(LEAN) PROCESSPLANNING in the DESIGN PHASE

(1)

CASE: ACADEMY OF ART AND DESIGN IN BERGEN (KHIB)

(2)

(3)

KHIB: SOME FACTS…

Projectstart and designcompetition: Autumn 2005 Granting of final construction work fundings: June 2013

Total budget (pr. July 2013): 1.038 mill. NOK (incl. VAT) Floor space (pr. July 2013): 14.500 sqm

Schedule:

2014: Detailled design / Demolition / Ground preparations 2015: Foundation works / Framework / Enveloping

2017: Scheduled completion Q2

OWNER - CLIENT: Statsbygg

ARCHITECTS: Snöhetta

(4)

1) Experiences from Lean Construction (ie. UiO Domus Medica, Oslo) 2) Lean construction seminars (ie. Porsche Consulting)

3) Takt - Train

4) Film-clip: 30 floors in 14 days (China)

And as an objective: A very lean project.

(5)

• Strategy

- An as lean project as possible in design and construction. - Lean on all levels and in all phases.

• Tools - BiM

- dRofus (room functional database)

KHIB PLAN

(6)

GENERAL PROJECT PRINCIPALS



Transparency / Overview / Collaboration



Culture for continous improvement



Lean included in all contract documents



Extended lean requirements for contractors



Reduce, minimize or (preferably) eliminate waste



Flow where possible

(7)

KHIB LEAN STEP BY STEP

1) Pre-Seminar

Discussing and preparing a lean construction strategy. Getting to know the building.

2) Product Creation Process (w/ Porsche Consulting) Project top level overview.

Mindshifting.

3) Now what ..? A design train and takt ..?

4) Developing and improving the lean design process «Unfamiliar territory!»

5) Extended use of lean takt planning and construction with contractors. - Contract review.

- Contract handover (from design to contractors). - Frontloading (putting the puzzle together).

- Lean construction. 6) Lessons learned

(8)

PLANNING USING LAMINATED A0-DRAWINGS

(9)

DRAFT 2ND FLOOR CONSTRUCTION

(10)

1) Pre-Seminar

2) Product Creation Process (w/ Porsche Consulting) Project top level (1) overview.

Mindshifting.

(11)

(12)

(13)

COMPLETE PROCESSMAP LEVEL 1

DEPENDENCIES & TRANSPARENCY EVERYONE ON THE SAME PAGE

(14)

«LEVEL 2 & 3»

COMPLETE PROCESSMAP LEVEL 1

PROCESSES (7)

STATSBYGG PHASES & MILESTONES (MAINTAINED)

(15)



Everyone developed the PCP-level-1-map together.



Everyone’s «on the same page».



Everyone has «the same mind».



Everyone has the same objectives.

(16)

1) Pre-Seminar

Mindshifting.

3) Now what ..? A design train and takt ..? From construction to design.

(17)



Cutting the elephant into minor manageable pieces.



Continous flow to BiM and physical construction.



Restructure flow according to contracts and milestones.



Issues/topics have appointed owners.



2-week «takt» with one 3-day big-room co-location.



Continous priority 1-2-3 (or: must-should-can).



Iteration-steps: 5 fw and 1 bw (instead of 4-3).



Efficiency: 80% effort & 20% time spent (instead of 100-100).

(18)

TOPICS WITH ISSUSES & OWNERS

CONTINOUS FLOW TO THE VIRTUAL BUILDING (BIM) AND

THE PHYSICAL BUILDING

(19)

OWNER TOPIC ISSUES: - RESOURCES - TIME - INPUT DEADLINE «PRODUCT»/OUTPUT

(20)

2-WEEK «TAKT» INCL.

3-DAYS BIG-ROOM CO-LOCATION «TAKT and TRAIN»

(21)

2 WEEK TAKT / WORK PROCEDURE

(22)

1) Pre-Seminar

Mindshifting.

(23)

(24)

TOPICS / OWNERS / PRIORITY / STATUS CONNECTED TO: PROCESSES AND KEYPOINTS (LEVEL 1) «LEVELS 2 & 3» PROCESSES (7)

MILESTONES & KEYPOINTS & BIM-DEVELOPMENT

LEVEL 2 PROJECT DESIGNPLAN (TOPIC OVERVIEW)

(25)

(26)

3-DAYS BIG-ROOM CO-LOCATION

3-DAY MEETING SESSIONS BOOKING LIST

TOPIC OWNER SHARING

TOPIC OWNER

(27)

1) Pre-Seminar

Mindshifting.

(28)



The lean processes in the project are ongoing.



Lean takt-planning and construction are yet to come.

(From 2015 onwards.)

KHiB goal:



The lessons so far learned in KHiB lean design, have

been visualized in this presentation.

(29)



Common mindset for all parties involved in the project



Common objectives and tools and agreed transparency



Lean project strategy (for mindshift, construction and design)



Complete and transparent project processoverview («all in»)



Agreeing on «minor pieces» and continous flow



Assign topics with issues and owners



Agree on work-procedures and managing (decision)levels



Big-room transparency



Putting the pieces together (BiM & construction)

(30)

QUESTIONS…?

(If time…)

(31)

Hans Thomas Holm / Statsbygg

•

Projectmanager with Statsbygg since 2007.

•

Projectmanager for KHiB since June 2013.

•

Email: [email protected]

•

Cell-phone: +47 - 915 73 626

Sven Wertebach / Terramar

•

Projectmanager with Terramar since 2013.

•

Designmanager for KHiB since September 2013.

•

Email: [email protected] / [email protected]
