Positioning Guide:

Cisco Unified Communications

(2)

Positioning Guide: Cisco Unified Communications

A Unified Call Manager Solution can replace a traditional telephone system, offering telephone functionality throughout an entire organisation, whilst allowing easy integration of company-specific applications. For example, choosing a phone number from a document or number recognition of a caller through a customer databank, can contribute to increased productivity and customer satisfaction. This positioning guide outlines the various possibilities of the relevant Cisco solutions (Cisco Unified Communications Manager / Express / Business Edition and Cisco UC 500)

UC 500

UC Manager

_Express

UC Manager

_{Business Edition}

UC Manager

Users 8 to 48, depending on the _{selected platform} Up to 240, depending on the _{choosen Cisco Router} Up to 500 Up to 30,000 per cluster

Installation

possibilities Complete UC solution for

small organisations

Complete UC solution for small to medium organisations

Centrally controlled solution, external connection through SRST for small enterprises

Centralised - up to 100 locations can be clustered for large corporations

Platform Device Router Server Server

Redundancy No No No Yes

Protocols SIP, SCCP, H323 SIP, SCCP, H323 SIP, SCCP, H323, MGCP SIP, SCCP, H323, MGCP

Voicemail Unity Express integrated Optional Unity Express (as _{AIM or NM)} Unity Connection integrated Optional Unity or Unity _Connection 8

50 users

200 users

500 users

30.000 users

UC 500

8 - 48 phones

Phones

Business Edition

MCS 7828 to 500 phones

Phones

MCS 7816

up to 500 phones up to 1,000 phonesMCS 7825 up to 2,500 phonesMCS 7835 up to 5,000 phonesMCS 7845

Cisco Unified Communications

Manager Express

2811 2821 2851 3825 3845 2801 up to 24 phones up to 36 phones up to 48 phones up to 96 phones up to 168 phones up to 240 phones 1861 up to 8 devices Comstor Belgium

Mechelen Campus Schaliënhoevedreef 20E BE - 2800 Mechelen

(3)

Comstor Belgium

Positioning Guide: Cisco Unified Communications

Manager Express can in most cases be reconfigured to become the gateway router for a Communications Manager solution through a simple firmware upgrade. Because of this flexible customisation the investment for successful companies which exceed their existing capacity can be preserved.

Optional products: Cisco Unity Express

Cisco Unity Express can integrate voice mail and auto attendant services in a cost-effective manner with the Cisco Integrated Services Routers. This enables the reduction of operating costs and increases productivity within the company.

Additional uses for the Cisco Communications Manager Express

Integrating information systems such as, CRM or Microsoft Office (Cisco Unified Call-•

Connector for Microsoft Dynamics CRM, Cisco Unified CallConnector for Salesforce.com, Cisco Unified CallConnector for Microsoft Office)

Integrating voice and web functionality for interactive meetings and presentations •

(Cisco Unified MeetingPlace Express)

Enabling video communications for the entire company (Cisco Unified Video Advantage) •

Integrating Wireless IP phones and Soft phones for PCs (Cisco IP Communicator) •

Cisco Unified Communications Manager Express

Cisco Unified Communications Manager Express and Cisco Unity Express deliver rich voice and unified communications capabilities on a Cisco integrated services router (ISR) platform. Data networking, video, wireless LAN, and security, including VPN and firewall, can be enabled on the same platform. Cisco Unified Communications Manager Express and Cisco Unity Express are well suited to businesses with 30 to 200 employees. Cisco ISRs are simple to deploy and manage, with high reliability to ensure continuous operation. The many features of Cisco Unified Communications Manager Express include:

Paging •

Intercom •

Integration with Microsoft Dynamics CRM and Salesforce.com •

Resilience •

SIP line-side enhancements •

Integration with Cisco Unified Contact Center Express supporting up to 50 agents •

Extension Mobility within the site •

For added resiliency, businesses can use the Hot Standby Routing Protocol (HSRP) between two different Cisco Unified Communications Manager Express routers or use Cisco Unified Survivable Remote Site Telephony (SRST) on one of the routers.

Support of IP telephony

Cisco UC Manager Express supports between 8 and 240 IP Phones. Table 1 gives an overview of the number of IP phones that each router platform, running Cisco Unified Communications Manager Express, can support.

A secure investment with easy upgrade possibilities

To maximise the level of re-usability during upgrade it is possible to migrate the Communications Manager Express to support a Cisco Unified Communications Manager, this is possible due to their shared foundations and operating systems. The Cisco Unified Communications

Unified Communications 500

For organisations with 8 to 48 employees the Cisco Unified Communications 500 series is a cost-effective, integrated Unified Communications solution. The systems consists of voice mail, an auto attendant, video support, VPN and wireless capabilities. Moreover, the system can be integrated with existing desktop systems such as a diary, e-mail and CRM software. The system offers corporate Unified Communications technology for small and medium businesses and can be adapted easily to meet changing business needs.

The basic system consists of the following components:

Cisco Unity Express (voice mail and auto attendant) •

Eight Power over Ethernet ports integrated •

Expandable with the Cisco Catalyst 520 series switches •

Security, firewall and VPN functionality •

Optional WLAN •

GUI-based configuration assistant •

The basic configuration of the Cisco UC500 consists of 8 switched Power over Ethernet connections (PoE), 4 FXS ports for connecting analogue devices with either 2 ISDN ports or 4 FXO ports. Moreover, it is possible to expand the system at a later time with a Voice Interface Card for additional analogue or ISDN ports. Voicemail functionality, audio connection for music on-hold music, an Ethernet uplink port for WAN and a console are all included. For connecting more than 8 devices, the basic configuration can be extended through an additional ethernet up-link by using 8 or 24 port Cisco UC Companion switches. The variance licensed for 8 or 16 users are desktop units. Which can optionally be incorporated into a 19“ racking system. The various licensed for 8 or 16 usrs are desktop units with can optionally include a built in Wireless LAN Access point or can be incorporated into a 19“ racking system.

ISR models 1861 2801 2811 2821 2851 3825 / 3845

Max. number of

participants 8 24 36 48 96 168 / 240 Max. ISDN BRI 2 8 12 20 20 20 / 32

Max. ISDN PRI – - 2 4 6 12 / 16

ADSL optional Yes Yes Yes Yes Yes Yes

Firewall Yes Yes Yes Yes Yes Yes

Rack Mount No Yes Yes Yes Yes Yes

Technical details:

1861 8 UC500 48 2801 24 2851 96 3825 2811 36 2821 48 3845 168 240

Overview of Cisco models

(4)

Positioning Guide: Cisco Unified Communications

Cisco Unified Communications Manager

The Cisco Unified Communications Manager facilitates phone system functionality and supports PC applications (such as Cisco Unified CallConnector & Attendant Console), VoIP gateways, IP phones and multimedia applications within an enterprise office. Other services such as Unified Messaging, Multimedia Conferencing, Contact Center and interactive Auto Attendant are fully supported.

The product consists of a complete communications and service package, including the Cisco Unified Communications Manager Bulk Administration Tool, Cisco Communications Manager CDR (call data registration) Analysis and Reporting Tools, Cisco Unified Communication Manager Real-Time Monitoring Tools and the Cisco Unified Communications Manager Assistant application.

Features and benefits

Scalable and modular with fail over support •

A complete end-to-end Unified Communications solution providing holistic security and •

Quality of Service (Intelligent voice priority)

Scalable up to 30,000 IP phones per cluster, enabling balanced load and redundancy • MCS 7828 Business Edition MCS 7816 MCS 7825 1.000 MCS 7835 2.500 MCS 7845 500 500 5.000

Overview of Cisco models

Maximum number of phones

Cisco Unified Communications Manager, Business Edition is suitable for medium-sized companies with up to 500 employees and 20 remote sites. This solution integrates voice, video, mobility and messaging services through a single platform. Until recently a separate server was required for each application. Business Edition brings all these applications together on a single server. This provides significant cost savings for installation, support and maintenance of the system, thus substantially reducing the total cost of ownership. With the Cisco Unified Communications Manager Business Edition medium-sized companies can now easily and cost-effectively implement Enterprise phone communication systems and applications at headquarters and branches.

The basic system consists of the following components:

Cisco Unified Communications Manager •

Cisco Unity Connection •

Mobility Manager •

Cisco MCS Media Convergence Server 7828 •

The Cisco Unified Communications Manager increases the communication capabilities of packed oriented devices like IP phones, Voice-over-IP (VoIP) gateways and, interactive multimedia applications. Business Edition improves the productivity and mobility of employees through, “single number reach“ and a voice mail box, which filters and transmits messages intelligently to mobile employees through IP or mobile phones.

Additionally Business Edition offers applications such as, a the Bulk Administration Tool, CDR Analysis (call data registration) and Reporting Tool, Real-Time Monitoring Tool and Cisco Unified Communications Manager Assistant.

Cisco Unity Connection incorporates integrated messaging, voice recognition and automated call-routing into a single system. Messaging and voice components are linked to the data network in a transparent way, enabling any time any place access to calls and messages. These advanced communication services make use of the converged network. Voice mail messages can be viewed and heard from the E-mail inbox or through a proprietary Web browser. Advanced Automated Attendant functionalities make use of intelligent routing, allowing call screening by enabling messages to be heard as they are recorded.

Cisco Unity Connection Release 2.0 is the voicemail software that is part of the Cisco Unified Communications Manager software.

Cisco Unified Communication Manager, Business Edition

Comstor Belgium

(5)

Positioning Guide: Cisco Unified Communications

Model Program key Display Handsfree Protocol Switch ports

CP-7985G 1 Yes, Video Yes SCCP 10/100

CP-7975G 8 Yes, colour / touch _screen Yes SCCP / SIP 10/100/1000

CP-7971G-GE 8 Yes, colour / touch _screen Yes SCCP 10/100/1000

CP-7970G 8 Yes, colour / touch _screen Yes SCCP / SIP 10/100

CP-7965G 6 Yes, colour Yes SCCP / SIP 10/100/1000

CP-7962G 6 Yes Yes SCCP / SIP 10/100

CP-7961G-GE 6 Yes Yes SCCP / SIP 10/100/1000

CP-7945G 2 Yes, colour Yes SCCP / SIP 10/100/1000

CP-7941G-GE 2 Yes Yes SCCP / SIP 10/100/1000

CP-7937 1 Yes Yes SCCP

-CP-7931G 24 Yes Yes SCCP 10/100

CP-7914 14 Yes - SCCP

-CP-7911G 1 Yes monitor only SCCP / SIP 10/100

CP-7906G 1 Yes monitor only SCCP / SIP No

SCCP = Skinny Client Control Protocol, SIP = Session Initiation Protocol

IP phone 7906G / 7911G Graphic pixel display (192x64)

-10/100 switch ports (7911)

-Illuminated Hold and Menu keys

-Four function keys and Scroll Toggle Bar

-Power over Ethernet

-phone

Video Advantage 640x480 VGA sensor for

-better video quality Supports Cisco Unified IP

-phones and IP Communicator Camera on/off

-H.263 Video Codec - 128

-Kbps to 1.5 Mbps bit rate USB 2.0 connector with 1.80

-m cable

Applicable to certain models: -794x, 796x, 797x, IP Communicator IP Phone 7921G Wireless wireless 802.11b/g IP phone

-Large colour display

-Number display and voicemail messaging

-Standard features such as transfer,

-hold and conference

Application key for Push To Talk through XML

-Handsfree calling and connectivity for

-external headset

WLAN standards IEEE 802.11a, 802.11b

-and 802.11g

Wireless

IP video phone 7985 High resolution video images

-Advanced XML support

-Five keys to control the video function

-Integrated connection for external headset

-Integrated dual Ethernet switch ports

-Power over Ethernet based on standard

-Video

IP phone 7941G 7941G-GE

Additional options in addition to those of the 7940: Gigabit support (only GE version)

-Graphic black and white high-resolution display

-Illuminated function keys

-IP phone 7942 / 7945

Additional options in addition to those of the 7941G:

Broadband audio (G722 codec)

-Gigabit support (only 7945) -Colour (only 7945) -(Electronic Hook Switch compatible) IP phone 7940G Graphic black and white display

-4 dynamic function keys

-2 programmable function keys

-Integrated dual Ethernet switch port

-Cisco In-Line Power compatible

-IP phone 7961G / 7961G-GE Additional options in addition to those of the 7960:

Gigabit support (only GE version)

-High resolution black and white display

-Illuminated keypad

-phone IP Phone 7960G

Graphic black and white display

-Four dynamic function keys

-Six programmable keys

-Integrated dual Ethernet switch port

-phone

phone phone

Telefoon

IP phone 7962 / 7965

Additional options in addition to those of the 7961G:

Broadband audio (G722 codec)

-Gigabit support (only 7965) -Colour (only 7965) -(Electronic Hook Switch compatible) IP Phone 7975G

Additional options in addition to those of the 7970: Gigabit support

-Broadband audio (G722 Codec)

-phone

IP Phone 7970G 8 programmable keys

-Touch screen colour display with 320x234

-pixels

5 dynamic function keys

-Advanced XML support

-Power over Ethernet support

-Integrated connection for external microphone

-and speakers

phone

IP phone 7971G-GE

Additional options in addition to those of the 7970: Gigabit support

-phone

IP Conference Station 7937G The Cisco Unified IP Conference Station 7937G offers many improvements over the existing Cisco Unified IP Conference Station 7936. New features include:

Superior wideband acoustics with the support of

-the G.722 wideband codec

Support for IEEE Power over Ethernet (PoE) or

-the Cisco Power Cube 3

Expanded room coverage up to 30 feet by 40

-feet with the optional external microphone kit Support for a third-party lapel microphone kit

-New larger backlit liquid crystal display

Overview of Unified Cisco IP phones

To benefit from all the rich features that IP telephony has to offer, Cisco has developed a wide range of IP devices, including IP phones (desk phones), which can be used for business communication. In addition, Cisco offers the 7921G wireless (WLAN) Phone, the IP Communicator (soft phone) and the Unified Personal Communicator for the PC, analogue PC adaptors (ATA) and a video conferencing system. For each application within your organisation, Cisco offers the right IP-phone/device.
