(12) United States Patent
Nguyen
(54) VARIABLE CAMBER CONTINUOUS
AERODYNAMIC CONTROL SURFACES AND METHODS FOR ACTIVE WING SHAPING
CONTROL
(71) Applicant: The United States of America as Represented by the Administrator of the National Aeronautics & Space Administration (NASA), Washington, DC (US)
(72) Inventor: Nhan T. Nguyen, Santa Clara, CA (US)
(73) Assignee: The United States of America as Represented by the Administrator of the National Aeronautics & Space Administration (NASA), Washington, DC (US)
(*) Notice: Subject to any disclaimer, the term of this patent is extended or adjusted under 35 U.S.C. 154(b) by 409 days.
(21) Appl. No.: 13/648,197
(22) Filed: Oct. 9, 2012
Related U.S. Application Data
(60) Provisional application No. 61/628,299, filed on Oct.
7, 2011. (51) Int. Cl. B64C 3150 (2006.01) B64C 3114 (2006.01) B64C 9120 (2006.01) B64C 9114 (2006.01) (52) U.S. Cl. CPC ... B64C 9114 (2013.01); B64C 3114 (2013.01); B64C 3150 (2013.01); B64C 9120 (2013.01)
(58) Field of Classification Search
CPC ... B64C 3/50; B64C 3/48; B64C 3/44; B64C 3/38; B64C 3/14; 1364C3/10; B64C
2003/142; B64C 2003/147; B64C 9/20;
(1o)
Patent No.:
US 9,227,721 B1
(45) Date of Patent
:Jan. 5, 2016
B64C 9/16; B64C 9/12; B64C 9/10; B64C
9/04
See application file for complete search history.
(56) References Cited
U.S. PATENT DOCUMENTS
4,796,192 A * 1/1989 Lewis ... 244/76 R 5,082,207 A * 1/1992 Tulinius ... 244/195 5,797,105 A * 8/1998 Nakaya et al . ... 244/177 6,161,801 A * 12/2000 Kelm et al . ... 244/195 6,209,824 131 4/2001 Caton et al. 7,004,428 132 * 2/2006 Tracy et al . ... 244/35 R 7,455,264 132 * 11/2008 Wakayama ... 244/215 7,878,459 132 2/2011 Mabe et al. 8,056,865 132 11/2011 Grip 8,118,264 132 2/2012 Mabe et al. 2008/0149779 Al* 6/2008 Phillips ... 244/201 * cited by examiner
Primary Examiner Tien Dinh
Assistant Examiner Richard R Green
(74) Attorney, Agent, or Firm Christopher J. Menke; Robert M. Padilla
(57) ABSTRACT
An aerodynamic control apparatus for an airvehicle improves various aerodynamic performance metrics by employing multiple spanwise flap segments that jointly form a continu-ous or a piecewise continucontinu-ous trailing edge to minimize drag induced by lift or vortices. At least one of the multiple span-wise flap segments includes a variable camber flap subsystem having multiple chordwise flap segments that may be inde-pendently actuated. Some embodiments also employ a con-tinuous leading edge slat system that includes multiple span-wise slat segments, each of which has one or more chordspan-wise slat segment. A method and an apparatus for implementing active control of a wing shape are also described and include the determination of desired lift distribution to determine the improved aerodynamic deflection of the wings. Flap deflec-tions are determined and control signals are generated to actively control the wing shape to approximate the desired deflection.
18 Claims, 39 Drawing Sheets
