Unit - I
8086- PROCESSORS
In December 1970, Gilbert Hyatt filed a patent application entitled “Single Chip Integrated Circuit Computer Architecture”, the first basic patent on the microprocessor.
The microprocessor was invented in the year 1971 in the Intel labs. The first processor was a 4 bit processor and was called 4004.The following table gives chronologically the microprocessor revolution. Microprocess ors Year of Introduct ion Word Length Memory Addressi ng
Pins Clock Remarks
4004 1971 4 bits 1KB 16 750KHz Intel’s 1stP
8008 1972 8 bits 16KB 18 800KHz Mark-8 used
this; 1st computer for the home. 8080 1973 8 bits 64KB 40 2 MHz 6000trs, Altair-1st PC 8085 1976 8 bits 64KB 40 3-6 MHz Popular
8086 1978 16 bits 1 MB 40 5-10 MHz IBM PC, Intel
became one of fortune 500 companies. 8088 1980 8/16 bits 1MB 40 5-8MHz PC/XT 80186 1982 16 bits 1 MB 68 5-8MHz More a Microcontroller 80286 1982 16 bits 16 MB real, 4GBv 68 60-12.5MHz PC/AT, 15 million PC’s sold in 6 years 80386DX 1985 32 bits 4GB real, 64TBv 132 PGA 20-33MHz 2,75,000 transistors 80386SX 1988 16/32 16MB 100 20MHz 32b int 16b ext
bits real, 64TBv 80486DX 1989 32 bits 4 GB real, 64TBv 168 PGA 25-66MHz Flaot pt cop, Command line to point and click Pentium 1993 64 bits 4 GB, 16 KB cache 237 PGA 60-200 MHz 2 intr. At a time, Process real world data like sound, hand written and photo images.
Pentium Pro 1995 64 bits 64Gb,
256K/512 K L2 Cache
387
PGA 150MHz Speedy CAD
Pentium II 1997 64 bits 64Gb 242 400MHz Capture, edit &
share digital photos via Internet Pentium II Xeon 1998 64 bits 512k/1M/2M L2 cache 528 pins LGA 400MHz Workstations thriving on business applications Pentium III
Xeon 1999 64 bits 16 k L1data + 16 k L1 instr; 512 kB/1 MB/2 MB L2
370
PGA 1GHz e-commerceapplications
Pentium 4 2000 64 bits 514,864
KB 423PGA 1.3 - 2GHz 1.5 GHz,Professional quality movies, rendering 3D graphics.
Xeon 2001 64 bits 8 MB iL3
cache 3.33 GHz Choice ofoperating system
Itanium 2001 64 bits 2MB/ 4MB L3 cache 418 pins FCP GA 800 MHz Enabling e-commerce security transactions Itanium 2 2002 64 bits 1.5 – 9MB L3 cache 611 pins FCP GA 200 MHz Business applications
Centrino
mobile 2003 64 bits Mobile specific,increased battery
life. Pentium 4 processor extreme 2003 64 bits 2 MB L2 cache 423pins PGA 3.80 GHz Hyper threading technology, games Centrino M
(mobile) 2004 64 bits 90nm,2MB L2cache400MHz
power-system optimized system bus
Apart from Intel, Motorola, Zylog Corporation, Fairchild and National (Hitachi, Japan) are some of the other microprocessor manufacturers.
Microprocessors are used in all modern appliances, which are Intelligent, meaning that they are capable of different modes of working. For example an automatic washing machine has different wash options, one for woolen and the other for nylon etc., Also in a printing Industry right from type setting to page lay out to color photo scanning and printing and cutting and folding are also taken care of by microprocessors.
The applications of microprocessors can be sub divided into three categories. The first and most important one is the computer applications. The second one is the control application (micro controllers, embedded controllers etc.) and the third is in Communication (DSP processors, Cell phones etc.).
The basis of working of all the microprocessors is binary arithmetic and Boolean logic. The number system used is Hexadecimal (base 16) and the character code used is ASCII. Many assemblers are available to interface the machine code savvy processor to English language like programs of the users.(CP/M, MASM, TASM etc.).
For Games we have joysticks, electronic guns and touch screens. Nowadays laptop and palmtop computers are proliferating and in future nano computing, bio computing, molecular and optical computing also are contemplated.
Microprocessor Based Personal Computer System
Different Components of Computers
• Microprocessor – 8086, 8088, 80186, 80188, 80286, 80386, 80486, Pentium, Pentium Pro, Pentium II, Pentium III, Pentium IV
• Memory System – DRAM, SRAM, Cache, ROM, Flash Memory, EEPROM, SDRAM, RAMBUS
• I/O System – Printer, Serial communications, Floppy Disk Drive, Hard Disk Drive, Mouse, CD-ROM drive, Plotter, Keyboard, Monitor, Scanner, DVD, Pen Drive Summary of Simple Microcomputer Bus Operation
1. A microcomputer fetches each program instruction in sequence, decodes the instruction, and executes it.
2. The CPU in a microcomputer fetches instructions or reads data from memory by sending out an address on the address bus and a Memory Read signal on the control bus. The memory outputs the addressed instruction or data word to the CPU on the data bus. 3. The CPU writes a data word to memory by sending out an address on the address bus,
sending out the data word on the data bus, and sending a Memory write signal to memory on the control bus.
4. To read data from a port, the CPU sends out the port address on the address bus and sends an I/O Read signal to the port device on the control bus. Data from the port comes into the CPU on the data bus.
5. To write data to a port, the CPU sends out the port address on the address bus, sends out the data to be written to the port on the data bus, and sends an I/O Write signal to the port device on the control bus.
ADDRESS BUS CONTROL
BUS CONTROLBUS
INPUT DEVICE
OUTPUT DEVICE
I/O PORTS PROCESSINGCENTRAL UNIT (CPU)
MEMORY (RAM AND
ROM) DATA BUS
8086 Internal Block diagram (Intel Corp.)
The block diagram of 8086 is as shown. This can be subdivided into two parts, namely the Bus Interface Unit and Execution Unit. The Bus Interface Unit consists of segment registers, adder to generate 20 bit address and instruction prefetch queue.
Once this address is sent out of BIU, the instruction and data bytes are fetched from memory and they fill a First In First Out 6 byte queue.
Execution Unit:
The execution unit consists of scratch pad registers such as 16-bit AX, BX, CX and DX and pointers like SP (Stack Pointer), BP (Base Pointer) and finally index registers such as source index and destination index registers. The 16-bit scratch pad registers can be split into two 8-bit registers. For example, AX can be split into AH and AL registers. The segment registers and their default offsets are given below.
Segment Register Default Offset
CS IP (Instruction Pointer)
DS SI, DI
SS SP, BP
The Arithmetic and Logic Unit adjacent to these registers perform all the operations. The results of these operations can affect the condition flags.
Different registers and their operations are listed below: Register Operations
AX Word multiply, Word divide, word I/O
AL Byte Multiply, Byte Divide, Byte I/O, translate, Decimal Arithmetic AH Byte Multiply, Byte Divide
BX Translate
CX String Operations, Loops CL Variable Shift and Rotate
DX Word Multiply, word Divide, Indirect I/O
IP SR DI SI BP SP DX CX AX BX ES SS DS CS Instruction Pointer Code Segment Register
Data Segment Register Stack Segment Register Extra Segment Register
AH
Stack Pointer Register AL
BE BL
CE CL
DH DL
Break Pointer Register Source Index Register Destination Index Register
Status Register Code Segment (64Kb) Data Segment (64Kb) Stack Segment (64Kb) Extra Segment (64Kb) FFFFF16 00000016 8086/8088 MPU MEMORY
Generation of 20-bit Physical Address:
8086 flag register format
(a) : CARRY FLAG – SET BY CARRY OUT OF MSB (b) : PARITY FLAG – SET IF RESULT HAS EVEN PARITY (c) : AUXILIARY CARRY FLAG FOR BCD
(d) : ZERO FLAG – SET IF RESULT = 0 (e) : SIGN FLAG = MSB OF RESULT (f) : SINGLE STEP TRAP FLAG (g) : INTERRUPT ENABLE FLAG (h) : STRING DIRECTION FLAG (i) : OVERFLOW FLAG
(i) (h) (g) (f) (e) (d) (b) (c) (a) 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 U U U U 0F DF IF TF SF ZF U AF U PF U CF U= UNDEFINED BIT LOGICAL ADDRESS SEGMENT REGISTER 0000 ADDER
There are three internal buses, namely A bus, B bus and C bus, which interconnect the various blocks inside 8086.The execution of instruction in 8086 is as follows:
The microprocessor unit (MPU) sends out a 20-bit physical address to the memory and fetches the first instruction of a program from the memory. Subsequent addresses are sent out and the queue is filled upto 6 bytes. The instructions are decoded and further data (if necessary) are fetched from memory. After the execution of the instruction, the results may go back to memory or to the output peripheral devices as the case may be.
Real mode memory addressing
The segment registers have contents of 16-bits. Hence, 216= 64Kb of memory can be addressed by segment registers. Normally, the segment base register contains three zeroes, so that each segment can start from say E0000 to EFFFF. The segments namely code segment, data segment, stack segment and extra segment for a particular program can be contiguous, separate or in case of small programs overlapping even. i.e., for example, code segment is supposed to have 64Kb and in case of small programs data segment may be within the code segment.
Fig: One way four 64-Kbyte segment might be positioned within the 1-Mbyte address space
of an 8086 5FFFFH 70000H 7FFFFH FFFFFH PHYSICAL ADDRESS MEMORY
EXTRA SEGMENT BASE ES=7000H
HIGHEST ADDRESS TOP OF EXTRA SEGMENT
STACK SEGMENT BASE SS = 5000H
TOP OF CODE SEGMENT TOP OF STACK SEGMENT
CODE SEGMENT BASE CS=348AH
TOP OF DATA SEGMENT
BOTTOM OF DATA SEGMENT 64K 64K 64K 64K 50000H 4489FH 348A0H 2FFFFH 20000H
Fig: Addition of IP to CS to produce the physical address of the code byte (a) Diagram 3 4 8 A 0 4 2 1 4 3 8 A B 4 (b) Computation Segment Over Ride Prefix
SOP is used when a particular offset register is not used with its default base segment register, but with a different base register. This is a byte put before the OPCODE byte.
0 0 1 S R 1 1 0 SR Segment Register 00 ES 01 CS 10 SS 11 DS 348A0H 38AB4H 4489FH PHYSICAL ADDRESS MEMORY CODE BYTE
TOP OF CODE SEGMENT
START OF CODE SEGMENT CS=348AH IP=4214H CS IP + PHYSICAL ADDRESS HARDWIRED ZERO
Here SR is the new base register. To use DS as the new register 3EH should be prefix. Operand Register Default With over ride prefix
IP (Code address) CS Never
SP(Stack address) SS Never
BP(Stack Address) SS BP+DS or ES or CS
SI or DI(not including Strings) DS ES, SS or CS SI (Implicit source Address for
strings)
DS ”
DI (Implicit Destination Address for strings)
ES Never
Examples: MOV AX, DS: [BP], LODS ES: DATA1 S4 S3 Indications
0 0 Alternate data
0 1 Stack
1 0 Code or none
1 1 Data
Bus High Enable / Status BHE A0 Indications
0 0 Whole word
0 1 Upper byte from or to odd address 1 0 Lower byte from or to even address
1 1 None
Segmentation:
The 8086 microprocessor has 20 bit address pins. These are capable of addressing 220= 1Mega Byte memory.
To generate this 20 bit physical address from 2 sixteen bit registers, the following procedure is adopted.
The 20 bit address is generated from two 16-bit registers. The first 16-bit register is called the segment base register. These are code segment registers to hold programs, data segment register to keep data, stack segment register for stack operations and extra segment register to keep strings of data. The contents of the segment registers are shifted left four times with zeroes (0’s) filling on the right hand side. This is similar to multiplying four hex numbers by the base 16. This multiplication process takes place in the adder and thus a 20 bit number is generated. This is called the base address. To this a 16-bit offset is added to generate the 20-bit physical address.
Segmentation helps in the following way. The program is stored in code segment area. The data is stored in data segment area. In many cases the program is optimized and kept unaltered for the specific application. Normally the data is variable. So in order to test the program with a different set of data, one need not change the program but only have to alter the data. Same is the case with stack and extra segments also, which are only different type of data storage facilities.
Generally, the program does not know the exact physical address of an instruction. The assembler, a software which converts the Assembly Language Program (MOV, ADD etc.) into machine code (3EH, 4CH etc) takes care of address generation and location.
Sr. No 8088 80086
1. Its has only eight data lines. Therefore, it has AD0– AD7 and A8–A15signals.
It has sixteen data lines. Therefore it has AD0– AD15signals.
2. As data bus is 8-bit wide, it
does not have BHE signal. It has BHE signal to access higher byte. 3. It has 4 byte instruction queue.
Due to 8-bit data bus instruction fetching is slow and 4 bytes are sufficient for queue.
It has 6 byte instrucyion queue.
4. Its pin number 34 is SSO. It acts as S0in the minimum mode. In maximum mode, SSO pin is always high.
Its pin number 34 is BHE/S7. During T1(first clock cycle) BHE should be used to enable data on to the most significant byte of the data bus. During T2, T3and T4status of this pin is logic 0. In maximum mode, 8087 monitors this pin to identify the CPU as a 8088 or a 8086, and accordingly sets its own queue length to 4 or 6 bytes.
5. In minimum mode its pin 28 is
Addressing Modes
Addressing modes of 8086
When 8086 executes an instruction, it performs the specified function on data. These data are called its operands and may be part of the instruction, reside in one of the internal registers of the microprocessor, stored at an address in memory or held at an I/O port, to access these different types of operands, the 8086 is provided with various addressing modes (Data Addressing Modes).
Data Addressing Modes of 8086
The 8086 has 12 addressing modes. The various 8086 addressing modes can be classified into five groups.
A. Addressing modes for accessing immediate and register data (register and immediate modes).
B. Addressing modes for accessing data in memory (memory modes) C. Addressing modes for accessing I/O ports (I/O modes)
D. Relative addressing mode E. Implied addressing mode
8086 ADDRESSING MODES
A. Immediate addressing mode:
In this mode, 8 or 16 bit data can be specified as part of the instruction.
OP Code Immediate Operand Example 1 : MOV CL, 03 H
Moves the 8 bit data 03 H into CL Example 2 : MOV DX, 0525 H
Moves the 16 bit data 0525 H into DX
In the above two examples, the source operand is in immediate mode and the destination operand is in register mode.
A constant such as “VALUE” can be defined by the assembler EQUATE directive such as VALUE EQU 35H
Example : MOV BH, VALUE
Used to load 35 H into BH
B. Register addressing mode :
The operand to be accessed is specified as residing in an internal register of 8086. Fig. below shows internal registers, any one can be used as a source or destination operand, however only the data registers can be accessed as either a byte or word.
Register Byte (Reg 8) Operand sizesWord (Reg 16) Accumulator AL, AH Ax Base BL, BH Bx Count CL, CH Cx Data DL, DH Dx Stack pointer - SP Base pointer - BP Source index - SI Destination index - DI Code Segment - CS Data Segment - DS Stack Segment - SS Extra Segment - ES
Example 1 : MOV DX (Destination Register) , CX (Source Register) Which moves 16 bit content of CS into DX.
Example 2 : MOV CL, DL
Moves 8 bit contents of DL into CL MOV BX, CH is an illegal instruction.
* The register sizes must be the same. C. Direct addressing mode :
The instruction Opcode is followed by an affective address, this effective address is directly used as the 16 bit offset of the storage location of the operand from the location specified by the current value in the selected segment register.
The default segment is always DS.
The 20 bit physical address of the operand in memory is normally obtained as PA = DS : EA
But by using a segment override prefix (SOP) in the instruction, any of the four segment registers can be referenced,
PA = CS
DS : Direct Address
SS ES
The Execution Unit (EU) has direct access to all registers and data for register and immediate operands. However the EU cannot directly access the memory operands. It must use the BIU, in order to access memory operands.
In the direct addressing mode, the 16 bit effective address (EA) is taken directly from the displacement field of the instruction.
Example 1 : MOV CX, START
If the 16 bit value assigned to the offset START by the programmer using an assembler pseudo instruction such as DW is 0040 and [DS] = 3050.
Then BIU generates the 20 bit physical address 30540 H. The content of 30540 is moved to CL
The content of 30541 is moved to CH Example 2 : MOV CH, START If [DS] = 3050 and START = 0040
8 bit content of memory location 30540 is moved to CH. Example 3 : MOV START, BX
With [DS] = 3050, the value of START is 0040. Physical address : 30540
MOV instruction moves (BL) and (BH) to locations 30540 and 30541 respectively. Register indirect addressing mode :
The EA is specified in either pointer (BX) register or an index (SI or DI) register. The 20 bit physical address is computed using DS and EA.
Example : MOV [DI], BX
register indirect
If [DS] = 5004, [DI] = 0020, [Bx] = 2456 PA=50060.
The content of BX(2456) is moved to memory locations 50060 H and 50061 H. CS
PA = DS BX
SS = SI
ES DI
Based addressing mode: CS
PA = DS BX
SS : or + displacement
ES BP
when memory is accessed PA is computed from BX and DS when the stack is accessed PA is computed from BP and SS.
Example : MOV AL, START [BX] or
MOV AL, [START + BX] based mode EA : [START] + [BX]
PA : [DS] + [EA]
Indexed addressing mode: CS
PA = DS SI
SS : or + 8 or 16bit displacement
ES DI
Example : MOV BH, START [SI] PA : [SART] + [SI] + [DS] The content of this memory is moved into BH. Based Indexed addressing mode:
CS
PA = DS BX SI
SS : or + or + 8 or 16bit displacement
ES BP DI
Example : MOV ALPHA [SI] [BX], CL
If [BX] = 0200, ALPHA – 08, [SI] = 1000 H and [DS] = 3000 Physical address (PA) = 31208
8 bit content of CL is moved to 31208 memory address. String addressing mode:
The string instructions automatically assume SI to point to the first byte or word of the source operand and DI to point to the first byte or word of the destination operand. The contents of SI and DI are automatically incremented (by clearing DF to 0 by CLD instruction) to point to the next byte or word.
Example : MOV S BYTE
If [DF] = 0, [DS] = 2000 H, [SI] = 0500, [ES] = 4000, [DI] = 0300
Source address : 20500, assume it contains 38 PA : [DS] + [SI]
Destination address : [ES] + [DI] = 40300, assume it contains 45 After executing MOV S BYTE,
[40300] = 38
[SI] = 0501 incremented [DI] = 0301
C. I/O mode (direct) :
Port number is an 8 bit immediate operand. Example : OUT 05 H, AL
Outputs [AL] to 8 bit port 05 H
I/O mode (indirect):
OR OR
OR Example 1 : INAL, DX
If [DX] = 5040
8 bit content by port 5040 is moved into AL. Example 2 : IN AX, DX
Inputs 8 bit content of ports 5040 and 5041 into AL and AH respectively. D. Relative addressing mode:
Example : JNC START
If CY=O, then PC is loaded with current PC contents plus 8 bit signed value of START, otherwise the next instruction is executed.
E. Implied addressing mode:
Instruction using this mode have no operands. Example : CLC which clears carry flag to zero.
SINGLE INDEX
DOUBLE INDEX
Fig.3.1 : Summary of 8086 Addressing Modes Encoded in the instruction BX OR BP SI OR DI + + + + + CS 0000 PHYSICAL ADDRESS DS 0000 SS 0000 ES 0000 DISPLACEMENT Explicit in the instruction Assumed unless over ridden by prefix EU BIU BX OR BP OR SI OR DI
Special functions of general-purpose registers: AX & DX registers:
In 8 bit multiplication, one of the operands must be in AL. The other operand can be a byte in memory location or in another 8 bit register. The resulting 16 bit product is stored in AX, with AH storing the MS byte.
In 16 bit multiplication, one of the operands must be in AX. The other operand can be a word in memory location or in another 16 bit register. The resulting 32 bit product is stored in DX and AX, with DX storing the MS word and AX storing the LS word.
BX register : In instructions where we need to specify in a general purpose register the 16 bit effective address of a memory location, the register BX is used (register indirect).
CX register : In Loop Instructions, CX register will be always used as the implied counter. In I/O instructions, the 8086 receives into or sends out data from AX or AL depending as a word or byte operation. In these instructions the port address, if greater than FFH has to be given as the contents of DX register.
Ex : IN AL, DX
DX register will have 16 bit address of the I/P device Physical Address (PA) generation :
Generally Physical Address (20 Bit) = Segment Base Address (SBA) + Effective Address (EA) Code Segment :
Physical Address (PA) = CS Base Address + Instruction Pointer (IP) Data Segment (DS)
PA = DS Base Address + EA can be in BX or SI or DI Stack Segment (SS)
PA + SS Base Address + EA can be SP or BP Extra Segment (ES)
PA = ES Base Address + EA in DI
Instruction Format :
The 8086 instruction sizes vary from one to six bytes. The OP code occupies six bytes and it defines the operation to be carried out by the instruction.
Register Direct bit (D) occupies one bit. It defines whether the register operand in byte 2 is the source or destination operand.
D=1 Specifies that the register operand is the destination operand. D=0 indicates that the register is a source operand.
Data size bit (W) defines whether the operation to be performed is an 8 bit or 16 bit data W=0 indicates 8 bit operation
7 2 1 0 7 6 5 4 3 2 1 0
Opcode D W MOD REG R/M Low Disp/DATA High Disp/DATA
The second byte of the instruction usually identifies whether one of the operands is in memory or whether both are registers.
This byte contains 3 fields. These are the mode (MOD) field, the register (REG) field and the Register/Memory (R/M) field.
MOD (2 bits) Interpretation
00 Memory mode with no displacement follows except for 16 bit displacement when R/M=110
01 Memory mode with 8 bit displacement 10 Memory mode with 16 bit displacement 11 Register mode (no displacement)
Register field occupies 3 bits. It defines the register for the first operand which is specified as source or destination by the D bit.
REG W=0 W=1 000 AL AX 001 CL CX 010 DL DX 011 BL BX 100 AH SP 101 CH BP 110 DH SI 111 BH DI
The R/M field occupies 3 bits. The R/M field along with the MOD field defines the second operand as shown below.
Byte 1 Byte 2 OR
Register Operand/Register to use EA Calculation
Register Operand/Extension of opcode Register mode/Memory mode with displacement length
Word/byte operation
Direction is to register/from register Operation code DIRECT ADDRESS LOW BYTE DIRECT ADDRESS HIGH BYTE
MOD 11
R/M W=0 W=1 000 AL AX 001 CL CX 010 DL DX 011 BL BX 100 AH SP 101 CH BP 110 DH SI 111 BH DIEffective Address Calculation
R/M MOD=00 MOD 01 MOD 10
000 (BX) + (SI) (BX)+(SI)+D8 (BX)+(SI)+D16
001 (BX)+(DI) (BX)+(DI)+D8 (BX)+(DI)+D16
010 (BP)+(SI) (BP)+(SI)+D8 (BP)+(SI)+D16
011 (BP)+(DI) (BP)+(DI)+D8 (BP)+(DI)+D10
100 (SI) (SI) + D8 (SI) + D16
101 (DI) (DI) + D8 (DI) + D16
110 Direct address (BP) + D8 (BP) + D16
111 (BX) (BX) + D8 (BX) + D16
In the above, encoding of the R/M field depends on how the mode field is set. If MOD=11 (register to register mode), this R/M identifies the second register operand.
MOD selects memory mode, then R/M indicates how the effective address of the memory operand is to be calculated. Bytes 3 through 6 of an instruction are optional fields that normally contain the displacement value of a memory operand and / or the actual value of an immediate constant operand.
Example 1 : MOV CH, BL
This instruction transfers 8 bit content of BL
Into CH
The 6 bit Opcode for this instruction is 1000102D bit indicates whether the register specified by the REG field of byte 2 is a source or destination operand.
D=0 indicates BL is a source operand. W=0 byte operation
In byte 2, since the second operand is a register MOD field is 112. The R/M field = 101 (CH)
Register (REG) field = 011 (BL)
Hence the machine code for MOV CH, BL is 10001000 11 011 101
Byte 1 Byte2
Example 2 : SUB Bx, (DI)
This instruction subtracts the 16 bit content of memory location addressed by DI and DS from Bx. The 6 bit Opcode for SUB is 0010102.
D=1 so that REG field of byte 2 is the destination operand. W=1 indicates 16 bit operation. MOD = 00
REG = 011 R/M = 101
The machine code is 0010 1011 0001 1101
2 B 1 D
2B1D16
Summary of all Addressing Modes
Example 3 : Code for MOV 1234 (BP), DX
Here we have specify DX using REG field, the D bit must be 0, indicating the DX is the source register. The REG field must be 010 to indicate DX register. The W bit must be 1 to indicate it is a word operation. 1234 [BP] is specified using MOD value of 10 and R/M value of 110 and a displacement of 1234H. The 4 byte code for this instruction would be 89 96 34 12H.
Opcode D W MOD REG R/M LB displacement HB displacement
100010 0 1 10 010 110 34H 12H
Example 4 : Code for MOV DS : 2345 [BP], DX
Here we have to specify DX using REG field. The D bit must be o, indicating that Dx is the source register. The REG field must be 010 to indicate DX register. The w bit must be 1 to indicate it is a word operation. 2345 [BP] is specified with MOD=10 and R/M = 110 and displacement = 2345 H.
Whenever BP is used to generate the Effective Address (EA), the default segment would be SS. In this example, we want the segment register to be DS, we have to provide the segment override prefix byte (SOP byte) to start with. The SOP byte is 001 SR 110, where SR value is provided as per table shown below.
MOD / R/M Memory Mode (EA Calculation) Register Mode
00 01 10 W=0 W=1
000 (BX)+(SI) (BX)+(SI)+d8 (BX)+(SI)+d16 AL AX
001 (BX) + (DI) (BX)+(DI)+d8 (BX)+(DI)+d16 CL CX
010 (BP)+(SI) (BP)+(SI)+d8 (BP)+(SI)+d16 DL DX
011 (BP)+(DI) (BP)+(DI)+d8 (BP)+(DI)+d16 BL BX
100 (SI) (SI) + d8 (SI) + d16 AH SP
101 (DI) (DI) + d8 (DI) + d16 CH BP
110 d16 (BP) + d8 (BP) + d16 DH SI
SR Segment register
00 ES
01 CS
10 SS
11 DS
To specify DS register, the SOP byte would be 001 11 110 = 3E H. Thus the 5 byte code for this instruction would be 3E 89 96 45 23 H.
SOP Opcode D W MOD REG R/M LB disp. HD disp.
3EH 1000 10 0 1 10 010 110 45 23
Suppose we want to code MOV SS : 2345 (BP), DX. This generates only a 4 byte code, without SOP byte, as SS is already the default segment register in this case.
Example 5 :
Give the instruction template and generate code for the instruction ADD OFABE [BX], [DI], DX (code for ADD instruction is 000000)
ADD OFABE [BX] [DI], DX
Here we have to specify DX using REG field. The bit D is 0, indicating that DX is the source register. The REG field must be 010 to indicate DX register. The w must be 1 to indicate it is a word operation. FABE (BX + DI) is specified using MOD value of 10 and R/M value of 001 (from the summary table). The 4 byte code for this instruction would be
Opcode D W MOD REG R/M 16 bit disp. =01 91 BE FAH
000000 0 1 10 010 001 BEH FAH
Example 6 :
Give the instruction template and generate the code for the instruction MOV AX, [BX] (Code for MOV instruction is 100010)
AX destination register with D=1 and code for AX is 000 [BX] is specified using 00 Mode and R/M value 111
It is a word operation
Opcode D W Mod REG R/M =8B 07H
100010 1 1 00 000 111
Questions :
1. Write a note on segment registers. 2. List the rules for segmentation.
3. What are the advantages of using segmentation? 4. What do you mean by index registers?
5. What is the function of SI and DI registers?
6. Explain the addressing modes of 8086 with the help of examples. 7. What do you mean by segment override prefix?
Unit - 2
INSTRUCTION SET OF 8086
The instructions of 8086 are classified into SIX groups. They are: 1. DATA TRANSFER INSTRUCTIONS
2. ARITHMETIC INSTRUCTIONS 3. BIT MANIPULATION INSTRUCTIONS 4. STRING INSTRUCTIONS
5. PROGRAM EXECUTION TRANSFER INSTRUCTIONS 6. PROCESS CONTROL INSTRUCTIONS
1.DATA TRANSFER INSTRUCTIONS
The DATA TRANSFER INSTRUCTIONS are those, which transfers the DATA from any one source to any one destination. The data’s may be of any type. They are again classified into four groups. They are:
GENERAL – PURPOSE BYTE OR
WORD TRANSFER INSTRUCTIONS PORT TRANSFER INSTRUCTIONSIMPLE INPUT AND OUTPUT TRANSFER INSTRUCTIONSPECIAL ADDRESS FLAG TRANSFERINSTRUCTIONS MOV PUSH POP XCHG XLAT IN OUT LEA LDS LES LAHF SAHF PUSHF POPF 2.ARITHMETIC INSTRUCTIONS
These instructions are those which are useful to perform Arithmetic calculations, such as addition, subtraction, multiplication and division. They are again classified into four groups. They are:
ADDITION INSTRUCTIONS SUBTRACTION
INSTRUCTIONS MULTIPLICATIONINSTRUCTIONS DIVISION INSTRUCTIONS ADD ADC INC AAA DAA SUB SBB DEC NEG CMP AAS DAS MUL IMUL AAM DIV IDIV AAD CBW CWD
3.BIT MANIPULATION INSTRUCTIONS
These instructions are used to perform Bit wise operations.
LOGICAL INSTRUCTIONS SHIFT INSTRUCTIONS ROTATE INSTRUCTIONS NOT AND OR XOR TEST SHL / SAL SHR SAR ROL ROR RCL RCR 4. STRING INSTRUCTIONS
The string instructions function easily on blocks of memory. They are user friendly instructions, which help for easy program writing and execution. They can speed up the manipulating code. They are useful in array handling, tables and records.
STRING INSTRUCTIONS REP
REPE / REPZ
REPNE / REPNZ MOVS / MOVSB / MOVSW COMPS / COMPSB / COMPSW SCAS / SCASB / SCASW LODS / LODSB / LODSW STOS / STOSB / STOSW
5.PROGRAM EXECUTION TRANSFER INSTRUCTIONS
These instructions transfer the program control from one address to other address. (Not in a sequence). They are again classified into four groups. They are:
UNCONDITIONAL TRANSFER
INSTRUCTIONS CONDITIONAL TRANSFERINSTRUCTIONS ITERATION CONTROLINSTRUCTIONS INSTRUCTIONSINTERRUPT CALL RET JMP JA / JNBE JAE / JNB JB / JNAE JBE / JNA JC JE / JZ JG / JNLE JGE / JNL JL / JNGE JLE / JNG JNC JNE / JNZ JNO JNP / JPO JNS JO JP / JPE JS LOOP LOOPE / LOOPZ LOOPNE / LOOPNZ JCXZ INT INTO IRET
6.PROCESS CONTROL INSTRUCTIONS
These instructions are used to change the process of the Microprocessor. They change the process with the stored information. They are again classified into Two groups. They are:
FLAG SET / CLEAR INSTRUCTIONS EXTERNAL HARDWARE SYNCHRONIZATION INSTRUCTIONS STC CLC CMC STD CLD STI CLI HLT WAIT ESC LOCK NOP Addition:
There are two instructions ADD and ADC Register Addition:
ADD AL,BL AL=AL+BL ADD CX,DI CX=CX+DI ADD CL,10H CL=CL+10
ADD [BX],AL the contents of AL are added with the contents of a memory location addressed by BX and the result is stored in the same memory location
Example
ADD AL,BL AL=10H BL=30H the result AL=40H
ADD AX,[SI+2] the word content of the data segment memory location addressed by sum of SI+2 is added with AX and the result is stored in AX
Example
AX=1234H SI=2000 SI+2=2002 and let the word stored in memory location 2002 be 1122H The result AX=2356H
ADD BYTE PTR [DI],3 –3 is added to the byte contents of the data segment memory location addressed by DI
Example
DI=2000 and the contents of that memory location is 11H
The contents of address 2000 will be 14H after the execution of this instruction
The contents of the flag register change after the addition operation. The flags affected are SIGN,CARRY,ZERO, AUX CARRY,PARITY,OVERFLOW
The INTR,TRAP and other flags not affected.
Immediate Addition
An 8 bit immediate data is added. Example
MOV AL,10H ADD AL,30H The result AL=40H
Memory to Register addition
ExampleMOV AX,0 ADD AX,DI ADD AX,DI+1
Let DI=2000 the contents of this memory location is 22H After first add AX will have 22+0=22H
Then DI+1=2001 let the contents be 11H
The result will be 33H
Array addition The offset address of the array is moved to the SI or DI register Example
MOV AL,0
MOV SI,OFFSET of Array ADD AL,[SI] ADD AL,[SI+2] ADD AL,[SI+4] Array Offset addr 2000 10H 2001 11H 2002 22H 2003 33H 2004 44H
After first add the contents AL will be 0+10=10H After the second add instruction AL will be 10+22=32H After the third add instruction AL will be 32+44=76H
Increment addition
INC adds a 1 to a register or a memory location used for memory increments Example
INC AX
This instruction adds one to the contents ox AX let Ax=1234H the result will be AX=1235H INC BYTE PTR [DI]
This instruction adds one to the byte contents of the data segment location addressed by DI
Addition with carry
ADC adds the bit in carry flag to the operand data.
Example
ADC AL,BH AL=AL+BH+CARRY
ADC CX,AX CX=CX+AX+CARRY
ADC BX,[BP+2] the word contents of the stack segment memory location addressed by BP+2 is added to BX with carry and the result is stored in BX.
Subtraction
Many forms of subtraction appears to use with any addressing mode 8 16 and 32 bit data SUB
SBB subtract with borrow Register Subtraction: SUB AL,BL AL=AL-BL
SUB CL,10H CL=CL-10 The carry flag holds the borrow.
Decrement
A 1 is subtracted from the register or the memory location. Example
DEC AX
DEC BYTE PTR [DI] DEC CL
DEC BL
Subtracts 1 to from a register or a memory location CMP
This changes only the flag the destination operand never changes This instruction is usually followed by conditional jump instructions and tests the condition against the flags
Multiplication
The multiplication is performed on bytes words or double words and can be a signed integer or unsigned integer MUL: unsigned IMUL: signed Flags CARRY,OVERFLOW 8 Bit multiplication Example MOV BL,05H MOV AL,10H MUL BL The multiplicand is in AL
The multiplier is in BL (even a memory location can be used) 8 Bit multiplication
Example
IMUL BYTE PTR [BX]
AL is multiplied by the byte contents of the data segment memory location addressed by BX the signed product is placed in AX
For signed multiplication the product is in true binary form if positive and in two’s complement form if negative
Example
AL 00000010 BL 10000100 AL contains +2 and BL contains -4 IMUL BL
The product is -8
The product is in two’s complement form stored in AX AX 11111000
Division DIV,IDIV
The dividend is always a double width dividend that is divided by the operand An 8 bit division devides a 16 bit number by a 8 bit number
Errors: Divide by zero,devide overflow
AX register stores the dividend that is divided by contents of any 8 bit register or memory location.
the Quotient(result) moves to AL and AH has the remainder.
For signed division the remainder always assumes sign of dividend and is an integer AX=0010H equivalent to +16
BL=FDH equivalent to -3 DIV BL
AL=05H and AH=-1 11111111H AX=1111111100000101H
AX=0010H equivalent to +16 BL=FDH equivalent to -3 DIV BL
AL=-5 11111011 and AH=1 AX=0000000111111011H BCD Arithmetic:
The microprocessor allows manipulation of BCD and ASCII data BCD used in Cash registers and ASCII used by many programs There are two instructions
DAA decimal adjust after addition DAS decimal adjust after subtraction
Both instructions correct the result. The BCD number is stored as packed form 2 digits/byte and if unpacked form means 1 digit/byte it functions with AL only.
DAA decimal adjust after addition The result is in AL
The Logic of this instruction If lower nibble>9 or AF=1 add 06
After adding 06 if upper nibble>9 or CF=1 add 60 DAA instruction follows ADD or ADC
Example1
ADD AL,CL DAA
Let AL=53 and CL=29 AL=53+29
AL=7C
AL=7C+06 (as C>9) AL=82
Let AL=73 CL=29 AL=9C
AL=9C+06 (as C>9) AL=A2
AL=A2+60=02 and CF=1
The instruction affects AF,CF,PF and ZF Example3 MOV DX,1234H MOV BX,3099H MOV AL,BL ADD AL,DL DAA MOV AL,BH ADC AL,DH DAA MOV CH,AL BL=99H DL=34H 99+34=CD AL=CD+6(D>9) AL=D3 AL=D3+60(D>9) AL=33 and CF=1 BH=30 DH=12 AL=30+12+CF AL=43
DAA does not do anything The result is placed in CX=4333 DAS instruction follows subtraction The result is in AL
Logic of this instruction
If lower nibble>9 or AF=1 subtract 06
After subtracting 06 if upper nibble>9 or CF=1 add 60 The instruction affects AF,CF,PF and ZF
Example1 SUB AL,BH DAS
Let AL=75 BH=46 AL=75-46=2F AF=1
AL=2F-6(F>9) AL=29 Example 2 SUB AL,CH DAS AL=38 CH=61 AL=38-61=D7 CF=1(borrow) AL=D7-60(D>9) AL=77 CF=1(borrow) Example 3 MOV DX,1234H MOV BX,3099H MOV AL,BL SUB AL,DL DAS MOV CL,AL MOV AL,BH SBB AL,DH DAS MOV CH,AL AL=99-34=65
DAS will not have affect AL=30-12=1E
AL=1E-06(E>9) AL=18
The result is 1865 placed in CX ASCII Arithmetic
Functions with ASCII coded numbers The numbers range from 30-39H for 0-9 AAA
AAD AAM
AAS use AX as source and destination AAA
Example
add 31H and 39H the result is 6AH it should have been 10 decimal which is 31H and 30H AAA is used to correct the answer
AAA instruction examines the lower 4 bits of AL for valid BCD numbers and checks AF=0 sets the 4 high order bits to 0
AH cleared before addition
If lower digit of AL is between 0-9 and AF=1 06 is added The upper 4 digits are cleared and incremented by 1
If the lower value of the lower nibble is greater than 9 then increment AL by 06 AH by 1 AF and CF set
The higher 4 bits of AL are cleared to 0 AH modified
To get the exact sum add 3030H to AX AAS
Correct result in AL after subtracting two unpacked ASCII operands The result is in unpacked decimal format
If the lower 4 bits of AL are>9 or if AF=1 then AL=AL-6 and AH=AH-1 CF and AF set otherwise CF and AF set to 0 no correction
r
esult the upper nibble of AL is 00 and the lower nibble may be any number from 0-9 AAMFollows multiplication instruction after multiplying two unpacked BCD numbers Converts the product available in AL into unpacked BCD
Lower byte of result is in AL and upper in AH
Example
let the product is 5D in AL D>9 so add 6 =13H
LSD of 13H is lower unpacked byte
Increment AH, AH=5+1=6 upper unpacked byte After execution AH=06 and AL=03
MOV AL,5 MOV CL,5 MUL CL AAM
Accomplishes conversion by dividing AX by 10
Benefit of AAM –converts from binary to unpacked BCD use of AAM for conversion
XOR DX,DX MOV CX,100 DIV CX AAM ADD AX,3030H XCHG AX,DX AAM ADD AX,3030H
AAD
Appears before division
requires AX to contain two digit unpacked BCD number(not ASCII) before executing
After adjusting AX with AAD it is divided by an unpacked BCD number to generate a single digit result in AL with remainder in AH
Example .MODEL .CODE .STARTUP MOV AL,48H MOV AH,0 AAM ADD AX,3030H MOV DL,AH MOV AH,2 PUSH AX INT 21H POP AX MOV DL,AL INT 21H .EXIT END Logic instructions AND OR Exclusive OR NOT TEST
The above instructions perform bitwise operation and the src and destination could be register or memory location. Their function is same as logic opeartions
JUMP Group of Instructions Introduction:
• In almost any meaningful program, we need to alter the sequential flow of execution. • Examples:
Instruction at reset CS:IP: At rest, 8086 begins execution at the address FFFF:0000H (absolute address of FFFF0H). There are only 16 bytes from this location to the end of the memory space (FFFFH)! It is unlikely that any meaningful program can be written within this space. Thus the instruction at this reset location is usually a “long jump”
instruction that transfers control to some suitable lower address based on the available memory.
A Sorting Program: A comparison-based sorting program would need to swap or not swap two elements based on the outcome of the comparison of the two elements. This would mean that we need an instruction to “conditionally jump” to some other location in the program.
Any number of such examples can be given to illustrate the need for instructions that alter the linear flow of control, either unconditionally or conditionally.
• Unconditional and Conditional Jump Instructions allow such a control over the execution flow.
Unconditional Jump:
• No testing of any flags is involved in deciding whether a jump is to be executed or not. • Control transfer occurs always.
• This is illustrated in the following figure:
Unconditional Jump: Example
Before:
CS=FFFF; IP=0000
After:
CS=F000; IP=8000
FFFF0 EA
00
80
00
F0
F8000
Unconditionally Jump hereB8
00
01
Target
Location
The instructions used for such unconditional jumps are discussed in detail later. Conditional Jump:
• Values of one or more flags are used in deciding whether a jump is to be executed or not. • Thus, a jump may or may not occur depending on the values of such flag bits
This idea is illustrated in the following figure:
Conditional JUMP: Example
CMP AX,BX JE LAB1 MOV BX,1 … … LAB1: MOV BX,0 … …Test the Z flag
Control is transferred here only if Z = 1. A conditional Jump. Test fails i.e Z=0 No jump; Execution continues with the next sequential instruction.
Target location
The instructions used for such conditional jumps are discussed in detail later. Unconditional Jump Instructions:
• Unconditionally transfer control to an instruction located else where. • 3 different instructions are available for such unconditional jumps.
• All have similar behavior; but differ in where the target instruction is allowed to be and consequently, the instruction lengths also differ. And that is the main advantage.
• The 3 forms are:
Short Jump: Target location must be within -128 to +127 bytes from the address following the Jump instruction, i.e current IP. In this case, there is no change in the CS value. Only IP is changed
Near Jump: Target location must be within -32768 to +32767 bytes from the address following the Jump instruction, i.e current IP. In this case also, there is no change in the CS value. Only IP is changed
Far Jump: Target location can be any where in the memory space. In this case, CS as well as IP is changed.
Intra-Segment Jump Instructions:
• Both Short Jump and Near Jump are called intra-segment jumps also because in both the cases, there is no change in the CS value and only IP is changed. In other words, the jump is to a location that is within the same code segment.
• For these jumps, the target IP value is not specified as absolute value. Instead, displacement (relative distance) from the current IP is specified.
• Thus both are relative jumps. (Called Relative Program Memory Addressing in earlier sessions)
• Jump can be forward (to a higher address) or backwards (to a lower address). • So, displacement must be a signed number (can be positive or negative). • Short and Near Jumps differ in the way the displacement is specified. Short Jump Instruction:
• Specifies one byte displacement. It is sign-extended to 16 bits and added to current IP to get new IP.
• Displacement can be -128 to +127
• This instruction occupies 2 bytes; the first byte specifies the opcode and the second byte specifies the relative displacement as a signed 8-bit quantity. The format is shown below:
A short jump instruction with positive relative displacement is illustrated in the following figure:
Short Jump Instruction
10000 10001
EB1A
CS = 1000 H ; IP = 0002 H (Address following the JMP instruction)
Displacement = 1A H = 0001 1010 Sign Extend = 001A H
New IP = 0002 + 001A = 001C H Branch to 1000:001C
(+ve displacement; Forward Jump) 10002
1001C Jmp Target
Opcode
Displacement
A similar situation but with a negative relative displacement is illustrated in the following figure:
Short Jump Instruction
10003
10004
EB
F2
CS = 1000 H ; IP = 0012 H (Address
following the JMP instruction)
Displacement = F2 H = 1111 0010
Sign Extend = FFF2 H
New IP = 0012 + FFF2 = 0004 H
(ignoring the carry out)
Branch to 1000:0004
(-ve displacement; Backward Jump)
10005
10011
10012
10010
Jmp Target
• In a typical Assembly Language Program, we use labels for branch targets and the Assembler will automatically compute the displacement.
• We can force Short Jump to be assembled using the SHORT directive.
• Anyway, most Assemblers choose the short form if possible (that is, if the displacement is in the range of -128 to +127)
• A program illustrating the Short Jump instruction is shown below:
XOR BX, BX ST1: MOV AX, 1
ADD AX, BX
JMP SHORT NXT5 ; assume that the forward displacement <= 127 ; some instructions
NXT5: MOV BX, AX
JMP ST1 ; assume that the backward displacement <= 128
• Generally labels are used to denote branch targets.
• However, it is also allowed to directly specify the target as $ + displacement ($ stands for current IP)
• Example: JMP $ + 2 jumps over the next 2 memory locations following the JMP instruction. Thus if the above instruction starts at 1000:0010, the after the jump, control is transferred to the instruction at 1000: 0014
Near Jump Instruction:
This is quite similar to Short Jump except that the displacement is specified as 16 – Bit signed integer rather than as 8-bit integer.
• Target range is thus -32768 to +32767.
• Target can be any where in the current code segment
• Instruction is 3 – Byte long. The first byte specifies the opcode and the next two bytes specify the displacement. The format is shown in the following figure:
A near jump instruction with positive relative displacement is illustrated in the following figure:
Near Jump Instruction
10000
10001
E9
1A
CS = 1000 H ; IP = 0003 H (Address
following the JMP instruction)
Displacement = 201A H
New IP = 0003 + 201A = 201D H
Branch to 1000:201D
(+ve displacement; Forward Jump)
10002
1201D
Jmp Target20
10003
A similar situation with a negative displacement is shown in the following figure:
Opcode
Displacement
Near Jump Instruction
10004
10005
E9
F2
CS = 1000 H ; IP = 0013 H (Address
following the JMP instruction)
Displacement = FFF2 H
New IP = 0013 + FFF2 = 0005 H
(ignoring the carry out)
Branch to 1000:0005
(-ve displacement; Backward Jump)
10006
10011
10012
10010
Jmp TargetFF
An Assembly Language Program illustrating Near Jump instruction is shown below:
XOR BX, BX ST1: MOV AX, 1 ADD AX, BX JMP NXT5 ; Some instructions NXT5: MOV BX, AX
The above program is quite similar to Short Jump Program listed earlier except that the
displacement toNXT5is assumed to be greater than 127 and hence the instructionJMP NXT5
is assembled as Near Jump.
Inter-Segment Jump Instruction:
• FAR Jump is the only inter-segment jump instruction. It is called inter-segment because the target location can be to any other code segment! Thus it is possible that change occurs in the IP value as well as in the CS value.
• Target is directly specified as new CS:IP.
• This instruction is 5 – Byte long. The first byte specifies the opcode, the next 2 bytes specify the new IP value and the last 2 bytes specify the new CS value. The format is shown in the following figure:
An example illustrating the far jump is shown in the following figure:
Inter-Segment Jump Instruction
10003
10004
00
00
Before Far Jump:
CS = 2000 H ; IP = 0015 H (Address
following the JMP instruction)
After the Far Jump:
New CS:IP = 1000:0004 H
Branch to 10004 H
10005
20013
20014
20012
Jmp Target10
EA
04
20011
20010
• In the ALP, we can use a label with FAR PTR directive. • Or, we can use a label that is defined as FAR LABEL.
(A label can be FAR only if it is external to the current code segment. So, it is preceded by EXTRN directive.)
• In such cases, the Linker will fill the CS and IP values at the link time. • An ALP showing the far jump is shown below:
EA
Low
Byte
Low
Byte
Low
Byte
Low
Byte
IP
CS
EXTRN L1:FAR ST1: MOV AX, 1 … … … JMP FAR PTR ST1 … … … … … … JMP L1
Jump with Register Operands:
• A 16-Bit register may be used as the operand for the jump instruction. (Indirect Jump) • Contents of the register are transferred directly into IP (no concept of relative
displacement).
• This option is available for Near Jump only. • Example: Assume BX = 0080H
After the execution ofJMP BXinstruction, the control is transferred to the address 0080H in the current code segment.
Indirect Jump Using Index:
• Uses [] form of addressing to directly access a table of jump addresses.
• FAR PTR directive indicates a far jump ( jump table is assumed to contain double words giving CS, IP values)
• Otherwise a near jump is indicated. ( jump table is assumed to contain words giving IP values)
• This form is some times called Double Indirect Jump.
• Example:JMP TABLE [SI]
Fetch the word, using indexed addressing, at the offset ofTABLE [SI]from the current code segment and copy that value into IP. (Near Jump)
• Example:JMP FAR PTR [SI]
Fetch the double word, using indexed addressing, at the offset of[SI]from the current code segment and copy the values into IP and CS.
Conditional Jump
• Conditional jumps are always short jumps (relative displacement is -128 to +127). • Based on the values of one or more flags, jump to target address may occur or execution
may continue with the next sequential instruction.
• Usually preceded by instructions like CMP, SUB, TEST, AND etc which affect the flags. Example: CMP AX, BX JZ LAB1 MOV AX, BX LAB1:MOV CX, AX … … …
• In the above program, equality of the operands is tested based on the Z flag.
• Conditional jumps following general relative magnitude comparison are more complicated. Consider the comparison of FEH with 1AH. Is FEH > 1AH ?
The answer depends on how we interpret the numbers!
• Interpreted as Unsigned integers,0FE H = 254in decimal and1A H = 170in decimal. Thus 0FE H > 1A H is true.
• Interpreted as Signed integers using 2’s Complement system,0FE H = -2in Decimal and1A H = 170Decimal. Thus 0FE H > 1A H is false!
• Thus, we have one set of conditional jump instructions that are to be used if the numbers are to be interpreted as Unsigned Integers and another set of conditional jump instructions that are to be used if the numbers are to be interpreted as Signed Integers. • After comparison of Unsigned integers:
Mnemonic Condition Operation
JA Z=0 and C=0 Jump if above
JAE C=0 Jump if above or equal
JB C=1 Jump if below
• After comparison of Signed integers:
Mnemonic Condition Operation
JG Z=0 and S=O Jump if greater than
JGE S=O Jump if greater or equal
JL S< >O Jump if less than
JLE Z=1 or S< >O Jump if less or equal
(Both S and O Flags are required to test the condition when comparing signed numbers!)
• After comparison of Signed or Unsigned integers:
Mnemonic Condition Operation
JE or JZ Z=1 Jump if equal or Jump if Zero
JNE or JNZ Z=0 Jump if not equal or Jump if not Zero
• Alternative, less often used mnemonics also exist. JA same as JNBE JG same as JNLE
JAE same as JNB JGE same as JNL JB same as JNAE JL same as JNGE JBE same as JNA JLE same as JNG
• Other Conditional Jump Instructions:
Mnemonic Condition Operation
JC C=1 Jump if carry set
JNC C=0 Jump if no carry
JO O=1 Jump if overflow
JNO O=0 Jump if no overflow
JS S=1 Jump if sign is set
JNS S=0 Jump if no sign
• Some more Conditional Jump Instructions:
Mnemonic Condition Operation
JNP or JPO P=0 Jump if no parity or Jump if parity is odd
JCXZ CX = 0 Jump if CX = 0
(Note that the last instruction, JCXZ is some what different from the rest in the sense that it tests the contents of CX register rather than flags. This instruction, generally used in loops, is illustrated in later sessions. Programs illustrating other conditional jump instructions are also discussed in later sessions.)
LOOP Instruction:
• Program loops are quite common. Most of the counting loops have a typical structure that is shown below:
MOV CX, 10H ; Initialize the count that determines the number of ; times the loop is to be executed.
Start1: Instructions constituting the loop body DEC CX ; Decrement counter JNZ Start1 ; Repeat if not over
If the pair of instructions that test whether the loop body is to be executed again or not, that is the instructions,DEC CX and JNZ Start1,could be combined in to one instruction, we would get more elegant and clearer program.
TheLOOPinstruction does so combine the above pair of instructions.
Thus the single instruction:
LOOP LAB1
is equivalent in effect to the two instructions:
DEC CX JNZ LAB1
Conditional LOOP Instructions:
• These instructions are similar to LOOP instruction except that equality (Z flag) is also tested. This allows a loop to be controlled by a count as well as a comparison test (like in the case of String instructions).
• There are two such instructions.
• LOOPE(Loop While Equal) orLOOPZ
• LOOPNE(Loop While Not Equal) or LOOPNZ
Exit the loop if the condition is equal or if CX decrements to 0.
ESC Instruction
• This instruction is related to 8087 Numeric Data Coprocessor. Details of 8087 are discussed in later sessions. Briefly, 8087 provides support for floating point operations and works as a coprocessor to 8086. It
– Shares Pin bus with 8086.
– Implements floating point arithmetic – and Has its own instruction set
• The program has instructions for 8086 as well as 8087. How does 8087 know the instruction is for itself? The solution to this problem is the ESC instruction.
• ESC indicates that it is 8087 instruction. Opcode has 11011 as the higher-order 5 bits. Thus ESC is never used by itself.
• Generated by Assembler automatically when 8087 mnemonic is used! Consequently, ESC is never coded directly by the programmer.
WAIT Instruction • Monitors the TEST/ pin of 8086.
• At the time of executing this instruction, if
TEST/ pin is LOW , there is no effect; execution simply continues with the next instruction. However, if
TEST/ is HIGH , then 8086 waits in an “idle” state until TEST/ returns to LOW. • TEST/ is sampled during leading edge of CLK in each clock cycle during “waiting”. • This instruction is generally used in conjunction with 8087.
• 8086 and 8087 can execute in parallel (concurrently)
• WAIT instruction allows synchronization between the concurrently executing 8086 and 8087.
• When 8086 needs the “result” from 8087, it executes the WAIT instruction. • TEST/ pin of 8086 is connected to the BUSY pin of 8087.
• When 8087 is busy executing its instruction, it sets its BUSY pin = HIGH. Thus TEST/ of 8086 will also be HIGH. This forces 8086 to “wait” for the completion of 8087 activity.
• When 8087 is not executing its instruction, its BUSY pin = LOW and thus the TEST/ of 8086 will also be LOW. This allows 8086 to continue its execution.
• In this manner, synchronization between 8086 and 8087 is achieved. • More on this topic in the session on 8087.
NOP Instruction • As the name implies, it is a no operation instruction! • Takes a short time to execute; otherwise no effect.
• Used in early days to provide for manual code patches. Some NOP instructions would be written every 100 bytes or so. When code was to be patched, the space occupied by the NOP instructions was used. However, this is irrelevant in modern times because the program development usually is based on Assemblers nad manual coding is no more common.
• Another use for this instruction is that it could be used for producing short time delays if delay accuracy is not of concern.
HLT Instruction
• As the name implies, it “halts” the program; the processor enters the “HALT” state. • An interrupt or a hardware reset will force the 8086 out of the “HALT” state.
• May be used when the program has to wait for an interrupt to occur; but rarely used so in practice.
• In the early days, this instruction was used in the trainer kits as the last instruction of a user program. It is no more used in this fashion. In fact, presently it is rarely used for any other purpose either!
LOCK Prefix • LOCK can be prefix of an instruction.
• When such an instruction is executed, the LOCK/ pin of 8086 is activated (forced LOW). Now, another bus master can not gain control of the bus until the end of the “bus lock”. Thus the Lock prefixed instruction executes as an indivisible instruction even if it has several memory cycles. (Without the LOCK prefix, the bus could be taken over by another bus master after a memory cycle, even if the current instruction is not completed!)
• This feature is useful for implementing indivisible “read – modify-write” kind of operations that are necessary in multi-processor systems.
• Example:LOCK: XCHG AL, SEM1
The instruction is executed without the possibility of another bus master intervening. Instruction shown above can be used in implementing semaphores in a
multi-processor system.
Shift instructions
They manipulate binary numbers
Used to control I/O Devices. Shift operation moves the number either to left or right within memory location or a register. There are four instructions.There are two types of shift (1) arithmetic and (2) logical. The shift left operation is equivalent to multiply operation and shift right is divide operation. The data is shifted to left or right only by one position.
Shift left operation
Logical left: The contents of the register or memory location are shifted left by one position the MSB bit moves to Carry flag bit and a zero is added to the LSB position
Example SHL AX,1
AX=0000 1111 0000 1111 and Carry=1 After the execution of the instruction AX=0001 1110 0001 1110 and Carry =0 Example
MOV CL,3 SHL DX,CL
The contents of the DX register are shifted left by three postions Arithmetical Left: It is same as logical left shift.
Logical right: The contents of the register or memory location are shifted right by one position the LSB bit moves to Carry flag bit and a zero is added to the MSB position
Example SHR AX,1
AX=0000 1111 0000 1111 and Carry=0 Result
AX=0000 0111 1000 0111 and carry=1
Arithmetic right: The contents of the register or memory location are shifted right by one position the LSB bit moves to Carry flag bit and the sign bit is copied through the MSB position Example
SAL AX,1
AX=1000 0000 0000 1111 and carry=0 Result
AX=1100 0000 0000 0111 and carry=1 Example
SAR SI,3
SI= 1010 1100 1010 0101 C=0
After first shift SI= 1101 0110 0101 0010 C=1 second shift SI=1110 1011 0010 1001 C=0 third shift SI= 1111 0101 1001 0100 C=1 All condition flags are affected
Rotation instructions
There are four rotate instructions.
Rotate left: The contents of the memory location or the register are rotated left by the no of positions indicated in the instruction through the carry or without the carry.
ROL BL,4
Let BL=0001 0110 C=0
After first rotate C= 0 BL= 0010 1100 After second rotate C=0 BL= 0101 1000 After third rotate C=0 BL= 1011 0000 After fourth rotate C=1 BL= 0110 0000
Rotate right
The contents of the memory location or the register are rotated right by the no of positions indicated in the instruction through the carry or without the carry.
Assembly Language programming
Assembler: is a program that accepts an assembly language program as input and converts it into an object module and prepares for loading the program into memory for execution. Loader (linker) further converts the object module prepared by the assembler into executable
form, by linking it with other object modules and library modules.
The final executable map of the assembly language program is prepared by the loader at the time of loading into the primary memory for actual execution.
The assembler prepares the relocation and linkages information (subroutine, ISR) for loader. The operating system that actually has the control of the memory, which is to be allotted to
the program for execution, passes the memory address at which the program is to be loaded for execution and the map of the available memory to the loader.
Based on this information and the information generated by the assembler, the loader generates an executable map of the program and further physically loads it into the memory and transfers control to for execution.
Thus the basic task of an assembler is to generate the object module and prepare the loading and linking information.
Procedure for assembling a program
Assembling a program proceeds statement by statement sequentially.
The first phase of assembling is to analyze the program to be converted. This phase is called Pass1 defines and records the symbols, pseudo operands and directives. It also analyses the segments used by the program types and labels and their memory requirements.
The second phase looks for the addresses and data assigned to the labels. It also finds out codes of the instructions from the instruction machine, code database and the program data. It processes the pseudo operands and directives.
It is the task of the assembler designer to select the suitable strings for using them as directives, pseudo operands or reserved words and decides syntax.
Directives
Also called as pseudo operations that control the assembly process.
They indicate how an operand or section of a program to be processed by the assembler.
Assembler Memory models
Each model defines the way that a program is stored in the memory system. Tiny: data fits into one segment written in .COM format
Small: has two segments data and memory. There are several other models too.
Directive for string data in a memory segment
DB define byte
DW define word
DD define double word
DQ define 10 bytes Example
Data1 DB 10H,11H,12H
Data2 DW 1234H
SEGMENT: statement to indicate the start of the program and its symbolic name. Example Name SEGMENT Variable_name DB ……. Variable_name DW ……. Name ENDS Data SEGMENT Data1 DB ……. Data2 DW ……. Data ENDS Code SEGMENT
START: MOV AX,BX …
… … Code ENDS
Similarly the stack segment is also declared. For small models
.DATA … … ENDS
