1 Introduction

NexeTalk Telephone Interconnect (NTI) is an integral part of NexeTalk Suite. It is also possible to install NTI as a

standalone application. The telephone gateway allows calls between Nexedge radio users and telephone subscribers. In Diagram 1, you can see a typical scheme of a Nexedge radio network. The network can include any number of Kenwood Nexedge sites and groups of users.

NexeTalk Telephone Interconnect

(NTI)

NTI is an IP-based software module that makes connection between radios and phones much more comfortable

and cost-effective. It does not require any additional hardware. NTI connects to telephone lines via SIP 2.0 capable PBXs. Analog PBXs may need a hardware adapter supporting SIP.

In Diagram 1, internal phones are connected to the PBX, either via analogue or digital lines. The PBX allows making internal calls and connecting internal telephones to the PSTN. Telephones from the PSTN can also access internal phones via the PBX.

NexeTalk Telephone Interconnect

(NTI)

2 Software and Hardware Prerequisites

 PBX supporting SIP 2.0.

 PC with Windows 7 / 8 / 2003 / 2008 / 2012 for installation of NexeTalk

 Nexedge trunked or conventional radio system

 SQL Express 2008 / 2012

Please read NexeTalk Installation Guide to install software on your computer.

3 Configuration Guide

Please follow the below instructions to set up NTI.

3.1 NexeTalk SIP Extension

Please assign a SIP extension to NexeTalk in your PBX’s settings or request it from your telephone system administrator.

The following information is required to configure the application:  SIP server IP address or Host Name

 SIP server port

 Extension ID (SIP ID)

 Extension Login (SIP Login)

 Extension Password (SIP Password)

3.2 Nexedge Network Configuration

3.2.1 Nexedge Trunking System (NXR x00 Repeaters in the Trunking Mode)

 Click "Edit", then choose Telephone Line Information, click "Add", as shown in Figure 1.

NexeTalk Telephone Interconnect

(NTI)

3.2.2 Nexedge Conventional System (NXR x00 / x10 Repeaters in the

Conventional Mode)

 Launch KPG 129D or KPG 109D to configure NXR x10 or NXR x00 repeaters respectively.

 Click "Edit", then choose Conventional IP Network, as shown in Figure 2.

 Add a NXDN ID (see Figure 3).

Figure 3-2 KPG 109D / KPG 129D

NexeTalk Telephone Interconnect

(NTI)

3.3 Nexedge Network Configuration

Please enter the information in the SIP Connection window.

Go to the Connections tab in the respective Fleet’s settings and add a new Phone Connection entry. Use the NXDN ID you have created in the Phone Connection settings.

NexeTalk Telephone Interconnect

(NTI)

Click "Save" and restart the server.

NexeTalk Telephone Interconnect

(NTI)

4 Making Calls

4.1 Phone-to-Radio Calls

Note: A telephone shall support tone-dialing.

 Dial the SIP extension of NexeTalk on the telephone. The call will be answered by NexeTalk, and you will hear an IVR message.

 Dial a radio ID and press #. The connection between the telephone and the radio will be established.

 To answer the call, the radio user shall press the PTT button.

4.2 Phone-to-Talk Group Calls

Note: A telephone shall support tone-dialing

 Dial the SIP extension of NexeTalk on the telephone. The call will be answered by NexeTalk, and you will hear an IVR message.

 Dial a talk group ID and press *. The connection between the telephone and the talk group will be established.

 Press # to allow talk group’s radios to answer the call.

 Press * to talk.

Note: In the conventional mode, a radio user can answer an incoming call by pressing the PTT button.

4.3 Radio-to-Phone Calls

Note: The Autodial function must be enabled in Kenwood System Manager.

 Dial a phone number or choose a phone number form the Contacts menu.

 Press PTT. The connection will be established.
