Catalogue

(1)

Catalogue

2014

(2)

All schematic line drawings, photographs and copy in this catalogue are fully protected by copyright.

No part of this catalogue may be reproduced in any form without written permission of Duckworth

& Kent Ltd. Duckworth & Kent Ltd., reserves the right to make changes at any time, without notice,

in product specifi cation and availability. Schematic line drawings and photos may vary from actual

size. Tip drawings are shown enlarged. Descriptive, typographic, or photographic errors are subject to

correction. Name(s) of instruments are often comprised of a surgeon’s name, combination of surgeons’

names or DK’s name together with the category of the instrument. “DK” is used in this catalogue to

identify Duckworth & Kent. Arrow indicates view at point.

D&K® is a registered trademark of Duckworth & Kent Ltd. All other brand names are trademarks or

registered trademarks of their respective owners.

It has never been easier to

stay in touch with Duckworth & Kent

.

For further information on our

current range

of ophthalmic instrumentation and services visit

www.duckworth-and-kent.com

or

contact us

:

Duckworth & Kent Ltd.

Terence House

7 Marquis Business Centre

Royston Road, Baldock

Herts, SG7 6XL, England

Tel: +44 (0) 1462 893254

Fax: +44 (0) 1462 896288

Email:

[email protected]

Website:

www.duckworth-and-kent.com

Website

(3)

CONTENTS

1

Scissors

5-10

2

Forceps

13-70

3

Needle Holders

73-78

4/5

Diamond Knives

81-90

6

Hooks, Probes, Manipulators

and Miscellaneous

93-131

7

Punches and Inserters

135-136

8

Irrigation and Aspiration

139-154

9

Fixation Rings, Gauges,

Markers and Specula

157-188

DK

IOL Loading and Delivery Systems

191-195

T

Sterilising Trays

199-202

Index

205-210

(4)

(5)

2014

Scissors

Capsule, Capsulotomy

Conjunctival

Corneal & Corneal Section

Iris

IOL Cutter

Retinal

Utility & Westcott

Vannas

(6)

• Blunt tips, curved blades • Universal cutting blades

• Cut length 6mm, tip to pivot length 11mm • Standard handle, length 116mm

DK Castroviejo Miniature Corneal Scissors, Curved

1-118

• Blunt tips, curved blades

• Long inner blade with smoothly polished ends • Cut length 5mm, tip to pivot length 11mm • Round handle, length 108mm

Anwar Corneal Scissors, Curved to Right

Corneal scissors specially designed for removal of the fi nal corneal lamella in front of the Descemet’s membrane. One blade is longer to avoid an accidental cut into the Descemet’s membrane. The longer blade has a smoothly polished tip end to allow minimum dissection of any attachment between the Descemt’s membrane and the corneal lamella.

1-218

h fi l l l ll i ff f h D ’ bb O bldd i

Westcott Style Tenotomy Scissors, Curved

1-510

• Cut length 10mm, tip to pivot length 21mm • Standard handle length 116mm

• Fine blades, suitable for precise bevelled incision opening

Osher Universal Conjunctival Micro Scissors

1-227

DK Capsule Scissors, Curved

1-116

Scissors - Capsule, Capsulotomy

Scissors - Conjunctival

Scissors - Corneal and Corneal Section

• Sharp tipped straight scissor

• Curved 23 gauge tube, length 20.5mm • Squeeze action handle closes scissors • Round squeeze handle, length 127mm

Capsule Scissors, curved 23 gauge

1-625

m m

• Long outer blade with smoothly polished ends • Cut length 5mm, tip to pivot length 11mm • Round handle, length 108mm

Anwar Corneal Scissors, Curved to Left

1-219

Corneal scissors specially designed for removal of the fi nal corneal lamella in front of the Descemet’s membrane. One blade is longer to avoid an accidental cut into the Descemet’s membrane. The longer blade has a smoothly polished tip end to allow minimum dissection of any attachment between the Descemt’s membrane and the corneal lamella.

(7)

Designed for penetrating keratoplasty, or for surgeons who may require Scissors for enlargement of cataract incision. • Blunt tips, curved blades

• Universal cutting blades

• Cut length 6mm, tip to pivot length 11mm • Barrett balanced set handle, length 120mm • Distinctive identifi cation labelling

Barrett Corneal Scissors, Curved

1-223

m mm

• Blunt tips, curved blades, right

Castroviejo Corneal Scissors, Curved to Right

1-400

• Blunt tips, curved blades, left

Castroviejo Corneal Scissors, Curved to Left

1-401

• Blunt tips, curved blades, right

• Cut length 5.mm, tip to pivot length 10mm • Standard handle, length 113mm

Castroviejo Corneal Scissors, Curved to Right

1-410

• Blunt tips, curved blades, left

Castroviejo Corneal Scissors, Curved to Left

1-411

Scissors - Iris

• Sharp tips, straight blades

• Cut length 5mm, blade length 11mm • Round handle, length 107mm

DK Iris Scissors, Straight

1-210

• Sharp tips, curved blades

DK Iris Scissors, Curved

1-211

DK Iris Scissors, Curved

(8)

• Sharp tipped straight micro scissors • 2.2mm long blade

• Straight 23 gauge tube, length 32.5mm

• Squeeze action handle closes scissors • Round squeeze handle, length 138mm

Squeeze Handle Straight Micro Scissors - 23 Gauge

The fi xed head range of Vitreoretinal forceps and scissors are a one piece device featuring the same tip and handle design as the interchangeable head.

All fi xed head vitreoretinal forceps and scissors are supplied with a protective guard which can be sterilised.

Tips of the the Osher Haptic Cutter have a notch that fi ts over and grasps the haptic (fi g1). When the handle of the Osher Haptic Cutter is squeezed (fi g2 - 3) the outside tube of the tip moves forwards and severs the haptic.

• 20 gauge, 20mm long shaft

• Squeeze action activates jaws to sever haptic • Round squeeze handle, length 145mm

Osher Haptic Cutter

• Blunt tips with micro serrated blades • Cut length 8mm

• Tip to pivot length 9.5mm • Standard handle, length 94mm

Osher IOL Cutter, Angled

1-705

• Blunt tips with micro serrated blades • Cut length 8mm

• Tip to pivot length 9.5mm • Standard handle, length 98mm

Osher IOL Cutter, Straight

Video available on our website - www. duckworth-and-kent.com/media

1-700

1-805

₁

2 3

Scissors - Retinal - Fixed Heads

1-841

Squeeze Handle Straight Micro Scissors - 23 Gauge

1-841B

• Blunt tipped straight micro scissors • 1.75mm long blade

IOL Cutters

Squeeze Handle Straight Micro Scissors - 20 Gauge

1-841-1

(9)

All Interchangeable Vitreoretinal (VR) Heads are sold separate from the handle.The VR Heads require a handle for operation. ONLY the DK Squeeze Handle for VR Instrument Heads, ref 6-676, is suitable. All VR Heads come fi tted with a plastic (PEEK) re-usable Protective Cover, that can withstand cleaning and reprocessing cycles. The VR Heads are screwed onto the thread of DK Squeeze Handle for VR Instrument Heads. It is recommended, for device protection, to keep the plastic (PEEK) re-usable protective cover fi tted until the instrument is required for use.

Squeeze Handle for Vitreoretinal Instrument Heads

• Suitable for all Duckworth & Kent Vitreoretinal Instrument Heads • Overall Length 92 mm (without head)

• Squeeze action handle

• Sharp tipped curved micro scissors • 2.2mm long blade

Squeeze Handle Curved Blade MicroScissors - 23 Gauge

• Sharp tipped curved micro scissors • 2.2mm long blade

• Straight 23 gauge tube, length 31.3mm • Requires DK Squeeze Handle, ref 6-676

• Detachable tip heads for cleaning purposes • Colour coding for tip and gauge size identifi cation • Once attached to round squeeze handle, length is 144mm

Curved Blade Micro Scissors Head, 23 Gauge

Straight Micro Scissors Head, 20 Gauge

• Blunt tipped straight micro scissors • 1.9mm long blade

Straight Blunt Micro Scissors Head, 23 Gauge

Straight Micro Scissors Head, 23 Gauge

1-842

issors

1-841N

1-841BN

Scissors - Retinal - Interchangeable Heads

1-841-1N

1-842N

(10)

• Cut length 10mm,tip to pivot length 20mm • Standard handle, length 115mm

Westcott Style Tenotomy Scissors, Curved

DK Westcott Style Stitch Scissors, Curved

• Semi-sharp tips, curved blades

Westcott Style Stitch Scissors, Curved

• Blunt tips, straight blades

DK Westcott Style Stitch Scissors, Straight

• Semi-sharp tips, straight blades

Westcott Style Stitch Scissors, Straight

Fine blades, designed with suffi cient length, suitable for iridectomy, iridotomy, sphincterotomy as well as cutting 10.0 nylon suture. • Blunt tips, slightly curved blades

• Cut length 6mm, tip to pivot length 12mm • Barrett balanced set handle, length 120mm • Distinctive identifi cation labelling

Barrett Micro Scissors, Curved

Scissors - Utility & Westcott

1-221

1-500

1-500B

1-501

1-501B

1-510

1-512

(11)

• Sharp tips, angled blades

• Cut length 6mm, tip to pivot length 11.5mm • Standard handle, length 97mm

DK Gills Vannas Scissors, Angled

• Cut length 9mm, tip to pivot length 16.5mm • Standard handle, length 100mm

Gills Welsh Vannas Scissors, Angled

DK Vannas Scissors, Curved

DK Vannas Scissors, Straight

DK Vannas Scissors, Angled

DK Vannas Scissors, Curved

Vannas Scissors, Curved

Vannas Scissors, Straight

Scissors - Vannas

1-110

1-111

1-111B

1-112

1-120

1-121

1-122

1-312

(12)

(13)

2014

Forceps

Capsulorhexis

Cilia

Clamps

Conjunctival

Corneal

Flap Lifting / Utility

Intraocular Lens

Muscle

Notched / Pierse

Nucleus Cracking & Prechopping

Plain Tip

Retinal

Toothed

Tissue / Dressing

Tying

Miscellaneous

(14)

• Utrata style tip

• Iris stop platforms 8.5mm from tips • Curved shafts, tip to curve length 13mm • Round handle, length 115mm

DK Utrata Capsulorhexis Forceps, Curved Shafts

• Utrata style tip

• Iris stop platforms 8.5mm from tips • Curved shafts, tip to curve length 13mm • 8mm diameter round handle, length 115mm

DK Utrata Capsulorhexis Forceps, Curved Shafts

• Utrata style tips

• 1mm increment markings along shafts • Iris stop platforms 8.5mm from tips • Curved shafts, tip to curve length 13mm • 8mm diameter round handle, length 115mm

The 1mm markings along the shafts provide a gauge to estimate the size of the capsulorhexis

• Iris stop platforms 8.5mm from tips • Angled shafts, tip to angle length 13mm • Round handle, length 115mm

DK Utrata Capsulorhexis Forceps, Straight Shafts

m

Capsulorhexis, Utrata Direct Action

2-712NR

2-712NR8

2-712-1NR8

2-2-712

• Iris platforms 8.5mm from tips • Curved shafts, tip to curve length 13mm • Round handle, length 118mm

2-2-712S

• Iris platforms 8.5mm from tips • Curved shafts, tip to curve length 13mm • Round handle, length 90mm

DK Utrata Capsulorhexis Forceps, Curved Shafts

(15)

• Iris stop platforms 8.5mm from tips • Curved shafts, tip to curve length 13mm • Flat handle length 89mm

• Iris stop platforms 8.5mm from tips

• 45° angled curved shafts, tip to curve length 13mm • Flat handle, length 84mm

• Iris stop platforms 8.5mm from tips • Angled shafts, tip to angle length 13mm • 8mm diameter round handle, length 115mm

DK Utrata Capsulorhexis Forceps, Straight Shafts

• Iris stop platforms 8.5mm from tips

• 45° angled fi ne shafts, tip to angle length 13mm • 8mm diameter round handle, length 115mm

DK Utrata Capsulorhexis Forceps, Straight Fine Shafts

mm 3 3mm

2-714NR8

2-714-1NR8

2-718

2-718N

Utrata Capsulorhexis Forceps, Curved Shafts

2-2-718

• Iris platforms 8.5mm from tips • Curved shafts, tip to curve length 13mm • Flat Handle, length 118mm

DK Utrata Capsulorhexis Forceps, Curved Shafts

2-2-718S

• Iris platforms 8.5mm from tips • Curved shafts, tip to curve length 13mm • Flat handle, length 90mm

(16)

• Iris stop platforms 8.5mm from tips • 45° angled shafts, tip to angle length 13mm • Flat handle, length 84mm

Utrata Capsulorhexis Forceps, Straight Shafts

• Iris stop platforms 8.5mm from tips • 45° angled shafts, tip to angle length 13mm • Flat long handle, length 115.5m

Utrata Capsulorhexis Forceps, Straight Shafts

• Iris stop platforms 8.5mm from tips • 45° angled shafts, tip to angle length 13mm • Flat handle, length 89mm

Utrata Capsulorhexis Forceps, Straight Shafts

2-719

2-719N

2-719-1

2-2-719-1

• Iris platforms 8.5mm from tips • Straight shafts, tip length 13mm • Flat handle, length 118mm

DK Utrata Capsulorhexis Forceps, Straight Shafts

2-2-719S

• Iris platforms 8.5mm from tips • Straight shafts, tip length 13mm • Flat handle, length 90mm

(17)

11mm

1.5mm 0.9mm

When entering through a corneal incision the increased curvature of forceps shafts prevent corneal deformation during use. The forceps are available with either sharp pointed tips or smooth blunt tips, both have serrated interlocking platforms.

Increased curvature of forceps shafts prevent corneal deformation • Pointed serrated interlocking tips

• Curved shaft

• Tip to pivot point 11mm

Mackool-Inamura Round Handle Capsulorhexis Forceps with Pointed Tips

• Cross action tips, 1.5mm width at pivot box • Tips angled 45° to handle

• Round handle, overall length 120mm

When entering through a corneal incision the increased curvature of forceps shafts prevent corneal deformation during use. The pointed tips puncture the anterior capsule in initiating the tear.

11mm

1.5mm 0.9mm

dh b

• Blunt serrated interlocking tips • Curved shaft

Mackool-Inamura Round Handle Capsulorhexis Forceps with Blunt Tips

When entering through a corneal incision the increased curvature of forceps shafts prevent corneal deformation during use. The smooth blunt tips ensure easy entry.

• Pointed serrated interlocking tips • Curved shaft

Mackool-Inamura Flat Handle Capsulorhexis Forceps with Pointed Tips

• Flat handle, overall length 120mm

When entering through a corneal incision the increased curvature of forceps shafts prevent corneal deformation during use. The pointed tips puncture the anterior capsule in initiating the tear.

11mm 1.5mm 0.9mm 11mm 1.5mm 0.9mm

• Blunt serrated interlocking tips • Curved shaft

Mackool-Inamura Flat Handle Capsulorhexis Forceps with Blunt Tips

When entering through a corneal incision the increased curvature of forceps shafts prevent corneal deformation during use. The smooth blunt tips ensure easy entry.

11mm

1.5mm 0.9mm

Capsulorhexis, Mackool Inamura Cross Action

2-2-706G

2-2-706GR

2-2-706G-1

(18)

• Pointed serrated interlocking tips • Curved shaft, tip to pivot point 11mm • Cross action tips, 1.5mm width at pivot box

Inamura Flat Handle Capsulorhexis Forceps, Suitable For Scleral Tunnel Incision

• Tips angled 45° to handle • Flat handle, overall length 120mm

Inamura Short Flat Handle Capsulorhexis Forceps, Suitable For Scleral Tunnel Incision

• Tips angled 45° to handle

• Short fl at handle, overall length 92mm

Inamura Round Handle Capsulorhexis Forceps, Suitable For Scleral Tunnel Incision

• Round handle, overall length 120mm SMALL INCISION SIZE

Designed to fi t comfortably through any incision down to 1.8mm.

SMOOTH ACTION Three pivot point precision provides the highest quality with a smooth controlled action. CORNEAL INCISION

or SCLERAL TUNNEL

Tip to pivot length either 10.0mm or 11.0mm. Designed specifi cally for cornea or scleral placed incisions. POINTED SERRATED TIPS

Precise interlocking serrated tips with a sharp point enable the surgeon to initiate the capsule tear then securely grasp the capsule to perform the capsulorhexis. 10mm or 11mm 1.5mm 0.9mm

Dr O. Malauzat from Bordeaux France has carried out an independent review of the Duck-worth and Kent Inamura Capsulorhexis Forceps reference 2-2-716G-7R. Dr Malauzat evalu-ated the forceps through four diff erent clear corneal incision sizes: 2.2mm, 1.8mm, 1.7mm and a tapered 1.5 to 1.7mm incision.

1.8mm corneal incision

Inamura Short Round Handle Capsulorhexis Forceps, Suitable For Scleral Tunnel Incision

• Short round handle, overall length 92mm

11mm 1.5mm 0.9mm 11mm 1.5mm 0.9mm 11mm 1.5mm 0.9mm 11mm 1.5mm 0.9mm Ti l d 45°t h dl

Capsulorhexis, Inamura Cross Action

2-2-716G-6

2-2-716G-6S

2-2-716G-6R

(19)

Inamura Short Round Handle Capsulorhexis Forceps, Suitable For Corneal Incision

• Short round handle, overall length 91mm • Pointed serrated interlocking tips

• Curved shaft, tip to pivot point 10mm • Cross action tips, 1.5mm width at pivot box

Inamura Short Flat Handle Capsulorhexis Forceps, Suitable For Corneal Incision

Inamura Round Handle Capsulorhexis Forceps, Suitable For Corneal Incision

• Round handle, overall length 119mm • Pointed serrated interlocking tips

Inamura Flat Handle Capsulorhexis Forceps, Suitable For Corneal Incision

• Tips angled 45° to handle • Flat handle, overall length 120mm

10mm 1.5mm 0.9mm 10mm 1.5mm 0.9mm 10mm 1.5mm 0.9mm 10mm 1.5mm 0.9mm T

• Tiips angled 45° to handlel

l d h dl

Video available on website duckworth-and-kent.com/media

2-2-716G-7

2-2-716G-7R

2-2-716G-7S

(20)

Calladine-Inamura Short Flat Handle Capsulorhexis Forceps, Scleral Tunnel Incision

• Marks on shaft at 2.5mm and 5mm denote desired size of capsulorhexis • Tips angled 45° to handle

Calladine-Inamura Round Handle Capsulorhexis Forceps, Scleral Tunnel Incision

Calladine-Inamura Short Round Handle Capsulorhexis Forceps, Scleral Tunnel Incision

• Short round handle, overall length 92mm

Calladine-Inamura Flat Handle Capsulorhexis Forceps, Corneal Incision

• Flat handle, overall length 119mm • Pointed serrated interlocking tips

Calladine-Inamura Flat Handle Capsulorhexis Forceps, Scleral Tunnel Incision

• Flat handle, overall length 120mm Consistent capsulorhexis size is crucial for optimal IOL function.

Utilising the smooth action of the Inamura cross action capsulorhexis forceps, the new Calladine Inamura Capsulorhexis Forceps incorporate a visible scale engraved at the functional end of the tips that denotes the desired diameter and radius of the capsulorhexis. The surgeon can repeatedly measure the size of the capsulorhexis using the forceps within the anterior chamber. It has been found that measuring on the cornea surface overestimates the actual size of the capsulorhexis when measured within the anterior chamber by up to 20%.

Scale at tips enables the sur-geon to visualise the desired

rhexis size just prior to and validate just after its creation.

Measuring on the cornea surface can overestimate the actual size of the cap-sulorhexis by up to 20% 2.5mm 5mm 11mm 1.5mm 0.9mm 2.5mm 5mm 11mm 1.5mm 0.9mm 2.5mm 5mm 11mm 1.5mm 0.9mm 2.5mm 5mm 11mm 1.5mm 0.9mm 2.5mm 5mm 10mm 1.5mm 0.9mm • M

• Markarks os on sn shafhaft at at 2t 22.5m5 m aandnd n 5mm55mmdedenotnote de ddesiesiredredsisize zeofof cacapsullorhorhexiexiss

rks oon shaft at at 2t 2.5m5 m and5mmdenote desired sizeofcapsulorhexis

Capsulorhexis, Calladine Inamura Cross Action

2-2-716G-8

2-2-716G-8S

2-2-716G-8R

2-2-716G-8RS

(21)

• Pointed serrated interlocking tips • Curved shaft, tip to pivot point 11mm • Marks on shaft every 1mm from tip to 6mm

Jones - Inamura Round Handle Capsulorhexis Forceps, Suitable For Scleral Tunnel Incision

Accurate capsulorhexis size is crucial for optimal IOL function. Dr Jones has utilised the Inamura cross action capsulorhexis forceps by adding an engraved scale from the tip to 6.0mm along the shaft. The scale is in 1.0mm increments and enables the surgeon to repeatedly measure the size of the capsulorhexis using the forceps within the anterior chamber. Measuring on the cornea surface overestimates the actual size of the capsulorhexis when measured within the anterior chamber.

• Pointed serrated interlocking tips • Curved shaft, tip to pivot point 11mm • Marks on shaft every 1mm from tip to 6mm

Jones - Inamura Flat Handle Capsulorhexis Forceps, Suitable For Scleral Tunnel Incision

Accurate capsulorhexis size is crucial for optimal IOL function. Dr Jones has utilised the Inamura cross action capsulorhexis forceps by adding an engraved scale from the tip to 6.0mm along the shaft. The scale is in 1.0mm increments and enables the surgeon to repeatedly measure the size of the capsulorhexis using the forceps within the anterior chamber. Measuring on the cornea surface overestimates the actual size of the capsulorhexis when measured within the anterior chamber.

Calladine-Inamura Short Round Handle Capsulorhexis Forceps, Corneal

• Short round handle, overall length 91mm • Pointed serrated interlocking tips

Calladine-Inamura Short Flat Handle Capsulorhexis Forceps, Corneal Incision

Calladine-Inamura Round Handle Capsulorhexis Forceps, Corneal Incision

2.5mm 5mm 10mm 1.5mm 0.9mm 2.5mm 5mm 10mm 1.5mm 0.9mm 2.5mm 5mm 10mm 1.5mm 0.9mm 0.9mm 1mm 6mm 11mm 1.5mm 0.9mm 1mm 6mm 11mm 1.5mm

2-2-716G-9S

2-2-716G-9R

2-2-716G-9RS

Capsulorhexis, Jones Inamura Cross Action

2-2-716G-10

(22)

• Sharp pointed serrated tips

• Cross action tips, 1.2mm width at pivot box • Curved shaft, tip to pivot point 8.5mm

Inamura Flat Handle Capsulorhexis Forceps, Corneal Incision

• Marks on shaft 2.5mm and 5mm denote desired size of capsulorhexis • Tips angled 45° to handle

Inamura Round Handle Capsulorhexis Forceps, Corneal Incision

Designed to fi t comfortably through any incision down to 1.5mm. Precise interlocking serrated tips with a sharp point enable the surgeon to initiate the capsule tear then securely grasp the capsule to perform the capsulorhexis. Designed specifi cally for corneal placed incisions, tip to pivot length reduced to 8.5mm. Keeping the pivot in the incision reduces the leakage from the anterior chamber, it also enables the tips to operate fully at the smaller incision sizes without stretching the incision and causing corneal deformation. Accurate capsulorhexis size is crucial for optimal IOL function. The new Inamura cross action capsulorhexis forceps have an engraved scale from the tip to 2.5mm and 5.0mm along the shaft. The scale enables the surgeon to repeatedly measure the size of the capsulorhexis using the forceps within the anterior chamber. Measuring on the cornea surface overestimates the actual size of the capsulorhexis when measured within the anterior chamber.

Original Capsulorhexis Forceps New Capsulorhexis Forceps

10.0mm 8.5mm 2.5mm 5mm 8.5mm 1.2mm 0.9mm 2.5mm 5mm 8.5mm 1.2mm 0.9mm

Capsulorhexis, New Inamura Cross Action

2-716GN

2-716GNR8

2-716GN-2

2-716GN-3

• Extra sharp pointed serrated tips angled 80° from shaft • Cross action tips, 1.2mm width at pivot box

• Curved shaft, tip to pivot point 8.5mm

Inamura Flat Handle Capsulorhexis Forceps, Corneal Incision

• Marks on shaft 2.5mm and 5mm denote desired size of capsulorhexis • Flat handle, overall length 111mm

2.5mm

5mm

8.5mm

1.2mm 0.9mm

• Sharp pointed serrated tips angled 45° from shaft • Cross action tips, 1.2mm width at pivot box • Curved shaft, tip to pivot point 9.5mm

Inamura Flat Handle Capsulorhexis Forceps, Corneal Incision

• Marks on shaft 2.5mm and 5mm denote desired size of capsulorhexis • Flat handle, overall length 111.5mm

2.5mm 5mm

9.5mm

1.2mm 0.9mm

(23)

• Serrated tips

• Curved shafts, tip to curve length 14mm • 1.5mm diameter shaft at cross junction • Flat cross action handle, length 105mm

Inamura Capsulorhexis Forceps, Scleral Tunnel Incision; Serrated Tips Designed To Interlock

• Curved shafts, tip to curve length 13mm • 1.5mm diameter shaft at cross junction • Flat cross action handle, length 104.5mm

Inamura Capsulorhexis Forceps, Corneal Incision

• Iris stop platforms 8.5mm from tips • Curved shafts, tip to curve length 13mm • Barrett balanced set handle, length 120mm • Distinctive identifi cation labelling

Barrett Capsulorhexis Forceps, Corneal Incision

Cross section of jaws are fl attened vertically providing a rectangular cross section which strengthens forceps in horizontal plane, minimizes incision gape and loss of viscoelastic during capsulorhexis. Jaws maintain consistent alignment of tips.

Inamura Capsulorhexis Forceps, Scleral Tunnel Incision

Cross point of instrument is in corneal or scleral tunnel while performing capsulorhexis so it does not gape wound. Prevents leakage of viscoelastic from anterior chamber.

mm

Inamura Round Handle Capsulorhexis Forceps, Corneal Incision

• Extra Sharp pointed serrated tips angled 90° from shaft • Cross action tips, 1.2mm width at pivot box

• Curved shaft, tip to pivot point 8.5mm

Inamura Round Handle Capsulorhexis Forceps, Corneal Incision

• Marks on shaft 2.5mm and 5mm denote desired size of capsulorhexis • Shaft angled 45° to handle

2.5mm 5mm 8.5mm 1.2mm 0.9mm 2.5mm 5mm 8.5mm 1.2mm 0.9mm

2-716GNR8-1

2-716GNR8-2

Capsulorhexis, Inamura Cross Action

2-711

2-716

2-716-2

(24)

2-716G-2

• Fine pointed tips with platforms • 0.9mm tip opening

• Curved 22 gauge tube

DK Squeeze handle Capsulorhexis Forceps

• Squeeze action activates both jaws • Round squeeze handle, length 118.5mm • Serrated tips

• Curved shafts, tip to curve length 13mm • 1.5mm diameter shaft at cross junction • Flat cross action handle, length 104.5mm

Inamura Capsulorhexis Forceps, Corneal Incision; Serrated Tips Designed To Interlock

Inamura Capsulorhexis Forceps, Scleral Tunnel Incision; Serrated Tips Designed To Interlock

2-716G-5

Small Incision Capsulorhexis

2-847

DK Squeeze handle Capsulorhexis Forceps

• 2mm Utrata style tips

• 22 gauge, 16.5mm long curved shaft • Squeeze action activates both jaws • Round squeeze handle, length 126mm

2-847-1

DK Squeeze handle Capsulorhexis Forceps

• 1.5mm fi ne Utrata style tips • 22 gauge, 16.5mm long curved shaft • Squeeze action activates both jaws • Round squeeze handle, length 124mm

vedd shaft

2-847-2

Panzardi Squeeze Handle Capsulorhexis Forceps

• 1mm smooth tips

• Improved visibility with fi ner upper jaw • Squeeze action activates lower jaw • 22 gauge, 16mm long curved shaft • Round squeeze handle, length 125mm

2-847-4

(25)

• Tapered, smooth tips

• 30° angled shafts, tip to angle length 10.5mm • Standard cross action handle, length 105mm

DK Beaupre Cilia Forceps

• Tapered, smooth oval tips

• 30° angled shafts, tip to angle length 10.5mm • Standard cross action handle, length 105mm

Otaka Cilia Forceps

Oval shape of jaws reduce contact area with cilia therefore cilia fall away when removed

• 30° angled shafts, tip to angle length 11.5mm • New round cross action handle, length 115mm

DK Round Handle Cilia Forceps

• 8.5mm medium angled jaws

• 30° angled shafts, tip to angle length 8.5mm • Round handle, length 107mm

KY Cilia Forceps

• 30° angled shafts, tip to angle length 7mm • Short ridged handle, length 85mm • Single piece construction

DK Cilia Forceps

• Tapered, smooth tips with blunt end • 30° angled shaft, tip to angle length 7mm • Short ridged handle, length 84mm • Single piece construction

DK Cilia Forceps

Cilia / Epilation

2-195

2-195-1

2-195NR8

2-196

2-2195

2-2195-1

(26)

• 30° angled fl at face of tips, tip width 2.5mm • 4.5mm platforms

• Straight shaft

• Short ridged handle, length 85mm • Single piece construction

DK Straight Cilia Forceps

• 11.5mm x 17.5mm inside oval circular working diameter upper plate • 14mm x 20mm diameter lower plate

• Polished fi nish lower plate

• Standard handle, locking thumb screw, length 88mm

DK Desmarres Chalazion Forceps / Clamp

• Length 91mm

• Exposure of the surgical site using chalazion clamp principles • Externalised suturing facilitated by absence of base plate • Ambidextrous - clamp can be used on right & left eyelids • Anatomical opposition is overcome

- marginal artery-clamping ensures haemostasis

- canalicular apparatus-calibrated shaft protects canaliculus

• Non slip teeth ensure the clamp does not move during the procedure • The millimeter scale allows the surgeon to work well away from the canaliculus

• The open loop on the bottom of the clamp allows quick release of the clamp when an externalised suture is used

• The clamp incorporates a ‘Canalicular/lid margin friendly curve’ which reduces the lid crush seen when Chalazion clamps are used.

Mulhern E-Z Clamp for Medial Ectropion

n

ngg diameter upper plate

p

opion

• Textured underside of tips (area marked xxxxx) to avoid slip • 30° angled shaft, tip to angle length 7mm

Kobayashi Cilia Forceps

• 10° angled fl at face of tips, tip width 1.25mm • Straight shaft

DK Straight Cilia Forceps

xxxxxxx

2-2195-2

2-2196

2-2197

Clamps

2-640

2-641

(27)

• Holds conjunctiva securely

• Particularly during fornix based conjunctival incisions • Single handed action

• Holds and protects the conjunctival edge during antimetabolite application • Tip width 12mm

• Overall length 74.5mm

Khaw Large Conjunctival Clamp

• 8.5 mm serrated cross action jaws • Length 46mm

Bulldog Clip

• 14mm serrated cross action jaws • Length 82mm

• Distinctive identifi cation labelling

Barrett LeClip Utility Clamp

Replaces need for a mosquito or artery forces. Holds sutures to drape without piercing plastic drapes. • 6.5mm wide highly polished tips

• Length 73mm

DK Conjunctival Clamp

Designed to hold and protect ‘free’ edge of conjunctival fl ap created in trabeculectomy.

Khaw Small Conjunctival Clamp

• Clamp length 25mm

• Plate dimensions 31mm x 17mm • Flat handle, length 103mm

• Non-refl ective fi nish, textured surface upper top face

Rabkin Lid Clamp

For upper eyelid fi xation and globe protection in carbon dioxide laser upper lid blepharoplasty.

pfacceceeee

2-645

2-685

2-686

2-687

6-800

6-805

• 0.12mm, 1 x 2 teeth, tip length 2mm • 6mm tying platforms

• Colibri style shafts • Flat handle, length 87.5mm

DK Troutman Barraquer Colibri Forceps, 0.12mm

Colibri, 0.12 Toothed

(28)

• Colibri style shafts • Flat handle, length 83mm

Colibri Toothed Forceps, 0.12mm

• Colibri style shafts

• Dolphin handle, length 93mm

DK Troutman Barraquer Colibri Forceps, 0.12mm

• 10mm diameter round handle, length 83mm

Colibri Toothed Forceps, 0.12mm

• Flat long handle, length 115mm

DK Colibri Forceps, 0.12mm

• Long fl at handle, length 114mm

2-132N

2-132D

2-132NR

2-132NR8

2-132-3N

2-135

2-135N

• Long round handle, length 114mm

(29)

• Long 8mm diameter round handle, length 114mm

Colibri Toothed Forceps, 0.12mm

• 0.12mm, 1 x 2 teeth, tip length 2.5mm • 6mm tying platforms

DK Colibri Forceps, 0.12mm

• 0.12mm, 1 x 2 teeth, tip length 1.5mm • 4.5mm tying platforms

• Micro fl at handle, length 78mm

DK Troutman Barraquer Colibri Forceps, 0.12mm

• 0.12mm, 1 x 2 teeth, tip length 0.8mm • 4.5mm tying platforms

DK Troutman Barraquer Colibri Forceps, 0.12mm

Colibri Toothed Forceps , 0.2mm

• 0.2mm, 1 x 2 teeth • Tip length 1.5mm

• 4.5mm highly textured tying platforms • Colibri style shafts

• Micro fl at handle, length 76.5mm

DK Troutman Barraquer Colibri Forceps , 0.2mm

Colibri, 0.2 Toothed

2-135NR8

2-138D

2-214

2-215

2-2-445

• 0.12mm, 1x2 interlocking teeth • 6mm tying platforms

• Colibri style shafts, tip length 2mm • Coloured gold

• Round handle, length 118mm

DK Colibri Toothed Forceps 0.12mm

2-2-445S

2-132-2N

2-214-2

• 0.12mm, 1x2 interlocking teeth • 6mm tying platforms

• Colibri style shafts, tip length 2mm • Coloured gold

(30)

• Pierse 0.25mm notched, tip length 2mm • 6mm tying platforms

• Colibri style shafts • Flat handle, length 87.5mm

DK Pierse Notched Colibri Forceps, 0.25mm

Colibri Notched Forceps, 0.25mm

DK Pierse Notched Colibri Forceps, 0.25mm

• 6mm tying platforms • Colibri style shafts • Flat handle, length 114mm

Colibri Tying Forceps

• Plain tips without tying platform • 60° Angle to Shaft, Tip Length 2mm • Colibri style shafts

• Flat handle, length 87.5mm

DK Plain Tip Colibri Forceps

• 1mm ring tips • Straight shafts

Allows atraumatic fi rm grasp of conjunctival

Osher Conjunctival Forceps

Colibri, Notched

Colibri, Tying

2-130

2-130N

2-130D

2-137N

Colibri, Plain

2-910

Conjunctival

2-167

(31)

• 6 equally spaced cups over 4.5mm • Slightly curved shafts

• Barrett balance set handle, length 120mm • Distinctive identifi cation labelling

Barrett Conjunctival Forceps

Designed with series of small cusps to avoid crushing conjunctiva while holding tissue securely.

• 6mm tying platforms • Serrated tips • Straight shafts

Chihara Straight Conjunctival Forceps

• 6mm tying platforms • Serrated tips • Straight shafts

• Flat handle, length 84mm

Chihara Straight Conjunctival Forceps

• 6mm tying platform • Serrated tips • Straight shafts

• 6mm tying platforms • Serrated tips • Curved shafts

Chihara Curved Conjunctival Forceps

• 5mm highly polished tying platforms

• For massaging and adjusting intraocular pressure to desired level • Adjustable Suture Control technique

• Straight shafts

Khaw Transconjunctival Adjustable Suture Control Forceps

2-182

2-500-4

2-500-4N

2-500-4NR8

2-501-2

2-501-2N

2-501-2NR8

2-502N

(32)

• Textured tips

• Grooved channel along platform length, stopping just before tip • Straight shafts

Otaka Conjunctival Forceps

Features:

Can be used for pterygium surgery

Grooved channel down centre of platform helps reduce the amount of dried blood on tips Also used for tying 8-0 suture with its lateral platform

Chihara Straight Conjunctival Forceps

• 6mm tying platform • Serrated tips • Curved shafts

Chihara Curved Conjunctival Forceps

• 6mm tying platform • Serrated tips • Curved shafts

• 6.5mm wide highly polished tips • Length 73mm

DK Conjunctival Clamp

Designed to hold and protect ‘free’ edge of conjunctival fl ap created in trabeculectomy.

2-2-502S

• 5mm highly polished tying platforms

• For massaging and adjusting intraocular pressure to desired level • Adjustable Suture Control technique

• Straight shafts

Khaw Transconjunctival Adjustable Suture Control Forceps

2-503

2-504-4N

2-504-4NR

2-504-4NR8

2-505-4N

2-505-4NR8

2-685

(33)

• Holds and protects the conjunctival edge during antimetabolite application • Particularly during fornix based conjunctival incisions

• Single handed action • Tip width 12mm • Overall length 74.5mm

Khaw Large Conjunctival Clamp

• 0.12mm, 1 x 2 teeth, 2 point fi xation, 1mm separated • Colibri style shafts

• Pierse 0.25mm notched, 2 point fi xation, 0.5mm separated • Colibri style shafts

Bates Corneal Graft Notched Forceps, 0.25mm

• 0.12mm, 1 x 2 Teeth, Tip Length 2mm • 20° angled shafts, tying platforms, 10mm • Miniature cross action Colibri style shafts • Round Cross Action Handle, Length 127mm

Maumenee Corneal Forceps, 0.12mm

• Serrated interlocking tips • Tip to pivot point 10mm • 1.5mm width at pivot box

Galindez DSEK Forceps

• Direct relationship between tip movement and handle movement • Tips angled 45° to handle

• Flat handle with cross action tips, length 118mm

The Galindez DSEK forceps have been designed to assist in DSEK procedures. The forceps is used to peel off the De-scemet membrane once it has been scored with the reverse sinskey hook. The forceps can also be used in removing DSEK buttons that have failed. The procedure is similar to and becomes as easy as performing a capsulorhexis.

• Two 1.75mm textured grasping platforms • 5.0mm gap between platforms

• 40° angled tips, tip to angle length 13mm • Round handle, length 115mm

Daya Donor Disc Forceps

The forceps are used to grasp the folded donor disc. The two textured platforms hold the tissue at the edge and the space between prevents the tissue from being crushed protecting the endothelium.

mmm

0.12mm

Theh Gallindez DSEK forceps hhave been designed to assist

Khaw Small Conjunctival Clamp

2-686

Corneal

2-687

2-170

DK Double Fixation Colibri Forceps

2-171

2-185

2-2-787

(34)

• Blades closed at rest and tips open when forceps are squeezed • Tip end to pivot box length 11mm

• 40° angled shafts

• Reverse action style handle, length 98mm • Forceps tips act as dissecting blades

Daya Lamellar Separator Forceps

• Sharp outer edges to blades • Blades have slight curve

• Width at tip when blades closed 2mm • Height at middle of blades 0.8mm

• Small fl at ring tips

• 45° angled shafts, tip to angle length 4mm • Flat handle, length 84mm

Stein Utility / Flap Lifting Forceps

• Small fl at ring tips, inner tip surfaces lightly textured • 25° angled shafts, tip to angle length 3.5mm • Flat handle, length 85mm

DK Stein Utility Forceps

Designed with shortened, small fl at ring tips for removal of contact lens at slit lamp biomicroscope. Useful contact lens removal following PRK and other refractive surgical procedures.

• 60° angled shafts, tip to angle length 11.5mm • Internal faces of tip are cross hatched • Cross action handle, length 112mm

Kudo Meibomian Gland Pressing Forceps

• 60° angled shafts, tip to angle length 11.5mm • Internal faces of tip are cross hatched • Cross action handle, length 112mm

Kudo Meibomian Gland Pressing Forceps (veterinary)

d Sh d bl d

2-248

• 0.12mm, 1 x 2 teeth, 2 point fi xation, 3mm separated • 37° angled shafts

Bores Corneal Fixation Forceps

2-280

2-795

Flap Lifting

2-798

Gland Pressing

2-635

2-635V

atted

(35)

• Slightly curved tips

• Cross action handle, length 112mm

Shepard IOL Forceps

• Slightly Curved Tips

Kratz IOL Forceps

• 6mm platforms

• 45° angled shafts, tip to angle length 11mm • Cross action handle, length 102mm

Angled jaws in vertical plane facilitate IOL insertion.

Thornton IOL Forceps

• 1mm tips, tip to curve • Slightly curved shafts

Clayman IOL Forceps

• Inside jaws textured, 4mm tip angle • 20° angled shafts, tip to angle length 14mm • Highly polished outer jaws

Deitz ICL Loading Forceps

Extra delicate, long jaws for inserting ICL into barrel of Injector Cartridge.

• Paddle style jaws

• Stops in handle design prevent “over folding” • Flat handle, length 112mm

DK IOL Folding Forceps

Conducive for upward folding. Highly polished inner jaw surface protects from scratching. Designed specifi cally for AcrySof approved by Alcon.

IOL Folding / Insertion / Loading

2-700

2-720

2-725

2-750

2-770N

2-774-1

2-2-774-1

• Paddle style jaws

• Stops in handle design prevent “over folding” • Flat handle, length 114.5mm

Conducive for upward folding. Highly polished inner jaw surface protects from scratching. Designed specifi cally for AcrySof approved by Alcon.

(36)

• Biconvex jaw design, jaw length 10mm • 30° angled shafts

• Tip to angle length 13.5mm • Flat handle, length 118mm

Lens Insertion Forceps, for Acrylic IOL’S

• Smooth fl at fronted 0.12mm, 1 x 2 teeth • 45° curved shafts, tip to curve length 6mm • O’Gawa round handle, length 118.5mm

Enclavation Forceps

• Highly polished curved jaw, length 9mm • Lower jaw tip width 2mm

• Upper jaw tip width 0.73mm • Cross action handle, length 122mm

Implantation Forceps

m

• Tip to angle length 11.5mm • Flat handle, length 116.5mm

Lens Insertion Forceps, for Silicone IOL’S

• Tip to angle length 11.5mm • Flat handle, length 116.5mm

Lens Insertion Forceps, for Acrylic IOL’S

2-782

• Biconvex jaw design

• 30° angled shafts, tip to angle length 11.5mm • Flat handle, length 113.5mm

Osher IOL Insertion Forceps

Designed for inserting silicone IOLs. Hold forceps like a pen and insert IOL by simple supination of wrist.

2-2-782

2-2-782-1

2-2-783-1

2-2-783

2-789-1

Lens Insertion Forceps, for Silicone IOL’S

• Tip to angle length 13.5mm • Flat handle, overall length 118mm • For Silicone IOL’s

(37)

• 4mm serrated tips

For removal of IOL or manual removal of nucleus.

DK IOL / Nucleus Removal Forceps, Serrated Tip

• Small raised disc on inner face of jaw with matting hole • Tips angled at 15°

• Squeeze action handle activates both jaws

Small Incision Manipulating Forceps, Angled Tips

• 20 gauge, 32.5mm long straight shaft • Round squeeze handle, length 138mm Suitable for ICL lens manipulation and Donor Disk manipulation for DSEK

• Jaws curved up and angled right • Tip to angle length 5.5mm

• Cross action handle, length 108.5mm

Lens Positioning Forceps, Angled Right

• Jaws curved up and angled left • Tip to angle length 5.5mm

• Cross action handle, length 108.5mm

Lens Positioning Forceps, Angled Left

• Highly polished curved jaw, length 10mm • Lower jaw off set 0.5mm in front of upper jaw • Tip width 0.65mm

m jaw

2-896-1

2-896

• Small raised disc on inner face of jaw with matting hole • Squeeze action handle activates both jaws

• 20 gauge, 32.5mm long straight shaft • Round squeeze handle, length 138mm

Small Incision Manipulating Forceps

Suitable for ICL lens manipulation and Donor Disk manipulation for DSEK

2-796N

2-789-5

2-789-4

2-789-3

(38)

• Flat tip, 1.9mm wide disc with platform • Tips angled at 10°

• Squeeze action handle activates both jaws

Small Incision ICL Manipulating Forceps, Angled Flat Disc Tips

• Flat tip, 1.9mm wide disc with platform

• Upper disc coloured gold for orientation reference • Tips angled at 15°

Small Incision ICL Manipulating Forceps, Angled Flat Disc Tips

• 20 gauge, 32.5mm long straight shaft • Round squeeze handle, length 138.5mm Designed for delivering ICL lens

• Corresponding gold star on handle, relates to gold tip • Squeeze action handle activates both jaws

• 20 gauge, 32.5mm long straight shaft • Round squeeze handle, length 139mm

2-896-2

2-896-3

• 45° angled shafts, tip to angle length 7mm • Highly polished inner jaw surface • Flat handle, length 108.5mm

DK IOL Forceps

Highly polished inner jaw surface protects from scratching. Designed specifi cally for AcrySof approved by Alcon.

• Front 3.0mm of tip curved down

• 45° angled shafts, tip to angle length 11.5mm • Textured inner jaw surface.

DK IOL Forceps

• For loading AcrySoft IOL into the MONARCH II and III cartridges • Highly polished tips protects from scratching the lens surface • Round handle, length 122mm

DK Lens Loading Forceps

The DK7717 Lens Loading Forceps are used to the load the IOL into the cartridge. To ensure a successful IOL delivery and implantation, proper loading of the IOL into the cartridge is essential.

DK IOL Folding Forceps

Orientation mark for proper load location. Conducive for upward folding. Handle style assures secure grasp. Designed specifi cally for AcrySof approved by Alcon.

• 30° angled shafts, tip to angle length 12mm • Round cross action handle with lock, length 160mm

DK Lens Folding Forceps (with lock)

s

s,tiptiptotoanangleglelelengtngth 1h 12mm2mm

on handle with lock length 160mm

IOL Folding / Insertion / Loading

DK7710

DK7710-2

DK7717

DK7722

DK7723

• 45° angled shafts, tip to angle length 11.5mm • Stops in handle design prevent “over folding” • Flat handle, length 109mm

(39)

• For loading the TECNIS® 1-Piece IOL into the One Series™ Ultra Cartridge • Polished tips protects from scratching the lens surface

• A stop ensures the IOL is not advanced beyond the recommended position in the cartridge • Flat handle, length 113.5mm

Lens Loading Forceps

• 40° angled shafts, tip to angle length 16.0mm

• Highly polished inner jaw surface protects from scratching • Flat handle, length 112mm

• Highly polished inner jaw • Biconvex jaw design

• 40° angled shafts, tip to angle length 7.5mm • Flat handle, length 110mm

DK IOL Insertion Forceps

Highly polished inner jaw surface protects from scratching. Designed specifi cally for AcrySof approved by Alcon.

• Textured inner jaw surface • Biconvex jaw design

• 40° angled shafts, tip to angle length 7.5mm • Flat handle, length 110mm

DK IOL Insertion Forceps

• Biconvex jaw design

• 45° angled shafts, tip to angle length 14.5mm • Textured inner jaw surfaces

DK IOL Insertion Forceps

• Highly polished inner jaw • Biconvex jaw design

• 40° angled shafts, tip to angle length 7.5mm • Flat handle with lock, length 110mm

DK IOL Insertion Forceps (with lock)

Highly polished inner jaw surface protects lens from scratching. Designed specifi cally for AcrySof approved by Alcon.

crratchinging

DK7726-1

DK7735

DK7740

DK7740-1

DK7740-2

DK7741

• For loading the TECNIS® 1-Piece IOL into the One Series™ Ultra Cartridge • Polished tips protects from scratching the lens surface

• A stop ensures the IOL is not advanced beyond the recommended position in the cartridge • Round handle, length 113.5mm

Lens Loading Forceps

The DK7726 Lens Loading Forceps are used to load the AMO TECNIS® 1-Piece IOL into the AMO One Series Ultra Cartridge. To ensure a successful IOL delivery and implantation, correct loading and setting of the IOL into the cartridge is essential.

(40)

• 0.5mm, 1 x 2 teeth

Troutman Superior Rectus Forceps

• Pierse 0.25mm notched, 6mm tying platforms • Straight shafts

Pierse Notched Forceps, 0.25mm Straight

Muscle

Notched / Pierse, 0.25mm

2-160

2-100

2-100N

2-100NR

2-100NR8

2-100D

2-2-100

• Pierse 0.25mm notched tip • 6mm tying platforms • Tip width 0.28mm • Straight shafts • Coloured purple

(41)

• Pierse 0.25mm notched, 6mm tying platforms • Curved shafts

Pierse Notched Forceps, 0.25mm Curved

Pierse Notched Forceps, 0.25mm Straight

• Pierse 0.25mm notched, with no tying platform • Straight shafts

Pierse Notched Forceps, 0.25mm Straight

2-2-100S

• Pierse 0.25mm notched tip • 6mm tying platforms • Tip width 0.28mm • Straight shafts

2-100-2

2-100-2N

• Coloured purple • Flat handle, length 90mm

2-101

2-101N

2-101D

2-103

2-104

m s ms

raight

(42)

Pierse Notched Colibri Forceps, 0.25mm

• Pierse 0.25mm notched, 2 point fi xation, 0.5mm separated • Colibri style shafts

Bates Corneal Graft Notched Forceps, 0.25mm

• Pierse 0.25mm notched, tip length 1.5mm • 4.5mm tying platforms

Pierse Notched Forceps, 0.25mm Straight

• Colibri style shafts • Flat handle, length 87.5

s

2-104N

2-104NR

2-130

2-130N

2-130D

2-171

2-200

(43)

• 8mm diameter round handle • Handle length 115mm

Notched Round Handle Forceps, 0.65mm

2-2-400

• Coloured purple

DK Straight Notched Forceps

2-2-400S

• Coloured purple

DK Straight Notched Forceps

2-2-432

• Pierse 0.25mm notched tip • 6mm tying platforms • Curved shafts • Coloured purple

DK Curved Notched Forceps

Notched / Pierse, 0.3mm

2-100-1

2-100-1N

Notched / Pierse, 0.65mm

(44)

• Tips fully open to 2.5mm

• Flattened tips in vertical plane, tip height 1.6mm • 1.7mm maximum width at incision point • Straight shafts, reverse cross action style • Round handle, length 123mm

Inamura Talon Prechopper Forceps

Video available on website

duckworth-and-kent.com/media r a h s p d e eg g d e t n u l

b _e • Tips fully open to 2.5mm

Salvitti Akahoshi Micro Prechopper Forceps (large tip)

• Tips fully open to 2.5mm • Smooth pointed tips

• 1.7mm maximum width at incision point • Straight shafts, reverse cross action style • Round handle, length 124mm

Akahoshi Prechopper Forceps

blunt edge

sharp edge

Salvitti Akahoshi Micro Prechopper Forceps (small tip)

gh ght 1t 1.3m3mmm

Video available on website duckworth-and-kent.com/media • 0.7mm notched, 6mm tying platforms

• Straight shafts

Atraumatic skin handling forceps utilised in carbon dioxide laser blepharoplasty to minimize ecchymosis.

Rabkin Notched Skin Forceps, 0.7mm

Tip of instrument has pointed sharp front edges that initially penetrates nucleus; squeeze forceps, tips open to crack and split nucleus. The narrow paddle is easy to insert into denser nucleus.

Ti

Tip of instr ment has poiinted sharp front edgesd thath

Notched / Pierse, 0.7mm

2-106

Nucleus Cracking and Prechopping

2-2-815

2-2-817

2-2-817-1

Designed to crack nucleus into four segments with minimal stretching of incision. Forceps shafts open to a maximum of 1.7mm at incision point. Tips open to 2.5mm. Tip of instrument has a sharp point that initally penetrates nucleus; squeeze forceps, tips open to crack and split nucleus. By fl ipping forceps over, blunt edge may be used to go deeper in initial split to fully split nucleus. Using blunt edge of tip reduces risk of damaging posterior capsule.

2-2-818

2-2-819

• Arrow tip shape for penetrating nucleus

• Flattened paddle area of tips for nucleus splitting, tip height 1mm • 1.7mm maximum width at incision point

• Straight shafts, reverse cross action style • Round handle, length 123mm
