Vol. 28, No. 16, (2019), pp. 1810 – 1831
Performance Analysis of Workflow Scheduling Algorithm in Cloud Computing Environment using Priority Attribute
Nidhi Rajak*
1, Diwakar Shukla
21,2Department of Computer Science and Applications Dr.Harisingh Gour Central University, Sagar(M.P.), India [email protected]1, [email protected]2
Abstract
Workflow scheduling is represented by a well known graph that is Directed Acyclic Graph (DAG) and the scheduling problem is also known as NP-complete. There are number of heuristics algorithms has been developed for workflow scheduling and its primary objective to minimize the overall execution time that is scheduling length of the tasks of a given DAG. This paper presents new algorithm for workflow scheduling in cloud computing environment using priority attribute. The priority attribute is computed by using adjacency matrix which consists of the communication time between the tasks. If there is a direct path between the tasks then assign its communication time as matrix element otherwise zero in the matrix.
Then after ,find maximum column element allocated into max array. This algorithm is worked in two phases such first phase compute max array and sort the max array as per their attribute value. Second phase, to remove entry task(s) from priority queue and allocate entry task as duplicate into all available virtual machine. To allocate non entry if satisfied precedence constraint otherwise insert at end of the queue. The propose algorithm is compared with well known four heuristic algorithms such as Heterogeneous Earliest Finish Time(HEFT), Critical-Path-on-a-Processor(CPOP), As Late As Possible(ALAP), and Performance Effective Task Scheduling (PETS) algorithms. The performance analysis of the algorithms has been done based on well known metrics such as speedup, efficiency, scheduling length ratio, cost and resource utilization. The proposed algorithm gives good results in respect of performance metrics as compared to four heuristic algorithms.
Keywords: DAG, Scheduling Length, Cloud Computing, Speedup, Efficiency , Critical Path.
1. Introduction
Cloud computing is one of recent topic of research in computer science and it optimized to use of technology. Sometime, cloud computing is also called as Internet based computing due to it reduces the cost of resources and fast speed of Internet. These are the following areas where cloud computing have widely used such as advance scientific computing, medical science, DNA computing and computational physics etc. This computing environment follows the principle “Pay-Per-Use basis”[1].
The heterogeneous computing environment[2] which includes Cluster, Grid, and Cloud etc widely used in massive where complex application computing. Complex application computing is process of assigning multiple tasks onto available resources. In another term, it is called as Scheduling which comprise of multiple tasks and these tasks are allocated to various machines. Scheduling is also known as workflow scheduling and it is defined as the process of assigning the tasks to computing resources [3]. The primary objective of task scheduling method is to find optimal scheduling length and it is generally considered as NP-complete problem[4]. There are basically three major components [5] of any task scheduling which are as follows: performance of the machines, tasks mapping and order of execution of the tasks. Deterministic and non-deterministic scheduling are the two basic classification of task scheduling. Deterministic task scheduling is a scheduling method which has information about the number of tasks, number of virtual machines and precedence constraint among the tasks are known in advanced. It is also called as compile time scheduling whereas Non-deterministic task scheduling is scheduling method does not have all information in advanced. It is also called as run time scheduling.
Vol. 28, No. 16, (2019), pp. 1810 – 1831
.
Generally, an application program is represented by a Directed Acyclic Graph(DAG) where node denote tasks and the arcs denote the dependencies between the tasks of a given DAG. Figure 1 shows the mapping of the tasks among the virtual machines. Here, firstly application program is decomposed into the number of subtasks, these subtasks are represented by DAG and finally allocate it onto the virtual machines
Application Program
Subtask
Subtask Subtask
Subtask Subtask
Subtask
Virtual Machine (VM)
Virtual Machine(VM) Virtual Machine(VM) Subtask
Subtask Subtask
Subtask Subtask
Subtask
Task Decomposition
Task Scheduling
Figure 1. Mapping of tasks onto Virtual Machines
Vol. 28, No. 16, (2019), pp. 1810 – 1831
Any task scheduling follow three basic steps for scheduling of the tasks onto the available virtual machines such as find the priority of tasks of a given DAG using priority attribute, sort the tasks as per priority value and allocate the tasks among the available virtual machines as per EST and EFT. This paper present new task scheduling algorithm in cloud computing environment which is based on priority attribute. The priority attribute compute using adjacency matrix of the graph.
The proposed algorithm is worked on two phases: First Phase : find the adjacency matrix [6]of the given DAG using communication time between the tasks, allocate the task priority value as per column maximum . Second Phase: Sort the tasks in non deceasing order and Allocate the tasks into a Priority Queue(PQ). Use PQ and precedence constraint for allocation of the tasks onto available virtual machines. Here , entry task(s) will be allocated as duplicate to all cloud servers which minimize scheduling length. The performance of the new algorithm gives better results as compared to heuristics algorithms such as HEFT, CPOP, ALAP and PETS. The comparison study is based on performance metrics such Scheduling length, Speedup, Efficiency, Scheduling Length Ratio (SLR), Resource Utilizations and Cost.
The paper is organized as follows : Section 1 briefly explain the cloud computing, basis of scheduling and its objective. Problem Statement, Basic terminologies and priority attribute will be discussed in section 2, Section 3 proposed algorithm and explain it with various DAG models.
Performance analysis will be done in section 4 and finally come to conclusion part in section 5.
2. Workflow Scheduling Model
This model consists of Application Model, Platform Model, Basic Scheduling Terminologies, Performance Metrics and Objective function.
2.1.Application Model
Suppose an application program is denoted by Directed Acyclic Graph(DAG).
G=(T,E,TC) where T={ T1,
T
2,…T
n} finite set of n tasks of DAG, E is set of edges between the tasks, T
C is the communication arcs between the tasks i.e.TC(Ti,Tj) where iand j are two different tasks. Generally a DAG model having an entry task or more than
T5
T6
T3
T4
T2
T1
4
3
4 3
5 2 5
5
Tentry
TC
Figure 2. A DAG Model with six tasks [7]
Texit
Vol. 28, No. 16, (2019), pp. 1810 – 1831
one entry tasks and an exit task. An example of application model with six tasks is depicted in figure 2.
2.2.Platform Model
A Platform model is represented by Cloud Server CS={CS1,CS2,…,CSm} with m number of cloud servers where CS1= CS2 = CS3 = …..CSm={VM1, VM2, VM3,…, VMp} consists p number of VM and each cloud server may consists one or more virtual machines which are interconnected through very high speed network. The communication time(CT) between two virtual machines is considered negligible if they belongs to same cloud server otherwise it will be included. Here, also considered that no preemption and no any interrupt during execution of the tasks on virtual machine. Figure 3 shown mapping of tasks and virtual machines.
2.3. Basic Scheduling Terminologies
Following are the basic terminologies which will be used in workflow scheduling in proposed algorithm and to performance metrics and table 1 consists the notations used in this paper.
I. Estimated Computation Time(ECT)[8]
𝐸𝐶𝑇𝑖𝑗 =
𝐸𝐶𝑇11 𝐸𝐶𝑇12⋯ 𝐸𝐶𝑇1𝑛
𝐸𝐶𝑇21 𝐸𝐶𝑇22 … . . 𝐸𝐶𝑇2𝑛
𝐸𝐶𝑇𝑚 1 𝐸𝐶𝑇𝑚 2 𝐸𝐶𝑇𝑚𝑛
(1) Where ECTij is estimated computation time of task Ti on resource VMj. II. Average ECT (AVG)[9] of a task Ti is defined as
𝐴𝑉𝐺𝑖 = 𝑇𝑜𝑡𝑎𝑙 𝑉𝑀𝑗 =1 𝐸𝐶𝑇𝑖,𝑗
𝑇𝑜𝑡𝑎𝑙 𝑉𝑀 (2) III. Critical Path(CP)[10,11] of a DAG is defined as follows:
𝐶𝑃 = max
𝑝𝑎𝑡 𝜖𝐷𝐴𝐺 𝑙𝑒𝑛𝑔𝑡 𝑝𝑎𝑡 3
CS1 ={VM1, VM2, VM3,…, VMp}
CS2 ={VM1, VM2, VM3,…, VMp}
CSm ={VM1, VM2, VM3,…, VMp} Scheduler
T1,T2,T3,…Tn
Task Queue
Figure 3. Mapping of Tasks onto VMs
Vol. 28, No. 16, (2019), pp. 1810 – 1831
𝑙𝑒𝑛𝑔𝑡 𝑝𝑎𝑡 = 𝐴𝑉𝐺 𝑇𝑖 + 𝐶𝑜𝑚𝑚. 𝑇𝑖𝑚𝑒(𝑇𝑖, 𝑇𝑗)
𝑒𝜖𝐸 𝑇𝑖𝜖𝑇
4 IV. Earliest Start Time EST[12] is defined as follows:
𝐸𝑆𝑇 𝑇𝑖, 𝑉𝑀𝑗
= 0 𝑖𝑓𝑇𝑖 ∈ 𝑇𝑒𝑛𝑡𝑟𝑦
𝑇𝑗∈𝑝𝑟𝑒𝑑 𝑇max 𝑖 {𝐸𝐹𝑇( 𝑇𝑗, 𝑉𝑀𝑗) + 𝑀𝐸𝑇 𝑇𝑖 + 𝐶𝑜𝑚𝑚. 𝑇𝑖𝑚𝑒(𝑇𝑖, 𝑇𝑗)} 𝑜𝑡𝑒𝑟𝑤𝑖𝑠𝑒 (5) V. Minimum Execution Time MET[13] is defined as follows:
𝑀𝐸𝑇 𝑇𝑖 = 𝑚𝑖𝑛. 𝐸𝐶𝑇 𝑇𝑖, 𝑉𝑀𝑚 (6) VI. Earliest Finished Time EFT[13] is defined as follows:
𝐸𝐹𝑇 𝑇𝑖, 𝑉𝑀𝑗 = 𝐸𝐶𝑇𝑖𝑗 + 𝐸𝑆𝑇 𝑇𝑖, 𝑉𝑀𝑗 (7)
VII. Static Level SL[11,12]: It is similar to B-level attribute but exclude the communication time between the tasks. It can be defined as follows:
𝑆𝐿 𝑇𝑖 = 𝐴𝑉𝐺𝑖+ max
𝑇𝑗𝜖𝑆𝑢𝑐𝑐 (𝑇𝑖) 𝑆𝐿 𝑇𝑗 8 Table 1. Notations Used
Notation Meaning DAG Directed Acyclic Graph
T Set of finite tasks n Total n number of tasks p Total p number of cloud servers m Total m number of virtual machines
r Total r number of rate for m VM TC(Ti,Tj) Communication time between Ti and Tj.
Pred(ti) Predecessor of task ti VMm Virtual Machine
CS Cloud Server
ECT Estimated Computation Time EST Earliest Start Time
EFT Earliest Finished Time MET Minimum Execution Time
MS Scheduling Length AM Adjacency Matrix
PQ Priority Queue
2.4. Performance Metrics
The comparison between proposed algorithm and heuristic algorithm are based on performance metrics which are as follows: Scheduling Length, Scheduling Length Ratio, Speedup and Efficiency, Resource Utilization and Cost. The details of the comparison metrics as follows:
I. Scheduling Length [13]: It is an important comparison metrics because it gives the overall execution time of the tasks of given DAG. Formally, Scheduling length is defined as the exit task of given DAG on available virtual machine will take minimum time. i.e.
𝑆𝑐𝑒𝑑𝑢𝑙𝑖𝑛𝑔𝐿𝑒𝑛𝑔𝑡 = 𝑀𝑖𝑛. 𝐸𝐹𝑇 𝑇𝑒𝑥𝑖𝑡, 𝑉𝑀 (9)
II. Scheduling Length Ratio (SLR)[14,15] : It is the ratio of Scheduling Length and the sum of minimum ECT of Critical Path (CPmin) task in given DAG i.e.
𝑆𝐿𝑅 =𝑆𝑐𝑒𝑑𝑢𝑙𝑖𝑛𝑔 𝐿𝑒𝑛𝑔𝑡 𝑜𝑓 𝐴𝑙𝑔𝑜𝑟𝑖𝑡 𝑚 𝑀𝑖𝑛 (𝐸𝐶𝑇𝑖,𝑗)
𝑇𝑗 ∈𝐶𝑃𝑚𝑖𝑛 (10 )
Vol. 28, No. 16, (2019), pp. 1810 – 1831
III. Speedup[15]: It is defined as the ratio of sum of ECT of all the tasks of given DAG on a VM which will take minimum and Scheduling Length. i.e.
𝑆𝑝𝑒𝑒𝑑𝑢𝑝 = 𝑀𝑖𝑛. 𝑚𝑗 =1𝐸𝐶𝑇𝑖, 𝑗
𝑆𝑐𝑒𝑑𝑢𝑙𝑖𝑛𝑔𝐿𝑒𝑛𝑔𝑡 (11) where m is number of VMs.
IV. Efficiency[15]: It is defined as the ratio of Speedup and total number of VMs. i.e.
𝐸𝑓𝑓𝑖𝑐𝑖𝑒𝑛𝑐𝑦 =𝑆𝑝𝑒𝑒𝑑𝑢𝑝
𝑚 × 100 (12)
V. Resource Utilization[16]: It is important metric for cloud computing which has primary objective is to maximize the resource utilization. It is calculated by Average Resource Utilization(ARU).
𝐴𝑅𝑈 = 𝑚𝑖=1𝑇(𝑉𝑀𝑖)
𝑆𝑐𝑒𝑑𝑢𝑙𝑖𝑛𝑔 𝐿𝑒𝑛𝑔𝑡 × 𝑚 (13)
Where 𝑇(𝑉𝑀𝑖) is Time taken by Virtual Machine i to finish all tasks of given DAG.
VI. Cost[17]: This metric is defined by following
𝐶𝑜𝑠𝑡 = 𝐸𝑖𝑗 × 𝐶(𝑉𝑀𝑗) (14)
Where Eij is the execution time of the task i on VMj and C(VMj) is the cost of VMj per unit time.
This cost metric is also depended on the user’s requirement and shown in the following table 2[12].
Table 2. Cost Rate for Virtual Machines
Virtual Machine(VM) VM1 VM2 VM3 … VMm
Cost / Unit Time Rate1 Rate2 Rate3 … Rater
2.5. Objective function
The objective of the workflow scheduling algorithm is to minimize overall execution time i.e.
scheduling length or makespan Ms. Formally, An objective function of scheduling algorithm can be defined as an exit task(Te) of a given DAG should be allocate to the available VM and it takes minimum beginning time and maximum finishing of execution time of Te. i.e.
𝑆𝑐𝑒𝑑𝑢𝑙𝑖𝑛𝑔 𝐿𝑒𝑛𝑔𝑡 = 𝑀𝑖𝑛[𝑀𝑎𝑥 𝐸𝐹𝑇 𝑇𝑒, 𝑉𝑀 ] (15
) 3. Proposed Method
The proposed algorithm is based on priority attribute which is found using adjacency matrix [1].
An adjacency matrix for DAG can be defined as the matrix of order T×T (n number of tasks in a given DAG) and the elements of the matrix would be the communication time(TC) between the tasks. The details of proposed algorithm is given in Table 3.
The elements of the adjacency matrix M can be computed as follows:
𝑴𝒊,𝒋= 𝑻𝒄 𝑻𝒊, 𝑻𝒋 𝒊𝒇 𝒅𝒊𝒓𝒆𝒄𝒕 𝒄𝒐𝒎𝒎𝒖𝒏𝒊𝒄𝒂𝒕𝒊𝒐𝒏 𝒍𝒊𝒏𝒌 𝒃𝒆𝒕𝒘𝒆𝒆𝒏 𝒕𝒘𝒐 𝒕𝒂𝒔𝒌𝒔 𝑻𝒊 𝒂𝒏𝒅 𝑻𝒋
𝟎 𝑶𝒕𝒉𝒆𝒓𝒘𝒊𝒔𝒆 (16) Where 𝑀𝑖,𝑗: the adjacency matrix elements at ith row and jth column of T× T matrix.
Vol. 28, No. 16, (2019), pp. 1810 – 1831 𝑇𝑐 𝑇𝑖, 𝑇𝑗 : Communication Time between two tasks Ti and Tj of a given DAG.
Table 3: Proposed Algorithm 1 Read DAG with finite n number of tasks
2 Compute Adjacency Matrix AM elements using For(i=1 to nth tasks)
For(j=1 to nth tasks)
𝑀𝑖,𝑗= 𝑇𝑐 𝑇𝑖, 𝑇𝑗 𝑖𝑓 𝑡𝑒𝑟𝑒 𝑖𝑠 𝑑𝑖𝑟𝑒𝑐𝑡 𝑐𝑜𝑚𝑚𝑢𝑛𝑖𝑐𝑎𝑡𝑖𝑜𝑛 𝑙𝑖𝑛𝑘 𝑏𝑒𝑡𝑤𝑒𝑒𝑛 𝑡𝑤𝑜 𝑡𝑎𝑠𝑘𝑠 𝑇𝑖 𝑎𝑛𝑑 𝑇𝑗 0 𝑂𝑡𝑒𝑟𝑤𝑖𝑠𝑒 AM[i][j]= 𝑀𝑖,𝑗
3 Find MaxArray Mx[n] of size n which contains Maximum value of each task of DAG from AM using Column wise.
Max=0
For(j=1 to nth tasks) {
For(i=1 to nth tasks) { If(Max<A[i][j]) Max=A[i][j]
} Mx[j]=Max }
4 Sorting of Mx elements in increasing order.
5 Mx Arrary Elements allocated to Priority Queue(PQ)
6 While(PQ!=Empty)
{
Remove a task T from PQ If T is an entry task then
Allocate to all available VM as duplicate task.
If T is a non entry task and satisfied Precedence Constraint(PC) then Allocate T onto available VM as per EST and EFT.
If T is a non entry task and not satisfied Precedence Constraint(PC) then Insert T into rear part of PQ
}
7 Find Scheduling Length i.e.
𝑺𝒄𝒉𝒆𝒅𝒖𝒍𝒊𝒏𝒈 𝑳𝒆𝒏𝒈𝒕𝒉 = 𝑴𝒊𝒏[𝑴𝒂𝒙 𝑬𝑭𝑻 𝑻𝒆, 𝑽𝑴 ]
8 Stop
4. Performance Analysis
This section evaluate the results of proposed algorithm with four heuristics algorithms such as HEFT[18], CPOP[18], ALAP[5] and PETS[19] algorithms. Consider three DAG models with 10, 15 and 26 tasks with their ECT and VM cost Tables are taken into account for the performance analysis of proposed algorithm and heuristics algorithms. The performance analysis is also being done with the help of some well known scheduling metrics such as Scheduling Length, Scheduling Length Ratio, Speedup and Efficiency, Resource Utilization and Cost
.
Vol. 28, No. 16, (2019), pp. 1810 – 1831
Case1: DAG1 Model with Ten Tasks
Table 4. ECT[12] Matrix for DAG1 Model
T1 T2 T3 T4 T5 T6 T7 T8 T9 T10
CS1 VM1 14 13 11 13 12 13 7 5 18 21
CS1 VM2 16 19 13 8 13 16 15 11 12 7
CS2 VM3 9 18 19 17 10 9 11 14 20 16
This DAG1 model[12] having ten tasks, single entry and also take into account two cloud servers CS1 and CS2. CS1 consists two virtual machines VM1 and VM2 and CS2 consists one virtual machine VM3. Figure 4 shown DAG with ten tasks and table 4 shown ECT of given DAG. The cost of VM rate for DAG1
model is taken arbitrary in the table 5. As per the proposed algorithm need to find adjacency matrix AM , Max Array and allocation onto the Priority Queue PQ for given DAG1 which is depicted in the figure 5
. The proposed algorithm gives 59 units of scheduling length and comparison with heuristic algorithms is shown in table 6.
Results of proposed and heuristic algorithms with different metrics shown in figure 7-12.
PQ tasks are removed one by one from front end , if it is satisfied PC , then allocate to VM as per computing of EST and EFT of the removed task. Otherwise , removed task should be inserted
T1
T4
T3 T6
T2
T9
T8
T7
T10
T5 18
12 9 11
14
17 13
11
16 15
23
19
27
13
23
Figure 4. DAG1Model with ten tasks
Vol. 28, No. 16, (2019), pp. 1810 – 1831
into PQ from rear end of the queue. Therefore, the complete mapping of the ten tasks in the available virtual machines as per proposed algorithm is shown in the Figure 6.
CS1
VM1 0~14
T1
14~25 T3
25~38 T2
43~48 T8
VM2 14~23
T4
25~40 T7
40~52 T9
52~59 T10
CS2 VM3 0~9
T1
9~19 T5
19~28 T6
Figure 6.Gantt. Chart for Proposed Algorithm for DAG1 Model and 59 units Scheduling Length.
Table 6: Comparison of Scheduling Algorithms Based on Metrics for DAG1 Model Scheduling
Algorithms
Performance Metrics for DAG1 Model
Scheduling Length
Speedup Efficiency(%) SLR Resource Utilization(%)
Cost/Unit Time
Proposed 59 2.15 71.67 1.44 76.27 212.13
HEFT 73 1.74 58.00 1.78 77.12 258.65
CPOP 86 1.48 49.22 2.09 77.51 301.12
ALAP 73 1.74 58.00 1.78 77.16 258.65
PETS 70 1.81 60.33 1.71 80.47 265.39
Tasks T1 T2 T3 T4 T5 T6 T7 T8 T9 T10
T1 0 18 12 9 11 14 0 0 0 0
T2 0 0 0 0 0 0 0 19 16 0
T3 0 0 0 0 0 0 23 0 0 0
T4 0 0 0 0 0 0 0 27 23 0
T5 0 0 0 0 0 0 0 0 13 0
T6 0 0 0 0 0 0 0 15 0 0
T7 0 0 0 0 0 0 0 0 0 17
T8 0 0 0 0 0 0 0 0 0 11
T9 0 0 0 0 0 0 0 0 0 13
T10 0 0 0 0 0 0 0 0 0 0
T1 T2 T3 T4 T5 T6 T7 T8 T9 T10
0 18 12 9 11 14 23 27 23 17
T1 T4 T5 T3 T6 T10 T2 T7 T9 T8
0 9 11 12 14 17 18 23 23 27
Table 5: VM rate for DAG1 Model
Virtual Machine(VM) VM1 VM2 VM3
Cost / Unit Time 1.71 1.63 1.21
Max Array Mx[10]
Priority Queue (PQ)
Front Rear
Figure 5. Find AM, Mx and PQ for DAG1 Model
AM
Vol. 28, No. 16, (2019), pp. 1810 – 1831
Figure 7. Scheduling Length for DAG1 Model
Figure 8. Speedup for DAG1 Model
Figure 9. Efficiency for DAG1 Model 0
20 40 60 80 100
Proposed HEFT CPOP ALAP PETS
Scheduling Length
Scheduling Algorithms
0 0.5 1 1.5 2 2.5
Proposed HEFT CPOP ALAP PETS
Speedup
Scheduling Algorithms
0 20 40 60 80
Proposed HEFT CPOP ALAP PETS
Efficiency(%)
Scheduling Algorithms
Vol. 28, No. 16, (2019), pp. 1810 – 1831
Figure 10. SLR for DAG1 Model
Figure 11. Resource Utilization for DAG1 Model
Figure 12. Cost/Unit time for VM for DAG1 Model
Case 2: DAG2 with fifteen Tasks
This DAG2 Model[13] having fifteen tasks, multiples entry as shown in the figure 13 and two cloud servers CS1 and CS2. CS1 consists two virtual machines VM1 and VM2 and CS2 consists two virtual machines VM3 and VM4. Table 8 shown ECT and Cost of VM is shown in the table 7 of given DAG2.
0 0.5 1 1.5 2 2.5
Proposed HEFT CPOP ALAP PETS
SLR
Scheduling Algorithms
72 74 76 78 80 82
Proposed HEFT CPOP ALAP PETS
Resoucre Utilization(%)
Scheduling Algorithms
0 50 100 150 200 250 300 350
Proposed HEFT CPOP ALAP PETS
Cost/Unit Time
Scheduling Algorithms
Vol. 28, No. 16, (2019), pp. 1810 – 1831
Similarly, As per the proposed algorithm need to find adjacency matrix AM , Max Array and allocation onto the Priority Queue PQ for given DAG2which is depicted in the figure 14.
Table 7. VM rate for DAG2 Model
PQ tasks are removed one by one from front end , if it is satisfied PC , then allocate to processor as per computing of EST and EFT of the removed task. Otherwise , removed task should be inserted into PQ from rear end of the queue. Therefore, the complete mapping of the ten tasks in the available virtual machines as per proposed algorithm is shown in the figure 14.
Table 8. ECT[13] Matrix for DAG2 Model
t1 t2 t3 t4 t5 t6 t7 t8 t9 t10 t11 t12 t13 t14 t15
CS1 VM1 17 14 19 13 19 13 15 19 13 19 13 15 18 20 11
CS1 VM2 14 17 17 20 20 18 15 20 17 15 22 21 17 18 18
CS2 VM3 13 14 16 13 21 13 13 13 13 16 14 22 16 13 21
CS2 VM4 22 16 12 14 15 18 14 18 19 13 12 14 14 16 17
Virtual Machine(VM) VM1 VM2 VM3 VM4
Cost / Unit Time 1.72 1.52 1.69 1.65
T1 T2 T3
T4 T5 T6 T7 T8
T9
T10
T11
T15 T14
T12 T13
22
23 7 15
8
12
\\
13 16
6 11
\\
14
\\
17
\\
18
\\
17 16 \\
\\
19
\\
7
16
\\
21
\\
11 9 13
\\
13 15
19
\\
Figure 13 .DAG2Model with fifteen tasks
Vol. 28, No. 16, (2019), pp. 1810 – 1831
Figure 14. Find AM, Mx and PQ for DAG2
Figure 15.Gantt. Chart for Proposed Algorithm for DAG2 Model and 144 units Scheduling Length.
Table 9: Comparison of Scheduling Algorithms Based on Metrics for DAG2 Model Scheduling
Algorithms
Performance Metrics for DAG2 Model
Scheduling Length
Speedup Efficiency(%) SLR Resource Utilization(%)
Cost/Unit Time
Proposed 144 1.60 40.00 1.62 60.06 575.03
HEFT 152 1.52 38.00 1.71 69.73 702.75
CPOP 164 1.41 35.25 1.84 64.93 694.92
ALAP 155 1.49 37.25 1.74 72.74 751.53
PETS 152 1.52 38.00 1.71 65.13 666.43
Tasks T1 T2 T3 T4 T5 T6 T7 T8 T9 T10 T11 T12 T13 T14 T15
T1 0 0 0 13 16 0 0 0 0 0 22 0 0 0 0
T2 0 0 0 15 0 11 14 0 0 0 0 23 0 0 0
T3 0 0 0 0 0 17 18 19 0 0 0 0 7 0 0
T4 0 0 0 0 0 0 0 0 8 0 0 0 0 0 0
T5 0 0 0 0 0 0 0 0 12 0 0 0 0 0 0
T6 0 0 0 0 0 0 0 0 16 0 0 0 0 0 0
T7 0 0 0 0 0 0 0 0 17 0 0 0 0 0 0
T8 0 0 0 0 0 0 0 0 19 0 0 0 0 0 0
T9 0 0 0 0 0 0 0 0 0 7 0 0 0 0 0
T10 0 0 0 0 0 0 0 0 0 0 13 16 9 0 0
T11 0 0 0 0 0 0 0 0 0 0 0 0 0 13 0
T12 0 0 0 0 0 0 0 0 0 0 0 0 0 21 0
T13 0 0 0 0 0 0 0 0 0 0 0 0 0 15 0
T14 0 0 0 0 0 0 0 0 0 0 0 0 0 0 11
T15 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
T1 T2 T3 T4 T5 T6 T7 T8 T9 T10 T11 T12 T13 T14 T15
0 0 0 15 16 17 18 19 19 7 22 23 9 21 11
T1 T2 T3 T10 T13 T15 T4 T5 T6 T7 T8 T9 T14 T11 T12
0 0 0 7 9 11 15 16 17 18 19 19 21 22 23
CS1 VM1 0~14 T2
14~27 T4
27~31
*
31~44 T6
VM2 0~14
T1
14~31 T3
CS2 VM3 0~13 T1
13~34 T5
34~47 T8
47~60
*
60~73 T9
73~86
*
86~100 T11
100~114
*
114~127 T14
VM4 0~16
T2
16~28 T3
28~42 T7
42~73
*
73~86 T10
86~100 T13
100~114 T12
114~127
*
127~144 T15
Max Array Mx[15]
Priority Queue (PQ)
Front Rear
AM
Vol. 28, No. 16, (2019), pp. 1810 – 1831
Figure 16. Scheduling Length for DAG2 Model
Figure 17. Speedup for DAG2 Model
Figure 18. Efficiency for DAG2 Model 130
135 140 145 150 155 160 165 170
Proposed HEFT CPOP ALAP PETS
Scheduling Length
Scheduling Algorithms
1.3 1.35 1.4 1.45 1.5 1.55 1.6 1.65
Proposed HEFT CPOP ALAP PETS
Speedup
Scheduling Algorithms
32 34 36 38 40 42
Proposed HEFT CPOP ALAP PETS
Efficiency(%)
Scheduling Algorithms
Vol. 28, No. 16, (2019), pp. 1810 – 1831
Figure 19. SLR for DAG2 Model
Figure 20. Resource Utilization for DAG2 Model
Figure 21. Cost/Unit Time for VM for DAG2 Model
Case 3: DAG3 Model with twenty six tasks
This model [14] having twenty six tasks, single entry task and communication time is added between 5 to 25 . Also ,considered two cloud servers CS1 and CS2. CS1consists two resources VM1 and VM2 and CS2
consists two resourcesVM3 and VM4. Figure 22 shown DAG with twenty six tasks, table 10 and table 11 shown ECT and Cost matrix of given DAG3 which are arbitrary value.
1.5 1.551.6 1.651.7 1.751.8 1.851.9
Proposed HEFT CPOP ALAP PETS
SLR
Scheduling Algorithms
0 20 40 60 80
Proposed HEFT CPOP ALAP PETS
Resoucre Utilization(%)
Scheduling Algorithms
0 200 400 600 800
Proposed HEFT CPOP ALAP PETS
Cost/Unit Time
Scheduling Algorithms
Vol. 28, No. 16, (2019), pp. 1810 – 1831
T0
T9
T5
T3
T2 T4
T1
T10
T7
T8
T6 T11
T18
T17
T14
T15
T13
T16
T12
T23
T20
T19
T22 T24
T21
T25 20
0
16 0 23
0 200
9
13 9
16 15
8 12 16
15
11 10
15
12 13
13 17 19
10 10
16 11 14 18
17 19
17 12
15 19
18 14
15 12
10 11
Figure 22.DAG3Model with twenty six tasks
