Temporary Kitchens
Hire solutions from PKL
PKL Group is the UK’s leading supplier of temporary kitchens for
hire. Whether you are undertaking a refurbishment, require extra
production capacity, are holding an event or are faced with a
sudden kitchen emergency, we are sure that you will be able to
find a solution from our range of 900 temporary kitchen units and
9,000 items of catering equipment providing the ability to feed
anywhere from a few, to many thousand of people each day.
Whether you are looking to hire a kitchen for just a few days, or
require a longer term solution for several years, our sales team
are here to help you, so please call on 0845 840 4242.
Sitework Services
Catering Equipment
Open Plan Kitchens
Favour ed Footprints ® Pr oven Packages ® Temporary Kitchens
Catering Equipment
Sitework Services
Temporary
Kitchen Units
The following section outlines our range of
standalone temporary kitchen units and ancillary
support facilities, which can be linked to our
kitchens to provide additional preparation,
storage, refrigeration or warewashing space.
Where you require help with design, we have
developed a range of Proven Packages -
combinations of our temporary kitchens and
support facilities linked together - which can be
viewed in the next section, on pages 28-51.
To make it easy for you to specify a kitchen
equipment layout that suits your menu
requirements, we have produced a range of
Favoured Footprints - combinations of catering
equipment that fit along the production side of
our temporary kitchens - which are illustrated on
pages 52-57. Once you have chosen a kitchen
size that suits your needs, all you need to do is
specify the Favoured Footprint that you would
like inside it and give us a call.
Alternatively, if your cooking requirements are
a little more specific, we have a range of 9,000
items of catering equipment from which you can
create your own bespoke kitchen design. A full
list of catering equipment is illustrated on pages
66-70 and more detailed information is provided
in the “PKL Catering Equipment Guide brochure”
which is available on request.
Temporary Kitchens
Mini Kitchen Facility
Pr oven Packages ® Favour ed Footprints ®
Open Plan Kitchens
Temporary Kitchens
Wall Construction
The wall panels are a composite sandwich panel construction, lined internally with a powder coated foodsafe steel skin
providing a wipe clean finish.
The wall is externally lined with a PVC plastisol coated steel skin. The core of the panel is comprised of 60mm dense rockwool insulation. The panel is non-combustible and CFC free.
Structural Steel
Construction
Kitchens are built utilising a robust steel frame construction.Self Levelling Facilities
All units are equipped withextendable and adjustable levelling posts located on the corners of the unit.This ensures a level working environment, even where units
Dual Fuel Capabilities
PKL portable kitchens are supplied with either gas or electric equipment, or a combination of both.Carbon Dioxide and
Monoxide Testing
PKL test portable kitchens and catering equipment as part of the commissioning and testing process to ensure a safe level of carbon monoxide and carbon dioxide in accordance with BS7967.
Full Length
Extraction Canopy
All of our temporary production kitchens are supplied with a full length extraction canopy as standard.Fire Suppression
All of our production kitchens are supplied with built in wet
chemical fire suppression
system as standard.
Temporary Kitchen Features
Climate Control
Portable kitchens are supplied with an easy clean, stainless steel, high powered ventilation system that guarantees 30 changes of air per hour. Optional temperature controlled kitchen preparation and storage units are also available.Light Levels
All portable kitchens have LUX levels of between 300 and 500 to ensure a safe food preparation environment.
Floors
The floors in PKL portable kitchens comply with BS7976 and achieve a friction coefficient of 36 or higher in order
to achieve a “low slip potential”. All units have a 5kN
floor loading, ensuring minimum deflection, and are solid
underfoot, able to withstand the rigours of the commercial catering environment.
Coved Flooring
The use of coved flooring in our kitchens makes them
Hygiene Stations
Kitchens are supplied with hygiene stations which includes a hand wash sink, towel dispenser and a soap dispenser.Gas Interlock
Ventilation is supplied in accordance with industry guidance DW172 and BS6173. A gas interlock system is supplied, which stops gas from entering the facility in the event of a loss of ventilation. All installations and testing are undertaken by Gas Safe registered engineers.Inside Your
Temporary Kitchen
All of our kitchens are manufactured to the highest standards
and incorporate the latest health and safety features.
All units are quality checked prior to each hire, ensuring they
reach you in the very best condition.
IP Rated Sockets
Our kitchens are supplied with additional IP rated 13 amp sockets, enabling you to plug in extra equipment or other electronic devices as required. Catering Equipment Sitework Services Pr oven Packages ® Favour ed Footprints ®Open Plan Kitchens
Temporary Kitchens
Mini Kitchens
The Mini Kitchen is our compact kitchen designed for use at sites where space may be at a premium. Ideal for smaller catering operations, the Mini Kitchen provides room for up to three chefs to work comfortably. The Mini Kitchen can produce up to 500 meals per day in its standard layout, although performance can be greatly increased with the addition of optional equipment. Extensively used by nursing homes, pubs and small
hotels, the Mini Kitchen is a fast and flexible solution for
your temporary catering needs.
Space for up to
three chefs to work
in comfort
Capable of producing up
to 500 meals per day
Extensively used by nursing
homes, pubs, small
hotels and event
caterers
Services Key
E1 63amp Single Phase w1 15mm Water Inlet F1 40mm Waste Outlet G1 Gas Inlet
Equipment Key
2 Racking 3 Water Heater 70lt4 Double Bowl Sink and Hand
Wash Station 1800mm
5 Undercounter Dishwasher 6 Six Burner Oven Range 7 Salamander Grill 8 Double Basket Fryer 12 Hot Cupboard 1200mm 18 Undercounter Fridge 354lt 19 Undercounter Freezer 354lt
Production Kitchens
Field Kitchens
E1 w1 F1 G1 3.8m 2.6mThe Field Kitchen is our smallest production kitchen and
is traditionally used for smaller or more specific catering
requirements.
Typically used by nursing homes, small pubs and hotels, the Field Kitchen provides a secure and hygienic working environment for two chefs.
The kitchen is ideal for supplying up to 250 meals per day and can be operational within minutes of arrival on site.
Operational within
minutes of arrival on site
Up to two chefs to
work in comfort
Can produce up to 250
meals per session
Ideal for small nursing
homes, pubs,
hotels
Interested in our Mini Kitchen?
See which of our Favoured Footprints you can specify for it on pages 54-55.
Services Key
E1 63amp Single Phase w1 15mm Water Inlet F1 40mm Waste Outlet G1 Gas Inlet
Equipment Key
1 Preparation Table 3 Water Heater 70lt124 Single Bowl Sink and Hand
Wash Station 1200mm
6 Six Burner Oven Range 7 Salamander Grill 8 Double Basket Fryer 9 Upright Fridge 610lt 12 Hot Cupboard 1200mm
Production Kitchens
9 12 124 3 1 8 7 6 E1 w1 F1 G1 6.2m 2.8m 2 18 4 3Choose your Favoured Footprint
from pages 54-55 8 12 7 6 5 19 w1 F1 Catering Equipment Sitework Services Pr oven Packages ® Favour ed Footprints ®
Open Plan Kitchens
Temporary Kitchens
Mixed Double Kitchens
The Mixed Double is the same size as our Magnum Kitchen, but provides a separate cold or dry storage room inside the unit.
This kitchen is suitable for use for large scale catering operations such as hospitals, large care homes, the MOD, event caterers and for industrial canteens.
Depending on the equipment specification, the Mixed
Double Kitchen is capable of producing up to 500 meals per day.
E1 w1 F1 G1 8.6m 2.8m
Services Key
E1 63amp Single Phase w1 15mm Water Inlet w2 22mm Water Inlet F1 40mm Waste Outlet G1 Gas Inlet
Equipment Key
1 Preparation Tables 2 Racking 3 Water Heater 70lt33 Double Bowl Sink and Hand
Wash Station 2400mm
6 Six Burner Oven Range 7 Salamander Grill 8 Double Basket Fryer 9 Upright Fridge 610lt 10 Upright Freezer 610lt 12 Hot Cupboard 1200mm 14 Combination Oven 24 Rack 18 Undercounter Fridge 354lt 19 Undercounter Freezer 354lt
Production Kitchens
Magnum Kitchens
The Magnum Kitchen is designed for use by all large scale catering operations including hospitals, hotels, MOD, industrial canteens and event caterers. Depending on the equipment selection, the Magnum Kitchen is capable of providing up to 1,000 meals per day, or an expanded menu range compared with our
smaller units, and provides space for up to five chefs
to work.
Services Key
E1 63amp Single Phase w1 15mm Water Inlet w2 22mm Water Inlet F1 40mm Waste Outlet G1 Gas Inlet
Equipment Key
1 Preparation Tables 2 Racking 3 Water Heater 70lt33 Double Bowl Sink and Hand
Wash Station 2400mm
6 Six Burner Oven Range 7 Salamander Grill 8 Double Basket Fryer 9 Upright Fridge 610lt 10 Upright Freezer 610lt 11 Hot Cupboard 1900mm 13 Combination Oven 10 Rack
Production Kitchens
14 6 7 12 8 9 10 19 18 2 33 3 w2 F1 E1 w1 F1 G1 8.6m 2.8mChoose your Favoured Footprint
from pages 56-57 13 9 11 33 13 6 7 2 10 8 3 6 1 w2 F1 F1 1
Space for up to
five chefs to work in
comfort
Capable of producing up
to 1,000 meals per day
Typically hired by hospitals,
hotels, the armed forces,
industrial caterers
and large event
caterers
Space for up to
five chefs to work in
comfort
Capable of producing up
to 500 meals per day
Typically hired by hospitals,
hotels, the armed forces,
industrial caterers
and large event
caterers
Catering Equipment Sitework Services Pr oven Packages ® Favour ed Footprints ®Open Plan Kitchens
Temporary Kitchens
Production Kitchens
Mini Triton
Plus Kitchens
The Mini Triton Plus is similar to the Mini Triton
Kitchen but offers extra preparation and storage
space.
The facility comprises four separate units
offering a pleasant walk -
through environment and is ideal for use in large scale events and for remote sites.
Quick to
assemble on site
Two units can be transported
per lorry, minimising transport
and offering a lower carbon
footprint
Ideal for medium to large scale
catering requirements, such as:
medium to large sized hotels,
small hospitals, medium
and large schools
Services Key
E1 63amp Single Phase E3 63amp Three Phase w1 15mm Water Inlet w2 22mm Water Inlet F1 40mm Waste Outlet G1 Gas Inlet
Equipment Key
1 Preparation Tables 2 Racking 3 Water Heater 70lt4 Double Bowl Sink and Hand
Wash Station 1800mm
6 Six Burner Oven Range 7 Salamander Grill 8 Double Basket Fryer 10 Upright Freezer 610lt 13 Combination Oven 10 Rack 18 Undercounter Fridge 354lt 19 Undercounter Freezer 354lt 20 Hood Dishwasher
56 Gastronorm Table Trolley
Mini Triton Kitchens
These three unit temporary kitchens offer all the benefits
of the large Triton Kitchens (see page 14), but have a smaller footprint.
They offer the same separation of kitchen areas for good
catering practice, and include production space, ample preparation facilities and an enclosed dry or cold storage space.
Production Kitchens
Additional preparation
or storage space
Quick assembly on site
Two units can be
transported per lorry
Services Key
E1 63amp Single Phase E3 63amp Three Phase w1 15mm Water Inlet w2 22mm Water Inlet F1 40mm Waste Outlet G1 Gas Inlet
Equipment Key
1 Preparation Tables 2 Racking 3 Water Heater 70lt33 Double Bowl Sink and Hand
Wash Station 1800mm
6 Six Burner Oven Range 7 Salamander Grill 8 Double Basket Fryer 10 Upright Freezer 610lt 13 Combination Oven 10 Rack 18 Undercounter Fridge 354lt 19 Undercounter Freezer 354lt 20 Hood Dishwasher
56 Gastronorm Table Trolley
6.2m 6m G1 w2 F1 E1 E1 E1 E3 w2 F1 E1 Choose your Favour ed Footprint from pages 54-55 11.2m 6.2m G1 E1 E1 w2 F1 E1 E1 w1 F1 E3 E1 w1 F1 w2 F1 Choose your Favour ed Footprint from pages 54-55 2 2 2 10 20 1 8 7 6 1 13 56 4 19 18 3 2 2 56 6 1 13 20 1 8 7 2 10 2 2 2 2 2 4 19 18 3 1 4 19 18 3 w2 F1 Catering Equipment Sitework Services Pr oven Packages ® Favour ed Footprints ®
Open Plan Kitchens
Temporary Kitchens
E1 w1 F1 G1 3.8m 2.6m 9 12 124 3 1 8 7 6
eKitchens
Our eKitchens are provided with a number of energy efficient
features which help to reduce energy consumption and improve the insulation property of the building.
We have a number of standard eKitchen units within our hire
fleet available in a range of different sizes. If you would like an
eKitchen facility rather than a standard temporary kitchen facility, please ask us.
0 10 20 30 40 50 60 70
JAN FEB MAR APR MAY JUN JUL AUG SEP OCT NOV DEC
Monthly energy consumption by fuel type (kWh/m
2)
Modified eKitchen unit Unmodified unit monthly consumption data
Latest
technology LED lights
Fully insulated floor with PIR
fire retardant insulation and heat
reflective membrane
Thermostatically controlled space heater
Double-glazed serving hatch
Wall panels with rockwool mineral
fibre insulation
Water and electricity metering
Optional solar energy
power supply
All of our units that have undergone these improvements have an energy performance rating of B42
Services Key
E1 63amp Single Phase w1 15mm Water Inlet F1 40mm Waste Outlet G1 Gas Inlet
Equipment Key
1 Preparation Table 3 Water Heater 70lt124 Single Bowl Sink and Hand
Wash Station 1200mm
6 Six Burner Oven Range 7 Salamander Grill 8 Double Basket Fryer 9 Upright Fridge 610lt 12 Hot Cupboard 1200mm
Production Kitchens
E1 E1 E3 w2 F1 F1 w1 F1 F1 w1 9.8m 8.6mTriton Kitchens
This kitchen is the most comprehensive of all our standard portable kitchens and comprises three separate units,
offering a pleasant walk-through working environment.
Measuring 75m2, the Triton Kitchen can be operational
within eight hours of delivery and is capable of producing in excess of 2,000 meals per sitting, depending on catering
equipment specification.
Triton Kitchens are widely specified by the MOD, hospitals,
large scale events and contract caterers.
Designed to
create an open plan
kitchen environment
for large events and
remote sites
Services Key
E1 63amp Single Phase E3 63amp Three Phase w1 15mm Water Inlet w2 22mm Water Inlet F1 40mm Waste Outlet G1 Gas Inlet
Equipment Key
1 Preparation Tables 2 Racking 3 Water Heater 70lt33 Double Bowl Sink and Hand
Wash Station 1800mm
6 Six Burner Oven Range 7 Salamander Grill 8 Double Basket Fryer 12 Hot Cupboard 1200mm 14 Combination Oven 24 Rack 18 Undercounter Fridge 354lt 20 Hood Dishwasher Choose your Favour ed Footprint from pages 56-57 14 14 6 7 8 1 2 2 2 2 2 2 2 2 2 33 1 33 1 3 3 18 1 20 12
Production Kitchens
E1 w2 F1 G1 Catering Equipment Sitework Services Pr oven Packages ® Favour ed Footprints ®Open Plan Kitchens
Temporary Kitchens
Production Kitchens
Central Island Canopies
Central Island Canopies have been developed to provide temporary production kitchens for larger events or mass public gatherings.
Catering equipment is installed along the centre of the canopy providing 12 metres of cooking space. Each canopy can hold up to eight 24 rack combination ovens, eight 250 litre boiling pans or twelve six burner ovens.
Fire
Safe
Example layout 6m 2.4m 2.5mBased on a 6m x
2.5m ISO container frame
Catering equipment installed
on both sides along the centre
Integrates fire suppression
systems, auto gas shut off and
gas detection devices
Complies with international
shipping codes and can be
easily transported
worldwide
Excludes Equipment
Services Key
E1 63amp Single Phase w2 22mm Water Inlet
F1 40mm Waste Outlet G1 Gas Inlet
Production Kitchens
Mobile Canopies
Fire safe Mobile Canopies have been specifically designed
for use within marquees, football stadia, conference venues and exhibition halls, allowing complete peace of mind. Catering equipment stands on a robust platform providing
a flat and hygienic base for your production operation.
The 2.25 or 2.9 metre canopies come with an automatic
fire suppression system and a full length extraction canopy to eliminate fire risks, carbon monoxide poisoning and the
release of cooking fumes and odours.
2.2m
1.3m 2.9m 2.25m
Available in 2 Sizes / Excludes Equipment
Fire
Safe
Services Key
E1 63amp Single Phase w2 22mm Water Inlet F1 40mm Waste Outlet G1 Gas Inlet
Service Requirement
With fully-integrated water, gas, electricity, extraction
and fire suppression systems,
these canopies provide a safe, hygienic and professional temporary catering facility.
Can be linked
to other canopies
Is easy to transport and offload
Comes with easy-to-connect
gas, electricity and ventilation
Has a fully integrated automatic
fire suppression system
Can be easily positioned
- anywhere!
Includes wheels for easy mobility
Catering Equipment Sitework Services Pr oven Packages ® Favour ed Footprints ®
Open Plan Kitchens
Temporary Kitchens
E2 E2
Cold Storage
Portable Coldrooms
The Portable Coldroom provides an immediate solution to refrigeration problems. Can have up to 40m3 of storage
space and requires only a single phase electrical supply. Supplied with four tier food safe racking, this unit is ideal for use during large refurbishment projects, to provide extra cold storage space during seasonal increases in demand, or to provide emergency facilities if your refrigeration equipment suddenly goes down.
+10
0C to
-22
0C
6.1m 2.9m 3.6mCompliance with
Food Safety Act 1990
Over 40m
3capacity
Over 40 linear metres of food
safe racking
Locking door
Temperature range of
+10°C to -22°C
Chill curtain
Equipment Key
2 RackingServices Key
E2 32amp Single Phase
Available in 2 Sizes
E1 F1 w1 E1 F1 w1Preparation Kitchens
Preparation Kitchens
Capable of standing alone or being linked to other temporary kitchen units for even greater production capacity, the Preparation Kitchen is fully compliant with all current food hygiene legislation.
Controlled
down
to 16
0C
6.2m 2.9m 3.8m Optional temperature controlled Preparation Kitchen availableFitted out with
stainless steel work
surfaces, refrigeration and
a double bowl sink with
wash hand basin
Can be stand-alone or linked to a
production kitchen for increased
capacity
Can be temperature controlled
down to 16°C
Ideal for nursing homes
or pubs
Equipment Key
1 Preparation Tables 2 Racking
3 Water Heater 70lt
33 Double Bowl Sink and Hand
Wash Station 1800mm
9 Upright Fridge 610lt
Services Key
E1 63amp Single Phase w1 16mm Water Inlet F1 40mm Waste Outlet
Available in 2 Sizes
3 1 1 33 9 2 1 1 9 1 3 1 33Standard Dimensions Standard Dimensions
Catering Equipment Sitework Services Pr oven Packages ® Favour ed Footprints ®
Open Plan Kitchens
Temporary Kitchens
Dry Storage
Dry Store Units
The Dry Store Unit is a secure, hygienic facility available in two sizes and can be linked to a temporary kitchen unit or to a permanent building with ease. Supplied with four tier food safe racking, this unit is ideal for use during large refurbishment projects or to provide additional storage during seasonal increase in demand.
E1 E1 2.9m 6.2m 3.8m
Equipment Key
2 RackingServices Key
E1 63amp Single Phase
Available in 2 Sizes
Can be linked
into an existing
building or any
of our portable
units
Cold Storage
Flat Pack Coldrooms
Flat Pack Coldrooms are ideal for locations where space
is limited, access is difficult or for use within an existing building or marquee. A flat, level site is required for these
units.
+4
0C to
-18
0C
E8 E8 4.8m 2.4m 2.4mTemperature
range of
-18°C to +4°C
Supplied with foodsafe
racking
Heavy duty non-slip floor
Chill curtain
Equipment Key
2 Racking
Services Key
E8 16amp Single Phase
Available in 5 Sizes
2.4m x 2.4m / 3.6m x 2.4m / 4.8m x 2.4m / 6.0m x 2.4m / 7.2m x 2.4m
Standard Dimensions Standard Dimensions
Catering Equipment Sitework Services Pr oven Packages ® Favour ed Footprints ®
Open Plan Kitchens
Temporary Kitchens
Warewashing Facility
Aquarius
Equipment Key
1 Preparation Tables 3 Water Heater 70lt 20 Hood Dishwasher33 Double Bowl Sink and Hand
Wash Station 1800mm
Services Key
E1 63amp Single Phase E3 63amp Three Phase w1 15mm Water Inlet w2 22mm Water Inlet
F1 40mm Waste Outlet
Dishwash output estimate
baskets per hour
Hood Dishwasher Rack Dishwasher 115 Rack Dishwasher 150 Hot Feed 55 115 150 Cold Feed 40 76 100
For best results we recommend using hot water feed
Pot Wash Units
E1 F1 w1 E1 F1 w1
Warewashing Units
When temporary dishwashing facilities are required, PKL’s portable Warewashing Units provide the ideal solution.
Warewashing Facility
6.2m 3.8m 2.9mAvailable in 2 Sizes
The pot wash unit
is perfect when you
need dedicated
warewashing facilities
Services Key
E1 63amp Single Phase w1 15mm Water Inlet F1 40mm Waste Outlet
Equipment Key
1 Preparation Tables 2 Racking 3 Water Heater 70lt33 Double Bowl Sink and Hand
Wash Station 1800mm 21 Sterilising Sink 2700mm 3 1 21 1 2 3 1 33 2
Tom Thumb
w2 F1 F1 w1 E3 E1 6.2m 2.8m 3 33 20 1 1 1Standard Dimensions Standard Dimensions
Equipment Key
2 Racking
20 Hood Dishwasher
Services Key
E1 63amp Single Phase w1 15mm Water Inlet F1 40mm Waste Outlet E1 F1 w1 3.8m 2 20 2.8m Catering Equipment Sitework Services Pr oven Packages ® Favour ed Footprints ®
Open Plan Kitchens
Temporary Kitchens
F2
w1 E1
Office
Support Facilities
Office and WC Units
Whether you need temporary office space or additional
facilities, these combination units are ideal.
3.2m
8.4m
Can be sited alone,
joined together or linked
into existing buildings
Ideal during refurbishments
or as extra facilities
Can be linked into existing
buildings or one of our
portable kitchen
facilities
Equipment Key
Toilet and Office Facilities
Services Key
E1 63amp Single Phase w1 15mm Water Inlet
F2 110mm Foul Outlet
Serving and Dining
Restaurant and Servery Units
PKL’s modular dining units can be linked together to form any size of facility, no matter how many people you wish to seat. By utilising till points, servery
and chilled refrigeration equipment from our fleet of catering equipment,
you can perfectly replicate a restaurant or canteen facility.
Our dining units can be easily linked to our portable kitchens, providing you with a complete temporary catering complex.
Modular open
plan building
Ideal for motorway services,
schools, hospitals, major event
sites and military sites
Suitable for over 1,000 people
in static location
Add male / female toilet
building as required
Seating for any
number
Standard Dimensions Example Design F2 Catering Equipment Sitework Services Pr oven Packages ® Favour ed Footprints ®Open Plan Kitchens
Temporary Kitchens
Support Units
The WC units complement our kitchen and dining modules. Whether you need temporary support units during referbishments or events, these combination units are ideal.
Support Units
WC Units
Standard design
format shown above -
PKL can adapt to suit
clients’ own requirements
Ideal during refurbishments
or as extra facilities
Can be linked into existing
buildings or one of our
portable kitchen
facilities
When professional portable laundry facilities are required, the unique PKL Portable Laundry system,
offers the most efficient, modern and comfortable
working environment.
Capable of standing alone or being linked to other PKL units or a permanent building, the unit comes
complete with a professional fitted laundry system,
chosen for easy cleaning and to withstand heavy duty use. F1 w1
Laundry Units
Equipment Key
2 Racking 3 Water Heater 70lt33 Double Bowl Sink and Hand
Wash Station 1800mm
200 Tumble Dryer 201 Washing Machine
Services Key
E3 63amp Three Phase w1 15mm Water Inlet w3 22mm Hot Water Inlet
F1 40mm Waste Outlet F3 50mm Waste Outlet G1 Gas Inlet
2.85m
6.2m
Hygienic non-slip
safety flooring
Capable of holding 35 bath
towels, 50 hand towels, 14
double sheets, 20 single sheets
Ideal for nusing homes,
hospitals, prisons, military sites
and other large-scale sites
Liquid soap and paper
towel dispenser
G1 F3 w3 E3 w3 F3 w13.2m
8.4m
Equipment Key
Toilet FacilitiesServices Key
E1 63amp Single Phase w1 15mm Water Inlet F2 110mm Foul Outlet w1 2 200 2 201 3 33 F2 E1 F2 F2 F2 Catering Equipment Sitework Services Pr oven Packages ® Favour ed Footprints ®
Open Plan Kitchens
Temporary Kitchens
Pr
oven Packages
®
Choose your ideal
Proven Package:
All our Proven Packages can be configured to suit
your site.
We will survey your site and advise on all siteworks,
services and delivery details.
Take advantage of our 25 years’ experience working
within the catering industry.
Proven Packages save you time and money when
choosing your temporary facility.
When deciding on a Proven Package there
are some important points to take into
consideration:
•
How many meal sittings will there be per day?
•
How many people are you feeding per sitting?
•
How long will you require the facility for?
•
How many staff will use the facility?
•
What type of catering do you expect to do?
•
How much fresh/frozen food is required?
•
Do you need food storage facilities, or can
you get fresh deliveries?
•
What type of support services are required
e.g. servery area?
•
What is the access to existing facilities e.g.
dishwashing?
Proven Packages
®+
Proven Packages
®
PKL Proven Packages are combinations of Mini or Magnum production kitchens alongside support facilities including storage units, refrigeration units, preparation units, warewashing facilities and optional dining areas. Together these combinations are proven
to work effectively as a temporary facility.
Proven Pacakges were created to save you time and money when deciding on a temporary facility. Our 15 Proven Packages range in size to cater for all your projects. Our smallest consists of only two units while our largest Proven Package is a combination of 12 units and dining for 360 people.
Although temporary facilities, many of our Proven Packages
have been specified for use on site for a number of years
during large scale or long term refurbishment projects.
You can also choose from our selection of
Favoured Footprints (equipment combinations)
for the production kitchens
Proven Package 10 with Dining Facility
We are
able to provide
a quote for any
Proven Package
within five
minutes!
Catering Equipment Sitework Services Favour ed Footprints ®Open Plan Kitchens
Contents
Temporary Kitchens
In the past this has ranged from use as an à la carte hospitality suite at one of the top motor racing events
of the season, to a temporary staff
canteen due to our client’s own being refurbished. With the Mini Kitchen changed to Favoured
Footprint D, you have got an impressive banqueting kitchen. Remove the furniture in the dining area, add some upright hot cupboards and you have an excellent holding and plate-up area.
Services Key
Equipment Key
E1 63amp Single Phase E2 32amp Single Phase E3 63amp Three Phase w1 15mm Water Inlet w2 22mm Water Inlet F1 40mm Waste Outlet G1 Gas Inlet 1 Preparation Table 2 Racking 3 Water Heater 70lt
4 Double Bowl Sink and Hand
Wash Station 1800mm
5 Undercounter Dishwasher 6 Six Burner Oven Range
12 Hot Cupboard 1200mm 18 Undercounter Fridge 354lt 19 Undercounter Freezer 354lt 27 Refrigerated Servery 1200mm 28 Hot Servery 1900mm
PP2
Kitchen
+
Dining Facility
PP2 +
6m 11.5m 12 5 8 7 6 1 4 3 19 18 2 27 28 Mini Production Dining Facility F1 w1 E1 E2 E1 G120
plSeat
up to
Favoured
Footprint
TMB
Mini ProductionProven Packages
®The Mini Kitchen provides an excellent facility for up to three
staff to work in comfort and the
addition of the coldroom (fridge or freezer) allows for weekly deliveries of chilled or frozen
food. This package is also a great hospitality kitchen and is often chosen for short term event projects as it is all delivered on a single vehicle and the hire rates
offer superb value for money.
16 6 13 13 13 4 19 18 2 2 2 Mini Production E1 G1 w2 F1 F1 w1 F1 F1 3 Coldroom
Services Key
Equipment Key
E1 63amp Single Phase E2 32amp Single Phase E3 63amp Three Phase w1 15mm Water Inlet w2 22mm Water Inlet F1 40mm Waste Outlet G1 Gas Inlet 2 Racking 3 Water Heater 70lt
4 Double Bowl Sink and Hand
Wash Station 1800mm
6 Six Burner Oven Range 13 Combination Oven 10 Rack 16 Boiling Pan 150lt
PP1
Kitchen Facility
PP1
3m 11m Mini ProductionFavoured
Footprint
TMG
Proven Packages
® E2 w2 F1 Pr oven Packages ® Catering Equipment Sitework Services Favour ed Footprints ®Open Plan Kitchens
Contents
If you need a kitchen and a comprehensive dining area for 60 people, look no further than PP3 plus dining.
PP3
Kitchen
+
Dining Facility
6m19m
60
plSeat
up to
Favoured
Footprint
TME
Mini Production 27 Dining Facility E1 E2 E2 25 28Proven Packages
®PP3 is an excellent all round solution to a kitchen closure in
a small school, hotel or staff
canteen.
PP3 has been used by several clients as a semi-permanent solution, where they have
freed up valuable table space in their pub/restaurant and bolted this option onto the back of the building, providing fantastic value for money while at the same time generating room for more covers.
Services Key
Equipment Key
E1 63amp Single Phase E2 32amp Single Phase E3 63amp Three Phase w1 15mm Water Inlet w2 22mm Water Inlet F1 40mm Waste Outlet G1 Gas Inlet 1 Preparation Table 2 Racking 3 Water Heater 70lt
4 Double Bowl Sink and Hand
Wash Station 1800mm
6 Six Burner Oven Range 7 Salamander Grill & Table Stand 8 Double Basket Fryer
12 Hot Cupboard 1200mm 13 Combination Oven 10 Rack 18 Undercounter Fridge 354lt 19 Undercounter Freezer 354lt 25 Till Point
27 Refrigerated Servery 1200mm 28 Hot Servery 1900mm 29 Hood Dishwasher 40 Basket
PP3
Kitchen Facility
PP3 +
11m 3mFavoured
Footprint
TMC
Mini Production 12 6 8 7 4 19 18 2 29 2 E1 G1 3 w2 F1 E1 13Mini Production Tom Thumb
1
Proven Packages
® w2 F1 w2 F1 Pr oven Packages ® Catering Equipment Sitework Services Favour ed Footprints ®Open Plan Kitchens
Contents
Even though the Aquarius Dishwash Unit is sometimes on the large side for the size of kitchen, it provides invaluable storage space during longer hire periods.
PP5 can be increased in production capacity by selecting one of the heavy duty Favoured Footprints, such as M or P, which can be backed up by upgrading the dishwasher to one of the more powerful 115 or 150 rack machines. 8 9 11 E1 G1 F1 w1 33 Magnum Production 7 13 1 6 2 10 13 3 w2 F1 F1 F1 w1 Aquarius Dishwash E1 E3 1 1 4 3 20 2
Services Key
Equipment Key
E1 63amp Single Phase E2 32amp Single Phase E3 63amp Three Phase w1 15mm Water Inlet w2 22mm Water Inlet F1 40mm Waste Outlet G1 Gas Inlet 1 Preparation Table 2 Racking 3 Water Heater 70lt
4 Double Bowl Sink and Hand
Wash Station 1800mm
6 Six Burner Oven Range 7 Salamander Grill & Table Stand
10 Upright Freezer 610lt 11 Hot Cupboard 1900mm 13 Combination Oven 10 Rack 20 Hood Dishwasher 55 Basket 33 Double Bowl Sink 2400mm
PP5
Kitchen Facility
PP5
15m 3mFavoured
Footprint
TMM
Magnum ProductionProven Packages
®At over 8.6m, the Magnum Kitchen can house a huge array of production equipment, making
it the most versatile unit in our fleet.
PP4 is an event favourite where large numbers of hospitality meals need to be provided, especially where the meals are mainly prepared on site and not pre-delivered, hence the
additional prep space offered.
This facility can easily produce in excess of 1,000 high quality meals, as a large number of our
existing clients do on a regular
basis. This configuration of units has
also proved popular as a research and development kitchen for ready meal manufacturers, giving them the facility they need without having to spend capital on building something that may not be needed long term.
F1 w1 E1 Magnum Production Preparation Kitchen w1 F1 1 4 3 2 9 1 1 1 33 9 E1 G1 3 7 7 6 2 10 11 8
Services Key
Equipment Key
E1 63amp Single Phase E2 32amp Single Phase E3 63amp Three Phase w1 15mm Water Inlet w2 22mm Water Inlet F1 40mm Waste Outlet G1 Gas Inlet 1 Preparation Table 2 Racking 3 Water Heater 70lt
4 Double Bowl Sink and Hand
Wash Station 1800mm
5 Undercounter Dishwasher 6 Six Burner Oven Range
9 Upright Fridge 610lt 10 Upright Freezer 610lt 11 Hot Cupboard 1900mm 33 Double Bowl Sink 2400mm
PP4
Kitchen Facility
PP4
3m 15mFavoured
Footprint
TMJ
Magnum ProductionProven Packages
® 1 6 5 1 F1 w2 w2 F1 F1 1 Pr oven Packages ® Catering Equipment Sitework Services Favour ed Footprints ®Open Plan Kitchens
Contents
Dining Facility E2 E2 E2 E1 25 27 28
If you need all of the facilities featured in PP6 plus a dining area seating up to 90, then look no further.
PP6
Kitchen
+
Dining Facility
14m 17m
90
plSeat
up to
Favoured
Footprint
TME
Mini ProductionProven Packages
®PP6 is widely used during kitchen refurbishment projects for medium to large kitchens where the hire length is usually from 4 weeks to 12 months. It also provides a great central production kitchen at major event sites.
With the use of the Mini Kitchen and the smaller prep rooms, it keeps the overall size down to a minimum, which, as we know at these major events, is imperative due to being charged per m2
of ground covered.
Services Key
Equipment Key
E1 63amp Single Phase E2 32amp Single Phase E3 63amp Three Phase w1 15mm Water Inlet w2 22mm Water Inlet F1 40mm Waste Outlet G1 Gas Inlet 1 Preparation Table 2 Racking 3 Water Heater 70lt
4 Double Bowl Sink and Hand
Wash Station 1800mm
6 Six Burner Oven Range 8 Double Basket Fryer 9 Upright Fridge 610lt 17 Griddle 900mm 18 Undercounter Fridge 354lt 19 Undercounter Freezer 354lt 25 Till Point 27 Refrigerated Servery 1200mm 28 Hot Servery 1900mm 29 Hood Dishwasher 40 Basket
PP6
Kitchen Facility
PP6 +
7m 13m 8 4 E1 G1 F1 w1 Preparation 17 6 13 13 2 19 29 18 w2 F1 E2 E1 F1 w1 Mini Production E1 E2Tom Thumb Dishwash
2 2 3 4 9 1 3 2 Coldroom Goods In / Out
Proven Packages
® F1 w2 F1 1 1 Pr oven Packages ® Catering Equipment Sitework Services Favour ed Footprints ®Open Plan Kitchens
Contents
This combination is capable of catering for 1, 000 meals, three times a day, with storage for deliveries two to three times per week. It has proved to be a very popular design for many overseas
requirements, as it has everything a permanent kitchen would have, with the distinct advantage of being able to be moved rapidly from one place to the next.
PP8
Kitchen Facility
Services Key
Equipment Key
E1 63amp Single Phase E2 32amp Single Phase E3 63amp Three Phase w1 15mm Water Inlet w2 22mm Water Inlet F1 40mm Waste Outlet G1 Gas Inlet 1 Preparation Table 2 Racking 3 Water Heater 70lt
4 Double Bowl Sink and Hand
Wash Station 1800mm
6 Six Burner Oven Range 7 Salamander Grill & Table Stand
10 Upright Freezer 610lt 11 Hot Cupboard 1900mm 13 Combination Oven 10 Rack 15 Bratt Pan 80lt
20 Hood Dishwasher 55 Basket 33 Double Bowl Sink 2400mm
PP8
19m 9.5m E1 E3 E1 E2 w2 F1 F1 F1 w1 E1 G1 w2 F1 F1 w1 F1 w1 E1 E2 PreparationMagnum Production Link Unit
Aquarius Dishwash Coldroom Coldroom Dry Store 8 7 6 6 1 15 1 2 10 11 9 33 3 2 9 1 1 4 3 2 2 2 1 4 3 2 20 Goods In / Out
Favoured
Footprint
TMK
Magnum ProductionProven Packages
®Up to 12 staff can work in this
facility, and the central link area can be adapted for any type of application - hospital trolley storage and distribution, event kitchen central hub, or additional dry storage. PP7 is a great kitchen
complex for longer term hires requiring extra circulation and
storage, and the catering staff will find the working environment
a pleasant one due to the space available.
PP7
Kitchen Facility
Services Key
Equipment Key
E1 63amp Single Phase E2 32amp Single Phase E3 63amp Three Phase w1 15mm Water Inlet w2 22mm Water Inlet F1 40mm Waste Outlet G1 Gas Inlet 1 Preparation Table 2 Racking 3 Water Heater 70lt
4 Double Bowl Sink and Hand
Wash Station 1800mm
6 Six Burner Oven Range 8 Double Basket Fryer
11 Hot Cupboard 1900mm 14 Combination Oven 24 Rack 15 Bratt Pan 80lt
16 Boiling Pan 150lt
20 Hood Dishwasher 55 Basket 33 Double Bowl Sink 2400mm
PP7
9.5m 12m 8 E1 G1 w2 F1 Preparation 1 15 1 16 6 E2 Magnum Production Aquarius Dishwash Link Unit F1 w1 F1 w1 w2 F1 w1 F1 F1 E1 E1 E3 1 14 2 2 10 11 9 33 3 1 4 3 2 20 2 9 1 3 1 1 4 Goods In / OutFavoured
Footprint
TMN
Mini ProductionProven Packages
® 1 1 E2 13 1 Pr oven Packages ® Catering Equipment Sitework Services Favour ed Footprints ®Open Plan Kitchens
Contents
E2 E1 E2 E2 Dining Facility 25 27 26 68 68
For a complete turnkey kitchen and dining facility
to cater for up to 500 staff at 120 per sitting, opt for
PP9 plus dining.
PP9
Kitchen
+
Dining Facility
14m27m
120
plSeat
up to
Favoured
Footprint
TMM
Magnum ProductionProven Packages
®PP9 provides caterers with an excellent use of space and incorporates a three-unit Triton
Kitchen plus a staff changing /
WC Unit.
The Triton Kitchens are widely used for long-term requirements. This facility provides caterers
with a first class cooking and
working environment as well as
incorporating a staff changing
facility.
Event caterers often use PP9 with additional stand-alone 3.6m or 6.2m freezer/fridge units alongside. This leaves the walk-in fridge and freezer unit of the Triton Kitchen ideally suited for daily storage.
w2 F1 F1 Preparation Magnum Production Coldroom Dishwashing 1 8 7 1 6 13 33 3 E1 G1 F1 w1 F1 w1 E1 E3 F2 w1 E1 F2 w1 Freezer Dry Store Male Female 13 2 2 2 18 20
Services Key
Equipment Key
E1 63amp Single Phase E2 32amp Single Phase E3 63amp Three Phase w1 15mm Water Inlet w2 22mm Water Inlet F1 40mm Waste Outlet G1 Gas Inlet 1 Preparation Table 2 Racking 3 Water Heater 70lt 6 Six Burner Oven Range 7 Salamander Grill & Table Stand 8 Double Basket Fryer
13 Combination Oven 10 Rack 18 Undercounter Fridge 354lt
25 Till Point
26 Ambient Servery 1200mm 27 Refrigerated Servery 1200mm 33 Double Bowl Sink and Hand
Wash Station 2400mm 68 Hot Servery 1200mm
PP9
Kitchen Facility
PP9 +
8.6m 13.8mProven Packages
® F1 w2 F1 1 1 2 2 1 1 33 3 Pr oven Packages ® Catering Equipment Sitework Services Favour ed Footprints ®Open Plan Kitchens
Contents
E2 E2 E2 E2 Dining Facility 25 26 69 28 28 E1
PP10
Kitchen
+
Dining Facility
18m
25m
The addition of a dining area for up to 150 people provides an excellent major construction site main kitchen.
150
plSeat
up to
Favoured
Footprint
TMM
Favoured
Footprint
TMP
Proven Packages
®We have often seen PP10 on hire for up to two years, where a kitchen has
been lost through fire and the
replacement has taken a considerable length of time to be rebuilt. It provides a great all round kitchen complex and
will give the caterers a comfortable working environment over a long period of time. With the extra dry storage available, this facility suits
operations offering a more complex
menu.
Services Key
Equipment Key
E1 63amp Single Phase E2 32amp Single Phase E3 63amp Three Phase w1 15mm Water Inlet w2 22mm Water Inlet F1 40mm Waste Outlet G1 Gas Inlet 1 Preparation Table 2 Racking 3 Water Heater 70lt
4 Double Bowl Sink and Hand
Wash Station 1800mm
6 Six Burner Oven Range 7 Salamander Grill & Table Stand 8 Double Basket Fryer
11 Hot Cupboard 1900mm 13 Combination Oven 10 Rack 20 Hood Dishwasher 55 Basket 25 Till Point
26 Ambient Servery 1200mm 28 Hot Servery 1900mm 33 Double Bowl Sink 2400mm 69 Refrigerated Servery 1990mm
PP10
Kitchen Facility
PP10 +
6m 18m Magnum Production 1 8 7 6 1 13 13 Coldroom F1 w1 Dry Store w2 F1 F1 F1 w1 F1 w1 E1 E1 E1 Aquarius Dishwasher Preparation Link Unit E1 E3 20 2 2 2 10 11 9 33 3 1 4 3 2 9 1 Goods In / Out 1 4 3Proven Packages
® 1 1 2 E1 G1 F1 w2 F1 E2 Pr oven Packages ® Catering Equipment Sitework Services Favour ed Footprints ®Open Plan Kitchens
Contents
E2 E2 E2 E2 Dining Facility 25 26 69 28 28 E1 E2 PP11 is an outstanding facility and has been used during many kitchen refurbishments and hospital projects.
PP11
Kitchen
+
Dining Facility
39m 18.5m
210
plSeat
up to
Favoured
Footprint
TMQ
Mini ProductionFavoured
Footprint
TMD
Magnum ProductionProven Packages
®With the main production kitchen backed up by the Mini Kitchen, this
unit configuration is ideally suited
to a complicated menu structure,
where different food styles need to
be catered for within one kitchen.
Services Key
Equipment Key
E1 63amp Single Phase E2 32amp Single Phase E3 63amp Three Phase w1 15mm Water Inlet w2 22mm Water Inlet F1 40mm Waste Outlet G1 Gas Inlet 1 Preparation Table 2 Racking 3 Water Heater 70lt
4 Double Bowl Sink and Hand
Wash Station 1800mm
6 Six Burner Oven Range 8 Double Basket Fryer 9 Upright Fridge 610lt 10 Upright Freezer 610lt 16 Boiling Pan 150lt 17 Griddle 900mm 18 Undercounter Fridge 354lt 19 Undercounter Freezer 354lt 22 Rack Dishwasher 115 Basket 25 Till Point
26 Ambient Servery 1200mm 28 Hot Servery 1900mm 33 Double Bowl Sink 2400mm
Above are maximum loads. Please contact PKL for average running loads.
PP11
Kitchen Facility
PP11 +
19m 13.5m Magnum Production 13 13 1 6 17 8 Coldroom w2 F1 F1 F1 w1 F1 w1 E1 Aquarius Dishwasher Preparation Pot Wash E1 E3 2 22 2 10 11 9 33 3 4 3 2 9 F1 w1 F1 w1 F1 w1 E2 E1 E2 E1 Mini Production Coldroom Dry Store 13 4 3 2 2 4 3 18 19 4 3 13 13 6 16 13 2 2 1 E1 G1 Goods In / OutProven Packages
® E1 G1 F1 w2 F1 2 1 1 1 1 1 1 F1 w2 F1 E2 Pr oven Packages ® Catering Equipment Sitework Services Favour ed Footprints ®Open Plan Kitchens
Contents
PP12
Kitchen
+
Dining Facility
Add a 360 seater restaurant to PP12 to create a catering complex that can provide a comprehensive kitchen and dining area.
This would be suitable for a thousand troops in a foreign location, a major construction site, a busy secondary school canteen or even a restaurant for athletes at a major event.
E2 E2 E2 E2 Dining Facility 69 26 28 E2 E2 25 28 E2 E1 20.5m 48m
360
plSeat
up to
Favoured
Footprint
TMQ
Favoured
Footprint
TMP
Proven Packages
® PP12 is a first class,high capacity, large scale, temporary catering facility. It includes everything that you would expect in a permanent large institutional kitchen. In addition, it can easily accommodate the extra
staff needed for
transporting the food from the kitchen out to the required location. If your requirement is for a kitchen to provide several thousand meals, either for a prolonged period of time or for
a one-off large scale
event, PP12 will certainly meet your needs.
Services Key
Equipment Key
E1 63amp Single Phase E2 32amp Single Phase E3 63amp Three Phase w1 15mm Water Inlet w2 22mm Water Inlet F1 40mm Waste Outlet G1 Gas Inlet 1 Preparation Table 2 Racking 3 Water Heater 70lt
4 Double Bowl Sink and Hand
Wash Station 1800mm
6 Six Burner Oven Range 8 Double Basket Fryer 9 Upright Fridge 610lt 10 Upright Freezer 610lt
16 Boiling Pan 150lt 17 Griddle 900mm 21 Sterilising Sink
23 Rack Dishwasher 150 Basket 25 Till Point
26 Ambient Servery 1200mm 28 Hot Servery 1900mm 33 Double Bowl Sink and Hand
Wash Station 2400mm
Above are maximum loads. Please contact PKL for average running loads.
PP12
Kitchen Facility
PP12 +
20.5m 22.5m Magnum Production 6 1 17 13 13 13 E1 G1 w2 F1 F1 F1 w1 F2 w1 E1 Aquarius Dishwasher Preparation Pot Wash E1 E3 2 23 10 11 9 33 3 33 3 E1 G1 F1 w1 F1 w1 E2 E1 Magnum Production Coldroom Dry Store 8 2 4 3 11 9 33 3 14 14 6 16 1 4 3 2 9 1 1 2 E1 E1 E1 F2 w1 E2 F1 w1 Preparation 16 2 9 1 10 1 1 1 2 Coldroom WC FacilityProven Packages
® 2 1 1 F1 w1 1 3 1 1 2 F1 w1 w2 F1 F1 F1 w2 F1 1 E2 Pr oven Packages ® Catering Equipment Sitework Services Favour ed Footprints ®Open Plan Kitchens
Contents
1000
plFeed
up to
PP14 comprises a four-unit open plan kitchen facility that allows for one favoured footprint and your choice of preparation, storage and warewashing equipment. A facility this size would be perfect to create a pop-up restaurant facility, or serve a basic menu for up to 1,000 meals per day.
PP14
Kitchen Facility
12.2m
4.8m
Proven Packages
®PP13 comprises two kitchens linked together and provides space for one Favoured Footprint as well as preparation, storage and dishwashing areas. This facility would be ideal for a smaller scale pop-up restaurant facility that can serve up to 500 meals per day.
PP13
Kitchen Facility
500
plFeed
up to
Proven Packages
®Services Key
Equipment Key
E1 63amp Single Phase w1 15mm Water Inlet w2 22mm Water Inlet F1 40mm Waste Outlet G1 Gas Inlet 1 Preparation Table 2 Racking 3 Water Heater 70lt
4 Double Bowl Sink and Hand
Wash Station 1800mm
6 Six Burner Oven Range 8 Double Basket Fryer 12 Hot Cupboard 1200mm
14 Oven 24 Rack
18 Undercounter Fridge 354lt 19 Undercounter Freezer 354lt 33 Double Bowl Sink and Hand
Wash Station 2400mm
56 Gastronorm Table Trolley 1250mm 57 Gastronorm Table Trolley 450mm
Above are maximum loads. Please contact PKL for average running loads.
6.5m
4.8m
Services Key
Equipment Key
E1 63amp Single Phase w1 15mm Water Inlet w2 22mm Water Inlet F1 40mm Waste Outlet G1 Gas Inlet 1 Preparation Table 2 Racking 3 Water Heater 70lt
4 Double Bowl Sink and Hand
Wash Station 1800mm
6 Six Burner Oven Range 7 Salamander Grill & Table Stand 8 Double Basket Fryer
10 Upright Freezer 610lt 11 Hot Cupboard 1900mm 14 Oven 24 Rack
18 Undercounter Fridge 354lt 20 Hood Dishwasher 55 Basket 55 Gastronorm Trolley
77 Beverage Water Boiler
81 Heated Gantry - Counter Top 1800mm
Above are maximum loads. Please contact PKL for average running loads.
G1 w2 F1 E1 E1 w1 F1 12 8 57 6 14 19 18 56 3 4 12 1 33 1 E1 F1 w1 w2 F1 G1 E1 F1 w2 F1 E1 F1 w1 E1 2 20 9 10 18 1 4 1 18 55 18 18 1 81 81 4 11 11 3 6 14 8 7 18 77
PP13
PP14
Pr oven Packages ® Catering Equipment Sitework Services Favour ed Footprints ®Open Plan Kitchens
Contents
19m
4.8m
PP15 is a six-unit complex and allows for two favoured footprints and your choice of preparation, storage and warewashing equipment.
A facility this size can be used to provide restaurant facilities for large-scale applications including music festivals and sporting events.
PP15
Kitchen Facility
Proven Packages
®Proven Packages
® w1 F1 E1 G1 w2 F1 E1 E1 w1 F1 F1 w2 E1 E1 F1 w1 2 33 1 18 1 18 2 2 56 22 18 1 79 11 11 8 8 17 17 17 7 18 18 77 1 81 81 11 11 4 8 7 6 14 18Services Key
Equipment Key
E1 63amp Single Phase w1 15mm Water Inlet w2 22mm Water Inlet F1 40mm Waste Outlet G1 Gas Inlet 1 Preparation Table 2 Racking 3 Water Heater 70lt
4 Double Bowl Sink and Hand
Wash Station 1800mm
6 Six Burner Oven Range 7 Salamander Grill & Table Stand 8 Double Basket Fryer
17 Griddle 900mm
18 Undercounter Fridge 354lt 22 Rack Dishwasher 115 Basket 33 Double Bowl Sink and Hand
Wash Station 2400mm
56 Gastronorm Table Trolley 1250mm 77 Beverage Water Boiler
79 Bain Marie - Counter Top
PP15
2000
plFeed
up to
F1 w1 F1 w1 Pr oven Packages ® Catering Equipment Sitework Services Favour ed Footprints ®Open Plan Kitchens
Contents
Favour
ed Footprints
®
Open Plan Kitchens
3 9 33 11 10 2
Favoured Footprints
®Why use PKL
Favoured Footprints?
Remove guesswork
Make use of our kitchen design experience
Quick and easy
14 designs for 150 to 2,000 meals per day
Tried and tested
Every design has been used successfully, many times
Cost effective
Standard package, discounted price
3 18 33 19 2
Magnum
Equipment Key
3 Water Heater 70lt33 Double Sink with Hand Wash Basin 9 Upright Fridge 610lt
11 Hot Cupboard 1900mm 10 Upright Freezer 610lt
2 Four Tier Mobile Racking
Mini
Equipment Key
3 Water Heater 70lt
33 Double Sink with Hand Wash Basin 18 Undercounter Fridge 354lt
19 Undercounter Freezer 354lt 2 Four Tier Mobile Racking
Mini Prep Side Standard
Magnum Prep Side Standard
Favoured Footprints
®
Choosing the catering equipment for your production kitchen can be a time consuming task.
We want to speed up the process, making it
easier and more cost effective for you with
PKL Favoured Footprints.
Favoured Footprints are predesigned
layouts and combinations of equipment
to run along the production side of our
Magnum and Mini Kitchens.
These 14 proven layouts have been
developed over thousands of hires.
An efficient, cost effective option, each
Favoured Footprint varies according to the
style of catering and the number of people
being fed.
Before deciding on the Favoured
Footprint for your production kitchen,
there are a number of points to
consider:
• The style of catering and
menu selection
• The Preferred workflow
• The number of meals to be
prepared each day
Choose your Favoured
Footprint from pages 54-55
Choose your Favoured
Footprint from pages 56-57
Mini Production Side
Magnum Production Side
Catering Equipment Sitework Services Contents Pr oven Packages ® Temporary Kitchens
