AQUANİT PORCELAIN SHOWER TILE

Models | 02

Color Alternatives | 08

Drain System | 10

Application-Installation | 11

13 | Product Combination

21 | Technical Information

22 | Application Detail

23 | Technical Information

Contents

AQUANİT

PORCELAIN

SHOWER TILE

Aquanit,

100% porcelain tile.

Porcelain tiles have thick bodies composed of

clay and other minerals combined in a superfine

mixture. The porcelain tiles that are printed in

strong presses are baked at 1250˚C to gain

a very hard structure that does not absorb

water. They are freeze-resistant as they are dirt

and stainproof. Regardless of the application

area, they maintain their color and beauty for

a long time. Aquanit that is produced from

100% porcelain brings all the good qualities of

porcelain to the bathrooms.

Resistant to chemicals

Stainproof

Product Specifications

Contents

Resistant to scratches

Matt | R10

Multi

Multi

90x90cm - 90x135cm

Linear Massive Cover

Slope

Slope

90x135cm - 80x120cm - 90x90cm - 80x80cm

Line Cover

* 80x80 size is only produces for order of 200 pieces or more.

*

Slope Nova

Slope Nova

80x120cm - 90x135cm

Line Cover

MOLD

Grit SERPEGIANTEWhite

CODE 529 HILL

White CODE 524 COSMOCopper

FIBRE Grey OAKWOOD Light Brown MARMO BIANCO White MOLD Basalt BETON White BETON

Olive AnthraciteBETON

BETON Taupe BETON

Grey BETON

Cream INFINITYWhite

AQUA

White Taupe-GreyGUSTO HAVANAWhite

ARC

White GreyARC VizonARC WhiteICON

ICON Grey ICON

Beige

Color Alternatives

Color Alternatives

Kombin Örnekleri / ---

Product Combinations

Code 511 Camelia - Arc

Product Combinations

Product Combinations

Rain - Beton Alvis - Beton Beton White 80x120cm Rain Grey 60x60cm Rain Grey 30x90cm Aquanit Floor Wall Beton Grey 80x120cm Alvis Grey 20x20cm Alvis Mix Decor 20x20cm Aquanit Wall

Code 524 Cosmo / Santorini - Code 524 Cosmo

Oakwood / Beton - Oakwood Light Brown

Cover Size Cover Alternatives Frame Siphon Parts

* Shipped mounted on Aquanit. ** Shipped with Aquanit box.

60 mm height - 36 l/min. Side Outlet 80 mm height - 60 l/min. Side Outlet 30 / 80 mm height - 48 l/min. Vertical Outlet

Multi 6x30 cm Linear Massive Hair Catcher Siphon Fastening Piece Insulation Flange Slope 4.5x50 cm Line Slope Nova 4.5x70 cm Line Siphon Types

**

**

*

*

**

**

**

Drain Systems

Application - Installation Steps

Insulation should be make according to country standards.

1

Insulation should be make according to country standards.

7

Measure the siphon axis and locate the siphon according to the technical drawing.

2

Y

X

Cut extension piece that interconnect one siphon to another siphon.

3

Apply repair mortar. Place the floor siphon into the housing.

4

Set and check the siphon axis measurement.

5

Check the screed and the siphon are on the same level. Beveling the waste pipe at least 3 mm is recommended.

6

Z

min. 3mm

The setting screed should have been set before the isolation process.

8

Spread the porcelain adhesive on floor which is prepared for montage of Aquanit Porcelain Shower Tile.

9

Displace the protective film.

10

Place Aquanit Porcelain Shower Tile. Beveling 3 mm towards drain is recommended.

13

min. 3mm

Perform eccentric adjustment from the drain gap to align the floor siphon with the axis.

14

Fix the floor siphon to the system using the fixation piece.

15

Place the spiral hair trap into its housing.

16

Install the cover.

17

Application - Installation Steps

Warning

• Do not rip off the protective cover film of siphon until the whole application is finished. • Before application, the wall tile must be one line short from the floor.

• Carry out the processes as explained in the user guide.

• Before implementation the product should be checked whether it has defect. No responsibility will be taken after installation. • Cutting and drilling processes should have been done at factory.

• You can contact us through our website (seranit.com.tr) for more detailed information before the application. Application installation steps have been prepared for all models.

Check the screed and the siphon are on the same level. Beveling the waste pipe at least 3 mm is recommended.

Apply porcelain adhesive to the back side of Aquanit porcelain shower tile.

12

Adjust the eccentric part in siphon.

11

Technical Drawing

Technical drawings are based on the level application alternative.

Multi Linear Model - 90x135cm

Multi Linear Model - 90x90cm

MULTI - 900X1350 - MASIF LINEER KAPAK 60X300mm

PLAN

A-A KESİTİ

900

1350

DUVAR ZEMİN DUVAR

SİFON AKS ÖLÇÜSÜ (SIVADAN)

1350

5

5

210 5 215 215 14 60

5

Plan A - A Section Wall Wall Floor

Siphon Axis Dimension (From Plaster)

900 215 5 5 60 4 5 210 5

MULTI - 900X900 - MASIF LINEER KAPAK 60X300mm

A-A KESİTİ PLAN DUVAR

900

900

ZEMİN DUVAR

SİFON AKS ÖLÇÜSÜ (SIVADAN)

900

5

210 5 215 215 14 60

5

5

Plan A - A Section Wall Floor

Slope Model - 90x135cm

Technical Drawing

Technical Drawing

Slope Model - 90x90cm

A-A KESİTİ

PLAN SLOPE - 900X900 - LINE KAPAK 45x500 mm

900

900

SİFON AKS ÖLÇÜSÜ (SIVADAN) ZEMİN DUVAR DUVAR

5

14 60

5

138 133 5 138 Plan Siphon Axis Dimension

(From Plaster) A - A Section Wall Wall Floor 900 140 133

SLOPE - 900X1350 - LINE KAPAK 45x500 mm

A-A KESİTİ

PLAN

1350

900

1350

SİFON AKS ÖLÇÜSÜ (SIVADAN) ZEMİN DUVAR DUVAR

5

5

5

181 5 186 186 14 60 Plan A - A Section Wall Wall Floor

Siphon Axis Dimension (From Plaster)

186 181

SLOPE - 800X1200 - LINE KAPAK 45x500 mm

A-A KESİTİ PLAN

1200

800

1200

ZEMİN DUVAR DUVAR

SİFON AKS ÖLÇÜSÜ (SIVADAN)

5

5

118 5 123

5

123 14 60 Plan Siphon Axis Dimension

(From Plaster) A - A Section Wall Wall Floor 5 125 123 118

Technical drawings are based on the level application alternative. Technical drawings are based on the level application alternative.

Slope Model - 80x135cm Slope Model - 80x80cm

SLOPE - 800X800 - LINE KAPAK 45x500 mm

A-A KESİTİ

PLAN

800

800

SİFON AKS ÖLÇÜSÜ (SIVADAN) ZEMİN DUVAR DUVAR 14

5

5

118 5 123 60

800

5

123 Plan Siphon Axis Dimension

Slope Nova Model - 90x135cm

Technical Drawing

Technical drawings are based on the level application alternative.

Slope Nova Model - 80x120cm

SLOPE NOVA - 900X1350 - LINE KAPAK 45x700 mm

A-A KESİTİ

PLAN

5

900

1350

5

DUVAR DUVAR ZEMİN DUVAR

900

186.00

SİFON AKS ÖLÇÜSÜ (SIVADAN)

5

14 60 181 5 186 Plan Siphon Axis Dimension

(From Plaster) A - A Section Wall Wall Floor 200

SLOPE NOVA - 800X1200 - LINE KAPAK 45x700 mm

A-A KESİTİ

PLAN

DUVAR

1200

5

5

800

DUVAR DUVAR ZEMİN

SİFON AKS ÖLÇÜSÜ (SIVADAN)

800

5

118 5 123 123 14 60

Siphon Axis Dimension (From Plaster) A - A Section Wall Wall Floor 1200 123 Plan

Dimensions are given from under ceramic plaster. Please ask for technical information before application.

The floor’s leveling screed height may vary depending on the siphon model to be used. The type of application may vary depending on the preferred elevation.

* Can use only with close cabinets.

Product & Size

Size

Multi Model

Slope Model

Slope Nova Model

800x800 X = 125 ; Y= 405 mm

900x900 X = 215 ; Y= 455 mm X = 140 ; Y = 455 mm

800x1200 X = 125 ; Y= 405 mm X = 125 ; Y = 600 mm

900x1350 X = 215 ; Y= 455 mm X = 190 ; Y = 455 mm X = 200 ; Y = 675 mm

Axis Dimensions for Aquanit Ceramic Shower Tile Installation

Floor Applications With Level Difference

1 2 3 4 6 1. Betonarme döşeme 2. Zemin tesviye şabı 60MM 3. Islak Mekan Sürme izolasyon 4. Flex yapıştırıcı 4MM

5. Banyo zemin Seranit/ Serra karo 10MM 6. Aquanit 14MM

7. Flex derz dolgu 3MM fuga 5 7 PAFTA NO: PROJE ADI PAFTA ADI ÇİZEN PROJE NO: KONTROL TARİH DENİZ SARIOĞLU 02.05.2016 REVİZYON 00 03

AQUANİT UYGULAMA DETAYI ALT.03

1 DETAY 1. Kat m² = Toplam m² = AQUANİT DETAY Alternative 3 1 2 3 4 7 5 6 1 _{Concrete floor} 2 _{Leveling screed}

3 _{Wet insulation drive space} 4 _{10mm flex adhesive}

5 _{10mm ceramic or porcelain floor tile}

PAFTA NO: PROJE ADI PAFTA ADI ÇİZEN PROJE NO: KONTROL TARİH DENİZ SARIOĞLU 02.05.2016 REVİZYON 00 01

AQUANİT UYGULAMA DETAYI ALT.01

1 DETAY 1. Kat m² = Toplam m² = 1 2 3 5 7 9 8 6 4 1. Betonarme döşeme 2. Zemin tesviye şabı 60MM 3. Islak Mekan Sürme izolasyon 4. Flex yapıştırıcı 4MM

5. Banyo zemin Seranit/ Serra karo 10MM 6. Aquanit 14MM

7. Flex derz dolgu 3MM fuga 8. Su izolasyon ve Kabin profili 9. Polimer sızdırmazlık AQUANİT DETAY Alternative 1 1 2 3 4 7 5 8 6 9 1 2 3 7 9 8 6 1. Betonarme döşeme 2. Zemin tesviye şabı 60MM 3. Islak Mekan Sürme izolasyon 4. Flex yapıştırıcı 4MM

5. Banyo zemin Seranit/ Serra karo 10MM 6. Aquanit 14MM

7. Flex derz dolgu 3MM fuga 8. Su izolasyon ve Kabin profili 9. Polimer sızdırmazlık

5

AQUANİT UYGULAMA DETAYI ALT.02

1 DETAY 4 Alternative 2 1 2 3 4 7 5 8 6 9

Technical Information

6 _{Aquanit 14mm} 7 _{3mm grouting fugo}

Box Pallet Information Size

(cm) Dimension Thickness Box / pcs Box (mNet 2) Box Pallet (m2₎ Box (kg) Pallet (kg) Pallet Size (cm) Box (kg)

80x80 800x800 14 1 0.64 9 5.76 21 233 99x99x76 36

80x120 800x1200 14 1 0.96 9 8.64 31 330 99x139x76 48

90x90 900x900 14 1 0.81 9 7.29 26 282 108x108x76 45

90x135 900x1350 14 1 1.215 9 10.94 39 415 109x154x76 58

Siphon Box - pcs

60 mm Side Outlet Drain System 9

80 mm Side Outlet Drain System 9

30 / 80 mm Vertical Outlet Drain System 9

Requested siphon is shipped to the customer on a separate pallet.

Application Profiles 2 1 3 4 6 5 2 1 3 4 6 5 2 1 3 4 6 ₅ Aquanit 14 mm Flex adhesive Wet surface applied insulation Insulation flange Floor leveling screed Siphon 1 2 3 4 5 6

36 l/min. Side Outlet Siphon 60 mm Height

Application Profile (Min. 65 mm screed height)

60 l/min. Side Outlet Siphon 80 mm Height

Application Profile (Min. 85 mm screed height)

The concrete must be cut with a drill of 125 mm in diameter.

48 l/min. Vertical Outlet Siphon Application Profile

(Min. 30 mm - max. 80 mm screed height)

Technical Information

Cabine profile is specially designed for Aquanit.

X

60

5

X

3

MODELE GÖRE SİFON

AKS ÖLÇÜSÜ (SIVADAN)

Cabine Profile

AQUANIT

YER KAROSU

MASTİK

14

7

18

32

14

6

Not: 6mm cam kullanılmalıdır.

10

Mastic

Floor Tile

Note: 6mm glass must be used.

Aquanit

Application Detail

Siphon Axis Dimension (From Plaster)

Prüfbericht Oktaber 2019 NR. 9060006 µ>0.60= GS4/GB3 R12/13 C Bemerkung: Die Platten können in Bereichen von GB 3 eingesetzt werden.

24

Environmental Management System Certificate

Occupational Health And Safety Management System Certificate Environmental Management

System Certificate

ISO 9001 Quality Management System Certificate Occupational Health And

Safety Management System Certificate

ISO 9001 Certificate

Russia - Gost Certificate

Russia - Hygiene Certificate Ukraine - Sepro Certificate Ukraine - Sepro Certificate For Facade

France - CSTB NF UPEC Poland Hygiene Certificate Poland Radiation Certificate

TS EN 14411

Certificate of Conformity to Turkish Standards Environmental Product Declaration, EPD

Turkish Standarts Institution Certificate Of Conformity To Double Star Criteria

SERANİT GRANİT SERAMİK SAN. TİC. A.Ş.

Organize Sanayi Bölgesi - BİLECİK / TÜRKİYE

06

DOP: 2013-1

Dry-pressed ceramic tiles, with water absorption Eb ≤ 0,5 %,for internal and external walls and f loorings. Please refer to our web site www.seranit.com.tr for technical information related to CE labeling.

Seranit Granit Seramik Sanayi ve Ticaret Anonim Şirketi Büyükdere Caddesi Likör Yanı Sokak No:1 K:4 D:401-402

34394 Şişli, İstanbul TURKEY Tel: +90 212 340 74 00
