Multiple Formatter Support for the

Logging Application Block

If you are involved in designing and developing Microsoft®

.NET Framework applications, you may be using the Logging Application Block to provide you with effective logging in your applications. The block is a reusable code component that uses the Microsoft Enterprise Instrumentation Framework (EIF) and the Microsoft .NET Framework to help you design instrumented applications.

The Logging Application Block provides extensions to the EIF architecture that help to address common usage scenarios for logging. These scenarios include:

● Formatting event information ● Configuring log levels

● Enhanced information in the published events ● Asynchronous logging

● Reliable logging ● Centralized logging

● Request tracing for Web services ● Metering for Web services

● Using the EIF publisher for the Exception Management Application Block (EMAB) The data transformation functionality in the Logging Application Block is responsible for formatting events before they are stored in the event sink and is designed to support any formatter. However, the original design of the Logging Application Block supported the use of only a single formatter per event or sink. To work around this restriction, the new version of the block now supports multiple formatters. An additional formatter is also supplied: the EncryptionEventFormatter, which supports encryption of events.

This guide discusses the design changes to the block to support multiple formatters, shows how to use the block in your applications to support multiple formatters, and examines how to deploy applications that include the new version of the block.

Who Should Read This Guide

(5)

2 Multiple Formatter Support for the Logging Application Block

Prerequisites

Prior to reading this guide, you should read the Logging Application Block guide in its entirety at http://msdn.microsoft.com/library/default.asp?url=/library/en-us/dnpag/html /logging.asp. The Logging Application Block guide describes the design and features of the Logging Application Block and demonstrates how you can use the block to produce instrumented applications. It also gives an overview of EIF and Web Services Enhancements (WSE).

To benefit fully from this guide, you should have a full understanding of the Logging Application Block, the .NET Framework (including .NET Framework security concepts), and how to use the framework to develop and deploy Web services. You should also be familiar with the following technologies:

the C# language, Microsoft Visual Basic® .NET, XML, Web Services Enhancements (WSE), Windows Management Instrumentation (WMI), Microsoft Message Queuing (MSMQ), and Microsoft SQL Server™.

Design of the Multiple Formatter Support for the Logging

Application Block

The original design of the Logging Application Block supported the use of a single formatter per event or sink, which implemented the IEventFormatter interface. This design has now been enhanced to support multiple formatters, where the formatters are chained together and executed in order.

If you are going to make use of the multiple formatter functionality, you will need to create formatters that implement a new interface supplied with the block, called IEventFormatter2. The IEventFormatter2 interface is inherited from the IEventFormatter interface. It supports the same Format method supported by IEventFormatter. However, whereas the method supported by IEventFormatter requires the input parameter to be of the type System.Xml.XPath.XPathDocument, the method supported by IEventFormatter2 accepts data formatted as a stream. Table 1 shows the two methods.

Table 1: Format Methods of the IEventFormatter and IEventFormatter2 Interfaces

Interface Method Type Parameters

IEventFormatter Format Void XPathDocument eventInformationToFormat, Stream serializationStream

(6)

Multiple Formatter Support for the Logging Application Block 3

This design allows you to chain together calls to a formatter. Figure 1 shows an event sink making consecutive calls to different formatters.

Figure 1

An event sink making consecutive calls to multiple formatters

Because multiple formatters are supported in this way, any formatter downstream in the chain must understand the output of the preceding formatter. Any new formatter should implement the IEventFormatter2 interface.

Encryption Formatter Support

The Logging Application Block now includes a new formatter that supports encryption, called EncryptionEventFormatter. You can use the encryption

(7)

Development Using the Logging Application Block with

Multiple Formatter Support

To support multiple formatters in the Logging Application Block, you will need to make a number of modifications to the application configuration file, the EIF configuration file, and the client application itself.

To enable event transformation for a particular event sink, you need to set the enableFormatting parameter value in the EIF configuration file to true. By default, the Logging Application Block sets enableFormatting to false.

The formatters you are using also need to be specified in order. You can specify the chain of formatters on a per-sink basis in the EIF configuration file by modifying the formatterName parameter on the type property for the event sink. You can also specify the chain on a per-event basis, either by setting the formatterName property directly in the application code to contain the formatter chain before raising the event, or by specifying the value in the application configuration file and writing application code to get the value when required. The formatterName property contains a string value, and contains each of the formatters, in order, separated by a semicolon ( ; ). This means that the semicolon is not a valid character in the formatter names themselves.

You also need to specify each formatter to use in the <eventFormatterSettings> section of the application configuration file or Web configuration file. Each formatter used is defined by the formatterInfo element. The element includes the formatter name, the fully qualified type name, and any special data that will be passed on to the actual provider type. In many cases, the application code does not need to be changed at all to support multiple formatters. You will need to make modifications if the formatter name is specified directly in the code, which may be the case if you are specifying which formatter to use on a per-event basis.

To view an example EIF configuration file and application configuration file with the settings mentioned in the previous discussion, see the

EnterpriseInstrumentation.config and App.config files in the MultipleFormatters sample, located in the folder <installation location>\Logging\Samples\cs

(8)

Multiple Formatter Support for the Logging Application Block 5

Configuration File Settings for the EncryptionEventFormatter

If you want to use the EncryptionEventFormatter supplied with the Logging Application Block, you need to make changes to the application configuration file to support the use of the formatter. As well as specifying the formatter in the <eventFormatterSettings> section, you also need to create a section called <cryptographicSettings>. The section defines all of the cryptographic providers available. Each provider is defined by a cryptographicInfo element, which contains a name corresponding to the cryptoProvider attribute specified in the <eventFormatterSettings> section. The cryptographicInfo element also specifies the fully qualified type, and any defined data that will be passed to the provider. If you are using the Data Protection API (DPAPI) provider, you must also specify a

validation key and validation type.

The following code snippet shows configuration file settings for the EncryptionEventFormatter: <configSections> <section name="eventFormatterSettings" type="Microsoft.ApplicationBlocks.Logging.EventSinks.FormatterConfigHandler, Microsoft.ApplicationBlocks.Logging.EventSinks" /> <section name="crytpographicSettings" type="Microsoft.ApplicationBlocks.Common.Crypto.CryptographicConfigurationHandler, Microsoft.ApplicationBlocks.Common" /> </configSections> <eventFormatterSettings> <formatterInfo name="cryptoFormatter" type="Microsoft.ApplicationBlocks.Logging.EventSinks.EncryptionEventFormatter, Microsoft.ApplicationBlocks.Logging.EventSinks" cryptoProvider="default"/> </eventFormatterSettings> <crytpographicSettings> <cryptographicInfo name="default" type="Microsoft.ApplicationBlocks.Common.Crypto.DPAPIProvider, Microsoft.ApplicationBlocks.Common" validationKey="Oci44OQ9C3xAdQ3/BMHpksPfzeTezLkXen/ahQ8T7nVk/KMgAFnssQJr00KUNhRso+M pLVwAinGep6i14X9M+A==" validation="SHA1"/> </crytpographicSettings>

MultipleFormatters Sample

The MultipleFormatters sample, located in the folder <installation location>

(9)

The sample behaves much as the formatting sample does, except that it uses multiple formatters. In fact, in the application itself only one line of code is modified: the name of the formatter used for per-event formatting.

Note: When using the Visual Basic .NET sample, located in the folder <installation location>\Logging \Samples\vb\MultipleFormattersSample, you must run PostBuildEvent.bat before running the sample code.

Deploying Applications that Use Multiple Formatter Support for

the Logging Application Block

There are no new deployment considerations for applications that use the multiple formatter support included with the Logging Application Block. However, if you have existing applications that you want to modify to use the multiple formatter functionality of the block, you will need to redeploy the Logging Application Block itself, the EIF configuration file, and the application configuration file. You may also need to redeploy the application itself if the code directly specifies the formatters to use.

The Logging Application Block now includes a new assembly, called Common. This assembly stores code common to different application blocks. If you want to deploy this assembly in the global assembly cache, you need to use the fully qualified type name.

Note: The Common project uses a different key than the Logging Application Block, so the public key token value for the fully qualified type name for types in the Common assembly will be different.

Summary

The ability to use multiple formatters with the Logging Application Block
