Wiring Accessories

n

Extensive range of switches, sockets, dimmers, media & data accessories

n

5mm deep mounting plate

n

Metal back plate

n

USB outlets 5V/2.1A

n

Front plate supplied with protective film

n

Made in UK

n

Available in a wide range of colours

Accessories mounted on robust metal grid providing

superior strength

Housing made of high quality thermo plastic

material Snap-on front plate

A range of slim profile, durable screwless wiring accessories offering a stylish solution for the home,

hotel and office applications.

(3)

WH White* SM Silver Matt* SG Silver Glossy* BG Black Glossy*

CH Champagne PL Pearl GN Green PK Pink PR Purple

BS Brass GG Gold Glossy GM Gold Matt CG Copper Glossy CM Copper Matt

Product Colours (- -) t

--Please specify the required option by adding the reference code as shown below

Full Product

Colour Code

White Insert t

Replacement Front Plate Only Colour Code t Plate 1 Plate 2 Plate 3 Plate 4 Plate 5 Plate 6 Plate 7 Plate 8 MAY4711- - W SS Stainless Steel MAYP01- - W MAYP02- - W MAYP03- - W MAYP04- - W MAYP05- - W MAYP06- - W MAYP07- - W MAYP08- - W

OPTION 1 OPTION 2

Colour Options

(4)

Mayfair

Wiring Accessories

Switches

10AX Switches

MAY4711WHW 1 Gang 1 Way 10AX Plate 1 MAY4712WHW 1 Gang 2 Way 10AX Plate 1 MAY4721WHW 2 Gang 1 Way 10AX Plate 1 MAY4722WHW 2 Gang 2 Way 10AX Plate 1 MAY4731WHW 3 Gang 1 Way 10AX Plate 1 MAY4732WHW 3 Gang 2 Way 10AX Plate 1 MAY4741WHW 4 Gang 1 Way 10AX Plate 2 MAY4742WHW 4 Gang 2 Way 10AX Plate 2

45A Switches

MAY4757WHW 1 Gang 45A DP Switch With Indicator (1G Plate) Plate 1 MAY4747WHW 1 Gang 45A DP Switch With

Indicator (2G Plate) Plate 4

MAY4711WHW MAY4712WHW MAY4736WHW MAY4713WHW MAY4757WHW MAY4799WHW MAY4747WHW MAY4721WHW MAY4722WHW MAY4731WHW MAY4732WHW MAY4741WHW MAY4742WHW

Bell Push & Fan Isolator

MAY4736WHW 1 Gang 10AX Bell Push Plate 1 MAY4713WHW 10AX Fan Isolator 3 Pole Switch

Plate 1

20A Switches

MAY4810WHW 1 Gang 20A Intermediate Switch

Plate 1

MAY4812WHW 1 Gang 2 Way 20A Switch Plate 1 MAY4815WHW 1 Gang 20A DP With Indicator

Plate 1

MAY4799WHW* 1 Gang 20A DP Flex Outlet

With Indicator Plate 1

Card Reader Switch

MAY4711KSWHW 16A Card Reader Switch With

Indicator Plate 3

MAY4711KSWHW

Fits 25mm back box

Fits 25mm back box

Fits 35mm back box

Fits 25mm back box *Fits 35mm back box

Fits 35mm back box For more colour options please see the colour chart.

(5)

USB & Connection Units

Dimmers

13A Connection Units

MAY4368WHW 13A Switched DP Flex Outlet

Plate 1

MAY4369WHW 13A Switched DP Flex Outlet With Indicator Plate 1

Dimmers

MAY4614/2WHW 1 Gang 2 Way 400W 50Hz

Push on/off Rotary Dimmers

Plate 1

MAY4615/2WHW 1 Gang 2 Way 500W 60Hz

Push on/off Rotary Dimmers

Plate 1

MAY4611/1WHW* 1 Gang 1 Way 1000W 60Hz

Push on/off Rotary Dimmers

Plate 1

USB Socket Outlet

13A Socket Outlets

MAY6342WHW 2 Gang 2 USB Socket 5V/2.1A

Plate 1

MAY4345WHW 1 Gang 13A Socket Plate 1 MAY4347WHW 1 Gang 13A DP Switched Socket With Indicator Plate 5 MAY4356WHW 2 Gang 13A DP Switched Socket Plate 6

Sockets

MAY4614/2WHW MAY4345WHW

MAY4347WHW

15A Socket Outlet

MAY4337WHW 1 Gang 15A DP Switched Socket With Indicator Plate 7

MAY4356WHW

MAY6342WHW

MAY4369WHW

Fits 35mm back box *Fits 47mm back box

Fits 25mm back box

Fits 35mm back box

Fits 35mm back box Fits 35mm back box

MAY4337WHW MAY4615/2WHW

(6)

Telephone, Data & Satellite Outlets

MAY4147WHW 1 Gang 75 Ohm Angular TV

Plate 1

MAY4149WHW 1 Gang 75 Ohm Angular Sat.

Plate 1

MAY4150WHW 1 Gang 75 Ohm Angular TV &

Sat. Plate 1

MAY4807WHW 1 Gang RJ11 (6P4C) Plate 1 MAY4808WHW 2 Gang RJ11 (6P4C) Plate 1 MAY4190WHW 1 Gang RJ45 CAT6 Data Socket Plate 1 MAY4191WHW 2 Gang RJ45 CAT6 Data Socket Plate 1

Telephone, Data & Satellite Outlets

Blank & Data Plates

Blank & Data Plates

MAY4880WHW 1 Gang RJ45 CAT6 & RJ11 Jack

Plate 1

MAY4849WHW 1 Gang Sat 75Ohm & RJ11 Jack

Plate 1

MAY4169WHW 1 Gang Telephone Master

Plate 1

MAY4170WHW 1 Gang Telephone Secondary

Plate 1

MAY4017WHW 1 Gang Blank Plate Plate 1 MAY4027WHW 2 Gang Blank Plate Plate 2 MAY4117WHW* 1 Gang 2 Module Data Plate

Plate 8

MAY4127WHW* 2 Gang 4 Module Data Plate

Plate 9 MAY4880WHW MAY4147WHW MAY4849WHW MAY4191WHW MAY4150WHW MAY4190WHW

Telephone, Data & Satellite Outlets

MAY4017WHW

MAY4027WHW

*To be used with Contactum Data Modules from the media range. See main catalogue for more details Fits 25mm back box

Fits 35mm back box

Fits 35mm back box

For more colour options please see the colour chart.

Mayfair

(7)

E1153W TV/SAT White

E1158W TV/Radio White

E1160W TV/Radio/SAT White

E1161W TV/Radio/SAT/SAT White

E6342W USB A+A 5V/2.1A White

Euro Modules (50 x 50)

Euro Modules

Euro Modules (25 x 50)

E1169W BT Master White

E1170W BT Slave White

E1180W RJ45 CAT5E White

E1181W RJ45 CAT6 White

E1182W RJ45 CAT6A White

E1117W RJ11 Western Electric line Jack

E1091W Brush 25mm White

E1092W Brush 50mm White

E1194W Brush 100mm White

E1147W E1181W E1091W E1169W E1158W

Euro Modules (25 x 50)

E1142W Speaker White

E1143W Phono White

E1146W TV Male White

E1147W TV Female White

E1151W F Connector White

E1187W Blank White

E7341W USB A+C 5V/3.1A White E1195W HDMI White

E7341W E1195W

Euro Module Data Plates

ALF4117WHW* 1 Gang 2 Mod Data ALF4127WHW* 2 Gang 4 Mod Data

E1161W

(8)

Contactum Ltd, Victoria House, 2 Blackmoor Lane, Croxley Green, Watford WD18 8GA

T: 020 8208 7419 E: [email protected] www.contactum.co.uk

M

AY04/18 (0121)
