PARTS SECTION. Section MF2. Engine Systems; exhausts, cooling, fuel,.

(1)

PARTS SECTION

Section MF2

Engine Systems;

(2)

All parts are aftermarket replacement parts and are not manufactured by the O.E.M. The original equipment part numbers are PART NO.

70248233

FITS:

180, 185,

190, 190XT

PART NO.

70243014

FITS:

180, 185,

190, 190XT

DESCRIPTION; Radiator Hose—Upper

ALLIS CHALMERS

RADIATOR HOSE

DESCRIPTION; Radiator Hose—Lower

ALLIS CHALMERS

RADIATOR HOSE

PART NO.

AC-1

FITS: Any 540 rpm PTO

PTO DRIVEN AIR PUMP

DESCRIPTION;

Side panel, LH. Metal

PART NO.

510458A M2

SECONDS

NO REFUNDS

FITS:

.

135, 2135

SIDE PANEL—LH

REJECTS/SECONDS

DESCRIPTION;

Side Panel, RH. Metal

PART NO.

510457A M2

SECONDS

NO REFUNDS

FITS:

135, 2135

SIDE PANEL—RH

REJECTS/SECONDS

Rubber Torque Pad for 8 and

10 ft. Rotary Cutters

Rubber Torque Pad

with 6 steel

bush-ings. Measures 6

5/16 outside

di-ameter and 2 1/8

inside diameter

and 3/4 thick.

(3)

PART NO.

3637307M91

FITS:

MF20, 20C, 30B, 40, For AD3-152 Diesel Eng. in MF135 after eng. S/N 152UA38571D,MF148 & 550, MF230 prior to eng. S/N 9A349239, MF235, 245, 202, 2135; 2500

DESCRIPTION; Old # 885363M91 , 2 Hole Mount

PART NO.

3637288M91

FITS: MF 35 w/Perkins Gas or Diesel, MF50, 135 prior to eng. S/N 152UA38571D, MF150 thru eng. S/N 152UA-46496D Replaces Perkins # 2641406 & 2641408

DESCRIPTION; Old # 886062M91. 2 Hole Mount.

FUEL LIFT PUMP

DESCRIPTION; Old# 892630M91, 2 Hole Mount

PART NO.

3637338M91

FITS:

MF65, MF165 prior to eng. S/N 29F4249, For Perkins Models; A4-192, A4-203, AD4-203, Replaces Perkins # 2641345

FUEL LIFT PUMP

DESCRIPTION; Old# 886100M91 or 1447693M91. 2 Hole Mount. PART NO.

3637286M91

FITS: MF 165 eng. SN 29F-4249 & Up, MF 255 w/AD4-203 eng.,285, 1085, 302, 3165, 30, 50, 50A, 540 Combine, 70 Backhoe,320 Skidder, 40B

FUEL LIFT PUMP

DESCRIPTION;Old #’s 1447017M91 & 1447688M91. 4 hole mount

PART NO.

3637290M92 or

3637300M91

FITS:

MF175 eng. S/N 236UA57083 & Up, MF180 eng. S/N

236UA57265 & Up, MF255 w/ A4-236 eng., MF265, 270, 274-4, 275, 283, 670, 690, Ind. 50C, & 50D

(4)

PART NO.

3637309M91

FITS: 1105, 1135, Combines: 510, 750, 760

FUEL LIFT PUMP

Perkins # 2641372 Replaces MF part no. 892632M91

PART NO.

735010M91

FITS:

AD3.152 ENGINES,

135, 150, 240

FUEL INJECTION LINE,

LEAK OFF; 3 cyl.

PART NO.

3638623/25

FITS:

AD3.152 ENGINES’

135, 150, 235,

230, 240

FUEL INJECTION LINE ASSY.

3 LINES

DESCRIPTION; 3 Lines, for fuel injection. Set includes 3638623M91, 3638624M91, & 3638625M91

PART NO.

35587344

FITS:

A4.236 & A4.248

ENGINES

FUEL INJECTION LINE,

LEAK OFF; 4 cyl.

PART NO.

35343025/28

Also MF Part #’s: 3641094M91, 3641262M91, 3641095M91, 3641156M91. Or 744512M91, 744513M91, 744514M91, 744515M91 FITS: 165, 175, 180, 255, 265, 275, 270, 282, 283, 290, 670, 690, 50D, 50C, 60 Tractor-B.Hoe, 374S, 384S, 394S, 374V,

A4.236 & A4.248 ENGINES

FUEL INJECTION LINE ASSY.

4 LINES

DESCRIPTION; 4 Lines, for fuel injection. Set includes 35343025, 35343026, 35343027, & 35343028.

DESCRIPTION; Old# 3637292M91, 4 Hole Mount

PART NO.

4222090M91

FITS: MF230, 231, 231S, 240, 240S,245, 250, 253, 263

(5)

DESCRIPTION; Glass bowl. Deep, flat bottom PART NO.

1024386M1

FITS: MF 35, 40, 50, 50A, 65, Super 90, 135, 150, 165, 175, 180, 2675, 1100, 1130, 300, 410, 510, 550, 750, 760, 1080, 1150, 1500/1800, 1105/1135, 203,205,302, 304,

SEDIMENT BOWL

SEDIMENT BOWL GASKET KIT

PART NO.

SDK1

FITS:

DESCRIPTION;

2 o’rings and plug

PART NO.

1039071M1

FITS: MF 230, 235, 245, 250, 255, 265, 275, 285, 1085, 2745, 20C, 30B, 30D, 40B, 50C, 50D, 1150, 1155, 4500& 6500 Forklifts

DESCRIPTION; Filter 2-3/4” tall with seals shown.

PART NO.

7111-296

FITS: Replaces CAV7111/296. Can replace 1049939M91, 1077260M1, 1851890M1.

FUEL FILTER

DESCRIPTION; Filter 4-3/8” tall with seals shown.

PART NO.

7111-796

FITS: Replaces CAV7111/796. Can replace 1896287M91, 350541M1

FUEL FILTER

DESCRIPTION; Glass bowl. Round bottom

INJECTOR PUMP GASKET KIT

PART NO.

7135-110

FITS: CAV INJECTOR PUMPS

(6)

PART NO.

898540M91

FITS: 135UK, 231, 240, 240-P, 240-S, 250, 20D, 20E, 20F, 30E, 30H, 40E. PART NO.

898580M91

FITS: 270, 282, 290 early prod., 271/281, 265-S, 285-S, 50E, 50F backhoe loader, 50H, 6500H forklift, 6800 forklift.

DESCRIPTION; Fuel shut off

FUEL TANK SHUT OFF

PART NO.

3762589M91

Old MF# 1672762M91 FITS:

240, 250

FUEL TANK

DESCRIPTION;

Metal fuel tank

PART NO.

1876534M91

FITS: 231, 240-P, 240, 250, 253, 263, 261, 270, 283, 290, 298, 670, 690, 698, 699

FUEL CAP

FUEL TANK

PART NO.

189468M93

FITS:

MF20, MF40,

MF35, MF135,

MF2135,

MF35/35X(FE)

(7)

DESCRIPTION; Replaces Perkins# 37764251 PART NO.

741922M1

FITS: MF 135, 150, 165, 230, 235, 245, 255, 265, 275,Indust. 20, 20C, 30, 30B, 30D, 40, 50A; 2500 & 4500 Fklift. Eng. AD3 -152 & AD4-203. Use w/Spin On Filter.

DESCRIPTION; Replaces Perkins# 37764181

PART NO.

741614M1

FITS: MF165, 175,180, 255, 265, 285, 6500 Fklift, w/ Perkins Eng. A4-318,

AD4-236 & AD4-248. Use w/Spin-On filter 1447048M1. Using 741614M1 & filter # 1447048M1 will replace old style cartridge type filter.

OIL FILTER HEAD

DESCRIPTION; Replaces Perkins # 2654403.

PART NO.

1447048M1

FITS: 165 gas, 175, 180, 255, 265, 275, 285, 1080, 1085 & other tractors with A4-212, AG4-212, A4-236, A4-248, A4 -318.

DESCRIPTION; Replaces Perkins # 2554408.

PART NO.

1447082M1

FITS:

135, 150, 165, 235, Indust. 203, 204. Other tractors with: A3-152, AG3-152, AD3-152, A4-203, AD4-203.

OIL FILTER –SPIN ON

DESCRIPTION; filter element with gasket

PART NO.

837595M91

835568M92

FITS: 35, 50, 65, 135, 150, 165, 3165, 2135, 30, 40, 50, 50A,154-4.

(8)

PART NO.

1877717M92

FITS:

231, 240, 240-P.,

250, 270, 282,

290, 298, 2775,

2805, 20D, 30E,

50E, 20E, 40E,

20F.

FUEL GAUGE

PART NO.

1672835M2

FITS: 240 S/N N01001 & UP 240 S/N N0 A20286 & Up, 20E, 20F, 30E power shuttle

AMMETER

DESCRIPTION;

DESCRIPTION; Also replaces # 1850377M96

PART NO.

1853097M91

FITS:

TO35,

FE35, 135UK, 175UK, 178UK

OIL PRESSURE GAUGE

PART NO.

1877719M92

FITS: 240, 240-P., 270, 282, 283, 290, 298, 2775, 2805, 20D, 30E, 50E, 20E; (British made 275, 290, 283)

TEMPERATURE GAUGE

PART NO.

UTG25

FITS:

Many MF

models with

2-

3/16

”

opening

UNIVERSAL TEMPERATURE

GAUGE

(9)

PART NO.

740221M1

37781571

FITS:

240, 250,

231, 20E, 20D

(HORZONTIAL)

PART NO.

732813M1

37781721

FITS:

65

PART NO.

734874M1

37781341

FITS: 135 (UK), 154-4, 154-4S, 240S (Turkey), 254-4, 20D, 20F, 30E, 30H PART NO.

734921M1

FITS: MF 135, 150, 230, 235, 245, 302, 2135, MF 200 SERIES

EXHAUST MANIFOLD

MANIFOLD for VERTICAL

EXHAUST

PART NO.

736245M1

FITS:

MF230,

MF245, 20C,

30B, 30D,

2200

TRACTOR,

2500

FORKLIFT

PART NO.

733206M1

37781781

FITS: MF165, 175, 180, 270, 283 (Brazilian & UK), 290, 220 Skidder, 265-S, 285-S, 175 & 178 UK.Replaces old# 736206

EXHAUST MANIFOLD

(10)

PART NO.

1865534M1

FITS:

231, 240, 250

EXHAUST ELBOW

PART NO.

1862807M1

FITS:

270, 290, 283,

165UK, 175UK,

275UK, 290UK,

283UK, 265-S,

285-S

EXHAUST ELBOW

PART NO.

897913M1

FITS:

165UK,

175UK, 178UK

EXHAUST ELBOW

PART NO.

507629M1

FITS:

MF 165, 165

UK, 175, MF 30,

3165 UTILITY

EXHAUST ELBOW

PART NO.

533446M2

FITS:

255, 265, 275,

285 EXHAUST MANIFOLD

PART NO.

741746M1

FITS:

255, 265,

275, 285

(11)

PART NO.

194742M1

FITS: 165, 175, 180, 255 gas/dsl, 265, 275, 270, 290, 283, 365, 375, 383, 390, 6760, 690, 30, 31, 50C, 60,

EXHAUST GASKET

PART NO.

735016M1

36862143

FITS: 135, 150, 230, 235, 240 prior to s/n N01001, 245, 250, 2135, 20, 40, 20D, 30E, 20E, 30F, 30H, 40E, 20C, 30B, 2500FL, 2200 Treever, 4500FL, 200 Loader

MANIFOLD GASKET

PART NO.

736754M1

36862134

FITS: 165 gas, 175 gas/ dsl, 180, 255, 265, 275, 670, 690, 270, 290, 282, 283, 375, 390, 3050, 3060, 3065, 3075, 374S, 384S, 394S, 374V, 30, 31

MANIFOLD GASKET

PART NO.

4222475M1-S

FITS: 154-4, 240-S, 154-4S, 135, 150, 2135, 231, 240-P., MH/MF 50, 65, 230, 245, 235, 240, 250, 290, 20, 50, 50A, 20D, 30E, 20E, 20C, 30B, 20F.

EXHAUST GASKET—METAL

PART NO.

735040M1

FITS: 165, 255, 3165, 40B, 30 Perkins# 36862144

EXHAUST MANIFOLD GASKET

DESCRIPTION; 2 required per engine.

PART NO.

731268M1

4223501M1

FITS: A3-152 DSL ENG. MF35, 50, 205, 35 TURF & UTIL

(12)

DESCRIPTION; WEATHER CAP PART NO.

192791M1

FITS:

230, 235, 245,

255, 261, 265,

275, 1080

DSL., 35 TURF

& UTILITY, MF95, SUPER95, 20C, 30B, 30D,

40B, 50C, 50D

PART NO.

505545M2

FITS:

TE-20, TO-20,

TO-30, TO-35,

MF35

(1955-63) Gas &

Diesel, MF135

(1964-74) Gas

& Diesel.

MUFFLER –Horizontal

WEATHER CAP

2” TO 2-1/4”

TACHOMETER

PART NO.

1674638M92

FITS:

20E, 30E, 40E,

231, 240, 240P,

240S, 250, 253,

263, 398

PART NO.

1853144M1

FITS: MF270, 274-4, 283, 290, 298, 670, 690, 698, 699, 154-4S, 174-4S, 274-4, 294-4, 50E, 50F, 50H, 50HX, 60H, 6500H FORKLIFT, 6800H FORKLIFT

TACHOMETER DRIVE

PART NO.

508231M91

FITS:

MOST

TRACTORS

WITH THREE

CYLINDER

PERKINS

ENGINES

TACHOMETER DRIVE CABLE

PART NO.

1876289M93

FITS:

MOST

TRACTORS

WITH FOUR

CYLINDER

PERKINS

ENGINES

TACHOMETER DRIVE CABLE

(13)

PART NO.

739527M91

747542M91

FITS:

Ad3.152 ENG.

MF135, 150,

230, 235, 245,

20, 20C, 30B,

2135, 240, 250

DESCRIPTION; Water pump with pulley and gasket

WATER PUMP W/GASKET

DESCRIPTION; Water pump with pulley and gasket

PART NO.

743064M91

3641832M91

FITS:

A4-236

MF175, 180, 265,

275 WATER PUMP W/GASKET

PART NO.

740611M91

3641250M91

FITS:

A4-203,

ad4-203 MF65, 165,

255, 30, 40B

WATER PUMP W/GASKET

PART NO.

3637335M1

731275M1

Perkins# 0941183 FITS:

Ad3.152 ENG.

MF135, 150,

230, 235, 245,

20, 20C, 30B,

2135, 240, 250

BACKPLATE,

for 739527 M91 Pump

Rubber Torque Pad for 8 and

10 ft. Rotary Cutters

Rubber Torque Pad

with 6 steel

bush-ings. Measures 6

5/16 outside

di-ameter and 2 1/8

inside diameter

and 3/4 thick.

(14)

PART NO.

746835M1

FITS: 35, 50, 135, 150, 230, 235, 240, 245, 250, 231, 240P., 240 -S(TURKEY), 35 turf & utility, 154-4, 2135, 2500FL, 20, 40 , 30D, 20D, 20E, 20F, 30H.

THERMOSTAT HOUSING

DESCRIPTION; Replaces Old MF# 737192M1, & Perkins # 37766362 PART NO.

731000M1

FITS: 35, 135, 230, 235, 245, 240, 250, 240 -S, 240 P., 231, 253, 263, 2135, 2500FL, 30B, 30D, 30E, 20E, 20F, 30H

CONNECTION-THERMOSTAT

HOUSING

DESCRIPTION; Replaces Perkins# 37747581 PART NO.

1446127M91

1853313M91

Perkins # 2485666 FITS:

35, 150, 165, 175,

180, 285, 245,

230, 235, 255,

265, 275, 374,

384, 394, 374v, 283, 270, 290, 282, 298,

THERMOSTAT

PART NO.

731211M2

3640918M1

Perkins# 37736242 FITS:

35, 135, 150, 50,

240, 250, 230, 235,

245

(15)

RADIATOR HOSE—LOWER

RADIATOR HOSE— LOWER

DESCRIPTION; Hose, radiator. Upper.

PART NO.

539808M1

FITS:

MF 245 cont.gas or dsl. eng., 230

w/gas eng. prior to and later than S/N 9A 349 239,

230 w/dsl. eng. S/ N 9A 234 032 & up

RADIATOR HOSE—UPPER

DESCRIPTION;Radiator Hose—Lower used w/metal tube part # 544081 PART NO.

544080M1

FITS: MF 245 cont.gas or dsl. eng., 230 w/gas eng. prior to and later than S/N 9A 349 239, 230 w/dsl. eng. S/N 9A 234 032 & up

RADIATOR HOSE—LOWER

DESCRIPTION; Hose, radiator. Lower. Black rubber.

PART NO.

532541M1

FITS: MF 285 prior to and later than S/N 9A 349 239 PART NO.

826775M1

FITS: MF 245 cont.gas or dsl. eng., 230 w/gas eng. prior to and later than S/N 9A 349 239, 230 w/dsl. eng. S/N 9A 234 032 & up

DESCRIPTION;Radiator Hose—Lower used w/metal tube part # 544081

PART#:

BH1311

FITS;

4:00X8 Tail Wheel

PART#:

12268

FITS;

4:00X8 Tail Wheel

TAILWHEEL HUB

(Old Style Hub uses bearing

cups & cones.)

Description:

4 BOLT, 5” BOLT CIRCLE

TAILWHEEL HUB

(New Style Hub for use w/bearing

sleeve)

(16)

PART NO.

772165M3

FITS:

MF 285 w/dsl.

eng. S/N 9A

349 239 & up,

MF 285 w/cab prior

to S/N 9A 349 239,

MF 298 U.K.

RADIATOR HOSE—LOWER

RADIATOR HOSE—UPPER

PART NO.

187554M1

FITS: MF 65, 302, 304, 50, 50A

RADIATOR HOSE

DESCRIPTION: RADIATOR HOSE- LOWER

PART NO.

180085M1

FITS:

TE-20, 20, 30, TO-35,20, 35, 35 Utility, 50, 135, 230, 235, 202, 203, 204, 205, 2135

RADIATOR HOSE

DESCRIPTION: Hose, radiator. Upper. Black rubber

PART NO.

579773M1

FITS: MF 275 w/dsl. eng. S/N 9A 349 239 & up. Fits Rad. Part # 579 337

DESCRIPTION: Hose, radiator.Lower. Black rubber. DESCRIPTION; Hose, radiator. Upper. Black rubber

PART NO.

194739M2

FITS: MF 165, 255, 3165, 30

RADIATOR HOSE

DESCRIPTION: RADIATOR HOSE- LOWER

PART NO.

186968M1

FITS:

TE-20, TO-20, TO-30, TO-35,20, 35, 35 Utility, 50, 135, 230, 235, 202, 203, 204, 205, 2135

RADIATOR HOSE

(17)

DESCRIPTION;

Rubber Hose. Replaces Perkins #0202016.

PART NO.

731256M1

747936M91

FITS:

TE-20, TO20, TO-30, TO-35, 35, 35 UTILITY, 50, 135, 230, 235, 240, 250, 202, 203, 204, 205, 2135.

WATER BY-PASS HOSE

DESCRIPTION; PART NO.

732443M1

FITS:

TE-20, TO20, TO-30, TO-35, 35, 35 UTILITY, 50, 135,

230, 235, 202, 203, 204, 205, 2135.

WATER PUMP INLET HOSE

PART NO.

194275M93

FITS: MF 135 (Diesel), 2135 utility, MF 20

RADIATOR

PART NO.

1680547M91

FITS: MF20D, MF20E, MF20F, MF30E, MF30H, MF40E, MF240, MF250

RADIATOR

PART NO.

1874445M94

FITS: 240-S, 240, 250, 270, 290, 298, 283, 231, 240-P., 261, 253, 263

RADIATOR CAP

RADIATOR HOSE—LOWER

PART NO.

511951M1

FITS: MF 245 dsl eng. prior to S/N 9A 349 239 Std & Vinyard clearance, MF 245 Orchard S/N 9A 349 239 & up, 235 Orchard, 20C,30B,30D,40

(18)

PART NO.

186819M91

FITS:

Fits MF 35, 50, 203, 205 & all

A3-152 engines

FAN ASSY.—4 BLADE

DESCRIPTION; 4 blade fan assembly

PART NO.

194046M91

FITS:

Fits MF 135 & all

AD3-152 engines

FAN ASSY.—4 BLADE

PART NO.

194379M93

FITS: 35, 135, 235, 230 2135

FAN SHROUD

PART NO.

539915M1

FITS: MF 230, 235, 245, 20C, 30B, 30D, 40, 4500 Forklift, 2200 Tractor, 2200 Treever

5” Water Pump-Fan

Extension

DESCRIPTION; also for new AGCO # 736442M1 PART NO.

544348M91

FITS: MF 230, 235, 245, 20C, 30B, 30D, 40, 4500 Forklift, 2200 Tractor, 2200 Treever

(19)

PART NO.

509682M91

273541M91

FITS: MF135, 150, 165, 175, 180, 230, 245, 255, 265, 275, 285, 290, 1080, 1100, 1105, 1130, 1135, 1150, 1155, Ind. 20, 20C, 30, 30B, 30D, 31, 40, 40B, 50, 50A, 50C, 50D, 2135

OIL PRESSURE SWITCH

PART NO.

3599307M91

1877721M92

FITS: 184-4, 194-4, 231, 240, 240P., 240-S, 250, 253, 261, 263, 274-4, 283, 283 BRAZIL, 271/281, 265-S, 285-S, 294-4, 360, 362, 364S, 365, 374S, 374V, 375, 383, 384S, 390, 390T, 394S, 396, 670, 690, 698, 699, 2640, 3050, 3070, 3090, 3630, 3650, 3065, 3125, 3095, 3645, 3655, 3120, 3140, 3660, 3120T, 3075, 3505, 3525, 3545, 4225, 4235, 4240, 4245, 4255, 4265, 4243, 4253, 4263, 4325, 4335, 4345, 4355, 4360, 4370, 6140, 6150, 6170, 6180, 6190, 6235, 6245, 6255, 6265, 6270, 6280, 6290, 8210, 8220, 8250, 50E

OIL PRESSURE SWITCH

PART NO.

963417M2

FITS: 231, 240 s/n N01001 & up, 240-P., 261, 253, 263, 362, 365, 375, 383, 390, 390T, 396, 398, 399, 30E, 50E, 20E, 50F, 20F. Also Replaces Part Numbers:

1679223M1

NEUTRAL SAFETY SWITCH

PART NO.

1877731M1

FITS: 154-4, 184-4, 3050, 3060, 3070, 3090, 3630, 3650, 3065, 3125, 3095, 3645, 3655, 3120, 3140, 3660, 3120T, 3075, 6140, 6150, 6170, 6180, 8120, 240S, 265S, 285S, 6190, 6235, 6245, 6255, 6265, 6270, 6280, 6290, 8210, 8220, 8250, 271, 281, 8240, 8220, 8250, 364S, 374S, 384S, 394S, 374V, 283(BRAZIL), 285, 2775, 2805, 2745, 2705, 2675, 254-4, 274-4, 294-4, 2640, 670, 690, 698, 240, 250, 270, 290, 282, 298, 20D, 30E, 3505, 3525, 3545, 699, 50E, 283, 154-4S, 174-4S, 194-4S, 6500H FKLIFT, 6800H FKLIFT, 231, 240p., 261, 4800, 4900, 50F, 20E, 20F, 30E, 30H, 50E, 375, 390, 398, 399, 360, 40E, 383, 253, 263, 390T, 362, 393, 396, 365, 4225, 4235, 4240, 4245, 4255, 4265, 4260, 4270, 4243, 4253, 4263, 4325, 4335, 4345, 4355, 4360, 4370.

WATER TEMP SENDING UNIT

NEUTRAL SAFETY SWITCH

PART NO.

181140M94

FITS: 31, 35, 65, 135, 150, 165, 175, 230, 235, 245, 255, 265, 275, 285, 1085, 2030, 4050, 200 SERIES TRACTORS Also Replaces Part Numbers:

1679223M1

PART NO.

BHTWK-11

FITS:

12268

Tail wheel hub,

Bush Hog (New

Style)

Includes: 12263

Tube, 2-12261

Washers, 2-12250

Bearings

(20)

PART NO.

3597426M3

FITS:

231, 240 s/n

N01001 & up.,

253, 263, 364

prior to s/n

D03066, 20E,

30H

STARTER—for 3 CYL.

PART NO.

1894395M91

1057576M91

FITS:

231, 240 s/n

N01001 & UP, 253,

263, 360, 364S

prior to s/n D03066

STARTER DRIVE

PART NO.

3473937M91

3904281M1

Old MF# 1894550 M91 FITS:

240, 250

SOLENOID for

MAGNETI-MARELLI STARTERS

DESCRIPTION; 12V, 55 amp Replaces old #’s: 1895398M91, 161795M92 PART NO.

3405390M1

FITS: 231, 240 prior to s/n N01001, 240P., 250, 270, 283, 290, 670, 690, 698, 2775, 2805, 2745, 2705, 2675, 2640, 20D, 30E, 50E, 20E, (British made 275, 290, 283)

(21)

IGNITION SWITCH w/ 2 keys

PART NO.

1874535M3

1874120M93

FITS:

.

231, 240, 240P, 240S, 250, 261, 265S, 270, 271, 282, 283, 285S, 290, 360, 383, 375, 390, 390T, 393, 396, 398, 399, 451, 471, 481, 491, 492, 3050, 3060, 3070,3090, 3630, 3650, 3680, 3065, 3125, 3095, 3645, 3655, 3120, 3140, 3660, 3670, 3690, 3120T, 3075, 6140, 6150, 6170, 6180, 8120, 8140, 8150, 8160, 6180, 6270, 6280, 6290, 8120, 8220, 3505, 3525, 3545 PART NO.
