Custom Arch Windows

Custom Shapes

and Sizes ... 129

Arch, Springline

™

_{& Springline}

™

Flanker Windows

Tables of Sizes ... 130–135

Opening Specifi cations ...131–133

Divided Light Patterns ... 134

Window Details ... 135

Flexiframe

®

_Windows

Custom Shapes

and Sizes ... 136

Window Details ... 137

Joining Details ...137–138

(2)

Circle Top

™

Window

F D E G H

Features

FRAME

A

Wood frame members are

treated with a water-repellent

wood preservative for long-lasting

*

protection and performance. Radii

are made of laminated select

hardwood, offering improved

strength and appearance.

B

The lineal sections of the

jamb and sill on Andersen

®

Flexiframe,

®

custom arch, arch

and enhancement windows are

covered with a low-maintenance,

ﬁ berglass reinforced composite.

The arched head members, and

Springline

™

units, are covered

with stretch formed aluminum.

C

The vinyl anchoring ﬂ ange

on Flexiframe,

®

custom arch, arch,

Springline,

™

and enhancement

units extends 1

1

_/

₄

_{" around the}

entire perimeter of the unit.

It helps secure the unit to

the structure.

D

Andersen Circle Top,

™

quarter

round, elliptical, circle and oval

windows are covered with a

rigid vinyl (PVC) pre-formed

sheath. Low-maintenance

exterior cladding provides

long-lasting

*

_beauty.

E

Pre-formed rigid vinyl sheath

on the Andersen Circle Top,

™

quarter round, elliptical, circle

and oval window frames forms a

full perimeter ﬂ ange for sealing

the unit to the structure. It also

helps maintain an attractive

appearance while minimizing

maintenance.

F

Inside trim stop is made of

unﬁ nished pine. Arched trim stops

are made with quality, full-length,

select hardwood laminations.

Units are shipped with the trim

stops tacked on, so removal is

easy — expediting ﬁ nishing and

joining procedures.

G

Unﬁ nished interior wood

glazing stops help secure the

glass in place. Arched glazing

stops are made with full-length

select hardwood laminations.

GLASS

H

High-Performance

™

glass

options include:

•

Low-E4

®

glass

•

Low-E4

®

SmartSun

™

glass

•

Low-E4

®

Sun glass

Tempered glass and other glass

options are available. Contact

your Andersen supplier. (Glass

option must be speciﬁ ed.)

PATTERNED GLASS

Patterned glass options are

available. See page 12 for

more details.

Specialty windows

are available with

Stormwatch

®

protection. For a copy of

the

Andersen

®

Coastal Product Guide

,

contact your Andersen supplier.

* For complete information on our limited warranties, visit andersenwindows.com or contact your Andersen supplier.

Arch Window

C F A G H B A

Naturally occurring variations in grain, color

and texture make each window one-of-a-kind.

White Sandtone Terratone®

Forest Green white pine

Specify a unit exterior option and an interior option to complete your order.

Circle/Oval Window

Flexiframe

®

Window

Springline

™

Window

(3)

CAUTION:

• Painting and staining may cause damage to rigid vinyl. • Products in Sandtone or Terratone®

color may be painted any color lighter than Terratone using quality oil-base or latex paint. Submit color samples to Andersen for approval when painting White. Submit color samples to Andersen for approval when painting Sandtone or Terratone any color darker than Terratone. • Do not paint Forest Green exterior. • Creosote-based stains should not come

in contact with Andersen products. • Do not paint weatherstripping. • Abrasive cleaners or solutions containing

corrosive solvents should not be used on Andersen products.

• For vinyl painting instructions and preparation, contact your Andersen supplier.

• Andersen does not warrant the adhesion of paint to vinyl.

Accessories

Sold Separately.

FRAME

Extension Jambs

Specify extension jambs

when ordering.

Standard unit jamb depth is

2

7

_/

₈

_{", except for elliptical and}

double-hung Circle Top

™

units,

which are 4

1

_/

₂

_".

Pine (or continuous laminated

select hardwood) extension

jambs are available for the

following wall thicknesses:

•

₄

9

_/

16

_"

•

₅

1

_/

4

_"

•

₆

9

_/

16

_"

•

₇

1

_/

8

_"

Some sizes may be pine veneer.

Springline

™

window extension

jambs and transition pieces are

applied when ordered with the

unit (key component block is

also applied to units with a

48" radius).

Auxiliary Extension Jambs

Use auxiliary extension jambs

for joining arch windows over

casement or alongside awning

windows. Available for the

following wall thicknesses:

•

4

9

_/

₁₆

_"

•

5

1

_/

₄

_"

•

6

9

_/

₁₆

_"

•

7

1

_/

₈

_"

* Select hardwoods for specialty window interior arch casing include Hard Maple, Red Maple, European Birch, White Poplar and White Aspen. The speciﬁ c species used will be dependent upon availability.

Interior Arch Casing*

Available in colonial or ranch

styles. Two transition blocks

come with each arch casing.

Arch window casings come with

plinth blocks. The 16' casing

for custom arch comes with two

plinth blocks and a key block.

For details, see the Andersen

Architectural products section of

this catalog, pages 175–218. For

easy integration and consistency,

casing dimensions are consistent

with Wood Moulding and

Millwork Producers Association

speciﬁ cations.

2

1

_/

₄

_{" Colonial style, in oak and}

select hardwoods.

WM

366.

2

1

_/

2

_{" Colonial style, in oak and}

select hardwoods.

WM

351.

3

1

_/

2

" Colonial style, in oak and

select hardwoods.

WM

444.

2

1

_/

4

" Ranch style, in oak and

select hardwoods.

WM

324.

2

1

_/

2

" Ranch style, in select

hardwoods.

WM

315. Plinth Blocks

For enhancing casing transitions.

Decorated with a radial sunburst,

or use the reverse side ﬂ ush face.

For arch windows: 2

7

_/

₈

_{" x 4"}

size for use with 2

1

_/

4

_{" and 2}

1

_/

₂

_"

casing, 3

7

_/

₈

_{" x 5}

1

_/

₄

_{" size for use}

with 3

1

_/

₂

_{" casing.}

For Circle Top,

™

elliptical, circle

and oval windows: 2

7

_/

8

_{" size}

for use with 2

1

_/

₄

_{" and 2}

1

_/

2

"

casing, 3

7

_/

₈

_{" size for use with}

3

1

_/

₂

_{" casing.}

GLASS

Andersen

®

Art Glass

Andersen art glass panels

come in eleven original

patterns, including four

Frank Lloyd Wright

®

Series

designs.

See page 139 for details on

Andersen art glass or visit

andersenwindows.com/artglass

for pattern information.

Key Block

Excellent for creating unique trim

designs or accents at arch casing

transitions. A key block comes

with the 16' custom arch casing,

and is an option for Andersen

circle and oval windows.

Transition Piece

Two transition pieces come

with the interior arch casing

extension jambs, providing

a beautiful accent for circle

and oval windows.

EXTERIOR TRIM

Select Specialty windows are now

available with Andersen Exterior

Trim. Contact your Andersen

supplier for details.

“Frank Lloyd Wright” is a registered trademark of the Frank Lloyd Wright Foundation.

For more information about

glass, patterned glass,

art glass, grilles and

installation accessories,

see pages 12–32 or visit

andersenwindows.com

400 Series Specialty W

indows

(4)

FCCXW3 CTQCW1 CTQCX1 CTQC1 CTQA3 CTCW1 CTCX1 CTC1 CTCXW1 C12, C125, C13, C135, C14, C145, C15, C155, C16, CTR2010, AR21, AN21, A21, AW21, A212, A213 CW12, CW125, CW13, CW135, CW14, CW145, CW15, CW155, CW16, CTR2410, AR251, AN251, A251, AW251, AX251 CX125, CX13, CX135, CX14, CX145, CX15, CX155, CX16, CTR2810, AR281, AN281, A281, AW281, AX281, AXW281 CXW13, CXW135, CXW14, CXW145, CXW15, CXW155, CXW16, P3030, P3035, P3040, P3045, P3050, P3055, P3060, AR31, AN31, A31, AW31, AX31, A335, AP32, A312, A313, PA3050, PA3060, AXW31, AXW312 2' -0 5⁄8 " 2' -0 1⁄8 " 19 1⁄2 " 2' -4 7⁄8 " 2' -4 3⁄8 " 23 3⁄4 " 2' -8 " 2' -7 1⁄2 " 26 7⁄8 " 3' -0 1⁄2 " 2' -1 1 15 ⁄16" 31 5⁄16 "

Table of Circle Top

™

_{, Quarter Round, and Full Chord Window Sizes — Casement/Awning}

Scale

1

_⁄

₈

_{" = 1'-0" (1:96)}

2'-11 15⁄16" 3'-0 1⁄2" 2'-7 1_⁄₂_" 2'-8" Window Dimension 1' -2 7⁄8 " 1' -2 3⁄8 " 9 3⁄4 " 26 7_⁄₈_" Unobstructed Glass 31 5_⁄₁₆_" 2'-4 3⁄8" 2'-4 7⁄8" 2'-0 1⁄8" 2'-0 5⁄8" 23 3_⁄₄_" 19 1_⁄₂_" Minimum Rough Opening 1' -5 " 1' -4 1⁄2 " 11 7⁄8 " 1' -6 1⁄2 " 1' -6 " 13 7⁄16 " 1' -8 3⁄4 " 1' -8 1⁄4 " 15 5⁄8 " 18 3⁄4" 1' -1 7⁄8 " 1' -1 3⁄8 " 8 11 ⁄ 16 " 28 15⁄16" Unobstructed Glass (Full Chord) Radius

Quarter Round Glass Area

Window Number Glass Area

Sq.Ft.

CTQC1 1.9

CTQCW1 3.0

CTQA3 5.2

CTQCX1 3.8

Double-Hung Circle Top

™

Glass Area

Sq.Ft. CTN20 1.1 CTN24 1.6 CTN28 2.2 CTN30 2.8 CTN34 3.6 CTN28-2 10.5 CTN30-2 13.4

Full Chord Glass Area

Sq.Ft. FCD28 0.688 FCD30 0.540 FCD34 1.145 FCD38 0.837 FCCXW3 1.241 FCC2 1.017 FCCW2 2.781 FCFW50 2.571 FCFW60 3.154

t"Window Dimension" always refers to outside frame to frame dimension.

t"Minimum Rough Opening" dimensions may need to be increased to allow for use brackets, fasteners or other items. See page 33 for more details.

FCD34 CTN34 FCD30 CTN30 FCD28 CTN28 CTN24 CTN20 20210, 2032, 2036, 20310, 2042, 2046, 20410, 2052, 2056, 20510, 2062, 2072, 2076 24210, 2432, 2436, 24310, 2442, 2446, 24410, 2452, 2456, 24510, 2462, 2472, 2476 28210, 2832, 2836, 28310, 2842, 2846, 28410, 2852, 2856, 28510, 2862, 2872, 2876 30210, 3032, 3036, 30310, 3042, 3046, 30410, 3052, 3056, 30510, 3062, 3072, 3076 34210, 3432, 3436, 34310, 3442, 3446, 34410, 3452, 3456, 34510, 3462, 3472, 3476

Table of Circle Top

™

_{and Full Chord Window Sizes — Double-Hung}

Scale

1

_⁄

₈

_{" = 1'-0" (1:96)}

3'-1 5⁄8" 3'-2 1⁄8" 2'-9 5⁄8" 2'-10 1⁄8" Window Dimension 1' -3 3⁄4 " 1' -3 3⁄16 " 10 3⁄16 " 28 3⁄8" Unobstructed Glass (Circle Top) 32 3⁄8" 2'-5 5⁄8" 2'-6 1⁄8" 2'-1 5⁄8" 2'-2 1⁄8" 24 3⁄8" 20 3⁄8" Minimum Rough Opening 1' -5 3⁄4 " 1' -5 3⁄16 " 12 3⁄16 " 1' -7 3⁄4 " 1' -7 3⁄16 " 14 3⁄16 " 1' -9 3⁄4 " 1' -9 3⁄16 " 16 3⁄16 " 1' -1 1 3⁄4 " 1' -1 1 3⁄16 " 18 3⁄16 " 3'-5 5⁄8" 3'-6 1⁄8" 36 3⁄8" 11" 10 7⁄16 " 5 3⁄4 " 9 5⁄8 " 9 1⁄8 " 4 3⁄8 " 1' -0 5⁄8 " 1' -0 1⁄16 " 7 5⁄16 " 18 3⁄4" 24" 24" 24 7⁄8" 26 1⁄8" 32 7⁄16" Unobstructed Glass (Full Chord) Radius

Casement Circle Top

™

Glass Area

Sq.Ft. CTC1 1.0 CTCW1 1.5 CTCXW1 2.7 CTC2 5.1 CTCW2 7.3 CTC3 12.3 CTCX1 2.0 CTCX2 9.3

Compatible double-hung,

casement, awning, and picture

windows are shown below

shaped windows.

Divided light patterns shown on

page 124.

(5)

Elliptical Glass Area

Sq.Ft. ET6 4.3 ET8 8.0 FCC2 FCCW2 CTCW2 CTC2 CTCX2 CTC3 CTR4010, CTR22010, C22, C225, C23, C235,C24, C245, C25, C255, AR41, AN41, A41, AW41, AX41, AXW41, AR221,AN221, A221, AW221, AP42V, AP4060, P4030, P4035, P4040, P4045, P4050, P4055, P4060, PTR4010, CTR4810, CTR22410, CW22, CW225, CW23, CW235, CW24, CW245, CW25, CW255, CW26, AR2251, AN2251, A2251, AW2251, AX2251 CTR6010, CRT32010, C32, C325, C33, C335, C34, C345, C35, C355, C36, P6030, P6035, P6040, P6045, P6050, AR61, AN61, A61, AW61, AX61, AXW61, AR321, AN321, A321, AW3231, PTR6010 CTR5210, CTR22810, CX23, CX235, CX24, CX245, CX25, AR2281, AN2281, A2281, AW2281, AX2281, AX2281 2' -2 7⁄8 " 2' -2 5⁄16 " 21 11⁄ 16 " 4'-0" 4'-0 1⁄2" 43 3⁄8" 2' -7 1⁄8 " 2' -6 9⁄16 " 25 15⁄ 16 " 4'-8 1⁄2" 4'-9" 51 7⁄8" 2' -1 0 1⁄8 " 2' -9 5⁄8 " 29" 5'-2 3⁄4" 5'-3 1⁄4" 58 1⁄8" 3' -2 3⁄4 " 3' -2 1⁄4 " 33 5⁄8 " 5'-11 7⁄8" 6'-0 3⁄8" 67 1⁄4" 32 1⁄4" 36" 11 1⁄4 " 10 11⁄ 16 " 6" 1' -2 1⁄4 " 1' -1 11 ⁄16" 9" 35 7⁄8" 47 7⁄8" Unobstructed Glass (Full Chord) Radius

t"Minimum Rough Opening" dimensions may need to be increased to allow for use of building

CTN28-2 CTN30-2 FCD38 28210-2, 2832-2, 2836-2, 28310-2, 2842-2, 2846-2, 28410-2, 2852-2, 2856-2, 28510-2, 2862-2, 2872-2, 2876-2 30210-2, 3032-2, 3036-2, 30310-2, 3042-2, 3046-2, 30410-2, 3052-2, 3056-2, 30510-2, 3062-2, 3072-2, 3076-2 38210, 3832, 3836, 38310, 3842, 3846, 38410, 3852, 3856, 38510, 3862, 3872, 3876 3' -0 1⁄2 " 3' -0 " 31 " 5'-7 5⁄16" 5'-7 7⁄8" 62 1⁄16" 3' -4 1⁄2 " 3' -4 " 34 1⁄4 " 6'-3 5⁄16" 6'-3 7⁄8" 70 1⁄16" 3'-9 5⁄8" 3'-10 1⁄8" 32 5⁄16" 10 " 9 7⁄16 " 4 3⁄4 " 32 1⁄4" Radius

Monumental Quarter Round

and Full Round Glass Area

Sq.Ft.

QR40 9.905

FR40 10.217

FR60 24.690

Circle & Oval Glass Area

Sq.Ft. CIR20 2.1 CIR24 3.0 CIR30 5.2 OVL1824 1.9 OVL2030 3.2 OVL3048 8.7

Gothic & Octagon Glass Area

Sq.Ft. GT2036 4.008 GT2440 5.841 GT3046 8.783 GT4056 14.877 OC20 2.138 OC24 3.118 OC30 5.629

Compatible double-hung, casement, awning, and picture windows are shown below shaped windows. Divided light patterns shown on page 124.

400 Series Specialty W

(6)

ET8

ET6

FWG6068, FWG60611, FWG6080,

FWH6068, FWH60611, FWH6080,

FWO6068, FWO60611, FWO6080,

NLGD6068, NLGD60611, NLGD6080,

ISID6068, ISID60611, ISID6076,

ISID6080

FWG8068, FWG80611, FWG8080,

FWH8068, FWH80611, FWH8080,

NLGD8068, NLGD80611, NLGD8080

Table of Elliptical Window Sizes — Patio Doors

Scale

1

_⁄

₈

_{" = 1'-0" (1:96)}

Window Dimension 1' -5 3⁄8 " 1' -4 3⁄4 " 11 7⁄8 " Unobstructed Glass 7'-11 1_⁄₄_" 8'-0" 5'-11 1_⁄₄_" 6'-0" 90 1⁄4" 66 1⁄4" Minimum Rough Opening 1' -9 5⁄8 " 1' -9 " 16 1⁄8 "

t"Minimum Rough Opening" dimensions may need to be increased to allow for use brackets, fasteners or other items. See page 33 for more details.

Compatible patio doors are

shown below shaped windows.

Divided light patterns shown

below.

FCFW60

FCFW50

FWG5068, FWG50611, FWG5080,

FWH5068, FWH50611, FWH5080,

FWO5068, FWO50611, FWO5080,

NLGD5068, NLGD50611, NLGD5080,

PS5068, ISPD5068, ISPD50611,

ISPD5076, ISPD5080

FWG6068, FWG60611, FWG6080,

FWH6068, FWH60611, FWH6080,

FWO6068, FWO60611, FWO6080,

NLGD6068, NLGD60611, NLGD6080,

ISPD6068, ISPD60611, ISPD6076,

ISPD6080

Table of Full Chord Window Sizes — Patio Doors

Scale

1

_⁄

₈

_{" = 1'-0" (1:96)}

36" 48" Window Dimension 1' -4 1⁄8 " 1' -3 9⁄16 " 10 13 ⁄16" Unobstructed Glass Radius 5'-11 1⁄4" 5'-11 3⁄4" 4'-11 1⁄4" 4'-11 3⁄4" 59 11⁄16" 49 7⁄16" Minimum Rough Opening 1' -4 3⁄8 " 13 13 ⁄ 16 " 11 1⁄8 "

Circle Top™_& Quarter Round Elliptical Monumental Quarter Round Monumental Circle Renaissance Colonial Full Chord Circle Oval Gothic Octagon

Divided Light Patterns

t s r u b n u S e c n a s s i a n e R

Custom Pattern Examples

Number of lights and overall pattern varies with window size.

Specialty window patterns may not align with picture windows

patterns when horizontally joined.

For more information on divided light see page 13 or visit

andersenwindows.com/grilles.

(7)

FR60

FR40

QR40

Table of Monumental Quarter & Full Round Window Sizes

Scale

1

_⁄

₈

_{" = 1'-0" (1:96)}

6'-0" 6'-0 1⁄2" Window Dimension 67 5⁄16" Unobstructed Glass Radius 4'-0" 4'-0 1⁄2" 4'-0" 4'-0 1⁄2" 43 5⁄16" 43 1⁄4" Minimum Rough Opening 36" 24" 48" OC24 OC30 OC20

Table of Octagon Window Sizes

Scale

1

_⁄

₈

_{" = 1'-0" (1:96)}

3'-0" 3'-0 1⁄2" Window Dimension 31 5⁄16" Unobstructed Glass 2'-4" 2'-4 1⁄2" 2'-0" 2'-0 1⁄2" 23 5⁄16" 19 5⁄16" Minimum Rough Opening GT2036 GT2440 GT3046 GT4056

Table of Gothic Window Sizes

Scale

1

_⁄

₈

_{" = 1'-0" (1:96)}

Window Dimension Unobstructed Glass Radius 2'-0 1⁄8" 2'-0 5⁄8" 19 7⁄16" Minimum Rough Opening 2'-4 3⁄8" 2'-4 7⁄8" 23 11⁄16" 2'-11 15⁄16" 3'-0 1⁄2" 31 1⁄4" 4'-0" 4'-0 1⁄2" 43 5⁄16" Chord Height 3' -6 " 3' -6 1⁄2 " 36 9⁄16 " 16 27⁄ 32 " Shoulder Height 32 1⁄4 " 4' -0 " 4' -0 1⁄2 " 42 3⁄4 " 21 9⁄32 "3 2 1⁄4 " 4' -6 " 4' -6 1⁄2 " 48 7⁄8 " 22 27 ⁄ 32 " 36 " 5'-6 " 5'-6 1⁄2 " 60 7⁄8 " 24 7⁄16 " 48 " 32 1⁄4" 32 1⁄4" 36" 48" OVL2030 OVL3048 OVL1824

Table of Oval Window Sizes

Scale

1

_⁄

₈

_{" = 1'-0" (1:96)}

3'-0" 3'-0 1⁄2" Window Dimension 2' -4 7⁄8 " 2' -4 3⁄8 " 24 " 31 3⁄8" Unobstructed Glass 2'-0" 2'-0 1⁄2" 1'-7 3⁄4" 1'-8 1⁄4" 19 3⁄8" 15 3⁄8" Minimum Rough Opening 3' -0 1⁄2 " 2' -1 1 15 ⁄ 16 " 31 9⁄16 " 4' -9 " 4' -8 1⁄2 " 52 1⁄8 " Key Block Dowel Key Component

Oval windows can be installed

either vertically or horizontally.

Circle, oval, gothic, octagon and monumental

glass area tables shown on page 123.

Divided light patterns shown on page 124.

• "Window Dimension" always refers to outside frame to frame dimension.

• "Minimum Rough Opening" dimensions may need to be increased to allow for use of building wraps, flashing, sill panning, brackets, fasteners or other items. See page 33 for more details.

Typical Andersen

®

_{key block kit installation.}

OVL1824

CIR24 CIR30

CIR20

Table of Circle Window Sizes

Scale

1

_⁄

₈

_{" = 1'-0" (1:96)}

2'-11 15⁄16" 3'-0 1⁄2" Window Dimension 31 9_⁄₁₆_" Unobstructed Glass 2'-4 3⁄8" 2'-4 7⁄8" 2'-0 1⁄8" 2'-0 5⁄8" 24" 19 3_⁄₄_" Minimum Rough Opening

400 Series Specialty W

indows

(8)

Unit Dimension Height

Min.

Rough Opening Height

Head

Sill

1⁄4" (6) Unit Dimension Width 1⁄4" (6)

Minimum Rough Opening Width

Jamb Jamb

Min. Rough Opening Height

Head

Sill

Flexible Drip Cap by Others

Unit Dimension Width Min. Rough Opening Width

1⁄4" (6) 1⁄4" (6)

Jamb Jamb

Head

Sill

1⁄4" (6) 1⁄4" (6) Jamb Jamb 2 5⁄8" (67) 2 3⁄8" (60) 4 1⁄2" (114) 1 5⁄16" (33)

Min. Rough Opening Height Unit Dimension Height

Head Sill Head Sill 2 1⁄8" (54)

Andersen® Extension Jambs 4 9_⁄₁₆_{" (116)} Jamb Width 1 5⁄16" (33) 2 1⁄4" (57)

Andersen® Extension Jambs Head Sill 4 9⁄16" (116) Jamb Width 1 5⁄16" (33) 2 1⁄4" (57) 2 1⁄4" (57)

Double-Hung Circle Top

™

Window Detail

Scale 1

1

_⁄

₂

_{" = 1'-0" (1:8)}

Gothic Window Details

Scale 1

1

_⁄

₂

_{" = 1'-0" (1:8)}

Casement/Awning Quarter Round

Window Detail

Scale 1

1

_⁄

₂

_{" = 1'-0" (1:8)}

• 4 9_/₁₆_{" jamb width measurement is from backside of installation flange.}

• Light-colored areas are parts included with window. Dark-colored areas are additional Andersen®_{parts required to complete window assembly as shown.}

• Rough openings may need to be increased to allow for use of building wraps, flashing, sill panning, brackets, fasteners or other items. See installation information on page 33.

• Details are for illustration only and are not intended to represent product installation methods or materials. Refer to product installation guides at andersenwindows.com.

Full Chord Window Details

Scale 1

1

_⁄

₂

_{" = 1'-0" (1:8)}

Octagon Window Details

Scale 1

1

_⁄

₂

_{" = 1'-0" (1:8)}

Casement/Awning Circle Top

™

Window Detail

Scale 1

1

_⁄

₂

_{" = 1'-0" (1:8)}

Vertical Section Vertical Section Vertical Section

(9)

Head

Sill

1⁄4" (6) 1⁄4" (6)

Jamb Jamb

Head

Sill

1⁄4" (6) 1⁄4" (6) Jamb Jamb 4 9⁄16" (116) Jamb Width 1 5⁄16" (33)

Minimum Rough Opening Height

Head Sill Andersen Key Block Standard Andersen Transition Block Andersen Extension Jambs and Transition Pieces Andersen Interior Arch Casing and Transition Pieces

4 9⁄16" (116) Jamb Width 1 5⁄16"

(33)

Head Sill Andersen Key Block Standard Andersen Transition Block Andersen Extension Jambs and Transition Pieces Andersen Interior Arch Casing and Transition Pieces 4 1⁄2" (114)

Head Sill 2 1⁄2" (64) 2" (51) 1 5⁄16" (33)

Circle Window Detail

Scale 1

1

_⁄

₂

_{" = 1'-0" (1:8)}

• 4 9_/

16" jamb width measurement is from backside of installation flange.

Elliptical Window Detail

Scale 1

1

_⁄

₂

_{" = 1'-0" (1:8)}

Monumental Quarter Round Window Details

Scale 1

1

_⁄

₂

_{" = 1'-0" (1:8)}

Monumental Full Round Window Details

Scale 1

1

_⁄

₂

_{" = 1'-0" (1:8)}

Oval Window Detail

Scale 1

1

_⁄

₂

_{" = 1'-0" (1:8)}

Vertical Section Vertical Section Vertical Section

Vertical Section Vertical Section

Horizontal Section Horizontal Section

400 Series Specialty W

(10)

Unit Dim. Unit Dim. 1⁄8" (3) 2 2 (73)7⁄8" 4 ₍₁₂₄₎7⁄8" 5⁄8" (67) Unit Dim. Unit Dim. Unit Dim. Unit Dim. 4 7⁄8" (124) -3⁄8" (-10) Unit Dim. 1⁄8" (3) 8 1⁄4" (210) Unit Dimension Unit Dim. 3⁄8" (10) 8 7⁄16" (214) Unit Dimension Unit Dim. 3⁄8" (10) ₆3⁄4" (171) Unit Dimension

• Consult with an architect or structural engineer regarding minimum requirements for structural support members between adjacent rough openings.

Vertical Section

Horizontal (stack) Non-Reinforced Joining Details

Scale 1

1

_⁄

₂

_{" = 1'-0" (1:8)}

Casement Circle Top

™

_{over Casement Window}

Overall Window Dimension Height

Sum of individual window heights plus

1

_⁄

₈

_{" for each join.}

Overall Rough Opening Height

Overall window dimension height plus

5

_⁄

₈

_".

Double-Hung Circle Top

™

_{over Tilt-Wash Double-Hung Window}

Overall Window Dimension Height

Sum of individual window heights plus 0" for each join.

Overall Rough Opening Height

Overall window dimension height plus

3

_⁄

₈

_".

Double-Hung Circle Top

™

_{over Narroline}

®

_{Double-Hung Window}

Overall Window Dimension Height

Sum of individual window heights minus

3

_⁄

₈

_{" for each join.}

Overall Rough Opening Height

Overall window dimension height minus

5

_⁄

₁₆

_".

Elliptical Window

over Frenchwood

®

_{Hinged Inswing Patio Door}

Overall Unit Dimension Height

Sum of individual unit heights plus

1

_⁄

₈

_".

Overall Rough Opening Height

Overall unit dimension height plus 1".

Elliptical Window

over Frenchwood

®

_{Gliding Patio Door}

Overall Unit Dimension Height

Sum of individual unit heights plus

3

_⁄

₈

_".

Overall Rough Opening Height

Overall unit dimension height plus

5

_⁄

₈

_".

Elliptical Window

over Perma-Shield

®

_{Gliding Patio Door}

Overall Unit Dimension Height

Sum of individual unit heights plus

3

_⁄

₈

_".

Overall Rough Opening Height

Overall unit dimension height plus

5

_⁄

₈

_".

Vertical Section

(11)

Andersen offers even greater design flexibility with

custom-dimensioned arches, unequal leg arches and partial chords along with

expanded arch capabilites to achieve Springline

™

_{window expressions.}

Custom arch windows can be designed using one of 10 standard

radii, further expanding the existing line of 90 standard sizes of

Andersen

arch windows.

Custom arch shapes and sizes are specially constructed to be used

in combination with other Andersen

®

_{windows including casement,}

awning, double-hung, gliding and Flexiframe

®

_{windows and hinged or}

gliding patio doors.

Color coordinate with any project. Arches are available in White,

Sandtone, Terratone

®

and Forest Green colors. Andersen divided

light is available for most styles and sizes. Contact your supplier for

availability.

Standard Radii for Custom Arch

Maximum Width for Equal Leg Arch.

1 2 3 4 7 6 5 18 3⁄4"R (3'-0 3⁄4") 3'R (5'-11 1_⁄₄₎ 4'R (7'-11 1⁄4") 5'R (5'-0") 6'R (6'-0 5⁄8") 8'R (8'-0 1⁄8") 16'R (12') 32 1⁄4"R (5'-3 3⁄4") 18 3_⁄4"R 32 1_⁄4"R 34 1_⁄4"R 2'R 3'R 4'R 5'R 6'R 8'R 16'R 1 2 3 4 5 6 7 FEET 34 1_⁄₄_"_R_(5'-73_⁄₄_") 2'R (3'-11 1⁄4")

• Do all calculations in inches to 3 decimal places

• Order extension jambs along with windows for correct sizing

• Design windload considerations may affect spacing dimensions and patterns

• All units are stationary

• Maximum standard glass area of 60 sq. ft.

• Ten standard radii (18

3

_⁄

₄

_{", 2', 32}

1

_⁄

₄

_{", 34}

1

_⁄

₄

_{", 3', 4', 5', 6', 8' and 16')}

• Maximum radii

(based on available radius piece length, contact supplier for specific information)

• Maximum equal leg width (36

3

_/

_{4" for 18}3

_/

_{4" radius to 12' for 16' radius)}

• Maximum unequal leg width

(18

3

_/

₄

_{" for 18}

3

_/

₄

_{" radius to 11'-2" for 16' radius)}

• Maximum partial chord width

(18

3

_/

₄

_{" for 18}

3

_/

₄

_{" radius to 11'-5}

1

_/

₂

_{" for 16' radius)}

• Only one dimension, height or width, can exceed 7'-0"

• No height dimension greater than 12'-0"

• No leg dimension less than 6"

Listed below are some factors that must be considered when

deciding on a custom arch size and shape. For specific design

criteria, joining guidelines and order information, contact your

Andersen supplier.

Custom Arch Windows

Design Criteria

Arch Unequal Leg Arch Partial Chord

Springline™_{Window Expressions}

16' Radius for Combinations

Colonial Renassiance

400 Series Specialty W

(12)

AFCP3045

AFCW145 AFC245 AFCW245 AFFW5045 AFFW6045

AFC145

AFC13 AFCW13 AFCP303 AFC23 AFCW2 AFFW503 AFFW603

AFCP304

AFC14 AFFW6006 AFFW5006 AFCW206 AFC206 AFCP3006 AFCW106 AFC106

AFCP3035

AFC135

AFCP305

AFC15

AFC155 AFC255 AFCW255 AFFW5055 AFFW6055

AFCW155 AFCP3055

Table of Archtop Window Sizes

Scale

1

_⁄

₈

_{" = 1'-0" (1:96)}

5'-11 1⁄4" 5'-11 3⁄4" 4'-0" 4'-0 1⁄2" 4'-8 1⁄2" 4'-9" 2'-11 15⁄16" 3'-0 1⁄2"

Window Width Dimension 4'-11 1⁄4"

4'-11 3⁄4" 66 1⁄2" 31 3⁄16" Unobstructed Glass 43 1⁄4" 51 3⁄4" 54 1⁄2" 2'-4 3⁄8" 2'-4 7⁄8" 2'-0 1⁄8" 2'-0 5⁄8" 23 5⁄8" 19 3⁄8" Minimum Rough Opening

CUSTOM SIZES AVAILALBLE

CUST OM SIZES A V A IL A LB LE 2' 2' 3' 4' 5' 5' 6' 3 1⁄4 " 4 13 ⁄ 16 " 4 21 ⁄ 32 " 6 7⁄16 " 7 1⁄16 " 7 13 ⁄ 16 " 9 7⁄16 " 6" Shoulder Height 2' -0 1⁄8 " 2' -1 1 15 ⁄ 16 " 3' -4 13 ⁄ 16 " 4' -0 " 4' -4 13 ⁄ 16 " Radius Chord Height

Minimum Rough Opening = window height +

1⁄2 " 9 1⁄4 " 10 13 ⁄ 16 " 10 21 ⁄ 32 "

Unobstructed Glass = window height

– 4 3⁄4 " 1' -0 7⁄16 " 1' -1 1⁄16 " 1' -1 13 ⁄ 16 " 1' -3 7⁄16 " 2' -3 3⁄8 " 2' -4 15 ⁄ 16 " 2' -4 25 ⁄ 32 " 2' -6 9⁄16 " 2' -7 3⁄16 " 2' -7 15⁄ 16 " 2' -9 9⁄16 " Window height shown in table 3' -3 3⁄16 " 3' -4 3⁄4 " 3' -4 19⁄ 32 " 3' -6 3⁄8 " 3' -7 " 3' -7 3⁄4 " 3' -9 3⁄8 " 3' -8 1⁄16 " 3' -9 5⁄8 " 3' -9 15 ⁄ 32 " 3' -1 1 1⁄4 " 3' -1 1 7⁄8 " 4' -0 5⁄8 " 4' -2 1⁄4 " 4' -4 1⁄4 " 4' -4 13⁄ 16 " 4' -4 21 ⁄ 32 " 4' -6 7⁄16 " 4' -7 1⁄16 " 4' -7 13 ⁄ 16 " 4' -9 7⁄16 " 4' -8 1⁄16 " 4' -9 5⁄8 " 4' -9 15⁄ 16 " 4' -1 1 15 ⁄ 32 " 4' -1 1 1⁄4 " 5'-0 5⁄8 " 5'-2 1⁄4 " 12 " 1' -3 1⁄4 " 1' -4 13 ⁄ 16 " 1' -4 21 ⁄ 32 " 1' -6 7⁄16 " 1' -7 1⁄16 " 1' -7 13 ⁄ 16 " 1' -9 7⁄16 " 4' -1 1 7⁄8 " 5'-4 13 ⁄ 16 " 5'-8 1⁄16 " 5'-9 5⁄8 " 5'-9 15 ⁄ 32 " 5'-11 1⁄4 " 5'-11 7⁄8 " 6' -0 5⁄8 " 6' -2 1⁄4 " 5'-11 7⁄8 " 6' -3 1⁄8 " 6' -4 11⁄ 16 " 6' -4 17⁄ 32 " 6' -6 5⁄16 " 6' -6 15 ⁄16" 6' -7 11 ⁄ 16 " 6' -9 5⁄16 " 8' -3 3⁄8 " 8' -0 1⁄8 " 8' -4 15⁄ 16 " 8' -4 25 ⁄ 32 " 8' -6 9⁄16 " 8' -7 3⁄16 " 8' -7 15 ⁄ 16 " 8' -9 9⁄16 " 5'-3 1⁄8 " 5'-4 11 ⁄ 16 " 5'-4 17⁄ 32 " 5'-6 5⁄16 " 5'-6 15⁄ 16 " 5'-7 11 ⁄ 16 " 5'-9 5⁄16 "

(13)

AFFW8045 AFFW803 AFFW804 AFFW8006 AFFW12006 AFFW802 AFFW1202 AFFW8035 AFFW801 AFFW1201 AFFW805 AFFW8055* AFFW806* 11'-9" 11'-9 1⁄2" 7'-11 1⁄8" 7'-11 5⁄8" 136 1⁄4" 90 3⁄8" 8' 16' 12 5⁄8 " 13 13 ⁄ 32 " 1' -6 5⁄8 " 1' -7 13⁄ 32 " 3' -0 3⁄4 " 3' -1 17⁄ 32 " 4' -0 9⁄16 " 4' -5 7⁄16 " 5'-0 5⁄8 " 5'-5 7⁄16 " 2' -0 5⁄8 " 2' -1 13⁄ 32 " 6' -5 7⁄16 " 7' -0 1⁄2 " 6' -0 1⁄2 "

*Tempered glass standard.

• "Minimum Rough Opening" dimensions may need to be increased to allow for use of building wraps, flashing, sill panning, brackets, fasteners or other items. See installation information on page 33.

Custom-size windows are

available in

1

_⁄

₈

_{" increments.}

Divided light patterns

shown on page 134.

Archtop Window Glass Area

Window Number Glass Area Sq. Ft. Overall Window Area Sq. Ft. AFC106 9 3_/ 4" 0.7 AFC11 1'-3 3_/₄_" _1.6 AFC12 2'-3 7_/ 8" 3.4 AFC13 3'-3 3_/₄_" _5.1 AFC135 3'-8 5_/ 8" 5.8 AFC14 4'-3 3_/₄_" _6.8 AFC145 4'-8 5_/ 8" 7.5 AFC15 5'-3 5_/ 8" 8.5 AFC155 5'-8 5_/₈_" _9.2 AFC16 6'-3 5_/ 8" 10.3 AFC18 8'-3 7_/₈_" _13.8 AFCW106 11 1_/ 4" 1.1 AFCW11 1'-5 1_/₄_" _2.1 AFCW12 2'-5 3_/ 8" 4.2 AFCW13 3'-5 1_/₈_" _6.3 AFCW135 3'-10" 7.1 AFCW14 4'-5 1_/₄_" _8.4 AFCW145 4'-10" 9.2 AFCW15 5'-5 1_/ 8" 10.4 AFCW155 5'-10" 11.3 AFCW16 6'-5 1_/ 8" 12.5 AFCW18 8'-5 3_/₈_" _16.8 AFCP3006 11 3_/ 8" 1.4 AFCP301 1'-5 3_/₈_" _2.8 AFCP302 2'-5 1_/ 2" 5.5 AFCP303 3'-5 1_/₄_" _8.2 AFCP3035 3'-10 1_/₈_" _9.3 AFCP304 4'-5 3_/ 8" 10.9 AFCP3045 4'-10 1_/₈_" _12.0 AFCP305 5'-5 1_/ 4" 13.6 AFCP3055 5'-10 1_/₈_" _14.7 AFCP306 6'-5 1_/ 4" 16.3 AFCP308 8'-5 1_/₂_" _21.8 AFC206 1'-1" 2.2 AFC21 1'-7" 4.1 AFC22 2'-7 1_/ 8" 7.8 AFC23 3'-6 7_/ 8" 11.5 AFC235 3'-11 3_/₄_" _13.0 AFC24 4'-7" 15.2 AFC245 4'-11 3_/₄_" _16.7 AFC25 5'-6 7_/ 8" 18.9 AFC255 5'-11 3_/₄_" _20.4 AFC26 6'-6 7_/ 8" 22.6 AFC28 8'-7 1_/₈_" _30.2 AFCW206 1'-1 5_/ 8" 2.8

Archtop Window Glass Area

Window Number Glass Area Sq. Ft. Overall Window Area Sq. Ft. AFCW21 1'-7 5_/ 8" 5.1 AFCW22 2'-7 3_/₄_" _9.5 AFCW23 3'-7 1_/ 2" 13.9 AFCW235 4'-0 3_/₈_" _15.7 AFCW24 4'-7 5_/ 8" 18.3 AFCW245 5'-0 3_/₈_" _20.1 AFCW25 5'-7 1_/ 2" 22.7 AFCW255 6'-0 3_/ 8" 24.6 AFCW26 6'-7 1_/₂_" _27.2 AFCW28 8'-7 3_/ 4" 36.1 AFFW5006 1'-2 3_/₈_" _3.2 AFFW501 1'-8 3_/ 8" 5.5 AFFW502 2'-8 1_/₂_" _10.3 AFFW503 3'-8 1_/ 4" 14.8 AFFW5035 4'-1 1_/₈_" _16.7 AFFW504 4'-8 3_/ 8" 19.5 AFFW5045 5'-1 1_/₈_" _21.4 AFFW505 5'-8 1_/₄_" _24.1 AFFW5055 6'-1 1_/ 8" 26.1 AFFW506 6'-8 1_/₄_" _28.8 AFFW508 8'-8 1_/ 2" 38.2 AFFW6006 1'-4" 4.4 AFFW601 1'-10" 7.2 AFFW602 2'-10 1_/₈_" _12.9 AFFW603 3'-9 7_/ 8" 18.5 AFFW6035 4'-2 3_/₄_" _20.8 AFFW604 4'-10" 24.2 AFFW6045 5'-2 3_/ 4" 26.5 AFFW605 5'-9 7_/₈_" _29.8 AFFW6055 6'-2 3_/ 4" 32.1 AFFW606 6'-9 7_/₈_" _35.5 AFFW608 8'-10 1_/ 8" 46.9 AFFW8006 1'-7 1_/₈_" _7.3 AFFW801 2'-1 1_/ 8" 11.1 AFFW802 3'-1 1_/₄_" _18.8 AFFW803 4'-1 1_/ 8" 26.4 AFFW8035 4'-6" 29.5 AFFW804 5'-1 1_/₈_" _34.1 AFFW8045 5'-6" 37.1 AFFW805 6'-1" 41.6 AFFW8055 6'-6" 44.8 AFFW806 7'-1" 49.3 AFFW12006 1'-8 1_/ 8" 9.9 AFFW1201 2'-2 1_/₈_" _15.6 AFFW1202 3'-2 1_/ 4" 27.1

400 Series Specialty W

indows

(14)

SE3145 SE315 SE3135 SE314 SE313 SE312 SE3106 SE311 SE6035 SE604 SE6045 SE605* SE6006 SE601 SE602 SE603 SE545 SE5445 SE544 SE5435 SE543 SE542 SE541 SE5406 SE585 SE5845 SE584 SE5835 SE583 SE582 SE581 SE5806 ELFW602 ELFW6006 ELFW601 SP4045 SP4035 SP402 SP403 SP404 SP405

Table of Springline

™

_Sizes

Scale

1

_⁄

₈

_{" = 1'-0" (1:96)}

5'-8 1⁄2" 5'-9" 6'-0" 6'-0 1⁄2" 5'-4 1⁄2" 5'-5" Window Width Dimension

59 3⁄4" Unobstructed Glass 63 3⁄4" 67 1⁄4" 4'-0" 4'-0 1⁄2" 3'-1 1⁄2" 3'-2" 43 1⁄4" 32 3⁄4" Minimum Rough Opening

CUSTOM SIZES AVAILABLE

CUST OM SIZES A VAILABLE 18 3⁄4" 24" 32 1⁄4" 34 1⁄4" 36" 18 3⁄4" 24" 32 1⁄4" 34 1⁄4" 36" 6" Shoulder Height 2' -0 1⁄8 " 2' -1 1 15⁄ 16 " 3' -4 13 ⁄ 16 " 4' -0 " Radius Chord Height M in im u m R o u g h O p e n in g = w in d o w h e ig h t + 1⁄ 2 " 2' -0 3⁄4 " Unob st ruc te d Glas s = w indow heig h t – 4 3⁄4 " 3' -6 7⁄8 " Window height shown in table 4' -6 11 ⁄ 16 " 4' -1 1 9⁄16 " 5'-6 3⁄4 " 12 " _2'-6 3⁄4 " 4' -4 13 ⁄16" 5'-1 0 3⁄4 " 4' -1 1 7⁄8 " 6' -5 3⁄4 " 4' -0 1⁄8 " 4' -1 1 15 ⁄ 16 " 5'-4 13 ⁄16" 6' -0 " 6' -4 " 6' -1 1" 3' -2 1⁄4 " 4' -8 3⁄8 " 5'-8 3⁄16 " 6' -1 1⁄16 " 6' -8 1⁄4 " 3' -8 1⁄4 " 7' -0 1⁄4 " 7' -7 1⁄4 " 3' -4 1⁄4 " 4' -1 0 3⁄8 " 5'-1 0 3⁄16 " 6' -3 1⁄16 " 6' -1 0 1⁄4 " 3' -1 0 1⁄4 " 7' -2 1⁄4 " 7' -9 1⁄4 " 3' -6 " 5'-0 1⁄8 " 5'-11 15 ⁄16" 6' -4 13 ⁄ 16 " 7' -0 " 4' -0 " 7' -4 " 7' -1 1" 30 13⁄16" 5'-11 1⁄4" 5'-11 3⁄4" 66 1⁄2" 3' -0 13 ⁄ 16 " 3' -6 13 ⁄ 16 " 4' -6 15 ⁄ 16 " 30 13⁄16"

Notes on the next

page also apply to

this page.

Additional heights

on page 134.

(15)

400 SERIES

• "Minimum Rough Opening" dimensions may need to be increased to allow for use of building wraps, flashing, sill panning, brackets, fasteners or other items. See installation information on page 33.

Custom-size windows are

available in

1

_⁄

₈

_{" increments.}

Extension jambs are

available factory-applied

when ordered at the

same time as Springline

™

windows.

Divided light patterns

shown on page 134.

Springline

™

_{Window Glass Area}

Window Number Glass Area Sq. Ft. Overall Window Area Sq. Ft. SE3106 2'-1 1_/ 4" 3.74 SE311 2'-7 1_/₄_" _5.10 SE312 3'-7 3_/ 8" 7.86 SE313 4'-7 1_/₄_" _10.54 SE3135 5'-0 1_/₈_" _11.65 SE314 5'-7 1_/ 4" 13.28 SE3145 6'-0 1_/₈_" _14.38 SE315 6'-7 1_/ 8" 15.98 SE3155 7'-0 1_/₈_" _17.10 SE316 7'-7 1_/ 8" 18.71 SE5406 3'-2 3_/₄_" _11.22 SE541 3'-8 3_/ 4" 13.71 SE542 4'-8 7_/₈_" _18.74 SE543 5'-8 3_/ 4" 23.64 SE5435 6'-1 5_/ 8" 25.66 SE544 6'-8 3_/₄_" _28.64 SE5445 7'-1 5_/ 8" 30.64 SE545 7'-8 5_/₈_" _33.57 SE5455 8'-1 5_/ 8" 35.61 SE546 8'-8 5_/₈_" _38.54 SE5806 3'-4 3_/ 4" 12.67 SE581 3'-10 3_/₄_" _15.33 SE582 4'-10 7_/ 8" 20.69 SE583 5'-10 3_/ 4" 25.92 SE5835 6'-3 5_/₈_" _28.08 SE584 6'-10 3_/ 4" 31.26 SE5845 7'-3 5_/₈_" _33.39 SE585 7'-10 5_/ 8" 36.51 SE5855 8'-3 5_/₈_" _38.70 SE586 8'-10 5_/ 8" 41.82 SE6006 3'-6 1_/₂_" _14.01 SE601 4'-0 1_/ 2" 16.81 SE602 5'-0 5_/₈_" _22.47 SE603 6'-0 1_/₂_" _27.98 SE6035 6'-5 3_/ 8" 30.26 SE604 7'-0 1_/₂_" _33.61 SE6045 7'-5 3_/ 8" 35.86 SE605 8'-0 3_/₈_" _39.16 SE6055 8'-5 3_/ 8" 41.46 SE606 9'-0 3_/₈_" _44.76 SP402 4'-0 5_/ 8" 11.62 SP403 5'-0 1_/₂_" _15.16 SP4035 5'-5 3_/₈_" _16.63 SP404 6'-0 1_/ 2" 18.78 SP4045 6'-5 3_/₈_" _20.23 SP405 7'-0 3_/ 8" 22.35 SP4055 7'-5 3_/₈_" _23.83 SP406 8'-0 3_/ 8" 25.95 SP8006 4'-6 1_/₂_" _24.98 SP801 5'-0 1_/ 2" 24.98 SP802 6'-0 5_/₈_" _36.46 ELFW6006 3'-1 3_/ 8" 11.58 ELFW601 3'-7 3_/ 8" 14.35 ELFW602 4'-7 1_/₂_" _19.95 ELFW8006 4'-0 1_/ 8" 20.88 ELFW801 4'-6 1_/₈_" _24.64 ELFW802 5'-6 1_/ 4" 32.25 SP802 SP8006 SP801 ELFW802 ELFW8006 ELFW801 48" 48" 8'-0" 8'-0 1⁄2" 91 1⁄4" 4' -6 " 6' -0 1⁄8 " 5'-0 " 7'-11 1⁄8" 7'-11 5⁄8" 90 3⁄8" 3' -1 1 9⁄16 " 5'-5 11⁄ 16 " 4' -5 9⁄16 " 41 9⁄16" 41 9⁄16"

400 Series Specialty W

indows

(16)

SE316 SE3155 SE6055* SE606* SE546* SE5455 SE586* SE5855* SP4055 SP406

Table of Springline

™

_{Window Sizes}

Scale

1

_⁄

₈

_{" = 1'-0" (1:96)}

5'-8 1⁄2" 5'-9" 6'-0" 6'-0 1⁄2" 5'-4 1⁄2" 5'-5" Window Width Dimension

59 3⁄4" Unobstructed Glass 63 3⁄4" 67 1⁄4" 4'-0" 4'-0 1⁄2" 3'-1 1⁄2" 3'-2" 43 1⁄4" 32 3⁄4" Minimum Rough Opening

CUSTOM SIZES AVAILABLE

CUST OM SIZES A VAILABLE 18 3⁄4" 24" 32 1⁄4" 34 1⁄4" 36" 18 3_⁄₄_" _24" ₃₂1⁄4" 34 1⁄4" 36" Shoulder Height Radius Chord Height M in im u m R o u g h O p e n in g = w in d o w h e ig h t + 1⁄ 2 " Unob st ruc te d Glas s = w indow heig h t – 4 3⁄4 " Window height shown in table 5'-4 13 ⁄ 16 " 6' -1 0 3⁄4 " 5'-11 7⁄8 " 7' -5 3⁄4 " 7' -4 " 7' -1 1" 8' -0 1⁄4 " 8' -7 1⁄4 " 8' -2 1⁄4 " 8' -9 1⁄4 " 8' -4 " 8' -1 1"

Table is continued

from page 132.

*Tempered glass standard.

• "Minimum Rough Opening" dimensions may need to be increased to allow for use of building wraps, flashing, sill panning, brackets, fasteners or other items. See installation information on page 33.

Number of lights and overall pattern varies with window size.

Patterns are not available in all configurations.

Specified equal light and custom patterns are also available.

For more information on divided light see page 13 or visit

andersenwindows.com/grilles.

Custom Pattern Examples

Colonial Renaissance Sunburst

Archtop

Springline™

Springline™ Flanker

Divided Light Patterns

(continued)

Extension jambs are available factory-applied when

ordered at the same time as Springline

™

_windows.

Divided light patterns shown below.

Custom-size

windows are

available in

1

_⁄

₈

_"

increments.

(17)

1⁄4" (6) Unit Dimension Width 1⁄4" (6) Minimum Rough Opening Width

Jamb Jamb

Head Sill Andersen® Arch Casing and Extension Jambs Flexible Drip Cap by Others

Head

Sill

1⁄4" (6) 1⁄4" (6)

Jamb Jamb

Springline

™

_{Window Details}

Scale 1

1

_⁄

₂

_{" = 1'-0" (1:8)}

• "Minimum Rough Opening" dimensions may need to be increased to allow for use of building wraps, flashing, sill panning, brackets, fasteners or other items. See installation information on page 33.

To order Springline

™

_{flanker windows}

contact your Andersen supplier.

Custom window dimensions shown in table

are compatible with standard casement

window widths (CR, CN, C, CW, CXW) and

heights (C3, C4, C5, C6).

Divided light patterns shown on page 134.

Examples:

SFL CR6 CR12 SP406 A41 SFR CR6 CR12 CR13 CR13 SFL SFR CXW6 CXW6 AXW31 AXW31 CR13 CR13

Archtop Window Details

Scale 1

1

_⁄

₂

_{" = 1'-0" (1:8)}

CR CN C3 C35 C4 C5 C6 C CW CXW

Table of

Springline

™

_Flanker

_{Window Sizes}

Scale

1

_⁄

₈

_{" = 1'-0" (1:96)}

2'-11 15⁄16" 3'-0 1⁄2" 2'-0 1⁄8" 2'-0 5⁄8" 5'-11 7⁄8 " 6' -0 3⁄8 " 67 1⁄4 " Window Dimension 4' -0 " 4' -0 1⁄2 " 3' -0 1⁄2 " 43 1⁄4 " 2' -1 1 15⁄ 16 " 31 3⁄16 " 55 1⁄8 " 4' -1 1 7⁄8 " 5'-0 3⁄8 " 31 3⁄16" 19 3⁄8" Unobstructed Glass 3' -5 3⁄8 " 3' -4 13 ⁄ 16 " 38 13⁄ 16 " 1'-8 1⁄2" 1'-9" 1'-5" 1'-5 1⁄2" 15 3⁄4" 12 3⁄4" Minimum Rough Opening 18 3⁄4" 24" 32 1⁄4" 32 1⁄4" 36" 18 5⁄8 " 24 " 36 " 32 1⁄4 " 32 1⁄4 " 17 5⁄16 " Shoulder Height 22 3⁄16 " Radius 1'-5" 1'-5 1⁄2" 12 3⁄4" 1'-8 1⁄2" 1'-9" 15 3⁄4" 2'-0 1⁄8" 2'-0 5⁄8" 19 3⁄8" 2'-11 15⁄16" 3'-0 1_⁄₂_" 31 3⁄16" 12 1⁄4 " 17 1⁄8 " 9 5⁄8 " 29 3⁄8 " 24 5⁄16 " 16 13 ⁄16" 16 " 41 1⁄4 " 36 3⁄16 " 28 11⁄ 16 " 27 7⁄8 " 23 7⁄8 " 53 1⁄4 " 48 3⁄16 " 40 11 ⁄16" 39 7⁄8 " 35 7⁄8 " 8 13⁄ 16 " 12 " 2'-4 3⁄8" 2'-4 7⁄8" 23 5⁄8" 2'-4 3⁄8" 2'-4 7⁄8" 23 5⁄8"

Horizontal Section Vertical Section

400 Series Specialty W

(18)

Pentagon

Rectangles contain four

equal angles and either two or

four equal sides. Include both

squares and rectangles.

Specify window width and

height.

Minimum and Maximum Limits

Flexiframe

®

_windows

may be assembled in

almost any shape or size

with these limitations:

Angled Pentagon contain an angle

cut, or a "cut-off corner" sloping to

left or right.

Specify width at head, width at sill,

height on short side and height on

long side.

Peaked Pentagon contain sides

of equal length, extending at right

angles from the sill, and two angled

sides, of equal length, that peak

above center of sill.

Specify window width at sill, height

of one vertical leg, and window

height from sill to peak.

Right Triangles contain one

90° corner.

Specify length of both legs

extending from the 90° corner.

Isosceles Trigangles contain

two sides of equal length and

equal angle.

Specify length of leg at sill &

window height (sill to peak).

Horizontal/Vertical

Parallelograms contain two

pairs of parallel sides.

Specify length of vertical and

horizontal legs and pitch.

Diamonds contain two pairs of

parallel and equal length sides.

Specify by window width and

window height.

Sloped to Left or Sloped to

Right contain angle face cut to

left or right.

Specify window width at sill,

window height, and length of

short side.

Slope is often designed to

match a roof's slope.

Equilateral Hexagons contain

six equal angles and sides.

Specify length of one leg.

Unequal Hexagons contain

three pairs of angles and two

sets of equal length legs.

Unequal leg at head of unit is

parallel to and is centered over

unequal leg at sill.

Specify length of leg at sill

and head, one vertical leg and

window height.

Equilateral Octagons contain

eight equal angles and sides.

Specify length of one leg.

Standard octagons sizes are

available in 2', 2'-4" and 3',

see page 125.

Flexiframe

®

_{Window Shapes and Sizes}

• Maximum standard glass area of 60 sq. ft.

• Square footage is based on a square or rectangular shape

• No angle may be less than 14

°

• No leg may be less than 6" or greater than 144"

• No short leg may be greater than 84"

• See product information below for additional limitations based on specific shapes

Rectangle

Parallelogram

Triangle

Hexagon

Octagon

Trapezoid

Equal Leg Sill to Peak Height Sill Width Width Height Sill Width Max. Height Min. Height

Max. Sill Width

Min. Height Min. Width Max. Height Pitch Leg Length Leg Width Height Width Height Width Unit Height Vertical Leg Equal Leg Unit Width Unit Height Sill Width Max. Height Min. Height Sill Width Sill to Peak Height Side Height

(19)

Andersen Wood Casing Andersen Wood Joining Strip Andersen Trim Strip Set in Continuous Bead of Sealant Each Side 3⁄16" (5) 1 3⁄8" (35) 1 3⁄8" (35)

Method A

Casement Jamb Flexiframe®_Jamb Auxiliary Extension Jamb Available in 4' and 6' Lengths, 4 9⁄16", 5 1⁄4", 6 9⁄16", or 7 1⁄8" Widths

Method B

Casement Jamb 1⁄4" (6) Filler Strip (by others) Modified Andersen Extension Jamb Aligned Without Tongue for Jamb Groove Flexiframe®_Jamb Sill Glazing Sealant Glass Stop 1 3⁄8" Trim Stop (included in factory set up) 2" Trim Stop Also Available Andersen Extension Jamb Installation Flange 1 3⁄8" (35)

2 7⁄8" (73) 1 5_⁄₁₆_{" (33)}

Flexiframe

®

_{Window Detail}

Scale 1

1

_⁄

₂

_{" = 1'-0" (1:8)}

Extension Jamb Alignment

Method A is used when picture frame trimming is desired in the

following applications: archtop or Flexiframe

®

_{over casement}

windows, awning over, under, or next to casement windows, or

awning next to archtop and Flexiframe windows.

Method B is used for all other conditions such as when a

continuous uninterrupted extension jamb is desired or when no

extension jambs are used (i.e. only joining trim is used).

Horizontal Section

Combination Examples

• Consult with an architect or structural engineer regarding minimum requirements for structural support members between adjacent rough openings.
