Portable cabin • Modular buildings
Sanitary cabin • WC cabin
A variety of space solutions ready to be used
Portable cabin
Single unit
Meeting room Double unit as sales office Single container 20’ as exhibition stand
Double unit
Double unit as showroom
• Easy interchangeable wall panels made of galvanised metal sheet profiles • Excellent heat and sound insulation • Various extra equipment available
• Robust steel frame with container corners and forklift pockets • CEE exterior sockets, embedded in the container frame
Type BM 16’
CONTAINEX portable cabin in package = Transpack Container
®Portable cabin
Individual design features due to panel construction
Up to ten cabins per truck
Easy D.I.Y. assembly
Finished office
• Portable cabins can also be supplied as flat packed Transpack Cabins
• Up to ten cabins can be loaded onto one truck
• Cost saving due to DIY assembly
• Quick and easy D.I.Y. assembly with standard tools • Expandable at any time
Your advantages:
• Buildings up to 3 storeys high • Individual floor layout
• Equipment for various applications • Painting according to CTX-RAL-chart
Portable Cabins can be combined to container units
Modular buildings
Corridor in container unit Changing rooms Additional space in operation
Different colours according to CTX-RAL-chart
Alternative office space Staff accommodation Construction office
Choose
your wall panels
Technical solutions which convince
• A robust construction is guaranteed by the massive steel frame • Easily interchangeable wall panels with galavanised steel skins provide for an excellent appearance over years
• High-quality heat and sound insulation guarantee comfort • Double glazed PVC windows with integrated roller shutters are exceptionally user-friendly
• The external dimensions of the CTX cabins match the ISO standard and can therefore easily be transported
Full Window Sanitary window Door with fixed glazing Door
Air conditioning Fixed glazing Double glazing Double winged door
Recessed CEE power connectors
Feature options allow customisation to suit the desired purpose
Choose
your desired features
External staircase Canopy roof / Fascia Door / Window grill
Plywood or cement-bonded particle board floor Interior stairs
Category 2 light fittings
Highly abrasion-resistant flooring PIR sensor for light
Interior decor (white or light oak)
TYPE
EXTERIOR INTERIOR
Length Width Height ¹ (assembled)
Height ¹
(package) Length Width Height ¹
Weight ² (assembled) Weight ² (packaging) BM 10’ 2,989 2,435 2,591 648 2,795 2,240 2,340 from 1,290 from 1,350 BM 16’ 4,885 2,435 2,591 648 4,690 2,240 2,340 from 1,690 from 1,750 BM 20’ 6,055 2,435 2,591 648 5,860 2,240 2,340 from 1,930 from 1,990 BM 24’ 7,335 2,435 2,591 648 7,140 2,240 2,340 from 2,250 from 2,310 BM 30’ 9,120 2,435 2,591 648 8,925 2,240 2,340 from 2,710 from 2,770
¹ Also available with external height 2,800 mm / internal height 2,540 mm ² Depending on layout Additionally we offer 16’ / 24’ corridor cabins and staircase cabins – details upon request
DIMENSIONS (mm) AND WEIGHTS (kg):
ENER GY SAV
Air conditioning Hatch
Choose
your desired features
Mini kitchen Isolation options
Full glazing with skylights Sliding window Fixed glazing
Fire rated components Window with sliding part
Optimum glazing
Panel with fixed glazing
• Exchange and combination with standard panels (full, window, door) possible
• Attractive price-performance ratio • Toughened safety glass (ESG) 4-16-4 gas filled (u = 1,1), white pvc profile • Delivery possible for internal heights 2,350 mm, 2,540 mm and 2,700 mm
Cabin glazing with skylight * • Attractive appearance
• ESG glass 6-16-6 gas-filled (u = 1.1), white PVC profile • Optional glass types available (VSG, TVG)
• Optional double wing door with fixed glazing • Optional tilting lever for skylight
• Available for spaces with internal heights of 2,540 mm and 2,700 mm
* The cabin glazing is available in the standard specification as discribed only. It is fixed to the frame and a later alteration isn't possible. For each building a technical review and clearance is required.
• Quick assembly on site • Promptly usable
• Robust steel construction • High quality insulation
• Complete and comfortable equipment • Fresh water instead of chemicals • Various equipment options possible • Steel interior design (optional)
Hygiene and cleanliness at the highest level
Sanitary cabin
Sanitary cabin 10’
Sanitary cabin interior view
Sanitary containers with hand basins and shower cabins Use at an event
Type SA 20’
Sanitary cabin
Sanitary containers with hand basins and shower cabins
Hand basins (set of 2 / 4) Shower cubicle with curtain Shatter-proof metal mirror
Flushing cistern with water saving device
Disabled WC Surestep flooring
Stop & Go fitting
Water connection, embedded in the wall
Hygrostatic controlled ventilator
TYPE EXTERIOR INTERIOR
Length Width Height ¹ Length Width Height ¹ Weight ² SA 10’ 2,989 2,435 2,591 2,815 2,260 2,340 from 1,490 SA 16’ 4,885 2,435 2,591 4,710 2,260 2,340 from 2,000 SA 20’ 6,055 2,435 2,591 5,880 2,260 2,340 from 2,490 SA 24’ 7,335 2,435 2,591 7,140 2,260 2,340 from 3,000 SA 30’ 9,120 2,435 2,591 8,925 2,260 2,340 from 3,490 WC 5’ 1,200 1,400 2,540 1,055 1,255 2,200 350 WC 8’ 2,400 1,400 2,540 2,255 1,255 2,200 570
DIMENSIONS (mm) AND WEIGHTS (kg):
¹ Also available with external height 2,800 mm / internal height 2,540 mm ² Depending on layout
ENER GY SAV ING ENER GY SAV ING
• Quick assembly on site • Promptly usable
• Solid steel construction • High quality insulation
• Comfortable equipment in various versions • Fresh water instead of chemicals
• Various options available (e.g. including showers)
The hygienic solution for high demands
WC cabin
8’ WC cabin 20’ WC cabin adapted as a car park toilet
20’ WC cabin ladies / men’s at an event 5’ WC cabin
Type WC 8’
For trade fairs, events and in public areas, authori-ties increasingly require WC containers that are accessible for disabled people.
Then CONTAINEX has the right solution for you! The new version of the accessible WC cabin from CONTAINEX is certified in accordance with DIN 18040-1 (“accessible construction”). This container meets the highest expectations.
Your advantages:
• Certified to DIN18040-1 (reg.nr. P1B064) • Stable and high-quality features
• Ideal for temporary or long term use
• Also can be delivered with other combinations (eg. 20 ft female / male / barrier-free)
• Alternative options are available
Accessible WC cabin with DIN certification
Alarm pull cord switch
Eurokey lock Alarm light
Interior accessible design according to DIN 18040-1 20’ WC cabin accessible men’s / ladies
Our factories
Made in Europe
CZECH-Cont
Ostrov
CZECH REPUBLIC
The long term partnership with certified production sites, owned by CONTAINEX, ensures a high and controlled product quality.
We push energy efficient construction methods, with the usage of recyclable materials and environmental manufacturing methods. The production of the portable and sanitary cabins and storage containers is carried out according to the environment and quality standards (Green Technology).
Further information on environment and quality measures undertaken by CONTAINEX can be found in the CTX-SSHE-Q-report (Safety-Security-Health-Environment-Quality). You can ask your CONTAINEX sales manager for a copy.
THE FACTORIES AT A GLANCE:
ARCONT
Gornja Radgona SLOVENIA
• Selection and use of recyclable materials
• Energy efficient and environmentally friendly production in certified, European production plants
• Continuous quality inspections and environmental audits in the production plants
• Long product life
Made in Europe
GREEN technology stands for
CESKO SLEZSKA Zlate Hory CZECH REPUBLIC ALFE-MI Zivinice BOSNIA & HERZEGOVINA CONTAINEX -MONOLIT Kovrov RUSSIA
Production of portable and sanitary cabins is undertaken according to strict environmental and quality standards.
Floor plan example
Portable cabin
Modular buildings
Portable cabin 20’ standard
Portable and sanitary cabin 2 units
Portable and sanitary cabin 3 units
Sanitary cabin
WC cabin
Many other variations and combinations available
Sanitary cabin 10’
Ladies / Gents Toilet Block 20’
WC cabin 5’
Multi-purpose use
Office building Workshop
Hotel staff accommodation Taxi driver lounge
Multi-purpose use
Perfectly adapted surface expansion Production office
Construction office Canteen
Multi-purpose use
Driving school office Show kitchen
Representative office Functional office space
Multi-purpose use
Kindergarten Pharmacy
Bedroom Petrol station shop
CONTAINEX Container-Handelsgesellschaft m.b.H. AT-2355 Wiener Neudorf, IZ NÖ-Süd, Straße 14 Telephone: +43 2236 601-0, E-Mail: [email protected]
