SeMSy® – Security Management System

SeMSy® is a high-performance and future-proof video management system with optimum user friendliness. Even complex video systems, such as those used in casinos, airports, railway stations or for city surveillance, can be efficiently managed and controlled with SeMSy®.

SeMSy® offers a comprehensive range of functions, including the display of live images, various search options within the foot-age, the control of PTZ cameras and an easy archiving of relevant sequences. The video management software is characterised with highest ease of use. The system can be operated easily and intuitively via drag-and-drop. It is also possible to customise the graphic layout of the user interface and adjust it to the requirements of specific projects or operators. SeMSy® can be scaled infinitely.

Features

• Switching of any camera/encoder onto any monitor/decoder, live display and playback

• PTZ cameras can be controlled via the operator station (PTZ control, fixed positions, camera configuration) • Processing of alarm messages

• Group switching (salvos)

• Search functions (time, date, index)

• Integration of site plans for camera selection • Redundant server security concept

Convenient control of complex systems

Operation

The entire system is operated via a professional and highly efficient management system. Operating procedures and complex controls can be stored in the system, so that personnel can conveniently and intuitively operate the system. The graphic user interface provides every user a quick overview of cameras and their corresponding monitors via a graphic display.

Evaluation

The graphic user interface at the control centre allows for the evaluation of recordings. Furthermore, playback can be controlled via an external jog-shuttle (e.g. VMC-1). In addition, recorded data can be exported to CD or DVD at the evaluation station.

Scalable

The SeMSy® system can be expanded and thus remains flexible at any time. For instance, additional cameras/encoders or more monitors/decoders can be integrated into the network at a later date.

Integration of third party systems

The SeMSy® Management System is based on standardised interfaces (e.g. OPC), so that the integration of further systems (dealing shoe, access control, building management, etc.) is easily achieved.

Different software packages are available. They differ regarding the number of channel licences (cameras), operator licences and the already included software modules for the workstations.

SeMSy® Software Packages

• Up to 50 inputs (cameras)

• Server licence for the connection of 2 workstations and dongle for the operation of one workstation • One licence each for SeMSy® III Main Server software, Archive Server software and Setup Server software

• Dedicated hardware for server applications (Main Server, Archive Server, Setup Server, workstation) not necessary (“all-in-one installation”)

• Up to 150 inputs (cameras)

• Server licence for the connection of 5 workstations and dongle for the operation of one workstation • One licence each for SeMSy® III Main Server software, Archive Server software and Setup Server software

• Dedicated hardware for server applications (Main Server, Archive Server, Setup Server, workstation) not necessary (“all-in-one installation”) Basic Module: - Navigator - Mainviewer - Camera Control - Archive Client - Camera Filter - PRemote - Panomera® _Control - Logbook - Navigator - Mainviewer - Camera Control - Archive Client - Camera Filter - PRemote - Panomera® Control - Logbook - Monitorwall - Salvos - Bookmarks - R·Management - Hotkeys Advanced Module:

The SeMSy® III Basic Software Package is particularly suited for use in retail businesses, banks etc.

The SeMSy® III Advanced Software Package is particularly suited for use in smaller casinos, smaller train stations, parkings or small-scale city surveillance etc.

Software Package “Basic”

Software Package “Advanced”

1

2

50

1+1

150

1+4

• Up to 500 inputs (cameras)

• Server licence for the connection of 20 workstations and dongle for the operation of one workstation

• One licence each for SeMSy® III Main Server software, Archive Server software, Setup Server software and PGuard Server software

• Dedicated hardware for server applications (Main Server, Archive Server, Setup Server, workstation) is required

• Unlimited number of inputs (cameras)

• Server licence for the connection of an unlimited number of workstations and dongle for the operation of one workstation

• One licence each for SeMSy® III Main Server software, Archive Server software, Setup Server soft-ware and PGuard Server softsoft-ware

• Dedicated hardware for server applications (Main Server, Archive Server, Setup Server, workstation) is required - Navigator - Mainviewer - Camera Control - Archive Client - Camera Filter - PRemote - Panomera® Control - Logbook - Monitorwall - Salvos - Bookmarks - R·Management - Hotkeys - PGuard - Sequencer - Camera History - Map - Pathfinder - Interfaces Enterprise Module: - Navigator - Mainviewer - Camera Control - Archive Client - Camera Filter - PRemote - Panomera® Control - Logbook - Monitorwall - Salvos - Bookmarks - R·Management - Hotkeys - PGuard - Sequencer - Camera History Professional Module:

The SeMSy® III Professional Software Package is particularly suited for use in stadiums, mines, shopping-malls, conven-tion centres or penal instituconven-tions etc.

The SeMSy® III Enterprise Software Package is particularly suited for large-scale projects, e.g. city surveillance, airports, casino and entertainment complexes or the surveillance of traffic and transport networks.

Software Package “Professional”

Software Package “Enterprise”

3

4

500

1+19

The individual workstation modules in detail



0

Navigator: Clear display and selection of cameras in a camera tree with different symbols for PTZ and fixed

cameras as well as display of status information.

Mainviewer: Module for MPEG2, MPEG4, H264 and MJPEG software decoder. Display in full screen or

different split types, various display and search functionalities for live streams and recorded footage. In-cludes the “SmartFinder” functionality for the intelligent search for movement within a picture.

Camera Control: Control of PTZ cameras (pan, tilt, zoom, camera menu).

Archive Client: Administration of backups, various search criteria, burning of backups on DVD/CD. Is capable

to merge clips from multiple cameras to create a seamless playback of specific events.

WorkstationModules Basic Advanced Professional Enterprise

Navigator Module

_

_

_

_

Mainviewer Module (incl. SmartFinder)

_

_

_

_

Camera Control Module

_

_

_

_

Archive Client Module

_

_

_

_

Camera Filter Module

_

_

_

_

PRemote Module

_

_

_

_

Panomera® _{Control Module}

_

_

_

_

Logbook

_

_

_

_

Monitorwall Module

0







Salvos Module

0







Bookmarks Module

0







Rights Management Module

0







Hotkeys Module

0







PGuard Module

0

0





Sequenzer Module

0

0





Camera History Module

0

0





Map Module

0

0

0



Pathfinder Module

0

0

0



Sequencer: Creation of camera sequences for any decoders/monitors and splits, sequence interval between

1 second and 1 minute.

PGuard: Evaluation and management software for system messages and events.

Camera History: List of the last ten selected cameras.

Map: Integration of site plans into the SeMSy® interface (formats CAD, DWG, JPEG, JPG, BMP, GIF, PNG),

display of status messages of cameras.

Pathfinder: Only in combination with SeMSy® Map. Shows the ten cameras which are closest to the selected

one which creates fast, simple and effective means of following a person or object throughout a facility using multiple cameras.

Interfaces: Integration of external systems (e.g. AngelEyeClient, InfoGenesisClient, MicrosClient, etc.). Camera Filter: Individual adjustment of decoder/monitor filters (brightness, contrast, colour, sharpness,

noise filter, dering, deblock), no modification of the footage.

Panomera® _{Control: Module for display and control of a Panomera® multifocal sensor camera system.}

Monitorwall: Management and configuration of all decoders/monitors available in SeMSy®.

Salvos: Five pre-defined salvo groups, user-defined extension of salvo groups for specific workstations and

user groups.

Bookmarks: Creation of bookmarks either manually via GUI or automatically via camera contact, management

of 16 bookmarks for each camera.

Rights Management: Customised adaptation of rights for each module and each module´s functionality,

e.g. which user group is allowed to see which monitor wall on the workstation.

Hotkeys: Programming of keyboard shortcuts, for the selection of freely configurable functions and actions. PRemote: Possibility to activate PRemote connections on Mainviewer or VarioDecoder, adjustment of

PRemote settings to allow remote control of the system over a WAN or LAN.

Tr ademark s which ar e designa ted b y ® ar e r egister ed tr ademark s o f Dallmeier elec tr onic 02 /2015 V1.2.0 P roduc t specifica tions subjec t t o chang e wi thout notic e. © Dallmeier elec tr onic

Further information to all of our products can be found at:

www.dallmeier.com

Dallmeier electronic GmbH & Co.KG · Cranachweg 1 · D- 93051 Regensburg

Phone +49 (0) 941 87 00-0 · Fax +49 (0) 941 87 00-180 · [email protected]

Application areas

Software Package “Basic”

Retail Bank Petrol station Premises Smaller projects up to 50 cameras.

Software Package “Advanced”

Station Parking Public places Amusement hall Projects up to 150 cameras.

Software Package “Enterprise”

City surveillance Traffic Airport Casino Large-scale projects with an unlimited amount of cameras.

Software Package “Professional”

Stadium Mining Shopping mall Convention centre Large-scale projects with up to 500 cameras.

The SeMSy® management software is the ideal control tool for any video system – no matter if it includes 10 or 100,000 cameras.

• User-friendly
