The Convenient and Compact CR
System for Veterinary Practices
Fire CR+ 20 / 40 / 60 / 80 vet with a throughput of 20 to 70
The small and fast CR system for digital
X-Ray imaging in veterinary medicine
The
Fire
CR
+
vet system is suitable for examinations with imaging plates both
in small veterinary practices requiring only a few images per day as well as
veterinary clinics dealing with large number of patients.
Robust, compact, light weight and fast: in combination with the professional
dicomPACS
®DX-R
image acquisition software, the CR system provides all the
necessary image processing functions. The
Fire
CR
+
solution may be
integrated into existing DR or DR systems and is therefore ideal as a second
or additional system for high workloads in large clinics or university facilities.
The
dicomPACS
®DX-R
software in particular allows quick and easy working.
Special emphasis was placed on maximum image quality and maximum
flexibility. For example, the included professional image processing software
dicomPACS
®DX-R
can be adapted very easily to the veterinarians specific
wishes or requirements for each x-ray examination. The user is not limited to
the selection of “pre-set” standards. The functionality provides the best
possible image quality in accordance with the veterinarians needs.
The creation of the best possible images, however, also
requires the correct set up of the x-ray unit and the correct
positioning of the patient. To help the x-ray assistant with
this task, a multimedia radiographic positioning guide for
each examination has been integrated directly into the
system. It allows the user to verify, prior to taking the x-ray,
how to correctly set up the x-ray image. Even videos on the
positioning of a patient etc are included. This guide removes
the need for radiographers to consult tables, reference
books or external software programs.
F
ir
e
C
R
+
2
0
/4
0
/6
0
/8
0
V
e
t
Highlights
All the benefits of the
Fire
CR
+
Vet at a glance
• Lightweight: only weighs approx. 30kg.
• Unventilated unit: silent in standby mode, does not attract dust, animal hair etc. • Robust: yet compact (dimensions: 11.7 x 46.4 x 70.3cm).
• High throughput: up to 70 cassettes per hour.
• Multiple formats available: 24 x 30cm and 35 x 43cm.
• Flexible use: as a compact stationary table system or a portable system. • Optional: wall mount to save space.
• Easy to upgrade: cassette throughput can be easily increased without having to exchange equipment.
• Simple conversion to a DR system: customers can continue to use the same operating software - investment protection!
• Convenient transport: in a suitcase with wheels and a pull-out handle. • Easy to operate.
The FireCR+ Vet system is available in different versions
FireCR+ CR20 vet: up to 20 plates / hour FireCR+ CR40 vet: up to 40 plates / hour FireCR+ CR60 vet: up to 60 plates / hour FireCR+ CR80 vet: up to 70 plates / hour
Only About
Flexibility
Place the unit in the perfect position!
1. Standard table Unit
2. Wall mounting as a space saving solution (optional)
Software
Advantages of the professional
dicomPACS
®DX-R
X-Ray
acquisition software:
• Modern graphical user interface (GUI) adaptable to almost any language.
• Touchscreen operation – to ensure quick and efficient work and a smooth workflow. • Capture of patient data via DICOM worklist, BDT/GDT, or other protocols – data may also
be captured manually.
• Use of DICOM Procedure Codes for the transfer of all relevant examination data directly from the connected patient management system (HIS/RIS).
• Freely configurable body parts with more than 200 projections and numerous possible adjustments in human and veterinary medicine already included.
• Safe and fast registration of emergency patients.
• Allows the user to switch between examinations of a patient, for instance to avoid having to re-position the patient frequently.
• Special tool for veterinary medicine, such as an extra dialog box for patient and owner data, integrated hip dysplasia measuring, special image filters, TPLO, TTA, Buchanan’s Vertebral Heart Score, distraction index, multi generator operation for alternating between mobile and stationary systems and much more…
• Entry of recurring examination procedures as macros.
• Fully integrated radiographic positioning guide for each examination including comprehensive notes, photos and correct x-ray images.
• A single workstation with installed dicomPACS®DX-R software may be upgraded by the following options (selection):
• Direct control of the x-ray generator (generator control). • Tools for taking images of an entire leg or a full spine
(image stitching).
• Planning and working with digital prostheses templates/
operation planning.
• Connection of several diagnostic monitors.
• Capture of additional patient and examination data and
their freely configurable statistical evaluation. • Facilitates the use of a flat panel and an intraoral sensor.
In
clu
de
d
Job creation Radiographic positioning guide
Preview of the X-Ray image and worklist Viewer
TTA measuring tool Buchanan’s Vertebral Heart Score
Software
Advantages of the professional
dicomPACS
®DX-R
X-Ray acquisition software
CR Unit
Performance: FireCR+ CR20 vet: up to 20 plates / hour (for 35 x 43cm / 14 x 17”) FireCR+ CR40 vet: up to 40 plates / hour
FireCR+ CR60 vet: up to 60 plates / hour
FireCR+ CR80 vet: up to 70 plates / hour System configuration: Top-table
Time until the first image: 49 seconds
Resolution: Data capture: 16-bits per pixel, 65,000 graytones Weight: 30kg (65lbs)
Dimensions (H x W x D): 4.6” x 18.3” x 27.7” (117 x 464 x 703mm) Power requirements: 110/220/240V, 60/50cs, 150W
PC connection: USB 2.0
Regulatory approvals: FCC, UL and CE
dicomPACS®DX-R control Console
Operating console (two options available), MS Windows 7 Professional, hardware stress test, software pre-installation, system checked and ready to use
Option 1: Archive and diagnostic station* Option 2: Notebook* Intel® Core Processor Intel® Core Processor 4GB RAM DDR 4GB RAM DDR 2 x 500GB hard drive (RAID1) 500GB hard drive
DVD+/-RW drive 1920 x 1080 pixel resolution 1000 Mbit network DVD+/-RW drive
1000 Mbit network
Wireless LAN 802.11 a/b/g/n
Suitcase
The FireCR+ requires very little space and is therefore also suitable for mobile use. Easy to set up and well padded in a sturdy suitcase, it is ideal for vehicle transport and mobile use, e.g. in horse stables. The transport suitcase is equipped with wheels and a pull-out handle.
dicomPACS
®DX-R
acquisition and diagnostic software
• dicomPACS®DX-R is an acquisition, diagnostic
and archiving software including an integrated professional PACS viewer with image editing,
measuring and export options, image printing, freely configurable user interface and much more.
• Operation via touch screen.
• More than 200 integrated X-Ray settings.
• Integrated multimedia radiographic positioning guide
for each examination including photos, videos and examples of correct X-Ray images.
• Capturing of macros for recurring examination
processes.
• Option to display the recommended X-Ray settings for
each examination (kVp, mA, mAs etc.) in accordance with the generator used.
• Extensive image processing can be adapted to the
customer’s individual requirements for each examination (CoP).
• Automatic black mask functionally. • Querying a DICOM Worklist (SCU). • Backup module.
• Automatic removal of grid lines when fixed grids are
used.
• Creation of patient CDs.
• Direct connection of other
viewing stations with miniPACS function.
Many other functions are available as options:
• Image transfer to PACS
system (DICOM store).
• X-ray generator control. • DICOM Basic Print. • Digital X-ray journal. • Integration of several
diagnostic evaluation monitors.
• Image stitching (tool for
generating full leg/full spine images).
• Pre-operative planning
with prosthesis documentation module.
• Wall mounting for CR unit. • System upgradable to a
networked image management system (PACS).
Image processing
Automatic image processing for optimal quality
• Perfect images at all times—generally no adjustment required. • Integrated software for automatic image optimisation.
• Professional, adaptable image processing for each individual examination to obtain best possible image settings for the needs of each customer.
• Due to specially developed processors, the image processing allows the user to vary the
X-Ray setting on a large scale while the image quality remains virtually the same (possibility of reducing the dosage).
• Bones and soft tissue in one image - this enables the user to significantly improve his diagnosis.
• Details of bones and microstructures are very easy to recognise. • Noise suppression.
• Black mask (automatic shutters). • Cropping of images (crop function).
• Automatic removal of grid lines when using fixed grids.
Exposure with standard image processing
Exposure with dicomPACS®
Built-In Flexibility!
The dicomPACS®DX-R software already includes all functions necessary to store X-Ray images and provide them to other workstations as a standard feature. Other workstations in your practices network may load these images directly and display them. This requires just one “dicomPACS® Diagnostic Module Standard” (optional extra) per workstation. Of course, the images can also be sent to an existing PACS system.
Investment Protection:
If you wish to create your X-Ray images with a flat panel system (DR= Direct Radiography) at a later stage, you only have to exchange the FireCR+ CR system for a flat panel, dicomPACS®DX-R is already designed to implement such a connection. You will not need to purchase new software or to get used to a new user interface.
