Our Clients Include
British Transport Police
HM Prison Service
NHS
Vinci Construction
Taylor Woodrow
DVLA
HMCS
Hover Travel
The Post Office
& Hundreds of Sub Post Offices around the UK
Security Counters & Screens
Physical Attack Resistant
Bullet Resistant
Ready to Buy Screens
Transaction Windows
Natural Speech
Electronic Speed
Bullet Resistant
KS Security is a UK designer, manufacturer, supplier
and installer of bespoke and off the shelf physical
security measures including bullet and attack resistant
security counters & screens
Transfer Units
Vertical Sliding Hatches
Shallow Trays
Cash Packet Trays
Bulk Transfer Units
Audio Trays
Focus Audio Systems
Physical Attack Resistant Counters and Screens
KS Security designs and manufactures aselection of exceptional quality physical attack resistant screens which are tailored to ensure your staff are protected from the threat of physical attack at all times. All industries; all scenarios covered.
If interaction between staff and customers is vital in your business, but you need to keep your employees protected, a KS security screen can be tailor made to suit your specific environment and your specific needs. Please visit our website’s typical designs page to see some examples of the many configurations available.
A two position attack resistant fortress counter and screen Screens
Ƚ Built to anti-bandit standards including BS EN 356, BS 5544 & DIN 52290 Ƚ Fitted within steel frames
Ƚ Natural speech or electronic speech transfer options
Counters
Ƚ Built to bullet resistant specification Ƚ Internal steel construction
Ƚ Under-counter refuge area Ƚ A range of cash transfer units
Bullet Resistant Counters and Screens
If your risk includes the possibility of anattack with firearms we have a range of bullet resistant counters and screens to protect you and your staff.
Secure fortress counters with internal steel construction, ballistic resistant ply core doors and steel partition panels provide safe refuge in the event of an attack.
Ceilings, walls and floors can also be made attack resistant, hindering attack from any angle.
Our estimators can work closely with your architects or builders to advise on suitable secure construction.
Left: A section of 42mm ballistic laminated glass.
Above: A section of shot tested ply-core door leaf using: .3 Carbine, .44 Magnum, 7.62 NATO Rifle and 12 Bore Rifled Slug. Screens
Ƚ Built to bullet resistant standards including BS EN 1063 & BS 5051
Ƚ Spall allowed, low spall and no spall glazing options
Ƚ Fitted within steel frames Ƚ Electronic speech transfer Counters
Ƚ Built to bullet resistant specification Ƚ Internal steel construction
Ƚ Under-counter refuge area Ƚ A range of cash transfer units
Thanks to the high quality, exceptional value design and manufacturing capabilities of KS Security, you can protect your employees against physical attack and ensure the safety of your assets and cash with the utmost peace of mind, safe in the knowledge that your physical security measures have been tailor made to your precise needs.
The Personal Service of a Dedicated Team of Physical Security Specialists
With a tight knit and highly experienced, knowledgeable team of designers and craftsmen; our service is personal and completely tailored to your exacting physical security requirements. KS Security has for 20 years served a wide range of industry needs including Royal Mail and Post Office security; Local Authority security; Bureau de Change counters and screens; Cash & Carry; NHS security and a whole variety of others.
A Flexible Approach to Your Security Needs
Whether you are looking for off the shelf bullet resistant security windows or bespoke attack resistant screens; security safety glass screens to fit into an existing installation or a complete custom made door window security system; KS Security has the expertise and experience to provide just what you need.
From supplying single, ready made physical attack security items through to the entire bespoke design, manufacture and fitting of a business premises; our specialists welcome any size or type of project.
All KS Security screens are available to the trade for incorporating into contractors’ own counter designs, as well as to businesses wishing to upgrade their current counter units with attack resistant screens.
Choose from our stock range of physical attack resistant screens in 7 different sizes or have them made bespoke to fit the design and perfectly complete the vision of the designer.
You can source all the security screens and accessories you need in one place at KS Security, at reasonable prices that won’t break the budget.
Product Code Unit Size (mm) Required Aperture (mm)
width height depth width height
SU1 1000 1050 76 1010 1060 SU2 1150 1050 76 1160 1060 SU3 1200 1050 76 1210 1060 SU4 1350 1050 76 1360 1060 SU5 1150 1250 76 1160 1260 SU6 1200 1250 76 1210 1260 SU7 1350 1250 76 1360 1260
SPEECH Natural speech transfer through mullions (Also available for use with electronic speech enhancement systems)
MATERIALS Frame - fully welded mild steel polyester powder coated goosewing grey, to BS 00 A 05, pre drilled fixing holes
APERTURE
SIZE For details see table GLAZING
MEDIUM 11.5mm 5 ply MRS laminated glass, arbokoled into stainless steel channels to all 4 sides
Screens Only - SU
Suitable for fitting to client supplied counter or in client prepared opening. Compatible for assembly in multiples and with other standard KS Security Ltd. supplied units.
Suitable for use in: Cash Offices, Ticket Offices, Enquiry Windows, Reception Windows, Dispensary Windows and Surgeries.
Natural Speech Transaction Windows
TRANSFER Shallow documents / cash tray. Depth 25mm MATERIALS Worktop - marmoleum - graphite bonded to
MDF, solid ash lippings
Tray - satin polished stainless steel
Frame - fully welded mild steel polyester powder coated goosewing grey, to BS 00 A 05, pre drilled fixing holes
APERTURE
SIZE 610mm wide x 960mm high GLAZING
MEDIUM 11.5mm 5 ply laminated glass, arbokoled into stainless steel channels to all 4 sides
PW1 - Shallow tray
Our physical attack resistant PW1 with document tray and PW2 with cash packet tray offer cost effective solutions to transact with your customers whilst maintaining the security of your staff and assets.
TRANSFER Documents / cash tray / small packages Depth 110mm
MATERIALS Worktop - marmoleum - graphite bonded to MDF, solid ash lippings
Tray - satin polished stainless steel Box - faced with formica laminate 7961 fog Frame - fully welded mild steel polyester powder coated goosewing grey, to BS 00 A 05, pre drilled fixing holes
APERTURE
SIZE 610mm wide x 1120mm high GLAZING
MEDIUM 11.5mm 5 ply laminated glass, arbokoled into stainless steel channels to all 4 sides
PW2 - Cash packet tray
Natural Speech Transaction Windows
TRANSFER Shallow documents / cash tray. Depth 25mm MATERIALS Worktop - marmoleum - graphite bonded to
MDF, solid ash lippings
Tray - satin polished stainless steel
Frame - fully welded mild steel polyester powder coated goosewing grey, to BS 00 A 05, pre drilled fixing holes
APERTURE
SIZE 610mm wide x 960mm high GLAZING
MEDIUM 11.5mm 5 ply laminated glass, arbokoled into stainless steel channels to all 4 sides
PW1
Our physical attack resistant PW1 with document tray and PW2 with cash packet tray offer cost effective solutions to transact with your customers whilst maintaining the security of your staff and assets.
TRANSFER Documents / cash tray / small packages Depth 110mm
MATERIALS Worktop - marmoleum - graphite bonded to MDF, solid ash lippings
Tray - satin polished stainless steel
Frame - fully welded mild steel polyester powder coated goosewing grey, to BS 00 A 05, pre drilled fixing holes
APERTURE
SIZE 610mm wide x 1120mm high GLAZING
MEDIUM 11.5mm 5 ply laminated glass, arbokoled into stainless steel channels to all 4 sides
Electronic Speech Transaction Windows
SPEECH Electronic speech enhancement & integral hearing induction loop
TRANSFER Documents / cash tray / small packages Depth 65mm
MATERIALS Worktop - marmoleum - graphite bonded to MDF, solid ash lippings
Tray - satin polished stainless steel Box - faced with formica laminate 7961 fog Frame - fully welded mild steel polyester powder coated goosewing grey, to BS 00 A 05, pre drilled fixing holes
APERTURE
SIZE 610mm wide x 1120mm high GLAZING
MEDIUM 11.5mm 5 ply laminated glass
PW3 - Integral speech system & cash tray
Whether from stock or bespoke, KS Security transaction windows can be equipped with electronic speech enhancement systems.
10
PW4 - Surface speech system with standard tray
SPEECH Independent electronic speech enhancement with hearing induction loop
TRANSFER Shallow documents / cash tray Depth 25mm
MATERIALS Worktop - marmoleum - graphite bonded to MDF, solid ash lippings
Tray - satin polished stainless steel
Frame - fully welded mild steel polyester powder coated goosewing grey, to BS 00 A 05, pre drilled fixing holes
APERTURE
SIZE 610mm wide x 960mm high GLAZING
LLPW3 - Low level integral speech system & cash tray
SPEECH Independent electronic speech enhancement with hearing induction loop
TRANSFER Shallow documents / cash tray Depth 25mm
MATERIALS Worktop - marmoleum - graphite bonded to MDF, solid ash lippings
Tray - satin polished stainless steel
Frame - fully welded mild steel polyester powder coated goosewing grey, to BS 00 A 05, pre drilled fixing holes
APERTURE
SIZE 610mm wide x 1160mm high GLAZING
MEDIUM 11.5mm 5 ply laminated glass
LLPW4 - Low level surface speech system with standard tray
11
SPEECH Electronic speech enhancement & integral hearing induction loop
TRANSFER Documents / cash tray / small packages Depth 65mm
MATERIALS Worktop - marmoleum - graphite bonded to MDF, solid ash lippings
Tray - satin polished stainless steel Box - faced with formica laminate 7961 fog Frame - fully welded mild steel polyester powder coated goosewing grey, to BS 00 A 05, pre drilled fixing holes
APERTURE
SIZE 610mm wide x 1320mm high GLAZING
MEDIUM 11.5mm 5 ply laminated glass
Bullet Resistant Transaction Windows
SPEECH Electronic speech enhancement & integral hearing induction loop
TRANSFER Documents / cash tray / small packages Depth 65mm
MATERIALS Worktop - marmoleum - graphite bonded to MDF, solid ash lippings
Tray - satin polished stainless steel Box - faced with formica laminate 7961 fog Frame - fully welded mild steel polyester powder coated goosewing grey, to BS 00 A 05, pre drilled fixing holes
APERTURE
SIZE 610mm wide x 1120mm high GLAZING
MEDIUM 42mm Laminated glass G2 S86
BRPW - Integrated speech system & cash tray
KS Security has a long history of serving a vast range of sectors and know that sometimes physical attack resistant is not sufficient to meet the potential threat.
Normally all bullet resistant windows are made to meet your specific needs but we offer an off the shelf bullet resistant pay window for urgent security implementation.
Natural Speech Transaction Windows
TRANSFER Shallow documents / cash tray. Depth 25mm MATERIALS Worktop - marmoleum - graphite bonded to
MDF, solid ash lippings
Tray - satin polished stainless steel
Frame - fully welded mild steel polyester powder coated goosewing grey, to BS 00 A 05, pre drilled fixing holes
APERTURE
SIZE 610mm wide x 960mm high GLAZING
MEDIUM 11.5mm 5 ply laminated glass, arbokoled into stainless steel channels to all 4 sides
PW1
Our physical attack resistant PW1 with document tray and PW2 with cash packet tray offer cost effective solutions to transact with your customers whilst maintaining the security of your staff and assets.
TRANSFER Documents / cash tray / small packages Depth 110mm
MATERIALS Worktop - marmoleum - graphite bonded to MDF, solid ash lippings
Tray - satin polished stainless steel
Frame - fully welded mild steel polyester powder coated goosewing grey, to BS 00 A 05, pre drilled fixing holes
APERTURE
SIZE 610mm wide x 1120mm high GLAZING
MEDIUM 11.5mm 5 ply laminated glass, arbokoled into stainless steel channels to all 4 sides
Bulk Transfer Units
MECHANISM Manual
TRANSFER Large to medium size packages through interlocked doors.
OPTIONS Wall or Counter mounted. APERTURE
SIZE 524mm wide x 624mm high(See website for height requirements) FINISH Brushed Stainless Steel door to customer side.
Painted Mild Steel Grey Texture.
MBTU - Manual Bulk Transfer Unit
Manual bulk transfer units are ideal for the secure handover of large items such as cash carrying cases or large confidential file bundles. Electronic bulk transfer units have a slightly larger capacity and unlike the manual unit have a flat pass through, making them more suitable for fragile items.
EBTU - Electronic Bulk Transfer Unit
MECHANISM Electronic
TRANSFER Large to medium size packages through electrically interlocked doors.
OPTIONS Wall or Counter mounted. Left or right hand versions. APERTURE
SIZE 485mm wide x 390mm high.(See website for height requirements) FINISH Brushed Stainless Steel door to customer side.
Painted Mild Steel Grey Texture.
Natural Speech Transaction Windows
TRANSFER Shallow documents / cash tray. Depth 25mm MATERIALS Worktop - marmoleum - graphite bonded to
MDF, solid ash lippings
Tray - satin polished stainless steel
Frame - fully welded mild steel polyester powder coated goosewing grey, to BS 00 A 05, pre drilled fixing holes
APERTURE
SIZE 610mm wide x 960mm high GLAZING
MEDIUM 11.5mm 5 ply laminated glass, arbokoled into stainless steel channels to all 4 sides
PW1
Our physical attack resistant PW1 with document tray and PW2 with cash packet tray offer cost effective solutions to transact with your customers whilst maintaining the security of your staff and assets.
TRANSFER Documents / cash tray / small packages Depth 110mm
MATERIALS Worktop - marmoleum - graphite bonded to MDF, solid ash lippings
Tray - satin polished stainless steel
Frame - fully welded mild steel polyester powder coated goosewing grey, to BS 00 A 05, pre drilled fixing holes
APERTURE
SIZE 610mm wide x 1120mm high GLAZING
MEDIUM 11.5mm 5 ply laminated glass, arbokoled into stainless steel channels to all 4 sides
