OVERVIEW
TEAM5 SOFTWARE
The TEAM5 software manages personnel and test data for personal ESD grounding devices.
Test and personnel data may be viewed/reported locally, via a network Web page and emailed automatically on a scheduled or on-demand basis. Robust and easy to use sort/filter capabilities are built in to all reporting controls.
TEAM5 uses date/time stamps on all user requirement changes to comply with quality control and record keeping requirements. This ensures archived tests are always linked to historically accurate personnel data, test requirements.
TEAM5 automatically maintains backups in a redundant network storage area.
The SmartLog V5™ ESD test stations and Network (Multi User) programs operate semi-autonomously to ensure continuous operation even while network or server outages occur.
WINDOWS COMPATIBILITY SYSTEM REQUIREMENTS
2GB Program and Database Disk Space 8GB Backup Disk Space
2GB RAM
1024 x 768 display resolution 1 available USB port 1 or more SmartLog V5™ devices Windows 2003 Server Windows 2008 Server Windows XP SP3 (Recommended) Windows 7 (All Versions) DescoEMIT.com Dated: 2012-01-03
COMMUNICATION
OPTIONS
TEAM5
Single Workstation Setup Single user access to TEAM5
TEAM5 ENTERPRISE Laboratory SmartLog V5™ Clean Room SmartLog V5™ Production SmartLog V5™ Multiple Workstation Setup
USER MANAGEMENT
TEAM5 makes it easy to add and manage users by allowing a entire employee list to be imported. TEAM5 guides you through the importing process and identifies any duplicate entries before the are imported
•
Department Managers – Assigning a manager to a department allows the manager to receive an ESD report for employees in their department•
Leave Time – Schedule when employees will be on leave to eliminate an absent test status on ESD reportsUSER MONITORING
Color coded test results make it easy to indentify the current status of each individual user. Enabling Auto refresh ensures the software is displaying the current ESD status of each individual user.
•
Historical Lookup – Select a specific day and time to view the ESD status of each user at that time•
Individual Test History – Launch the “click to view history” feature for a 31 day test history of each individual userESD ATTENDANCE LOG
•
Leave Time – Generate a report to identify which users are currently on a leave of absence•
User Pass/Fail – Generate a report to indentify which users are consistently failing their ESD tests•
User Compliance – Generate a report to indentify which users are not completing their monthly ESD testsIdentify each users attendance and completed ESD tests for each day with the Attendance Log. Enable the ESD statistics feature to display the overall monthly recorded tests
SMARTLOG MONITORING
•
Last Poll Time – Displays the last time TEAM5 communicated with each SmartLog V5™•
ID Count – Displays the number of users loaded in each SmartLog V5™.•
Transactions Today/Count – Displays the number of ESD transactions completed for the current day as well as overallTEAM5 continuously monitors the performance of each individual SmartLog V5™. Use the Network Status window to identify the status of all active SmartLogs.
ESD REPORTS
TEAM5 offers multiple methods for reporting the ESD data captured on each SmartLog V5™. Emailed reports can be scheduled daily, managed by supervisors and archived to a dedicated folder on the network.
Multiple formats are available including HTML, Excel, and Text
•
Department Managers – Manager’s will receive ESD status reports for employees in their respected departments•
Email Lists – Create a ESD email list of managers or supervisorsDATABASE MANAGEMENT
TEAM5 provides you with a number of tools used to manage the database. Backing up the data to a shared folder ensures a recent copy of the database can be accessed from another PC incase the initial
PC running the software crashes.
•
Database Maintenance – Run monthly to control the database size to prevent performance problems and to insure data is archived.•
Test Data Purge – Archives old data and reduces the database sizeWEB MONITORING
Monitor real-time activity of users and SmartLogs using the web monitor feature. The Web Monitors are a set of static web pages updated by the TEAM5 server as often as every polling cycle. This is a useful tool
for personnel needing to determine a users ESD status if the emailed report has not been received.
•
Web User Status Monitor – Displays real-time ESD test information of all users•
Web Test Log Monitor – Displays from one to seven days of ESD test log historyEMAILED ALERTS
Team5 has preset emailed alerts that when enabled will immediately notify you when an event occurs. TEAM5 keeps a log of all alerts which can be filtered by the day or for a specific time period.
•
Calibration – A notification will be sent when each SmartLog V5™ is due for recalibration.•
SmartLog Communication– A notification will be sent when each SmartLog V5™ loses communication to the softwareREMOTE ACCESS
TEAM5 Enterprise includes network applications that allow ESD Test and User data to be viewed and edited via a shared network drive. All changes made remotely are tracked using the user changed history
report
•
Remote Status – An interactive report that gives you access to current or past ESD test records of all users remotely•
Remote Administrators – Only remote administrators will have access to managing the ESD user listDATA SYNC
TEAM5 Enterprise has the ability to synchronize data between TEAM5 Enterprise and other personnel databases. Enable this feature to allow TEAM5 Enterprise to automatically import a user or leave time list
from a separate database
•
Import to Database/File – Allows the automated import of user data from a direct database or creates a file to be imported from a shared folder•
Export from Database/File – Allows the automated export of user data to a direct database or creates a file to be importedTIME CLOCK
•
Time Clock Reports – Generate reports to display time clock punches for the day, week or month•
Time Clock Import – Import punches from a third party software such as Kronos, Paychex, etc.•
Time Clock Export – Export punches to a third party software to be managed and formatted for payrollEnable the Time Clock feature to begin capturing in and out punches for each user from the SmartLog V5™. Sync the punch data with ESD reports to identify whether a user is not in the building that day or if
SUPPORT & DEMOS
TEAM5 SOFTWARE
1 year of software support is included
The support includes setup, training and technical support
EMIT offers several ways of support including:
Phone E-mail Web Conference
