The future of middleware: enterprise application integration and Fuse

The future of middleware:

enterprise application

integration and Fuse

Giuseppe Brindisi

Agenda

● Build an enterprise application integration platform that is:

● Resilient

● Maintainable

● Flexible

What is EIP?

• Work by Hohpe / Woolf

• Became a de facto standard • speak the same language

• reuse of know how and solutions • Avoid custom code for integrations

Enterprise Integration Patterns

What's JBOSS Fuse?

• An integration Middleware built on:

• JBoss AMQ (ActiveMQ) for messaging • Camel for mediations (routes)

• CXF for Web Services

• Fabric for governance (registry, provisioning)

What is OSGI?

• A standard for a “Modular” Java

• how to “pack” code in a bundle (jar)

• OSGi bundles can be remotely installed, started, stopped, paused, updated and more (Lifecycle Management)

• OSGi = SOA in a JVM

• First version in 2000, coming from the telco world.

What is Camel?

• Framework Open source implementing EIP patterns

• mapping 1:1 between pattern and components

• camel routes managed through OSGI • OSGI Container

What is ZooKeeper?

• Part of the Hadoop ecosystem

• Used to build coordination logics

• Sharding, Failover, Discovery, Master election, ecc.

MAVEN

• Maven is the “de facto” standard in Java dependency management

• Nexus (Artifactory) is a centralized Maven repo that makes “Devops” easy

• controls dependencies

• a server contains each and every project artifact

What is KARAF?

• Lightweight container for OSGI

• Hot deploy, logging, shell, configuration, provisioning services

What is ACTIVE-MQ?

• Open Source Messaging Broker

• JMS, AMQP, MQTT, OpenWire, STOMP, REST • Java, C, C++, C#, Ruby, Perl, Python, PHP

• Pluggable Transport

What is CXF?

• De facto open source standard for Web Services

• Used in JBoss too • WS-*, REST support • …

What is Fabric?

• Allocate Resources, Install & Connect containers in your environment

• Publish Services, Discover & Coordinate • Manage

• Provision • Visualize

• Scale Up / Down • and much more…

What is Fabric?

• Introduced with Fuse technology • But now an independent project

• http://fabric8.io

• It is now (will be) cross product (Fuse, EAP, Openshift, ecc.)

What is Fabric?

• configurations, scripts, code (aggregated in profiles)

• On every kind of container

• Karaf, Wildfly, Tomcat, plain JVMs • Everywhere

• Openshift, Docker, any public/private IAAS, bare metal, hybrid.

The Console: command line console

• SSH based

• Total local and remote control of the system • Scriptable

Performance - CAMEL

• Camel is a Java technology and doesn’t introduce any overhead

• Performance depends by the Camel components used

• provided components has usually been finely tuned and tested in hundreds of customers

• Camel code is probably much faster than your code ;)

Performance - ActiveMQ

• AMQ persistence File system based

• LevelDB, a nosql developed by Google

• O(1) to load stored messages thanks to the BTree Google algorithm

• 3 or 30.000.000 persistent messages instantaneously “loaded” by a broker.

Performance - ActiveMQ

• LevelDB has excellent write performance

• Disk speed is the single most important factor.

• About 10k msg/sec (5kb) of sustained traffic on a modern laptop with an SSD

• About 4.5k msg/sec (5kb) of sustained traffic on Amazon server (9k msg/sec using both disks)

High Availability and Scalability

• AMQ can be configured in Master - Slave • 1 Slave per 1 Master

• N Slaves per M Masters (example: 2 Slaves per 10 Masters)

• AMQ can scale horizontally with different topologies:

• Network of Brokers

• Client side partitioning HA

Conclusions

• Distributed Architecture • Failover

• Master/Slave for High Availability

• Horizontal Scalability: Network of Brokers, Client side partitioning

• Maintainability

• OSGI based, standardized software component lifecycle (with versioning)

• Powerful admin console • Performance

Links to useful resources

• _Fabric • _Container • _OSGI

• _{Route (Camel)} • _Provisioning • _Versioning • _Maven/Nexus • _GIT • _Queue • _REST/WS • _Zookeeper • _Profiles • _Bundle • _OSGI

• _{EIP, Enterprise}

Integration Patterns • _Aggregator • _Splitter • _CBR • _Enrichment • _Multicast • _Wiretap

Links to useful resources

Karaf

http://karaf.apache.org Fabric8

http://fabric8.io

JBoss FUSE 6.1 EA builds https://repository.jboss.org/ne xus/content/repositories/ea/or g/jboss/fuse/jboss-fuse-full/ Red Hat Supported!

https://www.jboss.org/product s/fuse.html Active MQ http://activemq.apache.org Camel https://camel.apache.org CXF http://cxf.apache.org ZooKeeper http://zookeeper.apache.org

Ask questons or rate the Speaker

Software Development Process

• Integration requisite

• If tag A contained in Message M has in

corresponding record in table B the X field • Trasform M (remove t1 tag, add X tag) • Add tag t3 to Message M in any case

Software Development Process

“Translation” in Enterprise Integration Patterns

Software Development Process

• Transform EIP in code • using a DSL in Java • using a DSL in XML

Software Development Process

• Bundle in an OSGI component

• mvn install

• Push on Maven/Nexus repo

Software Development Process

• With CLI console or Web Console, and following Roll-out company plan, pull the bundle from the repository

• Selected containers will download and start automatically the bundle

Software Development Process

• create a new route implementing business • pack the route in a bundle and “assign” to a

new version of a profile

• upgrade one of more containers to this profile to check everything is ok

Software Development Process

• Open the web console on a production server
