Solving big data problems in real-time with CEP and Dashboards - patterns and tips

Solving big data problems in real-time with CEP and Dashboards -

patterns and tips

Kevin Wilson Karl Kwong

• Big data is a reality and organizations must embrace to

succeed

• Complex Event Processing (CEP) technology gives us a new

way to look at big data – real-time micro-trending

• CEP supports data processing patterns that are very useful

but difficult to implement in traditional database model

• Leveraging big data in real-time will change the way

organizations run

IDC predicts size of data “digital universe” grow to 2.7 zetta-bytes by end 2012 - ↑ 48%

Recent Explosion of Data

Average human hair is about 70 µm diameter – very small Let’s say 1 byte of data = 1 human hair

2.7 zettabytes worth of hair side-by-side:

• distance circling the earth 100 billion times • go to the Sun and back 100 thousand times

Putting it into Perspective

Enterprises

• Web - weblogs, click stream events, web transactions

• ERP - B2B transactions, B2C transactions • Contact Center – Emails, telephony

Industries

• Telecomm – call records (CDR) • Utilities – smart meters

• Manufacturing - equipment health

Common Characteristics

• High volume and velocity • Streaming sources

• Operational in nature

Demands a new way to look at this data!

In-memory Analytical Appliances – SAP HANA

• Load data into large main memory • Store data an optimized format

• Large set aggregations (few million rows) can be done in seconds

• Data analysis tools can interface with the appliance to provide typical data analysis

Two Common Approaches to Big Data

Map Reduce and Distributed File Systems - Hadoop

• Takes advantage of distributed processing to transform data

• Aggregation and transformation of extremely large set (multi billion rows) can be done in hours • Data can then be fed into more traditional data

What is addressed by in-memory and map reduce?

• Volume of data • Processing time • Analysis

What do we gain from big data today?

• Higher resolution (more records) can be used for analysis

• Trending can done over longer periods

So what is missing?

• Focused on historical analysis

• Insights more suitable for strategic and tactical decisions

• Need a way to cope with big data and answer what

is happing right now!

Analytical Trending

• Examples:

• Quarterly sales performance • Annual customer satisfaction • Monthly branch queue time

• Typical Aggregation:

• Years • Quarters • Months • Weeks

• Support strategic and tactical decisions

• Strategic investments

• Compensation and rewards • Weekly Staffing

• Corporate performance

Different Way to Trend

Real-time Micro Trending

• Examples:

• Max wait time for agent • Banner ad click rate • Failed inspection rate

• Typical Aggregation:

• Days • Hours • Mins

• Rolling or sliding window

• Support operational or time-sensitive decisions

3 3.1 3.2 3.3 3.4 3.5 3.6 0-9 10-19 20-29

10 Min Avg.

5 Min Avg.

1 Min Avg.

landmark aggregation periods

• Longer the period the less up-to-date • Resolution is reduced

• Does not reflect what is happening right now

Increasing aggregation frequencies • Reduces latencies

• Increases resolution

• Still doesn’t tell what is happening right now

At some point shortening

aggregation period breaks down • Too short aggregation period exposes

noise in the data

• Loose visibility on general data movement

Is there a way hide noise and lower latency?

Rolling or Sliding Window Aggregation

Sliding window approach

• Aggregate over an logical time/event window • Computation is done continuously

• Filter out noise

• Take into account the most recent data

New Class of Software is Needed

Data Mart Performance Management

Complex Event Processing (CEP)

Semantic Layer Context History KPIs / Goals Alerts / Notifications Visualize Analyze

What is happening now?

What has happened

SAP Sybase Event Stream Processor

• Unlimited number of input streams • Input events in native formats

• Incoming data is processed as it arrives, according to the business logic defined using high level authoring tools

• Stream output to apps, dashboards • Range of built-in adapters for

out-of-the-box connectivity

• Java, C++ and .NET API’s for custom integration

?

Event Stream Processor Sybase IQ

CCL - primary method to interact with SAP Sybase ESP

• Extension to Structured Query Language (SQL)

• Added keywords for defining and manipulating time

windows and related operations

• CCL allows continuous processing of high-volume of

streaming data

Continuous Computing Language (CCL)

Insert Into StreamSummary

Select Max(Price) as High, Min(Price) as Low,

First(Price) as Open, Last(Price) as Close From StreamFeed Keep Every 1 minute

CCL enables some powerful window-based data processing concepts beyond continuous metrics

• Occurrence detection

• Detect 1-N occurrences of a condition over a time period

• Useful in fraud detection and intrusion detection • Example: detect excessive use of a smart cash card

over a short period of time

• Absence detection

• Test for absence of a certain event over a given period • Useful in transportation and logistic scenarios

• Example: matching order, packing and shipping records over set SLA period – absence of event trigger alert

• Threshold crossing

• Detect when a value crosses a predefined threshold • Support up, down or dual direction threshold violation • Use of multiple threshold to create complex alarm

conditions

• Example: combine multiple threshold such as wait-time, drop rate and skill set to set off critical alert to reallocated or call in addition agents

• Condition-based stream splitting

• State management

Power Dashboards with New Insights

Real-time dashboards allow users to:

• Assess current environment quickly

• Provide quick summary of situation

• Only see what’s relevant and important for job

• Comprehend severity of situation (or opportunity)

• Show “current” information vs. “projected” or “historic” data

• Reflect impact across activities or processes or

• Project status (red/yellow/green) • Show appropriate time window &

appropriate detail what is being measured

• Act in time

• Display prominent but relevant alerts • Point to specific actions

Some Questions Answered by Micro-trending Big Data

 Spot emerging threats or opportunities

before it’s too late

 React to changing conditions sooner

 Make decision based on more timely

information

Financial firm: “I want to track the current value and net gain of all my positions, and monitor my aggregate

exposures in real-time”

eCommerce: “I want to customize offers based on current behavior to improve conversion rates”

Telecom provider: “I want to alert Customer Service when an individual customer has just experienced their

4th _{dropped call in a 2 hours”}

Relevance in Every Industry

Financial

Capital markets

Banking fraud prevention

Telecommunications

Operations monitoring Mediation

Proactive churn management

Utilities

Smart grid applications Demand management

Transportation

Location-based monitoring Customer satisfaction / loyalty

Retail / consumer product goods

Real-time click stream analysis Customer sentiment analysis Supply chain management

Hospitality / Service

On-line gaming

Customer experience and loyalty

Healthcare

Healthcare (e-care, asset tracking)

Public Sector

• CEP complements HANA and map reduce in managing Big

Data

• Real-time micro-trending of big data supports informed

operational decision making

• CEP provides powerful data processing capabilities

unachievable using tradition databases

• Combining CEP and Big Data give organizations a definite

advantage
