ECTFE (Halar ) Piping System

(1)

Price List AH08-1

Effective November 20, 2008

Supercedes AH05-1, dated January 1, 2005 All Prices are in Canadian Dollars

Subject to change without notice. F.O.B. Thornhill, Ontario.

Taxes extra. Discount Code A

PDF Published November 20, 2008

Material Properties

Page

General Properties of ECTFE T1-T2

Pressure Curve for ECTFE Pipe T4

Permissible Component Operating Pressures P_Bfor ECTFE T4

Chemical Resistance T5

Pipe

Pipe 2

Butt Fusion Fittings

90o

Elbows – Short Spigot 2

90o_{Elbows – Long Spigot}

3

45o

Elbows – Long Spigot 3

Tees – Short Spigot 4

Concentric Reducers – Long Spigot 4

Concentric Reducers – Short Spigot 5

End Caps – Long Spigot 5

ANSI Stub Flanges – Short Spigot 6

ANSI Backing Rings 6

DIN Stub Flanges – Short Spigot 7

DIN Backing Rings 7

Unions 8

Valves

Diaphragm Valves 8

Piping Supports

Pipe Clips 9-10

ECTFE (Halar

®

)

Piping System

Pipe, Fittings, Pipe Supports

& Valves

(Zero Dead Leg Diaphragm)

Your Pipeline To Quality Valves,

Piping, Flow Meters and Controls

55 Guardsman Road

Thornhill, Ontario

Canada, L3T 6L2

Tel: 905-889-7890 Fax: 905-889-8553 [email protected] www.chemline.com

11/08 ©Chemline Plastics Limited 2008

(2)

Price List AH08-1 T1

ECTFE (Halar)

Piping Systems

Consult Chemline Plastics for availablilty. Subject to change without notice.

ECTFE is refered to as Halar

General properties of ECTFE (Ethylenechlorotrifluorethylene)

ECTFE has a unique combination of properties, which is due to its chemical structure - a copolymere with a changing structure of ethylene and chlorotrifluorethylene.

Physiological properties

ECTFE is safe for products in contact with food according to "BGA Deutschland".

Thermal properties

ECTFE is resistant to heat, intensive radiation and weathering. It can withstand temperatures up to 150°C and is one of the best plastics with good resistance to radiation.

Resistance to Weathering

ECTFE demonstrates only a slight change of properties or appearance when exposed to sunlight. Repeated tests showed remarkable stability of the polymers particularly with the elongation at break, which is a good indicator of the polymer-decomposition. Even after 1000 hours in a "Weather - Ometer" with xenon-light the important properties were only slightly changed.

Radiation Resistance

ECTFE demonstrates excellent resistance to different radiations. It even shows good values after irridation with 200 megarad cobalt 60.

Mechanical Properties

ECTFE is a solid, very impact resistant plastic, exhibiting good resistance temperature variatons. It also has good high impact strength, breaking strain and abrasion behaviour.

Advantages of ECTFE

wide temperature application range (short-term thermal resistance up to 150°C).

good resistance against UV- and g-radiation, therefore favourable ageing resistance. flame retardant (UL 94V0material) -oxygen index 60

excellent abrasion resistance

extremely good chemical resistance against most acids, alkalies and solvents as well as contact with chlorine.

excellent insulating properties in connection with very good electrical values

physiological non-toxic

very good surface slip characteristics

Reproduction of Microorganisms on ECTFE

The surface of a product constructed of ECTFE is not favourable to the proliferation of microorganisms - ie it is similar to glass. Due to these properties, ECTFE is used in the food and drug industry and for ultra-pure water applications.

C C C C

H

Cl F

H H H

H H

_n

C C C C

H

Cl F

H H H

H H

C C C C

H

Cl F

H H H

H H

_n

z z z z z z z z

Chemical structure of ECTFE

Material

Properties

(3)

ECTFE (Halar)

Piping Systems

P r ope r t y S t a nda r d U nit P V D F E CT F E

Spe cif ic de ns it y a t 2 3 ° C ISO 1 1 8 3 g/cm3 1 .7 7 1 .6 8 M e lt f low inde x M FR 1 9 0 /5 M FR 1 9 0 /2 .1 6 M FR 2 3 0 /5 M FI r a nge ISO 1 1 3 3 g/1 0 m in 6 0 .8 5

T e ns ile s tr e s s a t yie ld ISO 5 2 7 M P a 5 0 3 0 E longa t ion a t yie ld IS O 5 2 7 % 9 5 E longa t ion a t br e a k IS O 5 2 7 % 8 0 2 5 0 Im pa ct s t r e ngt h unnot che d a t +2 3 °C Im pa ct s t r e ngt h unnot che d a t -3 0 ° C IS O 1 7 9 k J /m 2 1 2 4 no br e a k Im pa ct s t r e ngt h not che d a t +2 3 ° C Im pa ct s t r e ngt h not che d a t 0 ° C Im pa ct s t r e ngt h not che d a t -3 0 ° C IS O 1 7 9 k J /m2 1 1 no br e a k

Ba ll inde nt a t ion ha r dne s s a cc. Rock w e ll ISO 2 0 3 9 -1 M P a

8 0 9 0

Fle xur a l st r e ngt h IS O 1 7 8 M P a 8 0 4 7 M odulus of e la s t icit y IS O 5 2 7 M P a 2 0 0 0 1 6 9 0 V ica t -Sof t e ning point V S T /B/5 0 IS O 3 0 6 ° C 1 4 0

H e a t de f le ct ion t e m pe r a t ur e H D T /B ISO 7 5 ° C 1 4 5 9 0 Line a r coe f f icie nt of t he r m a l e xpa ns ion D IN 5 3 7 5 2 K- 1 x 1 0- 4

1 .2 0 .8 T he r m a l conduct iv it y a t 2 0 ° C D IN 5 2 6 1 2 W /(m xK ) 0 .1 3 0 .1 5 Fla m m a bilit y U L9 4 D IN 4 1 0 2 --V -0 V -0 Spe cif ic volum e r e s is ta nce V D E 0 3 0 3 O H M cm >1 0 13 >1 016 Spe cif ic s ur f a ce r e s is ta nce V D E 0 3 0 3 O H M >1 012 >1 014 r e la t iv e die le ct r ic cons t a nt

a t 1 M H z D IN 5 3 4 8 3 -- 7 .2 5 2 .6 D ie le ct r ic s t r e ngth V D E 0 3 0 3 k V /m m 2 2 3 0 bis 3 5 P hys iologica lly non-t oxic E E C 9 0 /1 2 8 -- Y e s Y e s

FD A -- -- Y e s in pr e pe r a t ion

U V s ta bilize d -- -- Y e s Y e s

Colour -- -- na t ura l na tur a l

Me cha nica l P rope rt ie s Th erm al Pro p ert ies El ec tri ca l Pro p erti e s

General Properties PVDF and ECTFE General Properties PVDF and ECTFE General Properties PVDF and ECTFE General Properties PVDF and ECTFE General Properties PVDF and ECTFE

Material

Properties

(4)

ECTFE (Halar)

Piping Systems

Pressure Curve for ECTFE (Halar) Pipes

Permissible component operating pressures p_Bfor ECTFE

depending on temperature and operation period.

The data in this table applies to water service. The data was detemined from the creep curve taking into account a safety coefficient of C = 2.0

1)_{... We recommend for the calculation of the operating}

pressure in piping systems to multiply the operating pressure shown on the table with a system reduction coefficient fs=0.8 (This value contains installation-technical influences such as welding joint, flange or also bending loads).

2)_{... These operating pressures have to be reduced by}

the corresponding reducing coefficients depending on the application.

Tim e to fa il [h]

Re

fe

re

n

c

e

st

re

s

σ

v

[

N

/m

m

2

]

1

10

1

_{1 0}

2

_{1 0}

3

₁₀

4

_{1 0}

5

₁₀

6

1

2

3

4

5

7

10

20

30

40

50 90 °C

60 °C

23 °C

1

5

10

25

50 S tand ze it [Jah re]

1

10

1

_{1 0}

2

_{1 0}

3

₁₀

4

_{1 0}

5

₁₀

6

1

2

3

4

5

7

10

20

30

40

50 90 °C

60 °C

23 °C

1

5

10

25

50 Tim e to fail [years]

1

10

1

_{1 0}

2

_{1 0}

3

₁₀

4

_{1 0}

5

₁₀

6

1

2

3

4

5

7

10

20

30

40

50 90 °C

60 °C

23 °C

1

5

10

25

50 S tand ze it [Jah re]

1

10

1

10

1

_{1 0}

2

_{1 0}

3

₁₀

4

_{1 0}

5

₁₀

6

1

2

3

4

5

7

10

20

30

40

50 90 °C

60 °C

23 °C

1

5

10

25

50 S tand ze it [Jah re]

1

10

1

_{1 0}

2

_{1 0}

3

₁₀

4

_{1 0}

5

₁₀

6

1

2

3

4

5

7

10

20

30

40

50 90 °C

60 °C

23 °C

1

5

10

25

50 Tim e to fail [years]

21 33 10 16 10 6 20 1 11,5 7,2 5 10,5 6,6 10 10,0 6,3 60 1 6,5 4,0 5 6,3 3,9 10 6,0 3,8 90 1 3,0 1,9 5 2,8 1,8 10 2,7 1,7 Temperatur e [°C] Operating period [years]

Diameter wall thickness relation SDR

Pipe series S

PN

Permissible component operating pressure pB [bar] 1) 2)

Material

Properties

(5)

ECTFE (Halar)

Piping Systems

ECTFE has an outstandingly chemical resistance. It has excellent resistance against most industrial chemicals, e.g. strong mineral and oxidized acids, alkaline, metal-etching-products, liquid oxygen and all organic solvents, except hot amines (z.B. aniline, dimethylamine). The solvents in the following table were tested with undiluted solvents.

Like other fluorine plastics ECTFE will be attacked by sodium and potassium. The attack depends on the contact period and the temperature.

U-Insignificant

A-Reduction by 25-50% B-Reduction by um 50-75% C-Reduction by > 75%

Chemical Resistance ECTFE

Ch e m ical T e m p e ratu re W e ig h t g ain In flu e n ce o n Influ e n ce o n [°C] [% ] te n sile m o d u lu s e lo n g atio n at b reak Min e ral acid

Su lfu ric acid 7 8 % 2 3 < 0 .1 U U

1 2 1 < 0 .1 U U

H yd ro ch lo ric acid 3 7 % 2 3 < 0 .1 U U

7 5 1 0 5 0 .1 U U

H yd ro ch lo ric acid 6 0 % 2 3 < 0 .1 U U Ch lo ro sulfo n ic acid 6 0% 2 3 0 .1 U U Oxid izin g acid

N itric acid 7 0 % 2 3 < 0 .1 U U 1 2 1 0 .8 A C Ch ro m ic acid 50 % 2 3 < 0 .1 U U 1 1 1 0 .4 U U Aq u a re gia 2 3 0 .1 U U 7 5 1 0 5 0 .5 U U So lve n ts Alip h ate s 2 3 0 .1 U U H e xane 5 4 1 .4 A U Iso o ctan e 2 3 < 0 .1 U U 1 1 6 3 .3 A U Aro m ate s B e n zen e 2 3 0 .6 U U 7 4 7 C U T o lu e n e 2 3 0 .6 U U 1 1 0 8 .5 C U Alcoh o le s Me th an ol 2 3 0 .1 U U 6 0 0 .4 A U B utan ol 2 3 < 0 .1 U U 1 1 8 2 .0 A U Classical plastic so lve n ts D im e thyl fo rm am id e 7 3 2 .0 A U 2 5 0 7 .5 C U D im e thyl su lp h o xid e 7 3 0 .1 U U 2 5 0 3 .0 U U

Material

Properties

(6)

Pipe

ECTFE (Halar

®

)

Piping Systems

mm 1.9 1.9 2.4 3.0 3.0 4.3 5.3 kg/m 0.20 0.25 0.41 0.80 1.03 2.10 3.14 Nom. 1/2" 3/4" 1" 1-1/2" 2" 3" 4" Item No. H.705.0020.21 H.705.0025.21 H.705.0032.21 H.705.0050.21 H.705.0063.21 H.705.0090.21 H.705.0110.21 53.60 68.90 112.00 217.00 279.00 572.00 854.00

Pipe

Product 705 Unipigmented ECTFE Extruded da OD s Weight Poids Price/m* Prix/m* SDR 21 / ISO S-10 / PN 10 mm 20 25 32 50 63 90 110

* Price and weights are per meter, supplied in 5 meter lengths.

* Prix et poids au mètre, fourni en longueurs de 5 mètres.

Tuyau

Produit 705 ECTFE Natural Expulsé mm 1.9 2.4 3.0 4.3 5.3 kg 0.01 0.03 0.07 0.33 0.59 Nom. 1/2" 1" 1-1/2" 3" 4" Item No. H.001.0020.21 H.001.0032.21 H.001.0050.21 H.001.0090.21 H.001.0110.21 23.20 61.00 146.00 696.00 1044.00

90

o

_Elbows

Short Spigot Product 001 Unipigmented ECTFE Injection Moulded Contact or IR Butt Fusion

da

OD s Weight_Poids Price

Prix SDR 21 / ISO S-10 / PN 10 mm 20 32 50 90 110

Coudes 90

o Broche Courte Produit 001 ECTFE Naturel Moulé à injection

Souldure Bout IR ou Contact

r mm 33 43 59 103 125 mm 26 34 50 91 108 z

2 Price List AH08-1

**Indicates regularly stocked items. Consult Chemline Plastics for availability. Subject to change without notice.

(7)

Nom. 1/2" 3/4" 1" 1-1/2" 2" Item No. H.060.0020.21 H.060.0025.21 H.060.0032.21 H.060.0050.21 H.060.0063.21 36.30 39.50 76.30 180.00 304.00

45

o

Elbows

Long Spigot Product 060 Unipigmented ECTFE Injection Moulded Contact or IR Butt Fusion

da

OD s Weight_Poids _Price

Prix SDR 21 / ISO S-10 / PN 10 mm 20 25 32 50 63

Coudes 45

o Broche Longue Produit 060 ECTFE Naturel Moulé à injection

L3 mm 43 45 52 66 75 z mm 1.9 1.9 2.4 3.0 3.0 kg 0.02 0.02 0.05 0.09 0.17

Butt Fusion Fittings

ECTFE (Halar

®

)

Piping Systems

mm 39 40 46 56 62

Price List AH08-1 3

mm 1.9 1.9 2.4 3.0 3.0 4.3 5.3 kg 0.02 0.03 0.05 0.13 0.19 0.50 0.89 Item No. H.068.0020.21 H.068.0025.21 H.068.0032.21 H.068.0050.21 H.068.0063.21 H.068.0090.21 H.068.0110.21 29.00 39.20 76.20 182.00 305.00 870.00 1,305.00 da OD s Weight Poids Price Prix SDR 21 / ISO S-10 / PN 10 z r mm 20 25 32 50 63 90 110 mm 51 56 63 84 97 123 142 L3 mm 33 33 33 36 35 34 34

90

o

Elbows

Coudes 90

o

Broche Longue Produit 068

ECTFE Naturel Moulé à injection

mm 20 25 32 50 63 90 110 Nom. 1/2" 3/4" 1" 1-1/2" 2" 3" 4"

(8)

Butt Fusion Fittings

ECTFE (Halar

®

)

Piping Systems

mm 1.9 1.9 2.4 3.0 3.0 4.0 5.3 kg 0.02 0.03 0.08 0.15 0.24 0.56 1.09 Nom. 1/2" 3/4" 1" 1-1/2" 2" 3" 4" Item No. H.006.0020.21 H.006.0025.21 H.006.0032.21 H.006.0050.21 H.006.0063.21 H.006.0090.21 H.006.0110.21 40.90 51.30 73.90 130.00 278.00 910.00 1,130.00 da OD s Weight Poids Price Prix SDR 21 / ISO S-10 / PN 10 mm 20 25 32 50 63 90 110 L mm 35 40 45 60 75 92 110 mm 70 80 89 120 149 181 223 L3 mm 15 15 17 23 28 33 33 z

Tees

Pièces en T

Broche Courte Produit 006

Concentric Reducers

Long Spigot

Product 067 Unipigmented ECTFE Injection Moulded Contact or IR Butt Fusion

Réducteurs Concentriques

Broche Longue

Produit 067

mm 1.9 2.4 4.6 4.6 5.8 5.8 6.6 6.6 Item No. H.067.2520.21 H.067.3225.21 H.067.5025.21 H.067.5032.21 H.067.6332.21 H.067.6350.21 H.067.1163.21 H.067.1190.21 57.20 58.10 98.20 98.20 142.00 142.00 347.00 347.00 da/da1 OD/OD1 s Weight Poids Price Prix SDR 21 / ISO S-10 / PN 10 L s1 mm 1.9 1.9 2.3 3.0 3.0 4.6 3.8 5.4 mm 85 95 118 118 136 150 180 180 L1 mm 39 44 55 59 64 66 83 83 L2 mm 40 40 44 46 49 59 63 75 mm 25/20 32/25 50/25 50/32 63/32 63/50 110/63 110/90 kg 0.03 0.02 0.04 0.08 0.06 0.14 0.63 0.65

(9)

mm 3.0 5.3 kg 0.04 0.14 Nom. 2"/3/8" 4"/2" Item No. H.007.6316.21 H.007.1163.21 97.20 290.00

Concentric Reducers

da

Prix SDR 21 / ISO S-10 / PN 10 mm 63/16 110/63

Réducteurs

Concentriques

Broche Courte Produit 007 ECTFE Naturel Moulé à injection

s1 mm 9 11 mm 1.9 3.0 L1 L2 L mm 5 7 mm 56 65 mm 1.9 1.9 2.4 3.0 3.0 kg 0.01 0.01 0.03 0.06 0.11 Nom. 1/2" 3/4" 1" 1-1/2" 2" Item No. H.064.0020.21 H.064.0025.21 H.064.0032.21 H.064.0050.21 H.064.0063.21 42.00 47.80 49.10 111.00 177.00 da

Prix SDR 21 / ISO S-10 / PN 10 mm 20 25 32 50 63 L mm 41 41 45 60 68 mm 45 49 56 73 86 L3

End Caps

Montures d’Embout

Broche Longue

Produit 064

Butt Fusion Fittings

ECTFE (Halar

®

)

Piping Systems

(10)

Butt Fusion Fittings

ECTFE (Halar

®

)

Piping Systems

Nom. 1/2" 3/4" 1" 1-1/2" 2" 3" 4"

ANSI Stub Flanges

Short Spigot

Product 012.1 Unipigmented ECTFE Injection Moulded Contact or IR Butt Fusion

mm 27 33 40 61 75 105 125 kg 0.03 0.05 0.06 0.12 0.17 0.38 0.57 mm 20 25 32 50 63 90 110* da OD d3 Weight_Poids SDR 21 / ISO S-10 / PN 16 d4 h L3 L s mm 1.9 1.9 2.4 3.0 3.0 4.3 5.3 mm 30 25 25 20 18 40 38 mm 7 9 10 12 14 17 18 mm 44.5 54.1 63.5 82.5 100.4 132.4 158.0

Bridges de Moignon ANSI

Broche Courte

Produit 012.1

* Flange diameter slightly smaller than ANSI standard. Backing rings are required with stub flanges.

* Diamêtre de la bride est légerement moindre que ANSI-standard. Brides de moignon necessitent anneaux de support.

36.70 40.90 45.40 108.00 130.00 319.00 490.00 Price Prix mm 50 50 50 50 50 80 80 mm 95 102 114 133 162 194 229 kg 0.21 0.24 0.39 0.55 0.82 1.10 1.62 Nom. 1/2" 3/4" 1" 1-1/2" 2" 3" 4" Nom. 2-3/8" 2-3/4" 3-1/8" 3-7/8" 4-3/4" 6" 7-1/2" Item No. B.013.0020.11 B.013.0025.11 B.013.0032.11 B.013.0050.11 B.013.0063.11 B.013.0090.11 B.013.0110.11 26.60 33.10 39.00 56.10 69.70 101.00 132.00 da

OD d WeightPoids Price

Prix SDR 21 / ISO S-10 / PN 16 mm 20 25 32 50 63 90 110 d3 b No. of Bolts k mm 12 12 16 18 18 18 18 Torque ft-lbs. 11.1 11.1 11.1 25.8 25.8 29.5 29.5 mm 28 34 42 62 78 111 133 mm 60 70 79 99 121 152 191 Nom. 5/8" 5/8" 5/8" 3/4" 3/4" 3/4" 3/4" d2 mm 16 16 16 16 20 20 20 4 4 4 4 4 4 8

ANSI Backing Rings

Product 013

Grey PPG

Glass Filled Polypropylene Injection Moulded with Steel Core Used together with Stub Flanges for flange connections

Anneaux de Support de

Norme ANSI

Produit 013

PPG-gris

Polypropylène rempli de fibre de verre Moulé à injection avec insertion en acier Utilisé avec des brides de moignon pour des raccordementts de bride Item No. H.012.1020.21** H.012.1025.21** H.012.1032.21** H.012.1050.21** H.012.1063.21** H.012.1090.21** H.012.0110.21

(11)

Butt Fusion Fittings

ECTFE (Halar

®

)

Piping Systems

mm 1.9 1.9 2.4 3.0 3.0 4.3 5.3 kg 0.03 0.05 0.06 0.12 0.17 0.38 0.57 Nom. 1/2" 3/4" 1" 1-1/2" 2" 3" 4" Item No. H.012.0020.21 H.012.0025.21 H.012.0032.21 H.012.0050.21 H.012.0063.21 H.012.0090.21 H.012.0110.21 36.70 40.90 45.40 108.00 130.00 319.00 490.00 da OD s Weight Poids Price Prix SDR 21 / ISO S-10 / PN 10 mm 20 25 32 50 63 90 110 d3 d4 L h L3 mm 45 58 68 88 102 138 158 mm 27 33 40 61 75 105 125 mm 31 30 26 22 18 39 38 mm 6.0 6.5 7.0 9.0 10.0 17.0 12.0 mm 50 50 50 50 50 80 80

DIN Stub Flanges

Short Spigot

Product 012 Unipigmented ECTFE Injection Moulded Contact or IR Butt Fusion

Brides de Moignon DIN

Broche Courte

Produit 012

mm 15 20 25 40 50 80 100 kg 0.24 0.31 0.41 0.69 0.79 1.22 1.63 Item No. B.014.0020.11-DIN B.014.0025.11-DIN B.014.0032.11-DIN B.014.0050.11-DIN B.014.0063.11-DIN B.014.0090.11-DIN B.014.0110.11-DIN 19.90 21.90 28.20 41.70 48.10 63.50 75.50 da OD DN WeightPoids 4 4 4 4 4 8 8 No. of Bolts M12 M12 M12 M16 M16 M16 M16 Bolt Size Price Prix mm 20 25 32 50 63 90 110 d d3 k mm 28 34 42 62 78 108 128 b mm 12 14 16 18 18 20 20 mm 95 108 115 150 165 202 222 d2 mm 14 14 14 18 18 18 18 Torque ft-lbs. 11.1 11.1 11.1 25.8 25.8 29.5 29.5 p psi 235 235 235 235 235 235 235 mm 65 75 85 110 125 160 180

DIN Backing Rings

Product 014

Grey PPG

Glass Filled Polypropylene Injection Moulded with Steel Core Flange connection

Used together with Stub Flanges for flange connections

Anneaux de Support de

Norme DIN

Produit 014

PPG-gris

Polypropylène rempli de fibre de verre Moulé à injection avec insertion en acier Raccordement de bride

Utilisé avec des brides de moignon pour des raccordementts de bride

(12)

Butt Fusion Fittings

ECTFE (Halar

®

)

Piping Systems

Unions

Product 024 Unipigmented ECTFE

FPM Sealing with FDA Approval Injection Moulded

Contact or IR Butt Fusion

Union

Produit 024

ECTFE Naturel

FPM Sealing with FDA Approval Moulé à injection

mm 1.9 1.9 2.4 kg 0.08 0.11 0.16 Item No. H.024.0020.21 H.024.0025.21 H.024.0032.21 131.00 166.00 204.00 da OD s Weight Poids Price Prix SDR 21 / ISO S-10 / PN 10 L d mm 47 57 64 mm 107 112 119 L1 mm 24 24 25 L2 mm 35.5 36.5 39.3 mm 20 25 32 Nom. 1/2" 3/4" 1" mm 1.9 1.9 2.4 3.0 3.0 kg 0.45 0.50 0.72 1.70 2.45 Nom. 1/2" 3/4" 1" 1-1/2" 2" Item No. H.342.1020.21 H.342.1025.21 H.342.1032.21 H.342.1050.21 H.342.1063.21 987.00 1,007.00 1,040.00 1,700.00 2,218.00 da OD s Weight Poids Price Prix SDR 21 / ISO S-10 / PN 10 mm 20 25 32 50 63 L1 L2 k L kv mm 24.5 24.5 24.5 44.0 44.0 mm 16.5 17.0 20.5 32.0 38.5 l/min 72 93 221 500 875 mm 133 144 154 194 224 M6 M6 M6 M8 M8 t b h mm 36 36 36 46 54 mm 85 85 85 135 135 mm 100 100 107 144 170

Diaphragm Valves

Manually Operated

Product 342.1

Unipigmented ECTFE Body One Piece PTFE/EPDM Diaphragm Contact or IR Butt Fusion

Vannes a Diaphragme

Controllee Manuellement

Produit 342.1

ECTFE Naturel

Diaphragme PTFE/EPDM d’une pièce Fusion Bout à Bout IR ou Contact

(13)

ECTFE (Halar

®

)

Piping Systems

Piping Supports

mm 6.0 10.0 11.5 15.0 kg 0.01 0.01 0.01 0.03 Item No. BB.348.0020.00 BB.348.0025.00 BB.348.0032.00 BB.348.0050.00 6.80 7.70 8.10 10.60 da

OD s1 WeightPoids Price

Prix mm 20 25 32 50 s2 b h s3 d mm 14 16 16 20 mm 29 34 39 56 mm 6.5 6.5 6.5 6.5 mm 27.0 30.0 31.5 41.0 mm 6.5 6.5 6.5 6.5 s4 mm 9 9 9 9

Pipe Clips

Snap-in Type with Spacer Product 348

Black PPG

Glass Filled Polypropylene Includes fold-over spacer plate to allow greater clearances

Supports de Tuyau

Type à agrafe avec entretoise Produit 348

PPG noir

Polypropylène rempli de fibre de verre Inclut plat d’entretoise repliable pour permettre de plus grands dégagements

mm 94 128 152 kg 0.13 0.20 0.30 Item No. BB.049.0063.00 BB.049.0090.00 BB.049.0110.00 16.60 17.90 20.50 da

OD h WeightPoids Price

Prix mm 63 90 110 d2 b z d d1 mm 30 40 40 mm 78 108 137 mm 84 82 82 mm 52 67 71 mm 53 57 71

Pipe Clips

Retainer Type Product 049 Black PPG

Glass Filled Polypropylene Includes snap-on retainer

Supports de Tuyau

Type arrêtoir

Produit 049

PPG noir

Polypropylène rempli de fibre de verre Inclut arrêtoir à agrafe

(14)

ECTFE (Halar

®

)

Piping Systems

Piping Supports

mm 10 11 11 Item No. CLIP.0020.B CLIP.0025.B CLIP.0032.B 1.70 1.90 2.40 da OD d1 _Price** Prix** mm 20 25 32 d2 h b h1 h2 mm 34 35 44 mm 11 12 11 Carton Quantity 20 20 20 mm 32 41 49 mm 25 26 30 t mm 16 17 16

Pipe Clips

Low Cost Snap-in Type Product – CLIP

Grey PP*

Supports de Tuyau

Type prix reduit à clic

Produit – CLIP

PP Gris*

* Also available in black HDPE (high density polyethylene). Change B to PE in item number.

* Aussi disponible en PE (polyethylène noir. Changez B à PE dans le numero de produit.

**Prices are each, sold only in carton quantities.

**Prix à l’unité, seulement vendu au carton plein.

mm 7 7 9 9 9 9 Item No. CLIP.0040.B CLIP.0050.B CLIP.0063.B CLIP.0075.B CLIP.0090.B CLIP.0110.B 2.80 3.40 4.20 6.70 9.20 10.80 da OD d1 _Price** Prix** mm 40 50 63 75 90 110 d2 H b h k mm 68 77 94 107 124 146 mm 58 69 84 126 143 163 Carton Quantity 10 10 10 10 10 10 mm 25 25 25 30 30 30 s mm 8 8 8 10 10 10 t mm – – – 109 125 145 z mm 1 1 1 3 3 3

Pipe Clips

Low Cost Retainer Type Product – CLIP

Grey PP*

Includes snap-on PVC retainer

Supports de Tuyau

À Bas Prix avec Retenue Produit – CLIP

PP Gris*

Retenue de PVC “snap-in” inclus

* Also available in black HDPE (high density polyethylene). Change B to PE in item number.

* Aussi disponible en PE (polyethylène noir. Changez B à PE dans le numero de produit.

**Prices are each, sold only in carton quantities.

**Prix à l’unité, seulement vendu au carton plein.

mm 43 47 57 64 73 85 mm 5.0 5.5 5.5 mm 14.5 14.5 17.5 17.5 17.5 17.5 kg 0.190 0.225 0.300 Weight Poids kg 0.30 0.38 0.52 0.94 1.23 1.52 Weight Poids

Price List AH08-1 10 55 Guardsman Road, Thornhill, Ontario, Canada, L3T 6L2

Tel: 905-889-7890 [email protected] Fax: 905-889-8553 www.chemline.com
