ensure that the output voltage remains stable.

Output Voltage

ƒ All Weidmuller Switchmode Power Supplies have a regulated output voltage, that is the output voltage remains constant irrespective of input voltage or load current, provided the supply voltage is within the specified range. Some models can be powered from DC as well as AC

Environmental

ƒ Environmental issues to consider are the ambient temperature where the power supply is expected to operate. Note the de-rating for high ambient temperature use. Vibration in the area of use must also be considered.

Power Boost

ƒ All Weidmuller Switchmode Power Supplies have start up boost of up to 400%. This allows for non resistive loads to be started. Inductive loads, i.e. solenoid valves and motors, have a starting current as high as six times full load current, while capacitive loads, i.e. some electronic devices and PLC’s with input filtering capacitors have a start up current of up to twelve times. Switchmode power supplies have a built in protection circuit which turns the output off if a sudden load is introduced which exceeds the rated load of the power supply.

Short Ciruit Protection

ƒ Short circuit protection is also built in so that if there is a short circuit in the load circuit the power supply will shutdown until the short circuit is removed, and will auto start.

Overload Protection

ƒ Overload thermal protection is built in to protect the power supply if the load applied is in excess of the rated current, for a period of time. This will shutdown the output until the power supply cools down, and will need to be reset by disconnecting and reconnecting the input supply.

Mounting

ƒ Mounting types available are “DIN” rail mounting or chassis / panel mounting.

Redundancy

ƒ For redundant operation where two identical power supplies are connected in parallel, for reliability and safety reasons the use of diode auctioneering modules is necessary. In this configuration there is no possibility of a back feed from one power supply to the other and supply failure alarms can be operated.

Load Sharing

ƒ When two or more power supplies are to be connected in parallel for power sharing the output voltage of the power supplies must be adjusted to be within 50mV of each other. To achieve this the voltmeter being used must be accurate and all test leads must be securely connected when making the adjustment, not just held or pushed onto the terminals. The method of wiring must also be done in the correct configuration so as to avoid different wire lengths when bridging the power supplies. If possible the use of a single higher output power supply is a better option than parallel connect smaller power supplies. It is often difficult to get more than two parallel connected power supplies to current share.

3

ECOLine

PRO-M

PRO-H

4-5

The price vs performance winner.

Advanced feature power supply in ultra compact housing.

For industrial and critical power requirements.

6-7

8-9

EasyLine

Panel mount stable and reliable power for machines.

11

P

o

w

er

S

u

p

p

lie

s

CONTENTS

INSTAPower 24W

WAVEPower

Powering inductive loads. Up to 3 times starting current.

Slimline fully protected power supply with plug / socket connections.

10

10

INSTAPower 25-48W

Versatile adjustable output voltages from 4 to 55Vdc.

10

ECOline 88-132/176-264 110-330 24 24-28 3 to 20 50% for 2 - 5s Y Metal

ECOline

3 Phase 340-575 X 24 24-28 10 to 40 50% for 2 - 5s Y Metal

PRO-M 85-264 80-370 24 22.5-29.5 3 to 40 120% for 2min _spacewith Metal

PRO-M

3 Phase 320-575 450-800 24 22.5-29.5 5 to 40 120% for 2min spacewith Metal

PRO-H 85-132/187-264 N/A 24 24-28 3.75 to 25 N/A Y Metal

INSTAPower

25-48W 85-264 110-370 4 to 55 Y 1 to 5 N/A Y Plastic

INSTAPower

24W 85-265 120-300 5 to 28 N 1 to 2 400% Y Plastic

EasyLine 85-264 110-370 12, 24, 48 Y 1.1 to 10.5 150% N/A Metal

ECO

LINE

Efficient and Reliable DC Switchmode Power Supplies

Output LED Power Indication

Indication

Robust metal housing mounts on TS35 DIN Rail

Robust

Thanks to the wide range of inputs (85 V AC to 265 V AC), the power supplies range is suitable for a wide variety of

applications. Local and International Approvals: C Tick, CE, UL, CSA

International use

AC / DC

Ventilation Channel for Side by Side stacking with no derating

Note: All prices above are list prices and standard customer discounts may apply.

All prices exclude GST. Weidmuller standard terms & conditions of sale also apply. ₅

If you're comparing price with performance, the economical ECOLINE series is the flagship of Weidmuller's range of switchmode power supplies. Packed with features and with the same quality and reliability you've come to expect from Weidmuller, the ECOLINE will not disappoint.

ƒ Robust metal housing ƒ Mounts on TS35 Din Rail ƒ Output LED power indication

ƒ Adjustable output 24-28Vdc for Voltage Drop Compensation ƒ Wide range switchable supply input voltage

ƒ Built-in remote status alarm via C/O relay

ƒ Power diode module for parallel connection/redundancy

ƒ Built-in ventilation channel for side by side stacking & no de-rating ƒ Up to 50% overload protection and auto restart (Power boost 2-5s) ƒ Local and International Approvals: CTick, CE, UL, CSA

Max. Output

Power Output Current Output Voltage Input Voltage Dimensions (LxWxHmm) Order Number List Price

1-phase 72W 3 A 24-28 Vdc 85-264Vac/110-370Vdc 110 x 55.5 x 125 8708660000 $74.12 120W 5 A 24-28 Vdc 88-132Vac/176-264Vac/250-370Vdc 110 x 65.5 x 125 8708670000 $88.73 240W 10 A 24-28 Vdc 88-132Vac/176-264Vac/250-370Vdc 110 x 125.5 x 125 8708680000 $163.39 480W 20 A 24-28 Vdc 88-132Vac/176-264Vac/250-370Vdc 110 x 227.5 x 125 8778870000 $275.00 3-phase 250W 10 A 24-28 Vdc 3x400Vac/340-575Vac 110 x 125.5 x 125 8708700000 $173.00 480W 20 A 24-28 Vdc 3x400Vac/340-575Vac 110 x 227.5 x 125 8708710000 $260.00 960W 40 A 24-28 Vdc 3x400Vac/340-575Vac 125 x 280 x 150 8708730000 $440.00

It is often necessary to connect two power supplies in parallel for increased load current requirements or redundancy. The best solution to do this is to use a Diode Auctioneering Module. These modules contain two full current rated diodes with a common cathode connection. To install you simply connect the output of each power supply to the input terminals of the diode module. A single output is then available from the diode module. With this setup the power supplies can not drive each others output .

ƒ Robust metal housing ƒ Mounts on TS35 Din Rail

ƒ Built-in ventilation channel for side by side stacking & no De-rating ƒ Local and International Approvals: C Tick, CE, UL, CSA

240V~ 24V ECOLINE Power Supplies Diode Module DC E1 E2 V V + -240V~ 24V + -+

-Type Output _Current Output _Voltage Input _Voltage Input_Current Dimensions _(LxWxHmm) Order _Number List _Price

CP DM 10 0-20A max or 10A

redundancy mode Vin-0.5 typical 40Vdc max. 2 x 0-10Amax. 125x55.5x100 8710620000 $78.04

CP DM 20 0-40A max or 20A

redundancy mode Vin-0.5 typical 40Vdcmax. 2 x 0-20Amax. 142x55.5x100 8768650000 $111.73

ECO

LINE

Diode Modules

DOUBLE YOUR POWER / REDUNDANCY

PRO-M

Power supplies for space-saving use in automation technology

Module power can be increased by connecting up to five power supplies in parallel without diode module.

Parallel connection

Wide temperature range from –25 °C … +70 °C.

Robust

–25 °C

to

+70 °C

Space-saving configuration in the switching cabinet through very narrow housing construction and side-by-side connectability.

Narrow

from 33 mm

Thanks to wide-range input (both DC as well as AC voltages can be used; no switching required) and extensive approvals (UL/CSA and GL (EMC 1 - bridge).

International use

Note: All prices above are list prices and standard customer discounts may apply.

All prices exclude GST. Weidmuller standard terms & conditions of sale also apply. ₇

PRO-M Advanced Feature

Switchmode Power Supplies

ƒ The new PRO-M range of switchmode power supplies have a space saving of up to 50% and no gap required between multiple units. PRO-M will squeeze into the tightest of switchboards or machines

ƒ Extended temperature Range of -25°C to +70°C extends the number of application possibilities

ƒ Power increasing with up to 5 modules is accomplished without the need for external diode modules

ƒ A Power boost up to 120% is provided for up to 2 minutes and with overall efficiencies of up to 90% the new PRO-M series delivers in all areas

Max. Output

Power Output Current Output Voltage Input Voltage Dimensions (LxWxHmm) Order No. List Price

1-phase 70 W 3A 24 V (22.5 to 29.5 V) 85-264Vac / 80-370Vdc 125x33x130 8951330000 $99.00 120 W 5 A 24 V (22.5 to 29.5 V) 85-264Vac / 80-370Vdc 125x40x130 8951340000 $129.00 180 W 7.5 A 24 V (22.5 to 29.5 V) 85-264Vac / 80-370Vdc 125x50x130 8951350000 $199.00 250 W 10 A 24 V (22.5 to 29.5 V) 85-264Vac / 80-370Vdc 150x60x130 8951360000 $219.00 500 W 20 A 24 V (22.5 to 29.5 V) 85-264Vac / 80-370Vdc 150x115x130 8951370000 $369.00 1000W 40 A 24 V (22.5 to 29.5 V) 85-264Vac / 80-370Vdc 150x140x130 8951380000 $779.00 3-phase 120 W 5A 24 V (22.5 to 29.5 V) 320-575Vac / 450-800Vdc 125x40x130 8951390000 $249.00 250 W 10 A 24 V (22.5 to 29.5 V) 320-575Vac / 450-800Vdc 150x60x130 8951400000 $315.00 500 W 20 A 24 V (22.5 to 29.5 V) 320-575Vac / 450-800Vdc 150x115x130 8951410000 $429.00 1000 W 40 A 24 V (22.5 to 29.5 V) 320-575Vac / 450-800Vdc 150x140x130 8951420000 $665.00

The optimal and reliable power supply for machinery. The solid, very narrow metal housing of the 10 different versions of the 24 V DC supply enable installation without lateral spacing, thereby saving space on the DIN rail .

AC and DC wide-range inputs and a broad temperature range enable universal use. Thanks to its high efficiency, over load resistance and high performance reserves, the PRO-M is the reliable power supply in all applications. Should one phase fail, the 3-phase PRO-M power supply modules continue to work reliably, i.e. in two-phase operation.

Rated load Temperature 120 % 100 % 45 °C 60 °C 70 °C Power reserve

Powerful Wide choice

With additional power reserves at standard temperatures. The right power supply for every application:

1-phase 3 A, 5 A, 7.5 A, 10 A, 20 A, 40 A and

3-phase 5 A, 10 A, 20 A, 40 A.

Robust

Designed for use in areas of high shock and vibration

Shock & Vibration Proof

1G Vibration

15G Shock

Green LED OK Red LED OFF Remote alarms

Status Alarms

Equiped for long reliable service life. High Mean Time Between Failures

Reliable

Wide temperature range from –25 °C … +70 °C.

–25 °C

to

+70 °C

PRO-H

9

PRO-H

FOR EXTREME REQUIREMENTS

The PRO-H is a new generation of high performance DIN-rail mounted single-phase power supplies designed to work reliably even under the most demanding factory floor conditions. A high power reserve guarantees reliable start-up of loads with high inrush currents such motor starting applications. Excellent electrical specifications and high immunity against fluctuations in input voltage makes these compact modules the best choice to power sensitive loads in industrial process control systems, machine tools or other demanding industrial applications.

ƒ Industrial grade design

ƒ Rugged metal case for harsh industrial environments

ƒ Autoselect input and international safety approvals

ƒ Variable output voltage

ƒ Indefinite short circuit, overvoltage and over temperature protection

ƒ Power OK signal

ƒ Remote On/Off

ƒ Shock and vibration proof

ƒ Optional panel mounting

ƒ Redundancy module

Max. Output

Power Output Current Output Voltage Input Voltage Dimensions (LxWxHmm) Order Number

70 W 6.5 A 12 Vdc 85-132Vac / 187-264Vac 110x35x110 1105430000 140 W 13.0 A 12 Vdc 85-132Vac / 187-264Vac 110x54x110 1105440000 90 W 3.75 A 24 Vdc 85-132Vac / 187-264Vac 110x35x110 1105790000 180 W 7.5 A 24 Vdc 85-132Vac / 187-264Vac 110x54x110 1105810000 360 W 15 A 24 Vdc 85-132Vac / 187-264Vac 125x80x125 1105820000 600 W 25 A 24 Vdc 85-132Vac / 187-264Vac 125x165x125 1105840000 180 W 4 A 48 Vdc 85-132Vac / 187-264Vac 110x54x110 1105850000 360 W 7.5 A 48 Vdc 85-132Vac / 187-264Vac 125x80x125 1105860000 600 W 12.5 A 48 Vdc 85-132Vac / 187-264Vac 125x165x125 1105870000

Single-Phase

Power Supplies

PRO-H Diode Modules

DOUBLE YOUR POWER / REDUNDANCY

With a redundancy module and two PRO-H power supplies (of same type) you can configure a highly reliable, truly redundant power system without any additional components. This module enforces the equivalent sharing of the output current by each power supply. The system is fully redundant and provides output power even if one power supply has completely failed e.g by short circuit on the output. In the event that either power supply fails or is disconnected, the second unit will automatically supply the full current to the load. The redundancy of the system is monitored and if lost, indicated by an alarm output. The inputs are hot swappable and can be loaded up to 15 A each.

Type Output _Current Output _Voltage Input _Voltage Input_Current Dimensions _(LxWxHmm) Order _Number

CP T RM 10 15A @ 24Vdc

@ 40°C 24 Vdc 2 x 24Vdc 15 A 110x35x110 1105880000

CP T RM 20 15A @ 24Vdc

INSTA

POWER

1 Phase 24W

Devices such as relays, contactors, solenoids and motors all require an initial starting current many times their normal level. The compact INSTAPOWER range has the capacity to supply the initial inrush current to start inductive loads and can actually provide 3 times their rated output for a short duration.

ƒ Thermal overload protection & automatic restart

ƒ High Efficiency & universal inputs

ƒ Compact design only 52mm wide

ƒ Mounts on standard TS35 DIN rail

ƒ Suitable for use as a DC/DC converter

ƒ Local and International Approvals: C Tick, CE, UL, CSA

Max. Output

Power Output Current Output Voltage Input Voltage Dimensions (LxWxHmm) Order Number List Price

24 W 2 A 5 Vdc 85-265Vac/120-300Vdc 62.5x52x90.5 9928890005 $148.79

24 W 1.5 A 12 Vdc 85-265Vac/120-300Vdc 62.5x52x90.5 9928890012 $143.88

24 W 1.5 A 15 Vdc 85-265Vac/120-300Vdc 62.5x52x90.5 9928890015 $143.88

24 W 1 A 24 Vdc 85-265Vac/120-300Vdc 62.5x52x90.5 9928890024 $135.16

24 W 1 A 28 Vdc 85-265Vac/120-300Vdc 62.5x52x90.5 9928890028 $135.16

WAVE

POWER

1 Phase 12W

Compact design and powerful functionality make the WAVEPOWER a very valuable solution to spacing problems in many applications.

ƒ Slimline only 22.5mm in wide with plug/socket terminals

ƒ Thermal overload protection & automatic restart

ƒ Mounts on standard TS35 DIN rail

ƒ Local and International Approvals: C Tick, CE, UL, CSA

Max. Output

Power Output Current Output Voltage Input Voltage Dimensions (LxWxHmm) Order Number List Price

12 W 0.5 A 24 Vdc 85-265Vac/120-300Vdc 92.4x22.5x112.4 9918840024 $300.84

INSTA

POWER

1 Phase 25-48W

The new INSTApower single phase 25-48W power supplies provide the answer to a wide range of power supply needs. Just four different modules provide for all output voltages from 4 to 55VDC. An easily accessible trimpot is provided via an access port to enable wide adjustment to meet your requirements. Fully protected against overload INSTApower 48W provides up to 50% over current drive to start your load.

ƒ Wide range of adjustment & universal AC/DC inputs

ƒ Suitable for use as a DC/DC Converter

ƒ Ultra-compact only 70mm wide

ƒ Mounts on standard TS35 DIN rail

ƒ Local and International Approvals: CTick, CE, UL, CSA

Max. Output

Power Output Current Output Voltage Input Voltage Dimensions (LxWxHmm) Order Number List Price

25 W 5 A 4-8 Vdc 85-264Vac/110-370Vdc 62.5x70.0x90.5 8754960000 $103.55

48 W 4 A 9-15 Vdc 85-264Vac/110-370Vdc 62.5x70.0x90.5 8754970000 $103.55

48 W 2 A 15-28 Vdc 85-264Vac/110-370Vdc 62.5x70.0x90.5 8739140000 $93.74

48 W 1 A 46-55 Vdc 85-264Vac/110-370Vdc 62.5x70.0x90.5 8879230000 $103.55

ADJUSTABLE OUTPUT VERSATILITY

FOR DRIVING INDUCTIVE LOADS

11

Note: All prices above are list prices and standard customer discounts may apply. All prices exclude GST. Weidmuller standard terms & conditions of sale also apply.

Max. Output

Power (Watts) Output Current

Output

Voltage Input Voltage Dimensions (LxWxHmm) Order No. List Price

25W 1.1 A 24 V 85-264 Vac / 110-370 Vdc 105 x 77 x 35 7760052036 $29.95 75W 6 A 12 V 85-264 Vac / 110-370 Vdc 135 x 100 x 40 7760052043 $46.95 75W 3.2 A 24 V 85-264 Vac / 110-370 Vdc 135 x 100 x 40 7760052044 $49.95 75W 1.6 A 48 V 85-264 Vac / 110-370 Vdc 135 x 100 x 40 7760052045 $46.95 150W 6.5 A 24 V 85-264 Vac / 110-370 Vdc 205 x 100 x 50 7760052051 $69.95 250W 10.5 A 24 V 85-264 Vac / 110-370 Vdc 205 x 100 x 50 7760052054 $99.95 Accessories Bracket 250W 7760052061 $4.95

Easyline Chassis Mount

LONG SERVICE LIFE

With outputs from 25 to 250 Watts in industry standard 12, 24 and 48Vdc versions. Efficiencies of up to 87% the new “EasyLine” from Weidmuller can reduce your power requirements and extend overall service life of your equipment. Interna-tional approvals and universal input voltages, “EasyLine “ can be installed into equipment bound for any market.

ƒ Up to 150% overload protection.

ƒ Stable DC output voltage

ƒ Wide range input AC/DC

ƒ OEM Product

ƒ Long life and high efficiency in a compact chassis mount housing fitted with fingersafe terminations.

ƒ Extended temperature ratings: -20 °C to 70 °C and a low 100mV ripple add value to the already high value package.

ƒ All models feature adjustable output voltage

250 Watt EasyLine with

forced coiling keeps size

to a minimum

EasyLine Chassis Mount Power Supplies in a

range of capacities

Easily accessible

terminals with touch

safe cover
