GF Machining Solutions
Ready
for
delivery
Get your hands on a new, used or ex-demo GF Machining Solutions
high-performance machine tool now…no delay…no problem!
Act fast and make 2015 a year to remember!
Machining Solutions – for You
GF Machining Solutions
Every year, between October and December, we offer
customers something special … the opportunity to get a
new machine tool from us in double-quick time.
The new, used and ex-demo wire and sink EDM, milling and
laser machines available are all proven performers and are,
quite literally, raring to go.
Check-out the range of machines in the brochure … make
your selection … and then give us a call.
If you can’t find exactly what you need, or if you would like
more information on our best-in-class automation solutions,
training, consumables or maintenance services – call us
anyway as we’re sure we can identify and deliver the right
solution for you … immediately of course!
Milling
Mikron
HEM 500U
Mikron
HEM 500U
Mikron
HEM 700U
Machining Solutions –
for You
Ready for delivery
Mikron HEM 500U New machine
Rapid traverse speed 30 m/min
Spindle rpm 20.000 rpm - HSK-A63 Nr. of axes 5 Simultaneous Pallet change –
Tool magazine 60 tools Machine location Factory stock Available from Beginning of October Warranty 12 months
Mikron HEM 700U New machine
Rapid traverse speed 30 m/min
Spindle rpm 12.000 rpm - ISO-B40 Nr. of axes 5 - 3+2
Pallet change – Tool magazine 30 tools Machine location Factory stock Available from Beginning of October Warranty 12 months
Mikron HEM 500U New machine
Rapid traverse speed 30 m/min
Spindle rpm 12.000 rpm - ISO-B40 Nr. of axes 5 - 3+2
Pallet change – Tool magazine 30 tools Machine location Factory stock Available from Beginning of October Warranty 12 months Special Offer: Transport included Special Offer: Transport included Special Offer: Transport included
4 5
Mikron
HSM 200U LP
Mikron
VCE 600 PRO
Mikron
VCE 1000 PRO
Mikron
HEM 500U
Mikron
HSM 400 LP
Mikron
VCE 800 PRO
Mikron
VCE 1000 PRO
Mikron HSM 400 LP Demo machine
Rapid traverse speed 60 m/min
Spindle rpm 42.000 rpm - HSK E40
Nr. of axes 3
Pallet change – / Robot interface option Tool magazine 68 tools
Machine location Germany
Available from Beginning of October Warranty 6 months
Mikron VCE 800 PRO New machine
Rapid traverse speed 40 m/min
Spindle rpm 10.000 rpm - ISO / BT40
Nr. of axes 3
Pallet change – Tool magazine 24 tools Machine location Factory stock Available from Beginning of October Warranty 12 months
Mikron VCE 1000 PRO New machine
Rapid traverse speed 40 m/min
Spindle rpm 14.000 rpm - ISO / BT40
Nr. of axes 3
Pallet change – Tool magazine 40 tools Machine location Factory stock Available from Beginning of October Warranty 12 months
Mikron HSM 200U LP Demo machine
Rapid traverse speed 42 m/min
Spindle rpm 50.000 rpm - HSK E32
Nr. of axes 5
Pallet change – Tool magazine 30 tools Machine location France Available from December 2015 Warranty 6 months
Mikron VCE 600 PRO New machine
Rapid traverse speed 40 m/min
Spindle rpm 14.000 rpm - ISO / BT40
Nr. of axes 3
Pallet change – Tool magazine 24 tools Machine location Factory stock Available from Beginning of October Warranty 12 months
Mikron VCE 1000 PRO New machine
Rapid traverse speed 40 m/min
Spindle rpm 16.000 rpm - HSK-A63
Nr. of axes 3
Pallet change – Tool magazine 40 tools Machine location Factory stock Available from End of October 2015 Warranty 12 months
Mikron
HEM 700U
MIKRON HEM 700U New machine
Rapid traverse speed 30 m/min
Spindle rpm 20.000 rpm - HSK-A63 Nr. of axes 5 Simultaneous Pallet change –
Tool magazine 60 tools Machine location Factory stock Available from Beginning of October Warranty 12 months
Mikron HEM 500U Demo machine
Rapid traverse speed 30 m/min
Spindle rpm 20.000 rpm - HSK-A63 Nr. of axes 5 Simultaneous Pallet change –
Tool magazine 60 tools Machine location France Available from December 2015 Warranty 6 months
* The machines detailed within this campaign are available subject to prior sale. Technical specifications and images arenot binding and maybe modified without notice. Delivery before the end of December 2015 is subject to orders being placed to GF Machining Solutions by week 50-2015. This promotion is valid until 31 December 2015. General Terms and Conditions apply and available upon request.
* The machines detailed within this campaign are available subject to prior sale. Technical specifications and images arenot binding and maybe modified without notice. Delivery before the end of December 2015 is subject to orders being placed to GF Machining Solutions by week 50-2015. This promotion is valid until 31 December 2015. General Terms and Conditions apply and available upon request.
Special Offer: Transport included Special Offer: Transport included Special Offer: Transport included
Ready for delivery Ready for delivery
AgieCharmilles
CUT 300 Sp
AgieCharmilles
CUT 2000S
AgieCharmilles
AC Progress VP2
AgieCharmilles
CUT 200 Sp
AgieCharmilles CUT 300 Sp New machine
X, Y, Z travel (w,d,h) 550 x 350 x 400 mm Max workpiece dimensions (w,d,h) 1.200 x 700 x 400 mm Wire Diameters 0.15 - 0.33 mm Roughness (Ra) 0.1 µm Smart Options Setup 3D Machine location United Kingdom Available from End of October Warranty 12 months
AgieCharmilles CUT 2000S New machine
X, Y, Z travel (w,d,h) 350 x 250 x 256 mm Max workpiece dimensions (w,d,h) 750 x 550 x 250 mm Wire Diameters 0.15 - 0.30 mm Roughness (Ra) 0.07 µm Smart Options –
Machine location Factory stock Available from Beginning of October Warranty 12 months
AgieCharmilles AC PROGRESS VP2 New machine
X, Y, Z travel (w,d,h) 350 x 250 x 256 mm Max workpiece dimensions (w,d,h) 750 x 550 x 250 mm Wire Diameters 0.15 - 0.33 mm Roughness (Ra) 0.2 µm Smart Options Setup 3D Machine location Stock machine Available from Beginning of October Warranty 12 months
AgieCharmilles CUT 200 Sp New machine
X, Y, Z travel (w,d,h) 350 x 220 x 220 mm Max workpiece dimensions (w,d,h) 1.000 x 550 x 220 mm Wire Diameters 0.15 - 0.33 mm Roughness (Ra) 0.1 µm
Smart Options Power Expert, Surface Expert, Profl Expert Machine location Poland
Available from Beginning of October Warranty 12 months
Wire-cutting EDM
Mikron
HSM 200U LP
Mikron
XSM 400U
Mikron
HPM 800U HD
Mikron HSM 200U LP Used machine
Rapid traverse speed 42 m/min
Spindle rpm 50.000 rpm - HSK E32 Nr. of axes 5 Simultaneous
Pallet change 12 positions - Pallet MacroMagnum Tool magazine 30 tools
Machine location Italy
Available from Beginning of November Warranty 6 months
Year of Manufacture 2014 Worked hours 3.500
Mikron XSM 400U Used machine
Rapid traverse speed 80 m/min
Spindle rpm 42.000 rpm - HSK-E40
Nr. of axes 5
Pallet change 20 positions - Pallet ITS148 Tool magazine 68 tools
Machine location Benelux
Available from Beginning of October Warranty 6 months
Year of Manufacture 2009 Worked hours 4.300
Mikron VCE 1600 PRO Demo machine
Rapid traverse speed 24 m/min
Spindle rpm 14.000 rpm - ISO 40
Nr. of axes 3
Pallet change – Tool magazine 40 tools Machine location United Kingdom Available from End of October Warranty 12 months
Mikron
VCE 1600 PRO
Mikron HPM 800U HD Used machine
Rapid traverse speed 60 m/min
Spindle rpm 20.000 rpm - HSK-A63
Nr. of axes 5
Pallet change 7 positions - Pallet 500 x 630 Tool magazine 60 tools
Machine location Spain
Available from Beginning of December Warranty 6 months
8 9
AgieCharmilles
FORM 20
AgieCharmilles
CUT2000S with WPT1+
AgieCharmilles
FORM 200
AgieCharmilles
FORM 2000VHP
AgieCharmilles
FORM 30
AgieCharmilles
FORM 200
AgieCharmilles
CUT 30P
AgieCharmilles FORM 20 New machine
X, Y, Z travel (w,d,h) 350 x 250 x 250 mm Roughness (Ra) 0.1 µm
Max electrode weight 50 kg Max workpiece weight 200 kg Smart Options –
Machine location Factory stock Available from Beginning of October Warranty 12 months
AgieCharmilles CUT2000S with WPT1+ Demo machine
X, Y, Z travel (w,d,h) 350 x 250 x 256 mm Max workpiece dimensions (w,d,h) 750 x 550 x 250 mm Wire Diameters 0.15 - 0.30 mm Roughness (Ra) 0.07 µm
Smart Options SETUP 3D, IVU advanced x 156 Machine location Germany
Available from Beginning of October Warranty 12 months
AgieCharmilles FORM 200 New machine
X, Y, Z travel (w,d,h) 350 x 250 x 300 mm Roughness (Ra) 0.08 µm
Max electrode weight 50 kg Max workpiece weight 500 kg Smart Options 3DS Texturing Machine location Czech Republic Available from Mid of December Warranty 12 months
AgieCharmilles FORM 2000VHP New machine
X, Y, Z travel (w,d,h) 400 x 300 x 350 mm Roughness (Ra) 0.08 µm
Max electrode weight 100 kg Max workpiece weight 800 kg Smart Options –
Machine location Factory stock Available from Beginning of October Warranty 12 months
AgieCharmilles FORM 30 New machine
X, Y, Z travel (w,d,h) 600 x 400 x 400 mm Roughness (Ra) 0.1 µm
Max electrode weight 100 kg Max workpiece weight 1.000 kg Smart Options –
Machine location Factory stock Available from Beginning of October Warranty 12 months
AgieCharmilles FORM 200 New machine
X, Y, Z travel (w,d,h) 350 x 250 x 300 mm Roughness (Ra) 0.08 µm
Max electrode weight 50 kg Max workpiece weight 500 kg Smart Options –
Machine location Factory stock Available from Beginning of October Warranty 12 months
AgieCharmilles CUT 30P New machine
X, Y, Z travel (w,d,h) 600 x 400 x 350 mm Max workpiece dimensions (w,d,h) 1.030 x 800 x 350 mm Wire Diameters 0.15 - 0.30 mm Roughness (Ra) 0.25 µm Smart Options – Machine location Poland
Available from Beginning of October Warranty 12 months
Die-sinking EDM
* The machines detailed within this campaign are available subject to prior sale. Technical specifications and images arenot binding and maybe modified without notice. Delivery before the end of December 2015 is subject to orders being placed to GF Machining Solutions by week 50-2015. This promotion is valid until 31 December 2015. General Terms and Conditions apply and available upon request.
* The machines detailed within this campaign are available subject to prior sale. Technical specifications and images arenot binding and maybe modified without notice. Delivery before the end of December 2015 is subject to orders being placed to GF Machining Solutions by week 50-2015. This promotion is valid until 31 December 2015. General Terms and Conditions apply and available upon request.
Special Offer: Transport included Special Offer: Transport included Special Offer: Transport included
Ready for delivery Ready for delivery
AgieCharmilles
CUT 300 Sp
AgieCharmilles CUT 300 Sp Demo machine
X, Y, Z travel (w,d,h) 550 x 350 x 400 mm Max workpiece dimensions (w,d,h) 1.200 x 700 x 400 mm Wire Diameters 0.07 - 0.33 mm Roughness (Ra) 0.1 µm
Smart Options Taper Expert, Multijet, AC Opticam 3D Machine location Czech Republic
Available from Mid of December Warranty 12 months
GF Machining Solutions GmbH Steinbeisstraße 22-24 73614 Schorndorf Deutschland +49 (0) 7181 926 0 +49 (0) 7181 926 190 www.gfms.com/de
GF Machining Solutions SpA
Via Monte Nevoso 2 20095 Cusano Milanino Italy
+39 02 66 42 61 +39 02 66 42 63 20 www.gfms.com/it
GF Machining Solutions SAS
12 Avenue du 1er Mai 91127 Palaiseau Cedex France +33 (0)1 69 31 69 00 +33 (0)1 69 31 69 67 www.gfms.com/fr GF Machining Solutions Ltd North View
CV2 2SJ Coventry West Midlands United Kingdom +44 (0) 247 653 8666 +44 (0) 247 653 0023 www.gfms.com/uk GF Machining Solutions International SA
Via dei Pioppi 2 6616 Losone Switzerland +41 (0) 91 806 90 30 +41 (0) 91 806 90 33 www.gfms.com/ch GF Machining Solutions International SA
Branch Office Austria Hammerstrasse 17 4453 Trattenbach Österreich +43 (0) 2 782 800 30 08 www.gfms.com/at GF Machining Solutions International SA
Branch Office Benelux Spikweien 21 5943 AC Lomm Nederland +31 (0) 77 473 82 00 +31 (0) 77 473 21 75 www.gfms.com/nl
GF Machining Solutions S.A.U.
Riera de Fonollar 41-A 08830 Sant Boi de Llobregat, Barcelona España +34 (0) 93 652 95 50 +34 (0) 93 652 56 74 www.gfms.com/es Provozovna
GF Machining Solutions s.r.o.
Podolí 488 664 03 Podolí Česká republika +42 (0) 511 120 200 +42 (0) 511 120 201 www.gfms.com/cz
GF Machining Solutions Sp. z o.o.
Aleja Krakowska 81 Sękocin Nowy 05-090 Raszyn / Warszawa Polska +48 (0) 22 326 50 50 +48 (0) 22 326 50 99 www.gfms.com/pl
AgieCharmilles
LASER 1000 5Ax
AgieCharmilles
DRILL 300
AgieCharmilles
LASER 1200 5Ax
AgieCharmilles
DRILL 20
AgieCharmilles LASER 1000 5Ax New machine
X, Y, Z travel (w,d,h) 995 x 550 x 845 mm
Nr. of axes 5
Max. workpiece weight (5-axis) 1.700 kg Focal lenses included Yes - F254 Smart Options –
Machine location Factory stock Available from End of October Warranty 12 months
AgieCharmilles DRILL 300 Used machine
X, Y, Z travel (w,d,h) 600 x 400 x 450 mm Electrode diameter 0.3 ~ 3.0 mm Electrods change AEC/AGC 16/4 Max workpiece weight 1.000 kg Smart Options – Machine location Italy
Available from Beginning of October Warranty 6 months
Year of Manufacture 2014 Worked hours 2.800
AgieCharmilles LASER 1200 5Ax New machine
X, Y, Z travel (w,d,h) 1.200 x 900 x 1.200 mm
Nr. of axes 5
Max. workpiece weight (5-axis) 1.700 kg Focal lenses included Yes - F254 Smart Options –
Machine location Factory stock Available from Beginning of October Warranty 12 months
AgieCharmilles DRILL 20 New machine
X, Y, Z travel (w,d,h) 300 x 200 x 300 mm Electrode diameter 0.1 ~ 3.0 mm Electrods change –
Max workpiece weight 300 kg Smart Options –
Machine location Factory stock Available from Beginning of October Warranty 12 months
Laser
GF Machining Solutions
At a glance
We enable our customers to run their businesses
efficiently and effectively by offering innovative
Milling, EDM, Laser and Automation solutions.
A comprehensive package of Customer Services
completes our proposition.
www.gfms.com
