A Bold, New Look at Tool Storage
2009/10 Supplemental Catalog
TABLE OF CONTENTS
MAGNUM® SERIES ... 2-3 TRAXX® SERIES ... 4-5
TR SERIES ...6
TRAXX® POWER SERIES ... 7
PROMAXX™ SERIES ...8
GRAPHIC PROGRAM ...9
UTILITY CARTS... 10
BASIC STORAGE ... 11 PRODUCT INFO ...12-15
1
If any product is found to be defective in material or workmanship during normal use within the applicable warranty period, your exclusive remedy is replacement of the defective product of parts. This warranty does not cover products that are damaged through any misuse, abuse, accident, neglect, modification or mis- handling. Waterloo Industries, Inc. will not be responsible for any losses, injuries or costs of any nature, including indirect, incidental or consequential damages relating to this product, including transportation charges. Except as provided by law, this warranty is in lieu of and excludes all other warranties, conditions and guarantees, whether, expressed or implied, statutory or otherwise, including without restriction those of merchantability or fitness for a particular purpose.
Some states, provinces and nations do no allow the exclusion or limitations of incidental or consequential damages, so the above limitations or exclusions may not apply to you. This warranty gives you specific legal rights and you may have other rights which vary from state to state, province to province, nation to nation.
Waterloo Industries, Inc. will advise you of the procedure to follow in making warranty claims.
(Warranties do not cover units that are mounted or used in moving vehicles.)
WATERLOO®
LIMITED WARRANTY
Waterloo® products have been manufactured to the highest standards of quality and workmanship. Waterloo Industries, Inc. warrants its Waterloo®
brand products to be free from defects in materials and workmanship under normal use for the following periods from original date of purchase:
Magnum®
Tool Storage and Facility
Storage
Traxx® and
TR-Series ProMaxx™, Pro Series, Tool Room Series, Specialty Products,
Workbenches
Shop Series,
Portables,
and all other
products for
home use
Premium embossed drawer liners for non-slip
tool protection
Masterlock® One-Key™
locking system allows the user to quickly
key cabinet and accessories alike
Internal power strip with canopy Double ball bearing slides
on full width and deep drawers
Chrome plated ergonomic grip handle Quality features that you’ve come to expect...
• Posi-Latch System™ ensures a secure drawer latch, reducing accidental opening
• Industrial quality gas struts for safe and smooth opening and closing of canopy lid
• Super heavy-duty 6” x 2” casters and 14 gauge support channels for maximum support and easy maneuvering
• Full length canopy lid stiffener with embossed Waterloo logo provides extra rigidity
Vinyl coated MDF or optional SS work
surface
MAGNUM ®
Your workplace is one tough environment, so we built our Magnum® series tool boxes to be as equally tough and durable. No room for compromise because you demand a toolbox that will handle whatever you dish out.
Constructed with roll-cage framework and extra heavy-duty ball bearing slides that support 200 lbs for each drawer, this beast has a mammoth 3,600 lb total holding capacity. It’s no wonder the Magnum®
provides a lifetime warranty.
3
MAGNUM ®
The Magnum® line of tool storage provides maximum strength, security and organization demanded by professionals.
75” 13 Drawer Tool Cabinet MG7513RD Red MG7513BK Black MG7513BU Blue 56” 12 Drawer Tool Cabinet MG5612-24RD Red MG5612-24BK Black MG5612-24BU Blue
MG5612-24BU shown with Side Cabinet Accessory MG2406SCBU and Canopy MG56CNYBU
MG2406SCRD 24” Side Cabinet
MG2403SLRD
24” Full Height Side Locker
75” and 56” Canopies MG75CNYRD Red MG75CNYBK Black MG75CNYBU Blue MG56CNYRD Red MG56CNYBK Black MG56CNYBU Blue
30” and 24” deep 3 drawer full height side lockers
MG3003SLRD Red MG3003SLBK Black MG3003SLBU Blue MG2403SLRD Red MG2403SLBK Black MG2403SLBU Blue
30” and 24” deep 6 drawer side cabinet MG3006SCRD Red
MG3006SCBK Black MG3006SCBU Blue MG2406SCRD Red MG2406SCBK Black MG2406SCBU Blue
MG3003SLBK
30” Full Height Side Locker
MAGNUM ®
ACCESSORIES
Expand your tool storage capacity
and organization with these
convenient options:
TRAXX ®
Built to handle the toughest work environments, the Traxx® series has all the features you want and the durability you need. Constructed with a brute 1,200 lb load capacity, sturdy sidewall post construction and ball bearing drawer slides that support 100 lbs.
Quality features that you’ve come to expect...
• Posi-Latch System™ provides a secure latch for each drawer
• Internal keyed locking system secures all drawers
• Positive-stop side handles on all Traxx®
chests for easy lifting
• Full-length lid stiffener provides extra rigidity
• 6” x 2” Swivel and locking casters for easy maneuvering and added load support
4
Smooth operating gas struts
Polished chrome ergonomic handle
Heavy-duty, smooth rolling casters TRX5208BU/TRX5211BU
Embossed drawer liners for non-slip tool protection
Double drawer slides on full width and deep drawers
Thick rubber mat
for added protection
TRAXX® 52” and 41” Series
When a product performs like the TRAXX® series, you run with it.
And that’s just what we’ve done, with the new 8 drawer chests and 11 drawer tool cabinets.
41” 8 Drawer Chest
TRX4208 Red
TRX4208BK Black TRX4208BU Blue 41” 11 Drawer Tool Cabinet
TRX4211 Red
TRX4211BK Black TRX4211BU Blue
5
TRX5208/TRX5211
TRX4208BK/TRX4211BK
52” 8 Drawer Chest
TRX5208 Red
TRX5208BK Black TRX5208BU Blue 52” 11 Drawer Tool Cabinet
TRX5211 Red
TRX5211BK Black
TRX5211BU Blue
Quality features that you’ve come to expect
• Sidewall post construction for handling heavy loads
• Full extension ball bearing slides
• Internal keyed locking system secures all drawers
• 5” x 2” Swivel and locking casters for easy maneuvering
6
41” 7 Drawer Chest
TR4107 Red
TR4107BK Black TR4107BU Blue 41” 10 Drawer Tool Cabinet
TR4110 Red
TR4110BK Black TR4110BU Blue
TRAXX ®
TR Series
Like its big brother Traxx®, the TR series delivers quality, dependability and durability every day. This series offers heavy-duty features like sidewall post construction, full extension ball bearing drawer slides and 75 lb drawer capacity, all at an affordable price.
Smooth operating gas struts
Polished chrome ergonomic handle
Double drawer slides on deep drawers
TR4107/TR4110
Optional Side Shelf
SSR-2 Red
TR41801BK Black TR41801BU Blue Optional Side Chest
70747 Red
TR41802BK Black
TR41802BU Blue
TRAXX ® POWER
7
26” 5 Drawer Fully Powered Chest PXT5165BK Black 26” 5 Drawer
Fully Powered Cabinet PXB5186BK Black
26” 5 Drawer
Partially Powered Chest PXT4165BK Black 26” 5 Drawer
Partially Powered Cabinet PXB4185BK Black
Task lighting
PXT5165/PXB5186BK
PXT5165BK
PXT4165/PXB4185BK PXB5186BK
PXT4165BK
Quality features that you’ve come to expect
• Multi-functional message center
• 12v power outlet to support cell phone, MP3 players, etc
• 6 outlet power strips
• Heavy duty ball bearing drawer slides support up to 75 lbs per drawer
• Stylized swivel and locking casters offer a 1,200 lb load capacity
• Masterlock® One Key™ locking system allows you to key your chest and cabinet alike
• 12v power outlet to support cell phone, MP3 players, etc
• 6 outlet power strip
• Heavy duty ball bearing drawer slides support up to 75 lbs per drawer
• Stylized swivel and locking casters offer a 1,200 lb load capacity
With its sleek design, stacked I-frame construction, black/titanium finish and power strips, these tool boxes are loaded with features you need for maximum organization, appearance and function.
PXB4185BK
41” 7 Drawer Chest
PMX4107 Red
PMX4107BK Black PMX4107BU Blue 41” 11 Drawer Tool Cabinet
PMX4111 Red
PMX4111BK Black PMX4111BU Blue
PROMAXX ™
Expect more. No matter what features you’re looking for in a quality tool box at a value, you’ll find them all in our Promaxx™ Series.
Tri-channel construction and ball bearing slides with load rating
up to 50 lbs make this product ideal for DIY and professional applications.
8
Quality features that you’ve come to expect
• Keyed locks with internal lock bars to secure tools
• Chrome plated chest handles with comfort grip
• 5” x 2” Swivel and locking casters for easy maneuvering
Gas struts for easy and smooth lid operation
Chrome plated ergonomic
handle
Vinyl top mat
PMX4107/PMX4111
26” 8 Drawer Chest/Cabinet Leader of the Pack
PMX2808WLF Black 26” 8 Drawer Chest/Cabinet RealTree® AG HD®
PMX2808CAM Black 26” 8 Drawer Chest/Cabinet Blue Lightning
PMX2808LGT Black
GRAPHIC PROGRAM
Bring your tool storage to life!
Newly introduced are three different themed chest and cabinet combos with the same storage and security benefits of the original Promaxx™ Series. Durable, high quality printed decals give your toolbox a distinctive look.
9
Racing enthusiasts and mechanics will appreciate the bold, colorful lightning graphics that adorn this useful tool storage cabinet.
PMX2808CAM features REALTREE® APG HD®
camouflage pattern vinyl decals. It’s the perfect
complement to the hunting lifestyle.
“Leader of the Pack” graphics will appeal to the inner beast of the racing enthusiast, car mechanic, or the tool warrior in all of us.
PMX2808LGT PMX2808WLF
PMX2808CAM
1 0
Utility Carts
By their very name, you’ll soon realize how helpful and useful these portables have become.
Available in stainless steel, powder coated metal or durable molded plastic, these shop or home companions make any job easier. Perfect for on-site projects that require a work surface, tool storage and easy mobility.
UC110RD 1 Drawer Metal Utility Cart Red UC110BK 1 Drawer Metal Utility Cart Black UC110BU 1 Drawer Metal Utility Cart Blue UC310RD 3 Drawer Metal Utility Cart Red UC310BK 3 Drawer Metal Utility Cart Black UC310BU 3 Drawer Metal Utility Cart Blue UC310SS 3 Drawer Metal Utility Cart
Stainless Steel
UC410RD 4 Drawer Metal Utility Cart Red UC410BK 4 Drawer Metal Utility Cart Black UC410BU 4 Drawer Metal Utility Cart Blue UC342G Small 2 Tier Plastic Utility Cart Grey UC412G Large 2 Tier Plastic Utility Cart Grey
The four drawer 410 Series and three drawer 310 Series have quality added features...
• Gas struts for smooth lid operation
• Posi-Latch™ secures each drawer
• Chrome plated handle
• Bumper guards for added protection
• Cover stiffener provides extra rigidity
• Swivel/locking casters
Posi-Latch™
drawer securing system bearing Ball drawer slides
Smooth operating gas struts
Ball bearing drawer slides
UC410BU
UC310SS Our durable molded utility carts
offer the best of both worlds...
practicality and economy
UC412G
Our feature-rich, three drawer
310 Series
Basic Storage
Capacity, durability, versatility... that’s what you get with the variety of units available for your storage needs.
From fully assembled workbenches, floor and wall cabinets to carts, all with a high gloss blue finish, we have what you need to get organized.
FBMC3003 30” Mobile Cabinet Blue FBWC3012 Wall Cabinet Blue FBTCD3622 Floor Cabinet Blue FBWB6023 5’ Facility Workbench Blue FBBW600 5’ Bench Backwall Blue
11
• Durable painted finish resists rust and corrosion
• 7/8” sealed MDF work surface
• 1500 lb load capacity
• Adjustable leveling feet
• Durable painted finish resists rust and corrosion
• 1 Adjustable shelf with a 50 lb load capacity
• Reinforced door construction with 25 lb capacity adjustable storage area
FBWB6023
FBMC3003 FBTCD3622 FBWC3012
• Durable painted finish resists rust and corrosion
• 7/8” sealed MDF work surface
• 3 Drawers - 1–12” deep; 2–6” deep
• 50 lb capacity ball-bearing drawer slides
• Smooth rolling 4-1/2” casters FBBW600 • Durable painted finish resists
rust and corrosion
• Includes power strip and overhead light
• Durable painted finish resists rust and corrosion
• 3 Adjustable shelves each with 100 lb load capacity
• Reinforced door construction
Item # Description Unit Weight
(lbs)
Width Unit (in)
Depth Unit (in)
Height (in) Unit Including
Casters
Bank Drawer
Width (in)
Drawer Depth (in)
Drawer Height (in)
MG7513RD 75” Industrial Series 13 Drawer Cart Red 1110 75.00 30.00 43.00 Right 1 Drawer 53.00 27.50 4.00
MG7513BK 75” Industrial Series 13 Drawer Cart Black 1110 75.00 30.00 43.00 1 Drawer 53.00 27.50 2.00
MG7513BU 75” Industrial Series 13 Drawer Cart Blue 1110 75.00 30.00 43.00 3 Drawers 53.00 27.50 3.00
2 Drawers 53.00 27.50 6.00
Left 1 Drawer 16.00 27.50 4.00
1 Drawer 16.00 27.50 2.00
3 Drawers 16.00 27.50 3.00
1 Drawer 16.00 27.50 12.00
MG75CNYRD 75” Industrial Series Canopy Red 250 75.00 30.00 24.50
MG75CNYBK 75” Industrial Series Canopy Black 250 75.00 30.00 24.50
MG75CNYBU 75” Industrial Series Canopy Blue 250 75.00 30.00 24.50
MG5612-24RD 56” Industrial Series 12 Drawer Cabinet Red 600 56.00 24.00 43.00 Center 1 Drawer 53.00 21.50 4.00
MG5612-24BK 56” Industrial Series 12 Drawer Cabinet Black 600 56.00 24.00 43.00 Right 1 Drawer 32.00 21.50 2.00
MG5612-24BU 56” Industrial Series 12 Drawer Cabinet Blue 600 56.00 24.00 43.00 4 Drawers 32.00 21.50 3.00
1 Drawer 32.00 21.50 9.00
Left 1 Drawer 14.00 21.50 2.00
3 Drawers 14.00 21.50 3.00
1 Drawer 14.00 21.50 12.00
MG56CNYRD 56” Industrial Series Canopy Red 150 56.00 24.00 24.50
MG56CNYBK 56” Industrial Series Canopy Black 150 56.00 24.00 24.50
MG56CNYBU 56” Industrial Series Canopy Blue 150 56.00 24.00 24.50
MG3003SLRD 30” Deep 3 Drawer Full Height Side Locker Red 350 18.00 30.00 60.00 Center 3 Drawers 16.00 27.50 2.50
MG3003SLBK 30” Deep 3 Drawer Full Height Side Locker Black 350 18.00 30.00 60.00 MG3003SLBU 30” Deep 3 Drawer Full Height Side Locker Blue 350 18.00 30.00 60.00
MG3006SCRD 30” Deep 6 Drawer Side Cabinet Red 325 19.00 30.00 43.00 Center 1 Drawer 16.00 27.50 4.00
MG3006SCBK 30” Deep 6 Drawer Side Cabinet Black 325 19.00 30.00 43.00 1 Drawer 16.00 27.50 2.00
MG3006SCBU 30” Deep 6 Drawer Side Cabinet Blue 325 19.00 30.00 43.00 3 Drawers 16.00 27.50 3.00
1 Drawer 16.00 27.50 12.00
MG2403SLRD 24” Deep 3 Drawer Full Height Side Locker Red 225 19.00 24.00 60.00 Center 3 Drawers 16.00 21.50 2.50
MG2403SLBK 24” Deep 3 Drawer Full Height Side Locker Black 225 19.00 24.00 60.00 MG2403SLBU 24” Deep 3 Drawer Full Height Side Locker Blue 225 19.00 24.00 60.00
MG2406SCRD 24” Deep 6 Drawer Side Cabinet Red 215 19.00 24.00 43.00 Center 1 Drawer 16.00 21.50 4.00
MG2406SCBK 24” Deep 6 Drawer Side Cabinet Black 215 19.00 24.00 43.00 1 Drawer 16.00 21.50 2.00
MG2406SCBU 24” Deep 6 Drawer Side Cabinet Blue 215 19.00 24.00 43.00 3 Drawers 16.00 21.50 3.00
1 Drawer 16.00 21.50 12.00
MAGNUM® SERIES
Item # Description Unit Weight
(lbs)
Width Unit (in)
Depth Unit (in)
Height (in) Unit Including Casters
Bank Drawer
Width (in)
Drawer Depth (in)
Drawer Height (in)
TRX4208 41" 8-Drawer BB Chest Red 154 40.50 17.75 18.75 Left 1 Drawer 22.25 16.25 1.25
TRX4208BK 41" 8-Drawer BB Chest Black 154 40.50 17.75 18.75 1 Drawer 22.25 16.25 2.38
TRX4208BU 41" 8-Drawer BB Chest Blue 154 40.50 17.75 18.75 2 Drawers 22.25 16.25 3.50
Right 1 Drawer 11.50 16.25 1.25
1 Drawer 11.50 16.25 2.38
2 Drawers 11.50 16.25 3.50
Top Till 40.25 16.75 2.75
TRX4211 41" 11-Drawer BB Cabinet Red 252 41.00 18.10 41.10 Center 1 Drawer 36.50 16.25 3.50
TRX4211BK 41" 11-Drawer BB Cabinet Black 252 41.00 18.10 41.10 Left 1 Drawer 22.25 16.25 1.25
TRX4211BU 41" 11-Drawer BB Cabinet Blue 252 41.00 18.10 41.10 1 Drawer 22.25 16.25 2.38
3 Drawers 22.25 16.25 5.38
Right 1 Drawer 22.25 16.25 1.25
3 Drawers 22.25 16.25 2.38
1 Drawer 22.25 16.25 12.25
TRX5208 52" 8-Drawer BB Chest Red 160 51.10 17.80 19.80 Left 1 Drawer 22.25 15.75 1.25
TRX5208BK 52" 8-Drawer BB Chest Black 160 51.10 17.80 19.80 1 Drawer 22.25 15.75 2.38
TRX5208BU 52" 8-Drawer BB Chest Blue 160 51.10 17.80 19.80 2 Drawers 22.25 15.75 3.50
Right 1 Drawer 22.25 15.75 1.25
1 Drawer 22.25 15.75 2.38
2 Drawers 22.25 15.75 3.50
Top Till 51.00 17.25 2.75
TRX5211 52" 11-Drawer BB Cabinet Red 370 51.60 20.00 42.50 Center 1 Drawer 47.25 16.25 3.25
TRX5211BK 52" 11-Drawer BB Cabinet Black 370 51.60 20.00 42.50 Left 1 Drawer 22.25 16.25 1.25
TRX5211BU 52" 11-Drawer BB Cabinet Blue 370 51.60 20.00 42.50 1 Drawer 22.25 16.25 2.38
3 Drawers 22.25 16.25 5.63
Right 1 Drawer 22.25 16.25 1.25
1 Drawer 22.25 16.25 2.38
3 Drawers 22.25 16.25 5.63
13
Item # Description Unit
Weight (lbs)
Width Unit (in)
Depth Unit (in)
Height (in) Unit Including Casters
Bank Drawer
Width (in)
Drawer Depth (in)
Drawer Height (in)
TR4107 41" 7-Drawer BB Chest Red 166 40.50 18.00 19.75 Left 1 Drawer 22.25 14.25 1.25
TR4107BK 41" 7-Drawer BB Chest Black 166 40.50 18.00 19.75 1 Drawer 22.25 14.50 2.38
TR4107BU 41" 7-Drawer BB Chest Blue 166 40.50 18.00 19.75 2 Drawers 22.25 14.50 3.50
Right 1 Drawer 11.50 14.50 4.50
2 Drawers 11.50 14.50 3.50
Top Till 40.25 15.00 2.75
TR4110 41" 10-Drawer BB Cabinet Red 245 40.95 18.06 41.13 Center 1 Drawer 36.50 16.25 3.50
TR4110BK 41" 10-Drawer BB Cabinet Black 245 40.95 18.06 41.13 Left 1 Drawer 22.25 16.25 2.38
TR4110BU 41" 10-Drawer BB Cabinet Blue 245 40.95 18.06 41.13 2 Drawers 22.25 16.25 3.50
2 Drawers 22.25 16.25 5.38
Right 1 Drawer 11.50 16.25 1.26
2 Drawers 11.50 16.25 2.38
1 Drawer 11.50 16.25 12.25
1 Drawer 22.25 16.25 12.25
TRAXX® SERIES
TR SERIES
Item # Description Unit Weight
(lbs)
Width Unit (in)
Depth Unit (in)
Height (in) Unit Including Casters
Bank Drawer
Width (in)
Drawer Depth (in)
Drawer Height (in)
PXT5165BK 26" 5 Drawer Fully Powered Chest 115 27.00 19.00 24.00 Center 2 Drawers 22.37 14.68 2.00
2 Drawers 22.37 14.68 3.00
1 Drawer 22.37 14.68 4.00
PXB5186BK 26" 6 Drawer Fully Powered Cabinet 152 27.00 21.00 42.00 Center 2 Drawers 22.37 16.46 3.00
2 Drawers 22.37 16.46 4.00
2 Drawers 22.37 16.46 6.00
PXT4165BK 26" 5 Drawer Partially Powered Chest 92 27.00 19.00 21.00 Center 2 Drawers 22.37 14.68 2.00
3 Drawers 22.37 14.68 3.00
PXB4185BK 26" 5 Drawer Partially Powered Cabinet 145 27.00 21.00 42.00 Center 2 Drawers 22.37 16.46 4.00
3 Drawers 22.37 16.46 6.00
1 Drawer 22.37 16.46 3.08
TRAXX® POWER SERIES
Item # Description Unit
Weight (lbs)
Width Unit (in)
Depth Unit (in)
Height (in) Unit Including Casters
Bank Drawer
Width (in)
Drawer Depth
(in)
Drawer Height (in)
PMX4107 41" 7-Drawer BB Chest Red 143 40.50 16.00 19.80 Left 1 Drawer 22.25 14.25 1.25
PMX4107BK 41" 7-Drawer BB Chest Black 143 40.50 16.00 19.80 1 Drawer 22.25 14.50 2.38
PMX4107BU 41" 7-Drawer BB Chest Blue 143 40.50 16.00 19.80 2 Drawers 22.25 14.50 3.50
Right 1 Drawer 11.50 14.50 4.50
2 Drawers 11.50 14.50 3.50
Top Till 40.25 15.00 2.75
PMX4111 41" 11-Drawer BB Tool Cabinet Red 220 41.00 19.10 37.50 Center 1 Drawer 36.50 16.25 3.50
PMX4111BK 41" 11-Drawer BB Tool Cabinet Black 220 41.00 19.10 37.50 Left 1 Drawer 22.25 16.25 1.25
PMX4111BU 41" 11-Drawer BB Tool Cabinet Blue 220 41.00 19.10 37.50 4 Drawers 22.25 16.25 2.38
1 Drawer 22.25 16.25 5.38
Right 1 Drawer 11.50 16.25 1.26
2 Drawers 11.50 16.25 2.38
1 Drawer 11.50 16.25 12.25
PROMAXX® SERIES
Item # Description Unit Weight (lbs) Unit Width (in) Unit Depth (in) Unit height (in)
SSR-2 Side Shelf Red 10 17.10 17.75 2.31
TR41801BK Side Shelf Black 10 17.10 17.75 2.31
TR41801BU Side Shelf Blue 10 17.10 17.75 2.31
70747 Side Chest Red 33 32.56 20.56 14.25
TR41802BK Side Chest Black 33 32.56 20.56 14.25
TR41802BU Side Chest Blue 33 32.56 20.56 14.25
TR SERIES ACCESSORIES
15
Item # Description Unit
Weight (lbs)
Width Unit (in)
Depth Unit (in)
Height (in) Unit Including
Casters
Bank Drawer
Width (in)
Drawer Depth
(in)
Drawer Height (in)
PMX2808CAM 26" 8 drawer black chest and cabinet combo with
Realtree Camo graphics 160 26.50 18.10 47.50 Top Chest Center 3 Drawers 22.37 10.78 2.00
PMX2808LGT 26" 8 drawer black chest and cabinet combo with
Lightning graphics 160 26.50 18.10 47.50 1 Drawer 22.37 10.78 3.08
PMX2808WLF 26" 8 drawer black chest and cabinet combo with
Wolf graphics 160 26.50 18.10 47.50 Bottom
Cabinet Center 1 Drawer 22.37 16.46 2.00
1 Drawer 22.37 16.46 3.08
1 Drawer 22.37 16.46 6.32
1 Drawer 22.37 16.46 9.56
GRAPHIC SERIES
Item # Description Unit
Weight (lbs)
Width Unit (in)
Depth Unit (in)
Height (in) Unit Including
Casters
Bank Drawer
Width (in)
Drawer Depth (in)
Drawer Height (in)
UC342G Small 2 Tier Plastic Utility Cart Grey 38 34.50 17.50 33.75 Top Area 30.00 16.00 2.50
Bottom Area 29.25 15.25 2.75
UC412G Large 2 Tier Plastic Utility Cart Grey 48 40.50 25.75 33.50 Top Area 36.00 24.00 2.75
Bottom Area 35.00 23.00 2.75
UC110RD 1 Drawer Metal Utility Cart Red 80 30.00 16.25 35.50 Top Till 29.75 16.00 3.00
UC110BK 1 Drawer Metal Utility Cart Black 80 30.00 16.25 35.50 Top Surface 27.50 16.75 N/A
UC110BU 1 Drawer Metal Utility Cart Blue 80 30.00 16.25 35.50 Drawer 1 26.50 14.50 3.50
UC310RD 3 Drawer Metal Utility Cart Red 110 34.00 20.75 36.75 Center Top Till 27.00 17.75 5.00
UC310BK 3 Drawer Metal Utility Cart Black 110 34.00 20.75 36.75 Top Surface 30.50 20.75 N/A
UC310BU 3 Drawer Metal Utility Cart Blue 110 34.00 20.75 36.75 Drawers 1 & 2 12.00 17.25 3.00
UC310SS 3 Drawer Metal Utility Cart Stainless Steel 110 34.00 20.75 36.75 Drawer 3 25.50 17.25 3.00
Bottom Storage 30.00 18.75 3.00
UC410RD 4 Drawer Metal Utility Cart Red 175 38.75 21.50 44.00 Center Top Till 29.50 18.75 6.50
UC410BK 4 Drawer Metal Utility Cart Black 175 38.75 21.50 44.00 Top Surface 34.38 21.13
UC410BU 4 Drawer Metal Utility Cart Blue 175 38.75 21.50 44.00 Drawers 1 & 2 13.25 18.25 3.00
Drawer 3 28.38 18.25 3.00
Drawer 4 28.38 18.25 5.00
Bottom Storage 33.20 20.25 4.00
UTILITY CARTS
Item # Description Unit Weight (lbs) Unit Width (in) Unit Depth (in) Unit height (incl casters) (in)
FBMC3003 30” Mobile Cabinet 122 29.44 21.50 29.11
FBWC3012 Wall Cabinet 60 29.44 12.00 28.92
FBTCD3622 Tall Cabinet 157 36.00 21.50 70.15
FBWB6023 5’ Facility Workbench 130 60.00 23.00 40.10
FBBW600 5’ Bench Backwall 36 58.80 9.00 25.50
BASIC STORAGE
For more information about Waterloo Industries and our products, please visit us on the web at:
www.waterlooindustries.com www.leanstorage.com
www.waterlooimages.com
Waterloo Industries Contact Information Sales
Waterloo Industries
139 West Forest Hill Avenue Oak Creek, WI 53154
Phone 414-571-5625
Canadian Sales Office
Master Lock Oakville 2816 Bristol Circle
Oakville, Ontario L6H 5S7 Phone 800-227-9599 Fax 905-829-8952
Customer Relations
Waterloo Industries
139 West Forest Hill Avenue Oak Creek, WI 53154
Phone 800-833-8851 Fax 414-766-6388
Warranty Questions and Claims
Phone 800-833-8851 Fax 414-766-6388
Service Parts
Phone 800-833-4405
Fax 414-766-6585
Email: [email protected]
Waterloo Industries, Inc.
P.O. Box 927
139 W. Forest Hill Avenue Oak Creek, WI 53154
www.waterlooindustries.com
W103/3-11/V2
