Supercharge your Fence & Gate Manufacturing
Only
$3,650!
Vogel’s 25 Ton Power Tower
Model CSP-25-SA
Tonnage 25 tons - 50,000 lbs of power! Power Requirem ents 110V, 20am p circuit
Power Connection 3 Prong Plug on 6' cord Controls Foot Pedal on 6' cord
90° Notching Package
Triple Housing Turntable $995.00 90° Notcher for 1-3/8" x schedule 40 $445.00 90° Notcher for 1-5/8" x schedule 40 $445.00 90° Notcher for 1-7/8" x schedule 40 $445.00 Notching Package Total $2,330.00
Vogel’s Triple Housing Turntable will mount in your 25 Ton Tower Power with a single-bolt.
Simply rotate the turntable to quickly select the size you need.
T Eliminates changeover time
T Eliminates lost tooling
T Tooling Made in USA
T Tooling sharpenable for long life
T One-Bolt installation to quickly swap with other Vogel tools
T Many other sizes available - consult factory
T Order custom notchers for drainholes slots and more - consult factory
90° & Slope Notching
Triple Housing Turntable $995.00 90° Notcher $445.00
1 Cut Slope Notcherst $1,175.00 2 / 3 Cut Slope Notchernd rd $1,175.00 90° & Slope Notching Package Total $3,790.00
Vogel’s Triple Housing Turntable will mount in your 25 Ton Tower Power with a single-bolt. Simply rotate the turntable to quickly select the size you need.
T Specify your slope, either 35° or 45°
T Specify your tube size, either 1-3/8", 1-5/8" or 1-7/8"
T One housing contains your 90° notching tool
T One housing for the 1 cut Slope Notchst
T One housing for the 2 / 3 cut Slope Notchnd rd
T Need additional sizes? Remove turntable with one bolt and swap.
T Tooling Made in USA
T Tooling sharpenable for long life
Picket Forming
Com plete Radius Tip Picket Form ing Tool $3,475.00 Extra Form ing Tooling for Extra Tube Sizes $500.00
Simple Self-Contained Tool Flattens Square Tubing and Trims into a Picket One Press Stroke!
T Capacity: 1" square x 16 gauge steel tubing
T Capacity 1" square x 14 gauge aluminum tubing
T Unit includes one set of forming tooling, Specify:
T Small - For ½ square tubing
T Medium - For 3/4" & 5/8" square tubing
T Large - For 1" & 7/8" square tubing
T Tooling made in USA
T Tooling sharpenable for long life
T Two-Bolt installation to quickly swap with other Vogel tools
Pick-A-Picket
T An industry first, brought to you exclusively by Vogel Tool & Die.
T Customize pickets for a unique look that makes your ornamental fences stand out
T Sphere design can accept faceted glass jewels for a striking, luxury look
T Custom designs available, contact us with your ideas
T Fits Vogel standard housing and 110V Power Tower
T Great upsell for more profit!
Pick-A-Picket
Christian Cross M edical Cross Pierced hole
Channel & Tube Piercing
Channel Piercing
Com plete Channel Pierce Tool $3,750.00 Adjustable Stop Assem bly $775.00 Total for Channel Piercing Package $4,525.00 Extra Punch & Die Sets for Extra Hole Sizes $950.00
T Capacity: 2" wide x 1" legs x 1/8" wall channel
T Adjustable for all channel sizes, up to max. capacity
T Specify hole size to be pierced
T Additional punch & die sets easily change hole size
T Fully adjustable stop maintains consistent hole spacing
T Tooling made in USA
T Tooling sharpenable for long life
T Two-Bolt installation to quickly swap with other Vogel tools
T Power Tower sold separately
Tube Piercing
Com plete Tube Piercing Tool $5,225.00 Adjustable Stop Assem bly $775.00 Total for Tube Piercing Package $6,000.00 Extra Punch & Die Sets for Extra Hole Sizes $870.00 T Capacity: 1-1/2" square x 1/8" wall tubing
T Changing cams and / or spacers adjusts for all tube sizes, up to 1-1/2" square
T Specify hole size to be pierced
T Additional punch & die sets easily change hole size
T Side walls clamped during piercing to prevent bulging
T Deformation limited to top wall, exit hole - bottom wall clean
T Rotate tube upside down for panel assembly
T Quickly cut square tubing to length with minimal deformation.
T No chips to remove from tube
T Cut up to 1-1/4" square
T No changeover for different tube sizes
T Fits most ironworkers and Vogel's 110V Hydraulic Power Unit
T Low-cost sharpenable blades, $75.00 each
Square Tubing Cut Off
Tube Cutting
Vogel #4162 Econo Cut Off Die $3,575.00 Vogel #4162 Tube Guides $675.00 / set Vogel #4162 Econo Cut Blades $75.00 / ea.
Vogel Tool & Die INVENTED the pipe notcher and was issued the original US patent in 1934. Today, as a Division of Manor Tool & Manufacturing Company, we continue to offer our Arc-Fit pipe notchers and other tools for fabricating parts from tube and pipe. All Vogel tools are made with pride in the USA, featuring American steel and American heat-treating. Imported tools may look similar, but poor quality steel and improper heat-treating may lead to significantly reduced tool life and poor performance. Vogel tools are designed and built to last and provide many years of dependable performance.
Toll-Free: 800-272-8946
Outside US: 630-562-1400
Fax: 630-562-1500
Other Tools From Vogel
Hand Presses for Notching Tools to Miter Tube Ends Tools to Shear Round Bar Stock
Stands for Hand Presses Tools to Cut Tubes to Length Tools to Shear Flat Stock
Truck Hitch-mount for Hand Presses Tools to Shear Angle Tools to Shear Channel
Custom Dies for Specialized Tubular Part Fabrication
All prices are FOB Factory
Sales tax is added to orders shipped to Illinois addresses We accept Visa, MasterCard, Discover Card & American Express Please contact us with questions or to place your equipment order:
