Deploying an Optimized
Windows Desktop
Greg Milligan
Command line tools
Windows 7 Deployment Opportunities
Imaging
Deployment Image Servicing and Management
Add/Remove Drivers and Packages
WIM and VHD Image Management
Delivery
Windows
Deployment Services
Multiple Stream Transfer Dynamic Driver Provisioning
VHD and WIM Support
Migration
User State Migration Tool
Hardlink Migration Offline File Gather Improved user file detection
Microsoft Assessment and Planning Application Compatibility Toolkit Microsoft Deployment Toolkit
Integrated Solutions
Enhanced Deployment Toolset
User State Migration Tool Volume Activation
ImageX, Deployment Image Servicing and Management, WinPE
7
Dependencies Create Complexity
Hardware
OS
Data, User
settings
8
9
One size does not fit all
The need for Well Managed Desktop Strategy
Rich Client TS Remote Client Virtualized Applications VDI or Blade PC Contract / Offshore Task Mobile Office Anywhere -on non company PC
Primary Image Types
Near Retail Few or no configuration changes or apps Fully Customized Includes applications, driver payloads, configurations Lightly Customized Includes some applications and otherWindows Image Format (WIM)
Capabilities
• File-based vs.
Sector-Based
• Single instancing
• Install disk images on
partitions of any size
• Hardware agnostic
• Modify images offline
• Non-destructive
deployment
Benefits
• 1 to 3 images can be
achieved
• Work on any corporate
supported hardware
• Work in any region
• Store multiple image in a
single WIM
• Ability to provide the right
apps for most users
• Require minimum labor
and downtime
• Balance static vs. dynamic
requirements
• Drivers – Can be injected
or serviced offline now
12
Significant improvements to existing scenarios
Increased range of scenario support
Windows OS Deployment
New machine
-Clean install -Wipe and Load -No migration considerations - New or repurposed hardware Wipe-and-load - Target and install new OS to existing H/W - Application reinstall under new OS - Securely save/restore user state & settings
Side-by-side
- Machine to machine
- User and app data migration
- Application
reinstall -Securely save/restore user state & settings In-place migration - Scripted, targeted OS upgrade
- Not wipe and load - Sent as software distribution package Offline with removable media - Install without network - Removable media is source - CD/DVD,USB flash drive
- Good for low
bandwidth, mobile staff PXE boot - WDS integration, network boot delivered - PXE style delivery - Lite touch, network connection based
Deployment Strategy
Lite-Touch, High-Volume
Deployment
Zero-Touch, High-Volume
Deployment
High-Touch with
Retail Media
High Touch with
Standard Image
Bridging Compatibility Through Virtualization
Hosted
Applications
Desktop
Virtualization
Application
Virtualization
16
Current Deployment vs. App-V Provisioning
Office 2010 Deployment Tools
System Readiness
• Inventory Office Applications • Assess hardware & OS readiness • Suggests key upgrades
• Summary proposal of 2010 readiness
Application Compatibility
• Identify interfacing add-ins & interfaces • Tag known compatible apps
• Mitigate VBA and macro code
File Readiness
• Scan & identify potential format deltas • Identify potential macro issues
• Migrate Office files to OpenXML formats • Microsoft Assessment
Planning Toolkit (MAP)
• Office Environment Assessment
Tool (OEAT)
• Office Compatibility Code
Inspector (OCCI)
• Office Migration Planning
Manager (OMPM)
Guidance
• Desktop Deployment Planning Service (SA)
• Training Vouchers (SA)
• Office Resource Kit (ORK) • TechNet Resource Centers
19
Common Perceptions
Activation is
unnecessary and has
no benefit to me
We don’t have
counterfeit software
in our environment
License compliance continues
to be one of the top 10 issues
rated by CIOs
Perception
Fact
Evidence
Helps confirm license integrity,
reliability of the software and
improves manageability
2008, U.S. enterprise
customers self-report 30% mislicensing
SoftSummit– 2008 Key Trend Survey
“Counterfeit software…can infect entire business
networks with viruses and install Trojan horses
designed to steal data”
John Gantz CTO -IDC
Activation is too
complex and hard
• Transparent to end-users
• Integrated into deployment
with flexible admin control
• Automated reporting and
management
The Yankee Group
“Microsoft’s Genuine is open and straightforward”
Common Education Questions
We are very decentralized – how many sets of
product keys will I receive?
What if a faculty member leaves campus to go on
Sabbatical?
How can I manage student licenses?
How many KMS hosts should I deploy?
Should I mix activation types? Can I use only one
type?
21
Volume Activation for Windows 7
Multiple Activation Key
(MAK) – Upper Limit
One time activation against
Microsoft
30 day initial activation period.
Can be reset up to 3 times
(Slmgr
–rearm)
Two methods of activating using a
MAK:
1.
Individual Activation: Each
desktop individually connects
and activates with Microsoft
2.
Proxy Activation: One
centralized activation request
on behalf of multiple desktops
with one connection to
Microsoft
Key Management Service
(KMS) – No upper limit
Activate against a customer
hosted service
Systems must re-activate by
connecting to corporate
networks at least every 6
months
Requires 25 Windows 7
machines as a minimum
threshold to activate
22
Multiple Activation Key
MAK key available to volume
license customers on request
Install the MAK on the client
Directly
Provisioned by the IT Pro
(Image or Proxy)
Activate with Microsoft
Online (directly or via Proxy)
Phone
Perpetual activation
Some conditions may require
reactivation
Microsoft Hosted Activation Services IntranetVAMT
ImageO n e T i m e
23
MAK Key Groupings
Windows Vista Business Windows Vista Enterprise
MAK keys are
lateral
in nature
Product keys for MAK activations
are
directly associated with a
single product group
and can
only activate the Windows
editions
within
that specific
product group
Each “generation” has a
specific
MAK (e.g. Windows 7 client VL
MAK will only activate Windows 7,
not Windows Vista)
Windows 7 Professional Windows 7 Enterprise
Windows Server Web 2008 Windows HPC Server 2008
Windows Server Web 2008 R2 Windows Server 2008 R2 HPC
Windows Server 2008 Standard Windows Server 2008 Enterprise
Windows Server 2008 R2 Standard Windows Server 2008 R2 Enterprise
Windows Server 2008 Datacenter Windows Server 2008 for Itanium
Windows Server 2008 R2 Datacenter Windows Server 2008 R2 for Itanium
24
Count
Request
KMS Host
Key Management Service
MicrosoftHosted Activation Services
KMS key automatically available to
customers via normal channels
Install KMS key on KMS host machine
Activate KMS service with Microsoft
One-time activation of KMS host KMS host registers SRV with DNS
(VLMCS._TCP)
KMS client discovers KMS host
KMS client activates based on policy
- KMS count ≥ activation threshold
KMS client regularly reactivates
- Non-perpetual activation (180 days)
- Communication between KMS host and
KMS client is never exposed to Microsoft
KMS Client
Intranet
O n e T i m e
25
Windows Server 2008 Standard Windows Server 2008 Enterprise
Windows Server Web 2008 Windows HPC Server 2008
Windows Vista Business Windows Vista Enterprise
KMS Host Key Hierarchy
Windows Server 2008 Datacenter Windows Server 2008 for Itanium
Windows Server 2008 R2 Datacenter Windows Server 2008 R2 for Itanium
Windows 7 Professional Windows 7 Enterprise
Windows Server Web 2008 R2 Windows Server 2008 R2 HPC Windows Server 2008 R2 Standard Windows Server 2008 R2 Enterprise
KMS keys are
hierarchical
in
nature
Single KMS host
to support
multiple products
Each key
activates the
products
in that
group
, as well as
the groups
lower
26
Deployment Improvements
Key Management Service (KMS)
• Single KMS to support Windows Vista, Windows
Server 2008, Windows 7 and Windows Server 2008
R2
• KMS host now counts virtual machines
• Enabled KMS to support multiple applications (i.e.
Office 2010)
Better Integration with DNS
• DNS Suffix Search List
27
Volume Activation Management Tool
Simple Graphical User Interface
Performs both MAK Proxy and MAK Independent activation
Provides activation status of all machines in the environment
Enables local reactivation and monitoring of MAK usage
Supports discovery of machines in the environment
Requires remote WMI access
Active Directory (AD), workgroup, and individual (by IP address and
Machine Name) discovery of machines in the environment.
Stores all data in a well defined XML format
Allows for Import/Export of data
VAMT allows for “Exclude sensitive data” option for Computer
Information List (CIL)
VAMT ver. 3.0 is part of the Windows Automated Installation Kit
(AIK)
28
Dogfooding KMS @ Microsoft
One KMS host supporting all Windows 7 and
Windows Server 2008 R2 RTM
The machine started receiving 12290 events 7/23/2009
3:31:53PM and at 7/24/2009 10:42:35AM it had 11,569
events.
That's 11569/19.2 = 603.23 hits per hour.
4350 KMS clients have been activated
The KMS host machine is a 2.33GHz Core2 Duo with
2GB of RAM. Casually observing CPU usage show it is
almost always at 0 with occasional blips to 15 or
28, while the memory usage stays steady at
6.8MB*.
One KMS host supporting Office 2010 and
Windows
Answers to Common Questions
We are very decentralized – how many sets of product keys will I receive?
You will receive 1 KMS key and 1 MAK per license agreement. At this time we cannot assign multiple keys per license agreement.
What if a faculty member leaves campus to go on Sabbatical?
The member’s machine can be MAK activated, allowing it to roam away from the main network.
How can I manage student licenses?
KMS-activated machines ensure that the student remains on campus during the license term. If the student qualifies for a perpetual license at graduation, the
student may receive a unique retail product key and permanently activate their own machine.
How many KMS hosts should I deploy?
By default, each KMS key allows deployment of 2 KMS hosts. However your account manager can acquire additional activations at your request. You can deploy as many KMS hosts as you like as long as none of them are on unsecured networks allowing unauthorized machines to activate.
Should I mix activation types? Can I use only one type?
You should use whatever mix of activation types suits your deployment best.
How do I convert from one type to another?
Conversion from KMS MAK is achieved by changing the PK in the UI or via a script. A machine can switch types as often as you like.
30
Configuration Recommendations
Principles
Use KMS as much as possible, and minimize the
number of KMS hosts
Central KMS for all, if politically possible
Two hosts should be sufficient for most
Best solution for virtual machines
Use MAK only where needed
OK in small organizations/deployments
In medium and large orgs, use MAK only where you
cannot use KMS
Customers will probably need to use both methods
KMS port (1688 by default) should never be
exposed outside the organization
Access to a KMS host is the same as handing out
free volume licenses
