Superior School of Technologies and Experimental Sciences
DEPARTMENT OF MATHEMATICS
MATHEMATICAL METHODS TO PREDICT THE DYNAMIC SHAPE EVOLUTION
OF CANCER GROWTH BASED ON SPATIO-TEMPORAL BAYESIAN
AND GEOMETRICAL MODELS
Author: Advisors:
Iulian Teodor Vlad Prof. Dr. Jorge Mateu
Prof. Dr. Jos´e Joaquin Gual Arnau
Castell´on de la Plana 2015
Superior School of Technologies and Experimental Sciences
DEPARTMENT OF MATHEMATICS
Doctoral Thesis
Mathematical Methods to Predict the
Dynamic Shape Evolution of Cancer
Growth based on Spatio-Temporal
Bayesian and Geometrical Models
Author:
Ing. Iulian Teodor Vlad
Supervisors: Prof. Dr. Jorge Mateu Prof. Dr. Jos´e Joaquin Gual Arnau
A thesis submitted in fulfilment of the requirements for the degree of Doctor of Philosophy
in the
Computer Mathematics
the Dynamic Shape Evolution
of Cancer Growth based on
Spatio-Temporal Bayesian
and Geometrical Models
Copyrightc 2015 - Ing. Iulian Teodor Vlad
I, Ing. Iulian Teodor Vlad, declare that this thesis entitled, ’Mathematical Methods to Predict the Dynamic Shape Evolution of Cancer Growth based on Spatio-Temporal Bayesian and Geometrical Models’ and the work presented in it are my own. I confirm that:
This work was done wholly or mainly while in candidature for a research degree
at this University.
Where any part of this thesis has previously been submitted for a degree or any
other qualification at this University or any other institution, this has been clearly stated.
Where I have consulted the published work of others, this is always clearly
at-tributed.
Where I have quoted from the work of others, the source is always given. With
the exception of such quotations, this thesis is entirely my own work.
I have acknowledged all main sources of help.
Where the thesis is based on work done by myself jointly with others, I have made
clear exactly what was done by others and what I have contributed myself.
DATE: SIGNATURE:
... ...
PHILOSOPHY ON MATHEMATICAL COMPUTATIONrunning in the period: oct 2009 - oct 2013, in particular, of fulfill the period of two years (oct 2009 - oct 2011) as well as Formatting Professional Research and another two years (oct 2011 - oct 2013) as Member of the Research Team: Statistical Modeling to Environmental Problems, code 145 coordinated by the Prof. Dr. Jorge Mateu, as requirements of the course 14019 - “Matem´atica Computacional” on the Superior School of Technologies and Experimental Sciences, Department of Mathematics. I certify that I have read this dissertation and that, in my opinion, it is fully ade-quate in scope and quality as a dissertation for the degree of Doctor of Philosophy:
Director: Name: Prof. Dr. Jorge Mateu Signature: ...
I certify that I have read this dissertation and that, in my opinion, it is fully ade-quate in scope and quality as a dissertation for the degree of Doctor of Philosophy:
Co-Director: Name: Prof. Dr. Jos´e Joaquin Gual Arnau Signature: ...
I certify that I have read this dissertation and that, in my opinion, it is fully ade-quate in scope and quality as a dissertation for the degree of Doctor of Philosophy:
Committee Member: Name: ... Signature: ...
I certify that I have read this dissertation and that, in my opinion, it is fully ade-quate in scope and quality as a dissertation for the degree of Doctor of Philosophy:
Committee Member: Name: ... Signature: ...
I certify that I have read this dissertation and that, in my opinion, it is fully ade-quate in scope and quality as a dissertation for the degree of Doctor of Philosophy:
Committee Member: Name: ... Signature: ...
Axiom 5B: “Be good, beyond better, to become the best”.
I.T. Vlad
by Ing. Iulian Teodor Vlad
The aim of this research is to observe the dynamics of cancer tumors and to develop and implement new methods and algorithms for prediction of tumor growth. We offer some tools to help physicians for a better understanding and treatment of this disease. Using a prediction method, and comparing with the real evolution a physician can note if the prescribed treatment has the desired effect, and according to this, if necessary, to take the decision of surgical intervention.
In this thesis we analyze the spatio-temporal dynamics of shape evolution and we apply these to a particular case of brain tumors.
The plan of the thesis is the following. In Chapter 1 we briefly recall some proper-ties and classification of points processes with some examples of spatio-temporal point processes. Chapter 2 presents a short overview of the theory of L´evy bases and integration with respect to such basis is given, we recall standard results about spatial Cox processes, and finally we propose different types of growth models and a new algorithm, the Cobweb, which is presented and developed based on the pro-posed methodology. Chapters 3, 4 and 5 are dedicated to present new prediction methods. The implementation in Matlab software comes in Chapter 6. The thesis ends with some conclusion and future research.
Special thanks to my advisor Prof. Dr. Jorge Mateu for his collaboration and to University “JAUME I” of Castell´on for the inestimable help, supporting and invaluable experience offered, an educational institution of study nearby of citi-zens and nature, with a great human and material basis, designed to provide a permanently support to the current development of actual society.
Also we want to thank to our colleague Francisco, who offer us the right to use the image acquisitions of the tumor images based on which we have shown the functionality of these algorithms.
