Chapter 10

(1)

(2)

Section 10.1

Intermolecular Forces

Intramolecular Bonding

 _{“Within” the molecule.}

 _{Molecules are formed by sharing electrons between}

(3)

Section 10.1

 _{Forces that occur between molecules.}  _{Dipole–dipole forces}

 _{Hydrogen bonding}

 _{London dispersion forces}

(4)

Section 10.1

Intermolecular Forces

Hydrogen Bonding in Water

 _{Blue dotted lines are the intermolecular forces between}

(5)

Section 10.1

Which are stronger, intramolecular bonds or intermolecular forces?

How do you know?

(6)

Section 10.1

Phase Changes

 _{When a substance changes from solid to liquid to}

gas, the molecules remain intact.

 _{The changes in state are due to changes in the}

(7)

Section 10.1

(8)

Section 10.1

Phase Changes

 _{Solid to Liquid}

 _{As energy is added, the motions of the molecules}

increase, and they eventually achieve the greater movement and disorder characteristic of a liquid.

 _{Liquid to Gas}

 _{As more energy is added, the gaseous state is}

(9)

Section 10.1

(10)

Section 10.1

Dipole-Dipole Forces

 _{Dipole moment – molecules with polar bonds often}

behave in an electric field as if they had a center of positive charge and a center of negative charge.

 _{Molecules with dipole moments can attract each}

other electrostatically. They line up so that the

positive and negative ends are close to each other.

(11)

Section 10.1

Dipole-Dipole Forces

To play movie you must be in Slide Show Mode PC Users: Please wait for content to load, then click to play

(12)

Section 10.1

Hydrogen Bonding

(13)

Section 10.1

Hydrogen Bonding

 _{Strong dipole-dipole forces.}

 _{Hydrogen is bound to a highly electronegative atom}

– nitrogen, oxygen, or fluorine.

 _{That same hydrogen is then electrostatically}

(14)

Section 10.1

London Dispersion Forces

(15)

Section 10.1

London Dispersion Forces

 _{Instantaneous dipole that occurs accidentally in a}

given atom induces a similar dipole in a neighboring atom.

 _{Significant in large atoms/molecules.}

(16)

Section 10.1

Melting and Boiling Points

 _{In general, the stronger the intermolecular forces,}

(17)

Section 10.1

(18)

Section 10.1

Which molecule is capable of forming stronger

intermolecular forces?

N₂ H₂O

Explain.

(19)

Section 10.1

Draw two Lewis structures for the formula C₂H₆O and compare the boiling points of the two

molecules.

C

H

C

H

O H

C

(20)

Section 10.1

Which gas would behave more ideally at the same conditions of P and T?

CO or N₂

Why?

(21)

Section 10.2

The Liquid State

Liquids

 _{Low compressibility, lack of rigidity, and high density}

compared with gases.

 _{Surface tension – resistance of a liquid to an increase in}

its surface area:

 _{Liquids with large intermolecular forces tend to have}

(22)

Section 10.2

The Liquid State

Liquids

 _{Capillary action – spontaneous rising of a liquid in a}

narrow tube:

 _{Cohesive forces – intermolecular forces among the}

molecules of the liquid.

 _{Adhesive forces – forces between the liquid}

(23)

Section 10.2

The Liquid State

 _{Which force dominates alongside the glass tube –}

cohesive or adhesive forces?

cohesive forces

(24)

Section 10.2

The Liquid State

Concave Meniscus Formed by Polar Water

 _{Which force dominates alongside the glass tube –}

cohesive or adhesive forces?

(25)

Section 10.2

The Liquid State

Liquids

 _{Viscosity – measure of a liquid’s resistance to flow:}

 _{Liquids with large intermolecular forces or molecular}

(26)

Section 10.3

An Introduction to Structures and Types of Solids

Solids

 _{Amorphous Solids:}

 _{Disorder in the structures}  _Glass

 _{Crystalline Solids:}

(27)

Section 10.3

(28)

Section 10.3

Bragg Equation

 _{Used to determine the interatomic spacings.}

n = integer

= wavelength of the X rays

d = distance between the atoms

= angle of incidence and reflection = 2 sin

 

n d



(29)

Section 10.3

Bragg Equation

= 2 sin

 

(30)

Section 10.3

Types of Crystalline Solids

 _{Ionic Solids – ions at the points of the lattice that}

describes the structure of the solid.

 _{Molecular Solids – discrete covalently bonded molecules}

at each of its lattice points.

 _{Atomic Solids – atoms at the lattice points that describe}

(31)

Section 10.3

(32)

Section 10.3

(33)

Section 10.4

Structure and Bonding in Metals

Closest Packing Model

 _{Closest Packing:}

(34)

Section 10.4

The Closest Packing Arrangement of Uniform Spheres

 _abab_{packing – the 2}nd_{layer is like the 1}st_{but it is displaced so that}

each sphere in the 2nd_{layer occupies a dimple in the 1}st_layer.

 _{The spheres in the 3}rd_{layer occupy dimples in the 2}nd_{layer so that}

(35)

Section 10.4

The Closest Packing Arrangement of Uniform Spheres

 _abca_{packing – the spheres in the 3}rd_{layer occupy dimples in the}

2nd_{layer so that no spheres in the 3}rd_{layer lie above any in the 1}st

layer.

(36)

Section 10.4

(37)

Section 10.4

Structure and Bonding in Metals

(38)

Section 10.4

The Indicated Sphere Has 12 Nearest Neighbors

 _{Each sphere in both ccp}

(39)

Section 10.4

(40)

Section 10.4

Determine the number of metal atoms in a unit cell if the packing is:

a) Simple cubic

b) Cubic closest packing

a) 1 metal atom

b) 4 metal atoms

(41)

Section 10.4

A metal crystallizes in a face-centered cubic structure.

Determine the relationship between the radius of the metal atom and the length of an edge of the unit cell.

Length of edge = r  8

(42)

Section 10.4

Silver metal crystallizes in a cubic closest packed

structure. The face centered cubic unit cell edge is 409 pm.

Calculate the density of the silver metal.

Density = 10.5 g/cm

3 CONCEPT CHECK!

(43)

Section 10.4

Bonding Models for Metals

 _{Electron Sea Model}

(44)

Section 10.4

The Electron Sea Model

 _{A regular array of cations in a “sea” of mobile valence}

(45)

Section 10.4

Band or Molecular Orbital (MO) Model



Electrons are assumed to travel around the metal

crystal in molecular orbitals formed from the

(46)

Section 10.4

Molecular Orbital Energy Levels Produced When

(47)

Section 10.4

The Band Model for Magnesium

(48)

Section 10.4

Metal Alloys

 _{Substitutional Alloy – some of the host metal atoms are}

replaced by other metal atoms of similar size.

 _{Interstitial Alloy – some of the holes in the closest}

(49)

Section 10.4

Two Types of Alloys

 _{Brass is a substitutional}

alloy.

 _{Steel is an interstitial}

(50)

Section 10.5

Carbon and Silicon: Network Atomic Solids

Network Solids

(51)

Section 10.5

(52)

Section 10.5

(53)

Section 10.5

(54)

Section 10.5

Ceramics

 _{Typically made from clays (which contain silicates) and}

hardened by firing at high temperatures.

 _{Nonmetallic materials that are strong, brittle, and}

(55)

Section 10.5

Semiconductors

 _{n-type semiconductor – substance whose conductivity is}

increased by doping it with atoms having more valence electrons than the atoms in the host crystal.

 _{p-type semiconductor – substance whose conductivity is}

(56)

Section 10.5

Energy Level Diagrams for

(57)

Section 10.5

Silicon Crystal Doped with

(a) Arsenic and

(58)

Section 10.6

Molecular Solids

(59)

Section 10.7

Ionic Solids

(60)

Section 10.7

Ionic Solids

(61)

Section 10.7

Ionic Solids

Three Types of Holes in Closest Packed Structures

(62)

Section 10.7

Ionic Solids

(63)

Section 10.7

Ionic Solids

3) Octahedral holes are formed between two sets of three spheres in adjoining layers of the closest packed

(64)

Section 10.7

Ionic Solids

 _{For spheres of a given diameter, the holes increase in}

size in the order:

(65)

Section 10.7

Ionic Solids

(66)

Section 10.8

Vapor Pressure and Changes of State

Behavior of a Liquid in a Closed Container

(67)

Section 10.8

(68)

Section 10.8

Vapor Pressure

 _{Pressure of the vapor present at equilibrium.}

 _{The system is at equilibrium when no net change occurs}

(69)

Section 10.8

What is the vapor pressure of water at 100°C? How do you know?

(70)

Section 10.8

(71)

Section 10.8

Vapor Pressure

 _{Liquids in which the intermolecular forces are large have}

relatively low vapor pressures.

(72)

Section 10.8

(73)

Section 10.8

Clausius–Clapeyron Equation

P_vap = vapor pressure

ΔH_vap = enthalpy of vaporization

R = 8.3145 J/K·mol

T = temperature (in kelvin)

1

2

vap, _vap

vap, 2 1

1 1

ln__ __ =  _  _

 

T

P _H

(74)

Section 10.8

The vapor pressure of water at 25°C is 23.8 torr, and

the heat of vaporization of water at 25°C is 43.9 kJ/mol. Calculate the vapor pressure of water at 65°C.

(75)

Section 10.8

Changes of State

(76)

Section 10.8

(77)

Section 10.8

Which would you predict should be larger for a given substance: ΔH_vap or ΔH_fus?

Explain why.

(78)

Section 10.9

Phase Diagrams

 _{A convenient way of representing the phases of a}

substance as a function of temperature and pressure:

 _{Triple point}  _{Critical point}

(79)

Section 10.9

Phase Diagrams

(80)

Section 10.9

Phase Diagrams

(81)

Section 10.9

Phase Diagrams

As intermolecular forces

increase

, what happens to

each of the following? Why?

_{Boiling point} _Viscosity

_{Surface tension} _{Enthalpy of fusion} _{Freezing point}

_{Vapor pressure}

_{Heat of vaporization}
