Product details
Comes with
LTW8K LIGHT TOWER, COLD WEATHER, Tier 4F
5200004095
LTW8K LIGHT TOWER, COLD WEATHER, Tier 4F
Material number 5200004095
8 kW wide body light tower, factory installed cold weather package, Kubota engine
Wide wheel base, 30-foot adjustable light tower rotates 360 degrees, offers quiet operation and comes with large fuel tank for continuous run time
•
Ideal for powering remote or long run applications as well as general job sites
•
Elliptical light fixture for diffused and uniform job site illumination
•
Four-point jack stand allows for easy leveling and stability in any job site
•
Mast-mounted base winch eliminates bending for easy operation
•
Service doors are lockable, impact resistant, rust and dent proof heavy-gauge steel doors that provide protection from ground debris
•
Highway-ready trailer comes fully equipped with 2-inch ball hitch, 15-inch tires, four tie downs DOT lighting, VIN number and chains
•
Technical specifications
LTW8K LIGHT TOWER, COLD WEATHER, Tier 4F
MECHANICAL DETAILSENVIRONMENT DATA
LIGHTING - OUTPUT DETAILS
ELECTRICAL SYSTEM
ELECTRICAL - OUTPUT DETAILS
Length 4.490 mm
Gross Axle Weight Rating 1.588 kg
Width 1.920 mm
Height 1.900 mm
Operating weight 1.352,0 kg
gross vehicular weight 1.585,0 kg
Sound level LpA 67,3 dB(A)
NEMA Beam Spread Type 6
Coverage area 1.204 m2
Illuminance 0 Lux
RESERVE 33 A
Main Circuit Breaker Rating 33 A
Charging Time MH 1100W/BT37/4200K/E39
Lighting appliances MH 1100W/BT37/4200K/E39
Luminous flux 1.100 W
Bulb power 1.100 W
Nominal current 33,00 A
Nominal voltage 120 V
Nominal frequency 60 Hz
Nominal power [P] 8,00 KW
Power factor (cos ) 1,00 cos
Phase 1 ~
ENGINE
SHIPPING AND STORAGE
GENERATOR
Engine type Diesel engine
Engine operating mode four-stroke
Cylinder capacity 1.123 cm3
Fuel Diesel EN 590
Cylinder 3
Tank capacity 215,80 l
Oil filling max. 5,10 l
Power rating max. 11,5 KW
Nominal Engine speed 1.800 1/min
Engine speed (Power max.) 1.800 1/min
Effective power 10,1 KW
Standard (Operating power) ISO 3046 IFN
Operating Engine speed 1.800 1/min
Exhaust-gas limit IIIB/Tier IV Final
Starter battery Voltage 12 V
Battery Cold-start current CCA 750 A
Engine Manufacturer Kubota
Height for shipping 2.570 mm
Width for shipping 1.920 mm
Length for shipping 3.330 mm
Shipping weight 1.166,00 kg
Output frequency 60 Hz
Insulation class H
Nominal speed 1.800 1/min
Voltage accuracy 1,0 %
Regulation [U] - Steady State 1,0 %
Generator Manufacturer Mecc Alte
OPERATING FLUIDS
OPERATING FLUIDS
ELECTRICAL - OUTPUT DETAILS
GENERATOR
ENGINE
Cooling fluid volume 10,00 l
Tank capacity 215,80 l
Fuel consumption (Prime load) 2,9 L/hr
Run Time (Prime Load) 69,8 hrs
Tank capacity 57,0 gal US
Cooling fluid volume 10,6 qt US
Run Time (Prime Load) 69,8 hrs
Fuel consumption (Prime load) 0,8 GPH US
Nominal power [P] 8,00 KW
Phase 1 ~
Nominal current 33,00 A
Nominal voltage 120 V
Power factor (cos ) 1,00 cos
Nominal frequency 60 Hz
Insulation class H
Nominal speed 1.800 1/min
Output frequency 60 Hz
Voltage accuracy 1,0 %
Regulation [U] - Steady State 1,0 %
Generator Manufacturer Mecc Alte
Engine operating mode four-stroke
Engine type Diesel engine
Fuel Diesel EN 590
Cylinder 3
ENVIRONMENT DATA
SHIPPING AND STORAGE
LIGHTING - OUTPUT DETAILS
MECHANICAL DETAILS
Cylinder capacity 68,5 Inch3
Oil filling max. 1,3 gal US
Power rating max. 15,4 hp
Engine speed (Power max.) 1.800 1/min
Nominal Engine speed 1.800 1/min
Effective power 13,5 hp
Operating Engine speed 1.800 1/min
Standard (Operating power) ISO 3046 IFN
Starter battery Voltage 12 V
Exhaust-gas limit IIIB/Tier IV Final
Engine Manufacturer Kubota
Battery Cold-start current CCA 750 A
Tank capacity 57,0 gal US
Sound level LpA 67,3 dB(A)
Shipping weight 2.570,6 lb
Width for shipping 75,6 "
Height for shipping 101,2 "
Length for shipping 131,1 "
Illuminance 0,0 fc
NEMA Beam Spread Type 6
Coverage area 12.959,9 ft2
Length 176,8 "
Gross Axle Weight Rating 3.500,9 lb
Width 75,6 "
Height 74,8 "
ELECTRICAL SYSTEM
Operating weight 2.980,7 lb
gross vehicular weight 3.494,3 lb
Main Circuit Breaker Rating 33 A
RESERVE 33 A
Luminous flux 1.100 W
Lighting appliances MH 1100W/BT37/4200K/E39
Charging Time MH 1100W/BT37/4200K/E39
Bulb power 1.100 W
Please Note
This product availability can vary from country to country. It is possible that information / products may not be available in your country. More detailed information on engine power can be found in the operator's manual; the started power may vary due to specific operating conditions Subject to alterations and errors expected. Applicable also to illustrations.
