Cloud infrastructure challenges faced by enterprises

To achieve lower TCO and enhance operational efficiency, carriers and enterprises are migrating existing IT infrastructure and applications into virtualized clouds. Besides the TCO savings of the internal IT, enterprises are benefiting a lot from the new business opportunities via cloud. Cloud being adopted in business application systems effectively shortens the service deployment cycle and simplifies infrastructure planning and management. But, the migration into cloud also creates some key challenges:

1. Commercial and technical challenges for building and managing a distributed, multi-vendor infrastructure. 2. Smooth migration to cloud data center without impact on existing service.

3. Different application scenarios require different infrastructure resources. 4. Supporting both fixed access and mobile access challenges cloud services.

FusionSphere is an open Cloud OS for different industries’ customers, who contains of virtualization platform and cloud management software. FusionSphere could helps enterprises and carriers integrate physical and virtual resources in data centers, optimize service platforms, construct public and private clouds, improve IT infrastructure value, and provide better customer services. July 2014, in the report "Magic Quadrant for x86 Server Virtualization Infrastructure” of Gartner, as the only new member in the report this year，Huawei was evaluated as “an up-and-coming product in emerging markets ". In September 2014, Huawei will launch the FusionSphere 5.0 which combined the open-source OpenStack framework deeply (Huawei has become the Gold member of OpenStack in November 2013), and built more Data Center virtualization capabilities (including SDS, SDN) and enhanced management automation capabilities, and could support Telecom NFV (Network Function Virtualization) Commercial trial. FusionSphere 5.0 will provide a more open, agile, reliable cloud OS for enterprise and carrier customers, and could help customers deploy server virtualization, private cloud, public cloud and hybrid cloud services on-demond. Enterprises can freely choose the 3rd-party cloud products and services through the standard OpenStack architecture and API interface, and make the deployment of cloud computing calmer and easier.

Huawei FusionSphere: An open Cloud OS

• Compatible with OpenStack architecture, AWS APIs etc. • Seamless integration with

heterogeneous infrastructure • Supports private, public and

hybrid clouds

Open and

Compatible

性能领先

Leading

performance

• Leading virtualization performance in SPECvirt testing

• 3x higher performance with distributed storage virtualization

• Largest system capacity in the industry (4096 nodes &80K virtual machines)

Most

efficient and

scalable

• support trusted hosts, credible virtual machine, the credibility of confidential data storage etc.

• milliseconds-level rapid detection of hardware failure, second-level business recovery • Professional tools for reducing

migration cost

• GUI service templates speed implementation

• Virtual data center built within 10 minutes

• Resource scheduling and management across data centers

Flexible

orchestration

FusionSphere

Advantages

Proven Success

Huawei FusionSphere serves customers in 42 countries and regions around the globe, covering fields ranging from government and public utilities to telecommunications, energy, finance, transportation, health care, education, media, manufacturing and other industries. FusionSphere helps customers integrate and optimize their data centers and service platforms, improving system reliability and IT efficiency.

Open &

compatible

architecture

Based on OpenStack architecture, FusionSphere widely support 3rd party vendors’ server, storage, network, and security physical hardware and virtualization software products, and can provide more free and independent choice for customers. In the cloud service level, on the basis of OpenStack, FusionSphere provide data backup, disaster recovery, hot migration, resource scheduling across data centers, telecom cloud customized extensions, business resiliency scheduling, intelligent pipeline scheduling, distributed engines, physical resource pools extended services and so on. FusionSphere could better meet the demand of enterprises to deploy a private cloud, public cloud and hybrid cloud services.

Best

performance of

virtualization

FusionSphere has proven to be one of the most cost-effective virtualization platforms available today. FusionSphere employs a bare-metal virtualization engine that consumes less than 5% of physical CPU resources, yet this engine improves server utilization by up to 80% and reduces costs for IT infrastructure deployment by 30%. In the virtualization industry standard SPECvirt tests, FusionSphere had an outstanding performance. Distributed storage virtualization software has industry-leading performance, 1 TB data reconstruction time is less than 30 minutes, 10 times improvement of IOPS performance.

Secure,

reliable services

FusionSphere provides high availability and metropolitan area active-active Disaster Recovery (DR). These capabilities enable the backup and recovery of IT services that run on the FusionSphere platform to be backed up and recovered in the event of a disaster. Live migration allows the system to be upgraded or maintained without service interruption. And Huawei proprietary Health Advisor and Operation Recorder are able to provide operator early warning service and fast fault positioning for system exceptions.

Easy and

effective

operation

System operation is the key element that determines the level of virtualization system utilization efficiency for enterprise cloud computing. FusionSphere provides graphics-based application templates to implement one-click application deployment and more effective Operation and Maintenance (O&M). It could enable customers to create virtual data centers fast, simplifying cloud computing operations. FusionSphere’s open and integrated platform also offers Huawei's extended Application Programming Interfaces (APIs) and also the OpenStack APIs as well, allowing customers to quickly deploy on-demand cloud services.

FusionSphere utilizes the layered structure, and consists of two main components:

• FusionCompute: the virtualization engine. The main ability is to virtualize hardware resources, sharing of resources reuse;

• FusionManager: the cloud management node. It manages the virtualized resources and hardware resources, and provides other management functions such as service management.

In addition, FusionSphere also offers FusionSphere OpenStack, FusionStorage, FusionNetwork, UlterVR( disaster recovery software) and HyperDP( backup software), etc.

FusionSphere Layered Architecture

OpenStack API Cloud Storage API SNMP NBI

FusionSphere

Service Abstraction Layer

FusionManager

FusionStorage FusionCompute FusionNetwork

Hardware Infrastructure Nova

Nova-Compute Driver

Cinder

Cinder-Volume Driver

Neutron

Automation scheduling Cloud storage Management

Organization VDC Management SNMP Automatic OM Unified Portal Alarm monitoring

log file Neutron Plug-in

Server Storage Network & Security

SDS VRM SDN

StorHyper UVP VSA

Service Repr

esentation

FusionCompute Features & Capabilities

FusionCompute virtualizes servers, storage, and network resources and integrates them as an elastic IT resource pool. FusionCompute hides any differences in the underlying hardware from services and implements automatic virtual resource scheduling and management. It supports VxLAN networking and storage QoS control and also provides a variety of cloud infrastructure services and open O&M APIs, simplifying IT service virtualization for both carriers and enterprises. While improving IT resource utilization efficiency, FusionCompute accelerates service provisioning while improving IT resource utilization efficiency.

VM

FusionCompute

Availability

VMs Hot Migration Snapshot

HA

Computing Virtualization

bare-metal virtualization VMs QoS

VMs Resource dynamic adjustment Power Management

Storage Virtualization

Distributed Shared Storage small-scale configuration

Storage QoS Storage Hot Migration

Network Virtualization

Distributed vSwitch Network I/O Control

VXLAN Elastic vSwitch

Maintainability

Kbox System fault alarm System log management

Safety

Safety Optimization vFW Management Safety

FusionNetwork Features & Capabilities

FusionNetwork offers the evolution plan from traditional virtual switching to future software-defined network, and completes the network SDN automated configuration deployment by Huawei SDN Controller, SLA QOS control, multi-tenant isolation and stratification. FusionNetwork also integrates network services unit such as VSAM / VSA, Load Balance, DHCP, Route, Firewall and other basic network services. So it could reduce costs, increase the networking flexibility for customers. FusionNetwork ensures that the data center network is highly automatic, intelligent, dynamic programmable and application-oriented multi-level security.

Telecom element

VAS

_vDC/vApp

BSS/OSS

FusionSphere

FusionManager

Orchestration

service request (SR) Service assurance (SA) Deployment & OM automation

FusionCompute FusionStorage

Server vSwitch

VM VM VSA

FS C/S VSAM/VSA FusionNetwork SDN Controller Server vSwitch VM VM FS C/S Server LXC FS C/S VM VM iNIC

FusionStorage Features & Capabilities

Storage Interface

Layer

SCSI driver、iSCSI

distributed linked clone

Backup

Disaster Recovery

Cluster fault healing Distributed Snapshot

Distributed thin provisioning

Cluster state control Strong Consistency Copy protocol Distributed Cache

Distributed data routing parallel data reconstruction Storage

Service Layer

Storage

Management

Storage Engine Layer

FusionStorage is a distributed storage software, which be deployed on x86 server to organize all servers’ local hard disks into a virtual storage resource pool, and then to provide block storage capabilities. The advantages of FusionStorage are shown below:

Fully distributed architecture, distributed management of clusters, distributed HASH-data routing algorithms, distributed stateless head, distributed intelligence Cache, etc. All of those ensure that the whole storage system hasn’t the single point of failure.

Leading Distributed Architecture

Parallel fast fault reconstruction

Easy expansion

and ultra-large capacity

Computing and storage convergence deeply

High performance and high reliability

Load balance across all disks, and the data scattered storage avoid the hot-point. Efficient routing algorithms and distributed Cache technology ensure the high performance. FusionStorage support multiple data copies and each copy distribute in different servers / disks, any single hardware failure does not affect the business.

Data fragmentation was broken up in the resource pool, and after any hard disk failure, system could automatically parallel reconstruct the fault data in the whole resource pool range efficiently.

FusionStorage distributed stateless head can scale out, the storage could synchronize smooth expansion with server, and support ultra-large capacity.

FusionStorage deployed on the local hard disk, and organized each local hard disk of sever into a virtual pool of resources. So it naturally supports convergence of computing and storage devices.

FusionSphere OpenStack Features & Capabilities

Notes: as a stand-alone release, FusionSphere OpenStack 5.0 is only allowed for NFV scene currently.

FusionSphere OpenStack expands some features needed by carriers and enterprises to build IT infrastructure and business platform on the basis of OpenStack architecture, and achieves the unified open cloud platform architecture to support the public and private cloud management. It keeps the compatibility of OpenStack, and supports the 3th-party vendors’

computing, storage, network and security physical hardware, and also supports 3th-party server virtualization, storage virtualization, network virtualization and security virtualization products. In the cloud service level, based on OpenStack it further provides backup, hot migration, affinity resource scheduling, and customized telecom cloud expansion, physical resource pools and so on. In O&M level, it provides installation and deployment, upgrade / patch, management data backup / restore, information gathering, health checks and other operation and maintenance services.

Highlights:

• Openness: native compatible to North and South interface of OpenStack.

• Compatibility: other vendors' plug access to Huawei FusionSphere, such as SAN device plug-in. • NFV integration: pre-integration with Huawei telecom elements to meet the needs of carriers NFV.

IT Middleware

Network Middleware

FusionSphere 5.0

FusionManager

FusionSphere OpenStack

Portal vDC vAPP

NOVA Cinder

FusionCompute

UVP MaaS

FusionStorage

SDS-Controller StorHyper

FusionNetwork

VSA Neutron Keystone _deploymentAutomatic High reliable _framework

Glance Swift Lossless

upgrade schedulingAdvanced

Telecom HW COTS HW Storage Network

TNMS Enterprise IT Management Sys

MANO (Orchestrator/VNF

Manager)

EMS OSS/_BSS

SDN-Controller

Huawei FusionSphere features the industry's highest system capacity with top-ranked performance and has wide application in a variety of service deployment scenarios for carriers and enterprises. The following table lists the performance specifications for FusionSphere.

Performance Specifications

FusionManager Features & Capabilities

FusionManager enables customers to manage virtualized resources in a unified way with functions such as service catalogs, automatic resource provisioning, and automatic service deployment. FusionManager can manage third-party virtualization platforms so that allowing customers to schedule and manage virtualized resources with one interface, improving O&M efficiency. FusionManager also ensures system security and reliability, helping carriers and enterprises implement secure and low-power cloud data centers.

• hardware, virtual platforms, and applications unified management • Multi-vendor virtualization platforms,

hardware unified management • Organization VDC Management • rights- and domain-based management,

role-based access control

Unified management

• Hardware auto-discovery, auto- deployment

• Applications deployment templates, automation

• Resources scheduling on-demand • Service Catalog Management

Automation Management

• software systems, hardware systems unified management

• fully resources, topology, alarms, logs, and monitoring mechanism

• Performance Reports

Troubleshooting

System capacity Specifications

Maximum number of hosts supported by a VRM(*) node 1024

Maximum number of sites in a VRM domain 16

Maximum number of hosts supported by a host cluster 128(for LUN Storage)/64(for Storage Virtualization)

Maximum number of physical servers supported by the system 4096

Maximum number of VMs supported by the system 80000

One Physical server Specifications

Maximum CPU logical cores 512

Maximum RAM 16TB

Maximum VMs 1024

VM(Virtual Machine) Specifications

Maximum number of vCPUs supported by a VM 128

Telecommunication services have gone global with cloud computing, intelligent pipes, and mobile Internet, requiring more telecom companies to focus on Iinformation and Ccommunication Ttechnology (ICT) services for enterprises. In 2011, Sichuan Telecom launched the Cloud Sea project to develop its ICT services. This project uses Huawei FusionSphere, which integrates all existing infrastructure into one cloud computing resource pool, enabling Sichuan Telecom to provide cloud desktops to internal employees, integrate the service platform, and provide Virtual Private Server (VPS) services to external customers.

This project helped Sichuan Telecom increase its server utilization efficiency from 15% to 85% and shorten service rollout time by 80%. All resources can now be shared and managed in a unified way, while reducing power consumption significantly.

Sichuan Telecom: Transformation to ICT sServices

Success Stories

For more cases of other industries, please refer to the <Huawei cloud

computing case set>, or login Huawei official website.

China Fujian Province Administration for Industry and Commerce:

Huawei cloud computing and government affairs virtualization

The Administration for Industry and Commerce of Fujian is the provincial agency responsible for market supervision and management. The administration has 511 branches throughout the province. Huawei helped the administration build a cloud data center that includes two local disaster recovery centers in Fuzhou city and an inter-city backup center in Sanming city. Using FusionSphere, Huawei deployed virtual desktops and separated the administration’s external and internal networks on the service platform. With resource virtualization and unified resource scheduling, the solution greatly improves the agency’s efficiency. Compared with the budget what service platform construction without virtualization, this project reduced construction cost by 30%.

Huawei FusionSphere help dig out the China State

Grid’s potential of IT infrastructure

China State Grid Corporation, who build and operate the grid as its core business, and cover 88% area of China, over 1.1 billion population, is the world's largest power company. On 2013, Huawei FusionSphere ranks first in the State Grid’s virtualization testing program and win the information system server virtualization projects of State Grid. Through the use of a number of provinces By using Huawei FusionSphere server virtualization and cloud management technology, the server utilization rate of State Grid increased up 30%, the annual purchase demand for new server fell 30%, and the cost of energy saves up to ten million RMB, the efficiency of operation and maintenance improves10 times.

FusionSphere Offerings

Huawei charges for FusionSphere services using only the number of CPUs on existing servers and does not count any other in-use physical resources. Customers can try FusionSphere services in advance by taking advantage of the Huawei FusionSphere Foundation license for 6CPUs free trial. For more CPUs, customers can purchase a license to activate the full commercial version of the product. FusionSphere provides other three types of commercial licenses: FusionSphere Standard, Advanced, and Platinum. These licenses differ by function and price, as summarized in the table below.

Category Feature Product FusionSphere Offerings

Foundation Standard Advanced Platinum

Virtualization

Computing Virtualization

Fusion Compute

★ ★ ★ ★

Storage Virtualization ★ ★ ★ ★

Network Virtualization ★ ★ ★ ★

VM Reliability ★ ★ ★ ★

Security Management ★ ★ ★ ★

Virtualization Antivirus ★ ★ ★

VXLAN ★ ★

VDC

Security Management

Fusion Manager

★ ★ ★

Infrastructure Operation

Management ★ ★ ★

VPC Management ★ ★ ★

Measurement ★ ★ ★

Application Automatic

Deployment ★ ★ ★

Application Monitoring ★ ★ ★

Hypervisor Compatibility ★ ★ ★

Hardware Management ★ ★ ★

Cloud Services

Cloud Services API ★

Multi-DCs Management ★

Load Balance Service ★ ★ ★

Disaster Recovery

Data Protection HyperDP ★ ★ ★

Disaster Recovery UltraVR 　 　 ★

Performance

Optimization Performance Optimization FusionSphere SOI ☆ ☆ ☆

Enterprise customers are invited to visit the following website to purchase license as a registered partner:

http://enterprise.huawei.com/en/partners

Telecom carriers can contact a local branch office for more information:

Notes: Features listed in the above table is just only function frame of FusionSphere modules, for more feature details, please refer to the <Huawei FusionSphere feature list>.
