Streamline your O.R. workflow.

(1)

Share and distribute surgical content—right from the O.R.

(2)

Operation Room 2

Operation Room 1

Server Room

Medical Office

Lecture Hall

Medical Office

Distribute

Intuitive Control

Live Surgery

In Preparation

Video-Based

Education

Review/Train

Acquire

Distribute

View

Centralized Storage

Browse/Edit/Share/Review

Record

Introducing Sony’s smart O.R. workflow

solution, offering a comprehensive

way to manage your digital assets.

Video over IP has emerged as the chief

technology for video management,

enabling easy and secure video

transport throughout your hospital’s

network in virtual real time. From

capturing live video in the O.R. to

viewing stored content, this end-to-end

solution for distributing and sharing

gives you access to your content

any time from wherever you are.

The system’s IP-based design is

ideal for migration from HD to

4K. It is designed to help medical

professionals use valuable visual

content for surgical education, training,

research, presentations, and more.

Sony’s smart O.R. workflow

solution enhances your operational

efficiencies and offers a flexible

upgrade path from HD to 4K.

An end-to-end solution

for sharing digital

(3)

• Difficult to repurpose digital content

efficiently

• Need to see live surgery outside O.R.

• Extensive work needed before system can

be used, due to complex settings

Opening new possibilities for O.R. systems.

Current issues

Sony's solution

• Easy use of digital content for education and/or

presentations with fewer data transfer constraints

• User-friendly intuitive GUI of the CMS for easy

editing or distribution

• Live streaming to anywhere by IP

• Only one type of connector required—just plug in

and it’s ready to go

• Easy replacement of broken or malfunctioning

medical devices

• Use of O.R. controller features user-friendly GUI and

thumbnails for intuitive operation*

For doctors

For medical staff

* Sony provides integrators with an API (Application Programming Interface) that enables control from a general-purpose O.R. controller

One connector Screen images simulated

(4)

• Additional training expenses and staff

education needed when installing new

medical devices

• Security concerns over archiving digital

content on USB devices, discs, and tapes

• Need for the latest systems and technology

to provide new value to customers

• Need to customize O.R. controller for

customer

Current issues

Sony's solution

• No extra work, such as panel mounting, cable

replacement, or rewiring, required—less down time

• Little extra training needed, as O.R. controller

controls all medical devices

• Easy storage and retrieval of digital assets on a

secure server

• Provides upgrade path from HD to 4K

• Easy set-up and operation by medical staff,

thanks to IP-based design

• Centralized control of medical devices, including

portable types using an O.R. controller

• API for easily customizing O.R. controller

For hospital managers

(5)

Designed for exclusive use with NU-IP40S/D IP

converters, the Network System Manager software

package controls the destination of video output.

Along with the IP converters, the Network System

Manager manages the IPCs and allows operators

Sony’s CMS is a centralized medical assets

management system. This system can archive video,

still images, and documents effectively and can

enable easy and secure access to them throughout a

hospital’s network. This becomes a central repository

that’s more efficient and secure than removable

media. The CMS can store video content shot in

multiple O.R.s for repurposing and reuse.

• Enables control from a general-purpose O.R.

controller via an API (Application Programming

Interface)

• Includes functions to notify the O.R. controller of its

communication status—for example, outputs alert if

a cable is disconnected during a surgical procedure

• Creates a thumbnail image from modalities with a

connected IP converter and sends images to the O.R.

controller

• Enables O.R. controller to control modalities or AV

devices remotely via the RS-232C connection of the

IP converter

• Comprised of a dedicated professional server

pre-loaded with Sony CMS software.

• Fully scalable and expandable as the facility’s

storage needs grow.

• Able to be implemented without intense

bandwidth requirements or IT system overhauls

• Accessed through standard web browsers

• Capable of automatically creating proxy files

• Simple to add patient information and metadata

• Secure in access and control

• Convenient for quick scene searches

Network System Manager (NU-NM11B)

Content Management System (CMS)

Thanks to associated patient information, content

is easily searchable via PC, Mac®, or iPad®. CMS

also provides a near real-time monitoring function

for sharing the live camera in the O.R. Authorized

personnel can view activities in the O.R. from secure

remote locations within the hospital’s network.

In addition, CMS is:

to easily route videos to destination devices,

via an O.R. controller.

(6)

NU-IP40S NU-IP40D

Input Connectors 3G/HD SDI BNC type (4)*1_,

DC IN (3-pin DIN) (1)

DVI (1) HDMI (Type A) (1), DC IN (3-pin DIN) (1) Output Connectors 3G/HD SDI BNC type (4)*1 _{HDMI (Type A) (1)}

Other Interfaces Network (10GBASE-SR) LC type (2),

RS-232C (for device control or for servicing) 9-pin D-sub (1), Equipotential (1) Supported Interface -

Input

3G/HD SDI (4:2:2YCbCr 10bit)*2 _HDMI

DVI, DVI-D DVI-A

(Analog RGB*3_{, VIDEO}*4_{, S-VIDEO}*4_,

Component*4₎

Supported Interface - Output

3G/HD SDI (4:2:2YCbCr 10bit)*5 _HDMI

Transmission - Mode Uncompressed mode or Compressed mode (LLVC)*6

Audio Signals SDI embedded audio supported 2 ch 48 kHz 24 bit

HDMI Audio 2 ch, 16 bit (32 kHz/44.1 kHz/48 kHz)

Power Requirements +24 V DC Input Current 1 A Operating Temperature 0°C to 40°C (32°F to 104°F) Operating Humidity 30% to 85% (non-condensing) Operating Pressure 700 hPa to 1060 hPa Storage and Transport

Temperature

-20°C to +60°C (-4°F to +140°F) Storage and Transport

Pressure

700 hPa to 1060 hPa Mass Approx. 0.7 kg (Approx. 1 lb. 8.7 oz.) Dimensions

(W x H x D)*7

7 1/8 x 1 15/16 x 4 3/4 in. (180 × 48.5 × 120 mm) (with foot, excluding protrusions), 7 1/8 x 1 11/16 x 4 3/4 in. (180 × 42 × 120 mm) (without foot, excluding protrusions)

HVO-4000MT HVO-3300MT

Recording Video Format MPEG-4 AVC/H.264 Recording Audio Format LPCM, AAC LC AAC LC Recording File Format XAVC S, MP4 MP4 Recording Media Internal HDD (4TB),

External USB Storage,

Network (CIFS), DVD-R, BD-R/BD-R DL, BD-RE/BD-RE DL

Internal HDD (2TB), External USB Storage,

Network (CIFS), DVD-R, BD-R SL/BD-R DLBD-RE SL/BD-RE DL

Input Resolution 4096x2160, 3840x2160 -Recording Resolution 3840x2160, 1920x1080 -Recording Bit Rate (4K) 150Mbps (Best), 100Mbps (High),

60Mbps (Standard)

-Recording Bit Rate

(Full HD) -1080p: 24Mbps (Best), 18Mbps (High), 12Mbps (Standard) 1080i/720p: 20Mbps (Best), 12.5Mbps (High), 6Mbps (Standard) Recording Bit Rate (HD) 24Mbps (Best), 18Mbps (High),

12Mbps (Standard)

NT/PAL: 6Mbps (Best), 4Mbps (High), 2Mbps (Standard)

3D Recording

Line by Line, Top and Bottom

Side by Side, Top and Bottom (Input 3D Signals: Side by Side, Line by Line, Dual Stream) Input Connectors

3G-SDI (BNC type) (4), AUDIO (Stereo mini jack) (1), MIC (Stereo mini jack) (1), AC Inlet (3-pin) (1)

3G/HD/SD-SDI (BNC type) (2), DVI-D (Single link) (2), S-VIDEO (Mini DIN 4 -pin type) (1), VIDEO (BNC Type) (1), RGB (Mini D-Sub 15-pin) (1), AUDIO (Stereo mini jack) (1), MIC (Stereo mini jack) (1), AC Inlet (3-pin) (1) Output Connectors

3G-SDI (BNC type) (4), HDMI (Type A) (1), AUDIO (Stereo mini jack) (1)

3G/HD/SD-SDI (BNC type) (1), DVI-D (Single link) (1), S-VIDEO (Mini DIN 4 -pin type) (1), VIDEO (BNC Type) (1), AUDIO (Stereo mini jack) (1) Other Interfaces USB 3.0 (Type A) (2),

USB 2.0 (Type A) (4), USB 2.0 (Type B) (1),

Network (RJ-45, 1000 Base-T/100 Base) (1), REMOTE RS-232C (D-sub 9-pin) (1), REMOTE contact switch (Stereo mini jack) (4), Equipotential

USB 3.0 (TypeA) (2), USB 2.0 (TypeA) (4), USB 2.0 (TypeB) (1),

Network (RJ-45, 1000 Base-T/100 Base-TX) (1), REMOTE RS-232C (D-Sub 9-pin) (1), REMOTE contact switch (stereo mini jack) (4), MENU MONITOR (Mini D-Sub 15-pin) (1) Equipotential

Power Requirements 100 V to 240 V AC, 50/60 Hz Input Current 1.25 to 0.52 A Operating Temperature

41 °F t o 104 °F (5 °C to 40 °C)

Operating Humidity _{20% to 80% (Maximum wet-bulb temperature: 86 °F (30 °C)) (no condensation)} Operating Pressure _{700 hPa to 1060 hPa}

Storage and Transport

Temperature -4°F to +140°F (-20°C to +60°C) Storage and Transport

Humidity 20% to 90% (Maximum wet-bulb temperature: 86 °F (30 °C)) (no condensation) Storage and Transport

Pressure 700 hPa to 1060 hPa Mass _{Approx. 14 lb. 5.3oz. (Approx. 6.5 kg)} Dimensions

(W x H x D) *7 12 1/8 x 4 5/8 x 13 in. (305.0 × 115.5 × 329.0 mm§) (including longest protrusions)

1. B 2. I

3. Available when using with the supplied NUA-AA10 Analog adapter 4. Available when using the NUA-AA10 and optional SMF-405 cable 5. Output capability is available when it is set to Rx mode

6. Sony developed low latency video codec (LLVC) technology to support the video compression required for 4K 60p transmissiet

7. The values for dimensions are approximate Notes:

* BNC SDI connectors can be set either as input or output * Input capability is available when it is set to Tx mode

* Available when using with the supplied NUA-AA10 Analog adapter * Available when using the NUA-AA10 and optional SMF-405 cable * Output capability is available when it is set to Rx mode

* Sony developed low latency video codec (LLVC) technology to support the video compression required for 4K 60p transmission over 10 Gbps Ethernet * The values for dimensions are approximate

Specifications

IP Converters

Related products of Sony's smart O.R. solution

(7)

©2017 Sony Electronics Inc. All rights reserved. Reproduction in whole or in part without written permission is prohibited. Features and specifications are subject to change without notice. Sony and the Sony logo are trademarks of Sony. CAUTION: Federal (USA) law restricts this device to sale by or on the order of a physician or other appropriately licensed medical professional.

CAUTION: See product labeling for indications, contraindications, warnings, cautions, and directions for use.

Sony Electronics Inc.

1 Sony Drive

Park Ridge, NJ 07656

sony.com/4K3D

ME-4069

4K 3D Monitor 4K 2D Monitor Full HD 2D Monitor LMD-X550MT LMD-X310MT LMD-X550MD LMD-X310MD LMD-2765MD/2760MD

Panel a-Si TFT Active Matrix LCD

Picture Size (Diagonal) 54 3/4 in. 31 1/8 in. 54 3/4 in. 31 1/8 in. 27 in. 1387.8mm 789.06mm 1387.8mm 789.06mm 686 mm Effective Picture Size (H x V) 47 5/8 x 26 7/8 in. 27 1/2 x 14 1/2 in. 47 5/8 x 26 7/8 in. 27 1/2 x 14 1/2 in. 23 5/8 x 13 1/4 in.

1209.6 x 680.4 mm 698.0 x 368.1 mm 1209.6 x 680.4 mm 698.0 x 368.1 mm 597.9 x 336.3 mm Pixel Pitch 0.315 x 0.315mm 0.1704 x 0.1704 mm 0.315 x 0.315mm 0.1704 x 0.1704 mm 0.3114 x 0.3114 mm Resolution (H x V) 3840 x 2160 pix. 4096 x 2160 pix. 3840 x 2160 pix. 4096 x 2160 pix. 1920 x 1080 pix. (Full HD) Aspect 16 : 9 17 : 9 16 : 9 17 : 9 16 : 9

Pixel Efficiency 0.9999

Backlight LED

Panel Technology LCD with IPS

Luminance (Panel Specification) 520 cd/m2 (typical) 435 cd/m2 (Typical) 520 cd/m2 (typical) 770 cd/m2 (typical) 1000 cd/m2 (typical) Contrast Ratio 1400 : 1 1450 : 1 1400 : 1 1450 : 1 1000 : 1

Colors Approx. 1.073 billion colors Approx. 16.7 million colors Viewing Angle (Panel

Specification) 89°/89°/89°/89° (typical) Vertical Viewing Angle

(3D Mode)

32° at a viewing distance more than 1,200 mm,

crosstalk ratio less than 7% (typical)

27° at a viewing distance more than 775 mm,

crosstalk ratio less than 7% (typical)

-Gamma 1.8, 2.0, 2.2, 2.4, 2.6, DICOM, Highlight 1.8, 2.0, 2.2, 2.4, 2.6, DICOM Composite Input - LMD-2765MD: BNC (x1) Y/C input - LMD-2760MD RGB, Component Input -LMD-2765MD: Via HD-15 connector (D-sub 15-pin)* line 0.7 Vp-p (75ª)

(when Sync On Green,0.3 Vp-p sync) * Needs SMF-405 sold separately LMD-2760MD

HDMI Input HDMI (x1), (HDCP 1.4 correspondence) -DVI-D Input DVI-D (x1), (HDCP 1.4 correspondence) DVI-D (x2)

TMDS single link

SDI Input BNC (x5) BNC (x2) 3G/HD/SD-SDI

HD15 Input

- LMD-2765MD: D-sub 15-pin (x1)_LMD-2760MD External Sync Input

-LMD-2765MD: Via HD-15 connector (D-sub 15-pin)*

* Needs SMF-405 sold separately 0.3 Vp-p to 4.0 Vp-p (75 ª) LMD-2760MD Serial Remote (LAN) D-sub 9-pin (RS-232C) (x1), RJ-45 (x1), (Ethernet, 10BASE-T/100BASE-TX)

DC Input

-XLR-type 3-pin (male) (x1), 26 V DC

(output impedance 0.005 ohms or less)

-XLR-type 3-pin (male) (x1), 26 V DC

XLR-type 3-pin (male) (x1), 24 V DC

DVI-D Output DVI-D (x1), when HDCP disabling DVI-D (x1) SDI Output BNC (x5) BNC (x1)

DC 5 V/ 12V Output 5V Output(x1), 8W 12V Output (x1), 20W max 5V Output(x1), up to 1.2 A Power Requirements AC IN: 100 V - 240 V, 50/60 Hz, 3.2 A - 1.3 A DC Input: 26 V, 6.9 A AC adaptor’s AC IN: 100 V - 240 V, 50/60 Hz, 2.1A - 1.0 A AC IN: 100 V - 240 V, 50/60 Hz, 3.2 A - 1.3 A DC Input: 26 V, 6.9 A AC adaptor’s AC IN: 100 V - 240 V, 50/60 Hz, 2.1A - 1.0 A DC Input: 24 V, 6.25 A AC adaptor’s AC IN: 100 V - 240 V, 50/60 Hz, 2.5 A - 1 A Power Consumption Approx. 290 W (max.) Approx. 180 W (max.) Approx. 290 W (max.) Approx. 180 W (max.) Approx. 102 W (max.)

Operating Temperature 32°F to 104°F (Recommended: 68°F to 86°F) 32°F to 95°F (Recommended: 68°F to 86°F) 0°C to 40°C (Recommended: 20°C to 30°C) 0°C to 35°C (Recommended: 20°C to 30°C)

Operating Humidity 30% to 85% (no condensation) Storage/Transport Temperature -4°F to +140°F (-20°C to +60°C) Storage/Transport Humidity 0% to 90% Operating/Storage/Transport

Pressure 700 hPa to 1060 hPa Dimensions (W x H x D)*1 _{49 7/8 x 30 3/8 x 3 3/8 in.} 1264.6 x 771.5 x 85.5 mm (Slimmest D 33.9 mm) 29 3/4x 18 x 2 3/4 in. 753.8 x 456.4 x 69.3 mm (Slimmest D 28 mm) 49 7/8 x 30 3/8 x 3 3/8 in. 1264.6 x 771.5 x 85.5 mm (Slimmest D 33.9 mm) 29 3/4x 18 x 2 3/4 in. 753.8 x 456.4 x 69.3 mm (Slimmest D 28 mm) 25 5/8 x 16 1/2 x 2 3/8 in. 650 x 419 x 58 mm (Slimmest D 29 mm) Mass Approx. 77 lb. 9.6oz (35.2 kg) Approx. 26 lb. 0.23oz (11.8 kg) Approx. 77 lb. 9.6oz (35.2 kg) Approx. 26 lb. 0.23oz (11.8 kg) Approx. 18.75 lb. (8.5 kg) Mounting 200 x 200 mm VESA 300 x 300 mm VESA 100 x 100 mm VESA 100 x 200 mm VESA 200 x 200 mm VESA 300 x 300 mm VESA 100 x 100 mm VESA 100 x 200 mm VESA 100 x 100 mm VESA

Monitors

Note:

*1 The values for dimensions are approximate
