Large-scale solar heating plants

(1)

1

www.arcon.dk

arcon solar

large-scale

solar heating

plants

(2)

2

One thing is certain: the sun rises each and every day. Besides giving light and life, the sun emits enormous amounts of energy – and heat. A solar heating system from ARCON Solar can help ensure the lowest possible heating costs. Besides which, the sun is the cleanest of all energy sources – it emits no CO₂ – and solar heating systems make no noise and do not spoil the look of the countryside.

In contrast to most other energy sources, solar heating systems ensure fixed low energy costs for many years to come. That is why there has been considerable growth in the number of new, large-scale solar heating installations, especially in connection with district heating plants. Many additional installations are in the pipeline and many of the plants that already have solar heating wish to expand their capacity. Similar developments are expected within industrial process heat. A large-scale solar heating system costs per m2_{about a fifth of the price of a} small-scale system fitted to the roof of a house. Three large-small-scale solar collectors can provide as much energy annually as that required to provide an average single-family house with district heating.

It is, in other words, not so much a question of whether or not to invest in solar heating but more of identifying the best solar heating solution.

the world’s best

energy

is

(3)

3 2 4 6 8 12 14 16 18 economy environment

independence

stabilise the price of your

heating

While the price of fuels will rise in future, the sun provides energy at a fixed price: zero. As a result, the greater the proportion of a district heating plant's energy requirements which can be met by the sun, the better it will be for the plant's customers.

reduce global warming

Contribute to a sustainable future. The sun is our most powerful source of sustainable energy. A typical solar heating installation will reduce a

district heating plant's CO₂ emission by about 1 ton for each household

it supplies.

gain a significant saving

on heating price

A typical solar heating installation will allow a district heating plant to lower its prices from day one. In some cases by as much as 20%.

Why solar energy? ARCON Solar Process Products Applications District heating Commercial XL Industrial process heat

(4)

4

FLeXIBLe APPROACh

Solar heating systems from ARCON Solar can be installed in conjunction with any type of heating plant. Solutions can be chosen which provide as much as 50% of the energy produced. And if a smaller system is initially installed, it can always be extended later.

eXPeRIeNCe, COMPeTeNCe AND kNOW-hOW

ARCON Solar has worked with solar heating for more than 35 years and has installed more square metres of large-scale solar heating plants that any other company. Besides unique knowledge of the solar collectors themselves, ARCON Solar has extensive experience in all aspects of solar heating plant installation and can therefore help with system design, dimensioning and optimisation.

BeST PRODuCT

Specially designed to meet the characteristics and requirements of large-scale solar heating plants, the hT solar collector has higher output than any other collector on the market.

No-one knows more about large-scale solar heating plants than ARCON Solar. More than half the large-scale solar heating plants in europe have been instal-led by ARCON Solar. The oldest plant can celebrate its twenty-fifth anniversary in 2013, provi ding unique historical documentation of operating results and efficiency.

the world’s

leading

supplier

of

large-scale solar heating

plants

(5)

5 ARCON Solar is behind most of the large-scale solar heating plants already

established. 15 of the 25 largest plants were installed by ARCON Solar. In 2011 alone, ARCON Solar installed 48,000 m2_{of new solar collectors.}

The 10 LARgeST SOLAR heATINg INSTALLATIONS IN euROPe

LOCATION AReA YeAR

1 Marstal – DK 32,943 1996/2001/2012 2 Gråsten – DK 18,988 2012 3 Brædstrup – DK 18,612 2007/2012 4 Vojens – DK 17,500 2012 5 Ringkøbing – DK 15,000 2010 6 Sydfalster – DK 12,094 2011 7 Sæby – DK 11,866 2011 8 Gram – DK 10,077 2009 9 Kungälv – SE 10,048 2000 10 Jægerspris – DK 10,044 2010

(6)

6

We work closely with external consultants and district heating engineers, and are used to participating in all types of project, whether it be turnkey contracts or individual trade contracts.

ARCON Solar wishes to be the preferred solar collector supplier. To this end, we must provide the best product, high quality, professional documentation and project management, and expert technical sparring which ensures the best overall solution.

Our many years’ experience and countless references have given us a unique insight into the various stages involved in the planning and installation of a solar heating system. From consideration, decision taking and approval, through financing, authority approval, earthworks and installation, to testing and commissioning.

arcon solar

can

help

in

all

(7)

7

COS T-BE

NEFIT, POLICY, ENERGY PROFILE

Program

INSTAL

LATION, TEST, CERTIFIC

ATIO_N

Execution

ARCON

INDUSTRIAL

SOLAR CIRCLE

P

ro

je

ct

in

g

O

pe

ra

tio

n

PLA NN ING , D IME N SIO N IN G , P R O D U CT S S E R V IC E , Y E A R L_Y C_H E C_K S

1

2

3

4

COST

-BENEFIT, POLICY, ENERGY PROFIL

E

Program

INST

ALLATION, TEST, CERTIFICATION

Execution

ARCON

INDUSTRIAL

SOLAR CIRCLE

P

ro

je

ct

in

g

O

pe

ra

ti

on

PL_A N N IN G , D IM E N S IO N IN G , P R O D U CT S S E R V IC E , Y E A RL Y C HE CK S

1

2

3

4

As the leading manufacturer of large-scale solar heating systems, ARCON Solar has comprehensive documentation which can be used for techni-cal analyses, techni-calculations and outline proposals.

ARCON Solar performs annual service checks, including physical inspec-tions, to ensure optimum system operation.

ARCON Solar can help define relevant objectives during this stage and can provide input for preliminary overall calculations. ARCON Solar has also considerable experience in selecting suitable installation sites.

ARCON Solar's solar collec tors can be installed at lowest possible cost as they are designed for large-scale installations and can be easily connected in series.

(8)

8

ARCON Solar’s solar collectors are designed and developed for optimum performance in large-scale installations. Combining 40 years’ experience with the very latest technology, we offer high-performance solar collectors capable of operating perfectly at high temperatures for many years. ARCON Solar’s solar collectors are the ideal choice for installations at district heating plants, where it is often necessary to increase production temperature, for energy storage purposes for example.

why not use the

world’s most

efficient solar

collector?

(9)

9

eFFICIeNCY

why not use the

world’s most

efficient solar

collector?

ARCON Solar’s solar collectors are among the most efficient in the world. Their high output is due among other things to the foil used, combined with the anti-reflection treated glass and laser-welded absorber.

hT-SA SOLAR COLLeCTOR OuTPuT [W] Temperature difference [k] Tm_{– T}a Solar radiation [W/m2_] 400 700 1,000 10 3,800 6,870 9,940 30 3,113 6,183 9,253 50 2,290 5,360 8,430

hT-A SOLAR COLLeCTOR OuTPuT [W] Temperature difference [k] Tm_{– T}a Solar radiation [W/m2_] 400 700 1,000 10 3,870 7,070 10,260 30 3,000 6,190 9,390 50 2,000 5,190 8,390 Virkningsgrad Temperaturdifferens Solfanger middeltemp. – udetemperatur ARCON HT-A (uden folie) Standard

villa-solfanger ARCON HT-SA(med folie)

90 % 80 % 70 % 60 % 50 % 40 % 30 % 20 % 10 % 0 % 10o ₂₀o ₃₀o ₄₀o ₅₀o ₆₀o ₇₀o ₈₀o ₉₀o ₁₀₀o 0o 100 % Virkningsgrad Temperaturdifferens Solfanger middeltemp. – udetemperatur ARCON HT-A (uden folie) Standard

90 % 80 % 70 % 60 % 50 % 40 % 30 % 20 % 10 % 0 % 10o ₂₀o ₃₀o ₄₀o ₅₀o ₆₀o ₇₀o ₈₀o ₉₀o ₁₀₀o 0o 100 % Efficiency Temperature difference

Average solar collector temp. – outdoor

temperature

Standard house hold solar collector

Virkningsgrad Temperaturdifferens Solfanger middeltemp. – udetemperatur ARCON HT-A (uden folie) Standard

90 % 80 % 70 % 60 % 50 % 40 % 30 % 20 % 10 % 0 % 10o ₂₀o ₃₀o ₄₀o ₅₀o ₆₀o ₇₀o ₈₀o ₉₀o ₁₀₀o 0o 100 % ARCON HTA

(10)

10

section of ht-sa solar collector

Antireflection treated glass

Aluminium frame FEP foil Side insulation Rear insulation Absorber Foil tensioning

Common for all our solar collectors is that they do the job better than any other solar collector. That’s why we are not afraid to provide a performance guarantee. Although we have listed some of the most important advantages below, we are always delighted to discuss our products in greater detail.

performance

guarantee

on

the world’s best

solar collector

ARCON Solar constantly seeks to find new ways of increasing the durability of its solar collectors. Weather-resistant aluminium frame and brazed joints ensure long service life. Our first large-scale solar heating plant, installed in Denmark (Saltum) in 1988, is still in operation.

By using tried-and-tested materials from european suppliers and manufacturing the solar collectors in our own production facil-lities, we ensure high quality, low transport costs and least possible CO₂ impact.

eXCePTIONAL

DuRABILITY

MANuFACTuReD

BY ARCON SOLAR

Our solar collectors are designed to provide high temperatures. Besides the insulating foil, a high-performance, laser-welded absorber is used. This has an aluminium surface covered in a special selective coating, which ensures that almost all the sun's rays are captured and converted to heat.

OPTIMISeD

DeSIgN

foil between absorber and glass

Foil positioned 20 mm from the glass creates an insulating effect, which reduces heat loss. In addition to this, the solar collector is insulated with an extra thick layer of mineral wool. The combined effect increases efficiency by up to 20%.

(11)

11

Thanks to low pressure drop, up to 22 solar collectors can be connected in series simply by attaching a flexible, stainless steel pipe. Piping is thus kept to a minimum, ensuring simple, cost-effective installation.

The high quality and durability of our solar collectors, together with our many years' experience, mean we can offer a performance guarantee on our installations.

LOW INSTALLATION

COSTS

PeRFORMANCe

guARANTee

Our solar collectors can be combined at will, i.e. different collectors can be installed in the same row. While solar collectors without foil are good at low temperatures, the insulating foil increases output at high temperatures. A combination of the two types provides optimum efficiency along the entire row of collectors.

FLeXIBLe PRODuCT

RANge

arcon ht-a arcon ht-sa

External dimensions 2.27 x 5.96 x 0.14 m 2.27 x 5.96 x 0.14 m

Total area 13.57 m2 _{13.57 m}2

Effective area 12.60 m2 _{12.52 m}2

Weight without liquid 250 kg 250 kg

Liquid content 9.3 l 9.3 l

Insulation on rear 75 mm mineral wool 75 mm mineral wool

Insulation on sides 30 mm mineral wool 30 mm mineral wool

Glass Antireflection treated Antireflection treated

Insulating foil No foil FEP foil

Connectors 28 mm 28 mm

Testing pressure 13 bar 13 bar

Max. working pressure 10 bar 10 bar

efficiency

N0 0.845 0.817

a1 2.94 2.205

a2 0.0130 0.0135

Standard solar collectors are supplied with 28 mm connectors and 10 mm strips. Commonly known as 28/10. To ensure optimum pressure throughout the field, collectors are also available in 35/10 and 28/8 variants. Our solar collectors are thus available in six different variants, which can be combined at will.

(12)

12

Since 1974, we have installed more than 300,000 m2_{of solar collectors in Denmark and other}

countries. We have installed systems in a great variety of locations, including heat stations, decentralised district heating plants, housing complexes, sports centres and swimming pools, holiday centres and camping sites, hotels and conference centres, care centres, schools, offices and businesses.

our

solar

collectors

provide

unlimited

efficiency

for large-scale heating

solutions

(13)

13

A large-scale solar heating installation is the perfect supplement to a district heating plant, regardless of the fuel type used. A fixed low heating price can thus be assured for many years to come.

DISTRICT heATINg PLANTS

ARCON Solar has good experience with systems installed in buildings where large quantities of hot water are required. In such cases, any surplus heat produced can be used to heat either rooms or swimming pools.

CARe CeNTReS, hOLIDAY CeNTReS

AND hOuSINg COMPLeXeS

As industry uses energy both for heating purposes and for industrial processes, it can utilise the high temperatures obtainable in a solar heating system.

(14)

14 Tid Varmepris Installation af solvarmeanlæg Installation of solar heating system Heating price Time Tid Varmepris Installation af solvarmeanlæg Installation of solar heating system Heating price Time

district heating

A large-scale solar heating installation is the perfect supplement to

a district heating plant, regardless of the fuel type used.

A solar heating plant supplies a known amount of free energy each year, thus help-ing to stabilise heathelp-ing costs. The price of all other fuels is expected to rise over time.

Our solar heating systems can be installed in conjunction with any type of heating plant. Solutions can be chosen in which solar heating provides up to 50% of the energy produced. And if a smaller system is initially installed, it can always be extended later.

STABLe

heATINg PRICe

FuLL

FLeXIBILITY

A solar heating plant can give good sav-ings. We have seen examples where average households can save up to Dkk 3,500 in the first year. And this saving will rise in step with increasing cost of other energy types.

LOWeR

(15)

15 www.arcon.dk

large installatio

ns,

huge savings

Arcon SolAr Sol_{Ar heAting pl}

AntS for diStrict he_{Ating compAnieS}

FuRTheR INFORMATION

Read all about ARCON Solar’s district heating solutions in this brochure.

ARCON Solar’s solar collectors can be installed at lowest possible cost as they are designed for large-scale installations and can be easily connected in series.

Installing a solar heating system will prolong the lifetime of the rest of the plant.

(16)

16 2025 2030 2035 2040 2020 Tid Varmepris Installation af solvarmeanlæg Installation of solar heating system Heating price Time

care centres,

holiday centres and

housing complexes

ARCON Solar has good experience with systems installed in buildings where large quantities of hot water are required. In such cases, any surplus heat produced can be used to heat either rooms or swimming pools.

gReeN PROFILe

FuTuRe-PROOFeD

STABLe heATINg PRICe

The sun is a source of energy that will con-tinue to shine for countless years to come. Current trends indicate an increase in the proportion of hot water and heating provided by solar energy.

Worldwide, there is greater focus on the enviro n -ment and on how we can minimise environ-mental impacts. The sun is the most environmentally friendly of all energy sources and the installation of a solar heating system signals a strong desire to protect the environment. A solar heating system supplies a known

amount of free energy each year, thus help-ing to stabilise heathelp-ing costs. The price of all other fuels is expected to rise over time.

(17)

17

COST

-BENEFIT, POLICY, ENERGY PROFILE Program

INST

ALLATION, TEST, CERTIFICATION Execution ARCON INDUSTRIAL SOLAR CIRCLE P ro je ct in g O pe ra ti on PL_A N_N IN G , D_IM E N S IO N IN G , P R O D U CT S S E R V IC E , Y E A R L Y CH ECK S

1

2

3

4

Tid Varmepris Installation af solvarmeanlæg Installation of solar heating system Heating price Time

care centres,

holiday centres and

housing complexes

FuRTheR INFORMATION

If you have any questions or would like further information, please call us on +45 9839 1477. We are waiting by the phone and will be pleased to help you clarify the possibilities of installing a large-scale solar heating system which meets your needs.

You can also find further information on our website: www.arcon.dk.

CheAP eNeRgY

eXPeRTISe

Installing a solar heating system is the cheap-est way of fulfilling requirements on minimis-ing the use of fossil fuels.

Solar heating systems must be installed cor-rectly. Although they can be combined with almost any other heating system, expertise is required to be accomplished in the proper way. ARCON Solar’s many years’ experience can help in all stages concerning the estab-lishment or renovation of energy systems.

(18)

18 Tid Varmepris Installation af solvarmeanlæg Installation of solar heating system Heating price Time Tid Varmepris Installation af solvarmeanlæg Installation of solar heating system Heating price Time As industry uses energy both for heating purposes and for industrial processes, it can utilise the high temperatures obtainable in a solar heating system.

industrial

process heat

A solar heating system supplies a known amount of free energy each year, thus help-ing to stabilise heathelp-ing costs. The price of all other fuels is expected to rise over time.

Worldwide, there is greater focus on the environ-ment and on how we can minimise environenviron-mental impacts. The sun is the most environmentally friendly of all energy sources and the installation of a solar heating system signals a strong desire to protect the environment.

CheAP eNeRgY

Installing a solar heating system is the cheap-est way of fulfilling requirements on minimi-sing the use of fossil fuels.

gReeN PROFILe

STABLe heATINg PRICe

(19)

19

COST

-BENEFIT, POLICY, ENERGY PROFILE Program

INST

ALLATION, TEST, CERTIFICATION Execution ARCON INDUSTRIAL SOLAR CIRCLE P ro je ct in g O pe ra tion PL_A N_N IN G , D_IM E N S IO N IN G , P R O D U CT S S E R V IC E , Y E A R LY CH ECK S

1

2

3

4

2025 2030 2035 2040 2020

The sun is a source of energy that will con-tinue to shine for countless years to come. Current trends indicate an increase in the proportion of hot water and heating provided by solar energy.

Solar heating systems must be installed cor-rectly. Although they can be combined with almost any other heating system, expertise is required to be accomplished in the proper way. ARCON Solar’s many years’ experience can help in all stages concerning the estab-lishment or renovation of energy systems.

eXPeRTISe

FuTuRe-PROOFeD

INTegRATION

FuRTheR INFORMATION

If you have any questions or would like further information, please call us on +45 9839 1477. We are waiting by the phone and will be pleased to help you clarify the possibilities of installing a large-scale solar heating system which meets your needs.

You can also find further information on our website: www.arcon.dk.

(20)

20

ARCON Solar is europe’s leading expert in large-scale solar heating solutions. If a smaller system can meet your requirements, this can be provided by SONNeNkRAFT®_{, a sister company to ARCON Solar. Together, we offer solutions capable of meeting any}

needs for hot water, room heating and electricity, from small-scale installations for private households to large-scale installations for industrial companies.

We have extensive experience in developing individual solutions for hotels, schools, apartment buildings, hospitals, etc.

business

We have supplied more than 50% of all solar heating installations larger than 1.000 m2_{in europe.}

industry

We offer the largest range of solutions for your home or swimming pool.

home

olar and the AR

C ON S olar logo ar e tr ademark s belonging t o VKR Holding A/ S

contact arcon solar today.

the sun will rise again, as early as tomorrow.

ARCON Solar A/S • Skørping Nord 3 • DK-9520 Skørping • Denmark Tel.: +45 9839 1477 • [email protected] • www.arcon.dk
