Hotel TV Solution 2012

(1)

Hotel TV Solution

(2)

Multi-language support

Wake-up service

A rich selection of TV & radio channels

Express check-out

Games

Hotel activities & promotions

Video-on-demand

World Clocks

User friendly Interface

Bill viewing

On-demand music albums

News

KEY FEATURES

Interactive

Hotel TV

Solution

brings ultimate

entertainment to

your hotel room.

Feel the difference of Digiguest Interactive Hotel TV System,

a solution with no set-top box and no cable mess.

(3)

PROFESSIONAL FEATURES

Interactive Hotel TV Architecture

Triple Tuner + IP Streaming (RF & IP)

Remote Management System

Functional Requirement Specifications HotelTV 2, Atrium Company Confidential

1 / 11

1. Introduction

1.1. Purpose

This document provides a general overview of the Hotel TV 2 system and describes the functionality of the sub-systems that constitute the whole system.

1.2. General Overview

Hotel TV 2 is an IP based interactive in-room entertainment and communication system for hotel businesses. It enables hotel guests to access and enjoy Live TV broadcast from satellite, terrestrial, cable in both standard and high definition formats, video-on-demand, music-on-demand, a variety of interactive services.

It consists of several sub-systems and has a modular architecture and can be configured according to the desired features. DVB Server, VOD Server, Control Server, Administration Console and Client TV’s are the main components of the solution.

Figure 1 –A logical diagram of the Hotel TV solution.

DVB Server is a reception system that accepts live TV feed from a satellite, cable or terrestrial TV network and converts it to a number of unicast or multicast IP channels. VOD server is the component in the system that stores media files and then streams these files to the requesting clients which are in our case IP enabled TVs.

Interactive Hotel TV is an IP based interactive in-room entertainment and communication system for hotel businesses. It enables hotel guests to access and enjoy Live TV broadcast from satellite, terrestrial, cable in both standard and high definition formats, video-on-demand, music-on-demand, and a variety of interactive services.

The system provides the opportunity to select RF tuner and/ or IP streaming to watch TV channels.

IP streaming is performed via DVB-to-IP Gateways which have digital and analog input interfaces.

Triple RF tuner allows guests to enjoy terrestrial, cable and satellite channels.

Interactive Hotel TV system provides a dynamic and essential service management tool for the hotel personnel via administration console.

7/24 Service Support

Our professional technical support team provides system setup and maintenance services, a range of channel management services as well as the design, provision and installation of hotel TV networks.

(4)

Simple Remote Controller

High Resolution

USB Media Player

ENTERTAINMENT FEATURES

The system offers simplified remote control for the guest convenience, making multiple function control easier.

USB 2.0 provides access to multimedia files.

The guests can view photos, listen to music or watch movies stored on the USB.

DESIGN SPECIFICATION

SYS CODE: 01 Symbol FUNCTION Code (RC5) STBY 0x0C

RED TXT / RED 0x37

GREEN EPG /GREEN 0x36

YELLOW PAYTV / YELLOW 0x32

BLUE TV / BLUE 0x34

1 Direct Programme 0x01 Width

2 Direct Programme 0x02 Length

3 Direct Programme 0x03 Depth

4 Direct Programme 0x04 Weight

5 Direct Programme 0x05 6 Direct Programme 0x06 7 Direct Programme 0x07 8 Direct Programme 0x08 9 Direct Programme 0x09 0 Direct Programme 0x00

BACK Back 0x0A

Vol - Volume Decrease 0x11 Vol + Volume Increase 0x10 Mute 0x0D P/CH- Programme/Channel - 0x21 P/CH+ Programme/Channel + 0x20 HELP Info/Help 0x12 UP Cursor Up 0X14 LEFT Cursor Left / << Backward 0x15 OK / PLAY/PAUSE OK / Selection + PLAY/PAUSE 0X35 RIGHT Cursor Right / >> Forward 0x16

MENU Menu 0x30

DOWN Cursor Down 0X13 LANG Language 0x1A SURCE AV Mode 0x38 HOME / INTERNET HOME / INTERNET 0x3D PICTURE Picture Mode 0X2B SLEEP Sleep Timer 0X44 ALARM Alarm Timer 0X25

3F Low Voltage Indication

CHECKED

Stable Current, while pressing. Max. :15 mA In idle mode, leakage current. Max. : 10 uA

SPECIFICATION Carrier

Frequency System clock : 429KHzCarrier : 36 KHz Operating Vaoltage Loaded Voltage2,6V – 3,4V Initial Current, whenpressed. Max. : 30 mA

DRAWN BY

70µw/cm²

BRAND : OEM

CONFIDENTIAL

PROJECT :RC3410 PC/FILE NAME DESIGNER

DIMMENSIONS

DESCRIPTION APPROVED

CONDITION SPECIFICATION

Drop the sample with battaries from a height of 80 cm to the ground which is covered with a flat wooden board of 30 mm thickness, the test is performed at 6 faces.

1) No functional failure is allowed 2) No mechanical crack on the product is allowed DOCUMENT No: 1 DROP TEST Revision No: 000

Min. Emit Power :

KEYS OPERATING

LIFE

Activate the key at the centre with a load of 200 gr at 2 or 3 cycles/sec. Test is done for 50.000 cycles

CONDITION

It must satisfy the specification. Check all products.

BATTERY LID LIFE

CONDITION SPECIFICATION

Open and close the battery lid 100 times in or 3

cycles/sec Don’t close by the weight of the door.

SPECIFICATION

There should be rib on 5 key button for blind people.

CE CE logo should be added.

Recycling logo should be added on Remote Control package

There should be a label that describes Company Name, system code and batch number.

Weee logo should be added.

Interactive Hotel TV provides the best picture quality with sharper edges, more distinct images, more vivid colors and a smoother look for the fast moving objects.

Swivel stand allows hotel guests to watch TV at any direction.

(5)

Video on Demand (VoD)

Video on Demand feature enables hoteliers to offer their guests a wide selection of blockbusters and adult movies. Hotel guest experience is enhanced with easy to use features such as play, pause, forward, reverse.

Other features offered are free preview, multi-language sub-title support and parental control.

Parental control can be switched on by hotel personnel or by the guest.

Anonymous billing ensures maximum discretion for the guests.

Music on Demand

Games

Music on Demand service offers guests a wide range of music in rock, pop, jazz, R&B and classic genres.

Hotel TV offers games such as arcades, strategy games, card games, puzzles and many more to enhance guest satisfaction.

(6)

32970

40970

42970

46970

TECHNICAL DRAWINGS

956 mm 620 mm 1002 mm 649 mm 770 mm 520 mm 1089 mm 695 mm 40 mm 221 mm 221 mm 40 mm 203 mm 40 mm 40 mm 221 mm

(7)

Size 32" 40" 42" 46"

Resolution 1920x1080 1920x1080 1920x1080 1920x1080

Type LED LED LED LED

Dynamic Contrast Ratio 100,000:1 100,000:1 100,000:1 100,000:1

Digital Noise Reduction ● ● ● ●

Progressive Scan ● ● ● ● Invisible Speaker ● ● ● ● Audio Output 6W + 6W 8W + 8W 8W + 8W 8W + 8W Equalizer (5 Band) ● ● ● ● Carrier Mute ● ● ● ● Dolby Digital ● ● ● ●

Auto Volume Lever (AVL) ● ● ● ●

Hybrid Stream (Tuner+IP) ● ● ● ●

Tuner Modes DVB-T/C/S2 DVB-T/C/S2 DVB-T/C/S2 DVB-T/C/S2

Video On Demand optional optional optional optional

Property Management System (PMS) ● ● ● ●

Remote TV Management System ● ● ● ●

Welcome Message ● ● ● ●

Wake-up Alarm ● ● ● ●

USB Media Player ● ● ● ●

Power save mode ● ● ● ●

Energy Saving ● ● ● ●

VESA Compatible ● ● ● ●

Swivel optional optional optional optional

RF IN ● ● ● ● SCART ● ● ● ● Component In ● ● ● ● RGB In ● ● ● ● PC In ● ● ● ● HDMI 4 4 4 4

Digital Audio Out Optical Optical Optical Optical

USB 2 2 2 2 CI Slot ● ● ● ● LAN - Ethernet ● ● ● ● Voltage, Hz 220V/50Hz 220V/50Hz 220V/50Hz 220V/50Hz Consumption (Typical) 80W 95W 100W 110W Consumption (Max) 135W 150W 160W 165W Stand-by 0.5W< 0.5W< 0.5W< 0.5W< without Stand (mm) (HxDXW) 480 x 40 x 770 583 x 40 x 956 611 x 40 x 1002 658 x 40 x 1089 with Stand (mm) 520 x 203 x 770 620 x 221 x 956 649 x 221 x 1002 695 x 221 x 1089 Weight (Typical) (KG) 10,1 16,5 15,7 17,7 INTERFACES POWER DIMENSION VIDEO AUDIO FEATURES

TECHNICAL SPECIFICATIONS

(8)
