Design and Analysis of Real Time Video Processing Based on DWT Architecture for Mobile Robots

(1)

Procedia Computer Science 78 ( 2016 ) 544 – 549

Peer-review under responsibility of organizing committee of the ICISP2015 doi: 10.1016/j.procs.2016.02.100

ScienceDirect

International Conference on Information Security & Privacy (ICISP2015), 11-12 December 2015,

Nagpur, INDIA

Design and Analysis of Real Time Video Processing Based on

DWT Architecture for Mobile Robots.

Pramod Kumar Naik

a

*,Arun Tigadi

b

,Dr.Hansraj Guhilot

c

,Vyasaraj.T

d

a

Department of Electronics & Communication Engg.,VCET, Puttur, Karnataka, India.

b

Department of Electronics & Communication Engg.,KLE Dr. M.S.S.CET, Belagavi, Karnataka, India.

c

Principal K C College of Engg, Thane, Mumbai, Maharastra, India.

d

Department of Electronics & Communication Engg.,VCET, Puttur, Karnataka, India.

Abstract

In this paper we have discussed the design constraints of a computer vision based mobile robot and processing the real time video received from the mobile robot. The focus is on applying DWT algorithm on the real time video so that memory size required for storage is reduced.The mobile robot which feeds in the live steaming of video of surrounding area is of low quality, which has to be processed preciously. Storage of video with respect to memory is also another issue which is addressed. Memory controller is also used as an interface between memory and the processing element.

Peer-review under responsibility of organizing committee of the ICISP2015.

Keywords: DWT;Mobile Robots; Video Processing;Memory;

1. Introduction

The motivation of providing a Computer Vision mobile robot with high end Spartan 6 FPGA based video processing is to provide the robot with autonomous capabilities which is reliable, effective and efficient. This kind of mobile robot will help the rescue team to make use of the effective system for rescue operations. Natural calamity like earthquakes, flood, explosions or any other catastrophes often result in collapsed buildings with casualties and

* Pramod Kumar Naik Tel.: +91-9481772690; fax: +91-8251-236444.

E-mail address: [email protected]

(2)

wounded people trapped under the debris. When such disaster occur it is very important that one has to search for survivors with mobile robots with less human risk. Thus these robots will effectively search such areas which are dangerous and due to their size they can move more effectively and locate survivors.

In order to address the issue of memory, Real Time Video Processing DWT architecture is designed, implemented and analyzed in FPGA flow. At the heart of JPEG 2000 structure is a wavelet based compression technique provided a number of advantage over Discrete Cosine Transform. In DCT compression there will be blockiness associated with compressed video. Although DWT have rough edges they are able to render better picture. Since many years new algorithms and mathematical approaches are used for signal analysis and signal processing. Pertaining to this domain wavelets have gained both research interest and practical real time applications. Most of real time signal like music and video are very complex with non-periodic features. So analyzing and extracting features for recognition or monitoring of these signals have practical consequences.

2. Literature Survey

Since DWT requires intensive computations, several architectural designs using special purpose parallel processor have been proposed have been proposed in order to meet many real time applications. The basic solutions include parallel filter architecture, SIMD linear array architecture, SIMD multigrid architecture, 2D block based architecture and the AWARE’s wavelet transform processor [10]. First three architectures mentioned above are parallel processors which can be used for high level of abstraction. The 2-D block based architecture has four MAC unit with VLSI implementation to perform and execute the forward and inverse transforms. The AWARE’s wavelet transform processor is capable of computing forward and inverse wavelet transform for 1-D input using six filters coefficients [11]. Most of the DWT computation is executed either in pipelined or parallel architecture with extensive user control. There is a clear need for designing and implementing DWT architecture on FPGA with better memory control for high end applications. Memory controller will act as a module which will take care of synchronising and refreshing the needs of external memory being connected and requests generated by the processing elements.

3. FPGA Implementation of Multipliers

During the design of DWT video processing unit, the performance depends on speed of operation of the MAC unit. In order to make the MAC unit perform faster we made functional changes by implementing different multipliers in the design of MAC unit and using the best for design. The FPGA implementation results of various multipliers are compared. From the multipliers we have arrived at the conclusion that Booth Multiplier consumes more area and also more delay. Due to this fact it requires more time for data propagation from input register to output register. It is also found that the delay of Vedic unsigned multiplier is fastest compared to these multipliers mentioned below.

(3)

CPU DWT/DCT DWT/DCT I/O DDR-SDRAM

SDRAM Controller 4. Implementation of Real Time DWT Video Processing on FPGA

The heart of DWT computing process is always the MAC unit, therefore DSP engineers are constantly looking for new algorithm and architecture in MAC to improve performance of the system. Thus various algorithm we can constantly design and implement it on suitable hardware. The block diagram basically consists of a real time video input block, DWT video processing block, output block and the entire video processing algorithm is implemented on desired FPGA implementation. Initially we have real time video file which is to be processed is received from real time camera which feeds in the input video. This video is processed in the processing block. The main objective is to save the real time video for surveillance or any security measures in restricted areas. To save the video continuously it will tedious task as it consumes lot of memory space. Thus to reduce the memory space utility, we compress the real time video using DWT video compression technique. The major processing is done according to our algorithm then the video compressed will be displayed in output video file.

This algorithm is designed in MATLAB Simulink which is finally implemented on a FPGA with certain modifications in the MAC unit and controlling the processing using SDRAM controller. The DWT based compression of video is done so that the memory size of video is reduced. As shown in the below figure 4.1 a SDRAM controller has to be used to synchronies the requests raised from the processors. Memory controller is a component which will take care of the required commands being generated for the proper operation of the external RAM being connected. It will take for proper read and write cycles and even the proper refresh cycles to retain the data being written on to it. As shown in the figure 4.1 below an SDRAM controller has to be used to synchronies the requests raised from the processors. Memory controller is a component which will take care of the required commands being generated for the proper operation of the external RAM being connected. It will take for proper read and write cycles and even the proper refresh cycles to retain the data being written on to it.

Figure 4.1 Block Diagram of Real Time DWT Video Processing

Here in this paper we are discussing how video processing parameters can be improved on computer vision based mobile robots to enhance their performance. Various video processing techniques are applied and few algorithms are implemented keeping memory as major criteria. These algorithms are applied to real time video received from wireless camera placed on mobile robot. The RTL of above algorithm is shown in the figure below after synthesis during the FPGA implementation. The above model was synthesized using Xilinx 14.7 tool suite and implemented on real time hardware. Our focus is on priority based flow control for different memory access streams. For this purpose an architecture which resembles above block diagram is designed and implemented.

(4)

Figure 4.2 RTL of Real Video Processing

Once done, we are implementing the design on Spartan 6 FPGA. The algorithm created in Xilinx system generator using JTAG is successfully implemented on Spartan6-LX45 FPGA board and the output is compared with the software outputs obtained.

Figure 4.3 Input video Figure 4.4 Edge detected video

Figure 4.5 Composited video Figure 4.6 Compressed video

Although the DWT based video compression is achievable, it will be beneficial if parallel and pipelined architecture which consumes low power and processes at high speed is offered by FPGAs. Today when we purchase any mobile we look for high end video and multimedia processing. But these application consume huge

(5)

amount of memory. Thus this drawback can be overcome by using effective video compression algorithms. Thus this paper explains the overall flow of enhancing and improving the performance. The results shown above are experimental results demonstrated on Spartan 6 PFGA for high end video platform.

5. Design and Implementation of Mobile Robot

The construction of this rescue robot is very simple, instead of using MDF (Medium Density Fibre board), we have used metal body of dimension 28x18cm, which gives a ground clearance of around 8cm. The reason behind using this was the disadvantages encountered by MDF such as the quality of fibre may get staled due to weather condition and the clearance between the ground and robot was around 1 to 2 cm. The distance between the two wheels is around 24cm from shaft to shaft.

The body of mobile robot is incorporated by fixing Arduino Duemilanove board, motor driver circuit, XIGBEE transceiver, GPS module, metal detection circuit, fire sensor, general purpose board servomotors and finally DC motor. Each are connected separately by maintaining a proper distance between every components and maintain 1cm gap height from metal body of mobile robot, the reason behind this is to avoid the shorting of metal in PCB’s, which may cause severe damage to the robot. At the end the battery is clamped at the bottom of the body of mobile robot so that there the connection between board and battery is reduced. A MATLAB GUI was created which incorporated the motion control of robot, motion control of servomotors, live video streaming through robot to the GUI with a snapshot

Figure 5.1 Block Diagram of Real Time DWT Video Processing

6. Conclusion

The experimental setup for receiving real time video from mobile robot for analysis is processed in Spartan 6 FPGA. The mobile robot has a ground speed of 10 inches per second, battery life of approximately 55 minutes, wireless range of between 75 and 100meters, weighs 2.5Kg and has a high level of mobility. The above video processing algorithm was implemented on Xilinx’s Spartan-6 LX45 FPGA. The architecture uses 316 slices and 259 LUT slices for the above video processing algorithms. At the same time MAC performance is compared by using

(6)

various types of multipliers in the design. The proposed DWT unit can be extended for 3D real time video processing.

Acknowledgements

I would thank the Vivekananda College of Engineering & Technology for providing the various facilities and resources available. I would also thank KLE Dr. M.S.S.CET, Belagavi for their support in completing this work.

References

1.Frank Dellaert, Wolfram Burgard, Dieter Fox and Sebastian Thrun, Using the CONDENSATION Algorithm for Robust, Vision-based Mobile Robot Localization, Computer Science Department, Carnegie Mellon University, Pittsburgh PA 15213;1999.

2.Yong-Kul Ki, Accident Detection System using Image Processing and MDR, Department of Computer Science & Engineering, Korea University, RTSA. IJCSNS International Journal of Computer Science and Network Security, VOL:7, No.3;2007.

3.D. N. Vizireanu and R. O. Preda,A New Digital Watermarking Scheme for Image Copyright Protection using Wavelet Packets, 7th Int. Conf. Telecomm. in Modern Satellite, Cable and Broadcasting Services, vol. 2, pp. 518-521; 2005.

4.J. F. Delaigle, C. Devleeschouwer, B. Macq and I. Langendijk, Human Visual System Features Enabling Watermarking, IEEE Int. Conf. on Multimedia and Expo , VOL: 2, pp. 489- 492; 2002.

5.Yusnita Yosuf and Othman O. Khalifa, Digital watermarking for digital images using wavelet transform ,Proc.

IEEE International Conf. on telecommunications ; May 2007.

6.Sugreev Kaur1 and Rajesh Mehra, HIGH SPEED AND AREA EFFICIENT 2D DWT PROCESSOR BASED IMAGE COMPRESSION, An International Journal(SIPIJ) VOL:1, No.2; December 2010,pp1-9.

7.Yamanaka, O Yamaguchi, T Maeda, J, Suzuki, Y.; “Image compression using wavelet transform and vector quantization with variable block size”, IEEE Conference on Soft Computing in Industrial Applications

(SMCia);2008, Page(s): 359 – 364.

8.Dong-Gi Lee and Dey S, Adaptive and energy efficient wavelet image compression for mobile multimedia data services Communications. IEEE International Conference on Volume: 4. Page(s): 2484 - 2490 VOL.4; 2002

9.Marino,Two Fast Architectures for the Direct 2-D Discrete Wavelet Transform Signal Processing, IEEE

Transactions on [see also Acoustics, Speech, and Signal Processing, IEEE Transactions on] Volume 49, Issue 6;

June 2001 Page(s):1248 – 1259.

10.M.Vishwanath, R.Owens and M. J. Irwin, VLSI architecture for the discrete wavelet transform, IEEE

Trans.Circuits Syst.II,VOL.42, pp. 305-316.

11.J.S.Fridman and E.S. Manolakos, Discrete Wavelet Transform: Data dependence analysis and synthesis of distributed memory and control array architectures, IEEE Trans. Signal Processing, vol. 45, pp. 1291-1308.

12.Arun S.Tigadi , Dr. Hansraj.Guhilot, “Implementation of Reconfigurable SynchronousRAM Controller on FPGA for flexible platforms”, International conference on communication ,VLSI and signal processing

(ICCVSP2013),February 20-22 ;2013,Page(s):253-256.

13.Pei-Jun Ma; Ling-Fang Zhu; Kang Li; Jia-Liang Zhao; Jiang-Yi Shi; ,The application and optimization of SDRAM controller in multicore multithreaded SoC, Solid-State and Integrated Circuit Technology (ICSICT), 2010 10th IEEE International Conference on , vol., no.,pp.324-326; 2010.

14.Arun S.Tigadi, Dr. Hansraj.Guhilot, Implementation of Reconfigurable Synchronous RAM Controller on FPGA for flexible platforms, International conference on communication ,VLSI and signal processing (ICCVSP2013),February 20-22 ;2013,Page(s):253-256.

15.Pei-Jun Ma; Ling-Fang Zhu; Kang Li; Jia-Liang Zhao; Jiang-Yi Shi; ,The application and optimization of SDRAM controller in multicore multithreaded SoC, Solid-State and Integrated Circuit Technology (ICSICT), 2010 10th IEEE International Conference on , pp.324-326, ; Nov 2010.
