Preface

This document shows a fail over cluster configuration for Gemalto SA server using Evidian SafeKit product

Who Should Read This Book

This document contains technical description. Therefore Gemalto SA server product and Evidian Safe kit administration knowledge is required and global system administration skill will ease the reading.

For More Information

For more information on Evidian SafeKit , see the consult Sites:

Site Description

http://www.evidian.com/safekit/index.php Evidian SafeKit web Site

Contact Our Hotline

If you do not find the information you need in this manual, or if you find errors, contact the Gemalto hotline at

http://support.gemalto.com/.

(5)

1

Overview

This document describes how to integrate Gemalto SA server and Evidian Safekit in order to setup a fail over cluster.

Caution: Consequently, this document should not be considered as an instruction manual on how to configure your system.

To have a full infrastructure working you need:

• You need two computers running Microsoft windows 2003 server

o <IP SA SafeKit01> represents the IP of the first SA server : 10.10.280.41

o <IP SA SafeKit02> represents the IP of the second SA server : 10.10.280.41

o <IP SA Safekit Cluster> represents the cluster virtual IP : 10.10.238.44

o <SA firebird folder> represents the folder where the database is stored

o <SA service name> represents the name of SA service : saserver80

Main steps

In order to have the platform running here are the main steps that will be describes in this document: 1. SA server installation

a. Choose a specifiv installation folder b. Switch to SA service startup to manual 2. SafeKit installation

3. Safekit configuration

a. Use a configuration sample

(6)

2

Architecture and

Prerequisite

This section will describe the architecture to setup and the way to do so.

Global Architecture

Here is the architecture that is going to be describes in this document

Figure 1 - Cluster Architecture

(7)

Architecture and Prerequisite 3

SafeKit principe

Service Management

Here is a brief summary of mechanism that will rule the cluster switch.

SafeKit manage the clustered service. Therefor it is Safekit that start and Stop clustered services. In failover mode the clustered service is started on the primary machine and stopped on the backup machine.

Initial State

Figure 2 - Cluster Initial state

First state the Safe kit cluster is ready. Therefore :

• On both machine the SafeKit Service is running and the heart beat doesn’t indicate any problem.

(8)

4 Architecture and Prerequisite

Failover state

Figure 3 - Cluster switch state

If a problem occurs on the SA server service then SafeKit : • Detect it

(9)

Data Management

Figure 4 - Cluster data synchronization

In order to synchronize data between machines of the cluster, a folder will be declared on all clustered machines. Please note that this folder MUST have the same path on all clustered machines.

(10)

Gemalto SA Server installation

In order to simplify the SafeKit configuration, SA server installation will be done as follow: 1. At introduction click on Next

2. Accept the license and click on Next 3. Choose Typical and click on Next

4. At the installation folder click on Choose… and if needed create a folder with no space in the folder name. In this example saserver on c:\.

Figure 5 - SA server Installation folder

5. The SA server folder is now c:\saserver. Therefore the <SA firebird folder> is c:\saserver\DataStore. Click on Next

6. Enter your license and click on Next

(11)

Figure 6 - SA installation mode

9. Choose DB mode and click on Next

10. Click on install and finish the rest of the installation

Sakekit will start and stop SA server service. So once Installation is over saserver80 service startup has to be set to manual.

1. Click on start, choose “administrative tools” and click services

(12)

3. Change the startup type to Manual and click OK 4. Close the service windows.

SA server is installed on both machines using the exactly the same installation process

IMPORTANT

Services on both servers MUST have the same name. The SA service name is defined during installation process. In our example it is saserver80 because the TCP 80 port was available. If the port would have been used by another process then the SA service would have been installed on another TCP port and the service name would have been saserver< TCP port

number>.

Evidian SafeKit installation

(13)

Gemalto SA Server configuration

No more specific configuration has to be done on SA server.

Evidian SafeKit configuration

Safekit monitor

In order to configure Safekit you have to use Safekit monitor. Create an icon on your desktop with the following target

<Safekit installation Folder>\web\htdocs\safekit\safemonitor\safemonitor.jar

The Safekit monitor icon is :

Once done double-click on the icon Under SafeKit monitor :

1. In Server Admin Tab a. Declare both server

(14)

b. In apache.safe section put Saserver as name and click Install

Figure 8 - SafeKit Module Install

c. This is the result 2. In Quick Configure Tab

Figure 9 - SafeKit Node Ip address

a. Fill out the First Server IP addr field with <IP SA SafeKit01> b. Fill out the Second Server IP addr field with <IP SA SafeKit02>

Figure 10 - SafeKit Cluster IP address

(15)

3. In Expert Configuration tab

a. Modify start_prim.cmd file :

i. Find the line starting with : net start <apache service name> ii. And replace <apache service name> by : <SA service name> iii. You can modify also message body after any printi command

Please find in annex A the start_print.cmd file used for architecture.

b. Modify stop_prim.cmd file :

i. Find the line starting with : net stop <apache service name> ii. And replace <apache service name> by : <SA service name> iii. You can modify also message body after any printi command

Please find in annex A the stop_print.cmd file used for architecture.

c. Modify userconfig.xml file : i. Add the following section

<rfs>

Please find in annex A the userconfig.xml file used for architecture.

d. Save all the modification

e. Deploy the configuration an all cluster nodes f. Compile it

(16)

Evidian SafeKit First Run

Like any cluster system the first run is important.

Starting the PRIM server

Using Safe kit monitor, under Expert Configure

Figure 11 - SafeMonitor Expert Configure

(17)

• Choose Prim and confirm the command. This starts the first server of the fail over cluster. The server status change to WAIT. Then wait a few second and the status of the first server switch to ALONE.

Starting the SECOND server

The SA server now is available at the <IP SA Safekit Cluster> address, but the fail over is not setup yet.

• To start the second server, using Safe kit monitor, under Expert Configure right-click on the second server and choose Second (or Start). This starts the second server of the fail over cluster.

Note that the SA service is not running , but SafeKit Service is ready to start SA service in case of problem on the Prim server.

• The server status change to WAIT. Then wait a few second and the status of the second server switch to SECOND.

Please note that the status of the first sever has switch to PRIM.

(18)

3

Server Failover Switch

Once the SafeKit cluster is ready

1. connect the site http://<IP SA SafeKit Cluster>/saserver

The SA server main page is displayed

2. then switch off PRIM server

3. Wait a few second in order for Safekit to detect the failure and to start the SA service on the second machine

4. then connect the site http://<IP SA SafeKit Cluster>/saserver once again

(19)

A

SafeKit Scripts

start _prim.cmd

@echo on

rem Script called on the primary and secondary servers for starting applications

rem

rem If needed, add new applications starting

rem Execute recovery/cleanup procedures before starting rem to allow start after crash

rem See also stop_both for stopping applications

rem To locally apply a new start_both, stop and start SafeKit rem To remotly apply the new start_both, copy start_both on the rem remote host and stop and start SafeKit

rem --- rem Logging functions

rem --- rem

rem use %SAFE%\safekit printi | printe | printw "message" rem printi: log I[nformative] message in SafeKit log rem printe: log E[vent] message

rem printw: log W[arning] message

rem --- rem Main program for starting

rem --- set res=0

rem --- rem Applications starting calls

rem --- rem Fill with your application start call

rem and set res=0 if successfull rem or set res=1 if failed

(20)

16 SafeKit Scripts

if not %errorlevel% == 0 goto stop

%SAFE%\safekit printi "saserver80 started" if %res% == 0 goto end

:stop

set res=%errorlevel%

%SAFE%\safekit printi "saserver80 start failed"

rem uncomment to stop SafeKit when critical rem %SAFE%\safekit stop -i "start_both" :end

stop_prim.cmd

@echo on

rem Script called on the primary and secondary servers for stopping applications

rem started in start_both rem

rem If needed, add new applications stopping functions and calls rem Execute recovery/cleanup procedures after stopping

rem to allow quick restart

rem To locally apply a new stop_both, stop and start SafeKit rem To remotly apply the new stop_both, copy stop_both on the rem remote host and stop and start SafeKit

rem --- rem Logging functions

rem --- rem

rem use %SAFE%\safekit printi | printe | printw "message" rem printi: log I[nformative] message in SafeKit log rem printe: log E[vent] message

rem printw: log W[arning] message

rem --- rem Main program for stopping

rem --- set res=0

rem --- rem Applications stopping calls

rem

rem 2 stopping mode rem - graceful stop

rem call standard application stop rem - force stop (%1=force)

rem kill application's processes rem

rem Bounded time to execute to ensure non blocking stop: rem - 240 s for graceful stop

rem - 60 s for force stop rem

(21)

SafeKit Scripts 17

rem default: no action on forcestop if "%1" == "force" goto end

net stop saserver80

%SAFE%\safekit printi "saserver80 stopped" :end

userconfig.xml

<?xml version="1.0"?>

<!DOCTYPE safe SYSTEM "../private/conf/safeconf.dtd"> <safe>

<!-- Replace

* SERVER1_TO_BE_DEFINED and SERVER2_TO_BE_DEFINED by IP address of your 2 servers --> <heart> <heartbeat> <server addr="10.10.236.41"/> <server addr="10.10.236.42"/> </heartbeat> </heart> <rfs>

<!-- Replace

* VIRTUAL_TO_BE_DEFINED by the IP address of your virtual server --> <vip> <interface_list> <interface check="off"> <real_interface> <virtual_addr addr="10.10.236.44" where="one_side_alias"/> </real_interface> </interface> </interface_list> </vip>  <!-- Replace

* VIRTUAL_IP_ADDR_TO_BE_DEFINED by the IP address of your virtual server

--> <check>

(22)

18 SafeKit Scripts

</tcp> </check>
