Complete Data Center.

(1)

Complete–Data–Center

(2)

Compact. Validated. Turnkey-ready.

Complete-Data-Center for virtual environments

Has the IT environment of your company grown over time historically?

Do you face continuous growth and have a high expectation on IT security?

Run-rate changes are complicated and time consuming!

Our Complete-Data-Center is exactly the right solution you are looking for.

The CDC system is a safe, fire-protected and

vandal-proof IT container.

Only renowned manufacturers provide the necessary infrastructure components for secure operation.

They match perfectly – best-practice-design and commendable, instant ease of use. A 30 m² turnkey-ready system only requires connection to a network and power. The user-side contribution of the active IT technology takes place independently of the manufacturer. Coarse and fine art are spatially separated from each other and thus facilitate the implementa-tion of safety-related access restricimplementa-tions. Besides, the system distinguishes itself by its inherent flexibility – completely independent of application case, whether its an expansion due to limited space or an opportunity to provide a redundant infrastructure:

Our CDC container is always the right choice.

Best-practice-design

The tried-and-tested room layout to suit all the requirements of the components can be called

undoubtedly „best practice“. Coarse technology (FM) and fine technology (IT) are separated by a grid wall. Access restrictions, for example, for maintenance personnel, is easier to implement.

A further added benefit is that: the CDC is

not visible from the outside as is the case with a conventional data-center.

Flush mounting parts are not only visually appealing, they also simplify overall handling. Fire prevention with oxygen reduction form part of the standard design. Optimised reliability

and reduced operation costs are assured by

most efficient precision air conditioning and UPS systems.

The complete system is based on the fundamentals of TÜV Rheinland Consulting criteria catalog and is instantaneously suitable CAT 2 classification. In addition, the possibility of a RC4 classification exists to German Institute for Standardisation EN 1630 for the container shell. The whole security concept can be expanded on customer request. The following technology experts are involved in the realisation of your

turnkey-ready CDC container:

W DENIOS AG (fire compartment) W Panduit (passive IT infrastructure) W Socomec UPS GmbH

(safe, uninterruptible power supply) W STULZ GmbH (air conditioning) W Tyco Security Products EMEA (Safety & Security technology)

W WAGNER Group GmbH (fire detection, fire fighting and fire prevention technology) CHG-MERIDIAN is available as a partner modeling the right financing options of your CDC solution.

(3)

The technical department

In the technology space the following components are accommodated:

W Air conditioning technology in redundant design W Early fire detection and fire prevention system W Fire alarm control panel (FACP)

W Uninterruptible Power Supply (UPS) W Low-voltage main distribution (LVMD)

W Video management, access control and monitoring system with operator station

OxyReduct® _{– fire protection system}

W Fire prevention by oxygen reduction W Protective atmosphere can be maintained as long as desired

W Easy to maintain W High functional reliability

GreenPower 2.0 – reliable power supply

W Highest certified efficiency for reducing economic power consumption

W Maximum availability about single- and redundant architectures

W UPS design kW = kVA for data center and IT loads

Double safety in case of fire

The container shell provides full fire protection against risks both internally and externally. In addition to the fire prevention system via the reduction of oxygen inside the container, no emergency power shut down is required in the case of fire. Meanwhile, the data availability remains guaranteed.

CyberAir 3 – Closed-circuit precision air-conditioning system

W Operational reliability through redundant cooling design W Efficient operation by EC fan and optional EC compressor W Scalable in size and performance

W Components requiring maintenance are front accessible

Intevo – Security Management & Monitoring System

W Access control system W Integrated IP video solution

W Monitoring for FACP, UPS, air condition etc. W Optional: operation and service by Web and App (iOS / Android)

(4)

The server room

For the room layout there are several options available. Up to seven IT equipment cabinets with fully usable 42 HU can be easily accommodated. Convenient access to the racks is guaranteed regardless of the complex configurations. Above the IT cabinets, waste heat is combined and discharged into an air channel. The handling the highest packing densities thus also energetically not a problem. The system does feature preinstalled basic cabling infrastructures. The complete media distribution is installed by means of a specialised overhead cable pathway.

Due to the omission of a false floor comfortable access heights can be achieved.

Net-Access™ – data closet system

W Designed with IT hardware manufacturers for maximum energy efficiency

W Thorough hot-/cold aisle separation

W Optimum room condition by vertical exhaust system W Seamless and fully integrated cable management W „WyrGrid“ flexible cable pathways

(5)

Ten good reasons

... for your high-performance CDC

1

Review of your IT infrastructure to optimise the level of your CDC

2

3

4

5

Critical factors such as air conditioning, fire protection and secure power are optimised for increased reliability and efficiency

Growth and the increasing demands of the physical IT industry are considered and planned for

One central location and a single contact, per system owner, for all infrastructure commu-nications simplifies the process and provides cost savings in IT and facilities management

You will receive a state of the art, tried and tested solution, specifically designed for your needs

6

7

8

9

10

Through our established and internationally operating partners, your long term budgeting, planning and reliability are assured

CDC provides excellent value for money

Whether you are purchasing or leasing, we have the packages to meet your service and maintenance requirements

A turnkey-ready CDC can be available to you in a minimal amount of time

Your CDC ensures future challenges can be overcome safely

Flexibility by optimised interior design –

a sophisticated and integrated package
