TECHNICAL SPECIFICATION GUIDE

TC Series

Stellar

®

Service Crane

TC

(2)

TC SERIES TECHNICAL SPECIFICATION GUIDE

The Stellar TC Series of cranes offer a combination of European compact design and refinement with American control sensibilities. The TC Series is a tall mast telescopic crane commonly referred to as a "T-Boom" crane. The design offers ultimate compactness to take up minimal bed space, yet offers up to 18.6 feet of hydraulic reach to maximize the load radius of the larger models.

While these cranes are historically operated with a manual control valve requiring the operator to be near or under a suspended load, Stellar has Americanized these cranes through the use of the proprietary Stellar® CDT™ crane control system. Being a "Stellar® CDT™ Equipped" crane means the crane will have a handheld proportional radio remote transmitter with percentage of load feedback to the operator as a standard feature. With the use of the Stellar® CDT™ crane control system, the operator is able to better position themselves around the load and their work area. This means the operator has the ability to be in the best position they deem necessary to get their job done. You can see more on the CDT crane control system below.

The Stellar TC Series is normally powered by a PTO and pump located on the truck chassis. Stellar does offer an optional 12V power unit with integral hydraulic reservoir.

Stellar also offers suggested mounting designs for flatbed installations, as well as integral base systems to mount in the front of a truck body. Please consult with your Stellar Distributor on which system is right for you.

Stellar®CDTTMEquipped

The Stellar CDT equipped cranes will engage and communicate with the crane operator by using multiple sensory indicators when approaching maximum capacity. This will include the use of colored LED lights and pulsating vibrations on the handheld remote.

Remote Control

Stellar Industries was the first U.S. manufacturer to include the state-of-the-art fully proportional multi-functional remote control as a standard feature. The radio remote incorporates a variable speed trigger that allows the operators to feather the crane with precise control. It also has LED lights and the ability to vibrate to indicate capacities.

(3)

TC13 Crane

Crane Rating: Max Lifting Capacity: Max Reach: Slewing Angle: Slewing Torque: Operating Pressure: Pump Capacity: Shipping Weight: Standard Model TC13 2H 8,680 ft.lbs 2,400 lbs (1090 kg) 8.75 ft (2.67 m) 340° 2,390 ft.lbs 3.2 kNm (0.33 m) 2,755 psi 19.0 Mpa (190 bar) 2.5 US gal/min (9.5 I/min) 365 lbs (165 kg) Optional Model TC13 3H 8,680 ft.lbs 2,310 lbs (1050 kg) 11.18 ft (3.41 m) 340° 2,390 ft.lbs 3.2 kNm (0.33 m) 2,755 psi 19.0 Mpa (190 bar) 2.5 US gal/min (9.5 I/min) 412 lbs (187 kg)

TC23 Crane

Crane Rating: Max Lifting Capacity: Max Reach: Slewing Angle: Slewing Torque: Operating Pressure: Pump Capacity: Shipping Weight: Standard Model TC23 2H 16,635 ft.lbs 4,185 lbs (1900 kg) 9.94 ft (3.03 m) 340° 2,390 ft.lbs 3.2 kNm (0.33 m) 2,755 psi 19.0 Mpa (190 bar) 2.5 US gal/min (9.5 I/min) 498 lbs (226 kg Optional Model TC23 3H 16,635 ft.lbs 3,920 lbs (1780 kg) 13.22 ft (4.03 m) 340° 2,390 ft.lbs 3.2 kNm (0.33 m) 2,755 psi 19.0 Mpa (190 bar) 2.5 US gal/min (9.5 I/min) 540 lbs (245 kg)

TC33 Crane

Crane Rating: Max Lifting Capacity: Max Reach: Slewing Angle: Slewing Torque: Operating Pressure: Pump Capacity: Shipping Weight: Standard Model TC33 2H 23,145 ft.lbs 4,915 lbs (2230 kg) 11.97 ft (3.65 m) 340° 2,390 ft.lbs 3.2 kNm (0.33 m) 2,755 psi 19.0 Mpa (190 bar) 2.5 US gal/min (9.5 I/min) 706 lbs (320 kg) Optional Model TC33 3H 23,145 ft.lbs 4,650 lbs (2110 kg) 15.32 ft (4.67 m) 340° 2,390 ft.lbs 3.2 kNm (0.33 m) 2,755 psi 19.0 Mpa (190 bar) 2.5 US gal/min (9.5 I/min) 770 lbs (350 kg)

TC38 Crane

Crane Rating: Max Lifting Capacity: Max Reach: Slewing Angle: Slewing Torque: Operating Pressure: Pump Capacity: Shipping Weight: Standard Model TC38 4H 26,660 ft.lbs 4,520 lbs (2050 kg) 19.68 ft (6.00 m) 400° 2,390 ft.lbs 3.2 kNm (0.33 m) 2,755 psi 19.0 Mpa (190 bar) 2.5 US gal/min (9.5 I/min) 770 lbs (350 kg)

(4)

stellarindustries.com • TC13 REACH / CAPACITY ® Model TC13 3H 0 0 9.84 ft 3 m 9.84 ft 3 m 6.56 ft 2 m -6.56 ft -2 m 6.56 ft 2 m 3.28 ft 1 m -3.28 ft -1 m 3.28 ft 1 m 13.12 ft 4 m 1090 Kg 0.97 m 565 Kg1.82 m 400 Kg2.67 m 2400 lbs 3.18 ft 1245 lbs5.97 ft 880 lbs8.75 ft 0 0 9.84 ft 3 m -9.84 ft -3 m 9.84 ft 3 m 6.56 ft 2 m -6.56 ft -2 m 6.56 ft 2 m 3.28 ft 1 m -3.28 ft -1 m 3.28 ft 1 m 13.12 ft 4 m 16.40 ft 5 m 13.12 ft 4 m 1050 Kg 1.02 m 550 Kg1.87 m 390 Kg2.72 m 320 Kg3.41 m 2310 lbs 3.34 ft 1210 lbs6.13 ft 855 lbs8.92 ft 11.18 ft705 lbs Model TC13 2H • TC23 REACH / CAPACITY Model TC23 3H 0 0 9.84 ft 3 m 9.84 ft 3 m 6.56 ft 2 m -6.56 ft -2 m 6.56 ft 2 m 3.28 ft 1 m -3.28 ft -1 m 3.28 ft 1 m 13.12 ft 4 m 16.40 ft 5 m 13.12 ft 4 m 1900 Kg 1.16 m 1010 Kg2.09 m 715 Kg3.03 m 4185 lbs 3.80 ft 2225 lbs6.85 ft 1575 lbs9.94 ft 0 0 9.84 ft 3 m 9.84 ft 3 m 6.56 ft 2 m -6.56 ft -2 m 6.56 ft 2 m 3.28 ft 1 m -3.28 ft -1 m 3.28 ft 1 m 13.12 ft 4 m 16.40 ft 5 m 19.68 ft 6 m 16.40 ft 5 m 13.12 ft 4 m -9.84 ft -3 m 1780 Kg 1.22 m 960 Kg2.16 m 685 Kg3.09 m 530 Kg4.03 m 3920 lbs 4.00 ft 2115 lbs7.08 ft 1510 lbs10.13 ft 1165 lbs13.22 ft Model TC23 2H

TC

13

13 TC

TC

23

(5)

TC SERIES TECHNICAL SPECIFICATION GUIDE

• TC33 REACH / CAPACITY Model TC33 3H 0 0 9.84 ft 3 m 9.84 ft 3 m 6.56 ft 2 m -6.56 ft -2 m _{6.56 ft} 2 m 3.28 ft 1 m -3.28 ft -1 m 3.28 ft 1 m 13.12 ft 4 m 16.40 ft 5 m 13.12 ft 4 m 890 Kg 3.65 m 1245 Kg 2.55 m 2230 Kg 1.45 m 1960 lbs 11.97 ft 2740 lbs 8.36 ft 4915 lbs 4.75 ft 0 0 9.84 ft 3 m 9.84 ft 3 m 6.56 ft 2 m -6.56 ft -2 m 6.56 ft 2 m 3.28 ft 1 m -3.28 ft -1 m 3.28 ft 1 m 13.12 ft 4 m 16.40 ft 5 m 19.68 ft 6 m 16.40 ft 5 m 13.12 ft 4 m -9.84 ft -3 m 2110 Kg 1.53 m 1190 Kg2.63 m 850 Kg3.73 m 700 Kg4.67 m 4650 lbs 5.01 ft 2620 lbs8.62 ft 1870 lbs12.23 ft 1540 lbs15.32 ft Model TC33 2H • TC38 REACH / CAPACITY 0 0 9.84 ft 3 m 9.84 ft 3 m 6.56 ft 2 m -6.56 ft -2 m 6.56 ft 2 m 3.28 ft 1 m -3.28 ft -1 m 3.28 ft 1 m 13.12 ft 4 m -13.12 ft -4 m 16.40 ft 5 m 19.68 ft 6 m 19.68 ft 6 m 22.96 ft 7 m 16.40 ft 5 m 13.12 ft 4 m -9.84 ft -3 m 1200 Kg 2.90 m 855 Kg4.00 m 660 Kg5.00 m 555 Kg6.00 m 2050 Kg 1.80 m 2645 lbs 9.51 ft 1885 lbs13.12 ft 1455 lbs16.40 ft 1225 lbs19.68 ft 4520 lbs 5.90 ft Model TC38 4H

TC

TC33

33 TC

TC38

38

(6)

190 State Street P.O. Box 169 Garner, IA 50438 Telephone: (641) 923-3741 • (800) 321-3741 Fax: (641) 923-2812 Internet: www.stellarindustries.com Email: [email protected] An Employee Owned Company.

Our People. Our Products.

®

Your local distributor:

OPTIONAL STABILIZER 132.75 42.88 19.88 8.38 26.63 54.88 77.88 35.00 8.00 15.86 2.39 14.50 4.36 14.75 137.00 70.00 20.56 6.63 33.56
