1. Business Scenario

Among the many challenges in rolling out mobile apps is the distribution of your App to your target audience as well as providing the required configuration settings for the app. The configuration data could be the SMP server IP address, port, as well as provisioning certificates required for device registration and/or Single Sign-On (SSO) to the mobile device should they be a requirement.

2. Background Information

This document provides an overview of steps that one would need to follow to leverage SAP Mobile Secure to configure a Mobile Application built using SMP 3. The same libraries and setup described in this guide are applicable to Kapsel and Native Apps on SMP3 as well as Hybrid Web Container and Native Apps on SMP 2.3 and later, for the earlier versions specified, this guide should help you implement the end-to-end scenario for yourself, further information may be found in the

appropriate product documentation.

The steps described in this guide will be based on Mobile Secure (Cloud); however most of the steps are applicable to SAP Afaria (On-premise).

3. Prerequisites

This guide relies on you already having a Kapsel App to test this scenario with, for details on creation of a basic Kapsel App and implementing the Logon Plugin, please refer to the appropriate documentation or relevant How-to-Guide.

The following are pre-requisites that must be met in order for you to complete the business scenario in this H2G:

 A valid Mobile Secure Cloud account, a trial version may be obtained at https://portal.sapmobilesecure.com/free_trial.php

OR

 SAP Afaria on-premise 7sp3 or later. AND

 Access to the Admin Portal / MDM Administration Console.  An existing Kapsel project which includes the Logon Plugin.

 To test App registration, the Application created and configured on your SMP Runtime Server.

 An SMP 3.0 or later runtime server with the Hybrid (Kapsel) .  SAP Mobile Secure (or Afaria on-premise).

 An existing Kapsel App that uses the Logon Plugin.

(7)

March 2015 2

4. Step-by-Step Procedure

This H2G provides a basic procedure to follow for provisioning your SMP Kapsel Application with initial settings and registering on the SMP Runtime using those settings without having to provide them to the user for manual entry or having to hard-code the configuration into the App. The guide will take you through the steps required to add your Kapsel Application to Mobile Secure for distribution and configuration using MDM.

We will use Application Policies in MDM to provide the configuration settings for our Kapsel App and link that Application Policy to an appropriate group to ensure that the App (and the settings) are only deployed to an authorized user (by virtue of their group membership).

It’s important to note that the our App will use the Afaria Static Link Library (SLL) to connect to the MDM Package Server (Afaria) server from the mobile device to fetch the App configuration (and, if required, certificates). The Kapsel App will automatically check if there is an MDM client on the device when it is first run and if so try to fetch the configuration settings from the MDM Package Server. In Kapsel, this is achieved through the Logon Plugin without having to modify a single line of code within your Kapsel Project. It is also possible to implement the Afaria Static Link Library (SLL) which the Kapsel Logon Plugin uses in a Native Application and retrieve settings/certificates in the same manner using only a few lines of code, this is not covered in this guide.

4.1 Test Your Kapsel App without MDM

1. Install your Kapsel App onto your test device and launch the App.

(8)

March 2015 3

3. We will now add the App to Mobile Secure and provide the settings to our user automatically.

4.2 Create a new App on Mobile Secure

1. Logon to your SAP Mobile Secure Admin Portal with the appropriate Admin role. 2. Click Applications from the main dashboard.

(9)

March 2015 4

4. Select Enterprise Application and click Next to launch the Application workflow.

(10)

March 2015 5

6. Before Moving to the next step make sure you select the Deploy to managed users only checkbox. This will create an app policy in MDM and allow us to add the App configuration we need.

It’s important to note the Deploy to managed users only step described above is applicable to devices that are enrolled in MDM and would have the MDM client installed on the device. The functionality provided by the Static Link Library (SLL) is dependant the MDM client and MDM relationship between the device and MDM server in order to retrieve the settings for the App.

(11)

March 2015 6

8. In OS Platorm, select Android.

9. Select the appropriate Form factor checkboxes.

10. For App binary, click the Browse button and locate the binary file for your Kapsel project. This may take a while to upload, depending on the size of your Kapsel App.

11. Once, the upload is complete, click OK.

(12)

March 2015 7

13. Click OK.

14. You will see your new supported platform listed with a State of New in the listing, you could add additional operating systems and form factors as required.

15. Click Save.

16. Click the Actions button and then click Set to Production in the pop-up menu.

(13)

March 2015 8

4.3 Add the App Seed Data through MDM

We will now need to put the App’s configuration data (IP address of your SMP Server, Port etc) into the MDM Administration Console by way of creating an Application Policy. Currently, this is a separate user interface, which can be launched directly from the Mobile Secure administration dashboard.

(14)

March 2015 9

2. A new browser window will be launched for the MDM Administration (Afaria). You should be authenticated automatically via SSO.

3. Click Policy.

4. Now, locate the Android Application Policy which was automatically created in MDM when you published your Kapsel App in the Mobile Secure Admin Portal.

Note that an Application Policy and a Static Group for your Policy is automatically

generated from the Mobile Secure Administration Portal everytime you add a new App. The Policy should be easy to locate based on type, Last Modified date and the generated Policy name.

5. Click the Edit toolbar button for the selected App Policy and review the details.

(15)

March 2015 10

7. You will need a settings file to upload.

It is vital that you create a settings file and upload it, rather than pasting the text of the settings file directly into the MDM Admin Console.

Take particular note of the formatting, the settings are in the format

setting1=value1;setting2=value2 etc. They have to all be entered on the same line, word wrap to the next line is ok but do not enter each setting on a separate line.

8. Using your favorite text editor, create a new file called settings.txt and enter the configuration parameters you require for your App’s seed data. See the online SMP documentation located at http://help.sap.com/mobile-platform/ for details of the supported fields for your SMP version. Your content should look something like this, with the appropriate servername and port for your SMP server.

servername=1.2.3.4;serverport=8080;ishttps=false;vaultpolicy=defaulton;usercreationpolicy= automatic;

The example below for illustration purposes would be for creating a secure connection and using a certificate for user registration in SMP. The certificate request to your CA would be proxied through SMP view the Static Link Library, dependent on the CA settings being present in your MDM configuration.

servername=smp.server.com; serverport=8443; ishttps=true; vaultpolicy=defaulton; usercreationpolicy=certificate

(16)

March 2015 11

10. Click Save to commit your changes to the Application Policy.

11. Now we will simply need to assign the Application Policy to a Group. In this case we have selected “All Devices” for illustration purposes only.

12. Click the Link icon in the left hand toolbar with your Application Policy Selected.

13. In the link pane on the right, select the group of your choice and click the Link button, as shown.

(17)

March 2015 12

4.4 Test your Kapsel App Registration

1. On your device, open the Afaria MDM client.

2. If required, click the refresh button and locate the application you added in the previous steps. If it is not available, check your group assignment again.

3. Ensure that the App you tested with in the beginning of this document is uninstalled from the device before installing the app through the MDM (Afaria) client.

4. Install and run the App.

5. You should see the Registration screen shown below, without the server fields you saw in the beginning of this document.

6. If you have created the Application on your SMP server, enter your credentials and click Submit.

(18)

March 2015 13

Note, in the example screenshot above, the first entry in my App registration was created using a certificate, as shown in the User Name field.
