Digital Media Server (S-DMS) Software
STINOVA‘s Digital Media Server software is an an advanced WEB based content management system for Digital
Signage applications. It can control a variety of different player hardware starting from low cost IPTV Set Top
Boxes up to PC Player or Panel PCs running our Digital Media Player (DMP) software. DMS is available as a server
software license (DMS lite version for smaller installatios), as well as an ASP (Application Service Provider) model.
Core Features:
> WEB based CMS system for browser based access
> Highly scalable system from one to many thousands players
> iFrame Designer for easy screen layout design
> Playlist scheduling for scheduled campaign management
> Permission Manager for restricted system access
> Playlist import/export and system backup and restore function
> Support for various content formats
> Player grouping for easy player management
> Player content play-out reporting and alert reporting
> User and Client Manager for managing multiple customers on one server
> Auto-Player notification for automated easy player installation
DMS Workflow Diagram
Supported Content and Trigger Events:
> Video/Multicast/Video stream event
> Picture/Picture Slide/Picture Flash event
> Flash event
> Browser event (opens any remote web page)
> HTML slide event (local WYSIWYG HTML editor)
> Brows RSS event
> Ticker event (from RSS, text input, text file)
> Tuner event (if tuner hardware is present)
> Volume event for volume control
Digital Media Player Software S-DMP
STINOVA‘s Digital Media Player (DMP) software can be installed on most PC hardware running
Linux OS. Once installed, the PC can be managed and controlled via network by our Digital
Media Server (DMS), a WEB based Content Management System. DMP automatically synchronize
content and play-out scheduled playlists. It supports full screen and multi frame (multi zone)
Digital Media Player (DMP) Hardware
STINOVA‘s Digital Media Player (DMP) hardware starts from IPTV Set Top Players, PC-based hybrid players, up to
All-In-One TFT Panel Players.
The DMP 9432 and DMP 9440 series is a new generation of high-end modern industrial grade 32“, 40“TFT Panel PC Player Displays with aluminium finish frame, running our Digital Media Player software. It is based on Intel platform with standard 1 GB RAM, modern Graphic Chip supporting 90° rotated portrait mode, and CF-Card. designed for professional Digital Signage Applications with latest integrated PC technology supporting LAN or WLAN access for 24/7 operation. DMP is easy to install and easy to operate. Just plug-in the power plug, connect the network, and you are ready to go. Remotely manage the Panel PC with our Digital Media Server Software (DMS) and schedule your information play-out via your HTML Browser. DVB-T live content extension can be achieved by adding a USB DVB-T tuner stick.
DMP 9546 is a new generation of high-end modern „Slim Bezel“ (18 mm thin frame only) industrial grade TFT Panel PC Player Display, running our Digital Media Player software. It is based on Intel platform with standard 1 GB RAM, modern Graphic Chip supporting 90° rotated portrait mode, and CF-Card. Just plug-in the power plug, connect the network, and you are ready to go. Remotely manage the Panel PC with our Digital Media Server Software (DMS) and schedule your information play-out via your HTML Browser. DVB-T live content extension can be achieved by adding a USB DVB-T tuner stick.
DMP 6500 DMP 6600HD DMP 6700/6800 DMP 7900HD DMP 9440/9432 DMP 9546
32“ & 40“
46“
DMP 6500 is a cost effecive solid state Digital Media Player with 2 GB internal Flash Disk for a variety of Digital Signage applications. It is based on a VIA type embedded hardware platform that opens a wide area of applications. DMP 6600HD is a cost effetive, low power consumption solid state IPTV set top box player, supporting best quality full HD video playout for a variety of Digital Signage applications. Content can be stored on a USB Stick or USB HDD.
s-cube TV Streamer and IPTV Encoder
s-cube TV streamer and IPTV encoder provides live content as multicast stream via network from TV sources such
as DVB-T, DVB-C, DVB-S/S2 and analog TV to camera or other analog video sources. The s-cube 1000 series
supports per tuner moduled the streaming of the complete DVB bouquet.
DMX All-in-One Player & Server Appliance
DMX is an All-in-One Player & Server appliance that includes the Digital Media Server Lite software inside the
Digital Media Player hardware. With its Plug & Play capabilities your preferred content plays within minutes.
DMX is ideal for local networks and can control also other Digital Media Player within the same network.
DMX
DMX 7900HD
DMX 6800
s-cube 1100, s-cube 1200, s-cube 1400
s-cube 2000/2500 (h.264 SD Encoder/Decoder) s-cube 3000 (h.264 HD Encoder) (available Q4/2008)
The s-cube 2000/3000 series is a professional broadcast-quality advanced video/audio encoding and streaming 1-RU solution. This sophisticated, high performance encoder convinces with an outstanding picture quality at lower bit-rates and highest reliability for 24/7 usage. The installation of the s-cube is easy and can be configured remotely via a user-friendly web interface. The s-cube 2000 deliveres one SD (the s-cube 3000 one HD) channel of variable bitrate (VBR) or constant bitrate (CBR) MPEG-4 AVC/H.264 video (progressive and interlaced coding) and MPEG-4 audio. It also provides MPEG-4 Advanced Simple Profile (ASP) up to Level 5.
