Development brings

opportunities

The elderly population is increasing all the time – and there

are increasing demands for quality, safety and flexibility. We

think this is a good thing. Choice is important, as different

needs require different solutions. At the same time there is

rapid development of medical devices. This also increases the

possibilities for satisfying the wishes of our customers.

At Human Care we focus firmly on research and development

in order to meet future demands and to offer the best products

on the market – products that lift.

(4)

a lift for the future | overhead lift system

human Care

– for quality of

life anD Dignity

Human Care develops and manufactures innovative functional aids of excellent design,

high quality and flexible function for the day-to-day environment. Our product

range includes overhead lift systems, rollators, convertible chairs and specialist beds.

Around 90 per cent of sales are on markets outside Sweden. In addition to subsidiaries in the USA, Canada and Australia, we have distributors in a further 20 countries, including the UK, the Netherlands, Germany, Czech Republic, Russia and Japan.

Constant improvement

Our solutions aim to increase the dignity and quality of life for elderly people and those with reduced mobility. We strive constantly to become even better at adapting, the better to meet the changing needs of tomorrow’s markets.

Through our commitment to constant improve-ment and utilisation of our global reach, we are looking to strengthen our position as industry leaders in design, innovation, product portfolio and customer service.

Human Care was founded in 1993 and is listed with Mangold Fondkommission AB.

(5)

human Care

– for quality of

life anD Dignity

(6)

We strive for constant improvement and adaptation. Our product development

department offers high flexibility and efficiency. Here we test and develop our

existing range, and create new products with innovative features and details.

All this is so we can offer people with reduced mobility even higher quality,

improved safety and greater freedom in the future.

our r&D work

high quality development and produCtion

Human Care has an in-house development de-partment for overhead lifts in Sweden, which handles day-to-day and future product develop-ment work. Docudevelop-mentation, standard adaptation, quality assurance and product development are some of the tasks undertaken there.

Our global development organisation in Austra-lia, the USA and Hong Kong works closely with customers and suppliers in order to ensure that we develop and manufacture what customers want to the best of our ability. We also have our own production facilities in Sweden, giving us full control, speed, adaptability and guaranteed good quality on delivery. Add to that the high levels of skill and years of experience in overhead lift installation; our personnel ensure these benefits reach our customers in each product.

skilled at Cooperation

Cooperation is a prerequisite for development. At Human Care there is a close working relationship between the departments responsible for purcha-sing, product development, production and qua-lity assurance. External resources and expertise are also used to forge ahead in our development work. We are attentive to market demands and follow relevant standards and directives – national and international.

Thanks to our proximity to our suppliers, we can also offer efficient logistics and excellent warehou-sing.

(7)

high environmental

anD quality targets

When it comes to our environmental and quality work, we aim high.

Not satisfied with what we – according to laws and ordinances – have

to do, we strive constantly to become even better, which brings us a step

closer to moving even further ahead.

for the environment’s sake

The overall environmental work within the group focuses on minimising the effects of our activities and our products on the environment. None of the group’s product areas, overhead lifts or rollators, perform any activities requiring special permits.

our environmental poliCy

Human Care strives to be at the forefront of environmental work in our industry. When we launch a new product, we place great emphasis on the environment when it comes to the com-ponents we use. We work continuously on exten-ding the service life of our products, which helps to protect our natural resources. Human Care will comply with environmental legislation and other environmental requirements, as well as work constantly on improvements and preventive measures by:

• reducing the amount of waste produced and improving our waste management. • streamlining our transport of raw materials and finished products.

• increasing our employees’ knowledge and commitment in day-to-day environmental work.

• striving to reduce our energy usage. • Cooperating with suppliers and customers as well as the authorities with the aim of creating a better environment.

quality improvement

At Human Care we work systematically on quality improvement on all levels, both when it comes to production processes and final products. The company is certified in accordance with SS-EN ISO 9001:2008. All the company’s products are CE-marked and can thus be sold throughout the EU without local quality control in each individual EU country.

However, careful testing is performed internally on a regular basis to ensure that the right pro-duction processes are being applied, and that our products correspond to our own high targets, as well as to satisfy requirements set out by interna-tional authorities.

only rohs-approved produCts

From 2013 the scope of the EU’s RoHS Directive will be expanded to also cover medical devices. RoHS stands for ”restriction of hazardous sub-stances”. The directive forbids or restricts the use of certain hazardous substances in electric and electronic products in order to protect the environment and human health. The directive also aims to promote the use and management of waste containing electric and electronic products in ways that are kind to the environment. All Human Care overhead lifts will be RoHS-approved by January 2014.

(8)

proDuCts that lift

Our range of personal lifting products: overhead lifts,

lifting motors, freestanding gantries, slings, ceiling rail

systems, attachments, pendulums, accessories and services.

Our products are constantly being developed in order

to offer even higher quality, improved safety and greater

freedom.

(9)

(10)

RoomeR 5200

roomer 5200 is a portable lifting motor with a lifting capacity of 220 kg. this solution enables safe and uncomplicated transfer of the patient between different rail systems (room to room). it has an adjustable bar, options for 2-, 3- and 4-point suspen-sion, and soft start and soft stop. see figure 1.

New roomer 5200

• updated for iso 10535:2006 • emergency stop

• improved water protection • drainage and feet

• manual control with splash guard • ul/Csa approved

• all components ul/Csa approved • flame-resistant plastic

Replaces current Roomer 5200

siNgel 5100

singel 5100 is a portable lifting motor with a lifting capacity of 220 kg. it has an adjustable bar, options for 2-, 3- and 4-point suspension, and soft start and soft stop. see figure 2.

New singel 5100

• improved water protection – see figure 7 • drainage and feet – see figure 4

Replaces current Singel 5100

range of portable lifts

(11)

siNgel 4100

singel 4100 is a portable lifting motor with a lifting capacity of 150 kg. it has an adjustable bar, options for 2-, 3- and 4-point suspension, and soft start and soft stop. this product replaces singel 2100. see figure 3.

New singel 4100

• 150 kg

• identical new features to singel 5100, but a diffe-rent maximum load

• iso 10535:2006 • ip X4

• ul/Csa approved

siNgel 5100 HeRkules

singel 5100 herkules is a portable lifting motor with a lifting capacity of 300 kg. this product can be used as a pair, and can then lift 455 kg. herkules has an adjustable bar, options for 2-, 3- and 4-point suspen-sion, and soft start and soft stop. see figure X.

New singel 5100 herkules

Replaces current Singel 5100 HERKULES

4. 3.

7.

5.

(12)

range of lifts

siNgel 5100 satellit

singel 5100 satellit is a rail-mounted lifting motor with a lifting capacity of 300 kg, 2-point suspension, and soft start and soft stop.

New singel 5100 satellit

Replaces current Singel 5100 SATELLIT

stands

Niklas aNd leNa

niklas (see figure 1) is an adjustable freestanding gantry frame, with a maximum user weight of 220 kg, while lena (see figure 2) is a fixed-width freestand-ing frame, with a maximum user weight of 300 kg.

range of slings

We offer a complete range of slings for all needs, for example, hygiene sling, comfort sling, amputation sling, and slings for activities such as walking training, bathing and outdoor activities, plus a sling customi-sing service. our slings are being constantly deve-loped, with new features and details being added all the time. see figure 3 and 4.

1. 2. 4.

(13)

rail systems

human Care supplies a variety of ceiling rail types depending on the customer’s preferences. With one of the most complete rail systems on the market, alongside our existing discreet and well-designed rails, we are able to offer new, flexible and cost-effective rails.

our various rail systems can be easily adapted to the user’s requirements and can be installed irre-spective of the room layout or the building structu-re. the rails are made from white-painted extruded aluminium and are available in different standard lengths and profile types.

the rail systems consist of single rails or traverses which are mounted on ceilings. a single rail system consists of a straight rail, a curve, several straight rails or a combination of straight rails and curves installed in succession. all to achieve a rail system

with the desired appearance and function. if rails longer than our standard are required, two or more rails can be spliced together. this system allows the overhead lift and user to be moved along the rail. our rails can also be wall-mounted or supported with floor-posts.

a traverse system consists of two primary (side) rails and a secondary (traverse) rail, and is used to allow movement along both X and y axes.

Where necessary, the rails can be incorporated into the suspended ceiling. this is possible during instal-lation of ceiling attachments, pendulums or wood ceiling attachments. both single rail and traverse sys-tems can be installed. Covers should ideally be fitted to the end of each rail to improve the appearance of the system.

1.

4.

2. 5.

(14)

1.

4.

2. 3.

all rail profiles are stocked in a variety of standard lengths. our 100 mm ceiling rail is available as cur-ves with angles of 30, 45, 60 and 90 degrees. our 80 mm ceiling rail is available as curves with angles of 45 and 90 degrees.

the 90 degree angle rail is also available with exten-ded ends. the curves are for ceiling installation only and can be spliced with straight rails as required. the profiles are combined to form rail systems of vary-ing sizes, dependvary-ing on the solution required. We also have a complete range of carriages, traverse carriages and intermediate pieces. all products have an attractive appearance that blends in well in most settings.

our New rails

• Ceiling rail 82 mm is available as curves, 60 and 90 degrees

• heights: 82 mm, 110 mm and 180 mm

• faster and more flexible installation with new ceiling attachment

• lower weight

• the same carriages and other parts, etc. can be used

• new traverse carriage

• tested and approved in accordance with iso 10535:2006

• initial straight rail and traverse system • allows complete installation options in all types of buildings

(15)

1.

4. 5.

2. 3.

attaChments

Ceiling attachments are used to mount rails directly on the ceiling. Ceiling attachments are also used in combination with other attachments such as pendulums and wood ceiling attachments. • faster and more flexible installation with our new ceiling attachment

• no drilling in rails

• Compatible with old rail models

pendulums

pendulum attachments are used to eliminate the distance between the concrete ceiling and suspen-ded ceiling when a lowered rail installation is requi-red or the ceiling is very uneven. pendulum model to be selected according to need.

• screw adjustment

• suitable for inner ceilings or uneven ceilings • various lengths: 10-30 cm

• approved in accordance with iso 10535:2006 • Compatible with all rails and attachments

aCCessories

examples of accessories include portable scales, approved for medical use, with capacity to weigh up to 320 kg, a lift trolley for easy and convenient lift transport as well as storage of the lift and accesso-ries, a stretcher that allows horizontal lifting, and a 4-point bar.

serviCes

We also offer services such as project planning, in-stallation, transfer training for users and instructors, architectural services and marketing, including an image bank and reference database.

(16)

Day-to-Day Development

on all levels

Human Care offers innovative and well-designed overhead

lifts of high quality and with flexible function. For us

develop-ment and improvedevelop-ment work are part of our day-to-day

activities – on all levels. Contact us if you want to find out

more about how we are working to meet future demands and

to offer the best products on the market.
